3
Get Started
The phone is a Dual SIM mobile phone allowing you to use the
facility of two networks.
1. Switch off the mobile phone.
2. Insert the SIM card correctly in the card slot(s) (See figure below)
Insert SIM card
You can charge your battery using the charger or connect the USB
cable (supplied with this phone ) to the computer.
Charge the Battery or Connect to PC

4
Charge Mobile Phone
Your phone is powered by a rechargeable battery. If your phone comes
up a message which notifies you that the battery power is too low, at
that moment, please recharge the battery, if the charge is too low, it
may shorten the life of the battery.
Connect the charger to a power outlet and the micro USB connector to
the phone’s USB port. The LED flashlight on the top of the phone is
red. Once the phone has finished charging, the light turns green and
you should unplug the charger.
PC-Phone File Transfer
Once the mobile phone is connected to a PC with USB, the PC will
charge the mobile phone automatically. In such case, USB computer
connection will appear on your screen.
1. Drag the notification panel down and tap Use USB to Transfer files.
2. Select Transfer files.
3. The device is recognized as a Removable Disk by the computer.
Open the folder and transfer or copy files from your phone to PC and
vice-versa.

5
Keys and Parts
The phone gives you marvelous feelings to experience on Camera,
Video recorder, FM radio, Music and Sound recorder. Let you install
various APPs, games, and more (supports APK format) by
downloading from Google PlayTM.
9
5
11
10
1
6
8
7
3
4
2
12

6
1.Volume
Up/Down Key
To adjust the ringer volume, adjust the voice
volume during a call and adjust media volume.
2.Headset port
To connect an earphone so you can listen to
music or radio, etc.
3.Receiver
To hear the voice of the other side when
calling.
4.Front Camera
Allow you to take pictures while facing the
screen.
5.Power Key
Switch the phone on or off.
Press and hold to open phone options menu.
6.Return
Go back to the previous screen;
Close the on-screen keypad, a dialog box, an
options menu, or the notification panel.
7.Home Key Go to home screen;
Press and hold to open Google assistant.
8.Menu Switch to recently used applications.
9. USB jack
To connect charger or USB data cable for data
exchange.
10.Back Camera
lens
For taking photos.
11.Flashlight
To take photos in low-light conditions.
12.Fingerprint
key
After you set fingerprint, you can use it to
unlock the screen.

7
Lock and Unlock the Screen
Press power button to enter Sleep mode and meanwhile the screen will
be locked; press power button again to wake up and then drag the lock
upwards to unlock.
Notification Panel
Notification icons on the status bar report the new arrival of messages,
calendar events, alarm set and ongoing settings such as when call
forwarding is on or the current call status. You can open the
Notifications panel to open the message, reminder, or event
notification and see the mobile operator’s name. Even you can switch
on Data connection, WLAN, Bluetooth, etc.
-> Opening the Notifications panel
Press and hold the status bar, slide your finger downward to open the
Notifications panel.
If you have several notifications, you can scroll down the status bar to
view more notifications.
-> Closing the Notifications panel
Do one operation of the following:
1. Press and hold the bottom bar of the Notifications panel, then slide
your finger up the screen.
2. Press BACK or Home directly.
Arranging and Rearranging Widgets and Icons
Rearrange the widgets and icons on your Home screen to give room
for adding more items to the Home screen.
-> Press and hold the widget or icon you are desired to move.
You'll see this icon Remove on the screen. Don't release your finger.
-> Drag the widget or icon to a new location on the screen. Pause at
the left or right edge of the screen to drag the widget or icon onto
another Home screen panel.
-> When the widget or icon is where you are desired to put it, release
your finger. If you've released your finger but a message shows that
there's no space to place the widget or icon, drag it right or left again
to another Home screen panel.

8
Adding Folders on your Screen
Use folders to group related applications and other shortcuts to keep
your Home screen tidy and organized.
-> Adding folder on your screen
Press and hold an application icon or a widget that you want to move.
Don't release your finger. Drag the application icon or widget and drop
it on top of another application icon or widget. Then, simply tap the
folder to open it so you can access the applications and widgets inside
the folder.
-> Deleting folder
Drag out all the applications from the folder, then the folder will be
deleted automatically.
Adjusting Brightness
Drag the notification panel down and adjust brightness. Or enter
Settings ->Display ->Brightness level, and adjust the brightness level
here (by dragging the brightness slider to the left to decrease or to the
right to increase the screen Brightness).
Note: Lower the brightness of the screen to prolong the battery life.
Changing your Wallpaper
Personalizing your Home screen wallpaper with your favorite photo is
a quick and easy way to change the feel of your phone and give it a
fresh look. Browse the collection of wallpapers included in your
phone by default or choose from photos that you have taken with the
camera.
-> Press and hold the screen where there is space.
-> The screen will vibrate and an optional context.
-> Select the wallpaper you want and confirm to set it as wallpaper.
Or you can enter Settings->Display-> Wallpaper, then will show an
optional context.

9
Make a Call
On the start screen choose and enter a complete phone number to
make a call.
Call Log
Enter Phone interface, then tap access Call log. In call log options,
you can Make calls and send message etc.
Reject a Call by Sending a busy Message
While there is an incoming call, you are inconvenient to accept the
call, and then you can send a busy message for rejecting the call.
Drag the icon upward, some busy messages will show on the
screen, short tap any of them to send out.
Add a Contact
Tap and enter Contacts and then add a contact (see figure below.)
Tap to add a new contact to Phone or SIM card.
Messaging
Enter Messaging, and then compose new message. You touch a text
field where you want to enter text, to open the keyboard.

10
Receiving a New Message
When there is a new message comes, a new message icon will appears
in the notifications area of the status bar to notify you of a new text or
multimedia message.
To open the message, press and hold the status bar, and then slide the
status bar down to open the Notifications panel. Or go to Messaging,
read the message directly.
Editing SMS and MMS
-> When you are composing a new text message, you can select text
for cutting or copying. Touch the text field or portion that contains text.
You can select all contexts, copy, cut and paste. The selected text is
highlighted in Blue.
-> A multimedia message may contain video, pictures, audio,
sideshow, etc. Thus, when you are supposed to edit a MMS, you can
just add videos, pictures and more to SMS and change to MMS.
Message conversations
Text and multimedia messages that are sent to and received from a
contact (or a number) are grouped into conversations or message
threads in the All messages screen. Threaded SMS or MMS let you
see exchanged messages (similar to a chat program) with a contact on
the screen.
Browse the Web
Open the browser; click the URL on the screen to search or tap
website address.
The browser is fully optimized and comes with advanced features that
let you enjoy Internet browsing on your phone.
You must have an active data connection or Wi-Fi connection to
access the Internet.

11
Enjoy Music
When you copy music to your Micro SD card, the Music player
searches the device for music files and builds a catalog of your music,
based on information about each file that is stored in the file itself.
Download Applications from Android
->Add a Google account
->Enter Android Market (Play Store) and download apps.
Manage Applications
Enter Settings >Apps & notifications, then manage the applications.
Tap any app to view the information of the applications, and you can
also force the apps to stop or uninstall the apps.
To install Apps, you need switch on “Allow from this source” in
settings.

12
Warning shows
FCC statements:
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications or changes to
this equipment. Such modifications or changes could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of
the following measures:
‐R eori ent or rel ocate the recei vi ng antenna.
‐I ncrease the separati on between the equi pment and recei ver.
‐Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
‐Consul t the deal er or an ex peri enced radi o/TV techni ci an f or
help.

13
The SAR limit of USA (FCC) is 1.6 W/kg averaged over one
gram of tissue. Device types Panasonic ELUGA Ray 600 (FCC
ID: 2APTIS60ER6) has also been tested against this SAR
limit.The highest SAR value reported under this standard during
product certification for use when properly worn on the body is
0.681 W/kg and for head is 0.898 W/kg. Simultaneous RF
exposure is 1.233W/Kg. This device was tested for typical
body‐w orn op erati ons w i th the back of the handset k ep t 10 m m
from the body. To maintain compliance with FCC RF exposure
requirements, use accessories that maintain a 5mm separation
distance between the user's body and the back of the handset. The
use of belt clips, holsters and similar accessories should not
contain metallic components in its assembly. The use of
accessories that do not satisfy these requirements may not comply
with FCC RF exposure requirements, and should be avoided.
