Panasonic KX-TPA50 User manual

Installation Manual
Bedienungsanleitung
Manuel d’installation
Installatiehandleiding
Manual de Instalación
Istruzioni per l’uso
Additional Cordless Handset
Weiteres schnurloses Mobilteil
Combiné sans fil supplémentaire
Extra Draadloze Handset
Unidad portátil inalámbrica adicional
Portatile cordless aggiuntivo
KX-TPA50 B01

– 2 –
1
2
Belt clip
N To attach N To remove
25 mm
Screws
(Not supplied)
Hooks

– 3 –
Contents/Inhalt/Table des matières/Inhoud/Contenido/Indice
English ............................................................................................... 4
Deutsch .............................................................................................. 9
Français............................................................................................ 14
Nederlands....................................................................................... 19
Español ............................................................................................ 24
Italiano.............................................................................................. 29

– 4 –
PLEASE READ BEFORE USE AND SAVE
This unit is an additional handset compatible with the following series of
Panasonic SIP Cordless Phone:
KX-TGP500/KX-TGP550
You must register this handset with your base unit before it can be used. This
installation manual describes only the steps needed to register and begin using
the handset. For further details, please read the base unit’s User Guide on the
Panasonic Web site at:
http://panasonic.net/pcc/support/sipphone/
Supplied accessories
*1 Please read the replacement battery information section of the base unit’s
User Guide on the Panasonic Web site. See page 4 for Panasonic URL.
*2 The handset cover comes attached to the handset.
Note:
L Please read the additional/replacement accessory section of the base unit’s
User Guide on the Panasonic Web site. See page 4 for Panasonic URL.
L This equipment is designed for use in Germany, Spain, Italy, France, Belgium,
Netherlands, and Switzerland.
L In the event of problems, you should contact your phone system dealer in the
first instance.
L For use in other countries, please contact your equipment supplier.
Connection (page 2: 1 )
L Use only the supplied Panasonic AC adaptor PQLV219CE.
L The AC adaptor must remain connected at all times. (It is normal for the
adaptor to feel warm during use.)
Charger.......................................................................................................... 1
AC adaptor (PQLV219CE) ............................................................................ 1
Belt clip .......................................................................................................... 1
Rechargeable batteries
*1
(HHR-65AAAB)...................................................... 2
Handset cover
*2
............................................................................................. 1
English

– 5 –
Battery installation/Battery charge (page 2: 2 )
Important:
L Use the supplied rechargeable batteries. For replacement, we recommend
using the Panasonic rechargeable batteries noted in the base unit’s User
Guide on the Panasonic Web site. See page 4 for Panasonic URL.
L Wipe the battery ends ( S , T ) with a dry cloth.
L Avoid touching the battery ends ( S , T ) or the unit contacts.
L Confirm correct polarities ( S , T ).
L USE ONLY Ni-MH batteries AAA (R03) size.
L Do NOT use Alkaline/Manganese/Ni-Cd batteries.
Place the handset on the charger for about 6 hours before initial use.
Note:
L If the batteries are fully charged, but the operating time seems to be shorter,
clean the battery ends (
S , T ) and the charge contacts with a dry cloth and
charge again.
Registering a handset to the base unit
1 Base unit:
N KX-TGP500 series
Press and hold {x} for about 4 seconds until the 4 indicator flashes in
red.
N KX-TGP550 series
Press and hold {x} for about 4 seconds until the registration tone sounds
and the
4 indicator flashes in red.
L If all registered handsets start ringing, press the same button to stop. Then
repeat this step.
L The next step must be completed within 90 seconds.
2 Handset:
[
3 Wait until “ Enter Base PIN ” is displayed. i Enter the base unit PIN
(default:
“ 0000 ” ). i Press M , then wait until a long beep sounds.
L If you forget your PIN, contact your phone system dealer.

– 6 –
Note:
L If an error tone sounds, or if _ is still displayed, register the handset according
to the registering section of the base unit’s User Guide on the Panasonic Web
site. See page 4 for Panasonic URL.
For your safety
To prevent severe injury and loss of life/property, read this section carefully before using the
product to ensure proper and safe operation of your product.
WARNING
Power connection
L Completely insert the AC adaptor/power plug into the power outlet. Failure to do so may
cause electric shock and/or excessive heat resulting in a fire.
L Regularly remove any dust, etc. from the AC adaptor/power plug by pulling it from the
power outlet, then wiping with a dry cloth. Accumulated dust may cause an insulation
defect from moisture, etc. resulting in a fire.
L Unplug the product from power outlets if it emits smoke, an abnormal smell, or makes an
unusual noise. These conditions can cause fire or electric shock. Confirm that smoke has
stopped emitting and contact your phone system dealer.
L It is advisable to unplug the machine during thunderstorms as the warranty does not cover
any damage resulting from lightning strikes and power surges. Lightning protection is
advised.
Installation
L To prevent the risk of fire or electrical shock, do not expose the product to rain or any type
of moisture.
L Do not place or use this product near automatically controlled devices such as automatic
doors and fire alarms. Radio waves emitted from this product may cause such devices to
malfunction resulting in an accident.
Operating safeguards
L The use of excessive sound volume through earphones, headphones, or headsets may
cause hearing loss.
CAUTION
Installation and relocation
L The AC adaptor is used as the main disconnect device. Ensure that the AC outlet is
installed near the product and is easily accessible.

– 7 –
Battery
L We recommend using the supplied batteries or additional/replacement batteries noted in
the battery information section of the base unit’s User Guide on the Panasonic Web site.
See page 4 for Panasonic URL.
USE ONLY rechargeable Ni-MH batteries AAA (R03)
size
.
L Do not mix old and new batteries.
L Do not open or mutilate the batteries. Released electrolyte from the batteries is corrosive
and may cause burns or injury to the eyes or skin. The electrolyte is toxic and may be
harmful if swallowed.
L Exercise care when handling the batteries. Do not allow conductive materials such as
rings, bracelets, or keys to touch the batteries, otherwise a short circuit may cause the
batteries and/or the conductive material to overheat and cause burns.
L Charge the batteries provided with or identified for use with this product only, in
accordance with the instructions and limitations specified in this manual.
L Only use a compatible charger to charge the batteries. Do not tamper with the charger.
Failure to follow these instructions may cause the batteries to swell or explode.
Other information
L Operating the product near electrical appliances may cause interference. Move away
from the electrical appliances.
L Use only the power cord and batteries indicated in this manual. Do not dispose of batteries
in a fire. They may explode. Check with local codes for possible special disposal
instructions.
Routine care
L Wipe the outer surface of the product with a soft moist cloth.
L Do not use benzine, thinner, or any abrasive powder.
Notice for product disposal, transfer, or return
L This product can store your private/confidential information. To protect your privacy/
confidentiality, we recommend that you erase information such as phonebook or caller list
entries from the memory before you dispose of, transfer, or return the product.

– 8 –
Information for Users on Collection and Disposal of Old Equipment and used
Batteries
These symbols ( 1 , 2 , 3 ) on the products,
packaging, and/or accompanying
documents mean that used electrical and
electronic products and batteries should not
be mixed with general household waste.
For proper treatment, recovery and
recycling of old products and used batteries,
please take them to applicable collection
points, in accordance with your national
legislation and the Directives 2002/96/EC and 2006/66/EC.
By disposing of these products and batteries correctly, you will help to save valuable
resources and prevent any potential negative effects on human health and the environment
which could otherwise arise from inappropriate waste handling.
For more information about collection and recycling of old products and batteries, please
contact your local municipality, your waste disposal service or the point of sale where you
purchased the items.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national
legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment, please contact your dealer or
supplier for further information.
Information on Disposal in other Countries outside the European Union
These symbols ( 1 , 2 , 3 ) are only valid in the European Union. If you wish to discard these
items, please contact your local authorities or dealer and ask for the correct method of
disposal.
Note for the battery symbol
This symbol ( 2 ) might be used in combination with a chemical symbol ( 3 ). In this case it
complies with the requirement set by the Directive for the chemical involved.
123

– 9 –
VOR GEBRAUCH LESEN UND ANSCHLIESSEND
AUFBEWAHREN
Dieses Gerät ist ein zusätzliches Mobilteil das mit den schnurlosen SIP-
Telefonen von Panasonic der folgenden Serien kompatibel ist:
KX-TGP500/KX-TGP550
Bevor dieses Mobilteil verwendet werden kann, müssen Sie es an Ihrer
Basisstation registrieren. Diese Bedienungsanleitung beschreibt nur die
Registrierung des Mobilteils und die ersten Bedienschritte. Weitere Einzelheiten
finden Sie in der Bedienungsanleitung zu Ihrer Basisstation auf der Panasonic-
Website unter:
http://panasonic.net/pcc/support/sipphone/
Mitgeliefertes Zubehör
*1 Bitte lesen Sie den Abschnitt über den Austausch des Akkus in der
Bedienungsanleitung zu Ihrer Basisstation auf der Panasonic-Website.
Panasonic URL siehe Seite 9.
*2 Das Mobilteil wird mit angebrachter Akkufachabdeckung geliefert.
Hinweis:
L Bitte lesen Sie den Abschnitt über optionales bzw. Austauschzubehör in der
Bedienungsanleitung zu Ihrer Basisstation auf der Panasonic-Website.
Panasonic URL siehe Seite 9.
L Dieses Gerät ist für den Gebrauch in Deutschland, Spanien, Italien,
Frankreich, Belgien, den Niederlanden und der Schweiz geeignet.
L Wenden Sie sich bei Problemen bitte zunächst an Ihren Provider.
L Kontaktieren Sie Ihren Gerätelieferanten, wenn Sie das Gerät in anderen
Ländern verwenden möchten.
Ladegerät ...................................................................................................... 1
Netzteil (PQLV219CE)................................................................................... 1
Gürtelclip ....................................................................................................... 1
Akkus
*1
(HHR-65AAAB) ................................................................................. 2
Akkufachabdeckung
*2
.................................................................................... 1
Deutsch

– 10 –
Anschluss (Seite 2: 1 )
L Verwenden Sie ausschließlich das mitgelieferte Netzteil PQLV219CE von
Panasonic.
L Das Netzteil muss stets angeschlossen bleiben. (Es ist normal, dass sich das
Netzteil während des Betriebes warm anfühlt.)
Einsetzen des Akkus/Aufladen des Akkus (Seite 2: 2 )
Wichtig:
L Verwenden Sie die mitgelieferten Akkus. Zum Austausch empfehlen wir die
Akkus von Panasonic, die in der Bedienungsanleitung zu Ihrer Basisstation
auf der Panasonic-Website genannt werden. Panasonic URL siehe Seite 9.
L Die Pole des Akkus ( S , T ) mit einem trockenen Tuch abwischen.
L Achten Sie darauf, die Pole der Akkus ( S , T ) und die Kontakte des Gerätes
nicht zu berühren.
L Achten Sie auf richtige Polung ( S , T ).
L VERWENDEN SIE NUR Ni-MH-Akkus der Größe AAA (R03).
L Verwenden Sie KEINE Alkali-/Mangan-/Ni-Cd-Batterien.
Legen Sie das Mobilteil vor dem ersten Gebrauch ca. 6 Stunden lang auf
das Ladegerät.
Hinweis:
L Wenn die Akkus vollständig geladen sind, aber die Betriebszeit dennoch kurz
zu sein scheint, wischen Sie die Pole des Akkus (
S , T ) und die Kontakte des
Geräts mit einem trockenen Tuch ab und wiederholen Sie den Ladevorgang.
Display-Sprache
11 (Joystick) i {#}{ 1 }{ 1 }{ 0 }
2 {V} / {^} : Wählen Sie die gewünschte Einstellung.
3 Drücken Sie zum Speichern auf den Joystick. i {i}
