Panasonic HL-BT62S Operating instructions

Operating Instructions & Installation Instructions
ELECTRIC BUILT-IN OVEN
FOR DOMESTIC USE ONLY
Model No.
HL-BT62S / HL-BT62B
Please read these instructions carefully before using this product, and save
this manual for future use.

1
EN
English
Contents
Instructions for use........... 2-49
Important safety instructions ..........2-6
Environmental responsibility ..............7
Get to know your oven.................... 8
Accessories ..............................9-11
Using the rack or tray ..............................10
Using the Tray rack..................................10
Using the rotisserie rod............................ 11
Using the oven ........................12-24
Before using the appliance......................12
General Description ................................12
Warnings and general advice
for usage..................................................13
Description of the controls
on the front panel................................14-15
Operating modes.....................................16
First use...................................................17
Setting the current time ...........................17
Selecting a function .................................18
Modifying the preset temperature............19
Switching the oven off .............................19
Using the Minute timer.......................... 20
Programmed cooking .........................21-23
Secondary menu .....................................24
Cooking with the oven .............25-37
Types of heating mode .......................25-26
Cooking advice and instructions.........27-28
To save energy ........................................29
Cooking Charts...................................30-33
Recipes...............................................34-37
Cleaning and maintenance .......38-43
Cleaning stainless steel...........................38
Cleaning the glass of the lid ....................38
Ordinary daily cleaning............................38
Cleaning the door glazing........................39
Cleaning the inside of the oven ...............39
Removing guide frames...........................40
Pyrolysis: automatic oven cleaning ....41-43
Special maintenance................44-48
Replacing the light bulb ...........................44
Removing the door ..................................45
Removing the internal glass panels....46-47
What to do if… ........................................48
Technical specications .................49
Installation instructions .... 50-53
Electrical connection........................ 50
Fixing the appliance to a cabinet..... 51
Positioning the oven ...................52-53
Thank you for purchasing a Panasonic Oven.

2
3
EN
This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction by a person
responsible for their safety concerning the
use of the appliance in a safe way and
understand the hazards involved. Children
shall not play with the appliance. Cleaning
and user maintenance shall not be made by
children without supervision.
Excess spillage must be removed before
cleaning using the pyrolytic automatic oven
cleaning function. Whilst using the pyrolytic
automatic oven cleaning function the surfaces
may get hotter than usual and children should
be kept away.
Important safety instructions

2
3
EN
English
Before starting the automatic cleaning cycle
completely remove all accessories from inside
the oven. The roof liner is not considered an
accessory and must therefore be kept inside
the oven. Remove the guide frames, (see
page 40 EN, Removing guide frames).
For correct installation of the racks and
trays supplied with this oven (see page 10
EN, Using the rack or tray).
WARNING Ensure that the appliance is
disconnected from the power supply before
replacing the lamp, to avoid the possibility of
electric shock.
WARNING The appliance and its
accessible parts may become hot during
use. Care should be taken to avoid touching
heating elements inside the oven. Young
children should be kept away. Children less
than 8 years of age shall be kept away unless
continuously supervised.
Important safety instructions

4
5
EN
A steam cleaner is not to be used for
cleaning.
Do not use harsh, abrasive cleaners or
sharp metal scrapers to clean the oven door
glass since they can scratch the surface,
which may result in shattering of the glass.
Important safety instructions

4
5
EN
English
This manual constitutes an integral
part of the appliance. It should be kept
intact and at hand for the appliance’s
entire life cycle. It is important to
carefully read this manual and all of the
instructions contained herein before
using the appliance. Installation must
be carried out by competent persons
in accordance with the regulations in
force. This appliance is intended for
household use and complies with the
EEC directives currently in force. The
appliance has been built to carry out
the following functions: cooking food; it
is considered unsuitable for any other
use.
The manufacturer cannot be held liable
for use other than as indicated.
Do not use this appliance for heating
rooms.
Never obstruct the openings and
slits provided for ventilation and heat
dispersal.
Do not rest any weight or sit on the
open door of the appliance.
The identication plate with the
technical data, serial number and
brand name has been visibly afxed
to the appliance. Do not remove this
plate for any reason.
Before the appliance is put into
operation, all the protective lms
applied inside or outside must be
removed.
Take care that no objects are stuck in
the door of the oven.
The appliance becomes very hot during
use. Suitable heat-proof gloves should
be worn for all operations.
Use normal non-abrasive products,
including wooden or plastic utensils if
necessary. Rinse thoroughly and dry
using a soft cloth or chamois leather.
Do not allow residues of sugary foods
(such as jam) to set inside the oven
since they might damage the enamel
lining of the oven. Do not use plastic
kitchenware or containers. The high
temperatures inside the oven could
melt the plastic, and damage the
appliance.
Do not use sealed tins or containers in
the appliance. Overpressure may occur
inside the containers during cooking,
creating a danger of explosion.
Do not leave the appliance unattended
during cooking processes where fats
or oils could be released. Fats and oils
may catch re.
Do not cover the bottom of the oven
with aluminium or tinfoil sheets during
cooking and do not place pans or trays
on it to avoid damage to the enamelled
surface.
If the surfaces are still very hot during
cooking, do not pour water directly
onto the trays. The steam could
cause severe burns and damage to
enamelled surfaces.
All cooking operations must take place
with the door closed.
Important safety instructions

6
7
EN
Refer to the installation instructions
section of this manual (page 50 EN)
for the safety regulations for electric
appliances and ventilation functions. In
your interests and for your safety the
law requires that the installation and
servicing of all electrical appliances
is carried out by qualied personnel
in accordance with the regulations in
force.
Electrical appliances must always
be disconnected by suitably skilled
people. Before connecting the
appliance to the power supply, check
the data on the identication plate
against the data for the power supply
itself. Before carrying out installation/
maintenance work, make sure that
the appliance is not connected to the
power supply.
If the power supply cable is
damaged, contact our Customer
Contact Centre immediately to
arrange for it to be replaced.
It is obligatory for all electrical
equipment to be earthed according
to the methods laid down by safety
regulations.
Immediately after installation, carry
out a brief operational test. Should
the appliance not function, disconnect
it from the electricity supply and call
our Customer Contact Centre. Never
attempt to repair the appliance.
Never put inammable objects in the
oven: if it is switched on by accident,
it may cause a re.
During use the appliance becomes
very hot. Take care not to touch the
heating elements inside the oven.
Do not let children go near the
appliance when it is in operation or
play with it at any time.
Do not insert pointed metal objects
(cutlery or utensils) into any aperture
in the appliance.
Do not use a steam cleaner for
cleaning the appliance. The steam
could reach the electronics, damaging
them and causing short-circuits.
Do not modify this appliance.
Do not spray any spray products near
the electrical appliance while it is in
operation. Do not use spray products
while the product is still hot.
WARNING
The manufacturer cannot be held
liable for damage to persons
or things caused by failure to
observe the above instructions, by
interference with any part of the
appliance or by the use of non-
original spare parts.
Important safety instructions

6
7
EN
English
Information on Disposal
for Users of Waste
Electrical & Electronic
Equipment (private
households)
This symbol on the products and/or
accompanying documents
means that used electrical and
electronic products should not be
mixed with general household waste.
For proper treatment, recovery and
recycling, please take these products
to designated collection points, where
they will be accepted on a free of
charge basis.
Alternatively, in some countries you
may be able to return your products to
your local retailer upon the purchase of
an equivalent new product.
Disposing of this product correctly will
help to save valuable resources and
prevent any potential negative effects
on human health and the environment
which could otherwise arise from
inappropriate waste handling. Please
contact your local authority for further
details of your nearest designated
collection point.
Penalties may be applicable for
incorrect disposal of this waste, in
accordance with national legislation.
For business users in the
European Union
If you wish to discard electrical and
electronic equipment, please contact
your dealer or supplier for further
information.
Information on Disposal in other
Countries outside the European
Union
This symbol is only valid in the
European Union.
If you wish to discard this product,
please contact your local authorities or
dealer and ask for the correct method
of disposal.
WARNING
Do not discard the packaging or any
part of it, or leave it unattended. It
can constitute a suffocation hazard
for children, especially the plastic
bags.
Environmental responsibility

8
9
EN
1. Control panel
2. Roof liner
3. Inside lights
4. Insert for the rotisserie rod
5. Rack and tray guide frames
6. Identication rating plate
7. Oven fan
8. Door seal
Get to know your oven
Note
This illustration is for reference only.
1
2
3
5
4
7
5
3
8
6
