Panasonic Toughpad FZ-M1CCAAXBM User manual

Read Me First
Getting Started
Useful Information
Troubleshooting
Appendix
OPERATING INSTRUCTIONS
Personal Computer
Model No. FZ-M1 series
Please read these instructions carefully before using this product, and save this
manual for future use.
Contents
Read Me First
Safety Precautions .....................................2
Regulatory Information .............................10
Getting Started
Introduction...............................................18
Description of Parts ..................................21
First-time Operation..................................24
Turning On / Turning Off...........................30
Useful Information
Handling and Maintenance.......................32
Installing Software ....................................39
Troubleshooting
Troubleshooting (Basic)............................45
Appendix
LIMITED USE LICENSE AGREEMENT...54
Specifications ...........................................56
Standard Limited Warranty.......................62
CPE02825ZAFZ-M1mk1-8.1OIE.indb1CPE02825ZAFZ-M1mk1-8.1OIE.indb1 2014/02/1413:03:332014/02/1413:03:33

2
Read Me First
Safety Precautions
To reduce the risk of injury, loss of life,
electric shock, fire, malfunction, and
damage to equipment or property,
always observe the following safety
precautions.
Explanation of symbol word
panels
The following symbol word panels are
used to classify and describe the level
of hazard, injury, and property damage
caused when the denotation is disre-
garded and improper use is performed.
DANGER
Denotes a potential hazard that will
result in serious injury or death.
WARNING
Denotes a potential hazard that could
result in serious injury or death.
CAUTION
Denotes a hazard that could result in
minor injury.
NOTICE
Denotes a hazard that could result in
property damage.
The following symbols are used to clas-
sify and describe the type of instruc-
tions to be observed.
This symbol is used to alert
users to a specific operating
procedure that must not be
performed.
This symbol is used to alert us-
ers to a specific operating pro-
cedure that must be followed in
order to operate the unit safety.
DANGER
Precautions on the Battery Pack
Electrolyte leakage, generation of
heat, ignition or rupture of the Bat-
tery Pack may result.
Do Not Throw the Battery
Pack into a Fire or Expose
It to Excessive Heat
Do Not Insert Sharp Ob-
jects Into the Battery Pack,
Disassemble, or Modify It
Do Not Short the Positive
(+) and Negative (-) Con-
tacts
Do not place the battery
pack together with articles
such as necklaces or
hairpins when carrying or
storing.
CPE02825ZAFZ-M1mk1-8.1OIE.indb2CPE02825ZAFZ-M1mk1-8.1OIE.indb2 2014/02/1418:27:532014/02/1418:27:53

3
Read Me First
DANGER
Precautions on the Battery Pack
Do Not Apply Shocks to
the Product by Dropping It,
Applying Strong Pressure
to It, etc.
If this product is subjected
to a strong impact, dam-
aged or deformed, stop
using it immediately.
Do Not Charge the Battery
Using Methods Other Than
Those Specified
Do Not Use the Battery
Pack with Any Other Prod-
uct
• The battery pack is re-
chargeable and was in-
tended for the specified
product.
Do Not Use This Product
with a Battery Pack Other
Than the One Specified
Use only the specified
battery pack with your
product.
When the Battery Pack Has
Deteriorated, Replace It
With a New One
Do not continue to use a
damaged battery pack.
Avoid Extreme Heat (Near
the Fire, in Direct Sunlight,
for Example)
DANGER
Precautions on the Built-in
Bridge Battery (for disposal)
<Only for model with Built-in
Bridge Battery>
When disposing the battery, gen-
eration of heat, ignition or rupture
of the Built-in Bridge Battery may
result. (page 36)
Handling This Computer
Do Not Disassemble the
Computer Except When
Disposing
Handling the Built-in Bridge
Battery
Do Not Short the Positive
(+) and Negative (-) Con-
tacts
Do Not Throw the Battery
into a Fire or Expose It to
Excessive Heat
Do Not Apply Shocks to
the Built-in Bridge Battery
by Dropping It, Applying
Strong Pressure to It, etc.
Do Not Charge
Do Not Use
Do Not Deform, Disassem-
ble, or Modify the Battery
Avoid Extreme Heat (Near
the Fire, in Direct Sunlight,
for Example)
CPE02825ZAFZ-M1mk1-8.1OIE.indb3CPE02825ZAFZ-M1mk1-8.1OIE.indb3 2014/02/1418:27:532014/02/1418:27:53

4
Read Me First
Safety Precautions
WARNING
<Only for model with Built-in
Bridge Battery>
Generation of heat, ignition or rup-
ture of the Built-in Bridge Battery
may result.
Do Not Throw This Product
Into a Fire or Expose It to
Excessive Heat
Do Not Insert Sharp Ob-
jects Into This Product,
Disassemble, or Modify It
Do Not Apply Shocks to
the Product by Dropping It,
Applying Strong Pressure
to It, etc.
Do Not Charge the Battery
Using Methods Other Than
Those Specified
Avoid Extreme Heat (Near
the Fire, In Direct Sunlight,
for Example)
When the Battery Has
Deteriorated, Contact Your
Technical Support Office to
Replace the Battery
WARNING
Fire or electric shock may result.
Do Not Do Anything That
May Damage the AC Cord,
the AC Plug, or the AC
Adaptor
Do not damage or modify
the cord, place it near hot
tools, bend, twist, or pull
it forcefully, place heavy
objects on it, or bundle it
tightly.
Do not continue to use
a damaged AC cord, AC
plug and AC adaptor.
• Contact your technical
support office for repair.
Do Not Connect the AC
Adaptor to a Power Source
Other Than a Standard
Household AC Outlet
Connecting to a DC/AC
converter (inverter) may
damage the AC adap-
tor. On an airplane, only
connect the AC adaptor/
charger to an AC outlet
specifically approved for
such use.
Do Not Pull or Insert the
AC Plug If Your Hands Are
Wet
Do Not Disassemble This
Product
Do Not Touch This Product
In a Thunderstorm If Con-
nected with the AC Cable
or Any Other Cables
CPE02825ZAFZ-M1mk1-8.1OIE.indb4CPE02825ZAFZ-M1mk1-8.1OIE.indb4 2014/02/1413:03:342014/02/1413:03:34

5
Read Me First
WARNING
If a Malfunction or Trouble
Occurs, Immediately Stop
Use
If the Following Malfunc-
tion Occurs, Immediately
Unplug the AC Plug and
the Battery Pack
• This product is damaged
• Foreign object inside this
product
• Smoke emitted
• Unusual smell emitted
• Unusually hot
After the above procedure,
contact your technical sup-
port office for repair.
Clean Dust and Other Debris
of the AC Plug Regularly
• If dust or other debris ac-
cumulates on the plug,
humidity, etc. may cause a
defect in the insulation.
Insert the AC Plug Com-
pletely
Do not use a damaged
plug or loose AC outlet.
Close the Connector
Cover Tightly When Using
This Product Wherever
There is a Lot of Water,
Moisture, Steam, Dust,
Oily Vapors, etc.
If foreign matter has found
its way inside, immediately
turn the power off and un-
plug the AC cord, and then
remove the battery pack.
Then contact your techni-
cal support office.
WARNING
Burns or low-temperature burns
may result.
Do Not Use This Product
in Close Contact With Your
Body For a Long Period of
Time
Do not use this product
with its heat-emitting parts
in close contact with your
body for long periods of
time.
• Low-temperature burns
may result.
Do Not Touch The Surface
of The AC Adaptor Contin-
uously While Using/Charg-
ing
• Burns may result.
Detrimental health effects on your
body may result.
Do Not Turn the Volume Up
To Loud When Using Head-
phones
• Listening at high volumes
that overstimulate the ear
for long periods of time
may result in loss of hear-
ing.
CPE02825ZAFZ-M1mk1-8.1OIE.indb5CPE02825ZAFZ-M1mk1-8.1OIE.indb5 2014/02/1413:03:342014/02/1413:03:34

6
Read Me First
Safety Precautions
CAUTION
Fire or electric shock may result.
Do Not Move This Product
While the AC Plug Is Con-
nected
If the AC cord is damaged,
unplug the AC plug imme-
diately.
Do Not Subject the AC
Adaptor To Any Strong
Impact
Do not continue to use the
AC adaptor after a strong
impact such as being
dropped.
Contact your technical
support office for repair.
<Only for model with LAN>
Do Not Connect a Tele-
phone Line, or a Network
Cable Other Than the One
Specified, Into the LAN
Port
Do not connect to a net-
work such as the ones
listed below.
• Networks other than
100BASE-TX or 10BASE-T
• Phone lines (IP phone
(Internet Protocol Tele-
phone), Telephone lines,
internal phone lines (on-
premise switches), digital
public phones, etc.)
Do Not Leave This Product
in High Temperature Envi-
ronment for a Long Period
of Time
• Leaving this product where
it will be exposed to ex-
tremely high temperatures
such as near fire or in
direct sunlight may deform
the cabinet and/or cause
trouble in the internal parts.
Hold the Plug When Un-
plugging the AC Plug
Use Only the Specified AC
Adaptor With This Product
Do not use an AC adaptor
other than the one sup-
plied (supplied with the
unit or one sold separately
as an accessory).
This product may fall over or drop,
resulting in an injury.
Do Not Place This Product
on Unstable Surfaces
Avoid Stacking
CPE02825ZAFZ-M1mk1-8.1OIE.indb6CPE02825ZAFZ-M1mk1-8.1OIE.indb6 2014/02/1413:03:342014/02/1413:03:34

7
Read Me First
CAUTION
Detrimental health effects on your
body may result.
Take a Break Of 10-15 Min-
utes Every Hour
• Using this product for long
periods of time may have
detrimental health effects
on the eyes or hands.
Burns, low-temperature burns, or
frostbite may result.
Do Not Expose the Skin To
This Product When Using
the Product In A Hot Or
Cold Environment
When it is necessary to
expose the skin to this
product such as to scan
a fingerprint, perform the
operation in the shortest
time possible.
NOTICE
Do not place the computer near a
television or radio receiver.
Keep the computer away from
magnets. Data stored on the flash
memory may be lost.
This computer is not intended for
the display of images for use in
medical diagnosis.
This computer is not intended for
a use with connection of medical
equipment for the purpose of medi-
cal diagnosis.
Panasonic shall not be liable for
loss of data or other incidental or
consequential damages resulting
from the use of this product.
Do not touch the terminals on the
battery pack. The battery pack may
no longer function properly if the
contacts are dirty or damaged.
Do not expose the battery pack to
water, or allow it to become wet.
If the battery pack will not be used
for a long period of time (a month
or more), charge or discharge (use)
the battery pack until the remaining
battery level becomes 30 % to 40 %
and store it in a cool, dry place.
This computer prevents overcharg-
ing of the battery by recharging only
when the remaining power is less
than approx. 95 % of capacity.
The battery pack is not charged
when the computer is first pur-
chased. Be sure to charge it before
using it for the first time. When the
AC adaptor is connected to the
computer, charging begins automat-
ically.
CPE02825ZAFZ-M1mk1-8.1OIE.indb7CPE02825ZAFZ-M1mk1-8.1OIE.indb7 2014/02/1413:03:342014/02/1413:03:34

8
Read Me First
Safety Precautions
Should the battery leak and the fluid
get into your eyes, do not rub your
eyes. Immediately flush your eyes
with clear water and see a doctor
for medical treatment as soon as
possible.
NOTE
The battery pack may become
warm during recharging or normal
use. This is completely normal.
Recharging will not commence if
internal temperature of the battery
pack is outside of the allowable
temperature range (0 °C to 50 °C).
(Reference Manual “Battery
Power”) Once the allowable range
requirement is satisfied, charging
begins automatically. Note that the
recharging time varies based on
the usage conditions. (Recharging
takes longer than usual when the
temperature is 10 °C or below.)
If the temperature is low, the operat-
ing time is shortened. Only use the
computer within the allowable tem-
perature range.
This computer has a high tempera-
ture mode function that prevents
the degradation of the battery in
high temperature environments.
(Reference Manual “Battery
Power”) A level corresponding to a
100 % charge for high temperature
mode is approximately equivalent
to an 80 % charge level for normal
temperature mode.
The battery pack is a consum-
able item. If the amount of time
the computer can be run by using
a particular battery pack becomes
dramatically shorter and repeated
recharging does not restore its per-
formance, the battery pack should
be replaced with a new one.
When transporting a spare battery
inside a package, briefcase, etc., it
is recommended that it be placed in
a plastic bag so that its contacts are
protected.
Always power off the computer
when it is not in use. Leaving the
computer on when the AC adaptor
is not connected will exhaust the
remaining battery capacity.
<Only for model with Built-in Bridge
Battery>
To minimize deterioration of the
built-in bridge battery, connect the
computer to the AC adaptor and re-
charge it for approximately 2 hours
about once every year.
CPE02825ZAFZ-M1mk1-8.1OIE.indb8CPE02825ZAFZ-M1mk1-8.1OIE.indb8 2014/02/1413:03:342014/02/1413:03:34

9
Read Me First
THIS PRODUCT IS NOT INTENDED
FOR USE AS, OR AS PART OF, NU-
CLEAR EQUIPMENT/SYSTEMS, AIR
TRAFFIC CONTROL EQUIPMENT/
SYSTEMS, AIRCRAFT COCKPIT
EQUIPMENT/SYSTEMS, MEDICAL
DEVICES OR ACCESSORIES*1, LIFE
SUPPORT SYSTEMS OR OTHER
EQUIPMENTS/DEVICES/SYSTEMS
THAT ARE INVOLVED WITH ENSUR-
ING HUMAN LIFE OR SAFETY.
PANASONIC WILL NOT BE RESPON-
SIBLE FOR ANY LIABILITY RE-
SULTING FROM THE USE OF THIS
PRODUCT ARISING OUT OF THE
FOREGOING USES.
*1As defined by the European Medical De-
vice Directive (MDD) 93/42/EEC.
Panasonic cannot guarantee any
specifications, technologies, reliability,
safety (e.g. Flammability/Smoke/Tox-
icity/Radio Frequency Emission, etc)
requirements related to aviation stan-
dards that exceed the specifications of
our COTS (Commercial-Off-The-Shelf)
products.
This computer is not intended for use
in medical equipment including life-
support systems, air traffic control sys-
tems, or other equipment, devices or
systems that are involved with ensuring
human life or safety. Panasonic cannot
be held responsible in any way for any
damages or loss resulting from the use
of this unit in these types of equipment,
devices or systems, etc.
This computer has been designed so
as to minimize shock to the LCD and
flash memory drive, etc., but no war-
ranty is provided against such trouble.
Therefore, as a precision instrument,
be extremely careful in the handling.
CPE02825ZAFZ-M1mk1-8.1OIE.indb9CPE02825ZAFZ-M1mk1-8.1OIE.indb9 2014/02/1413:03:342014/02/1413:03:34

10
Read Me First
<Only for model with wireless LAN/Bluetooth/wireless WAN>
This product and your Health
This product, like other radio devices, emits radio frequency electromagnetic
energy. The level of energy emitted by this product however is far much less than
the electromagnetic energy emitted by wireless devices like for example mobile
phones.
Because this product operates within the guidelines found in radio frequency
safety standards and recommendations, we believe this product is safe for use by
consumers. These standards and recommendations reflect the consensus of the
scientific community and result from deliberations of panels and committees of
scientists who continually review and interpret the extensive research literature.
In some situations or environments, the use of this product may be restricted by
the proprietor of the building or responsible representatives of the organization.
These situations may for example include:
Using this product on board of airplanes, or
In any other environment where the risk of interference to other devices or
services is perceived or identified as harmful.
If you are uncertain of the policy that applies on the use of wireless devices in a
specific organization or environment (e.g. airports), you are encouraged to ask for
authorization to use this product prior to turning on the product.
Regulatory Information
We are not responsible for any radio or television interference caused by unau-
thorized modification of this product. The correction of interference caused by
such unauthorized modification will be the responsibility of the user. We and its
authorized resellers or distributors are not liable for damage or violation of govern-
ment regulations that may arise from failing to comply with these guidelines. 26-M-1
Lithium Battery
Lithium Battery!
This computer contains a lithium battery to enable the date, time, and other data to
be stored. The battery should only be exchanged by authorized service personnel.
Warning!
A risk of explosion from incorrect installation or misapplication may possibly occur.
15-E-1
Information to the User
Regulatory Information
CPE02825ZAFZ-M1mk1-8.1OIE.indb10CPE02825ZAFZ-M1mk1-8.1OIE.indb10 2014/02/1413:03:342014/02/1413:03:34

11
Read Me First
Regulations for Wireless LAN / Bluetooth
<Only for model with wireless LAN/Bluetooth>
Country / Region 802.11a 802.11b/g
Bluetooth
Austria, Belgium, Croa-
tia, Cyprus, Czech
Republic, Denmark, Es-
tonia, Finland, France,
Germany, Greece,
Hungary, Iceland, Ire-
land, Latvia, Lithuania,
Luxembourg, Macedo-
nia, Malta, Netherlands,
Poland, Portugal, Slo-
vakia, Slovenia, Spain,
Sweden, Switzerland,
United Kingdom
Restricted to indoor use.
Italy Restricted to indoor use.
General authorization
required if used outside.
General authorization
required if used outside
of own premises.
Turkey Restricted to indoor use.
Prohibited within an 1
km radius from the cen-
tre of the runway of the
airports.
Norway Restricted to indoor use. Prohibited within a 20
km radius from the cen-
tre of Ny-Ålesund.
The latest version of “ERC RECOMMENDATION 70-03” by European Radio-
communications Committee and the regulation in Turkey.
Use only the antenna specified by Panasonic.
Confirm the latest information to the radio regulation authorities. 40-E-1
CPE02825ZAFZ-M1mk1-8.1OIE.indb11CPE02825ZAFZ-M1mk1-8.1OIE.indb11 2014/02/1413:03:342014/02/1413:03:34

12
Read Me First
Regulatory Information
Information for Users on Collection and Disposal of
Old Equipment and used Batteries
These symbols on the products, packaging, and/or accompanying
documents mean that used electrical and electronic products and
batteries should not be mixed with general household waste. For
proper treatment, recovery and recycling of old products and used
batteries, please take them to applicable collection points, in ac-
cordance with your national legislation and the Directives 2002/96/
EC and 2006/66/EC. By disposing of these products and batteries
correctly, you will help to save valuable resources and prevent any
potential negative effects on human health and the environment
which could otherwise arise from inappropriate waste handling. For
more information about collection and recycling of old products and
batteries, please contact your local municipality, your waste disposal
service or the point of sale where you purchased the items. Penalties
may be applicable for incorrect disposal of this waste, in accordance
with national legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment, please
contact your dealer or supplier for further information.
[Information on Disposal in other Countries outside the Euro-
pean Union]
These symbols are only valid in the European Union. If you wish to
discard this product, please contact your local authorities or dealer
and ask for the correct method of disposal.
Note for the battery symbol (bottom two symbol examples):
This symbol might be used in combination with a chemical symbol. In
this case it complies with the requirement set by the Directive for the
chemical involved.
53-E-1
CPE02825ZAFZ-M1mk1-8.1OIE.indb12CPE02825ZAFZ-M1mk1-8.1OIE.indb12 2014/02/1413:03:342014/02/1413:03:34

13
Read Me First
<Only for model with wireless WAN>
The following safety precautions must be observed during all phases of the opera-
tion, usage, service or repair of any Personal Computer or Handheld Computer
incorporating wireless WAN modem. Manufacturers of the cellular terminal are
advised to convey the following safety information to users and operating person-
nel and to incorporate these guidelines into all manuals supplied with the prod-
uct. Failure to comply with these precautions violates safety standards of design,
manufacture and intended use of the product. Panasonic assumes no liability for
customer failure to comply with these precautions.
When in a hospital or other health care facility, observe the restrictions
on the use of mobiles. Switch Personal Computer or Handheld Computer
incorporating wireless WAN modem off, if instructed to do so by the guide-
lines posted in sensitive areas. Medical equipment may be sensitive to RF
energy.
The operation of cardiac pacemakers, other implanted medical equipment
and hearing aids can be affected by interference from Personal Computer
or Handheld Computer incorporating wireless WAN modem placed close
to the device. If in doubt about potential danger, contact the physician or
the manufacturer of the device to verify that the equipment is properly
shielded. Pacemaker patients are advised to keep their Personal Computer
or Handheld Computer incorporating wireless WAN modem away from the
pacemaker, while it is on.
Switch off Personal Computer or Handheld Computer incorporating wire-
less WAN modem before boarding an aircraft. Make sure it cannot be
switched on inadvertently. The operation of wireless appliances in an
aircraft is forbidden to prevent interference with communications systems.
Failure to observe these instructions may lead to the suspension or denial
of cellular services to the offender, legal action, or both.
For details on usage of this unit in aircrafts please consult and follow in-
struction provided by the airline.
Do not operate Personal Computer or Handheld Computer incorporat-
ing wireless WAN modem in the presence of flammable gases or fumes.
Switch off the cellular terminal when you are near petrol stations, fuel de-
pots, chemical plants or where blasting operations are in progress. Opera-
tion of any electrical equipment in potentially explosive atmospheres can
constitute a safety hazard.
Safety Precautions
CPE02825ZAFZ-M1mk1-8.1OIE.indb13CPE02825ZAFZ-M1mk1-8.1OIE.indb13 2014/02/1413:03:342014/02/1413:03:34

14
Read Me First
Regulatory Information
Your Personal Computer or Handheld Computer incorporating wire-
less WAN modem receives and transmits radio frequency energy while
switched on. Remember that interference can occur if it is used close to
TV sets, radios, computers or inadequately shielded equipment. Follow
any special regulations and always switch off Personal Computer or Hand-
held Computer incorporating wireless WAN modem wherever forbidden,
or when you suspect that it may cause interference or danger.
Road safety comes first! Do not use a Personal Computer or Handheld
Computer incorporating wireless WAN modem while driving a vehicle. Do
not place the computer with wireless WAN modem in an area where it
could cause personal injury to the driver or passengers. It is recommend-
ed to stow the unit in the boot or secure stowage area while driving.
Do not place the computer with wireless WAN modem in an area over an
air bag or in the vicinity where an air bag may deploy.
Air bags inflate with great force and if the computer with wireless WAN
modem is placed in the air bag deployment area may be propelled with
great force and cause serious injury to occupants of the vehicle.
IMPORTANT!
Personal Computer or Handheld Computer incorporating wireless WAN
modem operate using radio signals and cellular networks cannot be guar-
anteed to connect in all conditions. Therefore, you should never rely solely
upon any wireless device for essential communications, for example
emergency calls.
Remember, in order to make or receive calls, Personal Computer or Hand-
held Computer incorporating wireless WAN modem must be switched on
and in a service area with adequate cellular signal strength.
Some networks do not allow for emergency calls if certain network ser-
vices or phone features are in use (e.g. lock functions, fixed dialing etc.).
You may need to deactivate those features before you can make an emer-
gency call.
Some networks require that a valid SIM card be properly inserted in Per-
sonal Computer or Handheld Computer incorporating wireless WAN mo-
dem.
CAUTION:
Risk of Explosion if Battery is replaced by an Incorrect Type.
Dispose of Used Batteries According to the Instructions.
58-E-1
Interface Cable
Use of an interface cable longer than 3 m (9.84 feet) is not recommended.
11-E-1
CPE02825ZAFZ-M1mk1-8.1OIE.indb14CPE02825ZAFZ-M1mk1-8.1OIE.indb14 2014/02/1413:03:342014/02/1413:03:34

15
Read Me First
For Europe
<Only for model with a “CE ” mark on the bottom of the
computer>
Declaration of Conformity (DoC)
“Hereby, Panasonic declares that this Personal Computer is in
compliance with the essential requirements and other relevant
provisions of the Directive 1999/5/EC.”
Hint:
If you want to get a copy of the original DoC of our above mentioned products,
please contact our web address: http://www.doc.panasonic.de
Authorised Representative:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
Indication of the countries where WLAN is intended to be used:
AT BE BG CH CY CZ DE DK EE ES
FI FR GB GR HU IE IS IT LT LU
LV MT NL NO PL PT RO SE SI SK TR
18-25-E-0
Camera Light
<For model with rear camera>
CAUTION
- The light from the LED is strong and can injure human eyes. Do not look directly
at the LEDs with naked eyes. 57-E-1
CPE02825ZAFZ-M1mk1-8.1OIE.indb15CPE02825ZAFZ-M1mk1-8.1OIE.indb15 2014/02/1413:03:342014/02/1413:03:34

16
Read Me First
Regulatory Information
<Only for model with a “CE” mark on the bottom of the computer>
Declaration of Conformity (DoC)
“Hereby, Panasonic Corporation declares that this Personal Com-
puter is in compliance with the essential requirements and other
relevant provisions of Eu Council Directives.
Authorised Representative:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
18-E-0
For Used in Motor Vehicle
Warning: Check the following Commission Recommendation to determine proper
installation and usage of this product while operating within a motor vehicle.
“Commission Recommendation on safe and efficient in-vehicle information and
communication systems: A European statement of principles on human machine
interface.”
Commission Recommendation is available from Official Journal of the European
Communities. 35-E-1
When using Port Replicator or Car Mounter on which an external antenna
can be installed:
• External antenna for wireless LAN must be professionally installed.
• The gain of external antenna for wireless LAN must not exceed 5dBi.
• The user must maintain minimum of 20 cm spacing between the external anten-
na and all people (excluding extremities of hands, wrist and feet) during wireless
modes of operation. 41-E-1-1
For UK
For your safety, please read the following text carefully.
This appliance is supplied with a molded three pin mains plug for your safety and
convenience.
A 3 ampere fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that the replacement fuse has
a rating of 3 ampere and that it is approved by ASTA or BSI to BS1362.
Check for the ASTA mark A S A or the BSI mark on the body of the fuse.
If the plug contains a removable fuse cover you must ensure that it is refitted when the
fuse is replaced.
If you lose the fuse cover the plug must not be used until a replacement cover is
obtained. A replacement fuse cover can be purchased from your local dealer.
If the fitted molded plug is unsuitable for the socket outlet in your home then the
fuse should be removed and the plug cut off and disposed of safely.
There is a danger of severe electrical shock if the cut off plug is inserted into any
13-ampere socket.
CPE02825ZAFZ-M1mk1-8.1OIE.indb16CPE02825ZAFZ-M1mk1-8.1OIE.indb16 2014/02/1413:03:342014/02/1413:03:34

17
Read Me First
How to replace the fuse
The location of the fuse differs according to the type of AC mains plug
(figures A and B).
Confirm the AC mains plug fitted and follow the instructions below. Illus-
trations may differ from actual AC mains plug.
Open the fuse cover with a screwdriver and replace the fuse and close or at-
tach the fuse cover.
Figure A Figure B
Fuse cover
8-E-1
For Turkey / Turkiye icin.
AEEE complies with Directive of Turkey.
AEEE Yönetmeligine Uygundur.
For India
For the purpose of recycling to facilitate effective utilization of resources,
please return this product to a nearby authorized collection center, regis-
tered dismantler or recycler, or Panasonic service center when dispos-
ing of this product.
Please see the Panasonic website for further information on collection
centers, etc.
http://www.panasonic.co.in/wps/portal/home 68-M-1
CPE02825ZAFZ-M1mk1-8.1OIE.indb17CPE02825ZAFZ-M1mk1-8.1OIE.indb17 2014/02/1413:03:342014/02/1413:03:34

18
Getting Started
Introduction
Thank you for purchasing this Panasonic product. For optimum performance and
safety, please read these instructions carefully.
In these instructions, the names are referred as follows.
indicates Windows®8.1 Operating System.
indicates Windows®7 Operating System.
Terms and illustrations in these instructions
CAUTION : Conditions that may result in minor or moderate
injury.
NOTE : Useful and helpful information.
Enter
: Press [Enter] key.
Alt
+
Del
: Press and hold [Alt] key, and then press [Del]
key.
: Page in these Operating Instructions or in the
Reference Manual.
: Reference to the on-screen manuals.
Display “Charm”: Align the cursor to the top right (or bottom right)
corner of the screen to display Charm menu.
Alternatively:
Flick toward the center of the screen from the
right edge.
- : Touch (Settings) and then touch (Power).
(Start) - [All Programs] : Touch (Start), and then touch [All Programs].
Some illustrations are simplified to help your understanding and may look dif-
ferent from the actual unit.
If you do not log on as an administrator, you cannot use some functions or
cannot display some screens.
Refer for the latest information about optional products to the catalogs, etc.
In these instructions, the names and terms are referred as follows.
“Windows®8.1 Pro 64-bit” as “Windows” or “Windows 8.1”
“Windows®7 Professional 32-bit Service Pack 1” and “Windows®7 Profes-
sional 64-bit Service Pack 1” as “Windows” or “Windows 7”
“Multilingual User Interface” as “MUI”
CPE02825ZAFZ-M1mk1-8.1OIE.indb18CPE02825ZAFZ-M1mk1-8.1OIE.indb18 2014/02/1413:03:352014/02/1413:03:35

19
Getting Started

Screen messages are explained in [English (United States)].
(Depending on the language preference, some screen messages in these
instructions are different from the actual screen messages. For example, [Flight
mode] may be displayed instead of [Airplane mode] in some language prefer-
ence.)
Disclaimer
Computer specifications and manuals are subject to change without notice.
Panasonic Corporation assumes no liability for damage incurred directly or in-
directly from errors, omissions or discrepancies between the computer and the
manuals.
Trademarks
Microsoft®, Windows®, and the Windows logo are registered trademarks of Micro-
soft Corporation of the United States and/or other countries.
Intel, Core, Centrino and PROSet are either registered trademarks or trademarks
of Intel Corporation.
microSDXC Logo is a trademark of SD-3C, LLC.
Adobe, the Adobe logo and Adobe Reader are either registered trademarks or
trademarks of Adobe Systems Incorporated in the United States and/or other
countries.
Bluetooth®is a registered trademark owned by Bluetooth SIG, Inc., U.S.A. and
licensed to Panasonic Corporation.
HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other coun-
tries.
Names of products, brands, etc., appearing in this manual are trademarks or reg-
istered trademarks of their respective own companies.
CPE02825ZAFZ-M1mk1-8.1OIE.indb19CPE02825ZAFZ-M1mk1-8.1OIE.indb19 2014/02/1413:03:352014/02/1413:03:35

20
Getting Started
Introduction
On-screen Manual
For further information about the computer, you can refer to the on-screen manual.
Reference Manual
The Reference Manual contains the practical information to help you fully enjoy
the computer’s performance.
Important Battery Tips
The Important Battery Tips will provide you with the battery information so that
you can use the battery in the optimum condition to obtain longer operation
time.
To access the on-screen manuals, follow the steps below.
On the Start screen, touch the [Manual Selector] tile, and select the on-screen
manual.
Double-touch [Manual Selector] on the desktop screen, and select the on-screen
manual.
NOTE
[Contents] tab or [Search] tab is displayed on the left side of the window.
Select tab and display the desired item.
CPE02825ZAFZ-M1mk1-8.1OIE.indb20CPE02825ZAFZ-M1mk1-8.1OIE.indb20 2014/02/1413:03:352014/02/1413:03:35
