Panasonic HDC-SDT750 User manual

Operating Instructions
คูมือการใชงาน
High Definition Video Camera
กลองถายวิดีโอความละเอียดสูง
Model No. HDC-SDT750
HDC-TMT750
Before use, please read these instructions completely.
โปรดอานคูมือใหละเอียดกอนใชงาน
Please also refer to the Operating Instructions (PDF format)
contained on the CD-ROM (supplied).
You can learn about advanced operation methods and check the
Troubleshooting.
กรุณาอานรายละเอียดจากคําแนะนําในการใชงาน (ไฟลPDF) ที่จัดเก็บไวในแผน CD-ROM (จัดมาให)
คุณสามารถดูวิธีการใชงานขั้นสูงและตรวจสอบวิธีการแกไขปญหาเพิ่มเติมได
until
2010/9/16
VQT3B29
S-HDC-SDT750&TMT750GC_mst.book 1 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

2
VQT3B29 (ENG)
Information for Your Safety
∫Concerning the battery
Button-type battery: CR2025
For Australia and New Zealand
IF THE POWER CORD OF THIS
EQUIPMENT IS DAMAGED, IT MUST BE
REPLACED WITH AN ELECTRICALLY
APPROVED POWER CORD.
WARNING:
TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK OR PRODUCT
DAMAGE,
≥DO NOT EXPOSE THIS APPARATUS
TO RAIN, MOISTURE, DRIPPING OR
SPLASHING AND THAT NO
OBJECTS FILLED WITH LIQUIDS,
SUCH AS VASES, SHALL BE
PLACED ON THE APPARATUS.
≥USE ONLY THE RECOMMENDED
ACCESSORIES.
≥DO NOT REMOVE THE COVER (OR
BACK); THERE ARE NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION!
≥DO NOT INSTALL OR PLACE THIS
UNIT IN A BOOKCASE, BUILT-IN
CABINET OR IN ANOTHER
CONFINED SPACE. ENSURE THE
UNIT IS WELL VENTILATED. TO
PREVENT RISK OF ELECTRIC
SHOCK OR FIRE HAZARD DUE TO
OVERHEATING, ENSURE THAT
CURTAINS AND ANY OTHER
MATERIALS DO NOT OBSTRUCT
THE VENTILATION VENTS.
≥DO NOT OBSTRUCT THE UNIT’S
VENTILATION OPENINGS WITH
NEWSPAPERS, TABLECLOTHS,
CURTAINS, AND SIMILAR ITEMS.
≥DO NOT PLACE SOURCES OF
NAKED FLAMES, SUCH AS
LIGHTED CANDLES, ON THE UNIT.
≥DISPOSE OF BATTERIES IN AN
ENVIRONMENTALLY FRIENDLY
MANNER.
The socket outlet shall be installed near
the equipment and easily accessible.
The mains plug of the power supply cord
shall remain readily operable.
To completely disconnect this apparatus
from the AC Mains, disconnect the power
supply cord plug from AC receptacle.
Warning
Risk of fire, explosion and burns. Do not
disassemble.
Do not heat the batteries above the
following temperatures or incinerate.
Button-type battery 60 oC
Battery pack 60 oC
CAUTION
Danger of explosion if battery is
incorrectly replaced. Replace only with
the same or equivalent type
recommended by the manufacturer.
Dispose of used batteries according to
the manufacturer’s instructions.
Warning
Keep the Button-Type battery out of the
reach of children. Never put Button-Type
battery in mouth. If swallowed call your
doctor.
S-HDC-SDT750&TMT750GC_mst.book 2 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

3
(ENG) VQT3B29
∫Product identification marking
-If you see this symbol-
∫Cautions for use
For Australia and New Zealand
In the event of abnormal operation (e.g. if
the unit emits smoke or an unusual smell),
immediately stop operating the unit and
consult the Panasonic Customer Care
Centre on 132600.
Keep this unit as far away as possible
from electromagnetic equipment (such
as microwave ovens, TVs, video games
etc.).
≥If you use this unit on top of or near a TV,
the pictures and/or sound on this unit may
be disrupted by electromagnetic wave
radiation.
≥Do not use this unit near cell phones
because doing so may result in noise
adversely affecting the pictures and/or
sound.
≥Recorded data may be damaged, or
pictures may be distorted, by strong
magnetic fields created by speakers or
large motors.
≥Electromagnetic wave radiation generated
by microprocessors may adversely affect
this unit, disturbing the pictures and/or
sound.
≥
If this unit is adversely affected by
electromagnetic equipment and stops
functioning properly, turn this unit off and
remove the battery or disconnect AC
adaptor. Then reinsert the battery or
reconnect AC adaptor and turn this unit on.
Do not use this unit near radio
transmitters or high-voltage lines.
≥If you record near radio transmitters or
high-voltage lines, the recorded pictures
and/or sound may be adversely affected.
About connecting to a PC
≥Do not use any other USB cables except
the supplied one.
Product Location
High Definition
Video Camera Battery holder
AC adaptor Bottom
How to replace the fuse
The location of the fuse differ according
to the type of AC mains plug (figures A
and B).
Confirm the AC mains plug fitted and
follow the instructions below.
Illustrations may differ from actual AC
mains plug.
1) Open the fuse cover with a
screwdriver.
2) Replace the fuse and close or attach
the fuse cover.
Information on Disposal in other
Countries outside the European
Union
This symbol is only valid
in the European Union.
If you wish to discard
this product, please
contact your local
authorities or dealer
and ask for the correct
method of disposal.
English
S-HDC-SDT750&TMT750GC_mst.book 3 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

4
VQT3B29 (ENG)
∫Indemnity about recorded
content
Panasonic does not accept any
responsibility for damages directly or
indirectly due to any type of problems that
result in loss of recording or edited content,
and does not guarantee any content if
recording or editing does not work properly.
Likewise, the above also applies in a case
where any type of repair is made to the unit.
∫Cards that you can use with
this unit
SD Memory Card, SDHC Memory Card
and SDXC Memory Card
≥4 GB or more Memory Cards that do not
have the SDHC logo or 48 GB or more
Memory Cards that do not have the SDXC
logo are not based on SD Memory Card
Specifications.
≥Refer to page 16 for more details on SD
cards.
∫For the purposes of these
operating instructions
≥SD Memory Card, SDHC Memory Card
and SDXC Memory Card are referred to
as the “SD card”.
≥Functions that can be used for motion
picture recording/motion picture playback
are indicated by in these
operating instructions.
≥Functions that can be used for still picture
recording (including the still picture
recording in motion picture recording
mode)/still picture playback are indicated
by in these operating
instructions.
≥Pages for reference are indicated by an
arrow, for example: l00
These operating instructions are designed
for use with models and
. Pictures may be slightly
different from the original.
≥The illustrations used in these operating
instructions show model ,
however, parts of the explanation refer to
different models.
≥Depending on the model, some functions
are not available.
≥Features may vary, so please read
carefully.
≥Not all models may be available
depending on the region of purchase.
S-HDC-SDT750&TMT750GC_mst.book 4 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

5
(ENG) VQT3B29
PreparationBasicAdvancedOthers
Information for Your Safety.....................2
Accessories..............................................6
Preparation
Before using
[1] Parts identification
and handling................................. 8
Setup
[1] Power supply.............................. 12
Charging the battery .................... 12
Inserting/removing the battery ..... 13
Charging and recording time........ 14
Connecting to the AC outlet ......... 15
[2] Recording to a card ................... 16
Cards that you can use with
this unit......................................... 16
Inserting/removing an SD card .... 17
[3] Turning the unit on/off ............... 18
Turning the unit on and off with
the power button .......................... 18
Turning the unit on and off with
the LCD monitor/viewfinder.......... 18
[4] Selecting a mode ....................... 19
[5] Adjusting LCD monitor/
viewfinder ................................... 20
How to use the touch screen ....... 20
Viewfinder adjustment.................. 20
[6] Setting date and time................. 21
Basic
Recording/Playback
[1] Selecting a media to record
[HDC-TMT750] ............................ 22
[2] Recording motion pictures ....... 23
[3] Recording still pictures ............. 24
[4] Intelligent auto mode ................. 25
[5] Motion picture/
Still picture playback ................. 26
Setup
[1] Using the menu screen ............. 28
Language selection...................... 28
Advanced
Recording (Advanced)
[1] Zoom in/out function ................. 29
Zoom mode.................................. 29
Ring zoom.................................... 30
Extra optical zoom ....................... 30
[2] Image stabilizer function........... 31
Optical image stabilizer lock ........ 31
[3] Recording 3D video ................... 32
Functions not available during
3D recording ................................ 36
Editing
[1] Deleting scenes/
still pictures................................ 37
[2] Formatting .................................. 38
With a TV
[1] Watching Video/Pictures
on your TV .................................. 39
[2] 3D video playback ..................... 41
Functions not available during
3D playback ................................. 42
Others
Specifications ........................................43
About copyright.....................................48
Reading the Operating Instructions
(PDF format) ........................................... 49
Contents
S-HDC-SDT750&TMT750GC_mst.book 5 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

6
VQT3B29 (ENG)
Accessories
Check the accessories before using this unit.
Keep the accessories out of reach of children to prevent swallowing.
Product numbers correct as of Aug. 2010. These may be subject to change.
Battery pack
VW-VBG130
AC adaptor
VSK0698
AC cable
AK2CT39A00002
BK2CJ29A00002
( only)
CK2CQ29A00002
AHong Kong Special Administrative
Region of China and Saudi Arabia
BAustralia and New Zealand
CAreas Other than Hong Kong Special
Administrative Region of China, Saudi
Arabia, Australia and New Zealand
DC cable
K2GJYDC00004
Remote control
(Battery built-in)
N2QAEC000024
AV multi cable
K1HY12YY0004
USB cable
K1HY04YY0032
HDMI mini cable
VFA0531
Stylus pen
VGQ0C14
Lens hood
VDW2053
Shoe adaptor
VYC0996
CD-ROM
Software
CD-ROM
Operating Instructions
VFF0705
3D Conversion Lens
Lens storage bag
VFC4619
Lens front cap*
VYK4K64
Lens rear cap*
VGQ0M57
* This is attached to the 3D Conversion
Lens at the time of purchase.
S-HDC-SDT750&TMT750GC_mst.book 6 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

7
(ENG) VQT3B29
Product numbers correct as of Aug. 2010.
These may be subject to change.
Some optional accessories may not be
available in some countries.
Optional accessories
AC adaptor (VW-AD21E/EB-K)*1
Battery pack (lithium/VW-VBG130)
Battery pack (lithium/VW-VBG260)
Battery pack (lithium/VW-VBG6)*2
Battery pack holder kit (VW-VH04)
HDMI mini cable (RP-CDHM15,
RP-CDHM30)
Wide conversion lens (VW-W4607H)
Wide end conversion lens (VW-WE08H)*3
Filter kit (VW-LF46NE)*4
Video DC light (VW-LDC103E)
Light bulb for video DC light (VZ-LL10E)
Stereo microphone (VW-VMS2E)*5
Shoe adaptor (VW-SK12E)
DVD burner (VW-BN2)
DVD burner (VW-BN01)
*1 The supplied DC cables cannot be
used on this unit.
*2 The battery pack holder kit/VW-VH04
(optional) is necessary.
*3 When using the VW-WE08H, set the
zoom to W (wide) side. The focus will
be slightly out when it is set to T (tele)
side, so remove the VW-WE08H when
recording set to T (tele) side.
*4 When using the VW-LF46NE, remove
the lens hood (supplied) and set to the
flash setting to (OFF).
*5 External microphone may intrude into
the frame when recording. Set the
zoom to wide angle, and tilt the
external microphone upward so it will
not intrude into the frame. This will not
affect the audio being recorded.
S-HDC-SDT750&TMT750GC_mst.book 7 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

8
VQT3B29 (ENG)
Preparation
Before using 1Parts identification and
handling
1 Speaker
2 Power button [ ] (l18)
3 Inlet (cooling fan)
4 Intelligent auto/Manual button
[iA/MANUAL] (l25)
5 Optical image stabilizer button
[ O.I.S.] (l31)
6 Eyepiece corrector dial (l20)
7 1080/50p button [1080/50p]
8 Battery release lever [BATT] (l13)
9 Battery holder (l13)
10 DC input terminal [DC IN] (l15)
≥Always use the supplied AC adaptor or a
genuine Panasonic AC adaptor
(VW-AD21E/EB-K; optional).
11 HDMI mini connector [HDMI] (l39)
12 USB terminal [ ]
13 AV multi connector (l39)
≥Use the AV multi cable (only the supplied
cable).
14 Card slot (l17)
15 Access lamp [ACCESS] (l17)
16 Lens cover
≥The lens cover opens in motion
picture recording mode or still picture
recording mode. (l19)
17 Multi manual ring
18 Camera function button
[CAMERA FUNCTION]
19 Remote control sensor
20 Built-in flash
21 3D Conversion Lens attachment part
(concave) (l32)
22 Lens (LEICA DICOMAR)
23 AF assist lamp
24 Recording lamp
1089
23456
7
11
12
13
1
1415
16
17
18
19
20
22
21
23
24
S-HDC-SDT750&TMT750GC_mst.book 8 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

9
(ENG) VQT3B29
25 LCD monitor (Touch screen) (l20)
≥It can open up to 90o.
≥It can rotate up to 180oAtowards the lens
or 90o B towards the viewfinder.
26 Viewfinder (l20)
27 Quick menu button [Q.MENU]
28 Sub recording start/stop button
≥This button functions in the same manner
as the recording start/stop button.
29 Adjust zoom buttons (l29)
30 Menu button [MENU] (l28)
31 Delete button [ ] (l37)
32 Tripod receptacle
25 26
28
27 29 30 31
Due to limitations in LCD production
technology, there may be some tiny bright
or dark spots on the LCD monitor screen.
However, this is not a malfunction and
does not affect the recorded picture.
Due to limitations in LCD production
technology, there may be some tiny bright
or dark spots on the viewfinder screen.
However, this is not a malfunction and
does not affect the recorded picture.
32
S-HDC-SDT750&TMT750GC_mst.book 9 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

10
VQT3B29 (ENG)
33 Shoe adaptor mounting part
34 Shoe adaptor cover
35 Shoe adaptor release lever
[SHOE ADAPTOR RELEASE]
36 Photoshot button [ ] (l24)
37 Zoom lever [W/T] (In motion picture
recording mode or still picture
recording mode) (l29)
Thumbnail display switch [ / ]/
Volume lever [sVOLr] (In playback
mode)
38 Status indicator (l18)
39 Internal microphones
40 Recording start/stop button (l23)
41 Mode dial (l19)
42 Shoulder strap fixture
43 Grip belt
Adjust the length of the grip belt so that it fits
your hand.
1Flip the belt.
2Adjust the length.
3Replace the belt.
44 Microphone terminal [MIC]
≥A compatible plug-in powered microphone
can be used as an external microphone.
≥Audio will be stereo (2 ch) with the
external microphone input.
≥When the unit is connected with the AC
adaptor, sometimes noise may be heard
depending on the microphone type. In this
case, please switch to the battery for the
power supply and the noise will stop.
45 Headphone terminal [ ]
≥
Excessive sound pressure from earphones
and headphones can cause hearing loss.
≥Listening at full volume for long periods
may damage the user’s ears.
MIC
33
34
35
393736
40 41 42 43
44
45
38
S-HDC-SDT750&TMT750GC_mst.book 10 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

11
(ENG) VQT3B29
∫About the 3D Conversion Lens (l32)
1 Attachment screw
2 Protective glass (front)
3Lens
4 Adjustment dial cover
5 Vertical position adjustment dial
[]
6 Vertical alignment adjustment dial
[]
7 Horizontal image position adjustment
dial []
8 Protective glass (rear)
9 Camera body attachment part
(convex)
Lens front cap
10 Horizontal line for adjustment
≥Use to adjust the lens attachment position.
≥If you use the lens front cap as a stand as
shown below, you can leave the unit with
the 3D Conversion Lens attached.
1
3
2
4
5
6
7
8
9
10
S-HDC-SDT750&TMT750GC_mst.book 11 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

12
VQT3B29 (ENG)
Preparation
Setup 1Power supply
∫About batteries that you can use with this unit
The battery that can be used with this unit is VW-VBG130/VW-VBG260/VW-VBG6.
≥The unit has a function for distinguishing batteries which can be used safely. The
dedicated battery (VW-VBG130/VW-VBG260/VW-VBG6) supports this function. The
only batteries suitable for use with this unit are genuine Panasonic products and
batteries manufactured by other companies and certified by Panasonic. (Batteries
which do not support this function cannot be used). Panasonic cannot in any way
guarantee the quality, performance or safety of batteries which have been
manufactured by other companies and are not genuine Panasonic products.
≥
To use the VW-VBG6 for this unit, the battery pack holder kit VW-VH04 (optional) is required.
Important:
If the DC cable is connected to the AC adaptor, then the battery will not charge.
Remove the DC cable from the AC adaptor.
1Connect the AC cable to the AC adaptor and the AC outlet.
2Insert the battery into the AC adaptor by aligning the arrows.
It has been found that counterfeit battery packs which look very similar to the genuine
product are made available to purchase in some markets. Some of these battery packs are
not adequately protected with internal protection to meet the requirements of appropriate
safety standards. There is a possibility that these battery packs may lead to fire or explosion.
Please be advised that we are not liable for any accident or failure occurring as a result of
use of a counterfeit battery pack. To ensure that safe products are used we would
recommend that a genuine Panasonic battery pack is used.
Charging the battery
When this unit is purchased, the battery is not charged. Charge the battery before
using this unit.
Charging lamp [CHARGE] A
Lights up:
Charging (Battery charging time: l14)
Goes off:
Charging completed
Flashing:
Be sure to connect the unit correctly
S-HDC-SDT750&TMT750GC_mst.book 12 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

13
(ENG) VQT3B29
≥We recommend using Panasonic batteries (l6, 7, 14).
≥If you use other batteries, we cannot guarantee the quality of this product.
≥Do not heat or expose to flame.
≥Do not leave the battery(ies) in an automobile exposed to direct sunlight for a long period
of time with doors and windows closed.
Install the battery by inserting it in the direction shown in the figure.
Inserting/removing the battery
Removing the battery
Be sure to hold down the power
button until the status indicator
goes off. Then remove the battery
while supporting the unit to prevent
it dropping.
Move the battery release lever in
the direction indicated by the
arrow and remove the battery
when unlocked.
BATT
AInsert the battery until it clicks and
locks.
CAUTION
Danger of explosion if battery is
incorrectly replaced. Replace only with
the same or equivalent type
recommended by the manufacturer.
Dispose of used batteries according to
the manufacturer’s instructions.
S-HDC-SDT750&TMT750GC_mst.book 13 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

14
VQT3B29 (ENG)
∫Charging/Recording time
≥Temperature: 25 oC/humidity: 60%RH
* The battery pack holder kit VW-VH04 (optional) is necessary.
≥These times are approximations.
≥The indicated charging time is for when the battery has been discharged completely.
Charging time and recordable time vary depending on the usage conditions such as
high/low temperature.
≥Recordable time of 3D recording mode is the same. (During 3D recording mode, 1080/50p
recording mode can not be used.)
Charging and recording time
HDC-SDT750
Battery model number
[Voltage/Capacity
(minimum)]
Charging
time
Recording
mode
Maximum
continuously
recordable time
Actual
recordable
time
Supplied battery/
VW-VBG130 (optional)
[7.2 V/1250 mAh]
2h35min
1080/50p,
HA, HG, HX
1h40min 1h
HE 1 h 5 min
VW-VBG260 (optional)
[7.2 V/2500 mAh] 4h40min
1080/50p 3 h 10 min 1 h 55 min
HA, HG, HX 3h15min 2h
HE 3 h 20 min
VW-VBG6 (optional)*
[7.2 V/5400 mAh] 9h25min
1080/50p 7 h 50 min 4 h 50 min
HA 8h5min 5h
HG, HX 8h10min
HE 5 h 5 min
HDC-TMT750
Battery model number
[Voltage/Capacity
(minimum)]
Charging
time
Recording
mode
Maximum
continuously
recordable time
Actual
recordable
time
Supplied battery/
VW-VBG130 (optional)
[7.2 V/1250 mAh]
2h35min
1080/50p,
HA, HG, HX
1h40min 1h
HE 1 h 5 min
VW-VBG260 (optional)
[7.2 V/2500 mAh] 4h40min
1080/50p 3 h 10 min 1 h 55 min
HA, HG, HX 3h15min 2h
HE 3 h 20 min
VW-VBG6 (optional)*
[7.2 V/5400 mAh] 9h25min
1080/50p 7 h 50 min 4 h 50 min
HA 8h5min 5h
HG, HX 8h10min
HE 5 h 5 min
S-HDC-SDT750&TMT750GC_mst.book 14 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

15
(ENG) VQT3B29
≥The actual recordable time refers to the recordable time when repeatedly starting/stopping
recording, turning the unit on/off, moving the zoom lever etc.
≥The batteries heat up after use or charging. This is not a malfunction.
The unit is in the standby condition when the AC adaptor is connected. The primary circuit is
always “live” as long as the AC adaptor is connected to an electrical outlet.
Important:
While the DC cable is connected to the AC adaptor, the battery will not charge.
≥Do not use the AC cable with any other equipment as it is designed only for this unit.
Also, do not use the AC cable from other equipment with this unit.
1Connect the AC cable to the AC adaptor and the AC outlet.
2Connect the DC cable to the AC adaptor.
3Connect the DC cable to the DC input terminal [DC IN].
≥When removing the AC adaptor, be sure to hold down the power button until the status
indicator goes off. Then remove the AC adaptor.
Battery capacity indication
≥The display changes as the battery capacity reduces.
####
If there is less than 3 minutes remaining, then will become red. If the battery
discharges, then will flash.
≥The remaining battery capacity is displayed when using the Panasonic battery that you
can use for this unit. The actual time can vary depending on your actual use.
≥If the actual remaining time exceeds 9 hours 59 minutes, the indication will stay green
and will not change until the remaining time falls below 9 hours 59 minutes.
≥When using the AC adaptor or batteries made by other companies, the remaining
battery capacity will not be shown.
Connecting to the AC outlet

DC IN

ADC output terminal
B
DC input terminal
Insert the DC cable matching the
[ ] mark of the DC input terminal.
S-HDC-SDT750&TMT750GC_mst.book 15 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

16
VQT3B29 (ENG)
Preparation
Setup 2Recording to a card
The unit can record still pictures or motion pictures to an SD card or built-in memory. To
record to an SD card, read the following.
Use SD cards conforming to Class 4 or higher of the SD Speed Class Rating* for
motion picture recording.
* The SD Speed Class Rating is the speed standard for successive writes.
≥Please confirm the latest information
about SD Memory Cards/SDHC Memory
Cards/SDXC Memory Cards that can be
used for motion picture recording on the
following website.
http://panasonic.jp/support/global/cs/
e_cam
(This website is in English only.)
≥4 GB or more Memory Cards that do not
have the SDHC logo or 48 GB or more
Memory Cards that do not have the SDXC
logo are not based on SD Memory Card
Specifications.
≥When the write-protect
switch A on SD card is
locked, no recording,
deletion or editing will
be possible on the card.
≥Keep the Memory Card
out of reach of children to prevent
swallowing.
This unit (an SDXC compatible device) is compatible with SD Memory Cards, SDHC
Memory Cards and SDXC Memory Cards. When using an SDHC memory card/SDXC
memory card with other equipment, check the equipment is compatible with these memory
cards.
Cards that you can use with this unit
Card type Capacity Motion picture recording
Still
recording
SD
Memory
Card
8MB/16MB/32MB Cannot be used.
Can be
used.
64 MB/128 MB/
256 MB Cannot be guaranteed in operation.
512 MB/1 GB/
2GB
Can be used.
SDHC
Memory
Card
4GB/6GB/8GB/
12 GB/16 GB/
24 GB/32 GB
SDXC
Memory Card
48 GB/64 GB
32
S-HDC-SDT750&TMT750GC_mst.book 16 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

17
(ENG) VQT3B29
Caution:
Check that the access lamp has gone off.
1Open the LCD monitor.
2Open the SD card/terminal
cover and insert (remove) the
SD card into (from) the card
slot.
≥Face the label side Bin the direction
shown in the illustration and press it
straight in as far as it will go.
≥Press the centre of the SD card and then
pull it straight out.
3Securely close the SD card/
terminal cover.
≥Securely close it until it clicks.
≥Do not touch the terminals on the back of
the SD card.
≥Do not apply strong shocks, bend, or drop
the SD card.
≥
Electrical noise, static electricity or the failure of
this unit or the SD card may damage or erase
the data stored on the SD card.
≥When the card access lamp is lit, do not:
jRemove the SD card
jTurn the unit off
jInsert and remove the USB cable
jExpose the unit to vibrations or shock
Performing the above while the lamp is on may
result in damage to data/SD card or this unit.
≥Do not expose the terminals of the SD
card to water, garbage or dust.
≥Do not place SD cards in the following
areas:
jIn direct sunlight
jIn very dusty or humid areas
jNear a heater
jLocations susceptible to significant
difference in temperature (condensation
can occur.)
jWhere static electricity or
electromagnetic waves occur
≥To protect SD cards, return them to their
cases when you are not using them.
≥Refer to the Operation Instructions
(PDF format) about disposing of or giving
away the SD card.
Inserting/removing an SD card
When using an SD card not from Panasonic, or one previously used on other equipment,
for the first time on this unit, format the SD card. When the SD card is formatted, all of the
recorded data is deleted. Once the data is deleted, it cannot be restored.


Access lamp [ACCESS] A
≥When this unit is accessing the SD
card
or built-in memory , the access lamp
lights up.
S-HDC-SDT750&TMT750GC_mst.book 17 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

18
VQT3B29 (ENG)
Preparation
Setup 3Turning the unit on/off
You can turn the unit on and off using the power button, the LCD monitor or the viewfinder.
Press the power button to turn on the unit
AThe status indicator lights.
Opening the LCD monitor or extending the viewfinder turns on the unit. Closing the LCD
monitor/viewfinder turns off the unit.
During general use, you may find it convenient to turn the unit on/off using the LCD
monitor or viewfinder.
∫To turn on the unit
AThe status indicator lights.
∫To turn off the unit
BThe status indicator goes off.
≥The unit will not turn off unless the LCD monitor is closed and the viewfinder is retracted.
≥The unit will not turn off while recording motion pictures even if the LCD monitor is closed
and the viewfinder is retracted.
≥In the following cases, opening the LCD monitor or extending the viewfinder does not turn
on the unit. Press the power button to turn on the unit.
jWhen the unit is purchased
jWhen you have turned off the unit using the power button
Turning the unit on and off with the power button
Turning the unit on and off with the LCD monitor/
viewfinder
To turn off the unit
Hold down the power button
until the status indicator
goes off.

S-HDC-SDT750&TMT750GC_mst.book 18 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

19
(ENG) VQT3B29
Preparation
Setup 4Selecting a mode
Change the mode to recording or playback.
Operate the mode dial to change the mode to , or .
Motion picture recording mode (l23)
Still picture recording mode (l24)
Playback mode (l26)
≥Align with the status indicator A.
S-HDC-SDT750&TMT750GC_mst.book 19 ページ ２０１０年８月１８日 水曜日 午前１１時１８分

20
VQT3B29 (ENG)
Preparation
Setup 5Adjusting LCD monitor/
viewfinder
You can operate by directly touching the
LCD monitor (touch screen) with your finger.
It is easier to use the stylus pen (supplied)
for detailed operation or if it is hard to
operate with your fingers.
∫Touch
Touch and release the touch screen to select
icon or picture.
≥Touch the centre of the icon.
≥Touching the touch screen will not operate
while you are touching another part of the
touch screen.
∫Drag
Move your finger while pressing on the touch
screen. Can be used during direct playback
and playback zoom.
∫About the operation icons
///:
These icons are used to switch the menu
and thumbnail display page, for item
selection and setting etc.
:
Touch to return to the previous screen
such as when setting menus.
≥Do not touch the LCD monitor with hard
pointed tips, such as ball point pens.
≥Perform the touch screen calibration when
the touch is not recognised or wrong
location is recognised.
∫Adjusting the field of view
It adjusts the field of view to show the
images on the viewfinder clearly.
Adjust the focus by rotating the
eyepiece corrector dial.
≥Extend the viewfinder and close the LCD
monitor to turn on the viewfinder.
How to use the touch
screen
Viewfinder adjustment
S-HDC-SDT750&TMT750GC_mst.book 20 ページ ２０１０年８月１８日 水曜日 午前１１時１８分
