Panasonic HL-SX485B User manual

Operating Instructions / Installation instructions
Bedienungs / Installationsanleitung
Mode d’emploi / Instructions d’installation
Steam Combination Oven
Dampfkombinationsofen
Four combi-vapeur
Model No. HL-SX485S
HL-SX485B
English Deutsch Français
FOR DOMESTIC USE ONLY
NUR FÜR HAUSHALTSÜBLICHEN GEBRAUCH
POUR UN USAGE DOMESTIQUE
HL-SX485S

IMPORTANT SAFETY INSTRUCTIONS: Before operating this appliance, please read these
instructions carefully and keep for future reference.
WICHTIGE SICHERHEITSANWEISUNGEN: Bitte sorgfältig durchlesen und zur weiteren
Bezugnahme aufbewahren.
INSTRUCTIONS DE SÛRETÉ IMPORTANTES: Avant d’utiliser l’appareil, lisez attentivement les
recommandations d’utilisation et conservez-les soigneusement.

English
1 EN
Operating Instructions........................2-57
Safety Instructions...................................2-6
Disposal of Waste Products .......................7
Use of Your Oven .......................................8
Important Safety Instructions.................8-10
Parts of your Oven...............................10-11
Oven Accessories................................12-13
Control Panel............................................14
Cooking Modes.........................................15
Combination Cooking Modes ...................16
User Settings.......................................17-19
Home Key.................................................19
Child Lock.................................................19
Microwave Cooking and Defrosting..........20
Grilling .................................................21-22
Convection Cooking ............................23-24
Steam Cooking....................................25-26
Steam Shot ..............................................27
Combination Cooking ..........................28-29
Combination Cooking with Steam .......30-31
Turbo Cook..........................................32-33
Using the Timer ........................................34
Multi-Stage Cooking .................................35
Memory.....................................................36
Defrosting Guidelines ...............................37
Turbo Defrost.......................................38-39
Auto Cook Programs ...........................40-44
Auto Steam Programs .........................45-48
Auto Steam Programs with
Turbo Cook..........................................49-52
System Cleaning Programs .....................53
Cleaning the Water Tank and
Drain Tank ................................................54
Questions and Answers.......................55-56
Care of your Oven ....................................57
Installation Instructions....................58-62
Installation and connection.......................58
Safety Instructions...............................58-59
Dimensions...............................................60
Installing the Appliance........................61-62
Specications .........................................63
Thank you for purchasing this Panasonic appliance.
Contents

2 EN
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory and mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction by a person responsible for their safety
concerning the use of the appliance in a safe way and
understand the hazards involved, including escaping
steam. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
When this oven is installed, it should be easy to isolate
the appliance from the electricity supply by pulling out the
plug or operating a circuit breaker.
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualied
person in order to avoid a hazard.
Warning! The appliance should be inspected for damage
to the door seals and door seal areas and if these areas
are damaged the appliance should not be operated until
it has been repaired by a service technician trained by the
manufacturer.
Warning! Do not attempt to tamper with or make any
adjustments or repairs to the door, control panel housing,
safety interlock switches or any other part of the oven.
Warning! Do not remove the outer panels from the oven
which give protection against exposure to microwave
energy.
Repairs should only be made by a qualied service
person.
Warning! Liquids and other foods must not be heated in
sealed containers since they are liable to explode.
Safety Instructions
Operating Instructions

English
3 EN
Warning! Only allow children to use the oven without
supervision when adequate instructions have been given
so that the child is able to use the oven in a safe way and
understands the hazards of improper use.
When heating food in plastic or paper containers, check
the oven frequently as these types of containers can
ignite if overheated.
If smoke is emitted or a re occurs in the oven, touch On/
O and leave the door closed in order to stie any ames.
Disconnect the power cord, or shut o power at fuse or
circuit breaker panel.
This appliance is intended to be used in household
applications only.
When heating liquids, e.g. soup, sauces and beverages in
your oven, overheating the liquid beyond boiling point can
occur without evidence of bubbling. This could result in a
sudden boil over of the hot liquid.
The contents of feeding bottles and baby food jars are to
be stirred or shaken. The temperature has to be checked
before consumption to avoid burns.
Do not cook eggs in their shells and whole hard-boiled
eggs by MICROWAVE. Pressure may build up and the
eggs may explode, even after the microwave heating has
ended.
Clean the inside of the oven, door seals and door seal
areas regularly. When food splatters or spilled liquids
adhere to the oven walls, base of the oven, door
seals and door seal areas wipe o with a damp cloth.
Mild detergent may be used if they get very dirty. The
use of harsh detergent or abrasive cleaners is not
recommended.
DO NOT USE COMMERCIAL OVEN CLEANERS.
Safety Instructions

4 EN
When using the GRILL, CONVECTION, STEAM or
COMBINATION modes, some foods may splatter
grease on to the oven walls. If the oven is not cleaned
occasionally, it may start to “smoke” during use.
Failure to maintain the oven in a clean condition could
lead to deterioration of surfaces that could aect the
life of the appliance and possibly result in a hazardous
situation.
Warning! The accessible parts may become hot in GRILL,
CONVECTION, STEAM and COMBINATION use. Young
children less than 8 years of age should be kept away.
Children should only use the oven under adult supervision
due to the temperatures generated.
A steam cleaner is not to be used for cleaning the
appliance.
Do not use harsh, abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of the
glass.
Exterior oven surfaces, including air vents and the oven
door will get hot during GRILLING, CONVECTION,
STEAM, and COMBINATION modes, take care when
opening or closing the door and when
inserting or removing food and accessories.
This appliance is not intended to be operated by means
of an external timer or separate remote-control system.
Only use utensils that are suitable for use in microwave
ovens.
Warning! This appliance produces boiling hot steam.
Safety Instructions

English
5 EN
During and after cooking with steam function, do not
open the oven door when your face is very close to the
oven. Care must be taken when opening the door as
steam may cause injury.
Warning! Steam may billow out when you open the door.
If there is steam in the oven, do not reach in with your
bare hands! Risk of burns! Use oven gloves.
Please refer to pages 12-13 for correct installation of the
oven accessories.
Warning! The oven has four grill heaters situated in the
top of the oven and a convection heater situated in the
back of the oven. After using the GRILL, CONVECTION,
STEAM and COMBINATION functions, the inside
surfaces of the oven will be very hot. Care should be
taken to avoid touching the heating elements inside the
oven. To prevent burns, care should be taken to avoid
touching the inside surfaces of the oven.
This combination oven is intended for heating food
and beverages only. Take care when heating foods low
in moisture, e.g. bread items, chocolate, biscuits and
pastries. These can easily burn, dry out or catch on re if
cooked too long. We do not recommend heating foods
low in moisture such as popcorn or poppadoms. Drying
of food, newspapers or clothing and heating of warming
pads, slippers, sponges, damp cloths, wheat bags, hot
water bottles and similar may lead to risk of injury, ignition
or re.
Warning! The oven lamp must be replaced by a service
technician trained by the manufacturer. DO NOT attempt
to remove the outer panels from the oven.
Safety Instructions

6 EN
Before using the oven, place the drain tank in position.
Refer to page 10 for correct installation.
The purpose of the drain tank is to collect excess water
during STEAM and STEAM COMBINATION mode.
It should be emptied after each STEAM and STEAM
COMBINATION operation.
Do not use the water tank if it is cracked or broken, as
leaking water could result in electrical failure and danger
of electric shock. If the water tank becomes damaged,
please contact your dealer.
This oven is intended for built-in use only. This appliance
is not designed to be used as a tabletop appliance or
inside a cupboard.
CAUTION! In order to avoid a hazard due to inadvertent
resetting of the thermal cut-out, this appliance must not
be supplied through an external switching device, such as
a timer, or connected to a circuit that is regularly switched
on and o by the utility.
Safety Instructions

English
7 EN
Disposal of Waste Products
Information on disposal
for users of Waste
Electrical & Electronic
Equipment (private
households)
This symbol on the products and/
or accompanying documents means that
used electrical and electronic products should
not be mixed with general household waste.
For proper treatment, recovery and recycling,
please take these products to designated
collection points, where they will be accepted
on a free of charge basis. Alternatively, in
some countries you may be able to return
your products to your local retailer upon the
purchase of an equivalent new product.
Disposing of this product correctly will help to
save valuable resources and prevent
any potential negative effects on human
health and the environment which could
otherwise arise from inappropriate waste
handling. Please contact your local authority
for further details of your nearest designated
collection point.
Penalties may be applicable for incorrect
disposal of this waste, in accordance with
national legislation.
For business users in the
European Union
If you wish to discard electrical and electronic
equipment, please contact your dealer or
supplier for further information.
Information on disposal in other
countries outside the European
Union
This symbol is only valid in the European
Union.
If you wish to discard this product, please
contact your local authorities or dealer and
ask for the correct method of disposal.

8 EN
WARNING!
Important safety instructions
1. The door seals and seal areas should
be cleaned with a damp cloth. The
appliance should be inspected for
damage to the door seals and door seal
areas and if these areas are damaged
the appliance should not be operated
until it has been repaired by a service
technician trained by the manufacturer.
2. Do not operate this appliance if it
has a damaged cord or plug, if it is
not working properly, or if it has been
damaged or dropped. It is dangerous for
anyone other than a service technician
trained by the manufacturer to perform
repair service.
Important Safety Instructions
Use of Your Oven
Read carefully and keep for future reference
1. After plugging in the oven you will be
prompted to select a language and to
set the time. These settings can be
changed at any time, see page 17.
2. Do not use the oven for any reason
other than the preparation of food and
beverages. This oven is specically
designed to heat or cook food. Do not
use this oven to heat chemicals or
other non-food products.
3. Before use, check that utensils/
containers are suitable for use in
microwave ovens.
4. When the oven is not being used, do
not store any objects inside the oven
in case it is accidentally turned on.
5. The appliance must not be operated
by MICROWAVE or COMBINATION
WITHOUT FOOD IN THE OVEN.
Operation in this manner may damage
the appliance.
Heater operation
Before using CONVECTION, STEAM,
GRILL or COMBINATION function for the
rst time, wipe excessive oil off in the oven
cavity and operate the oven without food
and accessories on GRILL 1 for 15 minutes.
This will allow the oil that is used for rust
protection to be burned off.
CAUTION! Hot surfaces
After cooking the oven
accessories will be very hot.
Fan motor operation
After using the oven, the fan motor may
rotate for a few minutes to cool the electric
components. This is normal and you can
remove food even though the fan motor
operates. You can continue using the oven
during this time.
