Panasonic Lumix dmw-bggh5e User manual

Please read these instructions carefully before using this

product, and save this manual for future use.

Veuillez lire attentivement les présentes instructions avant d’utiliser

ce produit, et conserver ce manuel pour utilisation ultérieure.

请于使用前仔细阅读操作使用说明书，并将说明书妥善保

管，以备将来使用。

Operating Instructions

Manuel d’utilisation

使用说明书

BATTERY GRIP

PRISE D’ALIMENTATION

电池手柄

until

2017/03/24

DVQX1206ZA

F0217WT0

DMW-BGGH5

Model No.

Modèle

型号

If you have any questions, visit:

USA : http://shop.panasonic.com/support

Canada : www.panasonic.ca/english/support

Pour toute assistance supplémentaire, visiter :

www.panasonic.ca/french/support

DVQX1206.book 1 ページ２０１７年２月６日　月曜日　午後５時２９分

DVQX1206 (ENG)

Operating Instructions

BATTERY GRIP

Thank you for purchasing this Panasonic product.

Please read these instructions carefully before using this product, and

save this manual for future use.

Contents

Information for Your Safety .....................................................................2

Precautions .............................................................................................5

Supplied Accessories..............................................................................5

Names of the components ......................................................................6

Mounting on and removing from the digital camera................................7

Inserting/Removing the Battery...............................................................8

Using the battery grip............................................................................11

Cautions for Use ...................................................................................11

Specifications........................................................................................13

Limited Warranty (ONLY FOR U.S.A.)..................................................14

Limited Warranty (ONLY FOR CANADA) .............................................17

Information for Your Safety

The socket outlet shall be installed near the equipment and shall be

easily accessible.

CAUTION!

To reduce the risk of fire, electric shock or product damage,

•Do not install or place this unit in a bookcase, built-in cabinet or in

another confined space. Ensure this unit is well ventilated.

DVQX1206.book 2 ページ２０１７年２月６日　月曜日　午後５時２９分

(ENG) DVQX1206

ENGLISH

∫About the battery pack

• Do not heat or expose to flame.

• Do not leave the battery(ies) in a car exposed to direct sunlight for a long

period of time with doors and windows closed.

CAUTION

Battery pack (Lithium ion battery pack)

• Use the specified unit to recharge the battery pack.

• Do not use the battery pack with equipment other than the specified unit.

• Do not get dirt, sand, liquids, or other foreign matter on the terminals.

• Do not touch the plug terminals (i and j) with metal objects.

• Do not disassemble, remodel, heat or throw into fire.

If any electrolyte should come into contact with your hands or clothes,

wash it off thoroughly with water.

If any electrolyte should come into contact with your eyes, never rub

the eyes. Rinse eyes thoroughly with water, and then consult a doctor.

CAUTION

• Danger of explosion if battery is incorrectly replaced. Replace only with

the type recommended by the manufacturer.

• When disposing of the batteries, please contact your local authorities or

dealer and ask for the correct method of disposal.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above

60 xC (140 oF) or incinerate.

DVQX1206.book 3 ページ２０１７年２月６日　月曜日　午後５時２９分

DVQX1206 (ENG)

-If you see this symbol-

Disposal of Old Equipment

Only for European Union and countries with recycling systems

This symbol on the products, packaging, and/or

accompanying documents means that used electrical and

electronic products must not be mixed with general

household waste.

For proper treatment, recovery and recycling of old products, please

take them to applicable collection points in accordance with your

national legislation.

By disposing of them correctly, you will help to save valuable

resources and prevent any potential negative effects on human

health and the environment.

For more information about collection and recycling, please contact

your local municipality.

Penalties may be applicable for incorrect disposal of this waste, in

accordance with national legislation.

DVQX1206.book 4 ページ２０１７年２月６日　月曜日　午後５時２９分

(ENG) DVQX1206

Precautions

• This unit is exclusively for Panasonic digital camera DC-GH5. (As of

February 2017)

For the latest information on compatible devices, see the operating

instructions, catalogue or website of the digital camera.

• Ease of operation and grip when held vertically during the recording will

improve. The attached battery pack¢ (optional), in addition to the battery in

the digital camera, will allow longer recording time.

¢Indicated as battery pack or battery in the text.

∫Handling the unit

•The dust- and splash-proofing of this unit is not a guarantee of a full

protection against the intrusion of dust and water. Please take care of

following when using. If the unit does not operate properly, please

contact the dealer where you have purchased the unit or Panasonic.

• Mount this unit firmly to the digital camera.

• Close the battery door and DC coupler cover firmly.

• Be careful not to allow sand, dust, or water to adhere or enter into the

terminal area, digital camera, or this unit when attaching or removing this unit.

• This unit is not water-proof, so this cannot be used underwater. For

splash-proofing, this unit is constructed to resist the entry of water. If

splashes of water etc. do adhere to this unit, wipe after use with a soft dry

cloth.

•Do not subject the unit to strong vibration or impact. Those actions may

result in malfunctions and failure.

• Please also read the manual of your digital camera.

Supplied Accessories

Product numbers correct as of February 2017. These may be subject to

change.

•The battery is optional.

Terminal Cap

• The terminal cap is attached to the

battery grip at the time of purchase. DVKV1001Z

DVQX1206.book 5 ページ２０１７年２月６日　月曜日　午後５時２９分

DVQX1206 (ENG)

Names of the components

1Electrical contacts

2Cover storage

3Camera attachment pins

4Joystick

5Rear dial

6[AF/AE LOCK] button

7Attachment screw

8DC coupler cover

9Battery door

10 Release lever

11 Tripod mount

12 Operation ON/OFF switch

13 [Fn] button

14 [ ] (White Balance) button

15 Shutter button

16 Front dial

17 [ ] (ISO sensitivity) button

[ ] (Exposure Compensation)

button

19 Strap attachment holder

• We recommend using the battery

grip and the digital camera with

the supplied shoulder strap

attached to prevent them from

dropping. (Read the digital

camera operating instructions for

details on how to attach the

strap.)

15161718

13 14

123

10 9

DVQX1206.book 6 ページ２０１７年２月６日　月曜日　午後５時２９分

(ENG) DVQX1206

Mounting on and removing from the

digital camera

• Check that the digital camera is turned off. (Mounting the unit onto, or

disengaging it from, the camera while the power is on may cause trouble

and is not recommended.)

11Remove the cover for the

battery grip connector on

the digital camera.

• The cover for the battery grip

connector can be stored in the cover

storage in the battery grip.

2Remove the terminal cap on

the electrical contacts of the

battery grip.

• Return the cover for the battery grip

connector and the terminal cap to their

original position after use to protect the terminals.

• Be careful not to lose the terminal cap.

2 Insert by aligning the

attachment screw, electrical

contacts, and camera

attachment pins.

3 Turn the attachment screw in

direction of the arrow to

attach securely.

• Confirm that the attachment screw is

not loose while using.

Note

• Keep the Terminal Cap out of reach of children to prevent swallowing.

∫Remove the battery grip from the digital camera

• Confirm that the digital camera is not powered, and turn the attachment

screw in the opposite direction of the attachment.

DVQX1206.book 7 ページ２０１７年２月６日　月曜日　午後５時２９分

DVQX1206 (ENG)

Inserting/Removing the Battery

• Use the battery after charging with a dedicated charger.

• The battery grip can be used when the battery is inserted in either the digital

camera or the battery grip.

• Check that the digital camera is turned off.

1 Turn the release lever of the

battery grip toward [OPEN],

and open the battery door.

2 Taking care of the orientation,

insert securely all the way

until you hear locking, and

confirm that the 1 lever is

hooked to the battery.

• When removing the battery, push the

1 lever toward the arrow and pull

out the battery.

For the U.S.A., CANADA and Latin America

• Always use genuine Panasonic batteries (DMW-BLF19PP: optional).

• If you use other batteries, we cannot guarantee the quality of this product.

For Taiwan

• Always use genuine Panasonic batteries (DMW-BLF19GT: optional).

• If you use other batteries, we cannot guarantee the quality of this product.

For China

• Always use genuine Panasonic batteries (DMW-BLF19GK: optional).

• If you use other batteries, we cannot guarantee the quality of this product.

For Other Countries

• Always use genuine Panasonic batteries (DMW-BLF19E: optional).

• If you use other batteries, we cannot guarantee the quality of this product.

DVQX1206.book 8 ページ２０１７年２月６日　月曜日　午後５時２９分

(ENG) DVQX1206

3 Close the battery door and

turn the release lever toward

[LOCK].

Note

• Remove the battery after use. (The battery will exhaust if it is left unused for

long period of time.)

• The battery will be warm after using, while charging, and right after

charging. The battery grip will also be warm while using, but this is not a

malfunction.

•Confirm that there is no foreign matter on the battery door.

∫Using 2 batteries

The digital camera can be used for longer periods of time when batteries

are inserted in both the digital camera and the battery grip. (It will switch

to the other battery when one of the batteries is exhausted.)

• The battery to be used primarily can be set in the digital camera. Read the

operating instructions of your digital camera for details.

Note

•Do not remove the battery when the battery in the battery grip is being

used. (Power of the digital camera will be turned off.)

DVQX1206.book 9 ページ２０１７年２月６日　月曜日　午後５時２９分

DVQX1206 (ENG)

∫Using the AC adaptor (optional) and the DC coupler

(optional) instead of the battery

• Always use a genuine Panasonic DC coupler (DMW-DCC12: optional).

The digital camera can be used without worrying about exhaustion of

battery by connecting the AC adaptor and connect it to the outlet. To use

the AC adaptor, the DC coupler is required.

Note

• When the DC coupler is being mounted, the DC coupler cover opens, so the

structure ceases to be dust-proof and splash-proof. Be careful not to allow

sand, dust and water etc. to adhere to or enter the structure. After use,

check that there is no foreign matter attached to the coupler cover, and

close it firmly.

• Also read the operating instructions for the AC adaptor and DC coupler.

• Some optional accessories may not be available in some countries.

For the U.S.A., CANADA and Latin America

•
