Panasonic HL-CK655SEPG Product guide

Operating / Installation Instructions
Built-in Electric Oven
FOR DOMESTIC USE ONLY
Model No. HL-CK655S
HL-CK655B
HL-CK655S

2
IMPORTANT SAFETY INSTRUCTIONS: Before operating this appliance, please read these
instructions carefully and keep for future reference.

3
Thank you for purchasing this Panasonic appliance.
Contents
Operating Instructions �������������������������������������������������������������������������������������������������������4-36
Safety Instructions ..................................................................................................................4-6
Disposal of Waste Products ......................................................................................................7
Energy Saving Tips ....................................................................................................................7
Before Using Your Oven ............................................................................................................8
Features and Functions ........................................................................................................9-10
Operation Modes................................................................................................................. 11-12
Using the Appliance.............................................................................................................13-17
Accessories ........................................................................................................................17-18
Food Preparation ................................................................................................................19-28
• Baking ......................................................................................................................... 19-22
• Roasting ...................................................................................................................... 23-24
• Grilling and Browning .................................................................................................. 25-27
• Defrosting ......................................................................................................................... 28
Maintenance and Cleaning .................................................................................................29-34
Troubleshooting ..................................................................................................................35-36
Installation Instructions ���������������������������������������������������������������������������������������������������37-40
Specications ������������������������������������������������������������������������������������������������������������������������41

4
nThis appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
nWARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements. Children less than 8 years of
age shall be kept away unless continuously supervised.
nWARNING: Danger of re: do not store items on the
cooking surfaces.
nDo not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of the
glass.
nDo not use steam cleaners or high-pressure cleaners
to clean the cooking appliance, as this may result in an
electric shock.
nWARNING: Before replacing the light bulb, make sure
the appliance has been disconnected from the mains
power, in order to prevent an electric shock.
nThe appliance is not intended to be controlled with
external timers or special control systems.
Safety Instructions
Operating Instructions

5
nThe appliance is intended for household use. Do not use it for
any other purpose, such as room heating, the drying of paper
or fabrics, etc. as this may lead to injury or re hazard.
nTampering with the appliance or non-professional repair thereof
may result in risk of severe injury or damage to the product.
nIf the power cord is damaged, it should be replaced by the
manufacturer or an authorised service technician, in order to
avoid hazard.
nDo not line the oven walls with aluminium foil and do not
place baking trays or other cookware on the base of the oven.
Aluminium foil could prevent air circulation in the oven, hinder
the cooking process, and damage the enamel coating.
nThe appliance becomes very hot during use. Suitable
heat-proof gloves should be worn.
nOven door hinges may be damaged when under excessive
load. Do not place heavy pans on open oven door and do not
lean against open oven door when cleaning the oven cavity.
Never stand on the open oven door and do not let children sit
on it.
nMake sure the vents are never covered or obstructed in any
way.
nSpray canisters, areosols and other inammable substances
can ignite when heated. Do not store or use these items near
the oven.
nDo not use sealed tins or containers in the appliance.
nTake care when cooking with fats and oils.
Safety Instructions

6
nDo not attempt to tamper with or make any adjustments or
repairs to the door, control panel housing, safety interlock
switches or any other part of the oven. Repairs should only be
carried out by service technicians authorised by the appliance
manufacturer.
nAll cooking operations must take place with the door closed.
nThe appliance becomes very hot during use. Suitable heat-
proof gloves should always be worn.
nTake care when cooking foods containing high alcohol content.
Alcoholic vapours may ignite.
nThe socket the oven is plugged into must be connected to the
household main circuit board.
nThe manufacturer cannot be held liable for damage to persons
or items caused by failure to observe the above instructions,
by interference with any part of the appliance or by the use of
non-original spare parts.
Safety Instructions

7
Information on Disposal
for Users of Waste
Electrical & Electronic
Equipment (private
households)
This symbol on the products and/or
accompanying documents means that used
electrical and electronic products should not
be mixed with general household waste.
For proper treatment, recovery and recycling,
please take these products to designated
collection points, where they will be accepted
on a free of charge basis.
Alternatively, in some countries you may be
able to return your products to your local
retailer upon the purchase of an equivalent
new product.
Disposing of this product correctly will help
to save valuable resources and prevent any
potential negative eects on human health
and the environment which could otherwise
arise from inappropriate waste handling.
Please contact your local authority for further
details of your nearest designated collection
point.
Penalties may be applicable for incorrect
disposal of this waste, in accordance with
national legislation.
Information on Disposal in other
Countries outside the European
Union
This symbol is only valid in the European
Union.
If you wish to discard this product, please
contact your local authorities or dealer and
ask for the correct method of disposal.
Disposal of Waste Products
• Certain foods do not need a preheated oven. Do not preheat the oven unless
necessary or stated in the recipe.
• Do not use full grill if half grill will be sucient.
• Where possible, cook multiple items at once. This will lower the amount of time
that the oven is in use.
• Plan ahead. If you will be cooking food that will keep (puddings, cakes, pastries
etc.), do so whilst the oven is still hot from cooking a meal as you will only have to
heat up the oven once. This will also save time later on.
• Remove any accessories from the oven that are not required for cooking.
• Avoid opening the door during cooking.
• Do not use the cavity lighting unless necessary.
Energy Saving Tips

8
This manual constitutes an integral part of the appliance. It should be kept intact and
at hand for the appliance’s entire life cycle. It is important to carefully read this manual
and all of the instructions contained herein before using the appliance.
Examine your oven
Please make sure the appliance was supplied to you undamaged. Remove all
packaging and examine the oven for any damage such as dents, broken door latches
or cracks in the door. If you nd any damage, notify your dealer immediately. Do not
install a damaged oven.
Rating plate
The Rating Plate indicating the basic information of the appliance is attached to
the inside of the oven and is visible when you open the door (see page 10). Do not
remove.
• Before using the oven for the rst time, run Convection at 250 °C for 5 minutes. A
specic odour of a 'new appliance' will be present. Make sure the room is ventilated.
• After the oven has cooled down, clean the inside and all accessories with warm
water and a conventional detergent. Do not use abrasive cleaning aids.
Before Using Your Oven
WARNING
Remove all internal and external packaging. Please ensure all internal
packaging is removed before switching the oven on.

9
123
6
7
8
1
2
3
4
5
10
9
9
11
Features and Functions
1On/Off and function dial
2Program timer (see page 13)
3Plus / Minus dial.
This illustration is for reference only.
1. Grill elements
2. Oven lamp
3. Oven fan
4. Rating plate
5. Door glass release
6. Control Panel
7. Air vents
8. Telescopic guides
9. Shelving clips
10. Door hinge
11. Door glass

10
The oven is operated by the function and the plus/ minus
dials.
• Push the dial slightly, to make it pop out of the control
panel. After use press it back into its recessed position,
ush with the control panel.
Plus / Minus dial.
On/o and function dial.
Operation dials
The recessed dial may only be pushed back into its recessed postion when it is in the
“off” position.
Setting the temperature using the Plus / Minus dial�
Temperature and other settings can also be adjusted by using the Plus /Minus dial. This is an
alternative method to using the + / - keys.
• Rotate the plus/ minus dial clockwise or counterclockwise. The set temperature is displayed,
and the symbol “°C” will ash.
• The temperature is changed in 5°C steps.
• Temperature and all timer settings can be deleted using the temperature dial: decrease the
temperature to 30°C, then rotate the dial to the left once again. This will bring the oven back
to clock mode.
The switch will turn off the oven heating and the fan when
the door is opened during oven operation; when the door is
closed again, the heating is resumed.
After the oven is switched off, the cooling fan continues to
operate for a short time to cool the appliance.
The appliance features a built-in cooling fan which cools the
appliance housing and control panel.
Oven door switch
Extended operation
of the cooling fan
Cooling fan
Features and Functions

11
Operation Modes
Fan grill
The upper heater and the fan are activated simultaneously. It
is appropriate for grilling and browning poultry pieces, ribs or
gratins on one shelf position.
Half grill
The inner heater is activated. This mode is appropriate for
grilling smaller quantities of toasted sandwiches or bread.
Oven lighting
There is one interior lighting lamp: on the upper part of the
back wall. Oven lighting can be selected independently. With
all other modes of operation, the oven lighting is turned on
automatically when the operation mode is selected.
Full grill
The inner and the outer heaters are activated simultaneously.
This operation mode is appropriate for cooking smaller pieces
of meat, such as steaks, chops and sausages.
Upper / lower heater
The heaters on the upper and lower side of the oven radiate
uniformly and evenly into the oven interior. Pastries, cakes
and meat can be cooked on one shelf position.

12
Lower heater/ Steam clean
The bottom heater is activated. Select this mode when you
wish to cook the bottom side of the dish more thoroughly
(e.g. for deep pastry with fruit lling). Set the temperature with
the temperature selection dial. The lower heater can also be
used for cleaning the oven, for instructions please see the
“Maintenance and cleaning” section on page 29.
Lower heater and fan
The lower heater and the fan operate simultaneously. Used
for baking sweet bread dough and preserving fruit and
vegetables. Use the rst shelf position from the bottom and
shallow rather than deep baking trays.
Defrosting
The air is circulated without any heater being turned on. Only
the fan is in operation. This is used for defrosting frozen food.
Convection
The back heater and the fan operate simultaneously in
order for the hot air to circulate constantly. This mode is
appropriate for roasting meat and baking on several shelves
simultaneously. Cooking temperature should be set lower
than conventional operation.
Convection and lower heater
The back heater, the fan and the lower heater operate
simultaneously. This is suitable for making pizza, pastries,
fruit cakes or baked cheesecakes.
Operation Modes

13
• When the appliance is connected to the power supply or after a power failure, the word
“GLAS” is rst displayed; then, the display ashes. To allow operation of the oven the time
must be set using (b) and (c) .
Using the Appliance
Operation keys:
A Function selection and conrmation
key
B Temperature setting key
C Plus key
D Minus key
Display:
1 Duration/cooking timer
2 Program end time
3 Kitchen timer
4 Clock
5 Child lock
6 Time/ Temp display
7 Heater operation symbol
Setting the clock
• Press the (a) key until the (4) is selected .
• Press the (B) and (C) key to set the time of day.
• Conrm the setting by pressing the (A) key again; if the (A) key is not pressed, the time will
automatically set after a few seconds.
• This is a 24 hour clock.
To improve the response of the keys, touch them with a larger surface of your
nger.
Temperature and other settings may also be set using the plus/minus dial.
Setting the timer functions
The electronic program timer can also be used to set the temperature and the timer function. Both
settings are indicated on the same display. This is set by pressing the relevant key (A) or (B).
Selecting timer functions
• Select the type of function required by pressing the (A) key. The selected function will ash
for ve seconds, the value can be set during this time. Once set, the function will ash
slowly and the time is displayed. N.B. The symbols lit are selected. The most recent setting
will be shown in the display.
• Each press of a key is acknowledged by a beep.
• If one of the value settings keys (B) or (C) is touched and held, the speed of changing the
value will increase.
• In case of a power failure which lasts less than two minutes, all settings are maintained.

14
Setting the duration / cooking time
This mode allows you to set a function for a specic length of time. A maximum of 10 hours
can be set.
• Press the (A) key to select the symbol (1) . Use the (B) (C) and (0) keys to set the duration /
cooking time.
• Use the oven dials to set the operation mode and temperature. When the set time has
elapsed, the oven will automatically stop operating. An intermittent beep will sound, which
can be stopped by pressing any key; if no key is pressed, the beep will stop after one
minute.
• To edit the time set, press (a) . Use the (c) and (d) keys to modify.
• The symbol (1) and the sign (-.--) will ash. If you wish to resume cooking, press and hold
the (A) key to set a new cooking time or to return to the clock press and hold (C) and (d) .
Using the timer
Manually setting the oven
• Select the operation mode using the function dial (see page 9).
• Set the required temperature using the plus/ minus dial (see page 9). After each use, turn the
dial back to the off position or by setting the temperature back to 0°C using the keys (C) and
(D) or the plus/ minus dial.
Using the temperature setting key
• Touch the (B) key. Preset temperature of 180°C is displayed, and the symbol “°C” will ash for a
few seconds. The oven starts to operate.
• As long as the symbol “°C” is ashing, the keys (C) and (D) can be used to set the required
temperature. It counts in intervals from 30 to 275 °C, in 5°C steps. Each time the key is pressed,
the temperature is changed by 5 °C.
• Rising actual oven temperature is indicated on the display, in 5°C steps. As long as the oven
temperature is less than 30°C, “---°C” will be displayed. Symbol (7) is also displayed, indicating
the operation of the heaters.
• When the set temperature is reached, the symbol (7) will go off, and a short beep will sound.
• During cooking, the temperature is maintained by occasional activation of the heaters; when this
happens, the symbol (7) appears.
• During cooking temperature may be changed at any time by touching the (B) key and changing
the value using the keys (C) and (D).
NOTE - INTERIOR LIGHT:
If only the oven interior light is selected on the selector dial, the light will only be lit when the
key (B) is touched or plus/ minus dial is used. Ambient temperature inside the oven will be
shown in the display.
Using the Appliance

15
Setting the program end time
This mode allows you to set the time at which the oven should stop operating. A maximum of
10 hours relative to the current time of day can be set.
• Make sure the current time of day is set correctly.
• Use the (A) key to select (2) . The current time of day is indicated on the display. Press the
(B) and (C) keys to set the program end time.
• Use the oven dials to set the operation mode and temperature. When the set time has
elapsed, the oven will automatically stop operating. An intermittent beep will sound, which
can be stopped by pressing any key; if no key is pressed, the beep will stop after one
minute.
• The symbol (1) and the sign (-.--) will ash. If you wish to resume cooking, press and hold
the (A) key and set a new duration/ cooking time or to return to the clock press and hold (C)
and (D) .
Setting the delayed start
With this operation mode, two settings have to be made: duration / cooking time and cooking
end time.
Cooking end time can be delayed by a maximum of 24 hours relative to the current time of
day.
• Make sure the current time of day is set correctly.
• First, set the duration / cooking time: Press the (A) key to select the symbol (1). Use the (C)
and (D) keys to set the duration / cooking time.
• Then, set the program end time: Use the (A) key and select the symbol (2). Press the (C)
and (D) keys to set the program end time. (A sum of the current time of day and the oven
operation time is automatically shown on the display).
• Use the function dial to select the operation mode and the (0) key to select the required
temperature.
• Both symbols (1) and (2) are lit. When cooking begins only the symbol (1) will be displayed.
• When the set time has elapsed, the oven will automatically stop operating. An intermittent
beep will sound, which can be stopped by pressing any key; if no key is pressed, the beep
will stop after one minute.
• The symbol (1) and the sign (-.--) will ash. If you wish to resume cooking, press and hold
the (A) key and set a new duration/ cooking time or to return to the clock press and hold (C)
and (D) .
Using the Appliance

16
Setting the kitchen timer
The oven has a kitchen timer that sounds an alarm after counting down the preset time.
• Use the (A) key to select the symbol (3). Then, use the (C) and (D) keys to set the time before the
alarm sounds. Maximum time is 10 hours.
• When the set time has elapsed, an intermittent beep will sound, which can be stopped by
pressing any key; if no key is pressed, the beep stops after one minute. The symbol (3) will go off.
N.B. The last minute of the timer countdown is displayed in second intervals.
For safety reasons, the oven will automatically go off after a certain period of
time:
- after 10 hours, if the cooking temperature is above 120°C;
- after 24 hours, if the temperature set is lower than 120°C.
Setting the beep volume
The alarm volume can be set when no timer function is activated (only current time of day is
displayed).
• Press the (B) key and hold it approximately three seconds; a volume indicator will appear, and
the corresponding sample sound will sound. “oooo” indicates maximum volume, and “o” indicates
minimum volume. Use the (C) key to select among the four volume levels.
• Conrm the selected volume level by pressing the (A) key; if the (A) key is not pressed the setting
will be conrmed and stored automatically after a few seconds.
Setting the child lock
Activation: Press the (A) key to select the symbol (5). Use the (B) or C) keys to activate the child
lock; the display will read “ON”. Conrm the setting by pressing the (A) key. The symbol is lit
when activated.
Deactivation: Press the (A) key to select child lock, then pres the (C) or (D) key to deactivate the
child lock; “OFF” is displayed.
The setting must be conrmed by pressing the (A) key.
- If the child lock is activated when no timer or temperature function is set (only the current time of
day is displayed), the oven will not operate and no changes to any setting will be allowed.
- If the child lock is activated after one of the timer or temperature functions has been set, the oven
will operate as normal; however, no changes to the timer settings will be possible.
Deleting the timer settings
- All timer settings can be deleted at any time by pressing the (C) and (D) keys simultaneously and
holding them for three seconds. The set programs are automatically interrupted and the timer
switches to display of the current time of day.
- Another way to delete a setting is by setting the timer value to “0.00”.
Using the Appliance

17
Shelf levels
• Accessories (wire shelf, shallow baking tray and the
deep baking tray) can be inserted into the oven at four
levels.
• Please note that the shelf levels are always referred
to by consecutive numbers starting from the bottom
(particular shelf levels are described in the cooking
tables).
• The wire shelf and the trays should always be inserted
into the leading slot formed by adjacent wire proles of
the wire guides.
Wire shelf
Food is placed directly on wire shelf or in a container on wire
shelf.
A safety stop is tted on the wire shelf and on the
guides. To pull out the wire shelf, lift it slightly
when it hits the stop.
Shallow baking tray
This is used for baking pastry, small cakes and biscuits.
Deep baking tray
This is used for roasting meat and as a drip tray.
The deep baking tray is used only as a drip
tray when using the grill functions, the deep
tray should not be inserted into the fourth shelf
position.
Accessories
Using the Appliance

18
• To insert the wire shelf, deep baking tray, or shallow baking tray, rst pull out the telescopic
guides of the desired level.
• Place the wire shelf, deep baking tray, or shallow baking tray on the pull-out guides and
push it into the oven. Close the oven door only when the telescopic guides have been fully
retracted.
The fan on the oven back plate is covered by a catalytic
layer that can be installed or removed only by an authorised
service technician.
Accessories

19
Food Preparation
Baking
• Use the , or . mode of operation.
Instructions
• Always observe the instructions on the shelf / shelf position, temperature, and cooking time
indicated in the baking table. The values indicated in the table are dened and checked
especially for this particular oven.
• If the baking table does not specically mention a particular food, refer to the information for
a similar type of food.
Cooking /baking with upper and lower heater
• Cook /Bake at one level only.
• Upper / lower heater combination is suitable for cooking
various types of pastry, bread, and meat.
• Use dark-coloured baking trays. Light-coloured trays reect
the heat, which leads to poorer cooking (browning) results.
Always place your own cooking containers on the wire
shelf. If you are using the supplied baking tray, remove the
wire shelf.
• Preheating will shorten the cooking time. Place the dish
into the oven only when the selected temperature has been
reached, i.e. When the heater operation symbol goes off
for the rst time.
Cooking / baking with convection
Cooking / baking with convection is useful when you wish
to bake on several shelves simultaneously. Preheating
is recommended. This mode is also appropriate for large
sponge cakes and fruit cakes (in this case, bake on a single
level only).
• The temperature is normally set lower than when baking with
the upper/lower heater combination (see baking table).
• When baking with several baking trays simultaneously,
baking time for each tray can vary. You may have to
remove one of the trays earlier (normally, this would be the
uppermost tray).
• When using several baking trays simultaneously, there
may be a signicant amount of vapour in the oven,
resulting in condensation on the oven door.

20
Is the cake cooked?
At the end of the cooking time, insert a metal skewer into the highest point of the cake and
then withdraw it. If the batter does not stick to the metal skewer, the cake is cooked.
The sponge cake has collapsed after I take it out of the oven
Check the recipe. Check the instructions relating to mixing time. Ensure the oven door is ot
opened during cooking.
The pastry is too light-coloured
A dark-coloured baking tray cooks dishes faster and browns foods more than lighter coloured
pans. Place the tray one shelf position lower, or turn on the lower heater towards the end of
the cooking process.
Pastries with a moist lling (e.g. deep lled pie) is not cooked
Reduce the temperature and extend the cooking time.
Notes on the baking chart:
• Two values are indicated for temperature, lower and upper. Initially, set the lower
temperature; if the pastry is not brown enough, increase the temperature.
• Cooking times are a guideline only.
• The value printed in bold in the temperature table indicates the most appropriate operating
mode for a particular type of food.
• Always preheat the oven.
• When using baking paper, make sure it is resistant to high temperature.
Tips on baking
Food Preparation
