Panasonic AJ-RC905EN User manual

© 2004 Matsushita Electric Industrial Co., Ltd. All rights reserved.
Unauthorized copying and distribution is a violation of law.
.
ORDER NO. BSD04070147
D25
AJ-RC905P/EN/MC
Remote Control Unit
Sec. 1 Service Information
Sec. 2 Disassembly Procedures
& Electrical Adjustment
Sec. 3 Block Diagram,
Parts Location Table
& Schematic Diagrams
AJ-RC905
AJ-CA905G
AJ-CA905G
Camera Adapter

- 2 -
AJ-RC905P
! WARNING
This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not
contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product. Products powered
by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service or repair the product o
r
products dealt with in this service information by anyone else could result in serious injury or death.
