Panasonic PT-DZ870K User manual

Product Number : PT-DZ870K/DZ870W
PT-DZ870LK/DZ870LW
Product Name : DLP™Projectors
SPEC FILE
1/25
SFD13M004-2
As of September 2013. Specifications and appearance are subject to change without notice.

Main unit
Power supply
Power consumption 120–240 V AC, 50/60 Hz
DLP™ chip Panel size
Display method
Pixels
Lens PT-DZ870K/DZ870W
PT-DZ870LK/DZ870LW
Lamp
Screen size
Brightness*2
Center-to-corner uniformity*2
Contrast*2
Resolution
HDMI/DVI-D
RGB
YPBPR(YCBCR)
Video/S-Video
Optical axis shift
120–240 V AC, 10–5.2 A, 50/60 Hz
1,030 W (1,060 VA) (0.3 W with STANDBY MODE set to ECO*1, 3 W with
STANDBY MODE set to NORMAL)
17.0 mm (0.67 in) diagonal (16:10 aspect ratio)
DLP™ chip × 1, DLP™ system
2,304,000 (1,920 × 1,200) × 1, total of 2,304,000 pixels
Powered zoom/focus lenses (1.7–2.4:1), F 1.7–1.9, f 25.6–35.7 mm
Optional powered zoom/focus lenses and fixed-focus lens
420 W UHM lamps (× 2)
1.27–15.24 m (50 – 600 inches)
*1.27 – 5.08 m (50 – 200 inches) with the ET-DLE055 (16:10 aspect ratio)
*2.54 – 8.89 m (100 – 350 inches) with the ET-DLE030 (16:10 aspect ratio)
8,500 lumens (dual lamp, LAMP MODE: NORMAL)
90%
10,000:1 (full on/full off, in dynamic iris 3 mode)
1,920 × 1,200 pixels
fH: 15–100 kHz, fV: 24–120 Hz, dot clock: 25–162 MHz
fH: 15–100 kHz, fV: 24–120 Hz, dot clock: 162 MHz or lower
525i (480i): fH15.75 kHz; fV60 Hz,
625i (576i): fH15.63 kHz; fV50 Hz,
525p (480p): fH31.50 kHz; fV60 Hz,
625p (576p): fH31.25 kHz; fV50 Hz,
750 (720)/60p: fH45.00 kHz; fV60 Hz,
750 (720)/50p: fH37.50 kHz; fV50 Hz,
1125 (1035)/60i: fH33.75 kHz; fV60 Hz,
1125 (1080)/60i: fH33.75 kHz; fV60 Hz,
1125 (1080)/50i: fH28.13 kHz; fV50 Hz,
1125 (1080)/25p: fH28.13 kHz; fV25 Hz,
1125 (1080)/24p: fH27.00 kHz; fV24 Hz,
1125 (1080)/24sF: fH27.00 kHz; fV48 Hz,
1125 (1080)/30p: fH33.75 kHz; fV30 Hz,
1125 (1080)/60p: fH67.50 kHz; fV60 Hz,
1125 (1080)/50p: fH56.25 kHz; fV50 Hz
fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60]
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Vertical: +50% (powered), horizontal: ±10% (powered)
NOTE: Optical
If using the ET-DLE030, the optical axis is fixed.
axis shift function cannot be operated when used with the ET-DLE055.
Specifications
Scanning frequency SDI 3G-SDI signal (RGB 4:4:4 12-bit/10-bit):
SMPTE ST 424 compliant: 1125(1080)/60i, 1125(1080)/50i,
1125(1080)/25p, 1125(1080)/24p, 1125(1080)/24sF, 1125(1080)/30p
3G-SDI signal (YPBPR4:2:2 10-bit):
SMPTE ST 424 compliant: 1125(1080)/60p, 1125(1080)/50p
HD-SDI signal (YPBPR4:2:2 10-bit):
SMPTE ST 292 compliant: 750(720)/60p, 750(720)/50p, 1125(1035)/60i,
1125(1080)/60i, 1125(1080)/50i, 1125(1080)/25p, 1125(1080)/24p,
1125(1080)/24sF, 1125(1080)/30p
SD-SDI signal (YCBCR4:2:2 10-bit):
SMPTE ST 259 compliant: 525i(480i), 625i(576i)
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 2 / 2 5
SFD13M004-2

Terminals SDI IN
HDMI IN
DVI-D IN
RGB 1 IN
R, G, B
Y, PB, PR(Y, CB, CR)
S-Video signal
RGB 2 IN
R, G, B
Y, PB, PR(Y, CB, CR)
VIDEO IN
3D SYNC 1 IN/OUT
3D SYNC 2 OUT
BNC × 1,
3G-SDI signal: SMPTE ST 424 compliant
HD-SDI signal: SMPTE ST 292 compliant
SD-SDI signal: SMPTE ST 259 compliant
HDMI 19-pin × 1, Deep Color, compatible with HDCP,
VGA (640 × 480) – WUXGA*5(1,920 × 1,200),
dot clock: 25 MHz –162 MHz
NOTE: Compatible with non-interlaced signals only.
DVI-D 24-pin × 1, DVI 1.0 compliant, HDCP compatible,
for single link only
525i(480i)*4, 625i(576i)*4, 525p(480p), 625p(576p), 750(720)/60p,
750(720)50p, 1125(1080)/60i, 1125(1080)/50i, 1125(1080)/25p,
1125(1080)/24p, 1125(1080)/24sF, 1125(1080)/30p, 1125(1080)/60p,
1125(1080)/50p
VGA (640 × 480) – WUXGA*5(1,920 × 1,200),
dot clock: 25 MHz –162 MHz
NOTE: Compatible with non-interlaced signals only.
BNC × 5
R: 0.7 Vp-p, 75 ohms,
G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms,
B: 0.7 Vp-p, 75 ohms
HD, VD/SYNC: TTL, high impedance, positive/negative automatic
NOTE: SYNC/HD and VD terminals do not accept tri-level sync signals.
Y: 1.0 Vp-p (including sync signal), PB/PR(CB/CR): 0.7 Vp-p, 75 ohms
Y: 1.0 Vp-p, C: 0.286 Vp-p, 75 ohms
D-sub HD 15-pin (female) × 1
R: 0.7 Vp-p, 75 ohms,
G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms,
B: 0.7 Vp-p, 75 ohms
HD, VD/SYNC: TTL, high impedance, positive/negative automatic
NOTE: SYNC/HD and VD terminals do not accept tri-level sync signals.
Y: 1.0 Vp-p (including sync signal), PB/PR(CB/CR): 0.7 Vp-p, 75 ohms
BNC × 1, 1.0 Vp-p, 75 ohms
BNC × 1, 1.0 Vp-p, 75 ohms
Input: TTL, high impedance. Output: TTL, max. 10 mA
BNC × 1, 1.0 Vp-p, 75 ohms, TTL, max. 10 mA
525i(480i)*4, 625i(576i)*4, 525p(480p), 625p(576p), 750(720)/60p,
750(720)50p, 1125(1080)/60i, 1125(1080)/50i, 1125(1080)/25p,
1125(1080)/24p, 1125(1080)/24sF, 1125(1080)/30p, 1125(1080)/60p,
1125(1080)/50p
REMOTE 2 IN D-sub 9-pin × 1 for external control (parallel)
SERIAL IN
SERIAL OUT
REMOTE 1 IN
REMOTE 1 OUT
D-sub 9-pin (female)
(female)
× 1 for external control (RS-232C compliant)
D-sub 9-pin (male) × 1 for link control
M3 jack × 1 for wired remote control
M3 jack × 1 for link control
(RS-232C compliant)
Installation Ceiling/floor, front/rear
Vertical ±40°
(vertical ±30° with the ET-DLE085/DLE055, vertical +5° with
the ET-DLE030)
When using only the KEYSTONE correction of the Geometric Adjustment
function: Vertical ±40°, horizontal ±15°
(vertical ±30° and horizontal ±15° with the ET-DLE085/DLE055)
When using the optional upgrade kit ET-UK20*3:
Vertical ±45° and horizontal ±40°
(vertical ±22° and horizontal ±15° with the ET-DLE085/DLE055,
vertical +5° with the ET-DLE030)
When using both the KEYSTONE and CURVED corrections of the Geometric
Adjustment function: Vertical ±20°, horizontal ±15°
(vertical ±8° and horizontal ±8° with the ET-DLE085/DLE055)
Keystone correction range
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 3 / 2 5
SFD13M004-2

Supplied accessories
Optional accessories
Digital interface box
Zoom lens (1.3 – 1.9:1)
Zoom lens (2.3 – 3.6:1)
Zoom lens (3.6 – 5.4:1)
Zoom lens (5.4 – 8.6:1)
Fixed-focus lens (0.8:1)
Fixed-focus lens (0.4:1)
Ceiling mount bracket
Power cord (× 1) (× 2 for PT-DZ870EK/DZ870EW/DZ870ELK/DZ870ELW)
Wireless/wired remote control unit (× 1)
Batteries for remote control (AAA type × 2)
Software CD-ROM (Logo Transfer Software, Multi Projector Monitoring
& Control Software) (× 1)
ET-YFB100G
Zoom lens (0.8–1.0:1) ET-DLE085
ET-DLE150
ET-DLE250
ET-DLE350
ET-DLE450
ET-DLE030
ET-DLE055
ET-PKD120H (for high ceilings)
ET-PKD120S (for low ceilings)
High-ceiling mount bracket
(6-axis adjustment mechanism)
ET-PKD130H
Remote control unit
Power supply
Operation range*9
Dimensions (W × H × D)
Weight
3 V DC (AAA type battery × 2)
Approx. 30 m (98 ft 5 in) when operated from directly in front of the
signal receptor
48 × 145 × 27 mm (1-28/32 × 5-23/32 × 1-1/16 inches)
Approx. 102 g (3.6 oz) (including batteries)
Power cord length
Cabinet materials
Dimensions (W × H × D) PT-DZ870K/DZ870W
PT-DZ870LK/DZ870LW
Weight* PT-DZ870K/DZ870W
PT-DZ870LK/DZ870LW
Operation noise*2
7
Operating temperature
Operating humidity
3.0 m (9 ft 10 in)
Molded plastic
498 × 200* 6× 556 mm
(19-19/32 × 7-7/8*6× 21-7/8 inches) (with supplied lens)
498 × 200* 6× 513 mm
(19-19/32 × 7-7/8*6× 20-3/16 inches) (without lens)
Approx. 18.3 kg (40.3 lbs) (with supplied lens)
Approx. 17.6 kg (38.8 lbs) (without lens)
40 dB (dual lamp operation, LAMP MODE: NORMAL),
35 dB (dual lamp operation, LAMP MODE: ECO)
0 – 45 °C (32 –113 °F) * 8
10%–80% (no condensation)
Upgrade kit
Replacement lamp unit
Replacement lamp unit for portrait mode
Attachment for ceiling mount bracket ET-PKD130H/PKD120B
ET-UK20
ET-LAD120
ET-LAD120W (Twin Pack)
ET-LAD120P
ET-LAD120PW (Twin Pack)
connection, 100Base-TX, compatible with Art-Net, compliant with
PJLink™ (class 1), Deep Color, compatible with HDCP,
VGA (640 × 480) – WUXGA*4(1,920 × 1,200),
dot clock: 25 MHz –162 MHz
NOTE: Compatible with non-interlaced signals only.
525i(480i)*4, 625i(576i)*4, 525p(480p), 625p(576p), 750(720)/60p,
750(720)50p, 1125(1080)/60i, 1125(1080)/50i, 1125(1080)/25p,
1125(1080)/24p, 1125(1080)/24sF, 1125(1080)/30p, 1125(1080)/60p,
1125(1080)/50p
LAN/DIGITAL LINK RJ-45 × 1 for network and DIGITAL LINK (video/network/serial control)
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 4 / 2 5
SFD13M004-2

498 (19/32)
513 (20-3/16)
43
(1-11/16)
556 (21-7/8)
21
(13/16)
95
(3-3/4)
179 (7-1/16)
200 (7-7/8)
28
(1-3/32)
442 (13/32) 432 (17)
Dimensions
unit : mm (inch)
NOTE: This illustration is not drawn to scale.
The illustration shows the PT-DZ870K/DZ870W.
Terminals
1
8 9 10 11 12 13 14
2 3 4 5 6 7 1 Remote 1 input
2 Remote 1 output
3 Remote 2 input
4 Serial input
5 Serial output
6 3D sync 1 input/output
7 3D sync 2 output
8 SDI input
9 Video input
10 RGB 1 input
11 RGB 2 Input
12 DVI-D input
13 HDMI input
14 LAN/DIGITAL LINK connector
Weights and dimensions shown are approximate. Specifications and appearance are subject to change without notice.
*1 When the STANDBY MODE is set to ECO, network functions such as power on over the LAN network will not operate, and the serial output terminal
cannot be used. Also, only certain commands can be received for external control using the serial terminal.
*2 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.
*6 With
*7 Average value. May differ depending on models.
legs at shortest position.
*8 The operating temperature range is 0 °C to 40 °C (32 °F to 104 °F) when the fan control is set to High Altitude mode (for altitudes from 1,400 m
to 2,700 m (4,593 ft to 8,858 ft) above sea level). Also, if the ambient temperature exceeds 40 °C (104 °F) (35 °C (95 °F) in High Altitude mode)
when the projector is being used with Lamp Select set to Dual and Lamp Power set to High, the light output may be reduced approximately
20% to protect the projector.
*9 Operation range differs depending on environments.
*3 Up to a total of ±55° during simultaneous horizontal and vertical correction.
*4 Only compatible with dot clock frequency of 27 MHz (pixel repetition signal)
*5 WUXGA resolution is supported only when the signals are compliant with VESA CVT-RB (Coordinated Video Timing-Reduced Blanking).
DIGITAL LINK
SDI IN
3D SYNC
IN/OUT OUT
VIDEO IN
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 5 / 2 5
SFD13M004-2

Standard setting-up position (If using other than the ET-DLE030)
Caution:
• All construction work should be done by a qualified technician.
• When mounting to the ceiling, use the special mounting bracket. Furthermore, in order to prevent it from falling
down from the ceiling, use the supplied wire on the mounting bracket.
*1
451.5–531.5*2
(17-25/32– 20-15/16)
100 (3-15/16)
100
(3-15/16)
unit : mm (inch)
*1 When the lens protrudes to the maximum.
84 mm (3-5/16 in) with the ET-DLE085
43 mm (1-11/16 in) with the supplied lens
44 mm (1-23/32 in) with the ET-DLE150
27 mm (1-1/16 in) with the ET-DLE055
*2 Adjustable in 40 mm (1-9/16 in) steps.
NOTE:
Illustrations show the projector
installed using optional ceiling mount
bracket ET-PKD120H, optional bracket
assembly ET-PKD130B/PKD120B and an
optional lens.
This illustration is not drawn to scale.
*2
340–420
(13-3/8–
16-17/32)
45 mm (1-25/32 in) with the ET-DLE250
51 mm (2 in) with the ET-DLE350
95 mm (3-3/4 in) with the ET-DLE450
Projected image
E E
Lower edge of projected image
Upper edge of projected image
L
Projected image
L
L
269244
(10-19/32)(9-19/32)
ø60.5
370
(14-9/16)
259
(10-3/16)
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 6 / 2 5
SFD13M004-2

1.27
1.52
1.78
2.03
2.29
2.54
3.05
3.81
5.08
6.35
7.62
10.16
12.70
15.24
Screen size
(diagonal)
min. max. min. max.
Zoom
Zoom
lenses
Fixed-focus
Fixed-
focus
lens
Distance to screen (L) Height from the edge
of screen to
center of lens (H)
min. max. min. max. min. max.
ET-DLE150
Zoom lens
min.[m] [in] max.
ET-DLE085
Zoom lens
Supplied lens ET-DLE250
Zoom lens
ET-DLE350
Zoom lens
ET-DLE450
Zoom lens
ET-DLE055
Fixed-focus
lens
50
60
70
80
90
100
120
150
200
250
300
400
500
600
/
/
/
/
/
/
/
/
/
/
/
/
/
/
–
–
–
–
–
–
–
–
–
–
–
–
–
–
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.34
0.40
0.47
0.54
0.61
0.67
0.81
1.01
1.35
1.68
2.02
2.69
3.37
4.04
0.83
1.00
1.18
1.35
1.53
1.70
2.05
2.58
3.45
–
–
–
–
–
0.34
0.40
0.47
0.54
0.61
0.67
0.81
1.01
1.35
–
–
–
–
–
2.01
2.43
2.84
3.25
3.66
4.08
4.90
6.14
8.20
10.26
12.33
16.45
20.58
24.70
1.04
1.25
1.47
1.68
1.90
2.11
2.55
3.19
4.27
5.35
6.43
8.59
10.75
12.91
2.57
3.10
3.63
4.16
4.69
5.21
6.27
7.86
10.50
13.15
15.79
26.36
31.65
21.08
3.87
4.65
5.44
6.23
7.02
7.81
9.39
11.75
15.70
19.64
23.59
31.48
39.37
47.26
5.82
7.00
8.19
9.38
10.57
11.76
14.14
17.71
23.66
29.61
35.56
47.46
59.36
71.26
9.12
11.01
12.89
14.78
16.66
18.55
22.32
27.97
37.39
46.81
56.24
75.08
93.93
112.77
1.38
1.66
1.95
2.23
2.52
2.81
3.38
4.24
5.67
7.10
8.53
11.39
14.25
17.11
0.83
1.00
1.17
1.35
1.52
1.70
2.05
2.57
3.44
4.31
5.18
6.93
8.67
10.42
1.82
2.20
2.58
2.95
3.33
3.71
4.47
5.61
7.50
9.39
11.28
18.86
22.64
15.07
2.42
2.92
3.42
3.92
4.42
4.92
5.91
7.41
9.91
12.41
14.91
19.90
24.90
29.89
3.80
4.59
5.38
6.16
6.95
7.74
9.31
11.68
15.61
19.55
23.49
31.36
39.24
47.11
5.66
6.85
8.04
9.24
10.43
11.62
14.00
17.58
23.54
29.50
35.46
47.38
59.30
71.22
Screen size
(diagonal)
min. max. min. max.
Zoom
Zoom
lenses
Fixed-focus
Fixed-
focus
lens
Distance to screen (L) Height from the edge
of screen to
center of lens (H)
min. max. min. max. min. max.
ET-DLE150
Zoom lens
min. max.
ET-DLE085
Zoom lens
Supplied lens ET-DLE250
Zoom lens
ET-DLE350
Zoom lens
ET-DLE450
Zoom lens
ET-DLE055
Fixed-focus
lens
1.27
1.52
1.78
2.03
2.29
2.54
3.05
3.81
5.08
6.35
7.62
10.16
12.70
15.24
[m] [in]
50
60
70
80
90
100
120
150
200
250
300
400
500
600
/
/
/
/
/
/
/
/
/
/
/
/
/
/
–
–
–
–
–
–
–
–
–
–
–
–
–
–
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
1.1
1.3
1.6
1.8
2.0
2.2
2.7
3.3
4.4
5.5
6.6
8.8
11.0
13.3
2.7
3.3
3.9
4.4
5.0
5.6
6.7
8.5
11.3
–
–
–
–
–
1.1
1.3
1.6
1.8
2.0
2.2
2.7
3.3
4.4
–
–
–
–
–
6.6
8.0
9.3
10.7
12.0
13.4
16.1
20.1
26.9
33.7
40.4
54.0
67.5
81.0
3.4
4.1
4.8
5.5
6.2
6.9
8.4
10.5
14.0
17.6
21.1
28.2
35.3
42.3
8.4
10.2
11.9
13.6
15.4
17.1
20.6
25.8
34.5
43.1
51.8
86.5
103.8
69.1
12.7
15.3
17.9
20.4
23.0
25.6
30.8
38.6
51.5
64.4
77.4
103.3
129.2
155.0
19.1
23.0
26.9
30.8
34.7
38.6
46.4
58.1
77.6
97.1
116.7
155.7
194.7
233.8
29.9
36.1
42.3
48.5
54.7
60.8
73.2
91.8
122.7
153.6
184.5
246.3
308.2
370.0
4.5
5.5
6.4
7.3
8.3
9.2
11.1
13.9
18.6
23.3
28.0
37.4
46.7
56.1
2.7
3.3
3.9
4.4
5.0
5.6
6.7
8.4
11.3
14.1
17.0
22.7
28.5
34.2
6.0
7.2
8.5
9.7
10.9
12.2
14.7
18.4
24.6
30.8
37.0
61.9
74.3
49.4
7.9
9.6
11.2
12.8
14.5
16.1
19.4
24.3
32.5
40.7
48.9
65.3
81.7
98.1
12.5
15.1
17.6
20.2
22.8
25.4
30.6
38.3
51.2
64.1
77.1
102.9
128.7
154.6
18.6
22.5
26.4
30.3
34.2
38.1
45.9
57.7
77.2
96.8
116.3
155.4
194.6
233.7
Projection distance for 16:10 aspect ratio screen (If using other than the ET-DLE030)
Unit: feet
Unit: meters
• The value for L (distance to screen) varies slightly within ±5% depending on the zoom lens characteristics.
• The zoom lens characteristics may cause slight image distortion.
• When vertical keystone correction is used, the image is corrected in the direction that reduces its projected size.
• The brightness varies depending on the zoom setting.
Note: When the ET-DLE055 is mounted, the optical lens shift function cannot be used.
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 7 / 2 5
SFD13M004-2

Screen size
(diagonal)
min. max. min. max.
Zoom
Zoom
lenses
Fixed-focus
Fixed-
focus
lens
Distance to screen (L) Height from the edge
of screen to
center of lens (H)
min. max. min. max. min. max.
ET-DLE150
Zoom lens
min. max.
ET-DLE085
Zoom lens
Supplied lens ET-DLE250
Zoom lens
ET-DLE350
Zoom lens
ET-DLE450
Zoom lens
ET-DLE055
Fixed-focus
lens
1.27
1.52
1.78
2.03
2.29
2.54
3.05
3.81
5.08
6.35
7.62
10.16
12.70
15.24
[m] [in]
50
60
70
80
90
100
120
150
200
250
300
400
500
600
/
/
/
/
/
/
/
/
/
/
/
/
/
/
–
–
–
–
–
–
–
–
–
–
–
–
–
–
-0.06
-0.08
-0.09
-0.10
-0.11
-0.13
-0.15
-0.19
-0.25
-0.31
-0.37
-0.50
-0.62
-0.75
0.31
0.37
0.44
0.50
0.56
0.62
0.75
0.93
1.25
1.56
1.87
2.49
3.11
3.74
0.85
1.03
1.21
1.39
1.57
1.75
2.11
2.65
3.55
–
–
–
–
–
0.31
0.37
0.44
0.50
0.56
0.62
0.75
0.93
1.25
–
–
–
–
–
2.07
2.49
2.92
3.34
3.77
4.19
5.04
6.31
8.43
10.55
12.67
16.91
21.15
25.39
1.07
1.29
1.51
1.73
1.95
2.17
2.62
3.28
4.39
5.50
6.61
8.83
11.05
13.27
2.64
3.19
3.73
4.28
4.82
5.36
6.45
8.08
10.80
13.51
16.23
27.10
32.53
21.66
3.98
4.79
5.60
6.41
7.22
8.03
9.65
12.08
16.14
20.19
24.25
32.35
40.46
48.57
5.98
7.20
8.43
9.65
10.87
12.09
14.54
18.21
24.32
30.44
36.55
48.78
61.01
73.24
9.39
11.32
13.26
15.20
17.13
19.07
22.94
28.75
38.44
48.12
57.81
77.18
96.55
115.92
1.42
1.71
2.00
2.30
2.59
2.89
3.47
4.36
5.83
7.29
8.76
11.70
14.64
17.58
0.85
1.03
1.21
1.39
1.57
1.75
2.10
2.64
3.54
4.43
5.33
7.12
8.91
10.71
1.87
2.26
2.65
3.04
3.43
3.82
4.60
5.76
7.71
9.65
11.60
19.38
23.27
15.49
2.49
3.00
3.51
4.03
4.54
5.05
6.08
7.62
10.19
12.76
15.32
20.46
25.59
30.72
3.91
4.72
5.53
6.34
7.15
7.96
9.58
12.00
16.05
20.10
24.14
32.24
40.33
48.42
5.82
7.05
8.28
9.50
10.73
11.95
14.40
18.08
24.20
30.33
36.45
48.71
60.96
73.21
Screen size
(diagonal)
min. max. min. max.
Zoom
Zoom
lenses
Fixed-focus
Fixed-
focus
lens
Distance to screen (L) Height from the edge
of screen to
center of lens (H)
min. max. min. max. min. max.
ET-DLE150
Zoom lens
min. max.
ET-DLE085
Zoom lens
Supplied lens ET-DLE250
Zoom lens
ET-DLE350
Zoom lens
ET-DLE450
Zoom lens
ET-DLE055
Fixed-focus
lens
1.27
1.52
1.78
2.03
2.29
2.54
3.05
3.81
5.08
6.35
7.62
10.16
12.70
15.24
[m] [in]
50
60
70
80
90
100
120
150
200
250
300
400
500
600
/
/
/
/
/
/
/
/
/
/
/
/
/
/
–
–
–
–
–
–
–
–
–
–
–
–
–
–
-0.2
-0.3
-0.3
-0.3
-0.4
-0.4
-0.5
-0.6
-0.8
-1.0
-1.2
-1.6
-2.0
-2.5
1.0
1.2
1.4
1.6
1.8
2.0
2.5
3.1
4.1
5.1
6.1
8.2
10.2
12.3
2.8
3.4
4.0
4.6
5.2
5.7
6.9
8.7
11.7
–
–
–
–
–
1.0
1.2
1.4
1.6
1.8
2.0
2.5
3.1
4.1
–
–
–
–
–
6.8
8.2
9.6
11.0
12.4
13.8
16.5
20.7
27.7
34.6
41.6
55.5
69.4
83.3
3.5
4.2
5.0
5.7
6.4
7.1
8.6
10.8
14.4
18.1
21.7
29.0
36.3
43.5
8.7
10.5
12.2
14.0
15.8
17.6
21.2
26.5
35.4
44.3
53.2
71.1
88.9
13.0
15.7
18.4
21.0
23.7
26.3
31.7
39.6
52.9
66.2
79.5
106.1
132.7
159.4
19.6
23.6
27.6
31.7
35.7
39.7
47.7
59.7
79.8
99.9
119.9
160.0
200.2
240.3
30.8
37.1
43.5
49.9
56.2
62.6
75.3
94.3
126.1
157.9
189.7
253.2
316.8
380.3
4.6
5.6
6.6
7.5
8.5
9.5
11.4
14.3
19.1
23.9
28.8
38.4
48.0
57.7
2.8
3.4
4.0
4.6
5.1
5.7
6.9
8.7
11.6
14.5
17.5
23.4
29.2
35.1
6.1
7.4
8.7
10.0
11.2
12.5
15.1
18.9
25.3
31.7
38.1
50.8
63.6
106.776.4
8.2
9.8
11.5
13.2
14.9
16.6
20.0
25.0
33.4
41.8
50.3
67.1
84.0
100.8
12.8
15.5
18.1
20.8
23.5
26.1
31.4
39.4
52.7
65.9
79.2
105.8
132.3
158.9
19.1
23.1
27.1
31.2
35.2
39.2
47.2
59.3
79.4
99.5
119.6
159.8
200.0
240.2
Unit: feet
Unit: meters
• The value for L (distance to screen) varies slightly within ±5% depending on the zoom lens characteristics.
• The zoom lens characteristics may cause slight image distortion.
• When vertical keystone correction is used, the image is corrected in the direction that reduces its projected size.
• The brightness varies depending on the zoom setting.
Note: When the ET-DLE055 is mounted, the optical lens shift function cannot be used.
Projection distance for 16:9 aspect ratio screen (If using other than the ET-DLE030)
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 8 / 2 5
SFD13M004-2

Screen size
(diagonal)
min. max. min. max.
Zoom
Zoom
lenses
Fixed-focus
Fixed-
focus
lens
Distance to screen (L) Height from the edge
of screen to
center of lens (H)
min. max. min. max. min. max.
ET-DLE150
Zoom lens
min. max.
ET-DLE085
Zoom lens
Supplied lens ET-DLE250
Zoom lens
ET-DLE350
Zoom lens
ET-DLE450
Zoom lens
ET-DLE055
Fixed-focus
lens
1.27
1.52
1.78
2.03
2.29
2.54
3.05
3.81
5.08
6.35
7.62
10.16
12.70
15.24
[m] [in]
50
60
70
80
90
100
120
150
200
250
300
400
500
600
/
/
/
/
/
/
/
/
/
/
/
/
/
/
–
–
–
–
–
–
–
–
–
–
–
–
–
–
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.38
0.46
0.53
0.61
0.69
0.76
0.91
1.14
1.52
1.91
2.29
3.05
3.81
4.57
0.94
1.14
1.34
1.54
1.74
1.93
2.33
2.93
3.92
–
–
–
–
–
0.38
0.46
0.53
0.61
0.69
0.76
0.91
1.14
1.52
–
–
–
–
–
2.29
2.75
3.22
3.69
4.15
4.62
5.56
6.96
9.29
11.63
13.96
18.63
23.30
27.97
1.18
1.42
1.67
1.91
2.16
2.40
2.89
3.62
4.84
6.07
7.29
9.73
12.17
14.62
2.92
3.52
4.12
4.72
5.31
5.91
7.11
8.91
11.90
14.89
17.88
23.87
29.85
4.39
5.28
6.17
7.07
7.96
8.85
10.64
13.32
17.78
22.25
26.71
35.65
44.58
53.51
6.60
7.95
9.29
10.64
11.99
13.34
16.03
20.07
26.81
33.54
40.28
53.74
67.21
80.68
10.37
12.50
14.64
16.77
18.90
21.04
25.30
31.70
42.37
53.04
63.70
85.04
106.37
127.71
1.57
1.89
2.21
2.54
2.86
3.18
3.83
4.80
6.42
8.04
9.66
12.90
16.13
19.37
0.94
1.14
1.34
1.53
1.73
1.93
2.32
2.91
3.90
4.89
5.88
7.85
9.82
11.80
2.07
2.50
2.93
3.35
3.78
4.21
5.07
6.36
8.50
10.64
12.78
17.07
21.36
35.8425.64
2.75
3.31
3.88
4.44
5.01
5.58
6.71
8.40
11.23
14.06
16.88
22.54
28.19
33.85
4.32
5.21
6.11
7.00
7.89
8.78
10.56
13.24
17.69
22.15
26.61
35.52
44.44
53.35
6.45
7.80
9.15
10.49
11.84
13.19
15.89
19.94
26.69
33.44
40.18
53.68
67.17
80.67
Screen size
(diagonal)
min. max. min. max.
Zoom
Zoom
lenses
Fixed-focus
Fixed-
focus
lens
Distance to screen (L) Height from the edge
of screen to
center of lens (H)
min. max. min. max. min. max.
ET-DLE150
Zoom lens
min. max.
ET-DLE085
Zoom lens
Supplied lens ET-DLE250
Zoom lens
ET-DLE350
Zoom lens
ET-DLE450
Zoom lens
ET-DLE055
Fixed-focus
lens
1.27
1.52
1.78
2.03
2.29
2.54
3.05
3.81
5.08
6.35
7.62
10.16
12.70
15.24
[m] [in]
50
60
70
80
90
100
120
150
200
250
300
400
500
600
/
/
/
/
/
/
/
/
/
/
/
/
/
/
–
–
–
–
–
–
–
–
–
–
–
–
–
–
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
1.3
1.5
1.8
2.0
2.3
2.5
3.0
3.8
5.0
6.3
7.5
10.0
12.5
15.0
3.1
3.7
4.4
5.0
5.7
6.3
7.6
9.6
12.8
–
–
–
–
–
1.3
1.5
1.8
2.0
2.3
2.5
3.0
3.8
5.0
–
–
–
–
–
7.5
9.0
10.6
12.1
13.6
15.2
18.2
22.8
30.5
38.1
45.8
61.1
76.5
91.8
3.9
4.7
5.5
6.3
7.1
7.9
9.5
11.9
15.9
19.9
23.9
31.9
39.9
48.0
9.6
11.5
13.5
15.5
17.4
19.4
23.3
29.2
39.0
48.9
58.7
78.3
97.9
14.4
17.3
20.3
23.2
26.1
29.0
34.9
43.7
58.3
73.0
87.6
116.9
146.2
175.5
21.7
26.1
30.5
34.9
39.3
43.8
52.6
65.8
87.9
110.0
132.1
176.3
220.5
264.7
34.0
41.0
48.0
55.0
62.0
69.0
83.0
104.0
139.0
174.0
209.0
279.0
349.0
419.0
5.1
6.2
7.3
8.3
9.4
10.4
12.6
15.8
21.1
26.4
31.7
42.3
52.9
63.6
3.1
3.7
4.4
5.0
5.7
6.3
7.6
9.6
12.8
16.0
19.3
25.8
32.2
38.7
6.8
8.2
9.6
11.0
12.4
13.8
16.6
20.8
27.9
34.9
41.9
56.0
70.1
117.684.1
9.0
10.9
12.7
14.6
16.4
18.3
22.0
27.6
36.8
46.1
55.4
73.9
92.5
111.0
14.2
17.1
20.0
23.0
25.9
28.8
34.7
43.4
58.0
72.7
87.3
116.5
145.8
175.0
21.1
25.6
30.0
34.4
38.9
43.3
52.1
65.4
87.6
109.7
131.8
176.1
220.4
264.7
Unit: feet
Unit: meters
• The value for L (distance to screen) varies slightly within ±5% depending on the zoom lens characteristics.
• The zoom lens characteristics may cause slight image distortion.
• When vertical keystone correction is used, the image is corrected in the direction that reduces its projected size.
• The brightness varies depending on the zoom setting.
Note: When the ET-DLE055 is mounted, the optical lens shift function cannot be used.
Projection distance for 4:3 aspect ratio screen (If using other than the ET-DLE030)
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 9 / 2 5
SFD13M004-2

Standard setting-up position (If using the ET-DLE030)
Caution:
• All construction work should be done by a qualified technician.
• When mounting to the ceiling, use the special mounting bracket. Furthermore, in order to prevent it from falling
down from the ceiling, use the supplied wire on the mounting bracket.
unit : mm (inch)
*1 When the lens protrudes to the maximum.
84 mm (3-5/16 in) with the ET-DLE085
43 mm (1-11/16 in) with the supplied lens
44 mm (1-23/32 in) with the ET-DLE150
27 mm (1-1/16 in) with the ET-DLE055
*2 Adjustable in 40 mm (1-9/16 in) steps.
NOTE:
Illustrations show the projector
installed using optional ceiling mount
bracket ET-PKD130H, optional bracket
assembly ET-PKD130B and an optional lens.
This illustration is not drawn to scale.
45 mm (1-25/32 in) with the ET-DLE250
51 mm (2 in) with the ET-DLE350
95 mm (3-3/4 in) with the ET-DLE450
100
(3-15/16)
380
(14-31/32)
308
(12-1/8)
100
(3-15/16)
Upper edge of
projected image
A1
A2
239
(9-13/32)
274
(10-25/32)
L1
L4
L3
ø60.5
585〜695*2
(23-1/32–
27-3/8)
Projected image
Lower edge of
projected image
A1
A2
L1
L4
L3
Projected image
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 1 0 / 2 5
SFD13M004-2

Projection distance for 16:10 aspect ratio screen (If using the ET-DLE030)
Unit : meters
0.38:1 (0.39:1)
100
120
150
200
250
300
350
100
120
150
200
250
300
350
2.54
3.05
3.81
5.08
6.35
7.62
8.89
1.35
1.62
2.02
2.69
3.37
4.04
4.71
2.15
2.59
3.23
4.31
5.39
6.46
7.54
0.82
0.98
1.23
1.63
2.04
2.45
2.85
0.84
1.00
1.25
1.66
2.06
2.47
2.88
0.65
0.82
1.06
1.47
1.87
2.28
2.69
0.14
0.30
0.55
0.95
1.36
1.77
2.18
0.63
0.73
0.88
1.13
1.38
1.63
1.89
Unit : feet
2.54
3.05
3.81
5.08
6.35
7.62
8.89
4.4
5.3
6.6
8.8
11.0
13.3
15.5
7.1
8.5
10.6
14.1
17.7
21.2
24.7
2.7
3.2
4.0
5.4
6.7
8.0
9.4
2.8
3.3
4.1
5.4
6.8
8.1
9.4
2.1
2.7
3.5
4.8
6.1
7.5
8.8
0.5
1.0
1.8
3.1
4.5
5.8
7.1
2.1
2.4
2.9
3.7
4.5
5.4
6.2
Throw ratio
Diagonal
size
(Inches)
Diagonal
size
(m)
Height
(SH)
Width
(SW)
Ultra-short focal length lens ET-DLE030
Close-up system dimensions
0.43
0.53
0.68
0.93
1.18
1.43
1.69
1.4
1.7
2.2
3.1
3.9
4.7
5.5
From bottom of set
to bottom edge of
screen (A2)
From top of set to
bottom edge of
screen (A1)
From rear of
set to screen
(L4)
From front of
set to screen
(L3)
From tip of
lens to screen
(L2)
Projection distance
(From mirror reflective
surface to screen)
(L1)
0.38:1 (0.39:1)
Throw ratio
Diagonal
size
(Inches)
Diagonal
size
(m)
Height
(SH)
Width
(SW)
Ultra-short focal length lens ET-DLE030
Close-up system dimensions
From bottom of set
to bottom edge of
screen (A2)
From top of set to
bottom edge of
screen (A1)
From rear of
set to screen
(L4)
From front of
set to screen
(L3)
From tip of
lens to screen
(L2)
Projection distance
(From mirror reflective
surface to screen)
(L1)
Projection Distance Calculation Table
Screen aspect ratio 16:10
L1 (m) = 0.3205 x Diagonal image size + 0.0047
Projection distance calculation formula
A1 (m) = 0.1977 x Diagonal image size - 0.07210
Calculation formula for distance from top of set to bottom edge of screen
L1: Projection distance
(from screen to mirror reflective surface)
L2: From screen to tip of lens
L3: From screen to front of set
L4: From screen to rear of set
A1: From bottom edge of screen to top of set
A2: From bottom edge of screen to bottom of set
Screen
A1
A2
L4
L1
L3
L2
* The value for L1 may contain an error of within ±5%.
* When using vertical keystone correction, the images will be corrected so that they will tend to be smaller than the specified screen size.
* This measurement is not the distance between the rear of the projector and the wall, but is instead the distance between the rear of the projector and the screen surface.
Leave at least 500 mm of space between the rear of the projector and the wall and any other objects in order to provide adequate ventilation space. If setting up the
projector in a closed room, be sure to provide separate air conditioning and ventilation equipment. If there is insufficient ventilation in the room, radiated heat may build up
and cause the protection circuit of the projector to operate.
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 1 1 / 2 5
SFD13M004-2

Unit : meters
0.38:1 (0.4:1)
100
120
150
200
250
300
350
100
120
150
200
250
300
350
2.54
3.05
3.81
5.08
6.35
7.62
8.89
1.25
1.49
1.87
2.49
3.11
3.74
4.36
2.21
2.66
3.32
4.43
5.54
6.64
7.75
Unit : feet
2.54
3.05
3.81
5.08
6.35
7.62
8.89
4.1
4.9
6.1
8.2
10.2
12.3
14.3
7.3
8.7
10.9
14.5
18.2
21.8
25.4
Throw ratio
Diagonal
size
(Inches)
Diagonal
size
(m)
Height
(SH)
Width
(SW)
Ultra-short focal length lens ET-DLE030
Close-up system dimensions
0.84 0.86 0.68 0.16 0.51 0.71
1.01 1.03 0.84 0.33 0.63 0.83
1.26 1.28 1.09 0.58 0.81 1.01
1.68 1.70 1.51 1.00 1.10 1.30
2.10 2.12 1.93 1.42 1.39 1.59
2.52 2.54 2.35 1.84 1.68 1.88
2.93 2.95 2.77 2.25 1.98 2.18
2.8 2.8 2.2 0.5 1.7 2.3
3.3 3.4 2.8 1.1 2.1 2.7
4.1 4.2 3.6 1.9 2.6 3.3
5.5 5.6 5.0 3.3 3.6 4.3
6.9 7.0 6.3 4.6 4.6 5.2
8.3 8.3 7.7 6.0 5.5 6.2
9.6 9.7 9.1 7.4 6.5 7.1
From bottom of set
to bottom edge of
screen (A2)
From top of set to
bottom edge of
screen (A1)
From rear of
set to screen
(L4)
From front of
set to screen
(L3)
From tip of
lens to screen
(L2)
Projection distance
(From mirror reflective
surface to screen)
(L1)
0.38:1 (0.4:1)
Throw ratio
Diagonal
size
(Inches)
Diagonal
size
(m)
Height
(SH)
Width
(SW)
Ultra-short focal length lens ET-DLE030
Close-up system dimensions
From bottom of set
to bottom edge of
screen (A2)
From top of set to
bottom edge of
screen (A1)
From rear of
set to screen
(L4)
From front of
set to screen
(L3)
From tip of
lens to screen
(L2)
Projection distance
(From mirror reflective
surface to screen)
(L1)
Projection Distance Calculation Table
Screen aspect ratio 16:9
L1 (m) = 0.3294 x Diagonal image size + 0.0047
Projection distance calculation formula
A1 (m) = 0.2304 x Diagonal image size - 0.07210
Calculation formula for distance from top of set to bottom edge of screen
L1: Projection distance
(from screen to mirror reflective surface)
L2: From screen to tip of lens
L3: From screen to front of set
L4: From screen to rear of set
A1: From bottom edge of screen to top of set
A2: From bottom edge of screen to bottom of set
Screen
A1
A2
L4
L1
L3
L2
* The value for L1 may contain an error of within ±5%.
* When using vertical keystone correction, the images will be corrected so that they will tend to be smaller than the specified screen size.
* This measurement is not the distance between the rear of the projector and the wall, but is instead the distance between the rear of the projector and the screen surface.
Leave at least 500 mm of space between the rear of the projector and the wall and any other objects in order to provide adequate ventilation space. If setting up the
projector in a closed room, be sure to provide separate air conditioning and ventilation equipment. If there is insufficient ventilation in the room, radiated heat may build up
and cause the protection circuit of the projector to operate.
Projection distance for 16:9 aspect ratio screen (If using the ET-DLE030)
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 1 2 / 2 5
SFD13M004-2

Unit : meters
0.38:1 (0.46:1)
100
120
150
200
250
300
350
100
120
150
200
250
300
350
2.54
3.05
3.81
5.08
6.35
7.62
8.89
1.52
1.83
2.29
3.05
3.81
4.57
5.33
2.03
2.44
3.05
4.06
5.08
6.10
7.11
Unit : feet
2.54
3.05
3.81
5.08
6.35
7.62
8.89
5.0
6.0
7.5
10.0
12.5
15.0
17.5
6.7
8.0
10.0
13.3
16.7
20.0
23.3
Throw ratio
Diagonal
size
(Inches)
Diagonal
size
(m)
Height
(SH)
Width
(SW)
Ultra-short focal length lens ET-DLE030
Close-up system dimensions
0.93 0.95 0.76 0.25 0.50 0.70
1.11 1.13 0.94 0.43 0.61 0.81
1.39 1.41 1.22 0.71 0.78 0.98
1.85 1.87 1.68 1.17 1.07 1.27
2.31 2.33 2.14 1.63 1.35 1.55
2.77 2.79 2.60 2.09 1.63 1.83
3.23 3.25 3.06 2.55 1.92 2.12
3.0 3.1 2.5 0.8 1.6 2.3
3.6 3.7 3.1 1.4 2.0 2.7
4.6 4.6 4.0 2.3 2.6 3.2
6.1 6.1 5.5 3.8 3.5 4.2
7.6 7.6 7.0 5.3 4.4 5.1
9.1 9.2 8.5 6.9 5.4 6.0
10.6 10.7 10.1 8.4 6.3 6.9
From bottom of set
to bottom edge of
screen (A2)
From top of set to
bottom edge of
screen (A1)
From rear of
set to screen
(L4)
From front of
set to screen
(L3)
From tip of
lens to screen
(L2)
Projection distance
(From mirror reflective
surface to screen)
(L1)
0.38:1 (0.46:1)
Throw ratio
Diagonal
size
(Inches)
Diagonal
size
(m)
Height
(SH)
Width
(SW)
Ultra-short focal length lens ET-DLE030
Close-up system dimensions
From bottom of set
to bottom edge of
screen (A2)
From top of set to
bottom edge of
screen (A1)
From rear of
set to screen
(L4)
From front of
set to screen
(L3)
From tip of
lens to screen
(L2)
Projection distance
(From mirror reflective
surface to screen)
(L1)
Projection Distance Calculation Table
Screen aspect ratio 4:3
Projection distance calculation formula
Calculation formula for distance from top of set to bottom edge of screen
L1: Projection distance
(from screen to mirror reflective surface)
L2: From screen to tip of lens
L3: From screen to front of set
L4: From screen to rear of set
A1: From bottom edge of screen to top of set
A2: From bottom edge of screen to bottom of set
Screen
A1
A2
L4
L1
L3
L2
* The value for L1 may contain an error of within ±5%.
* When using vertical keystone correction, the images will be corrected so that they will tend to be smaller than the specified screen size.
* This measurement is not the distance between the rear of the projector and the wall, but is instead the distance between the rear of the projector and the screen surface.
Leave at least 500 mm of space between the rear of the projector and the wall and any other objects in order to provide adequate ventilation space. If setting up the
projector in a closed room, be sure to provide separate air conditioning and ventilation equipment. If there is insufficient ventilation in the room, radiated heat may build up
and cause the protection circuit of the projector to operate.
L1 (m) = 0.3628 x Diagonal image size + 0.0047
A1 (m) = 0.2238 x Diagonal image size - 0.07210
Projection distance for 4:3 aspect ratio screen (If using the ET-DLE030)
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 1 3 / 2 5
SFD13M004-2

Calculation of the projection distance
For a screen size different from the above, use the equation below to calculate the projection distance.
• Distances calculated with the above equations will include a slight error.
minimum L (m) = (diagonal screen size in inches) × 0.0174 - 0.0471
maximum L (m) = (diagonal screen size in inches) × 0.0216 - 0.0442
ET-DLE085
minimum L (m) = (diagonal screen size in inches) × 0.0286 - 0.0540
maximum L (m) = (diagonal screen size in inches) × 0.0413 - 0.0498
ET-DLE150
minimum L (m) = (diagonal screen size in inches) × 0.0379 - 0.0746
maximum L (m) = (diagonal screen size in inches) × 0.0529 - 0.0725
Supplied lens
minimum L (m) = (diagonal screen size in inches) × 0.0500 - 0.0800
maximum L (m) = (diagonal screen size in inches) × 0.0789 - 0.0792
ET-DLE250
minimum L (m) = (diagonal screen size in inches) × 0.0787 - 0.1351
maximum L (m) = (diagonal screen size in inches) × 0.1190 - 0.1346
ET-DLE350
minimum L (m) = (diagonal screen size in inches) × 0.1192 - 0.3017
maximum L (m) = (diagonal screen size in inches) × 0.1885 - 0.2991
ET-DLE450
L1 (m) = (diagonal screen size in inches) × 0.0081 - 0.0047
L3 (m) = L1-0.166
L4 (m) = L1-0.679
ET-DLE030 (fixed focus)
(fixed focus) L (m) = (diagonal screen size in inches) × 0.0175 - 0.0476ET-DLE055
Aspect ratio 16:9
Aspect ratio 16:10
minimum L (m) = (diagonal screen size in inches) × 0.0179 - 0.0471
maximum L (m) = (diagonal screen size in inches) × 0.0222 - 0.0442
ET-DLE085
minimum L (m) = (diagonal screen size in inches) × 0.0294 - 0.0540
maximum L (m) = (diagonal screen size in inches) × 0.0424 - 0.0498
ET-DLE150
minimum L (m) = (diagonal screen size in inches) × 0.0389 - 0.0746
maximum L (m) = (diagonal screen size in inches) × 0.0543 - 0.0725
Supplied lens
minimum L (m) = (diagonal screen size in inches) × 0.0513 - 0.0800
maximum L (m) = (diagonal screen size in inches) × 0.0811 - 0.0792
ET-DLE250
minimum L (m) = (diagonal screen size in inches) × 0.0809 - 0.1351
maximum L (m) = (diagonal screen size in inches) × 0.1223 - 0.1346
ET-DLE350
minimum L (m) = (diagonal screen size in inches) × 0.1225 - 0.3017
maximum L (m) = (diagonal screen size in inches) × 0.1937 - 0.2991
ET-DLE450
L1 (m) = (diagonal screen size in inches) × 0.0084 - 0.0047
L3 (m) = L1-0.166
L4 (m) = L1-0.679
ET-DLE030 (fixed focus)
(fixed focus) L (m) = (diagonal screen size in inches) × 0.0180 - 0.0476ET-DLE055
Aspect ratio 4:3
minimum L (m) = (diagonal screen size in inches) × 0.0197 - 0.0471
maximum L (m) = (diagonal screen size in inches) × 0.0244 - 0.0442
ET-DLE085
minimum L (m) = (diagonal screen size in inches) × 0.0324 - 0.0540
maximum L (m) = (diagonal screen size in inches) × 0.0467 - 0.0498
ET-DLE150
minimum L (m) = (diagonal screen size in inches) × 0.0429 - 0.0746
maximum L (m) = (diagonal screen size in inches) × 0.0599 - 0.0725
Supplied lens
minimum L (m) = (diagonal screen size in inches) × 0.0565 - 0.0800
maximum L (m) = (diagonal screen size in inches) × 0.0893 - 0.0792
ET-DLE250
minimum L (m) = (diagonal screen size in inches) × 0.0891 - 0.1351
maximum L (m) = (diagonal screen size in inches) × 0.1347 - 0.1346
ET-DLE350
minimum L (m) = (diagonal screen size in inches) × 0.1349 - 0.3017
maximum L (m) = (diagonal screen size in inches) × 0.2133 - 0.2991
ET-DLE450
L1 (m) = (diagonal screen size in inches) × 0.0092 - 0.0047
L3 (m) = L1-0.166
L4 (m) = L1-0.679
ET-DLE030 (fixed focus)
(fixed focus) L (m) = (diagonal screen size in inches) × 0.0198 - 0.0476ET-DLE055
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 1 4 / 2 5
SFD13M004-2

H
(Width of
projected image)
V
(Height of
projected image)
0.5V
0.1H0.1H
Standard postition
of projected image H
(Width of
projected image)
V
(Height of
projected image)
0.5V
0.1H0.1H
Standard postition
of projected image
Formula for calculating possible heights when using the ET-DLE030
Shift range
Optical
If using a screen size which has not been previously mentioned, use the following calculation formulas to
obtain the possible setting-up height.
axis shift function allows to shift the position of a projected image as shown below.
• Floor mount
(When the lens except the ET-DLE085 is mounted.)
• Ceiling mount
(When the lens except the ET-DLE085 is mounted.)
H
(Width of
projected image)
V
(Height of
projected image)
0.5V
0.4V
0.1H0.1H
Standard postition
of projected image
H
(Width of
projected image)
V
(Height of
projected image)
0.5V
0.4V
0.1H0.1H
Standard postition
of projected image
• Floor mount
(When the ET-DLE085 is mounted.)
• Ceiling mount
(When the ET-DLE085 is mounted.)
• The ET-DLE055 has a fixed short-focus lens. Therefore, the lens shift function provided in the main unit cannot be used.
For screen aspect ratio of 16:10 Possible setting-up height A1 (mm) = Projection screen size (inches) x 5.0-72.1
Possible setting-up height A2 (mm) = A1 + 200
For screen aspect ratio of 16:9 Possible setting-up height A1 (mm) = Projection screen size (inches) x 5.9-72.1
Possible setting-up height A2 (mm) = A1 + 200
For screen aspect ratio of 4:3 Possible setting-up height A1 (mm) = Projection screen size (inches) x 5.7-72.1
Possible setting-up height A2 (mm) = A1 + 200
* There may be a small margin of error in the values obtained from the above formulas.
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 1 5 / 2 5
SFD13M004-2

-15°
+15°
Installable angle
Install the projector at an angle within the range shown below.
• Vertical direction
The projector may be installed at a vertical
angle of 360°.
• Horizontal direction
The projector may be installed at a horizontal
angle of ±15°.
-15°
+15°
• Vertical direction in portrait mode with the
ET-LAD120P/LAD120PW mounted
The projector may be installed at a vertical
angle of ±15°.
• Horizontal direction in portrait mode with
the ET-LAD120P/LAD120PW mounted
The projector may be installed at a horizontal
angle of ±15°.
NOTE: The projector cannot be vertically installed all by itself. Also, the terminal side must face downward when vertically installed.
360°
-15°
+15°
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 1 6 / 2 5
SFD13M004-2

List of compatible signals
The signals that can be input to this projector are shown in the table below. Horizontal scanning fre-
quencies of 15 kHz to 100 kHz, vertical scanning frequencies of 24 Hz to 120 Hz, and a dot clock of
162 MHz maximum can be input.
NOTE: The native resolution of this projector is 1,920 × 1,200 pixels. If the display resolution of the input signal is different from the
native resolution, image compression or expansion will be used to convert the input signal to a level within the native resolution.
Display mode Display
resolution
(dots)*
Scanning frequency
H
(kHz)
V
(kHz)
Dot clock
frequency
(MHz)
Format
720 × 480i
720 × 576i
720 × 480i
720 × 576i
720 × 483
720 × 576
1280 × 720
1920 × 1080i
1920 × 1080
1920 × 1080i
1920 × 1080
640 × 400
640 × 480
800 × 600
832 × 624
1024 × 768
1152 × 864
1152 × 870
15.7
15.6
15.7
15.6
31.5
31.3
45.0
37.5
33.8
28.1
27.0
28.1
33.8
67.5
56.3
31.5
37.9
31.5
35.0
37.9
37.5
43.3
35.2
37.9
48.1
46.9
53.7
49.7
39.6
48.4
56.5
60.0
65.5
68.7
81.4
98.8
53.7
64.0
67.5
77.1
68.7
59.9
50.0
59.9
50.0
59.9
50.0
60.0
50.0
60.0
50.0
24.0
27.0 48.0
25.0
30.0
60.0
50.0
70.1
85.1
59.9
66.7
72.8
75.0
85.0
56.3
60.3
72.2
75.0
85.1
74.6
50.0
60.0
70.1
75.0
81.6
85.0
100.0
120.0
60.0
70.0
74.9
85.0
75.1
−
−
13.5
13.5
27.0
74.3
148.5
25.2
31.5
25.2
30.2
31.5
31.5
36.0
36.0
40.0
50.0
49.5
56.3
57.3
51.9
65.0
75.0
78.8
86.0
94.5
113.3
139.1
81.6
94.2
108.0
119.7
100.0
NTSC/NTSC4.43/PAL-M/PAL60
PAL/PAL-N/SECAM
525i (480i)
625i (576i)
525p (480p)
625p (576p)
750 (720)/60p
750 (720)/50p
1125 (1080)/60i
1125 (1080)/50i
1125 (1080)/24p
1125 (1080)/24sF
1125 (1080)/25p
1125 (1080)/30p
1125 (1080)/60p
1125 (1080)/50p
VGA400
VGA480
SVGA
MAC16
XGA
MXGA
MAC21
VIDEO/S-VIDEO
SDI/YCBCR/RGB
720(1440) × 480i
720(1440) × 576i
15.7
15.6
59.9
50.0
27.0
525i (480i)
625i (576i)
HDMI/DVI-D
YCBCR/RGB/
HDMI/DVI-D
SDI/YPBPR/RGB/
HDMI/DVI-D
HDMI/DVI-D/RGB
*The “i” appearing after the resolution indicates an interlaced signal.
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 1 7 / 2 5
SFD13M004-2

Display mode Display
resolution
(dots)*1
Scanning frequency
H
(kHz)
V
(kHz)
Dot clock
frequency
(MHz)
Format
1280 × 720
1280 × 768
1280 × 768
1280 × 768
1280 × 800
1280 × 800
1280 × 800
1280 × 960
1280 × 1024
1366 × 768
1400 × 1050
1440 × 900
1600 × 1200
1680 × 1050
1920 × 1080
1920 × 1080
1920 × 1080
1920 × 1080
1920 × 1200
1920 × 1200
37.1
44.8
76.3
92.6
39.6
47.8
47.4
60.3
68.6
41.3
49.7
49.3
62.8
71.6
60.0
52.4
64.0
72.3
78.2
80.0
91.1
47.7
39.6
54.1
64.0
65.2
65.3
78.8
82.2
55.9
46.3
75.0
65.3
54.1
55.6
66.6
67.2
61.8
74.0
74.6
49.8
59.9
100.0
120.0
49.9
59.9
60.0
74.9
84.9
50.0
59.8
59.9
74.9
84.9
60.0
50.0
60.0
66.3
72.0
75.0
85.0
59.8
49.9
50.0
60.0
60.0
60.0
60.0
72.0
75.0
59.9
49.9
60.0
50.0
49.9
59.9
60.0
49.9
60.0
59.9
60.5
74.5
131.8
161.6
65.3
79.5
68.3
102.3
117.5
68.0
83.5
71.0
106.5
122.5
108.0
88.0
108.0
125.0
135.1
135.0
157.5
85.5
69.0
99.9
108.0
122.6
121.8
149.3
155.9
106.5
86.8
162.0
146.3
119.5
141.5
138.5
173.0
158.3
154.0
193.3
1280 × 720
1280 × 768
1280 × 800
MSXGA
SXGA
1366×768
SXGA+
WXGA+
UXGA60
WSXGA+
1920×1080
WUXGA
RGB/HDMI/DVI-D
RGB
RGB/HDMI/DVI-D
RGB
*2
*2
*2
*2
*1 The “i” appearing after the resolution indicates an interlaced signal.
*2 Compliant with VESA CVT-RB (Coordinated Video Timing-Reduced Blanking).
NOTE: DIGITAL LINK and HDMI inputs share the same compatible signal.
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 1 8 / 2 5
SFD13M004-2

List of compatible 3D signals
The 3D signals that can be input to this projector are shown in the table below.
Yes
Yes
Yes
–
–
–
Yes
Yes Yes Yes
Yes
Yes Yes Yes
Yes
–
Yes
–
– –
Yes
Yes
–
Yes
–
––– – –
––– – – –
–
Yes
–
Yes
Yes Yes Yes Yes Yes Yes
Yes
–
Yes
–
Yes
–
–
Yes
–
Display mode Display
resolution
(dots)*1
Scanning
frequency
H
(kHz)
V
(kHz)
Dot clock
frequency
(MHz) Frame
packing
HDMI
Side by
side*2Top and
bottom
Side by
side*2
DVI
Top and
bottom
Line by
line
Frame
sequen-
tial
1280 × 720
1920 × 1080i
1920 × 1080
1920 × 1080i
1920 × 1080
640 × 480
800 × 600
1024 × 768
1152 × 864
1280 × 720
1280 × 768
1280 × 768
1280 × 800
1280 × 800
1280 × 960
1280 × 1024
1366 × 768
1400 × 1050
1440 × 900
1600 × 1200
1680 × 1050
1920 × 1080
1920 × 1080
1920 × 1200
1920 × 1200
45.0
37.5
33.8
28.1
27.0
27.0
28.1
33.8
67.5
56.3
31.5
37.9
39.6
48.4
81.4
98.8
53.7
37.1
44.8
76.3
92.6
39.6
47.8
47.4
41.3
49.7
49.3
60.0
52.4
64.0
47.7
39.6
54.1
64.0
65.2
65.3
55.9
46.3
75.0
65.3
54.1
55.6
66.6
61.8
74.0
60.0
50.0
60.0
50.0
24.0
48.0
25.0
30.0
60.0
50.0
59.9
60.3
50.0
60.0
100.0
120.0
60.0
49.8
59.9
100.0
120.0
49.9
59.9
60.0
50.0
59.8
59.9
60.0
50.0
60.0
59.8
49.9
50.0
60.0
60.0
60.0
59.9
49.9
60.0
60.0
50.0
49.9
59.9
49.9
60.0
74.3
74.3
74.3
74.3
74.3
74.3
74.3
74.3
148.5
148.5
25.2
40.0
51.9
65.0
113.3
139.1
81.6
60.5
74.5
131.8
161.6
65.3
79.5
68.3
68.0
83.5
71.0
108.0
88.0
108.0
85.5
69.0
99.9
108.0
122.6
121.8
106.5
86.8
162.0
146.3
119.5
141.5
138.5
158.3
154.0
750 (720)/60p
750 (720)/50p
1125 (1080)/60i
1125 (1080)/50i
1125 (1080)/24p
1125 (1080)/24sF
1125 (1080)/25p
1125 (1080)/30p
1125 (1080)/60p
1125 (1080)/50p
VGA480
SVGA
XGA
MXGA
1280 × 720
1280 × 768
1280 × 800
MSXGA
SXGA
1366 × 768
SXGA+
WXGA+
UXGA60
WSXGA+
1920 × 1080
WUXGA
*3
*3
*3
*3
*1 The “i” appearing after the resolution indicates an interlaced signal.
*2 Compatible with half-resolution signals.
*3 Compliant with VESA CVT-RB (Coordinated Video Timing-Reduced Blanking).
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 1 9 / 2 5
SFD13M004-2

Yes
–
Yes
–
Yes
Yes
–
Yes
–
Yes
–
Yes
–
Yes
–
Yes
–
Yes
–
Yes
–
Yes
–
Yes
–
Yes
Yes
–
–
Yes
Yes Yes
–
– –
Yes
Display mode Display
resolution
(dots)*1
Scanning
frequency
H
(kHz)
V
(kHz)
Dot clock
frequency
(MHz)
RGB1/RGB2 SDI
Side
by
side*2
Top
and
bottom
Simul-
taneous
Simul-
taneous
Side
by
side*2
HDMI
& DVI
RGB1
& Level B
RGB2
Yes
Simul-
taneous
3G-SDI
Top
and
bottom
Line
by
line
Line
by
line
Frame
sequen-
tial
1280 × 720
1920 × 1080i
1920 × 1080
1920 × 1080i
1920 × 1080
640 × 480
800 × 600
1024 × 768
1152 × 864
1280 × 720
1280 × 768
1280 × 768
1280 × 800
1280 × 800
1280 × 960
1280 × 1024
1366 × 768
1400 × 1050
1440 × 900
1600 × 1200
1680 × 1050
1920 × 1080
1920 × 1080
1920 × 1200
1920 × 1200
45.0
37.5
33.8
28.1
27.0
27.0
28.1
33.8
67.5
56.3
31.5
37.9
39.6
48.4
81.4
98.8
53.7
37.1
44.8
76.3
92.6
39.6
47.8
47.4
41.3
49.7
49.3
60.0
52.4
64.0
47.7
39.6
54.1
64.0
65.2
65.3
55.9
46.3
75.0
65.3
54.1
55.6
66.6
61.8
74.0
60.0
50.0
60.0
50.0
24.0
48.0
25.0
30.0
60.0
50.0
59.9
60.3
50.0
60.0
100.0
120.0
60.0
49.8
59.9
100.0
120.0
49.9
59.9
60.0
50.0
59.8
59.9
60.0
50.0
60.0
59.8
49.9
50.0
60.0
60.0
60.0
59.9
49.9
60.0
60.0
50.0
49.9
59.9
49.9
60.0
74.3
74.3
74.3
74.3
74.3
74.3
74.3
74.3
148.5
148.5
25.2
40.0
51.9
65.0
113.3
139.1
81.6
60.5
74.5
131.8
161.6
65.3
79.5
68.3
68.0
83.5
71.0
108.0
88.0
108.0
85.5
69.0
99.9
108.0
122.6
121.8
106.5
86.8
162.0
146.3
119.5
141.5
138.5
158.3
154.0
VGA480
SVGA
XGA
MXGA
1280 × 720
1280 × 768
1280 × 800
MSXGA
SXGA
1366 × 768
SXGA+
WXGA+
UXGA60
WSXGA+
1920 × 1080
WUXGA
*3
*3
*3
*3
*1 The “i” appearing after the resolution indicates an interlaced signal.
*2 Compatible with half-resolution signals.
*3 Compliant with VESA CVT-RB (Coordinated Video Timing-Reduced Blanking).
750 (720)/60p
750 (720)/50p
1125 (1080)/60i
1125 (1080)/50i
1125 (1080)/24p
1125 (1080)/24sF
1125 (1080)/25p
1125 (1080)/30p
1125 (1080)/60p
1125 (1080)/50p
NOTE: DIGITAL LINK and HDMI inputs share the same compatible signal.
PT-DZ870K/DZ870W/DZ870LK/DZ870LW
DLPTM Projector
As of September 2013 2 0 / 2 5
SFD13M004-2
