Panasonic KX-TU329FXME User manual

Operating Instructions
Easy Use Mobile Phone
Model No. KX-TU329 FX
Thank you for purchasing a Panasonic product.
Please read these operating instructions before using the unit and
save them for future reference.
Before initial use, see “Important Information” on page 12.
Supplied accessories
– AC adaptor (Part No. PNLV230CE): 1 pc
– Rechargeable battery (Part No. BJ-LT100010): 1 pc
– Charger: 1 pc
TU329FX(en)_1011_ver210.pdf 1 2016/10/11 14:54:15

Getting Started
Setting up ...............................3
Controls ..................................6
Display ....................................7
Turning the power on/off ......10
Initial settings ........................10
Important Information
For your safety .....................12
Important safety
instructions ...........................14
For best performance ...........15
Other information ..................15
SAR ......................................16
Specifications .......................17
Basic Operations
Making calls ..........................18
Answering calls ....................19
Call log .................................20
Voicemail service .................20
Text input ..............................21
Messages .............................21
Phonebook ...........................25
Alarm ....................................27
Night mode ...........................28
Calendar/Schedule ...............29
Voice recording ....................30
Priority call ............................31
Network service call
features ................................33
Security settings ...................34
Camera .................................35
Image viewer ........................37
File manager ........................38
Customising Your Phone
Menu list ...............................41
Connecting to Other Devices
Using the FM radio ...............49
Using a Bluetooth® wireless
connection ............................51
Using a USB connection ......54
Useful Information
Troubleshooting ....................55
General information ..............58
Sales department .................59
Declaration of conformity
form ......................................60
Index
Index......................................62
2
Table of Contents
TU329FX(en)_1011_ver210.pdf 2 2016/10/11 14:54:15

Setting up
Inserting a SIM card, microSD card, and the battery
A SIM card (not supplied) allows the phone to connect to a mobile
phone service. Contact your network operator/service provider for
more information.
A microSD card (not supplied) allows you to expand the phone’s
storage capabilities.
Important:
RWhen removing the battery, make sure you turn off the phone first.
RTo avoid loss of data or malfunction, do not damage, carelessly handle, or short-circuit the
gold-coloured contacts of the SIM card or microSD card.
1Remove the phone’s cover.
2Open the SIM card cover by
sliding it toward the nearest
side of the phone (A) and
then lifting up (B).
1
2
3Put the SIM card with the
gold-coloured contacts
facing down.
3
Getting Started
TU329FX(en)_1011_ver210.pdf 3 2016/10/11 14:54:15

4Close the SIM card cover
(A), and then gently slide
the cover toward the
opposite side of the phone
(B).
1
2
5Open the microSD card
cover by sliding it toward the
nearest side of the phone
(A) and then lifting up (B).
2
1
6Put the microSD card with
the gold-coloured contacts
facing down, close the
microSD card cover (A),
and then gently slide the
cover toward the opposite
side of the phone (B).
1
2
7Insert the battery (A) and
lower it into the phone (B),
then attach the cover (C).
3
1
2
Note:
RUse only the battery specified.
RWipe the battery ends ( , ), SIM card, and microSD card with a dry cloth.
RAvoid touching the battery ends ( , ) or the unit contacts.
RAfter installing the SIM card, microSD card, and battery, press MN for about 2 seconds to
turn the power on (page 10).
4
Getting Started
TU329FX(en)_1011_ver210.pdf 4 2016/10/11 14:54:15

Battery charging
You can charge the battery by connecting the phone to a power
outlet using the supplied AC adaptor, either directly or by using the
charger, or by connecting it to a computer using a USB cable (not
supplied).
RCharge for about 3 hours.
RCharging time and battery life might differ depending on the condition of the network.
RWhen using an AC adaptor, use only the supplied AC adaptor.
RWhen charging begins, the phone sounds and the battery indicator lights. When the battery is
fully charged, the battery indicator turns off.
AC adaptor or USB
connection
Using the charger
Battery indicator
To power outlet
Note:
RThe battery might swell when its life is close to an end. This is dependent on the usage
conditions and is not a problem.
RIt is normal for the phone and AC adaptor to feel warm during charging.
5
Getting Started
TU329FX(en)_1011_ver210.pdf 5 2016/10/11 14:54:16

Controls
A B
C
D
E
K
U
P
ST
G
J
F
H
I
L
M
N
O
R
ALED light
BCamera lens
CLED status indicator;
page 9
DVolume up/down
Change font display size;
page 10
EDisplay; page 7
FMake calls/Answer calls/
Select the function shown
above (page 9).
GNavigation key
MDN ( ): Open the main menu.
MCN ( ): View the contacts
list.
HOne touch dial key; page 18
6
Getting Started
TU329FX(en)_1011_ver210.pdf 6 2016/10/11 14:54:16

ICall voicemail; page 21
JInternational call; page 18
KReceiver
LPower/End calls/Select the
function shown above
(page 9).
MCamera key; page 35
NPress and hold for 2 seconds
to turn the silent mode on/off.
OMicrophone
PCharge contacts
QPriority call; page 31
RSpeaker
SPress to turn the light on/off
(page 36).
THeadset jack
UUSB connector (Micro-B
type); page 5, 54
Display
Symbols
Signal strength
R: Roaming network
E
E: The phone is connected
to an EDGE network.
G
G: The phone is connected
to a GPRS network.
Battery level
– : High
– : Medium
– : Low
–: Needs charging.
The phone is connected to
a computer via USB.
The call is not encrypted.*1
Silent mode is on. (page 7,
47)
Vibration is on. (page 47)
Handsfree is on. (page 19)
Ringer volume off.
Incoming call
Outgoing call
Missed call
Mute is on. (page 19)
Frequency control equalizer
is set. (page 19)
A 2nd call is on hold.
RContact is saved to the
phone.
RRoot directory of phone
RMobile phone is
discovered in Bluetooth
search menu.
Contact is saved to the SIM
card.
Contact name
7
Getting Started
TU329FX(en)_1011_ver210.pdf 7 2016/10/11 14:54:16

Mobile phone number
Office phone number
Home phone number
Fax number
Selected ringer tone.
RNew SMS message is
received.
RSMS message (unread/
unsent) is saved to the
phone.
SMS message (sent) is
saved to the phone.
SMS message (opened) is
saved to the phone.
SMS message (unread/
unsent) is saved to the SIM
card.
SMS message (sent) is
saved to the SIM card.
SMS message (opened) is
saved to the SIM card.
MMS is running for sending
or receiving data.
RNew MMS message is
received.
– Flashing: Message
memory is full.
RMMS message is unread
or unsent.
MMS message is read.
M
MMS message is
unreceived.
MMS message is sent.
– Image file
–Image file is attached to
the MMS message.
– Image file is selected for
caller picture.
Root directory of memory
card
– Sound file
–Sound file is attached to
the MMS message.
vcf
VCF (vCard) file
Other format file
Other format file is attached
to the MMS message.
Folder
To
MMS recipient is set to To.
Cc
MMS recipient is set to Cc.
Bcc
MMS recipient is set to Bcc.
New voicemail message
received.*2 (page 21)
Alarm is on. (page 27,
29)
Night mode is on.
(page 28)
Headset (optional) is
connected.
– Bluetooth feature is on.
(page 51)
– Another Bluetooth device
is connected.
Bluetooth compatible
computer is discovered in
Bluetooth search menu.
8
Getting Started
TU329FX(en)_1011_ver210.pdf 8 2016/10/11 14:54:16

Bluetooth headset is
discovered in Bluetooth
search menu.
Bluetooth headset is
connected to the phone.
Bluetooth hands-free car kit
is discovered in Bluetooth
search menu.
*1 Contact your network operator/service provider for more information.
*2 Voicemail subscribers only
Function keys
Calls emergency number.
Returns to previous screen.
Accepts current selection.
Erases a number/character.
Opens recent call log.
Makes/answers a call.
Ends the call.
Sets handsfree.
Opens option menu.
Answers a 2nd call.
Allows editing.
Selects multiple items.
Stops alarm.
Activates snooze function.
Turns the power off.
Pauses playback.
Resumes playback.
Stops recording or
playback.
LED status indicator
Message indicator
Flashes when a new
message is received.*1
Incoming call indicator
Flashes when there is an
incoming call, when you
have a missed call*1, or
while talking.
Battery indicator
Turns on when charging.
– Flashing: The battery is
low.
*1 Message indicator and incoming call indicator stop flashing after about 12 hours have
passed.
9
Getting Started
TU329FX(en)_1011_ver210.pdf 9 2016/10/11 14:54:16

Turning the power on/off
Press MN for about 2 seconds.
RThe phone vibrates when you turn the power on.
Note:
REnter the PIN1 code and press MN or M N when the PIN1 code request is displayed
(page 34).
RThe display becomes dark when you do not operate the phone for about 1 minute. Press any
key to turn the display back on.
Initial settings
The phone may prompt you to set display language, time zone, and
date and time each time a new SIM card is installed.
1MbN: Select the desired language. a MN
2MbN: Select the desired time zone. a M N
3Enter the current date, month, and year. a MN
4Enter the current time. a MN
Note:
RIf you select a language you cannot read:
Press MDN. a MbN: Select . a M N 2 times a MCN 2 times a MN a MbN: Select the
desired language. a MN
RIf you want to change the date and/or time format, see page 46.
RTo adjust the hour for summer time, see page 46.
Display font size
Press MN or MN to adjust the font size of displayed menus.
Note:
RYou cannot adjust the display font size while you are on a call or the phone is ringing for an
incoming call.
Changing the ringer tone
You can change the ringer tone by selecting one of the preset
tones (“Using a preset ringer tone”, page 11) or by selecting one
of your own sound files (including sounds recorded using the phone’
10
