Supplementary Instructions
for Fingerprint Reader
NOTE: Useful and helpful information.
CAUTION: Condition that may result in minor or moderate injury.
<Model with Windows XP>
[start] - [Run]: Click [start], and then click [Run].
<Model with Windows Vista>
(Start) - [All Programs]:
Click (Start), and then click [All Programs].
Î: Page in these Supplementary Instructions or in the
Reference Manual for the computer.
Some of the illustrations in this manual may differ slightly in shape from the
actual items in order to make the explanation easier to understand.
Terms and illustrations in this Manual
Contents
Names and Functions of Parts ................................... 2
Overview ....................................................................... 6
Installation .................................................................... 8
More Advanced Security ........................................... 12
Useful Information ..................................................... 13
Troubleshooting......................................................... 18
Specifications............................................................. 25
Personal Computer
Model No. CF-19 / CF-30 / CF-52 / CF-74 Series
00_FingerprintReader_UK.indd 100_FingerprintReader_UK.indd 1 30.01.2008 15:06:1130.01.2008 15:06:11

2
Except the following, refer to the Operating Instructions for the computer.
Names and Functions of Parts
<CF-19 Series>
Fingerprint Reader
(Appearance may differ, depending on specifications.)
<CF-30 Series>
(Appearance may differ, depending on specifications.)
Fingerprint Reader
00_FingerprintReader_UK.indd 200_FingerprintReader_UK.indd 2 30.01.2008 15:06:1130.01.2008 15:06:11

3
<CF-52 Series>
Fingerprint Reader
(Appearance may differ, depending on specifications.)
<CF-74 Series>
(Appearance may differ, depending on specifications.)
Fingerprint Reader
00_FingerprintReader_UK.indd 300_FingerprintReader_UK.indd 3 30.01.2008 15:06:1130.01.2008 15:06:11

4
How to Use the Fingerprint Reader
This section explains how your fingerprints are enrolled and authenticated.
1<CF-19 and CF-30 Series>
Slide your finger to the right or
left.
To prevent a reading error.
ASet the first joint of your finger on
the sensor as illustrated to the
right.
BSlide your finger to the right or left
while keeping it in contact with the
fingerprint sensor.
CSlide your finger to the right or left
until the sensor is visible.
<CF-52 and CF-74 Series>
Slide your finger toward
yourself.
To prevent a reading error.
ASet the first joint of your index
finger on the sensor as illustrated
to the right.
BSlide your finger toward yourself
while keeping it in contact with the
fingerprint sensor.
CSlide your finger down until the
sensor is visible.
When the fingerprint sensor does not enroll or authenticate your
fingerprint properly:
• You slid your finger too fast or too slow.
• Your finger was soiled or it has a scar on the surface.
• Your finger was wet or extremely dry.
• Your fingerprint does not have sufficient data for personal identification.
For further information, refer to “Troubleshooting (For Devices)”. (Îpage
18)
Names and Functions of Parts
or
Fingerprint sensor
Fingerprint sensor
Fingerprint sensor
<CF-52 and CF-74 Series>
<CF-19 and CF-30 Series>
00_FingerprintReader_UK.indd 400_FingerprintReader_UK.indd 4 30.01.2008 15:06:1130.01.2008 15:06:11

5
CAUTION
We shall not be liable for any loss or damage whatsoever resulting
from your Fingerprint device or neglect of Fingerprint device use,
or any data loss resulting from such developments as Fingerprint
authentication device malfunctioning.
<Only for CF-19 and CF-30 Series>
To protect the fingerprint sensor, be sure to close the cover when not
using the fingerprint reader.
00_FingerprintReader_UK.indd 500_FingerprintReader_UK.indd 5 30.01.2008 15:06:1130.01.2008 15:06:11

6
Fingerprint’s Outline
The conventional security systems use ID/passwords and token devices such as
IC cards to authenticate users. Therefore the passwords and token devices are
exposed to the risk of being lost, stolen and hacking.
The Fingerprint authentication method uses user’s fingerprints instead of
passwords for security authentication. You can use your fingerprints to start up
your computer and log on Windows.
We recommend you use the Fingerprint Reader in combination with the TPM
(Trusted Platform Module) to increase the security level of your computer.
Recommended Installation Procedure
Performed by the Computer Administrator Performed by each user
Step 1 Step 4
TPM Installation (ΓInstallation Manual of TPM”)
(If the TPM is not being used, skip this step.)
User Fingerprint Enrollment
User’s Data
• Windows Logon Password
• Fingerprint
• Fingerprint Backup Password
• Power-on Password
Step 2
Fingerprint Utility Installation
Step 3
TPM Fingerprint Utility Initialization
(If the TPM is not being used, skip this step.)
This manual describes Steps 2, 3 and the initial part of Step 4.
For further steps, refer to the UPEK Protector Suite QL Help menu.
(<Model with Windows XP> Click [start] - [All Programs] - [Protector Suite QL]
- [Help] /
<Model with Windows Vista> Click (Start) - [All Programs] - [Protector Suite
QL] - [Help]).
Overview
00_FingerprintReader_UK.indd 600_FingerprintReader_UK.indd 6 30.01.2008 15:06:1230.01.2008 15:06:12

7
Precautions
Security Functions
Fingerprint Authentication Technology does not guarantee complete
authentication and individual identification. Please acknowledge we shall not be
liable for any loss or damage whatsoever resulting from the use of, or inability
to use your Fingerprint device.
The Fingerprint authentication method uses multiple fingerprints, encryption
keys, credentials data and passwords. You might not be able to use your data if
you lose fingerprints, keys, credentials and passwords. Back up the Fingerprint
authentication data in a safe place. For further information, refer to “Backup”.
(Îpage 13)
General interaction with third-party applications: There is no guarantee
that there will not be any negative interaction with any third-party
software, and will not accept any responsibility for such an interaction.
<Model with Windows XP>
You cannot use this function at the same time as the SD security function
is being used. When SD security is set, disable SD security function in the
following order before initial setting of fingerprint authentication.
ALog on to Windows as an Administrator.
BClick [start] - [All Programs] - [Panasonic] - [SD Card Setup].
CRemove a check mark from [Use the SD card when starting the computer].
DClick [OK].
• Follow the on-screen instructions.
• SD security is disabled and all registered SD memory cards become
unavailable when your computer starts up.
00_FingerprintReader_UK.indd 700_FingerprintReader_UK.indd 7 30.01.2008 15:06:1230.01.2008 15:06:12

8
Installation
Step1 TPM Installation
Refer to on-screen manuals “Installation Manual Trusted Platform Module (TPM)”.
(<Model with Windows XP> Click [start] - [Run], enter [C:\util\drivers\tpm\
README.pdf], and click [OK]. /
<Model with Windows Vista> Click (Start) and input [C:\util\drivers\tpm\
README.pdf], and press
Enter
.)
Step2 Fingerprint Utility Installation
Performed by the Computer Administrator.
Preparation
<Only for CF-19 Series with Windows XP Tablet PC Edition>
Move Tablet PC Input Panel from upper right to the bottom right or bottom left.
If this procedure is skipped, the “Please swipe you finger” message may
overlap the Tablet PC Input Panel.
1Log on to Windows as an Administrator.
2Close all other programs.
3<Model with Windows XP>
Click [start] - [Run], enter “C:\util\drivers\fngprint\psql\
setup.exe”, and click [OK].
<Model with Windows Vista>
Click (Start) and input “C:\util\drivers\fngprint\
application\x86\install\setup.exe”, and press
Enter
.
The “Protector Suite QL ∗.∗Setup” screen appears.
4Click [Next].
Installation starts. Follow the on-screen instructions.
<Model with Windows XP>
Carefully read the License Agreement, select “I accept the license
agreement”, and click [Next].
00_FingerprintReader_UK.indd 800_FingerprintReader_UK.indd 8 30.01.2008 15:06:1230.01.2008 15:06:12

9
5When the “Protector Suite ∗.∗has been successfully
installed.” message appears, click [Finish].
At the confirmation message, click [Yes].
The computer restarts.
6Log on to Windows as an Administrator.
The “Protector Suite QL Icon” appears in the notification area.
Step 3 TPM Fingerprint Utility Initialization
Performed by the Computer Administrator.
The “Invalid TPM status” message is displayed by the “Protector Suite QL Icon”
in the notification area.
If the TPM is not being used, skip this step.
1Click on the “Invalid TPM status” message to start
“Advanced Security Initialization Wizard”.
Follow the on-screen instructions.
NOTE
If the “Invalid TPM status” message is not displayed
<Model with Windows XP>
Click [start] - [All Programs] - [Protector Suite QL] - [Control Center] -
[Settings] - [System Settings] - [TPM] - [Initialized TPM].
<Model with Windows Vista>
Click (Start) - [All Programs] - [Protector Suite QL] - [Control Center] -
[Settings] - [System Settings] - [TPM] - [Initialized TPM].
00_FingerprintReader_UK.indd 900_FingerprintReader_UK.indd 9 30.01.2008 15:06:1230.01.2008 15:06:12

10
Installation
Step 4 User Fingerprint Enrollment
Performed by each user.
1<Model with Windows XP>
Click [start] - [All Programs] - [Protector Suite QL] - [User
Enrollment].
The “Welcome” message appears, read the description carefully.
<Model with Windows Vista>
Click (Start) - [All Programs] - [Protector Suite QL] -
[User Enrollment].
Carefully read the License Agreement, select “I Accept the License
Agreement” and click [OK].
2Click [Next].
3Select an enrollment mode, and click [Finish].
Enrollment mode
You can make the configuration for the enrollment only once during this
initialization phase.
• Enrollment to the biometric device
All enrolled fingerprints are stored directly in the fingerprint sensor. The
user data will be secured by the hardware protection keys obtained by the
fingerprint sensor. This mode allows up to 21 fingerprints to be enrolled.
• Enrollment to the hard disk
All enrolled fingerprints are stored on the hard disk. Hardware protection
of the user data is not possible, but multiple users can enroll their
fingerprints.
When the “Finish” screen appears, read the description carefully.
