Panasonic TH-43LFE8U User manual

Operating Instructions
FULL HD LCD Display For business use
Model No. TH-43LFE8U 43-inch model
TH-48LFE8U 48-inch model
TH-55LFE8U 55-inch model
TH-65LFE8U 65-inch model
TH-43LFE8E 43-inch model
TH-48LFE8E 48-inch model
TH-55LFE8E 55-inch model
TH-65LFE8E 65-inch model
English Please read these instructions before operating your set
and retain them for future reference.

Dear Panasonic Customer
Welcome to the Panasonic family of customers. We hope that you will have many years of enjoyment from your new LCD Display.
To obtain maximum benefit from your set, please read these Instructions before making any adjustments, and retain them for future
reference.
Retain your purchase receipt also, and note down the model number and serial number of your set in the space provided on the
rear cover of these instructions.
Visit our Panasonic Web Site http://panasonic.com

3
English
Table of Contents
Before use
● IllustrationsandscreensinthisOperatingInstructions
areimagesforillustrationpurposes,andmaybe
differentfromtheactualones.
● DescriptiveillustrationsinthisOperatingInstructions
arecreatedmainlybasedonthe48-inchmodel.
Important Safety Instructions..................................... 4
FCC STATEMENT......................................................... 5
Important Safety Notice .............................................. 6
Safety Precautions ...................................................... 7
WARNING········································································· 7
CAUTION································································· 8
Precautions for use..................................................... 9
Cautionswheninstalling···················································· 9
Cleaningandmaintenance·············································· 10
WiredLAN······································································· 10
Disposal·········································································· 10
Accessories ............................................................... 11
AccessoriesSupply························································· 11
RemoteControlBatteries················································ 12
Kensingtonsecurity························································· 12
Connections............................................................... 13
ACcordconnectionandfixing········································· 13
Cablefixing······································································ 14
Videoequipmentconnection··········································· 15
HDMI1and2terminalsconnection································ 16
DVI-DINterminalconnection·········································· 17
PCINterminalconnection··············································· 18
VIDEOterminalconnection············································· 19
SERIALterminalconnection············································ 19
IRIN/OUTterminalconnection······································· 21
AUDIOOUTterminalconnection···································· 21
USBterminalconnection················································· 22
Identifying Controls................................................... 23
MainUnit········································································· 23
RemoteControlTransmitter············································ 24
Basic Controls ........................................................... 25
Selectingtheinputsignal················································ 27
RECALL··········································································· 27
VolumeAdjustment·························································· 28
SoundmuteOn/Off······················································· 28
OFFTIMER····································································· 28
ASPECT Controls ...................................................... 29
Digital ZOOM.............................................................. 30
USB Media Player...................................................... 31
Functiondescription························································ 31
Preparation······································································ 31
Playingbackthefiles······················································· 32
Networkenvironment(MultiMediaPlayeronly)·············· 34
Starting/endingMediaPlayer········································ 35
ResumePlayfunction····················································· 35
On-Screen Menu Displays ........................................ 36
Adjusting Position..................................................... 38
Autosetup······································································· 38
Sound Adjustment..................................................... 40
Picture Adjustments.................................................. 41
Picture Profiles .......................................................... 43
Savingprofiles································································· 44
Loadingprofiles······························································· 45
Editingprofiles································································· 45
Setup menu................................................................ 47
Signal·············································································· 47
Screensaver
(Forpreventingimageretention)····································· 50
Inputlabel········································································ 51
Powermanagementsettings··········································· 51
Wobbling········································································· 52
Noactivitypoweroff························································ 52
OSDlanguage································································· 52
MultiDisplaySettings······················································ 53
Setuptimer····································································· 54
Dateandtime·································································· 54
Networksettings······························································ 55
USBmediaplayersettings·············································· 56
Functionbuttonsettings·················································· 57
Displayorientation··························································· 58
OSDposition··································································· 58
Menudisplayduration····················································· 58
Menutransparency·························································· 58
Options Adjustments ................................................ 59
Using Network Function ........................................... 64
Necessaryenvironmentforcomputerstobeconnected· 64
Exampleofnetworkconnection······································ 64
Commandcontrol···························································· 65
PJLinkprotocol································································ 65
EarlyWarningSoftware··················································· 66
MultiMonitoring&ControlSoftware································ 66
Connecting with LAN ................................................ 66
Computeroperation························································· 66
Using Web Browser Control..................................... 67
BeforeUsingWebBrowserControl································ 67
AccessfromWebBrowser·············································· 67
OperatingwithWebBrowser··········································· 68
UsingWebBrowserControl············································ 71
ID Remote Control Function..................................... 73
Settingtheremotecontrol’sIDnumber··························· 73
Cancellingthesettingofremotecontrol’sIDnumber······ 73
Entering characters................................................... 74
Preset Signals............................................................ 75
Shipping condition.................................................... 77
Data Cloning .............................................................. 78
CopyingthedisplaydatatotheUSBmemory················· 78
CopyingtheUSBmemorydatatothedisplay················· 79
Troubleshooting ........................................................ 80
Specifications ............................................................ 82
Software License....................................................... 84

English
4
CAUTION
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
WARNING: To reduce the risk of electric shock,
do not remove cover or back.
No user-serviceable parts inside. Refer servicing
to qualified service personnel.
Thelightningflashwitharrow-headwithina
triangleisintendedtotelltheuserthatparts
insidetheproductareariskofelectricshock
topersons.
Theexclamationpointwithinatriangle
isintendedtotelltheuserthatimportant
operatingandservicinginstructionsareinthe
paperswiththeappliance.
WARNING:
To prevent damage which may result in fire or
shock hazard, do not expose this apparatus to
rain or moisture.
Do not place containers with water (flower vase,
cups, cosmetics, etc.) above the set.
(including on shelves above, etc.)
WARNING:
1)Topreventelectricshock,donotremovecover.No
userserviceablepartsinside.Referservicingto
qualifiedservicepersonnel.
2)Donotremovethegroundingpinonthepower
plug.Thisapparatusisequippedwithathreepin
grounding-typepowerplug.Thisplugwillonlyfit
agrounding-typepoweroutlet.Thisisasafety
feature.Ifyouareunabletoinserttheplugintothe
outlet,contactanelectrician.
Donotdefeatthepurposeofthegroundingplug.
Important Safety
Instructions
 1)Readtheseinstructions.
 2)Keeptheseinstructions.
 3)Heedallwarnings.
 4)Followallinstructions.
 5)Donotusethisapparatusnearwater.
 6)Cleanonlywithdrycloth.
 7)Donotblockanyventilationopenings.Installin
accordancewiththemanufacturer’sinstructions.
 8)Donotinstallnearanyheatsourcessuchas
radiators,heatregisters,stoves,orotherapparatus
(includingamplifiers)thatproduceheat.
 9)Donotdefeatthesafetypurposeofthepolarizedor
grounding-typeplug.Apolarizedplughastwoblades
withonewiderthantheother.Agroundingtypeplug
hastwobladesandathirdgroundingprong.The
widebladeorthethirdprongareprovidedforyour
safety.Iftheprovidedplugdoesnotfitintoyour
outlet,consultanelectricianforreplacementofthe
obsoleteoutlet.
10)Protectthepowercordfrombeingwalkedon
orpinchedparticularlyatplugs,convenience
receptacles,andthepointwheretheyexitfromthe
apparatus.
11)Onlyuseattachments/accessoriesspecifiedbythe
manufacturer.
12)Useonlywiththecart,stand,tripod,
bracket,ortablespecifiedbythe
manufacturer,orsoldwiththeapparatus.
Whenacartisused,usecautionwhen
movingthecart/apparatuscombination
toavoidinjuryfromtip-over.
13)Unplugthisapparatusduringlightningstormsor
whenunusedforlongperiodsoftime.
14)Referallservicingtoqualifiedservicepersonnel.
Servicingisrequiredwhentheapparatushasbeen
damagedinanyway,suchaspower-supplycordor
plugisdamaged,liquidhasbeenspilledorobjects
havefallenintotheapparatus,theapparatushas
beenexposedtorainormoisture,doesnotoperate
normally,orhasbeendropped.
15)Topreventelectricshock,ensurethegroundingpin
ontheACcordpowerplugissecurelyconnected.

5
English
FCC STATEMENT
Thisequipmenthasbeentestedandfoundtocomply
withthelimitsforaclassAdigitaldevice,pursuantto
Part15oftheFCCRules.Theselimitsaredesigned
toprovidereasonableprotectionagainstharmful
interferencewhentheequipmentisoperatedina
commercialenvironment.Thisequipmentgenerates,
usesandcanradiateradiofrequencyenergyand,ifnot
installedandusedinaccordancewiththeinstructions
manual,maycauseharmfulinterferencetoradio
communications.Operationofthisequipmentina
residentialareaislikelytocauseharmfulinterference
inwhichcasetheuserwillberequiredtocorrectthe
interferenceathisownexpense.
FCC CAUTION:
To assure continued compliance, follow the attached
installation instructions and use only the provided
power supply cord. Any changes or modifications
not expressly approved by Panasonic Corp. of North
America could void the user’s authority to operate
this device.
DeclarationofVerification
ModelNo.
TH-43LFE8U,TH-48LFE8U
TH-55LFE8U,TH-65LFE8U
ResponsibleParty:
PanasonicCorporationofNorthAmerica
TwoRiverfrontPlaza,Newark,NewJersey
07102-5490
ContactSource:
PanasonicSystemCommunicationsCompanyof
NorthAmerica
1-877-655-2357
GeneralContact:
http://www.panasonic.com/contactinfo
ThisdevicecomplieswithPart15oftheFCCRulesand
allapplicableICRSSstandards.Operationissubject
tothefollowingtwoconditions:(1)Thisdevicemaynot
causeharmfulinterference,and(2)thisdevicemust
acceptanyinterferencereceived,includinginterference
thatmaycauseundesiredoperation.
CANADIAN NOTICE:
ThisClassAdigitalapparatuscomplieswith
CanadianICES-003.
WARNING:
• Notforuseinacomputerroomasdefinedinthe
StandardfortheProtectionofElectronicComputer/
DataProcessingEquipment,ANSI/NFPA75.
• Forpermanentlyconnectedequipment,areadily
accessibledisconnectdeviceshallbeincorporated
inthebuildinginstallationwiring.
• Forpluggableequipment,thesocket-outletshall
beinstalledneartheequipmentandshallbeeasily
accessible.
Note:
Imageretentionmayoccur.Ifyoudisplayastill
pictureforanextendedperiod,theimagemight
remainonthescreen.However,itwilldisappearwhen
ageneralmovingpictureisdisplayedforawhile.
Trademark Credits
• Microsoft®,Windows®,WindowsVista®,Windows®7,
Windows®8andInternetExplorer®aretheregistered
trademarksortrademarksofMicrosoftCorporationin
theUnitedStatesand/orothercountries.
• Macintosh,Mac,MacOS,OSXandSafariarethe
trademarksofAppleInc.registeredintheUnited
Statesandothercountries.
• PJLinkisaregisteredorpendingtrademarkinJapan,
theUnitedStates,andothercountriesandregions.
• HDMI,theHDMILogo,andHigh-Definition
MultimediaInterfacearetrademarksorregistered
trademarksofHDMILicensingLLCintheUnited
Statesandothercountries.
• JavaScriptisaregisteredtrademarkoratrademarkof
OracleCorporationanditssubsidiaryandassociated
companiesintheUnitedStatesand/orother
countries.
• RoomView,CrestronRoomViewandFusionRVare
registeredtrademarksofCrestronElectronics,Inc,
andCrestronConnectedisthetrademarkofCrestron
Electronics,Inc.
Evenifnospecialnotationhasbeenmadeofcompany
orproducttrademarks,thesetrademarkshavebeenfully
respected.

English
6
Important Safety
Notice
WARNING
1)Topreventdamagewhichmayresultinfireor
shockhazard,donotexposethisapplianceto
drippingorsplashing.
Donotplacecontainerswithwater(flowervase,
cups,cosmetics,etc.)abovetheset.(includingon
shelvesabove,etc.)
Nonakedflamesources,suchaslightedcandles,
shouldbeplacedon/abovetheset.
2)Topreventelectricshock,donotremovecover.No
userserviceablepartsinside.Referservicingto
qualifiedservicepersonnel.
3)Donotremovetheearthingpinonthepower
plug.Thisapparatusisequippedwithathreepin
earthing-typepowerplug.Thisplugwillonlyfitan
earthing-typepoweroutlet.Thisisasafetyfeature.
Ifyouareunabletoinserttheplugintotheoutlet,
contactanelectrician.
Donotdefeatthepurposeoftheearthingplug.
4)Topreventelectricshock,ensuretheearthingpin
ontheACcordpowerplugissecurelyconnected.
CAUTION
Thisapplianceisintendedforuseinenvironments
whicharerelativelyfreeofelectromagneticfields.
Usingthisappliancenearsourcesofstrong
electromagneticfieldsorwhereelectricalnoisemay
overlapwiththeinputsignalscouldcausethepicture
andsoundtowobbleorcauseinterferencesuchas
noisetoappear.
Toavoidthepossibilityofharmtothisappliance,keep
itawayfromsourcesofstrongelectromagneticfields.
WARNING
ThisisaclassAproduct.Inadomesticenvironment
thisproductmaycauseradiointerferenceinwhich
casetheusermayberequiredtotakeadequate
measures.
IMPORTANT: THE MOULDED PLUG
FOR YOUR SAFETY, PLEASE READ THE
FOLLOWING TEXT CAREFULLY.
Thisdisplayissuppliedwithamouldedthreepin
mainsplugforyoursafetyandconvenience.A5amp
fuseisfittedinthisplug.Shallthefuseneedtobe
replaced,pleaseensurethatthereplacementfuse
hasaratingof5ampsandthatitisapprovedby
ASTAorBSItoBS1362.
CheckfortheASTAmark ortheBSImark on
thebodyofthefuse.
Iftheplugcontainsaremovablefusecover,youmust
ensurethatitisrefittedwhenthefuseisreplaced.
Ifyoulosethefusecovertheplugmustnotbeused
untilareplacementcoverisobtained.
Areplacementfusecovercanbepurchasedfrom
yourlocalPanasonicdealer.
Donotcutoffthemainsplug.
Donotuseanyothertypeofmainsleadexceptthe
onesuppliedwiththisdisplay.
Thesuppliedmainsleadandmouldedplugare
designedtobeusedwiththisdisplaytoavoid
interferenceandforyoursafety.
Ifthesocketoutletinyourhomeisnotsuitable,getit
changedbyaqualifiedelectrician.
Iftheplugormainsleadbecomesdamaged,
purchaseareplacementfromanauthorizeddealer.
WARNING : — THIS DISPLAY MUST BE EARTHED.
How to replace the fuse.
Openthefusecompartmentwithascrewdriverand
replacethefuse.

7
English
Safety Precautions
WARNING
■Setup
This LCD Display is for use only with the following
optional accessories.
Use with any other type of optional accessories may
cause instability which could result in the possibility
of injury.
(Allofthefollowingaccessoriesaremanufacturedby
PanasonicCorporation.)
• Pedestal
TY-ST43PE8(for43/48/55-inchmodels)
TY-ST65PE8(for65-inchmodel)
Wearenotresponsibleforanyproductdamage,etc.
causedbyfailuresintheinstallationenvironmentfor
thepedestalorwall-hangingbracketevenduringthe
warrantyperiod.
Alwaysbesuretoaskaqualifiedtechniciantocarryout
set-up.
Smallpartscanpresentchokinghazardifaccidentally
swallowed.Keepsmallpartsawayfromyoungchildren.
Discardunneededsmallpartsandotherobjects,
includingpackagingmaterialsandplasticbags/sheetsto
preventthemfrombeingplayedwithbyyoungchildren,
creatingthepotentialriskofsuffocation.
Do not place the Display on sloped or unstable
surfaces and ensure that the Display does not hang
over the edge of the base.
• TheDisplaymayfalloffortipover.
Install this unit at a location with minimal vibration
and which can support the weight of the unit.
• Droppingorfallingoftheunitmaycauseinjuryor
malfunction.
Do not place any objects on top of the Display.
• IfforeignobjectsorwatergetinsidetheDisplay,a
short-circuitmayoccurwhichcouldresultinfireor
electricshock.Ifanyforeignobjectsgetinsidethe
Display,pleaseconsultyourlocalPanasonicdealer.
Transport only in upright position!
• Transportingtheunitwithitsdisplaypanelfacing
uprightordownwardmaycausedamagetothe
internalcircuitry.
Ventilation should not be impeded by covering
the ventilation openings with items such as
newspapers, table cloths and curtains.
For sufficient ventilation, see page 9.
Caution - For use only with UL Listed Wall Mount
Bracket with minimum weight/load 36.2kg.
When installing the Display vertically;
WheninstallingtheDisplayvertically,besurethat
thePowerIndicatorcomestothedownside.Heatis
generatedanditmaycausefireordamagetothe
Display.
Powerindicator
43/48/55-inchmodels
65-inchmodel
Cautions for Wall or Pedestal Installation
• WallorPedestalinstallationshouldbeperformed
byaninstallationprofessional.InstallingtheDisplay
incorrectlymayleadtoanaccidentthatresultsin
deathorseriousinjury.UsetheoptionalPedestal.
• Wheninstallingonawall,awallhangingbracketthat
conformstoVESAstandardsmustbeused.
• 43/48-inchmodels:VESA200×200
55/65-inchmodels:VESA400×400(seepage9)
• IfyouterminatetheuseoftheDisplayontheWallor
Pedestal,askaprofessionaltoremovetheDisplayas
soonaspossible.
• WhenmountingtheDisplayonthewall,preventthe
mountingscrewsandpowercablefromcontacting
metalobjectsinsidethewall.Anelectricshockmay
occuriftheycontactmetalobjectsinsidethewall.
Do not install the product to a place where the
product is exposed to direct sunlight.
• Ifthescreenisexposedtodirectsunlight,theliquid
crystalpanelmayhaveadverseeffect.
■When using the LCD Display
The Display is designed to operate on 110 - 127 or
220 - 240 V AC, 50/60 Hz.
Do not cover the ventilation holes.
• DoingsomaycausetheDisplaytooverheat,which
cancausefireordamagetotheDisplay.
Do not stick any foreign objects into the Display.
• Donotinsertanymetalorflammableobjectsintothe
ventilationsholesordropthemontotheDisplay,as
doingsocancausefireorelectricshock.
Do not remove the cover or modify it in any way.
• Highvoltageswhichcancausesevereelectricshocks
arepresentinsidetheDisplay.Foranyinspection,
adjustmentandrepairwork,pleasecontactyourlocal
Panasonicdealer.

English
8
Ensure that the mains plug is easily accessible.
65-inch model
The mains plug shall be connected to a
mains socket outlet with a protective earthing
connection.
Do not use any power supply cord other than that
provided with this unit.
• Doingsomaycauseshort-circuit,generatesheat,
etc.,whichcouldcauseelectricshockorfire.
Do not use the supplied power supply cord with any
other devices.
• Doingsocouldcauseelectricshockorfire.
Securely insert the power supply plug as far as it
will go.
• Iftheplugisnotfullyinserted,heatmaybegenerated
whichcouldcausefire.Iftheplugisdamagedorthe
wallsocketisloose,theyshallnotbeused.
Do not handle the power supply plug with wet
hands.
• Doingsomaycauseelectricshocks.
Do not do anything that may damage the power
cable. When disconnecting the power cable, pull on
the plug body, not the cable.
• Donotdamagethecable,makeanymodifications
toit,placeheavyobjectsontopofit,heatit,placeit
nearanyhotobjects,twistit,benditexcessivelyor
pullit.Todosomaycausefireandelectricshock.If
thepowercableisdamaged,haveitrepairedatyour
localPanasonicdealer.
Do not remove covers and NEVER modify the
Display yourself
• Donotremovetherearcoveraslivepartsare
accessiblewhenitisremoved.Therearenouser
serviceablepartsinside.(High-voltagecomponents
maycauseseriouselectricalshock.)
• HavetheDisplaychecked,adjusted,orrepairedat
yourlocalPanasonicdealer.
Keep the supplied AAA/R03/UM4 batteries out of
reach of children. If accidentally swallowed, it will be
harmful to the body.
• Pleasecontactadoctorimmediatelyincaseyou
doubtthatthechildmayhaveswallowedit.
If the Display is not going to be used for any
prolonged length of time, unplug the power supply
plug from the wall outlet.
Picture noise may occur if you connect / disconnect
the connection cables of the input terminals you
are currently not watching, or if you turn the power
of the video equipment on / off, but it is not a
malfunction.
To prevent the spread of fire, keep
candles or other open flames away from
this product at all times.
CAUTION
If problems or malfunction occur, stop using
immediately.
■If problems occur, unplug the power supply
plug.
• Smokeoranabnormalodourcomeoutfromtheunit.
• Nopictureappearsornosoundisheard,
occasionally.
• Liquidsuchaswaterorforeignobjectsgotinsidethe
unit.
• Theunithasdeformedorbrokenparts.
If you continue to use the unit in this condition, it
could result in fire or electric shock.
• Turnthepoweroffimmediately,unplugthepower
supplyplugfromthewalloutlet,andthencontactthe
dealerforrepairs.
• TocutoffthepowersupplytothisDisplaycompletely,
youneedtounplugthepowersupplyplugfromthe
walloutlet.
• Repairingtheunityourselfisdangerous,andshall
neverbedone.
• Toenabletounplugthepowersupplyplug
immediately,usethewalloutletwhichyoucanreach
easily.
■When using the LCD Display
Do not bring your hands, face or objects close to the
ventilation holes of the Display.
• Heatedaircomesoutfromtheventilationholesatthe
topofDisplaywillbehot.Donotbringyourhandsor
face,orobjectswhichcannotwithstandheat,closeto
thisport,otherwiseburnsordeformationcouldresult.
At least 2 people are required to carry or unpack
this unit.
• Ifthisisnotobserved,theunitmaydrop,resultingin
injury.
Be sure to disconnect all cables before moving the
Display.
• IftheDisplayismovedwhilesomeofthecablesare
stillconnected,thecablesmaybecomedamaged,
andfireorelectricshockcouldresult.
Disconnect the power supply plug from the wall
socket as a safety precaution before carrying out
any cleaning.
• Electricshockscanresultifthisisnotdone.
Clean the power cable regularly to prevent it
becoming dusty.
• Ifdustbuiltuponthepowercordplug,theresultant
humiditycandamagetheinsulation,whichcould
resultinfire.Pullthepowercordplugoutfromthe
walloutletandwipethemainsleadwithadrycloth.
Do not step on, or hang from the display or the
Pedestal.
• Theymighttipover,ormightbebrokenanditmay
resultininjury.Payspecialattentiontothechildren.

9
English
Do not reverse the polarity (+ and -) of the battery
when inserting.
• Mishandlingthebatterymaycauseitsexplosion
orleakage,resultinginfire,injuryordamageto
surroundingproperties.
• Insertthebatterycorrectlyasinstructed.(seepage
12)
Remove the batteries from the remote control
transmitter when not using for a long period of time.
• Thebatterymayleak,heat,igniteorburst,resultingin
fireordamagetosurroundingproperties.
Do not burn or breakup batteries.
• Batteriesmustnotbeexposedtoexcessiveheatsuch
assunshine,fireorthelike.
Precautions for use
Cautions when installing
Do not set up the Display outdoors.
• TheDisplayisdesignedforindooruse.
Environmental temperature to use this unit
• Whenusingtheunitwhereitisbelow1400m(4593
ft)abovesealevel:0°Cto40°C(32°Fto104°F)
• Whenusingtheunitathighaltitudes(1400m(4593
ft)andhigherandbelow2800m(9186ft)abovesea
level):0°Cto35°C(32°Fto95°F)
Do not install the unit where it is 2 800 m (9 186 ft)
and higher above sea level.
• Failuretodosomayshortenthelifeoftheinternal
partsandresultinmalfunctions.
About space when installing
When using the pedestal (optional accessory), leave
a space of 10 cm (3 15/16”) or more at the top, left and
right, and 5 cm (1 31/32”) or more at the rear, and also
keep the space between the bottom of the display
and the floor surface.
If using some other setting-up method, follow the
manual of it. (If there is no specific indication of
installation dimension in the installation manual,
leave a space of 10 cm (3 15/16”) or more at the top,
bottom, left and right, and 5 cm (1 31/32”) or more at
the rear.)
Minimumdistance:
a
a
ba:10cm
(315/16”)
b:5cm
(131/32”)
a
About the screws used when using a wall hanging
bracket that conforms to VESA standards
Inch
model
Screw pitch for
installation
Depth of
screw hole
Screw
(quantity)
43 200mm×200mm 16mm M6(4)
48 200mm×200mm 16mm M6(4)
55 400mm×400mm 16mm M6(4)
65 400mm×400mm 20mm M8(4)
For43/48/55-inchmodels
Screwholesotherthantheabovehavealsobeen
providedonthisunit,however,thescrewholesinthe
abovetablearerecommended.

English
10
Be careful of the movable structure of the power
indicator and remote control sensor.
• Asfactorydefault,thepowerindicatorandremote
controlsensorarestoredinthemainunit.Fornormal
use,pullouttheremotecontrolsensorfromtheedge
sideofthemainunitbyoperatingtheleveronthe
rearpanel.Dependingonthesetupconditionsuchas
whenusingthemultidisplay,storetheremotecontrol
sensorinthemainunit.(seepage23)
Do not grab the liquid crystal panel.
• Donotforciblypresstheliquidcrystalpanel,orpush
itwithapointedobject.Applyingastrongforceto
theliquidcrystalpanelwillcauseunevennessofthe
screendisplay,resultinginmalfunction.
Depending on the temperature or humidity
conditions, uneven brightness may be observed.
This is not a malfunction.
• Thisunevennesswilldisappearwhileapplyingcurrent
continuously.Ifnot,consultthedistributor.
Cleaning and maintenance
The front of the display panel has been specially
treated. Wipe the surface of the display panel gently
using only a cleaning cloth or a soft, lint-free cloth.
• Ifthesurfaceisparticularlydirty,wipewithasoft,
lint-freeclothwhichhasbeensoakedinpurewateror
waterinwhichneutraldetergenthasbeendiluted100
times,andthenwipeitevenlywithadryclothofthe
sametypeuntilthesurfaceisdry.
• Donotscratchorhitthesurfaceofthepanelwith
fingernailsorotherhardobjects,otherwisethe
surfacemaybecomedamaged.Furthermore,avoid
contactwithvolatilesubstancessuchasinsect
sprays,solventsandthinner,otherwisethequalityof
thesurfacemaybeadverselyaffected.
If the cabinet becomes dirty, wipe it with a soft, dry
cloth.
• Ifthecabinetisparticularlydirty,soaktheclothin
watertowhichasmallamountofneutraldetergent
hasbeenaddedandthenwringtheclothdry.Usethis
clothtowipethecabinet,andthenwipeitdrywitha
drycloth.
• Donotallowanydetergenttocomeintodirectcontact
withthesurfaceoftheDisplay.Ifwaterdropletsget
insidetheunit,operatingproblemsmayresult.
• Avoidcontactwithvolatilesubstancessuchasinsect
sprays,solventsandthinner,otherwisethequalityof
thecabinetsurfacemaybeadverselyaffectedorthe
coatingmaypeeloff.Furthermore,donotleaveitfor
longperiodsincontactwitharticlesmadefromrubber
orPVC.
Usage of a chemical cloth
• Donotuseachemicalclothforthepanelsurface.
• Followtheinstructionsforthechemicalclothtouseit
forthecabinet.
Wired LAN
When setting up the Display at a place, where
electric statistic occurs often, take a sufficient anti-
static measure before start using.
• WhentheDisplayisusedatalocation,where
staticelectricityoccursoften,suchasonacarpet,
communicationsofthewiredLANaredisconnected
moreoften.Inthatcase,removestaticelectricityand
thenoisesourcethatmaycauseproblemswithan
antistaticmat,andre-connectthewiredLAN.
• Inrarecases,theLANconnectionisdisableddue
tostaticelectricityornoise.Inthatcase,turnoffthe
poweroftheDisplayandtheconnecteddevicesonce
andthenre-turnonthepower.ConnecttheLAN.
The Display may not work properly due to strong
radio wave from the broadcast station or the radio.
• Ifthereisanyfacilityorequipment,whichoutputs
strongradiowave,neartheinstallationlocation,set
uptheDisplayatalocationsufficientlyfarfromthe
sourceoftheradiowave.Or,wraptheLANcable
connectedtotheLANterminalbyusingapieceof
metalfoilorametalpipe,ofwhichisgroundedat
bothends.
Disposal
When disposing the product, ask your local
authority or dealer about the correct methods of
disposal.

11
English
Accessories
Accessories Supply
Checkthatyouhavetheaccessoriesanditemsshown
Operating Instructions
(Book)
Operating Instructions
(CD-ROM)
Remote Control Transmitter×1
● N2QAYA000099
Batteries for the Remote
Control Transmitter
(AAA/R03/UM4type×2)
Clamper × 3
For TH-43LFE8U,
TH-48LFE8U,
TH-55LFE8U and
TH-65LFE8U
Warranty card × 1
Power supply cord
TH-43LFE8U,TH-48LFE8U,
TH-55LFE8U
TH-43LFE8E,TH-48LFE8E,
TH-55LFE8E
TH-65LFE8U
TH-65LFE8E
Attention
● Storesmallpartsinanappropriatemanner,andkeep
themawayfromyoungchildren.
● Incaseyoulostaccessories,pleaseconsultyour
dealer.
● Disposethepackagingmaterialsappropriatelyafter
takingouttheitems.

English
12
Remote Control Batteries
1.Pullandholdthehook,thenopenthebatterycover.
2.Insertbatteries-notecorrectpolarity(+and-).
AAA/R03/UM4type
3.Replacethecover.
Helpful Hint
● Forfrequentremotecontrolusers,replaceold
batterieswithAlkalinebatteriesforlongerlife.
Precaution on battery use
Incorrectinstallationcancausebatteryleakage
andcorrosionthatwilldamagetheremotecontrol
transmitter.
Disposalofbatteriesshouldbeinanenvironment-
friendlymanner.
Observe the following precaution:
1.Batteriesshallalwaysbereplacedasapair.Always
usenewbatterieswhenreplacingtheoldset.
2.Donotcombineausedbatterywithanewone.
3.Donotmixbatterytypes(example:“ZincCarbon”with
“Alkaline”).
4.Donotattempttocharge,short-circuit,disassemble,
heatorburnusedbatteries.
5.Batteryreplacementisnecessarywhenremote
controlactssporadicallyorstopsoperatingthe
Displayset.
6.Donotburnorbreakupbatteries.
7.Batteriesmustnotbeexposedtoexcessiveheatsuch
assunshine,fireorthelike.
Kensington security
ThissecurityslotiscompatiblewiththeKensington
securitycables.
43-inch model
48-inch model
55-inch model
65-inch model

13
English
Connections
AC cord connection and fixing
43/48/55-inch models
Back of the unit
Insert the AC cord securely all the way seated on
the back side of the unit.
Class II equipment.
65-inch model
● The AC cord for the 65-inch model has a 3-pin plug
with earth.
Back of the unit
AC cord fixing
AC cord (supplied)
Plug the connector into the display unit.
Plug the AC cord until it clicks.
Note
● Make sure that the AC cord is locked on both the
left and right sides.
Unplug the AC cord
Unplug the connector pressing the two knobs.
Note
● When disconnecting the AC cord, be absolutely
sure to disconnect the AC cord plug at the socket
outlet first.
● The supplied AC cord set is for this unit exclusive
use. Do not use this for other purposes.
AC cord (supplied)
Insert the plug until the line is hidden.

English
14
Cable fixing
Note
● 3 clampers are supplied with this unit. Fix the cables
at 3 locations using the holes of clampers as shown
below.
If you need more clampers, purchase them from your
dealer. (Available from the customer service)
Keep pushing both
side snaps
hole
1. Attach the clamper
Insert the clamper in a
hole.
To remove from the
unit:
snaps
Keep pushing the
knob
hooks
2. Bundle the cables
Set the tip in the hooks
To loosen:
knob

15
English
Video equipment connection
1 AV IN (VIDEO): Composite Video Input Terminal
Connect to video equipment such as
VCR or DVD player, etc.
(see page 19)
2 PC IN: PC Input Terminal
Connect to video terminal of PC,
video equipment with “Y, PB(CB),
PR(CR)” or “R, G, B” output.
(see page 18)
3 AV IN
(HDMI 1,
HDMI 2):
HDMI Input Terminal
Connect to video equipment such as
VCR or DVD player, etc.
(see page 16)
4 DVI-D IN: DVI-D Input Terminal
Connect to video equipment with
DVI-D output.
(see page 17)
5 SERIAL IN: Serial Control Terminal
Control the Display by connecting
to PC.
(see page 19)
6 LAN: LAN Terminal
Control the Display by connecting to
Network.
(see page 64)
7 USB: USB Memory Terminal
Connect the USB memory to use
the USB media player function. Also,
this can be used to supply power of
up to 5V/1A to an external device
when receiving images.
(see page 22,31)
8 IR IN, IR OUT: Infrared Signal Input/output
Terminal
Use this when operating more than
one display with one remote control.
(see page 21)
9 AUDIO IN: Audio input terminal shared with
DVI-D IN and PC IN
(see page 17,18)
10 AUDIO OUT: Analogue Audio Output Terminal
Connect to audio equipment with
analogue audio input terminal.
(see page 21)
Note
● Depending on the outer shape of the plug of a
connection cable, it may come in contact with the plug
of an adjacent connection cable or the periphery such
as a back cover. Use a connection cable with the
suitable plug size for the terminal alignment.
● Due to the terminal block construction, some
connection cables and USB memory devices cannot
be used. Be sure to check the “CONNECTION
TERMINAL” information in the product specification
sheet. For the information about product
specifications, visit the following web site. http://
panasonic.net/prodisplays/download/specsheets02.
html

English
16
HDMI 1 and 2 terminals connection
Note
● Additional equipment and HDMI cable shown are not
supplied with this set.
● Some HDMI equipment may not be able to display
picture.
HDMI cable (not supplied)
Video Cassette Recorder
DVD Player
Pin assignments and signal names for HDMI
Terminal
Pin No. Signal name
T.M.D.S Data2+
T.M.D.S Data2 Shield
T.M.D.S Data2-
T.M.D.S Data1+
T.M.D.S Data1 Shield
T.M.D.S Data1-
T.M.D.S Data0+
T.M.D.S Data0 Shield
T.M.D.S Data0-
T.M.D.S Clock+
T.M.D.S Clock Shield
T.M.D.S Clock-
CEC
SCL
SDA
DDC/CEC Ground
+5V DC
Hot Plug Detect

17
English
DVI-D IN terminal connection
Note
● Additional equipment and cables shown are not
supplied with this set.
● Use the DVI-D cable complying with the DVI
standard. Image deterioration may occur depending
on the length or the quality of the cable.
Shared with PC IN.
DVI-D video cable (Within 5 m) (not supplied)
Stereo mini plug (M3) cable (not supplied)
PC with DVI-D video out
Pin assignments and signal names for DVI-D
Input Connector
Pin No. Signal Name
T.M.D.S. data 2-
T.M.D.S. data 2+
T.M.D.S. data 2 shield
DDC clock
DDC data
T.M.D.S. data 1-
T.M.D.S. data 1+
T.M.D.S. data 1 shield
+5 V DC
GND (Ground)
Hot plug detect
T.M.D.S. data 0-
T.M.D.S. data 0+
T.M.D.S. data 0 shield
T.M.D.S. clock shield
T.M.D.S. clock+
T.M.D.S. clock-

English
18
PC IN terminal connection
Connect a cable
which matches
the audio output
terminal on the
computer.
(not supplied)
(Male)
(Female)
Shared with DVI-D IN.
Mini D-sub 15p (not supplied)
Conversion adapter (if necessary) (not supplied)
Stereo mini plug (M3) cable (not supplied)
COMPUTER
The type of computer signal that can be connected
● With regard to the typical PC input signals that
are described in “Preset Signals” (see page 75),
adjustment values such as for the standard picture
positions and sizes have already been stored in this
unit. You can add up to eight PC input signal types that
are not included in the list.
● Computer signals which can be input are those with
a horizontal scanning frequency of 30 to 110 kHz and
vertical scanning frequency of 48 to 120 Hz.
● The display resolution is a maximum of 1 440 × 1 080
dots when the aspect mode is set to [4:3], and 1 920
× 1 080 dots when the aspect mode is set to [16:9].
If the display resolution exceeds these maximums, it
may not be possible to show fine detail with sufficient
clarity.
● In [ENGLISH(US)] OSD language, [16:9] is displayed
as [FULL].
Note
● The PC IN terminal is DDC2B-compatible. If the
computer being connected is not DDC2B-compatible,
you will need to make setting changes to the computer
at the time of connection.
● Some PC models cannot be connected to the set.
● There is no need to use an adapter for computers with
DOS/V compatible Mini D-sub 15P terminal.
● The computer shown in the illustration is for example
purposes only.
● Additional computer, cables and conversion adapter
shown are not supplied with this set.
● Do not set the horizontal and vertical scanning
frequencies for PC signals which are above or below
the specified frequency range.
● Component Input is possible with the pin 1, 2, 3 of the
Mini D-sub 15P Connector.
● Change the [Component/RGB-in select] setting in
the [Signal] menu to [Component] (when Component
signal connection) or [RGB] (when RGB signal
connection). (see page 48)
Pin assignments and signal names for PC Input
Terminal (Mini D-sub 15P)
1
678
3
9
45
10
15 14 13 12 11
2
Pin No. Signal Name
R (PR/CR)
G (Y)
B (PB/CB)
NC (not connected)
GND (Ground)
GND (Ground)
GND (Ground)
GND (Ground)
+5 V DC
GND (Ground)
NC (not connected)
SDA
HD/SYNC
VD
SCL

19
English
VIDEO terminal connection
Note
● Video equipment, connection cables and conversion
plugs are not supplied with this unit.
Yellow
White
Red
4-pole mini plug conversion cable (commercially
available)
Audio video pin cable
Video Cassette Recorder
DVD Player
Wiring specifications for 4-pole mini plug
Note
● Use a 4-pole mini plug (M3) with the following
wiring specifications for the VIDEO terminal
of this unit. If the wiring of a plug is different,
audio and video are not correctly input.
1
3
4
2
Audio L (White)
Video (Yellow)
GND (Ground)
Audio R (Red)
SERIAL terminal connection
The SERIAL terminal conforms to the RS-232C interface
specification, so that the Display can be controlled by a
computer which is connected to this terminal.
(Male)
(Female)
(D-sub 9p)
RS-232C Straight cable (not supplied)
COMPUTER, etc.
Note
● Use the RS-232C straight cable to connect the
computer to the Display.
● The computer shown is for example purposes only.
● Additional computer and cables shown are not
supplied with this set.
The computer will require software which allows the
sending and receiving of control data which satisfies
the conditions given below. Use a computer application
such as programming language software. Refer to the
documentation for the computer application for details.

English
20
Pin assignments and signal names for SERIAL
Terminal
6 7 8 9
1 3 4 52
Pin No. Signal Name
NC (not connected)
RXD
TXD
Non use
GND (Ground)
Non use
RTS Shorted in this set
CTS
NC (not connected)
These signal names are those of computer
specifications.
Communication parameters
Signal level: RS-232C compliant
Synchronization method: Asynchronous
Baud rate: 9600 bps
Parity: None
Character length: 8 bits
Stop bit: 1 bit
Flow control: None
Basic format for control data
The transmission of control data from the computer
starts with a STX signal, followed by the command, the
parameters, and lastly an ETX signal in that order. If
there are no parameters, then the parameter signal does
not need to be sent.
STX C1 C2 C3 P1 P2 P3 P4: P5 ETX
Start
(02h)
3-character command
(3 bytes)
Colon
Parameter(s)
End
(03h)
Command
Command Parameter Control details
PON None Power ON
POF None Power OFF
AVL *** Volume 000 - 100
AMT 0 Audio MUTE OFF
1 Audio MUTE ON
IMS None Input select (toggle)
HM1 HDMI 1 input
(HDMI1)
HM2 HDMI 2 input
(HDMI2)
DV1 DVI-D IN input
(DVI-D)
PC1 PC IN input (PC)
VD1 VIDEO input
(VIDEO)
UD1 USB input (USB)
Note
● If multiple commands are transmitted, be sure to wait
for the response for the first command to come from
this unit before sending the next command.
● If an incorrect command is sent by mistake, this
unit will send an “ER401” command back to the
computer.
● In Standby condition (power OFF with remote
control), the unit responds to PON command only.
● Consult your local Panasonic dealer for detail
instructions on command usage.
