Design and Functionality for Diverse Applications
Compact, Ergonomic Design [2550] [1760] [1710] [900A] [80WU]
The interface section and operation section are integrated into the
compactbody.Takingadvantageoftheslimsizeandlightweight
of the LCD panel, this integrated design enhances setup flexibility
and simplifies operation.
Detachable Control Panel Adds Versatility [900A]
The control panel is separated from the monitor, making the
BT-LH900A suitable for a wide range of applications, including use
as a monitor or viewfinder.
Function Keys [2550] [1760] [1710] [900A] [80WU]
Eachofthefunctionkeysonthefrontpanelcanbeassignedwitha
function selected from various display and switchover functions* to
enable one-touch display ON/OFF or mode change. These function
buttonsspeedoperationandcustomizethefunctionstothe
individual user’s needs.
Functions Assignable to Function Keys (for the BT-LH1760*)
HV Delay/Autosetup/Blue Only/Gamma Select/
SD Aspect/Scan/Sub Window/WFM/Vector/Marker/
Pixel to Pixel/Pixel Position/Level Meter/Cross Hatch/Mono/
Time Code/Closed Caption/Undef
* Assignable functions vary depending on the model.
Production Tough for Field Use [1760] [1710] [900A] [80WU]
Panasonic BT-Series LCD
monitors are built with an
aluminum diecast frame. This
superior build quality has been
proven in the field to be
production tough.
* Front section only for the BT-LH1760/
LH1710.
SDI and Component Input [2550] [1760] [1710] [900A] [80WU]
All five monitors allow for SDI with automatic switching between
HD and SD. The BT-LH2550/LH1760/LH1710 are equipped with
two SDI inputs and one SDI output. These models are also
equipped with a component input (Y, PB, PR, RGB switching),
Y/C, and composite. RGB is compatible with PC input.
The BT-LH900A is equipped with two SDI inputs and one SDI
output, one component input (Y, PB, PRor RGB switching),
and one composite input. The BT-LH80WU is equipped with SDI
(HD/SD) and Component (Y, PB, PR) input.
DVI-D Terminal (HDCP supported) [2550] [1760] [1710]
The BT-LH1760 is equipped with a DVI-D input terminal for
connection to a digital device with DVI-D output. It also supports
HDCP, so a device with an HDMI terminal, such as a BD/DVD
player, can be connected using a commercially available
conversion cable or adapter.
* DVI-A (analog) and DVI-DL (Dual Link) are not supported.
External Remote Compatibility
[2550] [1760] [1710] [900A] [80WU]
ThestandardRS-232C(9-pin)andGPI(9-pin)remoteinput
terminals allow the monitor to be operated by an external device.
Tally Lamps [2550] [1760] [1710] [900A] [80WU]
The front panel has red and green tally lamps. The BT-LH80WU also
has a rear tally lamp for added convenience when using as a viewfinder.
Viewfinder Connector [80WU]
Equippedwitha15-pinviewfinderterminal,theBT-LH80WUcan
also be used as a viewfinder* for compatible Panasonic camera-
recorders—AJ-HPX3700,AJ-HPX2700,AJ-HPX3000,AJ-HDX900,
AJ-HDC27H,AJ-HPX2000(USmodel),AJ-HPX2100(European/
Asian model), AG-HPX500* and AG-HPX502* (Asian model).
You can also run the BT-LH80WU on DC power supplied by these
camera-recorders. Connection is easy, requiring only a viewfinder
cable and DC power cable, supplied as the optional BT-CS80G.
*Optional hardware is required for mounting to a camera-recorder.
Stereo Speakers [1760] [1710]
The built-in speakers on the right and left sides of the screen let
you confirm stereo sound without having to connect external
speakers.
Headphone Jack [2550] [1760] [1710]
TheBT-LH2550/LH1760/LH1710areprovidedwithaheadphonejack.
Low Consumption Current [1760] [1710]
The low-current-consuming LCD provides extra flexibility for use in
an OB van or in the studio, and provides high cost-effectiveness.
The consumption current of the BT-LH1760 operating on AC power
is about 50% lower than our previous model.
Fanless Drive [2550] [1760] [1710]
Fanless drive and its quiet operation make these models ideal for
use in editing studios or MA rooms.
Power Save Mode [2550] [1760] [1710]
When no signal is received for 60 continuous seconds, the Power
SaveModeisactivatedtominimizepowerconsumption.
DC and Low Power Operation [900A] [80WU]
DC operation (Anton Bauer/DC IN) makes the BT-LH900A and
BT-LH80WU ideal for use outdoors. Power consumption is very
low, despite their HD/SD compatibility.
Rack Mounting [1760] [1710] [900A] [80WU]
These four models can be mounted in a 19” rack. The BT-LH80WU
and BT-LH900A allow side-by-side rack mounting when optional
rack mounting hardware is used. The BT-LH1760 and BT-LH1710
use the optional BT-MA1710G adaptor for rack mounting.
Wall Mounting [2550] [1760] [1710]
The optional wall mounting hardware (BT-WMA17G or
BT-WMA26G, sold separately) allows wall mounting of these thin,
lightweight LCD monitors.
Protective Panel [1760] [1710]
The optional protective panel (BT-PRP17G) protects the LCD panel
from environmental elements such as sand and dust in outdoor use.
