Panasonic KX-FPC135 User manual

© 1999 Kyushu Matsushita Electric Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
KX-FPC135
KX-FPC141
(for U.S.A.)
Plain Paper FAX With 900 MHz Cordless Phone
ORDER NO. KM79906281C1
F7

1 INTRODUCTION 4
1.1. SAFETY PRECAUTIONS 4
1.2. INSULATION RESISTANCE TEST 4
1.3. FOR SERVICE TECHNICIANS 4
1.4. BATTERY CAUTION 4
1.5. AC CAUTION 5
1.6. PERSONAL SAFETY PRECAUTIONS 5
1.7. SERVICE PRECAUTIONS 6
1.8. FEATURES 7
1.9. SPECIFICATIONS 8
1.10. OPTIONAL ACCESSORIES 9
1.11. CCITT No. 1 Test Chart (Actual size) 10
1.12. LOCATION OF CONTROLS 11
1.13. CONNECTIONS 16
1.14. INSTALLATION 18
1.15. MAINTENANCE ITEMS AND COMPONENT LOCATIONS
28
2 TROUBLESHOOTING GUIDE 32
2.1. TROUBLESHOOTING SUMMARY 32
2.2. USER RECOVERABLE ERRORS 33
2.3. TROUBLESHOOTING DETAILS 36
2.4. PROGRAMMING AND LISTS 101
2.5. TEST FUNCTIONS 116
3 ADJUSTMENTS 122
3.1. TABLE OF TEST EQUIPMENT AND TOOLS 122
3.2. ADJUSTING THE FEEDER PRESSURE 122
3.3. CONFIRMING THE SEPARATION SPRING 122
3.4. DOCUMENT READ START POSITION ADJUSTMENT
123
3.5. CORDLESS BASE BOARD 124
3.6. Objective 127
3.7. General Information 127
3.8. Equipment 127
3.9. Handset Preparation 127
3.10. Symptom/Remedy Table 127
3.11. Handset Adjustment Preparation 127
3.12. Adjustment Procedure 128
3.13. Handset Reference Drawing 129
4 HOW TO CHECK THE RF UNIT 130
4.1. Handset 130
5 DISASSEMBLY INSTRUCTIONS 131
6 HOW TO REPLACE THE FLAT PACKAGE IC 145
6.1. PREPARATION 145
6.2. FLAT PACKAGE IC REMOVAL PROCEDURE 145
6.3. FLAT PACKAGE IC INSTALLATION PROCEDURE 146
6.4. BRIDGE MODIFICATION PROCEDURE 146
7 CIRCUIT OPERATIONS 147
7.1. CONNECTION DIAGRAM 147
7.2. GENERAL BLOCK DIAGRAM 148
7.3. CONTROL SECTION 150
7.4. FACSIMILE SECTION 161
7.5. SENSORS AND SWITCHES 176
7.6. MODEM SECTION 180
7.7. DESCRIPTION OF BLOCK DIAGRAM IN ANALOG
SECTION 187
7.8. NCU SECTION 189
7.9. ITS (Integrated telephone System) and MONITOR
SECTION (for KX-FPC135) 193
7.10. ITS (Integrated telephone System) and MONITOR
SECTION (for KX-FPC141) 194
7.11. ATAS (Automatic Telephone Answering System)
SECTION 194
7.12. TAM INTERFACE SECTION (for KX-FPC135 only) 195
7.13. OPERATION BOARD SECTION 197
7.14. LCD SECTION 198
7.15. POWER SUPPLY BOARD SECTION 199
8 CORDLESS SECTION 202
8.1. Charge Circuit 202
8.2. Line Sending Signal 202
8.3. Line Receiving Signal 203
8.4. RX Data Circuit 203
8.5. ID Code Setting 203
9 HANDSET SECTION 204
9.1. Block diagram 204
9.2. Carrier detection circuit 206
9.3. Security code 207
9.4. CPU DATA 208
9.5. BLOCK DIAGRAM (Handset) 209
9.6. NEW CIRCUIT OPERATION (Handset) 210
10 EXPLANATION OF CPU DATA COMMUNICATION 212
10.1. Calling 212
10.2. To Terminate Communication 212
10.3. Ringing 212
10.4. Ports for Transmitting and Receiving of Data 212
10.5. Waveform of DATA Used for Cordless Transmission and
Reception 213
10.6. When LINKing 214
10.7. Pulse Dial 214
10.8. Tone Dial 214
10.9. FREQUENCY TABLE (MHz) 214
11 FOR THE SCHEMATIC DIAGRAMS 215
11.1. MEMO 216
12 PRINTED CIRCUIT BOARD (DIGITAL BOARD) 217
12.1. PRINTED CIRCUIT BOARD 217
12.2. PRINTED CIRCUIT DIAGRAM (DIGITAL BOARD) 218
13 PRINTED CIRCUIT BOARD (ANALOG BOARD) 219
13.1. PRINTED CIRCUIT BOARD 219
13.2. PRINTED CIRCUIT BOARD 220
14 PRINTED CIRCUIT BOARD (OPERATION BOARD) 221
15 PRINTED CIRCUIT BOARD (SWITCHING POWER SUPPLY)223
16 PRINTED CIRCUIT BOARD (HANDSET BOARD AND CHARGE
BOARD) 225
17 SCHEMATIC DIAGRAM (DIGITAL BOARD) 227
CONTENTS
Page Page
2
KX-FPC135 / KX-FPC141

17.1. SCHEMATIC DISGRAM (DIGITAL BOARD) (KX-FPC135)
227
17.2. SCHEMATIC DISGRAM (DIGITAL BOARD) (KX-FPC141)
228
18 SCHEMATIC DISGRAM (ANALOG BOARD) (KX-FPC135) 229
18.1. SCHEMATIC DISGRAM (ANALOG BOARD) (KX-FPC135)
229
18.2. SCHEMATIC DISGRAM (ANALOG BOARD) (KX-FPC141)
230
19 SCHEMATIC DIAGRAM (OPERATION BOARD) 231
19.1. SCHEMATIC DISGRAM (OPERATION BOARD) (KX-
FPC135) 231
19.2. SCHEMATIC DISGRAM (OPERATION BOARD) (KX-
FPC141) 232
20 SCHEMATIC DIAGRAM (SWITCHING POWER SUPPLY) 233
21 SCHEMATIC DIAGRAM (HANDSET BOARD AND CHARGE) 235
21.1. SCHEMATIC DIAGRAM (HANDSET BOARD AND
CHARGE) (KX-FPC135) 235
21.2. SCHEMATIC DIAGRAM (HANDSET BOARD AND
CHARGE) (KX-FPC141) 236
22 TERMINAL GUIDE OF THE IC´S TRANSISTORS AND DIODES
237
23 FIXTURES AND TOOLS 238
24 CABINET, MECHANICAL AND ELECTRICAL PARTS
LOCATION 239
24.1. OPERATION PANEL SECTION 239
24.2. UPPER CABINET SECTION 240
24.3. LOWER/P.C.B. SECTION 242
24.4. MOTOR SECTION 243
24.5. HANDSET SECTION 244
24.6. ACTUAL SIZE OF SCREWS AND WASHER 245
25 ACCESSORIES AND PACKING MATERIALS 246
26 REPLACEMENT PARTS LIST 247
26.1. CABINET AND ELECTRICAL PARTS 247
26.2. DIGITAL BOARD PARTS 249
26.3. ANALOG BOARD PARTS 254
26.4. OPERATION BOARD PARTS 259
26.5. POWER SUPPLY BOARD PARTS 260
26.6. CHARGE BOARD 261
26.7. HANDSET BOARD 261
26.8. FIXTURES AND TOOLS 263
3
KX-FPC135 / KX-FPC141

1 INTRODUCTION
1.1. SAFETY PRECAUTIONS
1.Before servicing, unplug the AC power cord to prevent an electric shock.
2.When replacing parts, use only the manufacturer´s recommended components.
3.Check the condition of the power cord. Replace if wear or damage is evident.
4.After servicing, be sure to restore the lead dress, insulation barriers, insulation papers, shields, etc.
5.Before returning the serviced equipment to the customer, be sure to perform the following insulation resistance test to prevent
the customer from being exposed to shock hazards.
1.2. INSULATION RESISTANCE TEST
1.Unplug the power cord and short the two prongs of the plug with a jumper wire.
2.Turn on the power switch.
3.Measure the resistance value with an ohmmeter between the jumpered AC plug and each exposed metal cabinet part
(screwheads, control shafts, bottom frame, etc.).
Note: Some exposed parts may be isolated from the chassis by design. These will read infinity.
4.If the measurement is outside the specified limits, there is a possibility of a shock hazard.
1.3. FOR SERVICE TECHNICIANS
ICs and LSIs are vulnerable to static electricity.
When repairing, the following precautions will help prevent recurring malfunctions.
1.Cover the plastic part´s boxes with aluminum foil.
2.Ground the soldering irons.
3.Use a conductive mat on the worktable.
4.Do not touch the IC or LSI pins with bare fingers.
1.4. BATTERY CAUTION
CAUTION
Danger of explosion if the battery is replaced incorrectly. Replace only with the same or equivalent type recommended by the
manufacturer. Discard used batteries according to following caution:
Disposal of lithium batteries should be performed by permitted, professional disposal firms knowledgeable in state government
federal and local hazardous materials and hazardous waste transportation and disposal requirements.
A battery continues to have no transportation limitations as long as it is separated to prevent short circuits and packed in strong
packaging.
Commercial firms that dispose of any quantity of lithium cells should have a mechanism in place to account for their ultimate
disposition. This is a good practice for all types of commercial or industrial waste.
Recommend Type Number:
CR2032 (BATT) Manufactured by MATSUSHITA
CR2032 (BATT) Manufactured by SONY
4
KX-FPC135 / KX-FPC141

1.5. AC CAUTION
For safety, before closing the lower cabinet, please make sure of the following precautions.
1.The earth lead is fixed with the screw.
2.The AC connector is connected properly.
3.Wrap the earth lead around the core 3 times.
(BOTTOM VIEW)
1.6. PERSONAL SAFETY PRECAUTIONS
1.6.1. MOVING SECTIONS OF THE UNIT
Be careful not to let your hair, clothes, fingers, accessories, etc., become caught in any moving sections of the unit.
The moving sections of the unit are the rollers and a gear. There is a separation roller and a document feed roller which are rotated
by the document feed motor. A gear rotates the two rollers. Be careful not to touch them with your hands, especially when the unit
is operating.
1.6.2. LIVE ELECTRICAL SECTIONS
All the electrical sections of the unit supplied with AC power by the AC power cord are live.
Never disassemble the unit for service with the AC power supply plugged in.
CAUTION:
AC voltage is supplied to the primary side of the power supply unit. Therefore, always unplug the AC power cord before
disassembling for service.
(Bottom View)
5
KX-FPC135 / KX-FPC141

1.7. SERVICE PRECAUTIONS
1.7.1. PRECAUTIONS TO PREVENT DAMAGE FROM STATIC ELECTRICITY
Electrical charges accumulate on a person. For instance, clothes rubbing together can damage electric elements or change their
electrical characteristics. In order to prevent static electricity, touch a metallic part that is grounded to release the static electricity.
Never touch the electrical sections such as the power supply unit, etc.
6
KX-FPC135 / KX-FPC141

General
•• Help function
Display:
1.SEND GUIDE (KX-FPC141 only)
2.HOW TO SET UP
3.JOG/AUTO DIAL
4.TAD OPERATION (KX-FPC141 only)
5.FAX SENDING
6.FAX RECEIVING
7.COPIER
8.Q and A
9.ERRORS
10.REPORTS
11.CALLER ID
•• LCD (Liquid Crystal Display) readout
•• IQ-FAXTM (for U.S.A. only)
This feature can only be used by those who apply to the
FaxSav service.
IQ-FAX is intelligent faxing which allows you to send faxes
via the internet by using the IQ-FAX button.
Behind the IQ-FAX button is the FaxSav Global Fax
Network which manages the delivery of your fax to any fax
machine in the world. It routes your fax via the best and
most time efficient route and will automatically resend your
fax for you, if the receiving fax machine is unavailable.
This "fax-only" network has the added advantage of cost
efficiency due to the internet being integrated into the net
work. Every fax is secure since the FaxSav net work utilizes
the highest encryption legally allowed, ensuring that your
documents stay secure. You get the benefits of carefree
faxing with savings associated with the use of the internet.
It is simple, quick, and secure.
Digital Answering System (KX-FPC141 only)
•• Voice Time/Day Stamp
•• 18-Minutes recording time
•• Voice guidance for remote operation
•• Voice and fax paper call
Plain Paper Facsimile Machine
•• 15 second transmission speed * (KX-FPC135)
•• 9 second transmission speed * (KX-FPC141)
•• Letter/Legal, G3 compatible
•• Automatic document feeder (15 sheets)
•• 6 stations one-touch dialer
•• Broadcast (up to 20 station) x 3
•• Resolution : Standard/Fine/Super fine/Half tone (64 level)
•• LCD Contrast : Normal/Darker
•• Delayed transmission
•• Overseas transmission function
•• Remote FAX receiving using an extension phone
•• 150-sheet paper capacity
•• Automatic fax/phone switching
•• Distinctive ring detection **
•• High speed 14400 bps fax modem (KX-FPC141 only)
•• Caller ID
•• Out of paper reception (up to 28 papers) ***
* The 15 second speed (KX-FPC135), 9 second speed (KX-
FPC141) is based upon the CCITT No. 1 Test Chart on the
condition that memory transmission is performed.
** Subscription to distinctive ring services required.
*** 350KB memory. Actual number of Pages depends upon the
contents of the Pages and the resolution. 28-page capacity
based upon CCITT No. 1 Test Chart at standard resolution.
Large Memory (28 pages) Performed by DRAM
Approx. 28 pages of memory reception
Approx. 25 pages of memory transmission
Integrated Telephone System
•• On-hook dialing
•• Digital duplex speakerphone (KX-FPC141 only)
•• Voice muting
•• Redialing function
•• 100-Station telephone directory with Jog Dial
•• One-Touch dial (3x2 Phone Numbers)
Copier function
•• Multi-copy function (up to 99 copies)
•• Enlargement and reduction
•• Collate
•• 64-Level halftone
•• Electronic film indicator
900 MHz Cordless
•• Fax activation from handset
•• Intercom with 2 way paging (KX-FPC141 only)
•• 21 day battery life
•• 10-station speed dial
•• Remoto speakerphone
•• Handset Compatible
•• Ultra Change™ 4-Hour Battery Charging System
1.8. FEATURES
7
KX-FPC135 / KX-FPC141

1.9. SPECIFICATIONS
These specifications are for the U.S.A. version only. Refer to the simplified manual (cover) for other areas.
■Main unit
Applicable Lines: Public Switched Telephone Network
Document Size: Max. 216 mm (8 1/2") in width
Max. 600 mm (23 5/8") in length
Effective Scanning Width: 208 mm (8 3/16")
Recording Paper Size: Letter: 216×279 mm (8 1/2"×11")
Legal: 216×356 mm (8 1/2"×14")
Effective Printing Width: 208 mm (8 3/16")
Transmission Time*: Approx. 9 sec./page (Original mode)**.... KX-FPC141 only,
15 sec./page (Original mode)**.... KX-FPC135 only
Scanning Density: Horizontal:
8 pels/mm (203 pels/inch)
Vertical:
3.85 lines/mm (98 lines/inch)—STANDARD mode
7.7 lines/mm (196 lines/inch)—FINE/HALF TONE mode
15.4 lines/mm (392 lines/inch)—SUPER FINE mode
Halftone Level: 64-level
Scanner Type: Contact Image Sensor (CIS)
Printer Type: Thermal Printing
Data Compression System: Modified Huffman (MH), Modified READ (MR)
Modem Speed: 14,400/12,000/9,600/7,200/4,800/2,400 bps; Automatic Fallback .... KX-FPC141 only
9,600/7,200/4,800/2,400 bps; Automatic Fallback .... KX-FPC135 only
Operating Environment: 5—35°C (41—95°F), 20—80 % RH(Relative Humidity)
Dimensions (H×W×D): 143×345×305 mm (5 5/8"×13 9/16"×12")
Mass (Weight): Approx. 4.4 kg (9.7 lb.)
Power Consumption: Standby: Approx. 11 W
Transmission: Approx. 18 W
Reception: Approx. 42 W (When receiving a 20% black document)
Copy: Approx. 48 W (When copying a 20% black document)
Maximum: Approx. 160 W (When copying a 100% black document)
Power Supply: 120 V AC, 60 Hz (This unit will not function at 50 Hz.)
Memory Capacity: Voice memory: Approx. 18 minutes of recording time including the greeting
message***.... KX-FPC141 only
Fax memory:
Approx. 28 pages memory reception
Approx. 25 pages memory transmission
(Based on the CCITT of No. 1 Test Chart in standard resolution.)
■Handset
Operating Environment: 5—35°C (41—95°F), 45—85 % RH(Relative Humidity)
Dimensions (H×W×D): Approx. 39×55×271 mm (1 17/32"×2 5/32"×10 11/16")
Mass (Weight): Approx. 200 g (0.4 lb.)
Power Supply: Ni-Cd battery (3.6 V, 600 mAh)
Frequency: 926 MHz-927 MHz, 902 MHz-903 MHz (30 channels)
Security Codes: 1,000,000
* Transmission speed depends upon the contents of the pages, resolution, telephone line conditions and capability of the receiving
unit.
** The 9 second speed is based upon the CCITT No. 1 Test Chart on the condition that memory transmission is performed. .... KX-
FPC141 only
** The 15 second speed is based upon the CCITT No. 1 Test Chart and original mode. If the capability of the other party´s machine
is inferior to your unit, the transmission time may be longer. .... KX-FPC135 only
*** Recording time may be reduced by the calling party´s background noise. .... KX-FPC141 only
8
KX-FPC135 / KX-FPC141

Design and specifications are subject to change without notice.
Note:
•• Any details given in these instructions are subject to change without notice.
•• The pictures and illustrations in these instructions may vary slightly from the actual product.
1.10. OPTIONAL ACCESSORIES
Note:
•• The film cartridge is not reusable. Do not rewind and use the film again.
9
KX-FPC135 / KX-FPC141

1.11. CCITT No. 1 Test Chart (Actual size)
10
KX-FPC135 / KX-FPC141

1.12. LOCATION OF CONTROLS
1.12.1. OVERVIEW
Note:
•• The document and recording paper will be ejected from the front of the unit. Install the unit on a desk or floor with a smooth
surface and do not place anything in front of the unit.
11
KX-FPC135 / KX-FPC141

1.12.2. LOCATION (HANDSET) (KX-FPC135)
12
KX-FPC135 / KX-FPC141

1.12.3. LOCATION (HANDSET) (KX-FPC141)
13
KX-FPC135 / KX-FPC141

1.12.4. CONTROL PANEL (KX-FPC135)
(Model KX-FPC135)
14
KX-FPC135 / KX-FPC141

1.12.5. CONTROL PANEL (KX-FPC141)
(Model KX-FPC141)
15
KX-FPC135 / KX-FPC141

1.13. CONNECTIONS
1.13.1. CONNECTIONS (KX-FPC135)
This connection is for the U.S.A. version only. Refer to the simplified manual (cover) for other areas.
Automatic dialing mode setting
When the telephone line cord and the power cord are connected, the unit will automatically start to detect
the dialing mode of your telephone line.
Display:
Wait until one of the following messages is displayed.
Your line has touch tone service.
Your line has rotary pulse dial service.
If the power cord is disconnected or a power failure occurs, the unit will detect the dialing mode again when
power is restored.
If you connect the power cord before connecting the telephone line cord, the following messages will be
shown alternately.
Connect the telephone line cord.
(Model KX-FPC135)
INSERT TEL LINENO TEL LINE
LINE IS PULSE
LINE IS TONE
CHECKING LINE
Wall jack
(RJ11C)
120 V, 60 Hz
Telephone
line cord
Power cord
Power surge
protector
( )
Line surge
protector
( )
Connect to “LINE”.
1
Connect the telephone line cord.
2
Connect the power cord.
The unit will automatically start to
detect the dialing mode of your
telephone line (see below).
When the power is turned on for the
first time, the unit will print some
basic information.
Note:
For additional equipment protection, we recommend the use of a surge protector. The following types are
available; TELESPIKE BLOK MODEL TSB (TRIPPE MFG. CO.), SPIKE BLOK MODEL SK6-0 (TRIPPE
MFG. CO.), SUPER MAX (PANAMAX) or MP1 (ITW LINX).
The warranty does not cover damage due to power line surges or lightning.
When
If you went to connect an answering machine to the unit.
you operate this product, the power outlet should be near the product and easily accessible.
2
1
16
KX-FPC135 / KX-FPC141

1.13.2. CONNECTIONS (KX-FPC141)
This connection is for the U.S.A. version only. Refer to the simplified manual (cover) for other areas.
Automatic dialing mode setting
When the telephone line cord and the power cord are connected, the unit will automatically start to detect
the dialing mode of your telephone line.
Display:
Wait until one of the following messages is displayed.
Your line has touch tone service.
Your line has rotary pulse dial service.
If the power cord is disconnected or a power failure occurs, the unit will detect the dialing mode again when
power is restored.
If you connect the power cord before connecting the telephone line cord, the following messages will be
shown alternately.
Connect the telephone line cord. (Model KX-FPC141)
INSERT TEL LINENO TEL LINE
LINE IS PULSE
LINE IS TONE
CHECKING LINE
Wall jack
(RJ11C)
120 V, 60 Hz
Telephone
line cord
Power cord
Power surge
protector
( )
Line surge
protector
( )
1
Connect the telephone line cord.
2
Connect the power cord.
The unit will automatically start to
detect the dialing mode of your
telephone line (see below).
When the power is turned on for the
first time, the unit will print some
basic information.
Note:
For additional equipment protection, we recommend the use of a surge protector. The following types are
available; TELESPIKE BLOK MODEL TSB (TRIPPE MFG. CO.), SPIKE BLOK MODEL SK6-0 (TRIPPE
MFG. CO.), SUPER MAX (PANAMAX) or MP1 (ITW LINX).
The warranty does not cover damage due to power line surges or lightning.
When you operate this product, the power outlet should be near the product and easily accessible.
2
1
17
KX-FPC135 / KX-FPC141

1.14. INSTALLATION
1.14.1. INSTALLATION SPACE
The space required to install the unit is shown below.
The dimensions given are necessary for the unit to operate efficiently.
Note:
•• Avoid excessive heat or humidity.
•• Use the unit within the following ranges of temperature and humidity.
•• Ambient temperature: 5°C to 35°C
•• Relative humidity: 20% to 80% (without condensation)
•• Power cord length should be less than 5 meters (16.4 feet). Using a longer cord may reduce the voltage or cause
malfunctions.
•• Avoid direct sunlight.
•• Do not install near devices which contain magnets or generate magnetic fields.
•• Do not subject the unit to strong physical shock or vibration.
•• Keep the unit clean. Dust accumulation can prevent the unit from functioning properly.
•• To protect the unit from damage, hold both sides when you move it.
18
KX-FPC135 / KX-FPC141

1.14.2. INSTALLING THE PAPER STACKER
1Remove the shipping tape from the paper stacker.
2Lift the front of the unit and hold the aluminum
sheet up to prevent it being bent by the paper
stacker while inserting the paper stacker into the
side slots.
Paper stacker
Shipping tape
Side slots
Bottom
Aluminum sheet
3Confirm that the paper stacker is locked into the
center slots and slide back. Center slots
Paper
stacker
4Slide the paper stacker forward until it stops.
Paper stacker
1.14.3. USING LEGAL SIZE PAPER
1Press the dotted area on the paper stacker
extender.
Paper stacker extender
Dotted area
2Open the paper stacker extender.
Paper stacker
extender
19
KX-FPC135 / KX-FPC141

1.14.4. INSTALLING THE PAPER TRAY
Insert the two tabs on the paper tray into the slots on the
back of the unit.
Do not place the unit in areas where the paper tray
may be obstructed by a wall etc.
Tabs
Slots
Paper tray
20
KX-FPC135 / KX-FPC141
