Panasonic Viera TC-42P1 User manual

ã 2000 Matsushita Electric Industrial Co.,Ltd.
All right reserved.Unauthorized copying and
distribution is a violation of law. 
ORDER NO.ITD0001001C0
B2
Wide Plasma Display
TC-42P1 TC-37P1
TC-42P1F TC-37P1F
TC-42PD1 TC-37PD1
TC-42PD1F TC-37PD1F
PT-42P1 PT-37P1
PT-42PD1
TC-42P1FA
TC-42PD1FA GP2D Chassis
Connection terminals:
AV VIDEO IN (BNC) 1.0V p-p (75
S-VIDEO IN Y: 1V p-p (75),
(Mini DIN 4-pin) C: 0.286V p-p (75)
AUDIO IN L-R 0.5Vrms (RCA pin jack x 2)
VIDEO OUT (BNC) 1.0V p-p (75) (bridge output)
COMPONENT Y/G1.0V p-p
/RGB (including synchronization)
PB/B ±0.35V p-p
PR/R ±0.35V p-p
HD ±1.0-5.0V p-p
VD ±1.0-5.0V p-p
AUDIO IN L-R 0.5Vrms
(RCA pin jack x 2)
PC VIDEO (High-density D-sub 15pin)
AUDIO0.5Vrms (3mm mini jack)
SPEAKERS For TY-SP42PD1E. (For 42 inch model only)
(8) For TY-SP37PD1E. (For 37 inch model only)
SERIAL External control terminal
TUNER
REMOTE
Dimensions (W x D x H):
42 inch model 37 inch model
1030mm x 633.5mm x 89mm 930mm x 573.5mm x 89mm
Weight (Mass):
42 inch model 37 inch model
33.0kg net (main unit only) 27.5kg net (main unit only)
36.4kg (with speakers) 30.7kg (with speakers)
Note:
Design and Specifications are subject to change without notice.
Weight and Dimensions shown are approximate.
Specifications
Power Source:
PT models:120V AC, 50/ 60Hz
TC models: 220-240V AC, 50/60 Hz
Power Consumption:
42 inch model 37 inch model
380W 290W
Stand-by condition: 1.7W Standby-condition:1.7W
Power off condition: 0.7W Power off condition: 0.7W
Plasma Display panel:
42 inch model 37 inch model
42-inch, 16:9 AC type 37-inch, 16:9 AC type
Screen size:
42 inch model
920mm(W) x518mm(H) x1056mm(diagonal)
No. of pixels
408,960(852 (W) x 480 (H)) [2,556 x 480 dots]
37 inch model
818mm(W) x461mm(H) x939mm(diagonal)
No. of pixels
408,960(852 (W) x 480 (H)) [2,556 x 480 dots]
Operating conditions:
Temperature:0-40C
Humidity: 20%-80%
Applicable signals
Colour System: NTSC, PAL, PAL-60,SECAM
Scanning format: 525i, 525p, 625i, 625p, 1080i
PC signals: VGA, S-VGA (compressed), Horizontal scanning fre-
quency 15.6-50 kHz

- 2 -

❑ 
❑  
❑ 
❑ !"#!#  $
❑  %&
❑'  %$
❑#(#!  %$
❑))!*  &%
❑+#,  &&
❑!#  &-
❑!#./  &-
❑01+! &-
❑%1+! &
❑1+! 2
❑31+! 2
❑41+! 2
❑-1+! 2
❑1+! 2
❑51+! 
❑&1+!  
❑1+!  
❑1+!  -
❑1+!  6%
❑1+!  63
❑1+!  6$
❑&1+!76&8  6$
❑1+!76&8  6$
❑61+!7-8  6$
❑31+!7-8  6$
❑91+!7-8  3&
❑1+!7-8  3&
❑91+!76&8  36
❑1+!76&8  36
❑%1+! 33
❑%1+! 33
❑&1+! 33
❑%1+!7-8  34
❑&1+!7-8  34
❑1+!7-8  34
❑61+!7-8  34
❑%1+!76&8  3
❑&1+!76&8  3
❑1+!76&8  3
❑61+!76&8  3
❑+'! 42
❑5&+' 42
❑:  4%
❑4%
❑/70;%;;3;4;-!+!8+'4&
❑%1+! 4
❑1+! 46
❑31+! 43
❑01+! 43
❑41+! 44
❑-1+! 44
❑1+! 4-
❑&1+! 4-
❑5+!+' 4
❑ #!7&;6;5!&+!8+' 4$
❑51+! -2
❑61+!-
❑&1+!-6
❑%1+! -6
❑%1+! -6
❑+!+'-3
❑1+! -4
❑+!+' -
❑1+!-$
❑%;&;!6+!+' $&
❑%1+!76&8$
❑&1+!76&8$6
❑1+!76&8$3
❑61+!76&8$4
❑%1+!7-8$-
❑&1+!7-8$
❑1+!7-8$$
❑61+!7-8%22
❑+!+'%2%
❑1+! %2&
❑9!+' %26
❑1+!76&8 %23
❑1+!7-8 %24
❑91+!76&8 %2-
❑91+!7-8 %2
❑+!+'%2$
❑1+! %%2
❑&1+! %%2
❑1+! %%2
❑61+! %%2
❑31+! %%2
❑* %%%
❑)  %%&
❑<) %%6
❑) %%3

- 3 -
Plasma Display Technology
Plasma display panel
FIg. A
Panasonic 37/42 inch wide plasma display panel is devel-
oped for large screen multimedia display with space saving.
The plasma display panel use AC type Sub-field drive sys-
tem with Dual scanning system.
This panel have also Panasonic original Asymmetric cell and
Plasma AI technology.
Fig. A is the CRT and Plasma Display Panel (PDP) compari-
son chart.
Plasma display panel structure
Fig. B
Plasma display panel structure.
Panasonic Plasma display panel is consist of front glass,
rear glass and Aluminum base.
The front glass has each 480 lines scan and sustain trans-
parence electrodes.
The rear glass has 2556 (852 x 3 ) data electrodes on the
inner surface. These electrodes are connected to the data
drive circuit boards directly.
Rear Glass Structure
Fig. C
On the rear glass the data electrode is mounted.
The dielectric is coated on the rear glass.
Red, Green and Blue color phosphors are formed on the
data electrode with the ribs. However to improve color repro-
duction and brightness, each color phosphors are formed dif-
ferent width This is called " Asymmetrical cell " as Panasonic
original technology.
Front Glass Structure
Fig. D
On the front glass scan and sustain transparent electrodes
are mounted in pair.
The dielectrics is coated on the front grass.
MgO over coat is also applied on the dielectrics.
The front and rear glasses are piled and sealed . And low
presser gas are charged between two glasses.
CRT PDP
Scan Dot Sequence Line Sequence
Interlace/
Progressive Progressive
Emission Dot Sequence Simultaneous
Phosphor
Excitation Electron Ultra Violet Lay
Brightness
Control Beam Current control Discharge Time control
(Sub-Filed Drive)
;;;;;;;;
;
;;;;;;
;
;
;;;;;;
;
;
;;;;;;
;
;;;;;;;;
yyyyyyyy
y
yyyyyy
y
y
yyyyyy
y
y
yyyyyy
y
yyyyyyyy
;;;;;;;;;
;
;;;;;;;
;
;
;;;;;;;
;
;
;;;;;;;
;
;
;;;;;;;
;
;;;;;;;;;
yyyyyyyyy
y
yyyyyyy
y
y
yyyyyyy
y
y
yyyyyyy
y
y
yyyyyyy
y
yyyyyyyyy
Data Drive Boards
Data Drive Boards
Aluminum Base
Rear Glass
Front Glass
Dielectrics
Color Phosphor
Asymmetrical Cell
Data Electrodes Rear Glass Rib
MgO
Scan & Sustain
Electrodes
Dielectrics
Front Glass

- 4 -
Pixel Structure
Fig. E
37/42 inch plasma display panel has 1,226,880 pixels.
Each pixels structure is shown fig. E.
Sub Field Drive system
Fig. F
Brightness control of plasma display panel is carried out by
plasma discharge time change. To control each pixel’s bright-
ness Sub-field drive system is used.
A sub-field is consist of Initialize, Write and sustain opera-
tion.
Initialization
Fig. G
To clear any remaining electric charge into the pixel, trape-
zoid voltage is applied between the scan and sustain elec-
trodes.
Plasma discharge is started but the discharge become small
gradually.
Then any electric charge is cleared.
Write
Fig. H
Data Pulse which is positive polarity is input to data electrode
and Scan pulse which is negative polarity is input to scan
electrode simultaneously.
That means sum of data and scan pulses voltage is applied
between two electrodes as discharge start voltage.
Discharge is started into the pixel and gas is ionized.
During discharging ion is charged on the scan electrode side
and electron is charged on data electrode side.
Scan Electrode
Sustain Electrode
Xenon
+
Neon
Data Electrode
Color Phosphor Rib
Rib
Dielectrics
Rear Glass Front Glass
Aluminum
Base
Address
Period Sustain Period
Sub Field
Initialize Write Sustain
VI
+++l l l
+ Ions
- Electrons
Data Pulse
Scan Pulse
| | | | |
+++++
| | | | |
+++++

- 5 -
Wall Voltage
Fig. I
when input pulses are stopped, Ions and Electrons which are
charged on the dielectric around the electrodes are
remained.
This charge is called Wall Voltage (Pilot voltage).
This operation is called Write .
Sustain Step 1
Fig. J
Negative polarity’s Sustain pulse is input between sustain
and scan electrodes and voltage potential between two elec-
trodes becomes sum of Sustain pulse and wall voltage.
Then discharge start.
Sustain Step 2
Fig. K
When sustain pulse is stopped, Ions and Electrons are
remained again as Wall voltage. However polarity of wall volt-
age is reversed.
Sustain Step 3
Fig. L
Positive polarity’s Sustain pulse is input between sustain and
scan electrodes and discharge start again.
++++
Vw
| | | |
++++
+++
| | | |
| | |
Vs
Vs + Vw
+++
| | |
+++
| | |
+++
| | |
Vs
Vs + Vw

- 6 -
Sustain Step 4
Fig. M
When sustain pulse is stopped, Ions and Electrons are
remained again as Wall voltage. However polarity of wall volt-
age is reversed.
Sustain Step 5
Fig. N
Ions and Electrons which is generated by 2nd sustain dis-
charge are charged on the pixel wall (dielectric) around the
electrodes.
Repeat Step 1 to Step 5
Fig. O
To keep discharge continuously step 1 to 5 operation will be
repeated.
As the result sustain pulse is alternated. Therefore we call
this drive system AC Drive type.
If sustain operation is repeated longer, brightness level of
the pixel is increased. Therefore depend on sustain dis-
charge time brightness of pixel is controlled.
Sub-Field drive
Fig. P
Sub-Field drive is PDP unique system.
While one TV field period, 8 bits digital video signal compo-
nent is reproduced by 8 sub-fields operation.
Each Sub-Field’s address period are all same.(Consist of
one initialization and 480 scanning operation.)
But Sustain period of each Sub-Field are different.
1st Sub-Field (SF) reproduce only 1 step brightness.
2nd SF reproduce 2 steps brightness.
Each sub-field’s sustain period are increased gradually.
However total 256 brightness difference can be reproduced
on the screen.
+++ | | | +++ | | |
+++ | | |
Vs
Sustain Cycle
AC Drive Type Plasma Display
Sustain Pulse
Address Period
8 Sub Fields
1 TV Field
1 2 4 8 16 32 84 128
=
1st 2nd 3nd 4th 5th 6th 7th 8th
Sustain Period

- 7 -
Dual Scan
Fig. Q
The sustain period of sub-field drive system. Therefore
brightness peak is limited. Because 480 horizontal lines
scanning is carried out during address period.
Dual scan system can reduce scanning time from 480 to 240
in the address period.
Then spaced time by dual scanning can be used for sustain
operation.
As the result Brightness peak level can be increased.
Plasma AI (Adaptive brightness Intensi-
fier)
Fig. R
Panasonic plasma AI control sub-field drive operation which
is called Multi-Sprit Sub-Field drive control system is used.
Depend on the picture contents ( APL : Average Picture
Level ) number of sub-field are changed from 10 to 12. (Vari-
able Sub-field)
Sustain time format of each sub-field are also rearranged
from binary format to linear cording sustain time. (Linear cod-
ing sub-field)
Plasma AI select the best display condition for Plasma dis-
play panel to display natural and crisp picture.
240240
480
852
Multi Sprit Sub-Field Drive System
1. Linear coding Sub-Field
2. Variable Sub-Field
+
•Increase Peak Brightness in Dark scenes
•Reduce Motion Picture Disturbance
•Keep Reasonable Power Consumption

- 8 -
Service Hint
Board name Function Board name Function
DS module I/P Converter V1 board Front Switch
HG board Interface S1 board Power Switch & Remote Receiver
D board Digital process & Control S2 board Factory use
P1 board Power supply P3 board Sustain voltage control
SC board Scan drive P5 board Processing voltage control
SS board Sustain Drive P6 board Prinaly voltage control
C1 board Data drive (Upper Left) P7 board Sustain voltage protection
C2 board Data drive (Upper Right) P8 board Processing voltage protection
C3 board Data drive (Lower Right) H2 board PC input terminal
C4 board Data drive (Lower Left) F board Line filter
SU board Scan out (Upper) H3 board Speaker terminal
SD board Scan out (Lower) SS2 board Sustain connection (Upper)
SS4 board Sustain connection (Upper) SS3 board Sustain connection (Lower)
SS5 board Sustain connection (Lower)
Remove: 8 screws (1)
14 screws (2)
9 screws (3)
4 screws (4)
C1
SU
C2
C4 C3
F
SD
SC P1 SS
SS2 (42 inch)
SS4 (37 inch)
HG
D
H2
H3
DS
V1 S1S2
P8
P5
P6
P7
P3
SS3 (42 inch)
SS5 (37 inch)
screw(1)
(30mm) Back Cover
Stand the Unit used for Optional Accessory
Remove the Back Cover
Service Position
Optional Accessory
(Pedestal)
screw(4)
(20mm)
screw(2)
(17mm)
screw(3)
(8mm)
(Front) (Front)(Front)

- 9 -
Adjustment Procedure
Item / Preparation
+B Set-Up
1. Confirm the main voltage set switch
is set to 110V (PT models)/ 230V (TC models)
Note: 230V covers input AC voltage from 200V till 265V, and 110V covers from 90V till 130V.
2. Input a Grey scale signal.
3. Set the picture controls: -
Picture mode Normal
White balance Normal
Driver Set-Up
4. Input an APL 100 % white signal.
5. Set the picture controls: -
Picture mode Normal
White balance Normal
Adjust and confirm indicated test point for the specified voltage
Test Point Voltage Volume Name
P4 pin 1 (Hot) 400 V ± 1 V R548 PFC
P1 pin 10 15 V ± 0.5 V +15 V
P5 pin 1 13 V ± 0.5 V +13 V
P6 pin 1 13 V ± 0.5 V Audio 13 V
P6 pin 3 -13 V ± 0.5 V Audio -13 V
P5 pin 5 5 V ± 0.5 V +5 V
P5 pin 8 3.4 V ± 0.5 V +3.3 V
P7 pin 1 14 V ± 1 V STB 14V
P7 pin 6 5 V ± 0.5 V STB 5 V
Adjustments
230 V 110 V
P6 board
Adjust driver section voltages referring panel data on the panel data label.
Test point Voltage Volume Name
TPDA1(C1) 75 V ± 0.5 V R528(P1) VDA
TPVSUS(SS) VSUS ± 1 V R639(P3) VSUS
TPVSET(SC) VSET ± 1 V R6587(SC) VSET
TPVSCN(SC) 80 V ± 0.5 V R6597(SC) VSCN
TPVE(SS) VSUS + VE± 0.5 V R494(P1) VE
P5 pin3 3 V ± 0.2 V R541 ABL
Confirmation (cold)

- 10 -
Adjustment Volume Location
Test Point Location
R6565
R6501 R6597 R6587 R6754230V/110V Switch
R541 R528
R494R639R6654
Panel Data Label
P4
TPDA3 TPDA1 TPDA2 TPDA5 TPDA4 TPDA6 TPVSUS TPVE
TPSC1 TPSCN TPSET TPSS2 TPSS1
TP216
TP295
TP294
TP293

- 11 -
Sustain Pulse Adjust
1. Input a Cross hatch signal.
2. Set the picture controls: -
Picture mode Normal
White balance Normal
Initialization Pulse Adjust
1. Input a Cross hatch signal.
2. Set the picture controls: -
Picture mode Normal
White balance Normal
Confirm the indicated test point for the specified wave form.
Adjust the angle of the erase pulse.
Adjust the indicated test point for the specified wave form.
Test Point Volume Name
TPSS1(SS) Sustain Pulse
Test Point Volume Name
TPSS1(SS) R6754(SS) Erase Pulse
Test Point Volume Name
TPSC1 (SC) R6565(SC) Initialize Pulse
TPSC1 (SC) R6654(SC) Initialize Pulse
2.6 sec.
1.6 sec.
185 V
5 ± 3 sec.
205 ± 5 V
15 ± 5 sec.(R6565)
75 V
30 ± 10 sec.(R6654)

- 12 -
Alignment Setting
How to access Alignment
1) Press and hold the volume down / - button on the front panel of the unit and press the Recall (PT models)/ Status (TC
models) [ ] button on the remote control 3 times quickly within 1 second, this will place the unit into the CAT menu
(Main service mode).
2) Press the ACTION (PT models)/ STR (TC models) button on the remote control.
3) Select the alignment Subject by the UP or DOWN button of the Cross buttons on the remote control.
4) Select the alignment item by the LEFT or RIGHT buttons of the Cross buttons on the remote control.
5) Adjust optimum setting by Volume Up / + and Down / - buttons.
(The reference figures below are normal and used for representative purpose only.)
Exit
6) To exit the IIC mode, press the menu button on the remote control.
To exit the CAT mode, access the ID mode by the down button of cross buttons and switch off the main power and
on again.
CAT
0
IIC
CD
IT
SD
OSD
ID
Mode
sys8.0
Mode
Mode
Mode
On/Off
Mode
INPUT - +
+
PAL : JUST Mid
Video signal adj.
R Cutoff
10 10
Subject
Items
New data
Original data

- 13 -
IIC menu structure
Subject Item
Access
Button UP/Down of Cross buttons Left/Right of Cross buttons
Video signal adj. Sub Brightness R Cutoff B Cutoff
G Drive
G Cutoff B Drive
R Drive
Chroma Control R-Y Axis Angle R-Y Axis Gain
Sub Color
DS contrast Sub Contrast
SG Hold
Sub Tint
Pos./Size H Position V Position
V Size H Size
Panel APL/ABL APL Shift Level ABL Point
ABL Bank select ABL Gain
Sub Contrast
Panel W/B Brightness R Cutoff B Cutoff
Contrast
Aging Panel Color
0:White 1:Blue 2:Green 3:Red
0 : Other 1 : NTSC 2 : PAL
3 : SECAM 4 : 525i 5 : 625i
6 : 525p 7 : HD 8 : ......Not used
Scroll Bar
R Drive B Drive
Volume +/-

- 14 -
Alignment (The reference figures below are normal and used for representative purpose only.)
DS contrast
1) Input 1 Vp-p NTSC (PT models)/ PAL (TC models) color bar signal into the Video in terminal.
2) Access the DS contrast mode and align as follow.
Video signal setting
1) Input 1Vp-p NTSC (PT models)/ PAL (TC models) color bar signal into the Video in terminal.
2) Set Picture mode to Normal mode and Manual W/B to Cool position.
3) Access the Video signal Adj. Mode and set each Item as follow.
4) Record the setting data of Sub contrast, R Drive and B Drive.
5) Access the SG Hold mode (Forced signal system set mode) and set the system to NTSC (PT models)/ PAL (TC models).
6) Return to the Video signal adj. mode and copy the Data 1 for each item.
7) Repeat item 5) and 6) for SECAM, 525i, 625i and 525p system.
Chroma Control
1) Access the Chroma Control Mode and set each Item as follow.
2) Record the setting data of Sub Tint and Sub Color.
3) Access the SG Hold mode (Forced signal system set mode) and set the system to NTSC (PT models)/ PAL (TC models).
4) Return to the Chroma Control mode and copy the Data 2 for each item.
5) Repeat item 3) and 4) for SECAM and 525i system.
(Sub color data for SECAM system should be reduced 5 steps from data 2.)
Alignment Item Reference Setting/Special feature
Sub Contrast 66 0.7V pedestal-peak on TP216.
Alignment Item Reference Setting /Special feature
Sub Brightness 80 Fixed data
R Cutoff 40 Fixed data
B Cutoff 40 Fixed data
Sub Contrast 63 Set the signal on TP294 to 0.7V pedestal-peak.
R Drive 71 Set the signal on TP293 to 0.7V pedestal-peak.
B Drive 71 Set the signal on TP295 to 0.7V pedestal-peak.
G Cutoff 80 Fixed data
G Drive 20 Fixed data
Sub Contrast R Drive B Drive
Alignment Item Reference Setting/Special feature
R-Y Axis Angle E Fixed data
R-Y Axis Gain 2E Fixed data
Sub Tint 47 Optimum setting
Sub Color 30 Optimum setting
Sub Tint Sub Color
**Data 2
**Data 1

- 15 -
Panel W/B (PD1 models only)
Composite/Component signals
1) Change to the AV input mode and input the NTSC (PT models)/ PAL (TC models) white pattern signal.
2) Set the manual W/B to Cool by the Menu button.
3) Access the Panel W/B mode and align the white balance (Slightly bluish white)
4) Change the Manual W/B to Normal by the Menu button, and set the white balance data by Increasing the R Drive data 24
steps and reducing the B drive data 2 steps, B Cutoff 1 step from Cool mode data.
5) Change the Manual W/B to Warm by the Menu button, and set the white balance data by Increasing the R Drive data 30
steps and reducing the B drive data 35 steps, B cutoff 2 step from Cool mode data.
6) Access the SG Hold mode (Forced signal system set mode) and set the system to NTSC (PT models)/ PAL (TC models).
7) Return to the Panel W/B mode and copy the Data 3 for each item.
8) Repeat item 6) and 7) for 525i, 625i and SECAM system.
PC/RGB signal
1) Change to the PC input mode and input the PC signal.
2) Set the manual W/B to Cool by the Menu button.
3) Access the Panel W/B mode and align the white balance (Slightly bluish white).
4) Change the Manual W/B to Normal by the Menu button, and set the white balance data by Increasing the R Drive data 34
steps and reducing the B drive data 2 steps from Cool mode.
5) Change the Manual W/B to Warm by the Menu button, and set the white balance data by Increasing the R Drive data 47
steps and reducing the B drive data 31 steps, R cutoff and B cutoff 1 step from Cool mode.}
Pos./Size setting
1) Receive the test pattern signal which can be found the center and edge position and align properly.
Alignment Item Reference Cool (Hi) Setting/Special feature
Brightness 71 Optimum setting
R Cutoff 8F Optimum setting
B Cutoff 87 Optimum setting
B Drive 82 Optimum setting
R Drive 64 Optimum setting
Contrast 84 Optimum setting
Manual W/B R Cutoff B Cutoff B Drive R Drive
Cool (High)
Normal (Mid)
Warm (Low)
Reference Cool (Hi) Setting/Special feature
Brightness 66 Optimum setting
R Cutoff 91 Optimum setting
B Cutoff 85 Optimum setting
B Drive 6A Optimum setting
R Drive 74 Optimum setting
Contrast 84 Optimum setting
Alignment Item Reference Setting /Special feature
H Position 9A Optimum setting
V Position C3 Optimum setting
H Size A8 Optimum setting
V Size 5E Optimum setting

- 16 -
Panel W/B (P1 models only)
Composite/Component signal
1) Set the AV mode and input the white pattern signal from NTSC (PT models)/ PAL (TC models) signal generator.
2) Press the Menu button twice to access main menu and set the manual W/B to Cool.
3) Access the Panel W/B mode and align the Low Light and High Light shown below by using color meter.
4) Record R Cutoff, B Cutoff, R Drive and B Drive setting data.(***Data 3)
5) Change the Manual W/B to Normal by the Menu button and ACTION (PT models)/ STR (TC models) button.
6) Modify the Data as follows.
Increase R Drive 24 steps and reduce B drive 2 steps and B cutoff 1 step from Cool mode.
7) Change the Manual W/B to Warm by the Menu button and ACTION (PT models)/ STR (TC models) button.
8) Modify the Data as follows.
Increase R Drive 30 steps and reduce B drive 35 steps, and B cutoff 2 steps from Cool mode.
9) Access the SG Hold mode (Forced signal system set mode) and set the system to NTSC (PT models)/ PAL (TC models).
10) Return to the Panel W/B mode and copy the Data 3 for each item.
11) Repeat item 9) and 10) for SECAM system.
Equipment NTSC (PT models)/ PAL (TC models) signal generator Color meter
xy
Cool (High) 0.272 0.290
Normal (Mid) 0.288 0.296
Warm (Low) 0.313 0.329
Alignment Item Reference Cool (Hi) Setting/Special feature
Brightness 71 10cd/m2by 15% signal level (Set by generator)
R Cutoff 7F Set to 15% signal level by the generator.
B Cutoff 7D Set 15% signal level by the generator.
B Drive 75 Set 75% signal level by the generator.
R Drive 62 Set 75% signal level by the generator.
Contrast 84 Optimum setting
Manual W/B R Cutoff B Cutoff B Drive R Drive
Cool (High)
Normal (Mid)
Warm (Low)

- 17 -
PC / RGB signal (P1 models only)
1) Set the PC mode and input the white pattern signal from RGB signal generator.
2) Press the Menu button twice to access main menu and set the manual W/B to Cool.
3) Access the Panel W/B mode and align the Low Light and High Light shown below by using color meter.
4) Record R Cutoff, B Cutoff, R Drive and B Drive setting data.(***Data 5)
5) Change the Manual W/B to Normal by the Menu button and ACTION (PT models)/ STR (TC models) button.
6) Modify the Data as follows.
Increase R Drive 34 steps and reduce B drive 2 steps from Cool mode.
7) Change the Manual W/B to Warm by the Menu button and ACTION (PT models)/ STR (TC models) button.
8) Modify the Data as follows.
Increase R Drive 47 steps and reduce B drive 31 steps, and R cutoff and B cutoff 1 steps from Cool mode.
Pos./Size setting (P1 models only)
1) Receive the test pattern signal which can be found the center and edge position and align properly.
Equipment RGB signal generator Color meter
xy
Cool (High) 0.272 0.290
Normal (Mid) 0.288 0.296
Warm (Low) 0.313 0.329
Alignment Item Reference Cool (Hi) Setting/Special feature
Brightness 66 10cd/m2by 15% RGB signal (Set by generator)
R Cutoff 91 Set to 15% RGB signal level by the RGB generator.
B Cutoff 85 Set 15% RGB signal level by the RGB generator.
B Drive 6A Set 75% RGB signal level by the RGB generator.
R Drive 74 Set 75% RGB signal level by the RGB generator.
Contrast 84 Optimum setting
R Cutoff B Cutoff B Drive R Drive
Alignment Item Reference Setting/Special feature
H Position 9A Optimum setting
V Position C3 Optimum setting
H Size A8 Optimum setting
V Size 5E Optimum setting

- 18 -
< Scroll Bar >< Scroll Bar >
Panel APL / ABL
1) Confirm each data.
SG Hold
SG Hold is the alignment tool for data copy function. Color/Signal system can be set regardless of input signal.
Aging
Aging mode is internal pattern generator for panel setting confirmation and the image retention removal.
Panel Color
There are 4 color pattern White, Red, Blue and Green.
1) Access desired color pattern by the Volume Up or Down button on the remote control and press the
ACTION (PT models)/ STR (TC models) button.
2) To exit, press Menu button.
Scroll Bar
Scroll bar is for the image retention removal.
Display scroll bar approximately 15 minutes after alignment is completed.
1) Access the Scroll bar menu by Left or Right button of cross button and press the
ACTION (PT models)/ STR (TC models) button.
2) To exit, press the Menu button.
Note:
CAT (Computer Aided Test) mode
Alignment Item Reference Setting/Special feature
APL Shift Level E2 Confirmation only
ABL Point 10 Confirmation only
ABL Gain E0 Confirmation only
ABL Bank Select 3F Confirmation only
Mode Function Access button
IIC Service Alignment ACTION (PT models)/ STR (TC models)
CD (Complete Diagnostics) Software version information
EEP ROM edit MUTE
IT (Integrated Text) Not used
SD (Status Display) Factory use
OSD on/off OSD display switch MUTE
ID (Initial Data) Not used
CAT sys8.0
0
IIC Mode
CD Mode
I T Mode
SD Mode
OSD On/Off
ID Mode

- 19 -
Self Check
Display Indication
1. Self-check is used to automatically check the bus line con-
trolled circuit of the Plasma display.
2. To get into the Self-check mode press the volume down
button on the customer controls at the front of the set, at
the same time pressing the SLEEP (PT models)/ OFF-
TIMER (TC models) button on the remote control, and
the screen will show : -
If the CCU ports have been checked and found to be incor-
rect or not located then “--”will appear in place of “OK”.
ID
HG
DS
D
IIC1
IC2401 OK H21
IIC2
IC8501 OK H51
IC8516 OK H52
IC8506 OK H53
IC8509 OK H54
IC8002 OK H55 IC8004 OK H51
IC8010 OK H59IC8013 OK H57
IC8007 OK H58
IC9100 OK H60
IC9210 OK H61
IC9410 OK H62
IC9801 OK H63
IC9804 OK H91
Trouble shooting guide
LED Indication
1. The Power LED indicates faulty status of power supply circuit by flashing.
When one of secondary supply voltage is decreased under 2/3 of original voltage, the power LED light change from green to
red flashing.
Red Color
Flashing
Remove
P7 board
Process Voltage lines failure
+3.3V +5V
+13V -15V
-15V
HG board
D board
DS pack
P board
Sustain Voltage lines failure
Vsus
Ve
VDA (+70V)
SS board
SC board
C1 - C4 board
SU or SD board
Red LED flashingTurn green LED

- 20 -
No Power
No Picture
TPSC1 SC pulse
Local screen failure
Plasma display may have local area failure on the screen. Fig-T is the possible defecrt P.C.B. for each local area.
Does not turn the power LED Check P9 Connecter PIN 1-3 voltage
P1 board
Check P1 boardOK
NG Check AC power code or power source
NG Chenge F900, F901
Check Fuse F900, F901 OK Check AC power code or power source
Red LED flashing Remove P7 and P8 board OK Check P7 and P8 board
NG Check +B lines
No picture
DS pack
D or P1 board
What signal?
Check OSD
Check
drive pulses
DS
input
HG board
D board
HG board
HG board
SC or D boardSS or D board
RGB/Component, PC
(525p, 625p)
All Input
Display
OK No SC pulse
on TPSC1 No SS pulse on TPSS1
No signal
OK
Component
AV
A-15, 17, 19
A-7, 9
Check
AV(NTSC, PAL, SECAM), Component(525i, 625i)
No signal
both SC & SS
When drive pulses are oscillated correctly,
slight hum noise can be heard from the boards.
1 Field
Panel(Vertical lines)
<Local screen failure chart>
SU board
Dboard
C2 board
Dboard C1 board Dboard
C3 board
Dboard C4 board Dboard
SD board
Dboard
