Panasonic PT-MZ770 Operating instructions

Thank you for purchasing this Panasonic product.
■This manual is common to all the models regardless of sufxes of the Model No.
zfor India
D: White model, the standard zoom lens supplied
zfor Asia (except for Taiwan, Korea) / Oceania
A: White model, the standard zoom lens supplied LA: White model, the lens sold separately
zfor Taiwan
A: White model, the standard zoom lens supplied
zfor Korea
Without L: White model, the standard zoom lens supplied
With L: White model, the lens sold separately (PT-MZ770L only)
zfor other countries or regions
Without L / LB: White model, the standard zoom lens supplied With L: White model, the lens sold separately
With LB: Black model, the lens sold separately (PT-MZ770LB only)
■Before operating this product, please read the instructions carefully and save this manual
for future use.
■Before using this product, be sure to read “Read this rst!” (xpages 5 to 15).
DPQP1224ZB/X1
LCD Projector Commercial Use
Operating Instructions
Functional Manual
ENGLISH
Model No. PT-MZ770
 PT-MW730

2 - ENGLISH
Contents
Contents
Read this rst! 5
Chapter 1 Preparation
Precautions for use 20
Intended use of the product 20
Lens protection material 20
Cautions when transporting 20
Cautions when installing 20
Security 23
Notes regarding the wireless LAN 23
Light ID 24
DIGITAL LINK 25
Application software supported by the projector
25
Storing 26
Disposal 26
Cautions on use 26
Accessories 27
Optional accessories 28
About your projector 29
Remote control 29
Projector body 31
Preparing the remote control 34
Inserting and removing the batteries 34
When using the multiple projectors 34
Connecting the remote control to the projector
with a cable 34
Chapter 2 Getting Started
Setting up 36
Installation mode 36
Parts for installation (optional) 37
Projected image and throw distance 38
Adjusting adjustable feet 48
Removing/attaching the projection lens 49
Removing the projection lens 49
Attaching the projection lens 50
Attaching the Wireless Module 51
Attaching the Wireless Module 51
Connecting 52
Before connecting 52
Connecting example: AV equipment 53
Connecting example: Computers 54
Connecting example using DIGITAL LINK 55
Chapter 3 Basic Operations
Switching on/off the projector 58
Connecting the power cord 58
Power indicator 59
Switching on the projector 60
When the initial setting screen is displayed 61
Making adjustments and selections 65
Switching off the projector 66
Projecting 67
Selecting the input signal 67
Adjusting the focus, zoom, and lens shift 68
Moving the lens position to the home position 69
Adjustment range by the lens position shift
(optical shift) 69
Using the USB memory 70
Notes on use 70
USB memory that can be used with the
projector 70
Attaching the USB memory 70
Removing the USB memory 71
Operating with the remote control 72
Using the shutter function 72
Using the mute function 72
Adjusting the volume 73
Using the freeze function 73
Using the on-screen display function 73
Using the automatic setup function 74
Using the screen adjustment function 74
Using the digital zoom function 75
Switching the image aspect ratio 76
Using the presentation timer function 76
Using the function button 76
Displaying internal test pattern 76
Using the status function 77
Using the ECO management function 77
Setting ID number of the remote control 77
Chapter 4 Settings
Menu navigation 80
Navigating through the menu 80
Main menu 81
Sub-menu 82

ENGLISH - 3
Contents
[PICTURE] menu 85
[PICTURE MODE] 85
[CONTRAST] 85
[BRIGHTNESS] 85
[COLOR] 86
[TINT] 86
[COLOR TEMPERATURE] 86
[GAMMA] 87
[DAYLIGHT VIEW] 88
[SHARPNESS] 88
[NOISE REDUCTION] 88
[DYNAMIC CONTRAST] 89
[SYSTEM SELECTOR] 89
[POSITION] menu 91
[SHIFT] 91
[ASPECT] 91
[ZOOM] 92
[CLOCK PHASE] 93
[REALTIME KEYSTONE] 93
[SCREEN ADJUSTMENT] 94
[ADVANCED MENU] menu 97
[DIGITAL CINEMA REALITY] 97
[BLANKING] 97
[INPUT RESOLUTION] 98
[CLAMP POSITION] 98
[RASTER POSITION] 98
[DISPLAY LANGUAGE] menu 99
Changing the display language 99
[DISPLAY OPTION] menu 100
[COLOR ADJUSTMENT] 100
[COLOR CORRECTION] 100
[SCREEN SETTING] 101
[AUTO SIGNAL] 101
[AUTO SETUP] 101
[RGB IN] 102
[HDMI IN] 103
[DIGITAL LINK IN] 105
[ON-SCREEN DISPLAY] 106
[CLOSED CAPTION SETTING] (only when
NTSC signal is input) 108
[SIGNAL SEARCH] 109
[BACK COLOR] 109
[STARTUP LOGO] 110
[SHUTTER SETTING] 110
[P-TIMER] 111
[FREEZE] 112
[DIGITAL ZOOM] 112
[PROJECTOR SETUP] menu 113
[PROJECTOR ID] 113
[PROJECTION METHOD] 113
[ECO MANAGEMENT] 114
[LightID] 116
[INITIAL STARTUP] 117
[STARTUP INPUT SELECT] 117
[DATE AND TIME] 118
[SCHEDULE] 119
[RS-232C] 120
[REMOTE1 MODE] 122
[FUNCTION BUTTON] 122
[LENS CALIBRATION] 122
[AUDIO SETTING] 123
[FILTER COUNTER] 125
[DC OUT] 126
[STATUS] 126
[DATA CLONING] 127
[SAVE ALL USER DATA] 130
[LOAD ALL USER DATA] 130
[INITIALIZE] 131
[SERVICE PASSWORD] 131
[TEST PATTERN] menu 132
[TEST PATTERN] 132
[SIGNAL LIST] menu 133
Registering new signals 133
Renaming the registered signal 133
Deleting the registered signal 133
Protecting the registered signal 134
Expanding signal lock-in range 134
Sub memory 135
[SECURITY] menu 136
[SECURITY PASSWORD] 136
[SECURITY PASSWORD CHANGE] 136
[DISPLAY SETTING] 136
[TEXT CHANGE] 137
[MENU LOCK] 137
[MENU LOCK PASSWORD] 137
[CONTROL DEVICE SETUP] 138
[CONTROL DEVICE PASSWORD CHANGE]
139

4 - ENGLISH
Contents
[NETWORK/USB] menu 140
[DIGITAL LINK MODE] 140
[DIGITAL LINK STATUS] 140
[DIGITAL LINK MENU] 141
[WIRED LAN] 141
[WIRELESS LAN] 142
[PROJECTOR NAME] 146
[NETWORK CONTROL] 146
[MEMORY VIEWER] 146
[Panasonic APPLICATION] 148
[MIRRORING] 150
[NETWORK STATUS] 151
Chapter 5 Operations
Network connection 154
Connecting via wired LAN 155
Connecting with the wireless LAN 157
Web control function 159
Computer that can be used for setting 159
Accessing from the web browser 159
Projecting with Panasonic APPLICATION input
179
Application that can be used 179
Connecting the device 179
Ending the connection with the device 179
Description of the standby screen 180
Using the moderator mode in the Panasonic
APPLICATION input 181
Projecting with MIRRORING input 182
Connecting the device 182
Ending the connection with the device 183
Using the moderator mode in the MIRRORING
input 183
Operating with the web browser 184
Description of the [MODERATOR MODE] page
185
Projecting with MEMORY VIEWER input 186
Images that can be played back with the
Memory Viewer function 186
Displaying the Memory Viewer screen 187
Operating the Memory Viewer screen 187
Playing back still images 189
Playing back movies 190
Description of the Memory Viewer screen 193
Playing back using the contents list 194
Using the pairing function 195
Pairing the USB memory 195
Chapter 6 Maintenance
Light source/temperature/lter indicators 198
When an indicator lights up 198
Maintenance/replacement 200
Before performing maintenance/replacement 200
Maintenance 200
Replacing the unit 202
Troubleshooting 204
FAQ 206
Wireless LAN connection 206
Mirroring connection 206
[SELF TEST] display 208
Chapter 7 Appendix
Technical information 2 11
PJLink protocol 211
Control commands via LAN 212
<SERIAL IN> terminal 215
<REMOTE 1 IN> terminal 219
Operating [MENU LOCK PASSWORD] 219
List of compatible signals 220
Specications 223
Dimensions 228
Precautions for attaching the Ceiling Mount
Bracket 229
Index 231

ENGLISH - 5
Read this rst!
Read this rst!
WARNING: THIS APPARATUS MUST BE EARTHED.
WARNING: To prevent damage which may result in re or shock hazard, do not expose this appliance to rain
or moisture.
This device is not intended for use in the direct eld of view at visual display workplaces. To avoid
incommoding reexions at visual display workplaces this device must not be placed in the direct
eld of view.
The equipment is not intended for used at a video workstation in compliance BildscharbV.
The sound pressure level at the operator position is equal or less than 70 dB (A) according to ISO 7779.
WARNING:
1. Remove the plug from the mains socket when this unit is not in use for a prolonged period of time.
2. To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to qualied
service personnel.
3. Do not remove the earthing pin on the mains plug. This apparatus is equipped with a three prong earthing-
type mains plug. This plug will only t an earthing-type mains socket. This is a safety feature. If you are
unable to insert the plug into the mains socket, contact an electrician. Do not defeat the purpose of the
earthing plug.
WARNING:
This equipment is compliant with Class A of CISPR32.
In a residential environment this equipment may cause radio interference.
(for Taiwan)
WARNING:
This equipment complies with the Class A standard of CISPR32.
This is Class A information technology equipment that may cause radio frequency interference when used in a
residential environment, in which the user will be required to take certain appropriate countermeasures.
CAUTION: To assure continued compliance, follow the attached installation instructions. This includes using
the provided power cord and shielded interface cables when connecting to computer or peripheral
devices. Also, any unauthorized changes or modications to this equipment could void the user’s
authority to operate this device.
This is a device to project images onto a screen, etc., and is not intended for use as indoor lighting in a
domestic environment.
Directive 2009/125/EC
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
WARNING: RISK OF ELECTRIC SHOCK. DON’T OPEN
or
Indicated on the projector
The lightning ash with arrowhead symbol, within an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may
be of sufcient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
product.

6 - ENGLISH
Read this rst!
WARNING: Do not look at the light emitted from the lens while the projector is being used.
As with any bright source, do not stare into the direct beam, RG2 IEC 62471-5:2015.
Indicated on the projector
Notice on laser
(for USA and Canada)
This projector is the Class 3R laser product that complies with IEC 60825-1:2007.
DPQT1359ZA
DANGER- CLASS 4 LASER RADIATION WHEN OPEN AVOID EYE OR
SKIN EXPOSURE TO DIRECT OR SCATTERED RADIATION
DANGER- RAYONNEMENT LASER DE CLASSE 4 - EN CAS D'OUVERTURE
EXPOSITION DANGEREUSE AU RAYONNEMENT DIRECT OU
DIFFUS DES YEUX OU DE LA PEAU
(Inside of product)
Indicated on the projector
(for India)
This projector is the Class 1 laser product that complies with IEC/EN 60825-1:2014.

ENGLISH - 7
Read this rst!
(for other countries or regions)
This projector is the Class 1 laser product that complies with IEC/EN 60825-1:2014.
CAUTION: Use of controls or adjustments or performance of procedures other than those specied herein
may result in hazardous radiation exposure.
CAUTION (North/Middle/South America/Taiwan)
Power Supply: This Projector is designed to operate on 100 V - 240 V, 50 Hz/60 Hz AC, house current only.
CAUTION: The AC power cord which is supplied with the projector as an accessory can only be used for
power supplies up to 125 V. If you need to use higher voltages than this, you will need to obtain a
separate 250 V power cord. If you use the accessory cord in such situations, re may result.
CAUTION (North/Middle/South America/Taiwan)
This equipment is equipped with a three-pin grounding-type power plug. Do not
remove the grounding pin on the power plug. This plug will only t a grounding-type
power outlet. This is a safety feature. If you are unable to insert the plug into the
outlet, contact an electrician. Do not defeat the purpose of the grounding plug.
Do not remove
WARNING (USA and Canada)
fNot for use in a computer room as dened in the Standard for the Protection of Electronic Computer/Data
Processing Equipment, ANSI/NFPA 75.
fFor permanently connected equipment, a readily accessible disconnect device shall be incorporated in the
building installation wiring.
fFor pluggable equipment, the socket-outlet shall be installed near the equipment and shall be easily
accessible.
NOTIFICATION (Canada)
This class A digital apparatus complies with Canadian ICES-003.
For USA-California Only
This product contains a CR Coin Cell Lithium Battery which contains Perchlorate Material – special handling
may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate

8 - ENGLISH
Read this rst!
FCC NOTICE (USA)
Supplier’s Declaration of Conformity
Model Number: PT-MZ770 / PT-MZ770L / PT-MZ770LB / PT-MW730 / PT-MW730L
Trade Name: Panasonic
Responsible Party: Panasonic Corporation of North America
Address: Two Riverfront Plaza, Newark, NJ 07102-5490
General Contact: http://www.panasonic.com/support
Projector Contact: https://panasonic.net/cns/projector/
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution:
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct the interference at his own
expense.
FCC Warning:
To assure continued compliance, follow the attached installation instructions. This includes using the provided
power cord and shielded interface cables when connecting to computer or peripheral devices. Also, any
unauthorized changes or modications to this equipment could void the user’s authority to operate this device.

ENGLISH - 9
Read this rst!
IMPORTANT: THE MOLDED PLUG
FOR YOUR SAFETY, PLEASE READ THE FOLLOWING TEXT CAREFULLY.
This appliance is supplied with a molded three pin mains plug for your safety and convenience. A 13 amp fuse
is tted in this plug. Should the fuse need to be replaced, please ensure that the replacement fuse has a rating
of 13 amps and that it is approved by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark on the body of the fuse.
If the plug contains a removable fuse cover, you must ensure that it is retted when the fuse is replaced. If you
lose the fuse cover, the plug must not be used until a replacement cover is obtained. A replacement fuse cover
can be purchased from an Authorized Service Center.
If the tted molded plug is unsuitable for the mains socket in your home, then the fuse should be
removed and the plug cut off and disposed of safely. There is a danger of severe electrical shock if the
cut off plug is inserted into any 13 amp socket.
If a new plug is to be tted, please observe the wiring code as shown below.
If in any doubt, please consult a qualied electrician.
WARNING: THIS APPLIANCE MUST BE EARTHED.
IMPORTANT: The wires in this mains lead are colored in accordance with the following code:
Green - and - Yellow: Earth
Blue: Neutral
Brown: Live
As the colors of the wire in the mains lead of this appliance may not correspond with the colored markings
identifying the terminals in your plug, proceed as follows.
The wire which is colored GREEN - AND - YELLOW must be connected to the terminal in the plug
which is marked with the letter E or by the Earth symbol or colored GREEN or GREEN - AND -
YELLOW.
The wire which is colored BLUE must be connected to the terminal in the plug which is marked
with the letter N or colored BLACK.
The wire which is colored BROWN must be connected to the terminal in the plug which is marked
with the letter L or colored RED.
How to replace the fuse: Open the fuse compartment with a screwdriver and replace the fuse.
Importer’s name and address within the European Union
Panasonic Marketing Europe GmbH
Panasonic Testing Centre
Winsbergring 15, 22525 Hamburg, Germany

10 - ENGLISH
Read this rst!
Hazard distance (IEC 62471-5:2015)
The distance at which the level of exposure has reached the level of the applicable Exposure Limit Value is known
as the hazard distance (HD) or safety distance.
Do not look into the projected light from inside the hazard distance (within RG3 range). The eyes may be damaged
by the direct irradiation. It is considered to be safe to look into the projected light from outside the hazard distance
(within RG2 range).
RG2
HD
D3
D4
RG3
RG2
HD
D1
D2
RG3
(Unit: m)
Lens HD*1 D1*2 D2*2 D3*2 D4*2
ET-ELW21
< 1.0
0.97 0.97 1.13 1.13
ET-ELW22 0.89 0.89 1.03 1.03
ET-ELW20 0.62 0.62 0.72 0.72
Standard Zoom Lens/
ET-ELS20 0.47 0.47 0.55 0.55
ET-ELT22 0.29 0.29 0.34 0.34
ET-ELT23 0.19 0.19 0.23 0.23
*1 HD: Hazard Distance
*2 D1, D2, D3, and D4 change in accordance with projection lens shift amount. Each value in this table represents the maximum range.
Note
fThe values in the table comply with IEC 62471-5:2015.

ENGLISH - 11
Read this rst!
WARNING:
rPOWER
The wall outlet or the circuit breaker shall be installed near the equipment and shall be easily accessible
when problems occur. If the following problems occur, cut off the power supply immediately.
Continued use of the projector in these conditions will result in re or electric shock, or will cause visual
impairment.
fIf foreign objects or water get inside the projector, cut off the power supply.
fIf the projector is dropped or the cabinet is broken, cut off the power supply.
fIf you notice smoke, strange smells or noise coming from the projector, cut off the power supply.
Please contact an Authorized Service Center for repairs, and do not attempt to repair the projector yourself.
During a thunderstorm, do not touch the projector or the cable.
Electric shocks can result.
Do not do anything that might damage the power cord or the power plug.
If the power cord is used while damaged, electric shocks, short-circuits or re will result.
fDo not damage the power cord, make any modications to it, place it near any hot objects, bend it
excessively, twist it, pull it, place heavy objects on top of it or wrap it into a bundle.
Ask an Authorized Service Center to carry out any repairs to the power cord that might be necessary.
Do not use anything other than the provided power cord.
Failure to observe this will result in electric shocks or re. Please note that if you do not use the provided power
cord to ground the device on the side of the outlet, this may result in electric shocks.
Completely insert the power plug into the wall outlet and the power connector into the projector terminal.
If the plug is not inserted correctly, electric shocks or overheating will result.
fDo not use plugs which are damaged or wall outlets which are coming loose from the wall.
Do not handle the power plug and power connector with wet hands.
Failure to observe this will result in electric shocks.
Do not overload the wall outlet.
If the power supply is overloaded (ex., by using too many adapters), overheating may occur and re will result.
Clean the power plug regularly to prevent it from becoming covered in dust.
Failure to observe this will cause a re.
fIf dust builds up on the power plug, the resulting humidity can damage the insulation.
fIf not using the projector for an extended period of time, pull the power plug out from the wall outlet.
Pull the power plug out from the wall outlet and wipe it with a dry cloth regularly.
rON USE/INSTALLATION
Do not place the projector on soft materials such as carpets or sponge mats.
Doing so will cause the projector to overheat, which can cause burns, re or damage to the projector.
Do not set up the projector in humid or dusty places or in places where the projector may come into
contact with oily smoke or steam.
Using the projector under such conditions will result in re, electric shocks or deterioration of components. Oil
may also distort the plastic and the projector could fall such as when mounted on the ceiling.
Do not install this projector in a place which is not strong enough to take the full weight of the projector
or on top of a surface which is sloped or unstable.
Failure to observe this will cause projector to fall down or tip over the projector, and severe injury or damage
could result.
Do not install the projector in a location where people pass through.
People may bump into the projector or trip on the power cord, which may result in re, electric shock, or injury.
Do not cover the air intake/exhaust ports.
Doing so will cause the projector to overheat, which can cause re or damage to the projector.
fDo not place the projector in narrow, badly ventilated places.
fDo not place the projector on cloth or papers, as these materials could be drawn into the air intake port.
fProvide at least 1 m (39-3/8") of space between any walls or objects and the exhaust port, and at least
50 cm (19-11/16") of space between any walls or objects and the intake port.

12 - ENGLISH
Read this rst!
WARNING:
Do not look at or place your skin into the light emitted from the lens while the projector is being used.
Do not enter the projection luminous ux using an optical device (such as magnier or mirror).
Doing so can cause burns or loss of sight.
fStrong light is emitted from the projector’s lens. Do not look at or place your hands directly into this light.
fBe especially careful not to let young children look into the lens. In addition, turn off the power and
disconnect the power plug when you are away from the projector.
Do not project an image with the lens cover attached.
Doing so can cause re.
Never attempt to remodel or disassemble the projector.
High voltages can cause re or electric shocks.
fFor any inspection, adjustment and repair work, please contact an Authorized Service Center.
Do not allow metal objects, ammable objects, or liquids to enter inside of the projector. Do not allow
the projector to get wet.
Doing so may cause short circuits or overheating, and result in re, electric shock, or malfunction of the
projector.
fDo not place containers of liquid or metal objects near the projector.
fIf liquid enters inside of the projector, consult your dealer.
fParticular attention must be paid to children.
Use the ceiling mount bracket specied by Panasonic.
Using the ceiling mount bracket other than the specied one will result in falling accidents.
fAttach the supplied safety cable to the ceiling mount bracket to prevent the projector from falling down.
Installation work such as mounting the projector on the ceiling should only be carried out by a qualied
technician.
If installation is not carried out and secured correctly, it can cause injury or accidents, such as electric shocks.
rACCESSORIES
Do not use or handle the batteries improperly, and refer to the following.
Failure to observe this will cause burns, batteries to leak, overheat, explode or catch re.
fDo not use unspecied batteries.
fDo not charge dry cell batteries.
fDo not disassemble dry cell batteries.
fDo not heat the batteries or place them into water or re.
fDo not allow the + and – terminals of the batteries to come into contact with metallic objects such as
necklaces or hairpins.
fDo not store or carry batteries together with metallic objects.
fStore the batteries in a plastic bag and keep them away from metallic objects.
fMake sure the polarities (+ and –) are correct when inserting the batteries.
fDo not use a new battery together with an old battery or mix different types of batteries.
fDo not use batteries with the outer cover peeling away or removed.
If the battery uid leaks, do not touch it with bare hands, and take the following measures if necessary.
fBattery uid on your skin or clothing could result in skin inammation or injury.
Rinse with clean water and seek medical advice immediately.
fBattery uid coming in contact with your eyes could result in loss of sight.
In this case, do not rub your eyes. Rinse with clean water and seek medical advice immediately.
Do not allow children to reach the batteries.
Accidentally swallowing them can cause physical harm.
fIf swallowed, seek medical advice immediately.
Remove the depleted batteries from the remote control promptly.
fLeaving them in the unit may result in uid leakage, overheating, or explosion of the batteries.

ENGLISH - 13
Read this rst!
CAUTION:
rPOWER
When disconnecting the power cord, be sure to hold the power plug and power connector.
If the power cord itself is pulled, the lead will become damaged, and re, short-circuits or serious electric shocks
will result.
When not using the projector for an extended period of time, disconnect the power plug from the wall
outlet.
Failure to do so may result in re or electric shock.
Before replacing the projection lens, be sure to turn off the power and disconnect the power plug from
the wall outlet.
fUnexpected projection of light may cause injury to eyes.
fReplacing the projection lens without removing the power plug may result in electric shock.
Disconnect the power plug from the wall outlet before carrying out any cleaning and replacing the unit.
Failure to do so may result in electric shock.
rON USE/INSTALLATION
Do not place heavy objects on top of the projector.
Failure to observe this will cause the projector to become unbalanced and fall, which could result in damage or
injury. The projector will be damaged or deformed.
Do not put your weight on this projector.
You could fall or the projector could break, and injury will result.
fBe especially careful not to let young children stand or sit on the projector.
Do not place the projector in extremely hot locations.
Doing so will cause the outer casing or internal components to deteriorate, or result in re.
fTake particular care in locations exposed to direct sunlight or near heaters.
Do not place your hands in the openings beside the optical lens, while shifting the lens.
Failure to observe this could cause injury.
Do not install the projector in a location where salt pollution or corrosive gas may occur.
Doing so may result in falling due to corrosion. Also, it may result in malfunctions.
Do not stand in front of the lens while the projector is being used.
Doing so can cause damage and burns to clothing.
fStrong light is emitted from the projector’s lens.
Do not place objects in front of the lens while the projector is being used.
Do not block the projection by placing an object in front of the projection lens.
Doing so can cause re, damage to an object, or malfunction of the projector.
fStrong light is emitted from the projector’s lens.
Always disconnect all cables before moving the projector.
Moving the projector with cables still attached can damage the cables, which will cause re or electric shocks to
occur.
Never plug headphones and earphones into <VARIABLE AUDIO OUT> terminal.
Excessive sound pressure from headphones and earphones can cause hearing loss.
When mounting the projector on the ceiling, keep mounting screws and power cord from contact with
metal parts inside the ceiling.
Contact with metal parts inside the ceiling can cause electric shocks.

14 - ENGLISH
Read this rst!
CAUTION:
rACCESSORIES
When not using the projector for an extended period of time, remove the batteries from the remote
control.
Failure to observe this will cause the batteries to leak, overheat, catch re or explode, which may result in re or
contamination of surrounding area.
rMAINTENANCE
Do not attach the air lter unit while it is wet.
Doing so may result in electric shock or malfunctions.
fAfter you clean the air lter units, dry them thoroughly before reattaching them.
Ask your dealer about cleaning inside the projector every 20 000 hours of usage as an estimated
duration.
Continuous use while dust is accumulated inside the projector may result in re.
fFor cleaning fee, ask your dealer.
To remove the battery
Remote Control Battery
1. Press the guide and lift the cover.
(ii)
(i)
2. Remove the batteries.

ENGLISH - 15
Read this rst!
Brazil Only
Brasil Apenas
rManuseio de baterias usadas
BRASIL
Após o uso, as pilhas e/ou baterias deverão
ser entregues ao estabelecimento comercial
ou rede de assistência técnica autorizada.
Cobrir os terminais positivo (+) e negativo (-) com uma ta isolante adesiva, antes de depositar numa caixa
destinada para o recolhimento. O contato entre partes metálicas pode causar vazamentos, gerar calor, romper
a blindagem e produzir fogo. (Fig. 1)
Fig. 1
Como isolar os terminais
Não desmonte, não remova o invólucro, nem amasse a bateria. O gás liberado pela bateria pode irritar a
garganta, danicar o lacre do invólucro ou o vazamento provocar calor, ruptura da blindagem e produzir fogo
devido ao curto circuito dos terminais. Não incinere nem aqueça as baterias, elas não podem car expostas a
temperaturas superiores a 100 °C (212 °F). O gás liberado pela bateria pode irritar a garganta, danicar o lacre
do invólucro ou o vazamento provocar calor, ruptura da blindagem e produzir fogo devido ao curto circuito dos
terminais provocado internamente.
Evite o contato com o liquido que vazar das baterias. Caso isto ocorra, lave bem a parte afetada com bastante
água. Caso haja irritação, consulte um médico.
rRemoção das baterias
1. Pressione a guia e levante a tampa.
(ii)
(i)
2. Remova as baterias.
Fita Isolante
Fita Isolante

16 - ENGLISH
rTrademarks
fSOLID SHINE is a trademark of Panasonic Corporation.
fPanasonic owns patents relating to Light ID technology in Japan and other countries.
f“LinkRay” and the icon are trademarks of Panasonic Corporation.
fWi-Fi®, Wi-Fi DirectTM and MiracastTM are registered trademarks or trademarks of Wi-Fi Alliance.
fWindows, Internet Explorer and Microsoft Edge are registered trademarks or trademarks of Microsoft
Corporation in the United States and other countries.
fMac, macOS, and Safari are trademarks of Apple Inc., registered in the United States and other countries.
fPJLinkTM is a registered trademark or pending trademark in Japan, the United States, and other countries and
regions.
fThe terms HDMI and HDMI High-Denition Multimedia Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
fCrestron Connected, the Crestron Connected logo, Crestron Fusion, Crestron RoomView, and RoomView are
trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or other countries.
fHDBaseTTM is a trademark of HDBaseT Alliance.
fIOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license.
fAndroid is a trademark of Google Inc.
fQR Code is a registered trademark of DENSO WAVE INCORPORATED in Japan and in other countries.
fAdobe, Adobe Flash Player, and Adobe Reader are trademarks or registered trademarks of Adobe Systems Inc.
in the United States and/or other countries.
fSome of the fonts used in the on-screen menu are Ricoh bitmap fonts, which are manufactured and sold by
Ricoh Company, Ltd.
fThis product is licensed under AVC Patent Portfolio License, VC-1 Patent Portfolio License, and MPEG-4 Visual
Patent Portfolio License, and following actions except for the personal or non-prot use are not licensed.
gRecording the image information in compliance with the AVC standard, the VC-1 standard, and the MPEG-4
Visual standard (AVC/VC-1/MPEG-4 video hereafter)
gPlaying back the AVC/VC-1/MPEG-4 video recorded by consumer practicing in a private activity, or AVC/VC-1/
MPEG-4 video acquired from the licensed provider
For details, refer to the website of MPEG LA, LLC (http://www.mpegla.com).
fAll other names, company names, and product names mentioned in this manual are trademarks or registered
trademarks of their respective owners.
Please note that the ®and TM symbols are not specied in this manual.
rSoftware information regarding this product
This product incorporates the following software:
(1) the software developed independently by or for Panasonic Corporation,
(2) the software owned by third party and licensed to Panasonic Corporation,
(3) the software licensed under the GNU General Public License, Version 2.0 (GPL V2.0),
(4) the software licensed under the GNU LESSER General Public License, Version 2.1 (LGPL V2.1), and/or
(5) open source software other than the software licensed under the GPL V2.0 and/or LGPL V2.1.
The software categorized as (3) - (5) are distributed in the hope that it will be useful, but WITHOUT ANY
WARRANTY, without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR
PURPOSE. Please refer to the detailed terms and conditions thereof shown in the attached CD-ROM.
At least three (3) years from delivery of this product, Panasonic will give to any third party who contacts us at
the contact information provided below, for a charge no more than our cost of physically performing source code
distribution, a complete machine-readable copy of the corresponding source code covered under GPL V2.0, LGPL
V2.1 or the other licenses with the obligation to do so, as well as the respective copyright notice thereof.
Contact Information: [email protected]
rIllustrations in this manual
fIllustrations of the projector, menu screen (OSD), and other parts may vary from the actual product.
fIllustrations displayed on the computer screen may differ depending on the computer type and its operating
system.
fIllustrations of the projector with the power cord attached are only examples. The shape of the supplied power
cords varies depending on the country where you purchased the product.

ENGLISH - 17
rReference pages
fReference pages in this manual are indicated as (xpage 00).
rTerm
fIn this manual, the “Wireless/wired remote control unit” accessory is referred to as “Remote control”.

18 - ENGLISH
Features of the Projector
High picture quality
▶With a unique optical system which uses
a new-generation laser light source, and
the laser light source drive system, high
luminance of 8 000 lm and high contrast
of 3 000 000:1*1 are achieved even with its
compact size. Also, 4K video signal input is
supported.
*1 When [PICTURE MODE] is set to [DYNAMIC], and
[DYNAMIC CONTRAST] is set to [1] or [2]
Easy and highly exible setup
▶In addition to the lens replacement method
and equipping of the lens shift, usage
in a wide range of application is made
possible by supporting a wide range of
interfaces such as DIGITAL LINK, and by
supporting the 360° installation utilizing the
characteristics of solid-sate light source.
Long life and high reliability
▶The maintenance cost for long-term
operation is reduced by the unique light
source cooling control technology and
improvement of the dust resistance.
Quick Steps
For details, refer to the corresponding pages.
1. Set up the projector.
(xpage 36)
2. Attach the projection lens.
(xpage 50)
3. Connect with external devices.
(xpage 52)
4. Connect the power cord.
(xpage 58)
5. Switch on the projector.
(xpage 60)
6. Make initial settings.
(xpage 61)
fTake this step when you switch on the
power for the rst time after purchasing the
projector.
7. Select the input signal.
(xpage 67)
8. Adjust the image.
(xpage 68)

ENGLISH - 19
Chapter 1 Preparation
This chapter describes things you need to know or check before using the projector.

Chapter 1 Preparation — Precautions for use
20 - ENGLISH
Precautions for use
Intended use of the product
The product is intended to project still/moving image signals from video equipment and computers onto a screen.
Lens protection material
If you purchased the projector with the standard zoom lens, remove the lens protection material before use, and
store it for the future use. Move the lens position to the home position and attach the lens protection material
when transporting.
If you purchased the projector with the lens sold separately, remove the lens hole cover before use, and store it
for the future use. Move the lens position to the home position, remove the projection lens, and attach the lens
hole cover when transporting.
For the steps to move the lens position to the home position, refer to “Moving the lens position to the home
position” (xpage 69).
Lens protection material Lens hole cover
Cautions when transporting
fWhen transporting the projector, hold it securely by its bottom and avoid excessive vibration and impacts. They
may damage the internal components and result in malfunctions.
fDo not transport the projector with the adjustable feet extended. Doing so may damage the adjustable feet.
Cautions when installing
rDo not set up the projector outdoors.
The projector is designed for indoor use only.
rDo not set up the projector in the following locations.
fPlaces where vibration and impacts occur such as in a car or vehicle: Doing so may cause damage to internal
components or malfunction.
fLocation close to sea or where corrosive gas may occur: The projector may fall due to corrosion. Also, failure to
do so may shorten the life of the components and result in malfunction.
fNear the exhaust of an air conditioner: Depending on the conditions of use, the screen may uctuate in rare
cases due to the heated air from the air exhaust port or the hot or cooled air from the air conditioner. Make sure
that the exhaust from the projector or other equipment, or the air from the air conditioner does not blow toward
the front of the projector.
fPlaces with sharp temperature uctuations such as near lights (studio lamps): Doing so may shorten the life of
the light source, or result in deformation of the projector due to heat, which may cause malfunctions.
Follow the operating environment temperature of the projector.
fNear high-voltage power lines or near motors: Doing so may interfere with the operation of the projector.
