Panasonic JS-970 Series User manual

Before operating this product, please read the instructions carefully and save this
manual for future use.
Operating Instructions
POS Workstation
Model No. JS-970 Series
JS-970WP
(Panel)
JS-970WS
(Upright)
English Deutsch Français Español Русский

2
For USA
For USA
Federal Communications Commission Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at
his own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This unit must be connected to a grounded power outlet.
Battery
This product contains a CR Coin Cell Lithium Battery which contains Perchlorate
Material-special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/Perchlorate.
For CANADA
For CANADA
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
This unit must be connected to a grounded power outlet.
Cette unité doit être branchée sur une prise de courant mise à la terre.

3
For USA / CANADA
A lithium ion battery that is recyclable powers the product you have purchased.
Please call 1-800-8-BATTERY for information on how to recycle this battery.
L’appareil que vous vous êtes procuré est alimenté par une batterie au
lithium-ion.
Pour des renseignements sur le recyclage de la batterie, veuillez composer le
1-800-8-BATTERY.
For EU
English
Warning :
This is a class A product. In a domestic environment, this product may cause radio interference in
which case the user may be required to take adequate measures.
This unit must be connected to a grounded power outlet.
Deutsch [German]
Warnung :
Dies ist ein Produkt der Klasse A. Wenn im Heim betrieben, kann das Produkt
Hochfrequenzstörungen verursachen, gegen die der Benutzer u.U. geeignete Maßnahmen treffen
muss.
Dieses Gerät muss an eine vorschriftsmäßig geerdete Netzsteckdose angeschlossen werden.
Français [French]
Avertissement :
Il s’agit d’un produit de classe A. Dans un environnement privé, ce produit risque de créer des
interférences radio auquel cas des mesures correctives adéquates peuvent être exigées de la part
de l’utilisateur.
Cette unité doit être branchée sur une prise de courant mise à la terre.
Česky [Czech]
Upozornění :
Toto je výrobek třídy A. Ve vnitřním prostředí může tento výrobek způsobovat rádiové rušení.
V takovém případě může být požadováno, aby uživatel přijal příslušná opatření.
Dansk [Danish]
Advarsel :
Dette er et klasse-A produkt. I hjemmeomgivelser kan dette produkt forårsage radiostøj, i hvilket
tilfælde brugeren kan være nødsaget til at træffe fyldestgørende forholdsregler.

4
For EU
Suomi [Finnish]
Varoitus :
Tämä on luokan A tuote. Kotiympäristössä tämä tuote saattaa aiheuttaa häiriöitä radiolähetyksiin,
jolloin käyttäjän tulee kenties suorittaa asianmukaiset toimenpiteet.
Laite on liitettava suojamaadoituskoskettimilla varustettuun pistorasiaan.
Norsk [Norwegian]
Advarsel :
Dette er et klasse A produkt. Ved innendørs bruk kan dette produktet forårsake radiointerferens.
I slike tilfeller kan det være nødvendig for brukeren å treffe nødvendige tiltak.
Apparatet ma tilkoples jordet stikkontakt.
Svenska [Swedish]
Varning :
Detta är en klass A produkt. I inomhusmiljö kan denna produkt orsaka radiostörningar. I sådant fall
åligger det användaren att vidta lämpliga åtgärder.
Apparaten skall anslutas till jordat uttag.
Slovenčina [Slovak]
Upozornenie :
Toto je výrobok triedy A. Vo vnútornom prostredí môže tento výrobok spôsobovať rádiové rušenie.
V takom prípade môže byť požadované, aby používateľ prijal príslušné opatrenia.
Italiano [Italian]
Attenzione :
Questo è un prodotto di classe A. In ambiente domestico, questo prodotto può causare interferenze
radio, nel qual caso può essere necessario che l’utente adotti misure adeguate.
Español [Spanish]
Aviso :
Éste es un producto de clase A. En la instalación en una vivienda, este producto puede causar
interferencias de radio, en cuyo caso puede resultar necesario que el usuario tome medidas
pertinentes.

5
Esta unidad deberá conectarse a una toma de corriente conectada a tierra.
Nederlands [Dutch]
Waarschuwing :
Dit is een Klasse A product. In een huiselijke omgeving kan dit product radiostoring veroorzaken, in
welk geval de gebruiker verplicht kan zijn afdoende tegenmaatregelen te nemen.
Português [Portuguese]
Advertência :
Este é um produto da classe A. Quando este produto for utilizado num ambiente doméstico, poderá
provocar interferências radiofónicas e, neste caso, pode ser necessário que o utilizador tome as
providências adequadas.
Importer’s name and address to follow EU rules:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, D-22525 Hamburg, Germany
For Arabic Countries
[Arabic]
For Russia
Русский [Russian]
Предупреждение :
Это изделие класса А. В домашних условиях данное изделие может вызвать радиопомехи, что
может требовать от пользователя принятия соответствующих мер.
Это устройство необходимо подсоединять к заземленной сетевой розетке.
ВНИМАНИЕ! Настоящее изделие (аппарат, оборудование) удовлетворяет нормам
индустриальных радиопомех, установленным для оборудования класса А по TP TC 020/2011,
и не должно применяться в жилых, коммерческих зонах и производственных зонах с малым
энергопотреблением и подключаться к низковольтным распределительным электрическим
сетям

6
For Russia
ИНФОРМАЦИЯ О СЕРТИФИКАЦИИ ПРОДУКЦИИ
Рабочие станции (РOS Workstation) модели JS-970Wxxxxx
(где “x” =0-9, А-Z или пробел) с торговой маркой Panasonic
Орган по сертификации: Орган по сертификации средств
информатизации АНО "СЕРТИНФО''
Аттестат рег. № РОСС RU.0001.11ME06
Сертификат соответствия: RU C-JP. ME06.B.01337
Сертификат соответствия выдан: 12.11.2014
Сертификат соответствия действителен до: 12.11.2019
Изготовлено:
Panasonic System Networks Co., Ltd. , 4-1-62
Minoshima,Hakata-ku,Fukuoka-shi,Fukuoka,812-8531 Япония
На заводах:
1. Tech-Front (Shanghai) Computer Co., Ltd.
No.2, Lane 58, Sanzhuang Rd., Songjiang Export Processing Zone, Shanghai 201613,
P.R. CHINA, китай
2. Tech-Com (Shanghai) Computer Co., Ltd.
No.68, Sanzhuang Road, Songjiang Export Processing Zone, Shanghai 201613, P.R.
CHINA, китай
Примечание:
Дату изготовления Вы можете определить по серийному номеру, расположенному на
задней части изделия и на коробке.
Серийный номер: yymXXXXXX
yy: год (последние цифры номера года) 15 –2015, 16 –2016, 17 –2017
m: месяц A – Январь, B – Февраль, C – Март, D – Апрель, E – Май, F – Июнь,
H – Июль, J – Август, K – Сентябрь, L – Октябрь, M – Ноябрь, N – Декабрь
Установленный производителем срок службы для данного изделия равен 5 годам с
даты производства при условии, что изделие используется в строгом соответствии с
настоящей инструкцией по эксплуатации и применимыми техническими стандартами.

7
For Korea
상호 또는 성명 : Panasonic Korea Ltd.(PKL)
기기의 명칭 : POS Workstation
기본모델명 : JS-970WS0M80, JS-970WS0M83, JS-970WP0M81, JS-970WS0M70,
JS-970WS0M73, JS-970WP0M71
인증 번호 : MSIP-REI-PKL-JS-970
제조자 /제조국가 : Panasonic System Network Co., Ltd./ Japan
제조날짜 본체 밑면의 시리얼 번호를 참조하시기 바랍니다 .
yymXXXXXX
yy: 년도 표시 (yy means year) (2015 ＝15, 2016 ＝16,.....)
m: 월표시 (m means month)
A: 1 월B: 2 월C: 3 월D: 4 월E: 5 월F: 6 월
H: 7 월J: 8 월K: 9 월L: 10 월M: 11 월N: 12 월
주의사항
이기기는 업무용으로 전자파적합등록을 한기기이오니 판매자 또는 사용자는 이점을
주의하시기 바라며 만약 잘못 판매 또는 구입하였을 때에는 가정용으로 교환하시기
바랍니다 .
본장치는 접지된 전원 콘센트에 연결해야 합니다 .
베터리 팩
( 경고 )
● 발열 , 화제 , 폭발 등의 위험을 수발할 수있으니 다음 사항을 지켜주시기 바랍니다 .
a) 육안으로 식별이 가능할 정도의 부풀음이 발생된 전지는 위험할 수있으므로 제조자
또는 판매자로 즉시 문의 할것
b) 지정된 정품 충전기만을 사용할 것
c) 화기에 가까이 하지 말것( 전자레인지에 넣지 말것)
d) 여름철 자동차 내부에 방치하지 말것
e) 찜질방 등고온다습한 곳에서 보관 , 사용하지 말것
f) 이불 , 전기장판 , 카펫 위에 올려 놓고 장시간 사용하지 말것
g) 전원을 켠상태로 밀폐된 공간에 장시간 보관하지 말것
h) 전지 단자에 목걸이 , 동전 , 열쇠 , 시계 등금속 제품이 닿지 않도록 주의할 것
i) 휴대 기기 , 제조 업체가 보증한 리튬 2 차전지 사용할 것
j) 분해 , 압착 , 관통 등의 행위를 하지 말것
k) 높은 곳에서 떨어뜨리는 등비정상적 충격을 주지 말것
● 이마크가 있는 제품을 폐기하려면 지역 관청이나 구매한 대리점에게 적절한 폐기 방법에
관하여 문의하십시오 .
● 이설명서에 표시된 것이외의 방법을 사용하여 배터리를 충전하지 마십시오이 설명서에
표시된 방법 중하나를 사용하여 배터리를 충전하지 않으면 전해질 유출 , 발열 , 발화
또는 파열 등이 발생할 수있습니다 .

8
For Taiwan
甲類
此設備經測試證明符號 BSMI（經濟部標準檢驗局）之甲類數位裝置的限制規定。這些限制
的目的是為了在商業環境中使用此設備時，能提供合理的保護以防止有害的干擾。此設備會
產生、使用並散發射頻能量：如果未導照製造廠商的指導手冊來安裝和使用，可能會干擾無
線電通訊。請勿在住宅區使用此設備。
警告使用者：
這是甲類的資訊產品，在居住的環境中使用時，可能會造成射頻干擾，在這種情況下，使
用者會被要求采取某些適當的對策。
本機必須連接至接地的電源插座。
安全：電池處理
警告：新電池安裝不正確會有爆炸的危險。更換電池時，請僅使用相同或製造商建
議的同等類型電池。請勿將廢棄電池丟棄於一般垃圾中。請聯絡當地廢棄物處理機
構以獲取有關最近的廢棄電池存放站的地址。
您的電腦使用鋰幣電池。鋰幣電池為長效用電池，很有可能您永遠都不需要更換它。然而，
如果確實需要更換，請參閱您的電腦說明文件。
請勿將廢棄電池丟棄於一般垃圾中。請聯絡當地廢棄物處理機構以獲取有關最近的廢棄電池
存放站的地址。
安全：電池聲明（台灣）
廢電池請回收

9
商品名稱:收銀機
型 號 : JS-970WS0M80, JS-970WS0M83, JS-970WP0M81,
JS-970WS0M70, JS-970WS0M73, JS-970WP0M71
D31221
額定電源: 19 V 9.48 A
進口商:台松電器販賣股份有限公司
聯絡地址:新北市中和區員山路 579 號
電 話 : [phone]
製造或委製廠商 :松下系統網絡科技株式會社 日本 福岡
生產地:中國大陸
製造年份及
製造號碼:請參照實體底面之序列號碼
yymXXXXXX
yy: 年度表示 (yy means year) (2015 ＝15, 2016 ＝16,.....)
m: 月表示 (m means month)
A: 1 月B: 2 月C: 3 月D: 4 月E: 5 月F: 6 月
H: 7 月J: 8 月K: 9 月L: 10 月M: 11 月N: 12 月

10
Contents
Read Me First.......................................................................................... 11
Introduction....................................................................................................... 11
Disclaimer of Warranty .......................................................................... 14
Safety Precautions ................................................................................. 15
Precautions for Use................................................................................ 18
Confirmation of Accessories................................................................. 21
Names of Parts and Their Functions.................................................... 23
AC Adapter Installation.......................................................................... 28
AC Cord Kit Installation ......................................................................... 30
Turning the Power On and Off............................................................... 32
How to turn the power on ................................................................................. 32
How to turn the power off ................................................................................. 32
Display Unit (Including Main Block) Replacement.............................. 33
Operator’s Display Replacement .......................................................... 37
When fixing parts that use VESA mounts are not installed .............................. 37
When fixing parts that use VESA mounts are installed .................................... 39
How to Remove Internal Battery Pack
(for Models with Internal Battery Pack)................................................ 41
SD Memory Card Installation................................................................. 43
Cable Wire Routing ................................................................................ 44
Cable wire routing in display unit...................................................................... 44
Cable wire routing in stand unit ........................................................................ 45
Cable wire routing in WP type display unit ....................................................... 47
Specifications ......................................................................................... 48
Cleaning of Filter .................................................................................... 52
Cleaning .................................................................................................. 53
Maintenance............................................................................................ 53
Troubleshooting ..................................................................................... 53

11
Read Me First
■Introduction
Thank you for purchasing the Panasonic POS Workstation.
This manual describes the instructions for the POS Workstation.
Please read this manual carefully before using this product.
The illustrations and photos in this manual may differ from the actual product.
List of models
Model No. Display Style Touch Panel Processor Chipset
JS-970WPX01X 15 type
LCD Panel Resistive
Intel®Pentium®
Processor
G3320TE
Intel®H81
Chipset
JS-970WPX11X 15 type
LCD Panel Capacitive
Intel®Pentium®
Processor
G3320TE
Intel®H81
Chipset
JS-970WPX02X 17 type
LCD Panel Resistive
Intel®Pentium®
Processor
G3320TE
Intel®H81
Chipset
JS-970WPX04X 15 type
LCD Panel Resistive
Intel®Pentium®
Processor
G3320TE
Intel®Q87
Chipset
JS-970WPX14X 15 type
LCD Panel Capacitive
Intel®Pentium®
Processor
G3320TE
Intel®Q87
Chipset
JS-970WPX05X 17 type
LCD Panel Resistive
Intel®Pentium®
Processor
G3320TE
Intel®Q87
Chipset
JS-970WPX07X 15 type
LCD Panel Resistive Intel®Core™
i5-4590T
Intel®Q87
Chipset
JS-970WPX17X 15 type
LCD Panel Capacitive Intel®Core™
i5-4590T
Intel®Q87
Chipset
JS-970WPX08X 17 type
LCD Panel Resistive Intel®Core™
i5-4590T
Intel®Q87
Chipset
JS-970WPX0AX 12.1 type
LCD Panel Resistive Intel®Celeron®
Processor N2930 —
JS-970WPX0BX 15 type
LCD Panel Resistive Intel®Celeron®
Processor N2930 —
JS-970WPX1BX 15 type
LCD Panel Capacitive Intel®Celeron®
Processor N2930 —
JS-970WPX0CX 17 type
LCD Panel Resistive Intel®Celeron®
Processor N2930 —
English

12
Read Me First
Model No. Display Style Touch Panel Processor Chipset
JS-970WSX01X 15 type
LCD Upright Resistive
Intel®Pentium®
Processor
G3320TE
Intel®H81
Chipset
JS-970WSX11X 15 type
LCD Upright Capacitive
Intel®Pentium®
Processor
G3320TE
Intel®H81
Chipset
JS-970WSX02X 17 type
LCD Upright Resistive
Intel®Pentium®
Processor
G3320TE
Intel®H81
Chipset
JS-970WSX04X 15 type
LCD Upright Resistive
Intel®Pentium®
Processor
G3320TE
Intel®Q87
Chipset
JS-970WSX14X 15 type
LCD Upright Capacitive
Intel®Pentium®
Processor
G3320TE
Intel®Q87
Chipset
JS-970WSX05X 17 type
LCD Upright Resistive
Intel®Pentium®
Processor
G3320TE
Intel®Q87
Chipset
JS-970WSX07X 15 type
LCD Upright Resistive Intel®Core™
i5-4590T
Intel®Q87
Chipset
JS-970WSX17X 15 type
LCD Upright Capacitive Intel®Core™
i5-4590T
Intel®Q87
Chipset
JS-970WSX08X 17 type
LCD Upright Resistive Intel®Core™
i5-4590T
Intel®Q87
Chipset
JS-970WSX0AX 12.1 type
LCD Upright Resistive Intel®Celeron®
Processor N2930 —
JS-970WSX0BX 15 type
LCD Upright Resistive Intel®Celeron®
Processor N2930 —
JS-970WSX1BX 15 type
LCD Upright Capacitive Intel®Celeron®
Processor N2930 —
JS-970WSX0CX 17 type
LCD Upright Resistive Intel®Celeron®
Processor N2930 —
X can be any alphanumeric character or blank.
Panel:
Use of mounting brackets compliant with VESA standards allows it to be mounted on a
counter top horizontally or on a wall.
Distance between screw holes in the mounting section: 100 mm × 100 mm
Horizontal or wall mounting brackets are separately required.

13
Upright:
It is equipped with a dedicated tiltable stand.
AC adapter is housed in the stand.
List of optional accessories
Unit Name Model No. Remarks
ID Module
Unit
MSR Unit JS-970MG-010 Magnetic Stripe Reader
JS-970MG-020 Secure Card Reader
Fingerprint
Reader Unit JS-970FP-010 Fingerprint Reader
I-button Reader
Unit JS-970DP-010 I-button Reader
MSR +
Fingerprint
Reader Unit
JS-970MF-010 Magnetic Stripe Reader +
Fingerprint Reader
Rear Display
Unit
Customer
Display Unit
JS-970RD-010
20 Columns × 2 Rows Vacuum
Fluorescent Display
For JS-970WS
JS-970RD-020
20 Columns × 2 Rows Vacuum
Fluorescent Display
For JS-970WP
2nd LCD Display
Unit
JS-970SD-010 2nd LCD Display
With Camera and Touch Panel
JS-970SD-020 2nd LCD Display
Without Camera and Touch Panel
JS-970SDB010 2nd LCD Display Bracket
Other Unit
Battery Unit JS-970BT-010 Battery Pack (Used at Shutdown
Due to Power Outage)
Storage Unit
JS-970HDB010 Storage Bracket for Stand Unit
JS-970HDD010 HDD Module
JS-970SSD010 SSD Module
Conversion Cable
JS-970KDV010 DisplayPort-VGA Conversion
Adapter
JS-970KM9010 Modular-D-SUB9 Conversion
Cable (COM Port)
JS-970KMC010 Modular-DIN Conversion Cable
(Cash Drawer)
English

14
Disclaimer of Warranty
IN NO EVENT SHALL Panasonic System Networks Co., Ltd. BE LIABLE TO ANY PARTY
OR ANY PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE
OF THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW:
● ANY DAMAGE AND LOSS, INCLUDING WITHOUT LIMITATION, DIRECT OR
INDIRECT, SPECIAL, CONSEQUENTIAL OR EXEMPLARY, ARISING OUT OF
RELATING TO THE PRODUCT;
● PERSONAL INJURY OR ANY DAMAGE CAUSED BY INAPPROPRIATE USE OR
NEGLIGENT OPERATION OF THE USER;
● UNAUTHORIZED DISASSEMBLE, REPAIR OR MODIFICATION OF THE PRODUCT
BY THE USER;
● LOSS OF REGISTERED DATA BY ANY FAILURE.

15
Safety Precautions
■POS Workstation: JS-970WP / JS-970WS series
IMPORTANT
Install a socket outlet adjacent to the equipment so that it will be easily accessible.
CAUTION
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
ATTENTION
Il y a risque d’explosion si la batterie est remplacée par une batterie de type incorrect.
Mettre au rebut les batteries usagées conformément aux instructions.
Avoid radio frequency interference
Do not place the POS Workstation near a television or radio receiver.
Avoid stacking
Do not place heavy objects on the POS Workstation.
Keep small objects away
Do not insert paper clips or other small objects into POS Workstation.
There are risks of heat, fire and explosion.
Keep dry
There are risks of heat, fire and explosion.
Do not disassemble the POS Workstation
Do not attempt to disassemble the POS Workstation. There are risks of heat, fire and
explosion.
Do not touch the plug with wet hands
There is a risk of electric shock.
Be certain to plug fully into the outlet
There are risks of electric shock and fire.
Unplug this unit from power outlets if it emits smoke, an abnormal smell or makes
unusual noise.
These conditions can cause fire or electric shock. Confirm that smoke has stopped and
contact an authorized service center.
When unplugging, make sure to hold the body of the plug
If the power cord or outlet is damaged, there is a risk of electric shock, short circuit or fire.
Do not use a damaged power cord or plug
There are risks of electric shock and fire.
Do not use the provided power cord and the AC adapter for anything other than the
POS Workstation.
There are risks of electric shock and fire.
English

16
Safety Precautions
Clean the dust off the plug, periodically
There are risks of heat and fire.
Do not use with any other battery
Please use the specified battery.
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the instructions and local requirements.
Do not touch the power-cord or plug during a storm
There are risks of electric shock and fire.
Do not use the POS Workstation outdoors
This product assumes the indoor use. There is a risk of breakdown.
Do not put the POS Workstation on a slope or an unstable place
This can cause damage to the unit or injury by falling.
(JS-970WP series)
Select an installation area that can support the total weight
Selecting an inappropriate installation surface may cause the product to fall down or topple
over, resulting in injury. Installation work shall be started after sufficient reinforcement.
Periodic inspections shall be conducted
Rust on the metal parts or screws may cause a fall of the product resulting in injury or
accidents.
Consult the dealer for the inspections.
The measures of protection against a fall of this product shall be taken
Failure to observe this may cause a drop resulting in injury.
Be sure to install the safety wire.
The screws and bolts must be tightened to the specified torque
Failure to observe this may cause a drop resulting in injury or accidents.
Note:
● Do not open the rear cover and the filter cover while the POS Workstation is operating.

17
■Precautions on the Built-in Battery Pack
Do not throw this product into a fire or expose it to excessive heat.
Generation of heat, ignition or rupture of the battery may result.
Do Not Insert Sharp Objects Into the Internal Battery, Disassemble, or Modify It.
Electrolyte leakage, generation of heat, ignition or rupture of the battery may result.
Do Not Apply Shocks to the Product by Dropping It, Applying Strong Pressure to It,
etc.
If this product is subjected to a strong impact, damaged or deformed, stop using it
immediately.
Do not charge the Battery using methods other than those specified.
The battery pack is rechargeable and was intended for the specified product.
Avoid Extreme Heat (Near the Fire, In Direct Sunlight, for Example).
Electrolyte leakage, generation of heat, ignition or rupture of the battery may result.
English

18
Precautions for Use
Attention for capacitive touch screen
● Do not touch it by finger nail, because capacitive touch screen can not recognize it.
Touch it by finger tip.
● Do not touch it during startup. It initializes touch screen during startup. If it is touched
during startup, touch screen is not initialized correctly.
● Be careful to not accidentally touch around display edges or press on display bezel as it
can negatively affect display touch sensor accuracy.
● Touch screen calibration can be affected by atmospheric change. In case of calibration
shifted, perform a calibration adjustment.
● Adequacy of touch screen reaction-time or sensitivity may vary by operator. Display
sensitivity can be adjusted by executing a display sensitivity adjustment program.*1
● Capacitive touch-screen panel uses radio frequency to detect finger tip touch. Terminals
are configured to use different frequencies to avoid conflict in the event of two or more
terminals operating within 1.5 m (approx. 5 inches) of each other. In the event of conflict
(‘ghost’ or inexplicable touch-screen reaction(s)), shutdown and reboot the terminal to
reselect touch screen frequency.
*1Inquire to the supplier about the display sensitivity adjustment program.
Attention for resistive touch screen
● Do not touch with your finger nail or the tip of a pen. Otherwise the touch screen film can
be damaged or torn, causing a possible failure. Touch it by finger tip.
● Do not touch it during startup. It initializes touch screen during startup. If it is touched
during startup, touch screen is not initialized correctly.
HDD
● For replacement or removal / installation of the HDD, contact the company from which
you have purchased it. Do not allow any person other than servicemen to perform such
work, as it may possibly cause an HDD or equipment failure.
Use of speakers
● Do not emit a sound such as warning beeps at the maximum volume from the speakers
for a long time.
Carrying / moving terminals
● Do not lift or carry the equipment by holding onto the cable cover, display unit or second
display. Firmly tighten the finger screws on the back of the display, and securely hold the
equipment at the bottom with both hands when lifting or carrying it.

19
(JS-970WP series)
Procure fixing screws separately.
● The screws that secure this product are not supplied. Prepare them according to the
material and strength of the area where the product is to be installed.
Screw tightening
● The screws and bolts must be tightened with an appropriate tightening torque according
to the material and strength of the installation area.
● Do not use an impact driver. Use of an impact driver may damage the screws or cause
tightening excessively.
● When a screw is tightened, make the screw at a right angle to the surface. After
tightening the screws or bolts, perform visual check to ensure tightening is enough and
there is no backlash.
(JS-970WS series)
Display angle adjustment
● Take care not to place the fingers between the main block and the stand unit when the
angle of display is adjusted. Injury may occur. Adjust the display tilt- and swivel angles
with two hands placed on outside, bezel edges of the display unit.
● To adjust the display angle, slowly move the display.
● With the display placed in a horizontal position, putting an object on top of it, or pressing
it down firmly, can result in possible damage to the hinge part in the direction of swivel
rotation.
Be sure to remove this product if it is not in use.
English

20
Installation
● Contact an installation contractor for the installation work.
Installation environment precautions
● Do not install it in a place exposed to direct sunlight or near heating equipment.
● Do not install it in a place subjected to severe temperature changes or high humidity.
● Do not install it outdoors or in a dusty or oily smoke-hazed place.
● Do not install it in a place where high magnetic field is present or near a receiver such as
TV or a radio.
● Install it in a room whose temperature ranges from +5 °C to +40 °C .
● When installing it, keep it at least 10 cm in all directions (except down) away from other
POSs or devices, ceiling, etc., and at least 6 cm away from walls.
● Do not block the vents in POS.
● Do not install it on an unsteady surface or in a place subjected to vibration or impact.
● Install it in a place where it can be kept away from any liquids or mists.
● Install an outlet in a location that makes connecting or disconnecting the plug easy.
Precautions for Use
