Panasonic NFC-TAG User manual

1
Panasonic NFC-TAG Development kit
Installation Manual
Version 2.70
May 11, 2016
Panasonic Semiconductor Solutions Co., Ltd.

2
Setup procedure 5..................................................
Summary 3
..................................................
Usage 15..................................................
Contents

3Summary of Development kit(1)
1. Structure
Antenna
Serial-USB
converter
8bit MCU
NFC
TAG
UART
USB
mobile phone
(with NFC controller)
NFC-TAG board
MCU board
PC Android application
Development kit
① Read/write data in tunnel memory by PC.
② Read/write data in NFC-TAG memory by PC.
③ Read/write data in NFC-TAG memory by mobile phone with NFC function.
④ Read/write data in tunnel memory by mobile phone with NFC function.
⑤ Transfer the files from mobile phone to PC over NFC.
⑥ Transfer the files from mobile phone to PC over Bluetooth. (But a pairing-information is transferred over NFC.)
⑦ Transfer the files from mobile phone to PC over WiFi. (But a pairing-information is transferred over NFC.)
Panasonic
Microcomputer
NFC-TAG
memory
4096byte
tunnel
memory
③
④
②
①
PC software
⑤Bluetooth ⑥
312500
bps Serial-IF
※ NFC TAG memory = 512 byte : MN63Y1210A / MN63Y1213
1024 byte : MN63Y1214 / MN63Y1221
※ tunnel memory = microcomputer memory
※ Serial-IF MN63Y1213 / MN63Y1214 / MN63Y1221 ： I2C 100Kbps
MN63Y1210A ： UART 9600bps, 38400bps , Clock synchronous serial 1Mbps
NFC
2. Functions
⑦

4Summary of Development kit(2)
Software Version File Name outline
Microcomputer Software 2.42 ※It is written in the MCU board Microcomputer board control software
PC Software
(control MCU board)
2.50 NFCTAG_DumpTool_v250.exe Read/Write the NFC-TAG/MCU memory from PC
3.5.605 InTheHand.Net.Personal.dll
Control the Bluetooth adapter when performing the file
transfer by Bluetooth
※About how to obtain, please refer to [setup procedure (3)]
1.0.1 NfcWifiCtrl.dll Control the WiFi adapter when performing the file transfer by
WiFi
PC Software
(control PC-R/W)
1.50 NFCTAG_DumpTool_PCSC_V150.exe Read/Write the NFC-TAG/MCU memory from
PC-R/W (Sony PaSoRi) that is connect to the PC
2.2.2 NfcRW.dll Control the ‘PaSoRi’ made by SONY Corporation
Android
Application
Read/Write 1.51 Panasonic_TagRW_v151.apk Read/Write the NFC-TAG/MCU memory from mobile phone
File transfer 1.55 Panasonic_TagFileTx_v155.apk transfer the files such as photos to the PC from the mobile phone
NFC TAG
setting
1.50 Panasonic_TagSetting1210_v150.apk MN63Y1210A TAG setting
1.50 Panasonic_TagSetting1213_v150.apk MN63Y1213 TAG setting
1.54 Panasonic_TagSetting1214_v154.apk MN63Y1214 TAG setting
1.01 Panasonic_TagSetting1221_v101.apk MN63Y1221 TAG setting
3. Software Version
In this document, we have assumed the use of the following software.
Usage of PC Software(control PC-R/W) , Please refer to the Software Manual for NFC-R/W （NFC-RW Application Manual(E)_v160.pdf)

5
Development kit setup procedure

.
..
6Setup procedure(1)
Step1. Board setting
Step2. Install driver and application (for PC)
・Microsoft .NET Framework 4 Client Profile
download site http://www.microsoft.com/en-us/download/details.aspx?id=24872
(2) Download and install [.NET Framework] from the following site.
Refer board connection of the following figure.
MCU board
(BTPB-101[B])
.
..
JP2
JP1
Jumper setting MN63Y1210A
UART
Clock synchronous serial
Serial-IF select switch
MN63Y1213/1214/1221
(1) Copy an application file to a personal computer.
Sample application : NFCTAG_DumpTool_vXXX.exe
※Supported OS : Microsoft Windows 7 SP1

7Setup procedure(2)
・Virtual COM Port Driver (FTDI)
download site http://www.ftdichip.com/Drivers/VCP.htm
→ Please choose an appropriate driver from the item of VCP Drivers.
(3) Download and install [driver of the MCU board] from the following site.
① Connect MCU Board to PC by USB
② Open the Device Manager
Right-click the
mouse on the
"computer"
Select
"Properties" Select "Device Manager"
③ Install driver for FT232
Right-click the mouse on
the "FT232R USB UART" Select
"Update Driver Software"
Select
"Browse my computer for driver software" Set the downloaded driver in the input box of
[Search for driver software in this location],
and Install the driver
④ Install driver for USB serial port
Right-click the mouse
on the "USB Serial Port" Select
"Update Driver Software"

8Setup procedure(3)
・32feet.NET (http://32feet.codeplex.com/)
download site http://32feet.codeplex.com/downloads/get/386489
※ file name : 32feet.NET 3.5.zip
・ PC application needs the library file that is included in “32feet.NET 3.5.zip”. (InTheHand.Net.Personal.dll)
・ Install the library file (InTheHand.Net.Personal.dll) in the same directory as the PC application.
Bluetooth Icon
Install step (run Setup.exe)
Input install folder
InTheHand.Net.Personal.dll
is installed in the “NET” folder in a
specification folder.
Microsoft standard driver
Confirm in device manager
(4) Download and install [library] from the following site.
About Bluetooth driver
OS standard driver of Microsoft should be used for the Bluetooth driver.
※When using Bluetooth, Bluetooth function is required for the personal computer.
We use following USB-Bluetooth Adapter
BT-MicroEDR2X, BT-Micro4 (PLANEX COMMUNICATIONS INC.)
http://www.planex.co.jp/product/bluetooth/bt-microedr2x/
This procedure is necessary for
performing a file transfer by Bluetooth

9Setup procedure(4)
Put the following library file in the same directory as the PC application.
・Library : NfcWifiCtrl.dll
※Supported OS : Microsoft Windows 7 SP1
(5) Copy WiFi control library(DLL) to a personal computer.
※When using WiFi, WiFi function is required for the personal computer.
We use following USB-WiFi Adapter
WLI-UC-GNM2 (BUFFALO INC.)
http://buffalo.jp/product/wireless-lan/client/wli-uc-gnm2/
About WiFi function
Our development kit uses "Virtual Wi-Fi (wireless hosted network)" that is Microsoft Windows7 standard function.
So Virtual Wi-Fi-enabled WiFi adapter is required.
(Our development kit supports one Virtual Wi-Fi-enabled WiFi adapter)
※After the PC software startup (startup as administrator),
you can see whether your PC has Virtual Wi-Fi-enabled WiFi adapter.
If your PC has Virtual Wi-Fi-
enabled WiFi adapter,
IP address is displayed.
If your PC doesn't have Virtual
Wi-Fi-enabled WiFi adapter,
"NO Adapter" is displayed.
This procedure is necessary for
performing a file transfer by WiFi

10 Setup procedure(5)
Step3. Install Android application
Install Android application to the mobile phone.
Android sample application
・Panasonic_TagRW_vXXX.apk (Data transfer application)
・Panasonic_TagFileTx_vXXX.apk (File transfer application)
・Panasonic_TagSettingXXXX_vXXX.apk (MN63Y1210A/1213/1214/1221 TAG setting application)
TagRW TagFileTx TagSetting
MN63Y1213
MN63Y1210A
MN63Y121４
MN63Y1221
Usage of the applications, refer to each manuals.
XX

11 Setup procedure(6)
Step4. NFC TAG initial setting
The initial configuration of the NFC TAG board (antenna board)
Serial Type : UART / Clock synchronous serial
(1) Board setting
■MN63Y1210A
MN63Y1210
(2) Writing initialization data (Serial Type setting)
UART
Clock synchronous serial
Initialize the TAG by using the application of TAG setting.
(Panasonic_TagSetting1210)
(1) Start Android application.
(2) Push the button of hope.
(3) Bring the mobile phone close to the TAG to write
initial data.
UART
Clock synchronous serial
Serial-IF select switch

12 Setup procedure(7)
■MN63Y1213/1214/1221
(1) Writing initialization data
MN63Y1213/1214/1221
MN63Y1213
MN63Y1214
TAG setting application (Android)
Initialize the TAG by using the application of TAG setting.
(Panasonic_TagSetting 1213 / 1214 / 1221)
(1) Start Android application.
(2) Push "initialize" button.
(3) Bring the mobile phone close to the TAG to write initial data.
XX
Initialize button
MN63Y1221

13 Setup procedure(8)
Step5. Reset MCU board
After connecting the personal computer and MCU board by USB,
push the reset switch on the MCU board.
MCU board
(BTPB-101[B])
USB
Version information is
displayed for a moment and
the address 0x00 value of
the tunnel memory
(microcomputer memory) is
displayed after that.
If VDD2/VDDEX(power for TAG） is on,
Red LED turns on.
Reset switch
MN63Y1210A
MN63Y1213/1214/1221

14 Setup procedure(9)
If you do the file transfer by WiFi, start the PC software as administrator.
※In order to use Microsoft Windows7 standard function "Virtual Wi-Fi (wireless hosted network)",
you must start the application as administrator.
When you start the PC software as administrator, the Security Alert screen will appear.
If you perform the file transfer by WiFi, check both of the check boxes.
※This is necessary to perform the data communication with mobile phones.
Check both of the check boxes
In case of performing the file transfer by WiFi
Click right button of the mouse on the software icon,
and select [Run as administrator] in the menu.
Step6. Start PC software
This procedure is necessary for
performing a file transfer by WiFi

15
Development kit usage

16 Usage 1(Read/Write TAG)
STEP1
Select virtual COM port
(connect to the board)
STEP3
Push the “Connect” button
STEP4
Push the reset switch on the
board
STEP5
Starting log is displayed
■Connect to the target board
STEP6
Input memory address
(16-byte alignment hexadecimal number)
※A click of a cell will input an address automatically
STEP7
Input length (hexadecimal number)
[NFC-TAG memory]
・ MN63Y1210A/1213
0x01 ～ 0x200 [1～512 byte]
・MN63Y1214/1221
0x01 ～ 0x400 [1～1024 byte]
[tunnel memory]
0x01 ～ 0x1000 [1～4096 byte]
STEP8
Push Read / Write button
※Before you write, set value to cell.
■Read/Write memory
STEP2
Select the TAG LSI model
User Area
Config Area
System Area
load/save the dump data.
Write all data
Read all data
NFC-TAG
memory
tunnel memory
TAG Read/Write BCC calculated value is displayed
* if the value of BCC set in the system area
has a problem, it is displayed with red.
（not use for MN63Y1210A）
After performing the contents of the [start-up procedure], start the PC software.

17 Usage 2(file transfer1)
Start the PC software, and connect to the MCU board
(See previous page)
Connect MCU board to PC by USB
STEP 1
STEP 2
Push the reset switch on the MCU board (reset the board)
STEP 3
Reset switch
Start the file transfer application on mobile phone
and select the file that you want to transfer to the PC
STEP 4
Android
file transfer application
（TagFileTx)
STEP 5
Touch the tag by the mobile phone
STEP 6
Screen of the PC software switches automatically,
and file transfer is started (See next page)

18
file transfer screen
If the mobile phone that is performing android
application (Panasonic_TagFileTx) is brought
close to NFC-TAG, a file transfer will be started
automatically and information will be displayed on
the “file Transfer” tab.
The following icons are displayed during a file
transfer by Bluetooth/WiFi.
Waiting for Bluetooth connection
File transfer by Bluetooth
Waiting for WiFi connection
File transfer by WiFi
Usage 3(file transfer2)

19
■Tag power supply
Control the power supply to the tag from the microcomputer
always : power supply to the tag always
not always : power supply to the tag when necessary
■Communication log mode
set of log display
Enable Log (All) : enable all log
Disable Log (except File Transfer) : enable only necessary logs for
file transfer
Disable Log : disable all log
■WiFi adapter info
Display the information of WiFi adapter (PC will be the access point)
SSID : SSID of the access point
IP Address : IP address of the access point
Check Adapter : update the information of WiFi adapter
Usage 4(setting)

20 (Supplement) Bluetooth file transfer sequence
②Start Bluetooth
Start Bluetooth in server mode
and wait connection from PC
(use RFCOMM protocol)
Antenna
Serial-USB
converter
8bit MCU
NFC
TAG
UART
Serial-IF
USB
mobile phone
(with NFC controller)
NFC-TAG board
MCU board
PC Android
application
312500
bps
①Write data into the tunnel memory
(Start Command & Bluetooth MAC address)
③Connection request between PC and mobile phone by Bluetooth
(use RFCOMM protocol and Bluetooth MAC address of the mobile phone)
⑤Send file data
④Connection OK
PC software
Touch the tag by
the mobile phone
