Epson S5U1C17656T User manual

Rev.1.0
CMOS 16-BIT SINGLE CHIP MICROCONTROLLER
S5U1C17656T Manual
(Software Evaluation Tool for S1C17656)

Evaluation board/kit and Development tool important notice
1. This evaluation board/kit or development tool is designed for use for engineering evaluation, demonstration,
or development purposes only. It is not intended to meet the requirements of design for finished products.
2. This evaluation board/kit or development tool is intended for use by an electronics engineer and is not a
consumer product. The user should use it properly and in a safe manner. Seiko Epson dose not assume any
responsibility or liability of any kind of damage and/or fire coursed by the use of it. The user should cease to
use it when any abnormal issue occurs even during proper and safe use.
3. The part used for this evaluation board/kit or development tool may be changed without any notice.
NOTICE
No part of this material may be reproduced or duplicated in any form or by any means without the written
permission of Seiko Epson. Seiko Epson reserves the right to make changes to this material without notice.
Seiko Epson does not assume any liability of any kind arising out of any inaccuracies contained in this material
or due to its application or use in any product or circuit and, further, there is no representation that this material is
applicable to products requiring high level reliability, such as, medical products. Moreover, no license to any
intellectual property rights is granted by implication or otherwise, and there is no representation or warranty that
anything made in accordance with this material will be free from any patent or copyright infringement of a third
party. When exporting the products or technology described in this material, you should comply with the
applicable export control laws and regulations and follow the procedures required by such laws and regulations.
You are requested not to use, to resell, to export and/or to otherwise dispose of the products (and any technical
information furnished, if any) for the development and/or manufacture of weapon of mass destruction or for other
military purposes.
All brands or product names mentioned herein are trademarks and/or registered trademarks of their respective
companies.
©SEIKO EPSON CORPORATION 2015, All rights reserved.

S5U1C17656T Manual Seiko Epson Corporation i
(Rev. 1.0)
Configuration of product number
S1
C
17xxx
F
00E1
00
Devices
■ Packing specifications
00: Besides tape & reel
0A: TCP BL 2 directions
0B: Tape & reel BACK
0C: TCP BR 2 directions
0D: TCP BT 2 directions
0E: TCP BD 2 directions
0F: Tape & reel FRONT
0G: TCP BT 4 directions
0H: TCP BD 4 directions
0J: TCP SL 2 directions
0K: TCP SR 2 directions
0L: Tape & reel LEFT
0M: TCP ST 2 directions
0N: TCP SD 2 directions
0P: TCP ST 4 directions
0Q: TCP SD 4 directions
0R: Tape & reel RIGHT
99: Specs not fixed
■ Specification
■ Package
D: Bare chip
F: QFP
B: BGA, WCSP
■ Model number
■ Model name
C: Microcontroller, digital products
■ Product classification
S1: Semiconductor
S5U1
C
17000
Y2
1
00
Development tools
■ Packing specifications
00: Standard packing
■ Version
1: Version 1
■ Tool type
Hx: ICE
Tx: Evaluation board
Cx: Compiler package
Yx: Programmer software
■ Corresponding model number
17xxx: For S1C17xxx
■ Tool classification
C: Microcontroller use
■ Product classification
S5U1: Development tool
for semiconductor products

ii Seiko Epson Corporation S5U1C17656T Manual
(Rev. 1.0)
Table of Contents
1. Overview ....................................................................................................................1
1.1 Directions for Use ................................................................................................................... 2
2. Name and Function of Each Part ..............................................................................3
2.1 Name of Each Part .................................................................................................................. 3
2.2 Function of Each Part ............................................................................................................. 5
2.2.1 Function of Jumper Switch ................................................................................................. 5
2.2.2 Functions of Parts............................................................................................................... 5
3. Block Diagram ...........................................................................................................6
4. Connection Terminals (Through Holes) ...................................................................7
Appendix A Circuit Diagram .........................................................................................8
Appendix B LCD Panel Wiring Diagram.......................................................................9
Appendix C S5U1C17656T1100 Parts List .................................................................10
Revision History............................................................................................................. 11

1. Overview
S5U1C17656T Manual Seiko Epson Corporation 1
(Rev. 1.0)
1. Overview
The S5U1C17656T (SVT17656: Software Evaluation Tool for S1C17656) is an evaluation board for the Seiko
Epson single-chip microcontroller S1C17656. This board includes an S1C17656, an LCD panel, touch keys, and
a piezoelectric buzzer.
1) CPU
S1C17656 (TQFP14-80pin)
2) Power supply voltage
Coin type battery (CR2032, 3.0 V) 1
3) CPU clock
OSC1A: 32.768 kHz crystal resonator
OSC3B: S1C17656 internal oscillator
4) Devices mounted
S1C17656 (16-bit MCU)
Crystal resonator (32.768 kHz)
LCD panel (7 SEG × 6 digits, 30 segments × 2 commons)
12 touch keys
Piezoelectric buzzer
Coin type battery holder
Jumper patterns for current consumption measurement
Through-hole patterns for debug interface
Through-hole patterns for UART communication
5) Operating temperature range
5 °C to 35 °C
6) Operating voltage range
2.2 V to 3.6 V
1 Note that no coin type battery is included.
Note! Be sure to avoid using chlorinated solvents on this board. Depending on the on-board component, they
may cause corrosion that interferes with using the board safely.

1. Overview
2 Seiko Epson Corporation S5U1C17656T Manual
(Rev. 1.0)
1.1 Directions for Use
An S1C17656 software debugging and evaluation environment can be constructed with the procedure shown
below.
<When performing software debugging>
(1) The S5U1C17656T has through hole electrodes for the debug signals but does not provide components
required for the debug interface such as connectors to connect with the 4-pin target interface cable and 4-pin
flash programming power supply cable supplied with the S5U1C17001H (ICDmini).
To perform software debugging using this board, prepare the components required for connecting with the
ICDmini.
(2) Supply power to the S5U1C17656T by putting a coin type battery (CR2032, 3.0V) into the battery holder, or
connecting the power supply cable of the S5U1C17001H2 (ICDmini Ver. 2) or a stabilized power supply to
the terminals of the battery holder. The power supply voltage must be within the S1C17656 operating
voltage range (1.8 V to 3.6 V when programming the flash memory embedded in the S1C17656).
(3) Connect the ICDmini to the PC using the USB cable supplied with the ICDmini.
The DIP switches on the ICDmini (SW4 and SW5 to select the DSIO signal level) should be set to “Voltage input
from the target system.” If the S5U1C17001H2 (ICDmini Ver. 2) is used as the emulator and the flash
erasing/programming voltage is supplied from the ICDmini, set DIP SW8 on the ICDmini to configure the flash
programming voltage output to be enabled.
Figure 1.1.1 Connections for Software Debugging
S5U1C17001H
For connecting
target system
For flash program-
ming power supply
USB cable
This board
(S5U1C17656T)
ICDmini (S5U1C17001H)
 Use the power supply in the ICDmini
Ver. 2 or a stabilized power supply.
Stabilized
power supply
1 2 3 4 5 6 7 8
ICDmini DIP switch
setting
OFF
ON

2. Name and Function of Each Part
S5U1C17656T Manual Seiko Epson Corporation 3
(Rev. 1.0)
2. Name and Function of Each Part
2.1 Name of Each Part
The figure below shows the name of each part.
Figure 2.1.1 Part Names on Front Side of S5U1C17656T
LCD Panel (LCD1)
Serial communication
terminals
Buzzer (BZ1)
Touch keys
(12 keys)
Crystal resonator
(X1) 32.768 kHz
S1C17656 (U1)
Debug interface
terminal Group 1
Debug interface
terminal Group 2

2. Name and Function of Each Part
4 Seiko Epson Corporation S5U1C17656T Manual
(Rev. 1.0)
Figure 2.1.2 Part Names on Back Side of S5U1C17656T
Battery holder
(BT1)
Jumper switch for
current consumption
measurement (JP1)

2. Name and Function of Each Part
S5U1C17656T Manual Seiko Epson Corporation 5
(Rev. 1.0)
2.2 Function of Each Part
2.2.1 Function of Jumper Switch
Table 2.2.1.1 Jumper Switch Function
Name
Type
Function
Factory setting
Optional setting
JP1
Soldered
S1C17656 current consumption measurement (VSS)
1
Short-circuited
Open
1 To measure current consumption of the S1C17656, insert an ammeter between the jumper terminals.
2.2.2 Functions of Parts
Table 2.2.2.1 List of Major Parts and Their Function
Part name
Location
Function
IC
U1
S1C17656 (16-bit MCU)
LCD
LCD1
TN 30 segments × 2 commons, 1/3 bias, 1/2 duty
Coin type battery holder
BT1
CR2032 coin type battery holder
Crystal resonator
X1
32.768 kHz, MC-146 (7 pF)
Piezoelectric buzzer
BZ1
Ø = 12.2 mm
Resistors
R1–R6
5.6 MΩ, for charging/discharging touch keys
Connection terminal
Vdd
Through hole for degug interface Group 1
Connection terminal
#RESET
Through hole for degug interface Group 1
Connection terminal
GND_2
Through hole for degug interface Group 1
Connection terminal
Vpp
Through hole for degug interface Group 1
Connection terminal
DCLK
Through hole for degug interface Group 2
Connection terminal
GND_3
Through hole for degug interface Group 2
Connection terminal
DSIO
Through hole for degug interface Group 2
Connection terminal
DST2
Through hole for degug interface Group 2
Connection terminal
P00/SIN0
Through hole for connecting a serial communication device
Connection terminal
P01/SOUT0
Through hole for connecting a serial communication device
Connection terminal
GND_1
Through hole for connecting a serial communication device

3. Block Diagram
6 Seiko Epson Corporation S5U1C17656T Manual
(Rev. 1.0)
3. Block Diagram
The figure below shows the block diagram of the S5U1C17656T.
Figure 3.1 S5U1C17656T Block Diagram

4. Connection Terminals (Through Holes)
S5U1C17656T Manual Seiko Epson Corporation 7
(Rev. 1.0)
4. Connection Terminals (Through Holes)
Table 4.1 List of Debug Interface Group 1 Connection Terminals
No.
Terminal name
I/O
Function
1
Vdd
I/O
Target operating voltage input/output
2
#RESET
I
Target reset signal input
3
GND
–
Power supply (GND)
4
Vpp
I
Flash programming voltage input
Table 4.2 List of Debug Interface Group 2 Connection Terminals
No.
Terminal name
I/O
Function
1
DCLK
O
Clock signal output for debugging
2
GND
–
Power supply (GND)
3
DSIO
I/O
Serial communication signal input/output for debugging
4
DST2
O
Debug status signal output
Table 4.3 List of Serial Communication Signal Connection Terminals
No.
Terminal name
I/O
Function
1
P00/SIN0
I
Serial communication (UART) signal input
2
P01/SOUT0
O
Serial communication (UART) signal output
3
GND
–
Power supply (GND)

Appendix A Circuit Diagram
8 Seiko Epson Corporation S5U1C17656T Manual
(Rev. 1.0)
Appendix A Circuit Diagram
A 9 pF capacitor is used for C4 and C5
so that the OSC1 oscillation frequency
measured value is adjusted as close to
32.768 kHz as possible.
Touch key layout
R10 should be arranged near U1.
C1 and C2 should be
arranged near U1.

Appendix B LCD Panel Wiring Diagram
S5U1C17656T Manual Seiko Epson Corporation 9
(Rev. 1.0)
Appendix B LCD Panel Wiring Diagram

Appendix C S5U1C17656T1100 Parts List
10 Seiko Epson Corporation S5U1C17656T Manual
(Rev. 1.0)
Appendix C S5U1C17656T1100 Parts List
Table C.1 S5U1C17656T1100 Parts List 1
No.
Location
Name
Product No.
Specification
Q’ty
Manufacture
1
U1
MCU
S1C17656
TQFP14-80pin
1
SEIKO EPSON CORPORATION
2
LCD1
LCD panel
Custom product
TN, driven with 3 V
1
MAP ELECTRONICS CO.,LTD.
3
BT1
Coin battery holder
CH7410-2032LF
for CR2032
1
TAKACHI ELECTRONICS
ENCLOSURE CO., LTD.
4
X1
Crystal resonator
MC-146 (CL = 7 pF)
32.768 kHz
1
SEIKO EPSON CORPORATION
5
BZ1
Piezoelectric buzzer
PS1240P02BT
Ø = 12.2 mm
1
TDK Corporation
6
R1, R2,
R3, R4,
R5, R6
Resistor
MCR03ERTJ565
5.6 MΩ 1608
6
ROHM Co., Ltd.
7
R7
Resistor
MCR03ERTJ103
10 kΩ 1608
1
ROHM Co., Ltd.
8
R8, R9
Resistor
MCR03ERTJ220
22 Ω 1608
2
ROHM Co., Ltd.
9
R10
Resistor
MCR03ERTJ330
33 Ω 1608
1
ROHM Co., Ltd.
10
C1, C6
Capacitor
GRM188R71C104KA01D
0.1 µF 16 V B 1608
2
Murata Manufacturing Co., Ltd.
11
C2
Capacitor
C1608X5R0J106M080AB
10 µF 6.3 V B 1608
1
TDK Corporation
12
C3
Capacitor
GRM188R71C474KA88D
0.47 µF 16 V 1608
1
Murata Manufacturing Co., Ltd.
13
C4, C5
Capacitor
GRM1885C1H9R0DZ01D
9 pF 50 V 1608
2
Murata Manufacturing Co., Ltd.
14
C7, C9,
C10, C11,
C12, C13
Capacitor
GRM188R61C105KA12D
1 µF 16 V B 1608
6
Murata Manufacturing Co., Ltd.
15
C8
Capacitor
GRM188R60J475KE19D
4.7 µF 6.3 V B 1608
1
Murata Manufacturing Co., Ltd.
1 Parts are subject to change without notice.
Table C.2 S5U1C17656T1100 Parts List (Installed Part, Attachments) 1
No.
Name
Product No.
Specification
Q’ty
Manufacture
1
Polycarbonate plate
N144005-01 (custom product)
Transparent, t = 0.5 mm,
55 × 65 mm
2
Nissho Sangyo Co.,Ltd
2
Plastic screw
PC-0204
M2 4 mm, Material: PC
4
Hirosugi-Keiki Co.,Ltd.
3
Plastic nut
PCNT-02
M2, Material: PC
4
Hirosugi-Keiki Co.,Ltd.
1 Parts are subject to change without notice.

Revision History
S5U1C17001Y23 Multi-Programmer Seiko Epson Corporation 11
System Manual (Rev. 1.0)
Revision History
Attachment-1
Rev. No.
Date
Page
Category
Contents
Rev 1.0
2015/03/13
All
New
New establishment

International Sales Operations
AMERICA
EPSON ELECTRONICS AMERICA, INC.
214 Devcon Drive,
San Jose, CA 95112, USA
Phone: [phone] FAX: [phone]
EUROPE
EPSON EUROPE ELECTRONICS GmbH
Riesstrasse 15, 80992 Munich,
GERMANY
Phone: [phone] FAX: [phone]
ASIA
EPSON (CHINA) CO., LTD.
7F, Jinbao Bldg., No.89 Jinbao St.,
Dongcheng District,
Beijing 100005, CHINA
Phone: [phone] FAX: [phone]
SHANGHAI BRANCH
7F, Block B, Hi-Tech Bldg., 900 Yishan Road,
Shanghai 200233, CHINA
Phone: [phone] FAX: [phone]
SHENZHEN BRANCH
12F, Dawning Mansion, Keji South 12th Road,
Hi-Tech Park, Shenzhen 518057, CHINA
Phone: [phone] FAX: [phone]
EPSON HONG KONG LTD.
Unit 715-723, 7/F Trade Square, 681 Cheung Sha Wan Road,
Kowloon, Hong Kong.
Phone: [phone] FAX: [phone]
EPSON TAIWAN TECHNOLOGY & TRADING LTD.
14F, No. 7, Song Ren Road,
Taipei 110, TAIWAN
Phone: [phone] FAX: [phone]
EPSON SINGAPORE PTE., LTD.
1 HarbourFront Place,
#03-02 HarbourFront Tower One, Singapore 098633
Phone: [phone] FAX: [phone]
SEIKO EPSON CORP.
KOREA OFFICE
19F, KLI 63 Bldg., 60 Yoido-dong,
Youngdeungpo-Ku, Seoul 150-763, KOREA
Phone: [phone] FAX: [phone]
SEIKO EPSON CORP.
MICRODEVICES OPERATIONS DIVISION
Device Sales & Marketing Department
421-8, Hino, Hino-shi, Tokyo 191-8501, JAPAN
Phone: [phone] FAX: [phone]
Document Code: 413001300
Issue May 2015 in JAPAN L
