Panasonic Viera TX-26LE8F User manual

Service Manual
Colour LCD Television
TX-26LE8F
TX-26LE8FS
TX-26LE8L
TX-26LE8P
TX-26LE8PS
GLP23A Chassis
Specifications
Power Source: 220-240V AC, 50Hz
Power Consumption 92W
Stand-by Power Consumption: 1W
Aerial Impedance: 75Ωunbalanced, Coaxial Type
Receiving System: PAL-I/H, B/G, D/K,
SECAM B/G, D/K, L/L’
PAL-525/60 (AV only)
M.NTSC (AV only)
NTSC (AV only)
Receiving Channels: VHF E2-E12 VHFH1-H2(ITALY)
VHFA-H(ITALY) VHFR1-R2
VHFR3-R5 VHFR6-R12
UHFE21-E69 CATV(S01-S05)
CATV S1-S10 (M1-M10) CATV S11-S20 (U1-U10)
CATV S21-S41 (Hyperband)
Operating Conditions: Temperature: 0°C ÷35°C
Humidity: 20% ÷ 80% RH (non condensing)
Scanning format: 480i(60Hz), 480p(60Hz), 576i(50Hz), 576p(50Hz), 720p(60Hz), 720p(50Hz), 1.080i(60Hz),
1.080i(50Hz)
Intermediate Frequency:
Video/Audio
Video 38,9MHz, 33,9MHz
Audio 33,4MHz (B/G), 33,16MHz (A2)
33,05MHz (NICAM B/G, D/K, L)
32,4MHz (D/K), 32,66MHz (CZ STEREO)
40,4MHz (L’), 39,75MHz (L’NICAM)
Colour 34,47MHz (PAL)
34,5MHz, 34,65MHz (SECAM)
38,3MHz, 38,15MHz (SECAM L’)
ORDER No. PCZ0809165CE

Terminals:
AV1 IN Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 10kΩ
RGB (21 pin) 0,7V p-p 75Ω
AV1 OUT Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 1kΩ
AV2 IN Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 10kΩ
RGB (21 pin) 0,7V p-p 75Ω
S-video IN (21-pin)Y: 1V p-p 75Ω
C:0,3V p-p 75Ω
AV2 OUT Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 1kΩ
AV3 IN S-Video IN (4-pin)Y: 1V p-p 75Ω
C:0,3V p-p 75Ω
Audio (RCAx2) 500mV rms 10kΩ
Video (RCAx1) 1V p-p 75Ω
HDMI1, HDMI2 Type A Connector
COMPONENT Video (RCAx3) Y:1V p-p 75Ω(including synchronization)
Pb, Pr: ±0,35V p-p 75Ω
AUDIO IN Audio (RCAx2) 500mV rms 10kΩ(for HDMI1, COMPONENT-AUDIO)
AUDIO OUT Audio (RCAx2) 500mV rms 1kΩ(high impedance)
LCD screen: L5EDD8Q00028
1366 x 768 XGA, 16:9
Visible Diagonal 660mm
Audio Output: 20W (2x10W)
Headphones: 3,5mm, 8ΩImpedance
Accessories supplied : Remote Control 2 x R6 (UM3) Batteries
Dimensions:
Height: Width: Depth:
Including TV stand 489mm 700mm 205mm
TV set only 452mm 700mm 108mm
Net weight:
Including TV stand 12.5kg
TV set only 10.0kg
Specifications are subject to change without notice.
Weights and dimensions shown are approximate.
This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not
contain warnings or cautions to advise non-technical individuals of potencial dangers in attempting to service a product. Products
powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service or repair the
product or products deal within this service information by anyone else could result in serious injury or death.
Warning
2

CONTENTS
SAFETY PRECAUTIONS........................................... 4
GENERAL GUIDE LINES...................................... 4
TOUCH – CURRENT CHECK............................... 4
PREVENTION OF ELECTROSTATIC DISCHARGE
(ESD) TO ELECTROSTATICALLY SENSITIVE (ES)
DEVICES.................................................................... 5
ABOUT LEAD FREE SOLDER (PBF)......................... 6
SUGGESTED PB FREE SOLDER........................ 6
APPLICABLE SIGNALS.............................................. 7
SERVICE HINTS ........................................................ 8
CHASSIS BOARD LAYOUT....................................... 9
LOCATION OF LEAD WIRING………………………….9
SETTING INSPECTION............................................ 10
SELF-CHECK ........................................................... 11
ADJUSTMENT METHOD.......................................... 12
WIRING DIAGRAM................................................... 13
BLOCK DIAGRAMS.................................................. 14
PARTS LOCATION................................................... 17
REPLACEMENT PARTS LIST.................................. 19
SCHEMATIC DIAGRAMS......................................... 28
A-BOARD (1 OF 5) SCHEMATIC DIAGRAM...... 29
G-BOARD SCHEMATIC DIAGRAM.................... 34
V-BOARD SCHEMATIC DIAGRAM.................... 35
K-BOARD SCHEMATIC DIAGRAM ................... 36
CONDUCTOR VIEWS .............................................. 37
3

Safety Precautions
General Guide Lines
1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated
or damaged by the short circuit.
2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
3. After servicing, make the following touch current checks to prevent the customer from being exposed to shock hazards.
4. Always ensure panel TKP0E37301 is correctly replaced before returning to customer (see Fig.1).
Touch-Current Check
1. Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check.
2. Connect a measuring network for touch currents between each exposed metallic part on the set and a good earth
ground such as a water pipe, as shown in Fig. 2.
3. Use Leakage Current Tester (Simpson 228 or equivalent) to measure the potential across the measuring network.
4. Check each exposed metallic part, and measure the voltage at each point.
5. Reserve the AC plug in the AC outlet and repeat each of the above measure.
6. The potential at any point (TOUCH CURRENT) expressed as voltage U1 and U2, does not exceed the following values:
For a. c.: U1 = 35 V (peak) and U2 = 0.35 V (peak);
For d. c.: U1 = 1.0 V,
Note:
The limit value of U2 = 0.35 V (peak) for a. c. and U1 = 1.0 V for d. c. correspond to the values 0.7 mA (peak) a. c. and
2.0 mA d. c.
The limit value U1 = 35 V (peak) for a. c. correspond to the value 70 mA (peak) a. c. for frequencies greater than 100
kHz.
7. In case a measurement is out of the limits specified, there is a possibility of a shock hazard, and the equipment should
be repaired and rechecked before it is returned to the customer.
Fig. 2
4
TO
APPLIANCES
EXPOSED
METAL PARTS
Resistance values in ohms (Ω)
V
R0=500
Ω
RS=1500
Ω
CS=0.22
μ
F
10k
Ω
0.022
μ
F
COLD
WATER PIPE
(EARTH GROUND)
V: Voltmetr or oscilloscope
(r.m.s. or peak reading)
Measuring network for TOUCH CURRENTS
Input resistance: ≥ 1M
Ω
Input capacitance: ≤ 200pF
Frequency range: 15Hz to 1MHz and d.c.respectively
NOTE – Appropriate measures should be taken to obtain the correct value in case of non-sinusoidal waveforms
U2(V)
Fig. 1

Prevention of Electrostatic Discharge (ESD) to Electrostatically
Sensitive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are
called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect
transistors and semiconductor "chip" components. The following techniques should be used to help reduce the incidence of
component damage caused by electrostatic discharge (ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on
your body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD
wrist strap, which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as
aluminum foil, to prevent electrostatic charge build up or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static (ESD
protected)" can generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it.
(Most replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil
or comparable conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective
material to the chassis or circuit assembly into which the device will be installed.
Caution
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the
brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity
(ESD) sufficient to damage an ES device).
There are special components used in this equipment which are important for safety.
These parts are marked by in schematic diagrams, exploded views and replacement parts list. It is essential that
these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire, or other hazards. Do
not modify the original design without permission of manufacturer.
IMPORTANT SAFETY NOTICE
5

About lead free solder (PbF)
Note: Lead is listed as (Pb) in the periodic table of elements.
In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder.
The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).
That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.
This model uses Pb Free solder in it’s manufacture due to environmental conservation issues. For service and repair work,
we’d suggest the use of Pb free solder as well, although Pb solder may be used.
PCBs manufactured using lead free solder will have the PbF within a leaf Symbol
stamped on the back of PCB.
Caution
•Pb free solder has a higher melting point than standard solder. Typically the melting point is 50 ~ 70 °F (30~40°C)
higher. Please use a high temperature soldering iron and set it to 700 ± 20 °F (370 ± 10 °C).
•Pb free solder will tend to splash when heated too high (about 1100 °F or 600 °C).
If you must use Pb solder, please completely remove all of the Pb free solder on the pins or solder area before
applying Pb solder. If this is not practical, be sure to heat the Pb free solder until it melts, before applying Pb solder.
•After applying PbF solder to double layered boards, please check the component side for excess solder which may
flow onto the opposite side. (see Fig.3)
Suggested Pb free solder
There are several kinds of Pb free solder available for purchase. This product uses Sn+Ag+Cu (tin, silver, copper) solder.
However, Sn+Cu (tin, copper), Sn+Zn+Bi (tin, zinc, bismuth) solder can also be used. (see Fig.4)
Fig.3
Fig.4
6

Applicable signals
Note:
•Signals other than above may not be displayed properly.
•The above signals are reformatted for optimal viewing on your display.
7
Signal name COMPONENT HDMI
525 (480) / 60i * *
525 (480) / 60p * *
625 (576) / 50i * *
625 (576) / 50p * *
750 (720) / 60p * *
750 (720) / 50p * *
1,125 (1,080) / 60i * *
1,125 (1,080) / 50i * *
Component (Y, Pb, Pr), HDMI

Service Hints
How to remove the backcover
Remove the 12 fixing screws. (see Fig.5)
How to remove the Pedestal assembly
Lay the main unit face down. (see Fig.6)
Remove the 4 fixing screws and the pedestal assembly. (see Fig.7)
Fig.6
8
SCREWS SCREWS
Fig.5
Fig.7
SCREWS

Chassis Board Layout
Location of Lead Wiring
To find the Part Number of required wire in Replacement Parts List click on the wire name in red box.
Board Name Function
A-Board AV Terminal, Audio Video Processor, Speaker out, TV tuner,
HDMI, HDMI Receiver
G-Board Side AV Terminal
V-Board Remote Receiver, R&G LED, C.A.T.S.
K-Board Main Switch
Power Unit Main Input, Power Supply, Power Supply Regulator
9
G-BOARD
A-BOARD POWER UNIT
V-BOARD
K-BOARD
A13
G51-A7
A5-SP
A8-V1
K1
P2
G51
TU001
INVERTER
V1
P3
A5
P1
A2
A2-Panel_LVDS
A1
A11
A7
A8 A4
A10
A13/P3-INVERTER
A4-K1

Setting Inspection
Voltage Confirmation
Confirm the following voltages:
A board
Description Test point Position Range
30V TP3822 D3865 28V - 32V
12V TP3824 C3864 11,4V – 12,6V
AUDO_15V A1, pin20,21 14V - 16V
8V TP3823 C3858, +pin 7,6V – 8,7V
STBY3.3V TP3817 C3844, +pin 3,2V – 3,45V
STBY1.8V TP3803 C3818, +pin 1,77V – 1,89V
STBY5V TP3813 C3801 4,8V – 5,4V
CEC3.8V TP3814 C1212 3,5V - 4,2V
3V3_HD TP3834 IC3808, pin 5 3V - 3,6V
1V8_HD TP3816 D3890 1,62V - 1,98V
5V_SIG TP3826 C3873 4,83V – 5,25V
10

Self Check
Self-check is used to automatically check the bus lines and hexadecimal code of the TV set. To enter Self-Check mode, keep
pressing the down (-/v) button on the TV set and press the STATUS button on the remote control. To exit Self Check,
switch off the TV set at the power button.
Display Ref.No. Description P.C.B
E2 IC1120 EEPROM A-Board
VCTP IC1501 AUDIO VIDEO PROCESSOR A-Board
TUN TU001 TUNER A-Board
HDMI IC5003 HDMI RECEIVER A-Board
If the CCU
p
orts have been checked and found to be incorrect or not located then " - - " will a
pp
ear in
p
lace of "O.K.".
11
TX-26LE8F
TX-26LE8FS Panasonic GLP23A
SW V1.09 25/06/08
E2 V04 CodeSum F6C1
E2 O.K.
VCTP O.K.
TUN O.K.
HDMI O.K.
E2CRC: 33
OPTION 1 0F
OPTION 2 00
OPTION 3 B9
OPTION 4 11
OPTION 5 00
OPTION 6 45
OPTION 7 7D
OPTION 8 D8
OPTION 9 00
OPTION 10 00
OPTION 11 53
OPTION 12 40
OPTION 13 18
CHECK 1E
Self Check Complete
Chasssis 22
Model 0A
Size 26
VCTP B3
TX-26LE8P
TX-26LE8PS Panasonic GLP23A
SW V1.09 25/06
/
08
E2 V04 CodeSum F6C1
TX-26LE8L Panasonic GLP23A
SW V1.09 25/06/08
E2 V05 CodeSum F6C1
E2 O.K.
VCTP O.K.
TUN O.K.
HDMI O.K.
E2CRC: 6F
OPTION 1 0F
OPTION 2 00
OPTION 3 B9
OPTION 4 11
OPTION 5 00
OPTION 6 45
OPTION 7 7D
OPTION 8 58
OPTION 9 00
OPTION 10 00
OPTION 11 53
OPTION 12 40
OPTION 13 18
CHECK 9E
Self Check Complete
Chasssis 22
Model 0B
Size 26
VCTP B3
E2 O.K.
VCTP O.K.
TUN O.K.
HDMI O.K.
E2CRC: 37
OPTION 1 0F
OPTION 2 00
OPTION 3 B9
OPTION 4 11
OPTION 5 00
OPTION 6 45
OPTION 7 3D
OPTION 8 58
OPTION 9 00
OPTION 10 00
OPTION 11 53
OPTION 12 48
OPTION 13 08
CHECK 56
Self Check Complete
Chasssis 22
Model 0C
Size 26
VCTP B3

White Balance Adjustment
Instrument
•Remote Control
•LCD WB meter (Minolta CA-210 or equivalent)
Condition
•Switch on the TV Set. Enter Service1. Step down to Highlight line and keep the aging time more than 20 minutes.
Procedure
•After aging time above set White Raster No.12 for Highlight and No.4 for Lowlight . Press the OK
button to store.
•Put Minolta Sensor to the center of the LCD Panel with 25mm gap between Minolta Sensor and LCD Panel. Adjust "x"
and "y" values by changing Red and Blue values.
•Press OK button to store setting.
Adjustment Method
How to enter Service 1
•Set the Bass to maximum position, set the Treble to minimum position then keep pressing the INDEX button on the
remote control and press the down button (-/v) on the TV set, this will place the TV set into the Service Mode 1.
Key Command
•Press the RED /GREEN buttons to step up / down through the functions.
•Press the YELLOW /BLUE buttons to alter the function values, to alter White Rasters use +/-buttons
•Press the OK button after each adjustment has been made to store the required values.
•To exit the Service Mode, press the "N" button.
Keep adjusting sequence: DVCO, Sub-Contrast, other items.
Item Setting indication
Note: All setting values are approximate Settings / Special features
Sub-Contrast Sub-Contrast
35
Receive a 80% white level Philips Pattern with correct
sound system (B/G, D/K) via aerial input. For Sub-
Contrast alignment press "Blue" button, wait until the
figure colour is changed from red to black colour.
Press the OK.
DVCO DVCO
1
Receive a 80% white level Philips Pattern via aerial
input. For DVCO alignment press "Blue" button, wait
until the figure colour is changed from red to black
colour. Press the OK.
Highlight
Lowlight For correct setting see White Balance Adjustment
Sub-Brightness Sub-Brightness
0 Optimum setting.
12
High 12 0330 0300 0304
Low 4 0048 0032 0042
High 12
Low 4
Item Value
x2790 ± 150
Highlight y2920 ± 150
x2840 ± 150
Lowlight y2870 ± 150

Wiring diagram
A-BOARD
G-BOARD
G51
JK3700
AV3
V-BOARD
V1
K-BOARD
K1
POWER UNIT
P2
LCD PANEL
AV1
AV2
A10
KEY
A7
JK3000
J
K
3050
A8 A4 A1
P1
P3
MAIN IN
A2
JK5001 JK5000 A11
TU001
YUV,AUDIO IN,
AUDIO OUT HDMI1 HDMI2 SERVICE
J
K
3
1
00
CN1
A5
SP
A13
13

Video & Stereo Audio Block Diagram
AV1 21PIN SCART
AV1_V 20
AV1_VOUT 19
AV1_RED 15
AV1_GREEN 11
AV1_BLUE 7
AV1_L 6
AV1_LOUT 3
AV1_R 2
AV1_ROUT 1
JK3000
G51
1
3
5
13
15
7
11
A7
1
3
5
13
15
7
11
R
L
V
L
R
Y C
JK3700
AV4_R
AV4_L
AV4_V
AV4_Y
AV4_C
HP_LOUT
HP_ROUT
G-BOARD
Y
PB PR
L R
Y_IN
PB_IN
PR_IN
JK3100
YPBPR, AUDIO / IN,OUT/
YUV/DVI_P0_L_IN
YUV/DVI_P,_R_IN
L
R
MONITOR_L
MONITOR_R
IC1501
[C5ZBZ0000037]
AUDIO VIDEO PROCESOR
172 PB_IN
174 PR_IN
9
A
V1_R_IN
10 AV1_L _IN
173 Y_IN
195 AV1_CVBS_OUT_VCTP
24 AV1_L_OUT
23
A
V1_R_OUT
11 AV2_R_IN
12 AV2_L_IN
190 AV2_CVBS_IN
194 AV2_CVBS_OUT_VCTP
22 AV2_L_OUT
21 AV2_R_OUT
15 YUV/DVI_P0_R_IN
26 MONITOR_L
16 YUV/DVI_P0_L_IN
25 MONITOR_R
189 AV1_CVBS_IN
Q3202 Q3205
AV2 21PIN SCART
AV2_V 20
AV2_VOUT 19
AV2_RED/C 15
AV2_GREEN 11
AV2_BLUE 7
AV2_L 6
AV2_LOUT 3
AV2_R 2
AV2_ROUT 1
JK3050
Q3201 Q3204
TUNER
21
VIDEO_OUT
SIF_OUT
TUNER_CVBS_IN 191
SIF_IN 31
11
13 AV3_R_IN
14 AV3_L_IN
184 AV3_CVBS_IN
188 AV3_Y_IN
187 AV3_C_IN
IC2350
[C1BB00000947]
HP AMP
1
7
53
HP_L_OUT
HP_R_OUT
Q123
SPEAKER_RIGHT 27
SPEAKER_LEFT 28
IC250
[C1AB00002916]
AUDIO AMPLIFIER
44
1
36
13
932
A5
4
3
2
1
SP_L SP_R
JK5001
HDMI1
JK5000
HDMI2
B(0-7),G(0-7),R(07), HD(EN,HS,VS),I2(SCL,SWS,SDI)
(1,3,4,6,7,9,10,12)
(1,3,4,6,7,9,10,12)
IC5003
[C1AB00002848]
HDMI RECEIVER
39,40,43,44, 47,48,51,52
58,59,62,63, 66,67,70,71
110,111,113,114, 116,117,118,119, 123,124,125,126, 129,130,131,132, 133,136,137,140, 141,142,143,144, 1,2,3,84,85,86
50-57
58-65 66-73 38-40,47-49
A2
2
4
8
12
14
16
20
TX0- TX0+ TX1- TX1+ TX2- TX2+ TCLK- TCLK+
TX3-
TX3+
141 140 138 137 135 134 132 131 129 128
TO LCD PANEL
6
10
18
TX0- TX0+ TX1- TX1+ TX2- TX2+ TCLK- TCLK+
TX3-
TX3+
14
A-BOARD
178 AV1 RED 177 AV1 GREEN 176 AV1 BLUE
179 AV2 BLUE 180 AV2 GREEN 181 AV2 RED

Power Supply Block Diagram
POWER UNIT
A
1
1
2
8 5
7
21
20
A2
26-30
LCD PANEL
K-BOARD
A4
1
3
K1
1
3
SW2501
RELAY_5V6
STB
_
5V RELAY_5V6
STBY_5V
V-BOARD
A
8
1
V
1
1
Q1004 Q1002
D1001
RM1001
V
CC
SN2551
9,16
18 30V
5V_SIG
TUNER
A13
3 3.3
V
_HDMI
STBY3.3V
12V
STBY_5V6
24
V
15V
RELAY_5V6
5V6_SW STBY1.8V
IC3801
4REGULATOR 5
LCF’s
VSUPFE_1.8V
VSUPDIG_1.8V
VSULVDS_1.8V
R3871
15V
15V_WS
D3864 D3863
30V
24V
30V
5V6_SW STBY3.3V
IC3806
2REGULATOR 5 VSUPVO_3.3V
VSUPCOM_3.3V
V
SUPDRI_3.3V
LCF’s
VSUPDAC_3.3V
VSUPDIG_3.3V
V
SULVDS_3.3V
VSUIO1_3.3V
V
SUPFE_3.3V
5V6_SW 5V_SIG
IC3813
4 REGULATOR 5 VSUPSIF_5V
LCF
24V
12V IC3810
2
IC for PS
3
3V3_HD
1V8_HD IC3808
5,8
REGULATOR
1
3.3V_HDMI
L3809
15V_SW 8V
IC3809
3REGULATOR 1 LCF VSUPAU_8V
Q3803 STBY3.3V
3.3V_HDMI
STBY3.3V
12V IC3812
2
V
oltage
Detecting IC
1
3V3_ PVCC
3V3_ AVCC
3V3_ XTAL
IC5003
5,6,7,16,26,76,89,109, 122
,
134
22,23,35,74,79,92,94, 105,114,128,139
37,55
38,42,46,50,57,61,65,69
98
99
3V3_HD
1V8_HD
3V3_ REG
HDMI RECEIVER 18
36
45,75
77
86
,
96
,
114
124
127,133,139,150,156
142
164
169
,
185
170
192
197
VSUPAU_ 8V
VSUPSIF_ 5V
VSUPDIG _3.3V
V
SUPDRI_3.3V
VSUPCOM_3.3V
VSUIO1_3.3V
VSUPDIG_1.8V
VSULVDS_ 3,3V
VSULVDS_1,8V
VSUPDAC_3,3V
V
SUPFE_1,8V
V
SUPFE_3,3V
V
SUPVO_3,3V
V
SUPIO3_3,3V
AUIDO VIDEO
PROCESSOR
IC1501 33
115 3.3V_HDMI
3V3_HD
LCF
3V3_XTAL
3V3_REG
3V3_PVCC
3V3_AVCC
IC3400
13 RGB SWITCH
5V_SIG
IC2350
8AUDIO AMP
5V_SIG
IC5001
8EEPROM EDID
5V_MIXED_P0
IC5002
8EEPROM EDID
5V_MIXED_P1
3V3_HD
3V3_HD
Q5000
Q5003
IC250
7,8,15,16, 29,30,37, 40,38 AUDIO AMP
15V_SW
IC1220
8LOGIC IC
STBY5V
IC1500
2RESET IC
STBY3.3V
Q1721
BACKLIGHT
3.3V_HDMI
LEVEL SHIFTER
STBY3.3V Q1101 Q1100
VIDEO SWITCH
5V_SIG Q3202 Q3205
Q3201 Q3204
R3860 STBY5V
CEC3.8V
R3828 STBY5V
5V6_SW HDMI CEC
STBY3.3V
Q1208 Q1209
CEC3.8V
HDMI_DETECTION_P0
5_SIG
Q5001
3V3_HD D5000
5V_MIXED_P0
HDMI_DETECTION_P1
5_SIG
Q5004
3V3_HD D5003
5V_MIXED_P1
A-BOARD
A11
1 STBY3.3V
SERVICE
PROTECTION
30V
5V_SIG
3.3V_HDMI
12V
15V
8V
TV_SWITCH_PROT
5V6_SW
STBY3.3V
STBY1.8V
STBY_5V6
Q3827 Q3829
D3886
STBY3.3V
Q3820 Q3821 Q3822 Q3823
D1101 D1102
5V_SIG
15

REMOTE
A8
5
6
V
1
5
V - BOARD
6
AI_SENSOR
2
2
R_LED_ON
REMOTE
AI_SENSOR
4
4
G_LED_ON
R_LED_ON
G_LED_ON
D1001
Q1004 Q1002
Q1010
RM1001
REMOTE
CONTROL SN2551
A7
G51
G - BOARD
2
2
HP_SENSE
JK3700
AV3
HP_SENSE
A4
K1
K - BOARD
4
4
ALL_OFF_DET
SW2501
ALL_OFF_DET
A10
1 KEYSCAN
KEY CONTROL
TU001
13 SCL_TUNER
14 SDA_TUNER
A1
6
POWER UNIT TV_SUB_ON_RELAY_ON
A
13
5
2
PWM_DIM
4
INV_ON
INV_SOS
LCD PANEL
CN1
KEYSCAN
IC1501
C5ZBZ0000037
AUDIO VIDEO
PROCESSOR
2 HDMI_5V_DET
1 REMOTE
3 PANEL OFF
83 SCL3V3
AV_LINK_IN 201
AV_LINK_OUT 200
47 HDVS
48 HDEN
49 HCLK
84,203 SDA3V3 87 HDMI_CEC_OUT
88 HDMI_CEC_IN
89 TV_SUB_ON_RELAY_ON
91 INVERTER_OFF 92 PC_INPUT
115 HDMI_RST
116 RGB_SWITCH
159 AI_SENSOR AV1_SLOW 161
KEYSCAN 162
HDMI_HPD_P0 165
HDMI_HPD_P1 166
BACKLIGHT_PWM 167
HDHS 171
BUS_REQUEST 204
R_LED_ON 208
7 PROTECTION
REMOTE
HDMI_5V_DET
PROTECTION
HDVS
HDEN HCLK
SDA3V3 SCL3V3
INVERTER_OFF
Q1217
TV_SUB_ON_RELAY_ON
PC_INPUT HDMI_RST
RGB_SWITCH
R_LED_ON
BUS_REQUEST
AV_LINK_IN
AV_LINK_OUT
HDHS
BACKLIGHT_PWM
HDMI_HPD_P1
HDMI_HPD_P0
KEYSCAN
AV1_FBL
EDID_WP_DISABLE
AI_SENSOR
AV2_FBL
AV1_FBL 175
AV2_FBL 183
AUDIO_MUTE 205 AUDIO_MUTE
160 AV2_SLOW
AV2_SLOW
EDID_WP_DISABLE 199
G_LED_ON 202
CEC_P0
Q1207
Q1209
PANEL_OFF
6 SUPPLY DETECT
SUPPLY DETECT
8 EAROM_VCC_OFF
EAROM_VCC_OFF
CEC_P1
AV1_IS_QLINK
AV1_IS_QLINK 198
G_LED_ON
Control Block Diagram
A11
7
2
SDA3V3
6
BUS_REQUEST
SCL3V3
SERVICE
2 HDHS
1 HDEN 3 HDVS
30 SCL3V3_P1
27 SDA3V3 28 SCL3V3
29 SDA3V3_P1
31 SDA3V3_P0 32 SCL3V3_P0 HDMI_5V_DET_P1 33
HDMI_5V_DET_P0 34
XTAL_OUT 96
XTAL_IN 97
HDMI_RST 102
HDEN
HDHS HDVS SDA3V3
SCL3V3 SDA_3V3_P1 SCL_3V3_P1 SDA_3V3_P0 SCL_3V3_P0
D5032
D5033
HDMI_5V_DET
HDMI_5V_DET_P1
HDMI_5V_DET_P0
MUTE_OUT
HDMI_RST
X5000
Q5008
Q5007
HCLK 121 HCLK
IC5003
C1AB00002848
HDMI RECEIVER
PROTECTION
PROTECTION
30V
3,3V_HDMI
8V
15V
5V_SIG
INV_SOS
INVERTER_OFF
12V
SDA_P1
SCL_P1
SDA_P0
AV1 21 PIN SCART
8 AV1_SLOW
16 AV1_FBL
HDMI2
13 CEC_P1
16 SDA_P1
15 SCL_P1
18 +5V_HDMI_P1
HDMI1
13 CEC_P0
16 SDA_P0
15 SCL_P0
18 +5V_HDMI_P0
AV2 21 PIN SCART
8 AV2 _SLOW
16 AV2_FBL
IC5002
6 SCL_P1 5 SDA_P1 EDID_WP_DISABLE 7
SCL_P0
Q5005
HDMI_HPD_P1
C3EBDC000067
6 SCL_P0 5 SDA_P0 EDID_WP_DISABLE 7
HPDT_5V_P1
Q5004
HDMI_5V_DET_P1 +5V_HDMI_P1
Q5003
SDA_3V3_P1 SDA_P1 SCL_3V3_P1 SCL_P1
Q5000
SDA_3V3_P0 SDA_P0 SCL_3V3_P0 SCL_P0
Q5002
HDMI_HPD_P0 HPDT_5V_P0
Q5001
HDMI_5V_DET_P0 +5V_HDMI_P0
Q5011 Q5012
EDID_WP_DISABLE
10 AV1_QLINK
10 AV2_QLINK
IC1120
SCL3V3 6
SDA3V3 5
19 HPDT_5V_P1
19 HPDT_5V_P0
IC5001
C3EBDC000067
EEPROM
AV1_SLOW
BACKLIGHT_PWM
PWM_DIM
Q1721
Sense Mute
MAIN_MUTE_IC
HP_SENSE
MAIN_SENSE_MUTE
HP_MUTE_IC
A7
2 HP_SENSE
G51
2
G - BOARD
JK3700
HP_MUTE
HW Mute
MAIN_MUTE
5V6_SW_ON
HP_MUTE_IC
ALL_OFF_DET
SW Mute
AUDIO_MUTE
MAIN_MUTE
MAIN_MUTE_IC
TV switch
PROT
SWITCH_HOLD_ON
5V6_SW_ON
90 SWITCH_HOLD_ON
SWITCH
_
HOLD
_
ON Q1100
Q1101 LEVEL
SHIFTER
SCL_TUNER
SDA_TUNER
SCL3V3
SDA3V3
SOFT
SWITCH
5V6
_
SW
_
ON
ALL_OFF_DET
IC1220
C0JBAS000215
LOGIC IC
1,6 AV_LINK_OUT
5 AV1_QLINK
3AV1_IS_QLINK
AV_LINK_OUT Q1232
8 AV_LINK_IN
AV_LINK_IN Q1231Q1229 Q1230
AV1_IS_QLINK Q1221 Q1222
AV1_QLINK
2 AV2_QLINK
AV2_QLINK
IC250
20
A
UDIO
AMP
MAIN_SENSE_MUTE
IC1500
1
RESET
IC
EAROM_VCC_OFF
IC2350
2
A
UDIO
AMP
HP_MUTE
IC3810
7
IC
PANEL_OFF
IC3812
1
V
OLTAGE
DETECTING IC
SUPPLY_DETECT
A - BOARD
POWER
AREA_PROT
TV_SUB_ON_RELAY_ON
INV_ON
INVERTER_OFF Q3831
Q1208
P2
16

Parts Location
NOTE:
The numbers on the exploded view below refer to the exploded view section of the Replacement Parts List.
(UK)
17
21
6
(CONTINENTAL
8
23
11
7
14

Parts Location
NOTE:
The numbers on the exploded view below refer to the exploded view section of the Replacement Parts List.
18
22
25
10
13
5
18
4
15 2
3
19
12
12
20
24
12
1
9
16
17
13

Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type number to your order.
Replacement Parts List
Important Safety Notice
The marking (RTL) indicates that the Retention Time is Limited for this item. After the
discontinuation of this assembly in production, the item will continue to be available for
a specific period of time. The retention period of availability is dependent on the type of
assembly, and in accordance with the laws governing part and product retention. After
the end of this period, the assembly will no longer be available.
RTL (Retention Time Limited)
Note:
X
The marking (X) indicates that board should be exchanged for service.
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COMMON PARTS
EXPLODED VIEW
SPEAKER1 EAS16S09A
TUNER2 ENG37E08GF
CONTROL PANEL3 K0RB00500032
LCD PANEL4 L5EDD6Q00028
POWER UNIT5 N0AC3GJ00015
REMOTE CONTROL6 N2QAYB000223
CONNECTOR COVER7 TKP0E37301
REAR AV BRACKET8 TKP0E37501
POWER BUTTON BRACKET9 TKP0E37601
SIDE AV BRACKET10 TKP0E92801-1
BACK COVER11 TKU0E1601
LCD BRACKET12 TKZ0E9184
LCD BRACKET13 TKZ0E9188
VESA METAL14 TKZ0E9933
G P.C.B.15 TNP8EGL91AA
K P.C.B.16 TNP8EKL92AA
V P.C.B.17 TNP8EVL91AB
L CHASSIS FIXING BRACK18 TUA0E1900-2
R CHASSIS FIXING BRACK19 TUA0E2100-2
MISCELLANEOUS COMPONENTS
BATTERY. R6RCOD/2P
SIDE AV LABEL. TBM0E1204
REAR AV LABEL. TBM0E1254-1
SPRING. TES0E299
SCREW. THTF012J
FELT. TMK0EA018
P P.C.B. BARRIER SHEET. TMK0EE002-1
TAB-RELEASE CABLE. TMM8E18048
SCREW. XTB3+8GFJ
SCREW. XTB4+15JFJK
SCREW. XTV3+10JFJK
SCREW. XTW3+12TFJ
SCREW. XTW4+Z15DFJ
SCREW. XYN4+C12FJ
SCREW. XYN4+F6FJ
BOTTOM CUSHIONBOTCUS TPD0E2019
CARTONCARTON TPC0E48700
FERRITE COREFC02 J0KG00000100
TOP CUSHIONTOPCUS TPD0E1046
I.C.s
AUDIO AMPLIFIERIC250 C1AB00002916
LOGIC ICIC1220 C0JBAS000215
I.C. RESETIC1500 C0EBE0000120
AUDIO/VIDEO PROCESSORIC1501 C5ZBZ0000037
AUDIO AMPLIFIERIC2350 C1BB00000947
REGULATORIC3801 C0DBAYY00372
REGULATORIC3806 C0DBAYY00372
REGULATORIC3808 C0CBCAD00082
REGULATORIC3809 AN78L08M-E1
IC FOR POWER SUPPLYIC3810 C0DBEYY00084
VOLTAGE DETECTING ICIC3812 C0EBH0000298
REGULATORIC3813 C0DBZYY00284
EEPROM EDIDIC5001 GLP23AEDID1
EEPROM EDIDIC5002 GLP23AEDID1
HDMI RECEIVERIC5003 C1AB00002848
LED RECEIVERRM2501 PNA4701M05TV
PHOTO IC DIODESN2551 B3JB00000046
DIODES
DIODED271 MA22D3900L
DIODED272 B0ACCK000015
DIODED273 B0ACCK000015
DIODED301 B0ACCK000015
DIODED302 MA22D3900L
DIODED303 B0ACCK000015
DIODED1101 MA24D5000B
DIODED1102 MA24D5000B
DIODED1201 MA2J72800L
DIODED1503 MAZ80820ML
DIODED2501 B3CKE0000007
DIODED3808 MA24D5000B
ZENER DIODED3813 MAZ80510ML
DIODED3851 MA2J11100L
DIODED3852 MA2J11100L
DIODED3853 MA2J11100L
DIODED3854 MA2J11100L
DIODED3855 MA2J11100L
DIODED3856 MA2J11100L
DIODED3861 MA24D5000B
DIODED3863 MA22F2000L
DIODED3864 MA22F2000L
DIODED3865 MAZ81500ML
DIODED3866 MAZ81500ML
DIODED3867 MA22D3900L
DIODED3869 MA24D5000B
DIODED3874 MA3X152E0L
DIODED3875 MA3X152E0L
DIODED3876 MAZ82700ML
DIODED3877 MAZ81800ML
DIODED3878 MAZ80820ML
19
RTL
RTL
RTL

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
ZENER DIODED3879 MAZ81300HL
DIODED3880 MA2J11100L
DIODED3881 MA2J11100L
DIODED3882 MA2J11100L
DIODED3883 MAZ802400L
ZENER DIODED3884 MAZ80470LL
ZENER DIODED3885 MAZ80330LL
DIODED3886 MA3X152E0L
DIODED3887 MA2J11100L
ZENER DIODED3888 MAZ80560HL
DIODED3890 MA22D3900L
DIODED5000 MA22D3900L
DIODED5001 MA2J11100L
DIODED5003 MA22D3900L
DIODED5004 MA2J11100L
DIODED5006 MAZ30560ML
DIODED5007 MAZ30560ML
VARISTORD5010 EZJZ0V80008B
VARISTORD5011 EZJZ0V80008B
VARISTORD5012 EZJZ0V80008B
VARISTORD5013 EZJZ0V80008B
VARISTORD5016 EZJZ0V80008B
VARISTORD5017 EZJZ0V80008B
VARISTORD5018 EZJZ0V80008B
VARISTORD5019 EZJZ0V80008B
VARISTORD5020 EZJZ0V80008B
VARISTORD5021 EZJZ0V80008B
VARISTORD5022 EZJZ0V80008B
VARISTORD5023 EZJZ0V80008B
VARISTORD5024 EZJZ0V80008B
VARISTORD5025 EZJZ0V80008B
VARISTORD5026 EZJZ0V80008B
VARISTORD5027 EZJZ0V80008B
VARISTORD5028 EZJZ0V80008B
VARISTORD5029 EZJZ0V80008B
VARISTORD5030 EZJZ0V80008B
VARISTORD5031 EZJZ0V80008B
DIODED5032 MA2J11100L
DIODED5033 MA2J11100L
TRANSISTORS
TRANSISTORQ123 BC847B
TRANSISTORQ254 BC847B
TRANSISTORQ272 B1ADCE000023
TRANSISTORQ276 BC847B
TRANSISTORQ277 BC847B
TRANSISTORQ1100 B1CFGG000007
TRANSISTORQ1101 B1CFGG000007
TRANSISTORQ1130 B1HFCFA00037
TRANSISTORQ1207 BC847B
TRANSISTORQ1208 BC847B
TRANSISTORQ1209 BC847B
TRANSISTORQ1217 B1ADCE000023
TRANSISTORQ1221 BC847B
TRANSISTORQ1222 BC847B
TRANSISTORQ1229 BC847B
TRANSISTORQ1230 BC847B
TRANSISTORQ1231 BC847B
TRANSISTORQ1232 BC847B
TRANSISTORQ1721 B1CFGG000007
TRANSISTORQ2504 2SD601ATX
TRANSISTORQ2505 2SB0709ASL
TRANSISTORQ2506 2SB0709ASL
TRANSISTORQ3201 B1ADCE000023
TRANSISTORQ3202 B1ADCE000023
TRANSISTORQ3204 BC847B
TRANSISTORQ3205 BC847B
TRANSISTORQ3803 B1DHDC000028
TRANSISTORQ3804 BC847B
TRANSISTORQ3805 B1DHCC000024
TRANSISTORQ3813 B1DHCC000024
TRANSISTORQ3818 BC847B
TRANSISTORQ3820 BC847B
TRANSISTORQ3821 BC847B
TRANSISTORQ3822 BC847B
TRANSISTORQ3823 B1ADCE000023
TRANSISTORQ3824 2SD0601ASL
TRANSISTORQ3825 2SB0709ASL
TRANSISTORQ3826 BC847B
TRANSISTORQ3827 B1DHDC000028
TRANSISTORQ3828 2SD0601ASL
TRANSISTORQ3829 2SB0709ASL
TRANSISTORQ3831 BC847B
TRANSISTORQ3832 BC847B
TRANSISTORQ5000 B1MBACA00008
TRANSISTORQ5001 2SK122800L
TRANSISTORQ5002 B1CFGG000007
TRANSISTORQ5003 B1MBACA00008
TRANSISTORQ5004 2SK122800L
TRANSISTORQ5005 B1CFGG000007
TRANSISTORQ5007 B1CFGG000007
TRANSISTOR
Q5008 B1CFGG000007
TRANSISTORQ5011 BC847B
TRANSISTORQ5012 BC847B
COILS
COILL101 ELJFC2R2KFB
COILL102 ELJFC2R2KFB
COILL103 TALV35VB100K
INDUCTORL250 G1C330MA0291
INDUCTORL251 G1C330MA0291
COILL253 J0JHC0000034
COILL254 J0JHC0000034
COILL255 J0JHC0000034
COILL256 J0JHC0000034
INDUCTORL257 G1C330MA0291
INDUCTORL258 G1C330MA0291
COILL335 J0JHC0000078
COILL336 J0JHC0000078
COILL337 J0JJC0000015
COILL1100 ELJFC2R2KFB
COILL1101 ELJFC2R2KFB
COILL1500A J0JHC0000078
COILL1501A J0JHC0000078
COILL1502 J0JHC0000078
COILL1503 J0JHC0000078
COILL1504A J0JHC0000078
COILL1505A J0JHC0000078
COILL1506A J0JHC0000078
COILL1507A J0JHC0000078
COILL1509A J0JHC0000078
COILL1514A J0JHC0000078
COILL1515A J0JHC0000078
COILL1518 J0JHC0000078
COILL1519 J0JHC0000078
COILL1520 J0JHC0000078
COILL1721 J0JHC0000078
COILL1722 J0JHC0000078
COILL1723 J0JHC0000078
COILL1724 J0JHC0000078
COILL1725 J0JHC0000078
COILL2350A J0JHC0000078
INDUCTORL3700 J0JCC0000100
INDUCTORL3701 J0JCC0000100
INDUCTORL3702 J0JCC0000364
INDUCTORL3703 J0JCC0000364
20
