Panasonic PT-RZ21K Installation manual
(2017-12)
・Please refer to the Operating Instructions for the serial command format, limitations, connectionand otherdetails.
・シリアルコマンドのフォーマット、制限事項、接続方法およびその他詳細につきましては、各モデルの取扱説明書をご覧ください。
・有关串行控制命令的格式、限制事项、连接方法以及其他详情、请参阅各机型的使用说明书。
Model No. PT-RZ21K
PT-RS20K
Control Commands
PT-RZ21K Series
1/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
BASIC
OPERAT
IO
N
REMOTE
CONTROL
POWER ON PON QPW 001 ✔✔
OFF (STANDBY) POF 000 ✔✔
INPUT SELECT
INPUT SELECT
(DIGITAL LINK)
COMPUTER1 IIS:RG1 QIN RG1 ✔✔
COMPUTER2 IIS:RG2 RG2 ✔✔
VIDEO IIS:VID VID ✔✔
Y/C IIS:SVD SVD ✔✔
DVI IIS:DVI DVI ✔✔
HDMI1 IIS:HD1 HD1 ✔✔
SDI1 IIS:SD1 SD1 ✔✔
SDI2 IIS:SD2 SD2 ✔✔
DIGITAL LINK IIS:DL1 DL1 ✔✔
COMPUTER1 IIS:DL1:PC1 DL1:PC1 ✔✔
COMPUTER2 IIS:DL1:PC2 DL1:PC2 ✔✔
VIDEO IIS:DL1:VID DL1:VID ✔✔
HDMI1 IIS:DL1:HD1 DL1:HD1 ✔✔
HDMI2 IIS:DL1:HD2 DL1:HD2 ✔✔
S-VIDEO IIS:DL1:SVD DL1:SVD ✔✔
FREEZE OFF OFZ:0 QFZ 0 ✔✔
ON OFZ:1 1 ✔✔
MENU KEY OMN ✔✔
ENTER KEY OEN ✔✔
UP KEY OCU ✔✔
DOWN KEY OCD ✔✔
LEFT KEY OCL ✔✔
RIGHT KEY OCR ✔✔
DEFAULT KEY OST ✔✔
AUTO SETUP KEY OAS ✔✔
SHUTTER ON OSH:0 QSH 0 ✔✔
OFF OSH:1 1 ✔✔
SHUTTER(Toggle) OFF OSH QSH 0 ✔✔
ON 1 ✔✔
FUNCTION KEY FC1 ✔✔
SYSTEM SELCTOR KEY OSL ✔✔
ASPECT KEY VS1 ✔✔
NUMERIC KEY 0 ONK:0 ✔✔
1 ONK:1 ✔✔
2 ONK:2 ✔✔
3 ONK:3 ✔✔
4 ONK:4 ✔✔
5 ONK:5 ✔✔
6 ONK:6 ✔✔
7 ONK:7 ✔✔
8 ONK:8 ✔✔
9 ONK:9 ✔✔
LENS HOME POSITION EXECUTE VXX:LNSI1=+00001 ✔✔
ACTIVE FOCUS OPTIMIZER-
ACTIVE FOCUS
OFF VXX:AFOI1=+00000 QVX:AFOI1 AFOI1=+00000 ✔✔
ON VXX:AFOI1=+00001 AFOI1=+00001 ✔✔
ACTIVE FOCUS OPTIMIZER-FOCUS
OFFSET BRIGHT
-00099 VXX:FOBI1=-00099 QVX:FOBI1 FOBI1=-00099 ✔✔
+00099 VXX:FOBI1=+00099 FOBI1=+00099 ✔✔
ACTIVE FOCUS OPTIMIZER-FOCUS
OFFSET DARK
-00099 VXX:FOBI2=-00099 QVX:FOBI2 FOBI2=-00099 ✔✔
+00099 VXX:FOBI2=+00099 FOBI2=+00099 ✔✔
ACTIVE FOCUS OPTIMIZER-
INITILIZE EXECUTE VXX:FOII1=+00001 ✔✔
2/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
LENS SHIFT-HORIZONTAL SLOW+
SLOW-
NORMAL+
NORMAL-
FAST+
FAST-
VXX:LNSI2=+00000
VXX:LNSI2=+00001
VXX:LNSI2=+00100
VXX:LNSI2=+00101
VXX:LNSI2=+00200
VXX:LNSI2=+00201
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
LENS SHIFT-VERTICAL SLOW+
SLOW-
NORMAL+
NORMAL-
FAST+
FAST-
VXX:LNSI3=+00000
VXX:LNSI3=+00001
VXX:LNSI3=+00100
VXX:LNSI3=+00101
VXX:LNSI3=+00200
VXX:LNSI3=+00201
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
LENS FOCUS SLOW+
SLOW-
NORMAL+
NORMAL-
FAST+
FAST-
VXX:LNSI4=+00000
VXX:LNSI4=+00001
VXX:LNSI4=+00100
VXX:LNSI4=+00101
VXX:LNSI4=+00200
VXX:LNSI4=+00201
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
LENS ZOOM SLOW+
SLOW-
NORMAL+
NORMAL-
FAST+
FAST-
VXX:LNSI5=+00000
VXX:LNSI5=+00001
VXX:LNSI5=+00100
VXX:LNSI5=+00101
VXX:LNSI5=+00200
VXX:LNSI5=+00201
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
LENS POSITION HORIZONTAL -02480
+02480
VXX:LNSI7=-02480
VXX:LNSI7=+02480 QVX:LNSI7 LNSI7=-02480
LNSI7=+02480
✔
✔
✔
✔
LENS POSITION VERTICAL -03200
+03200
VXX:LNSI8=-03200
VXX:LNSI8=+03200 QVX:LNSI8 LNSI8=-03200
LNSI8=+03200
✔
✔
✔
✔
LENS POSITION FOCUS +00000
+02560
VXX:LNSI9=+00000
VXX:LNSI9=+02560 QVX:LNSI9 LNSI9=+00000
LNSI9=+02560
✔
✔
✔
✔
LENS POSITION H/V -02480/-03200
+02480/+03200
VXX:LNSSB=-02480-03200
VXX:LNSSB=+02480+03200 QVX:LNSSB LNSSB=-02480-03200
LNSSB=+02480+03200
✔
✔
✔
✔
LENS POSITION H/V FOCUS -02480/-03200/+00000
+02480/+03200/+02560
VXX:LNSSC=-02480-03200+00000
VXX:LNSSC=+02480+03200+02560 QVX:LNSSC LNSSC=-02480-03200+00000
LNSSC=+02480+03200+02560
✔
✔
✔
✔
STATUS KEY STS ✔✔
LENS FOCUS KEY OLF ✔✔
LENS SHIFT KEY OLH ✔✔
LENS ZOOM KEY OLZ ✔✔
DIGITAL LINK KEY DLK ✔✔
INPUT MENU KEY IPT ✔✔
SELF DIAGNOSIS QVX:ERRS1 ERRS1=*****…… ✔✔
PICTURE MODE DYNAMIC
NATURAL
STANDARD
CINEMA
GRAPHIC
DICOM SIM.
USER
VPM:DYN
VPM:NAT
VPM:STD
VPM:CIN
VPM:GRA
VPM:DIC
VPM:USR
QPM DYN
NAT
STD
CIN
GRA
DIC
USR
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
PICTURE MODE-NAME SETTING USER PICTUREMODE VXX:NCGS0=
PICTUREMODE
QVX:NCGS0 NCGS0=
PICTUREMODE
✔✔
CONTRAST +1
+63
VCN:001
VCN:063 QVR 001
063
✔
✔
✔
✔
BRIGHTNESS +1 VBR:001 QVB 001 ✔✔
3/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
+63 VBR:063 063 ✔✔
COLOR +1
+63
VCO:001
VCO:063 QVC 001
063
✔
✔
✔
✔
TINT +1
+63
VTN:001
VTN:063 QVT 001
063
✔
✔
✔
✔
SHARPNESS 0
15
VSR:000
VSR:015 QVS 000
015
✔
✔
✔
✔
COLOR TEMPERATURE DEFAULT(MIDDLE)
USER
USER1(USER)
USER2
3200K
3300K
9200K
9300K
OTE:1
OTE:4
OTE:04
OTE:09
OTE:3200
OTE:3300
OTE:9200
OTE:9300
1
4
4
9
3200
3300
9200
9300
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
COLOR TEMP-NAME SETTING USER1 COLORTEMP1 VXX:NCGS1=
COLORTEMP1
QVX:NCGS1 NCGS1=
COLORTEMP1
✔✔
COLOR TEMP-NAME SETTING USER2 COLORTEMP2 VXX:NCGS3=
COLORTEMP2
QVX:NCGS3 NCGS3=
COLORTEMP2
✔✔
WHITE BALANCE LOW-RED -127
+127
VOR:001
VOR:255 QOR 001
255
✔
✔
✔
✔
WHITE BALANCE LOW-GREEN -127
+127
VOG:001
VOG:255 QOG 001
255
✔
✔
✔
✔
WHITE BALANCE LOW-BLUE -127
+127
VOB:001
VOB:255 QOB 001
255
✔
✔
✔
✔
WHITE BALANCE HIGH-RED 0
+255
VHR:000
VHR:255 QHR 000
255
✔
✔
✔
✔
WHITE BALANCE HIGH-GREEN 0
+255
VHG:000
VHG:255 QHG 000
255
✔
✔
✔
✔
WHITE BALANCE HIGH-BLUE 0
+255
VHB:000
VHB:255 QHB 000
255
✔
✔
✔
✔
GAMMA 1.0
1.8
2.0
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
USER1
USER2
DICOM
HDR HLG
HDR ST2048-500
HDR ST2048-1000
DEFAULT
VGA:1.0
VGA:1.8
VGA:2.0
VGA:2.1
VGA:2.2
VGA:2.3
VGA:2.4
VGA:2.5
VGA:2.6
VGA:2.7
VGA:2.8
VGA:US1
VGA:US2
VGA:DIC
VGA:HD1
VGA:HD2
VGA:HD3
VGA:DEF
QGA 1.0
1.8
2.0
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
US1
US2
DIC
HD1
HD2
HD3
DEF
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
GAMMA-NAME SETTING USER1 GAMMAUSER1 VXX:NCGS2=
GAMMAUSER1
QVX:NCGS2 NCGS2=
GAMMAUSER1
✔✔
GAMMA-NAME SETTING USER2 GAMMAUSER2 VXX:NCGS4=
GAMMAUSER2
QVX:NCGS4 NCGS4=
GAMMAUSER2
✔✔
DAYLIGHT VIEW FRONT INSTALL OFF
AUTO(1)
ON(2)
VXX:DLVI0=+00000
VXX:DLVI0=+00001
VXX:DLVI0=+00002
QVX:DLVI0 DLVI0=+00000
DLVI0=+00001
DLVI0=+00002
✔
✔
✔
✔
✔
✔
4/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
ON(3)
4
5
6
VXX:DLVI0=+00003
VXX:DLVI0=+00004
VXX:DLVI0=+00005
VXX:DLVI0=+00006
DLVI0=+00003
DLVI0=+00004
DLVI0=+00005
DLVI0=+00006
✔
✔
✔
✔
✔
✔
✔
✔
NOISE REDUCTION OFF
1
2
3
4
5
6
VNS:0
VNS:1
VNS:2
VNS:3
VNS:4
VNS:5
VNS:6
QNS 0
1
2
3
4
5
6
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
DYNAMIC CONTRAST/IRIS OFF
1
2
3
USER
OAI:0
OAI:1
OAI:2
OAI:3
OAI:4
QAI 0
1
2
3
4
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
DYNAMIC CONTRAST/AUTO IRIS
(AUTO CONTRAST)
OFF
1
255
OAI:A000
OAI:A001
OAI:A255
QAI:A 000
001
255
✔
✔
✔
✔
✔
✔
DYNAMIC CONTRAST
(BRIGHT SIGNAL LEVEL)
6%
50%
VXX:DYCI1=+00006
VXX:DYCI1=+00050 QVX:DYCI1 00006
00050
✔
✔
✔
✔
DYNAMIC CONTRAST
(LIGHTS OUT TIMER)
DISABLE
0.0s
10.0s
VXX:DYCS2=OFF
VXX:DYCS2=0.0
VXX:DYCS2=10.0
QVX:DYCS2 OFF
0.0
10.0
✔
✔
✔
✔
✔
✔
DYNAMIC CONTRAST
(LIGHTS OUT TIMER)
0
5
VXX:DYCI3=+00000
VXX:DYCI3=+00005 QVX:DYCI3 00000
00005
✔
✔
✔
✔
DYNAMIC CONTRAST/MANUAL
IRIS
(MANUAL INTENSITY)
OFF
1
255
OAI:M000
OAI:M001
OAI:M255
QAI:M 000
001
255
✔
✔
✔
✔
✔
✔
DYNAMIC CONTRAST
(DYNAMIC GAMMA)
OFF
1
2
3
OAI:D0
OAI:D1
OAI:D2
OAI:D3
QAI:D 0
1
2
3
✔
✔
✔
✔
✔
✔
✔
✔
COLOR SPACE NATIVE
ITU-709
DCI-P3
ITU2020
AUTO1
AUTO2
NTSC
NTSC4.43
PAL
PAL-M
PAL-N
PAL60
SECAM
VXX:CSPI1=+00000
VXX:CSPI1=+00001
VXX:CSPI1=+00002
VXX:CSPI1=+00003
VSG:AT1
VSG:AT2
VSG:NTS
VSG:N44
VSG:PAL
VSG:PAM
VSG:PAN
VSG:P60
VSG:SEC
QVX:CSPI1 CSPI1=+00000
CSPI1=+00001
CSPI1=+00002
CSPI1=+00003
AT1
AT2
NTS
N44
PAL
PAM
PAN
P60
SEC
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
TV-SYSTEM
SYSTEM SELECTOR
RGB(VGA/480P)
VGA60
480P(YCbCr)
480p(RGB)
ORF:0
ORF:1
ORF:3
QRF 0
1
3
✔
✔
✔
✔
✔
✔
SYSTEM SELECTOR
RGB(Other)/DVI/SLOT-DVI
RGB
YPbPr
ORF:0
ORF:1 QRF 0
1
✔
✔
✔
✔
SYSTEM SELECTOR RGB ORF:0 QRF 0 ✔✔
5/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
HDMI/DIGITAL LINK/SLOT-HDMI YPbPr
AUTO
ORF:1
ORF:2 1
2
✔
✔
✔
✔
POSITION
GEOMETRY OFF
KEYSTONE
CURVED
PC-1
PC-2
PC-3
CORNER-CORRECTION
VXX:GMMI0=+00000
VXX:GMMI0=+00001
VXX:GMMI0=+00002
VXX:GMMI0=+00003
VXX:GMMI0=+00004
VXX:GMMI0=+00005
VXX:GMMI0=+00010
QVX:GMMI0 GMMI0=+00000
GMMI0=+00001
GMMI0=+00002
GMMI0=+00003
GMMI0=+00004
GMMI0=+00005
GMMI0=+00010
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
GEOMETRY-KEYSTONE-
LENS THROW RATIO
0.7
16.5
0.1 step VXX:GMKS0=+00.7
VXX:GMKS0=+16.5 QVX:GMKS0 GMKS0=+00.7
GMKS0=+16.5
✔
✔
✔
✔
GEOMETRY-KEYSTONE-
VERTICAL BALANCE
-60
+60
VXX:GMKI4=-00060
VXX:GMKI4=+00060 QVX:GMKI4 GMKI4=-00060
GMKI4=+00060
✔
✔
✔
✔
GEOMETRY-KEYSTONE-
HORIZONTAL BALANCE
-30
+30
VXX:GMKI7=-00030
VXX:GMKI7=+00030 QVX:GMKI7 GMKI7=-00030
GMKI7=+00030
✔
✔
✔
✔
GEOMETRY-KEYSTONE-
VERTICAL KEYSTONE
-40.0 (-45.0)*
+40.0 (+45.0)*
0.2 step VXX:GMKS8=-40.0
VXX:GMKS8=+40.0 QVX:GMKS8 GMKS8=-40.0
GMKS8=+40.0
✔
✔
✔
✔
GEOMETRY-KEYSTONE-
HORIZONTAL KEYSTONE
-15.0 (-40.0)*
+15.0 (+40.0)*
0.2 step VXX:GMKS9=-15.0
VXX:GMKS9=+15.0 QVX:GMKS9 GMKS9=-15.0
GMKS9=+15.0
✔
✔
✔
✔
GEOMETRY-CURVED-LENS THROW
RATIO
0.7
16.5
0.1 step VXX:GMCS0=+00.7
VXX:GMCS0=+16.5 QVX:GMCS0 GMCS0=+00.7
GMCS0=+16.5
✔
✔
✔
✔
GEOMETRY-CURVED-
VERTICAL ARC
-50 (-100)*
+50 (+100)*
VXX:GMCI3=-00050
VXX:GMCI3=+00050 QVX:GMCI3 GMCI3=-00050
GMCI3=+00050
✔
✔
✔
✔
GEOMETRY-CURVED-
HORIZONTAL ARC
-50 (-100)*
+50 (+100)*
VXX:GMCI7=-00050
VXX:GMCI7=+00050 QVX:GMCI7 GMCI7=-00050
GMCI7=+00050
✔
✔
✔
✔
GEOMETRY-CURVED-
VERTICAL BALANCE
-60
+60
VXX:GMCI2=-00060
VXX:GMCI2=+00060 QVX:GMCI2 GMCI2=-00060
GMCI2=+00060
✔
✔
✔
✔
GEOMETRY-CURVED-
HORIZONTAL BALANCE
-30
+30
VXX:GMCI6=-00030
VXX:GMCI6=+00030 QVX:GMCI6 GMCI6=-00030
GMCI6=+00030
✔
✔
✔
✔
GEOMETRY-CURVED-
VERTICAL KEYSTONE
-40.0 (-45.0)*
+40.0 (+45.0)*
0.2 step VXX:GMCS8=-40.0
VXX:GMCS8=+40.0 QVX:GMCS8 GMCS8=-40.0
GMCS8=+40.0
✔
✔
✔
✔
GEOMETRY-CURVED-
HORIZONTAL KEYSTONE
-15.0 (-40.0)*
+15.0 (+40.0)*
0.2 step VXX:GMCS9=-15.0
VXX:GMCS9=+15.0 QVX:GMCS9 GMCS9=-15.0
GMCS9=+15.0
✔
✔
✔
✔
GEOMETRY-CURVED-
MAINTAIN ASPECT RATIO
OFF
ON
VXX:GMCIA=+00000
VXX:GMCIA=+00001 QVX:GMCIA GMCIA=+00000
GMCIA=+00001
✔
✔
✔
✔
GEOMETRY-CORNER
CORRECTION-UPPER LEFT(V)
min.
max.
VXX:GMFI1=+00000
VXX:GMFI1=+00300 QVX:GMFI1 GMFI1=+00000
GMFI1=+00300 0
+300
0
+263
GEOMETRY-CORNER
CORRECTION-UPPER RIGHT(V)
min.
max.
VXX:GMFI2=+00000
VXX:GMFI2=+00300 QVX:GMFI2 GMFI2=+00000
GMFI2=+00300 0
+300
0
+263
GEOMETRY-CORNER
CORRECTION-LOWER LEFT(V)
min.
max.
VXX:GMFI3=-00300
VXX:GMFI3=+00000 QVX:GMFI3 GMFI3=-00300
GMFI3=+00000 -300
0
-263
0
GEOMETRY-CORNER
CORRECTION-LOWER RIGHT(V)
min.
max.
VXX:GMFI4=-00300
VXX:GMFI4=+00000 QVX:GMFI4 GMFI4=-00300
GMFI4=+00000 -300
0
-263
0
GEOMETRY-CORNER
CORRECTION-LINEARITY(V)
min.
max.
VXX:GMFI5=-00127
VXX:GMFI5=+00127 QVX:GMFI5 GMFI5=-00127
GMFI5=+00127 -127
+127
-127
+127
GEOMETRY-CORNER
CORRECTION-UPPER LEFT(H)
min.
max.
VXX:GMFI6=+00000
VXX:GMFI6=+00480 QVX:GMFI6 GMFI6=+00000
GMFI6=+00480 0
+480
0
+350
GEOMETRY-CORNER
CORRECTION-UPPER RIGHT(H)
min.
max.
VXX:GMFI7=-00480
VXX:GMFI7=+00000 QVX:GMFI7 GMFI7=-00480
GMFI7=+00000 -480
0
-350
0
GEOMETRY-CORNER
CORRECTION-LOWER LEFT(H)
min.
max.
VXX:GMFI8=+00000
VXX:GMFI8=+00480 QVX:GMFI8 GMFI8=+00000
GMFI8=+00480 0
+480
0
+350
GEOMETRY-CORNER min. VXX:GMFI9=-00480 QVX:GMFI9 GMFI9=-00480 -480 -350
6/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
CORRECTION-LOWER RIGHT(H) max. VXX:GMFI9=+00000 GMFI9=+00000 0 0
GEOMETRY-CORNER
CORRECTION-LINEARITY(H)
min.
max.
VXX:GMFIA=-00127
VXX:GMFIA=+00127 QVX:GMFIA GMFIA=-00127
GMFIA=+00127 -127
+127
-127
+127
GEOMETRY-
CORNER/PINCUSHION-
min.
max.
VXX:GMFIB=-00100
VXX:GMFIB=+00100 QVX:GMFIB GMFIB=-00100
GMFIB=+00100
✔
✔
✔
✔
GEOMETRY-
CORNER/PINCUSHION-
min.
max.
VXX:GMFIC=-00100
VXX:GMFIC=+00100 QVX:GMFIC GMFIC=-00100
GMFIC=+00100
✔
✔
✔
✔
GEOMETRY-
CORNER/PINCUSHION-
min.
max.
VXX:GMFID=-00100
VXX:GMFID=+00100 QVX:GMFID GMFID=-00100
GMFID=+00100
✔
✔
✔
✔
GEOMETRY-
CORNER/PINCUSHION-
min.
max.
VXX:GMFIE=-00100
VXX:GMFIE=+00100 QVX:GMFIE GMFIE=-00100
GMFIE=+00100
✔
✔
✔
✔
GEOMETRY-
CORNER/PINCUSHION-
AUTO
MANUAL
VXX:GMFIF=+00000
VXX:GMFIF=+00001 QVX:GMFIF GMFIF=+00000
GMFIF=+00001
✔
✔
✔
✔
SHIFT-HORIZONTAL 0
+4095
VTH:0000
VTH:4095 QTH 0000
4095
✔
✔
✔
✔
SHIFT-VERTICAL 0
+4094
VTV:0000
VTV:4094 QTV 0000
4094
✔
✔
✔
✔
CLOCK PHASE 0
+31
VCP:000
VCP:031 QCP 000
063
✔
✔
✔
✔
ASPECT AUTO/VID AUTO/DEFAULT
NORMAL(4:3)
WIDE(16:9)
NATIVE(through)
FULL(HV FIT)
H-FIT
V-FIT
VSE:0
VSE:1
VSE:2
VSE:5
VSE:6
VSE:9
VSE:10
QSE 0
1
2
5
6
9
10
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
ZOOM-HORIZONTAL 50
999
OZH:050
OZH:999 QZH 050
999
✔
✔
✔
✔
ZOOM-VERTICAL 50
999
OZV:050
OZV:999 QZV 050
999
✔
✔
✔
✔
ZOOM-BOTH 50
999
OZO:050
OZO:999 QZO 050
999
✔
✔
✔
✔
ZOOM-INTERLOCKED OFF
ON
OZS:0
OZS:1 QZS 0
1
✔
✔
✔
✔
ZOOM-MODE INTERNAL
FULL
OZT:0
OZT:1 QZT 0
1
✔
✔
✔
✔
DIGITAL CINEMA REALITY AUTO
OFF
30p/25p FIXED
OPD:0
OPD:1
OPD:2
QPD 0
1
2
✔
✔
✔
✔
✔
✔
BLANKING-UPPER min.
max.
DBU:000
DBU:2398 QLU 000
2398 0
1198
0
1048
BLANKING-LOWER min.
max.
DBB:000
DBB:2398 QLB 000
2398 0
1198
0
1048
BLANKING-RIGHT min.
max.
DBR:000
DBR:3838 QLR 000
3838 0
1918
0
1398
BLANKING-LEFT min.
max.
DBL:000
DBL:3838 QLL 000
3838 0
1918
0
1398
INPUT RESOLUTION-
TOTAL DOTS
330
4095
VTD:0330
VTD:4095 QTD 0330
4095
✔
✔
✔
✔
INPUT RESOLUTION-
DISPLAY DOTS
300
4065
VDD:0300
VDD:4065 QDD 0300
4065
✔
✔
✔
✔
INPUT RESOLUTION- 155 VTL:0155 QTL 0155 ✔✔
7/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
ADVANCED
TOTAL LINES 2047 VTL:2047 2047 ✔✔
INPUT RESOLUTION-
DISPLAY LINES
150
2037
VDL:0150
VDL:2037 QDL 0150
2037
✔
✔
✔
✔
CLAMP POSITION 1
255
VLT:001
VLT:255 QLT 001
255
✔
✔
✔
✔
CUSTOM MASKING * OFF
PC-1
PC-2
PC-3
VXX:MSKI1=+00000
VXX:MSKI1=+00001
VXX:MSKI1=+00002
VXX:MSKI1=+00003
QVX:MSKI1 MSKI1=+00000
MSKI1=+00001
MSKI1=+00002
MSKI1=+00003
✔
✔
✔
✔
✔
✔
✔
✔
EDGE BLENDING OFF
ON
USER
VXX:EDBI0=+00000
VXX:EDBI0=+00001
VXX:EDBI0=+00002
QVX:EDBI0 EDBI0=+00000
EDBI0=+00001
EDBI0=+00002
✔
✔
✔
✔
✔
✔
EDGE BLENDING-UPPER ON/OFF OFF
ON
VGU:0
VGU:1 QGU 0
1
✔
✔
✔
✔
EDGE BLENDING-LOWER ON/OFF OFF
ON
VGB:0
VGB:1 QGB 0
1
✔
✔
✔
✔
EDGE BLENDING-LEFT ON/OFF OFF
ON
VGL:0
VGL:1 QGL 0
1
✔
✔
✔
✔
EDGE BLENDING-RIGHT ON/OFF OFF
ON
VGR:0
VGR:1 QGR 0
1
✔
✔
✔
✔
EDGE BLENDING-START-UPPER min.
max.
VEU:0000
VEU:2272 QEU 0000
2272 0
1023
0
1023
EDGE BLENDING-START-LOWER min.
max.
VEB:0000
VEB:2272 QEB 0000
2272 0
1199
0
1199
EDGE BLENDING-START-LEFT min.
max.
VEL:0000
VEL:3712 QEL 0000
3712 0
1023
0
1023
EDGE BLENDING-START-RIGHT min.
max.
VER:0000
VER:3712 QER 0000
3712 0
1919
0
1919
EDGE BLENDING-WIDTH-UPPER min.
max.
VXX:EUWI0=+00000
VXX:EUWI0=+02272 QVX:EUWI0 EUWI0=+00000
EUWI0=+02272 0
1023
0
1023
EDGE BLENDING-WIDTH-LOWER min.
max.
VXX:EBWI0=+00000
VXX:EBWI0=+02272 QVX:EBWI0 EBWI0=+00000
EBWI0=+02272 0
1199
0
1199
EDGE BLENDING-WIDTH-LEFT min.
max.
VXX:ELWI0=+00000
VXX:ELWI0=+03712 QVX:ELWI0 ELWI0=+00000
ELWI0=+03712 0
1023
0
1023
EDGE BLENDING-WIDTH-RIGHT min.
max.
VXX:ERWI0=+00000
VXX:ERWI0=+03712 QVX:ERWI0 ERWI0=+00000
ERWI0=+03712 0
1919
0
1919
EDGE BLENDING-MARKER-ON/OFF OFF
ON
VGM:0
VGM:1 QGM 0
1
✔
✔
✔
✔
EDGE BLENDING-NON-
OVERLAPPED BLACK LEVEL
0 (W,R,G,B)
255 (W,R,G,B)
VJI:000.000.000.000
VJI:255.255.255.255 QJI 000.000.000.000
255.255.255.255
✔
✔
✔
✔
EDGE BLENDING-NON-
OVERLAPPED BLACK LEVEL-
OFF
ON
VXX:EBII1=+00000
VXX:EBII1=+00001 QVX:EBII1 EBII1=+00000
EBII1=+00001
✔
✔
✔
✔
EDGE BLENDING-BLACK BORDER
LEVEL
0 (W,R,G,B)
255 (W,R,G,B)
VJO:000,000,000,000
VJO:255,255,255,255 QJO 000.000.000.000
255.255.255.255
✔
✔
✔
✔
EDGE BLENDING-BLACK BORDER
LEVEL-INTERLOCKED
OFF
ON
VXX:EBII2=+00000
VXX:EBII2=+00001 QVX:EBII2 EBII2=+00000
EBII2=+00001
✔
✔
✔
✔
EDGE BLENDING-BLACK BORDER
WIDTH-UPPER
min.
max.
VJU:0000
VJU:2272 QJU 0000
2272 0
1023
0
1023
EDGE BLENDING-BLACK BORDER
WIDTH-LOWER
min.
max.
VJB:0000
VJB:2272 QJB 0000
2272 0
1199
0
1199
EDGE BLENDING-BLACK BORDER
WIDTH-LEFT
min.
max.
VJL:0000
VJL:3712 QJL 0000
3712 0
1023
0
1023
8/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
EDGE BLENDING-BLACK BORDER
WIDTH-RIGHT
min.
max.
VJR:0000
VJR:3712 QJR 0000
3712 0
1919
0
1919
EDGE BLENDING-BLACK BORDER
WIDTH-UPPER KEYSTONE AREA
min.
max.
VXX:EBBI4=-02272
VXX:EBBI4=+02272 QVX:EBBI4 EBBI4=-02272
EBBI4=+02272 -1199
1919
-1199
1919
EDGE BLENDING-BLACK BORDER
WIDTH-LOWER KEYSTONE AREA
min.
max.
VXX:EBBI5=-02272
VXX:EBBI5=+02272 QVX:EBBI5 EBBI5=-02272
EBBI5=+02272 -1199
1919
-1199
1919
EDGE BLENDING-BLACK BORDER
WIDTH-LEFT KEYSTONE AREA
min.
max.
VXX:EBBI6=-03712
VXX:EBBI6=+03712 QVX:EBBI6 EBBI6=-03712
EBBI6=+03712 -1199
1919
-1199
1919
EDGE BLENDING-BLACK BORDER
WIDTH-RIGHT KEYSTONE AREA
min.
max.
VXX:EBBI7=-03712
VXX:EBBI7=+03712 QVX:EBBI7 EBBI7=-03712
EBBI7=+03712 -1199
1919
-1199
1919
EDGE BLENDING-OVERLAPPED
BLACK LEVEL-UPPER
0 (W,R,G,B)
255 (W,R,G,B)
VXX:EBBS0=000,000,000,000
VXX:EBBS0=255,255,255,255 QVX:EBBS0 EBBS0=000,000,000,000
EBBS0=255,255,255,255
✔
✔
✔
✔
EDGE BLENDING-OVERLAPPED
BLACK LEVEL-LOWER
0 (W,R,G,B)
255 (W,R,G,B)
VXX:EBBS1=000,000,000,000
VXX:EBBS1=255,255,255,255 QVX:EBBS1 EBBS1=000,000,000,000
EBBS1=255,255,255,255
✔
✔
✔
✔
EDGE BLENDING-OVERLAPPED
BLACK LEVEL-LEFT
0 (W,R,G,B)
255 (W,R,G,B)
VXX:EBBS2=000,000,000,000
VXX:EBBS2=255,255,255,255 QVX:EBBS2 EBBS2=000,000,000,000
EBBS2=255,255,255,255
✔
✔
✔
✔
EDGE BLENDING-OVERLAPPED
BLACK LEVEL-RIGHT
0 (W,R,G,B)
255 (W,R,G,B)
VXX:EBBS3=000,000,000,000
VXX:EBBS3=255,255,255,255 QVX:EBBS3 EBBS3=000,000,000,000
EBBS3=255,255,255,255
✔
✔
✔
✔
EDGE BLENDING-OVERLAPPED
BLACK LEVEL-UPPER
OFF
ON
VXX:EBII3=+00000
VXX:EBII3=+00001 QVX:EBII3 EBII3=+00000
EBII3=+00001
✔
✔
✔
✔
EDGE BLENDING-OVERLAPPED
BLACK LEVEL-LOWER
OFF
ON
VXX:EBII4=+00000
VXX:EBII4=+00001 QVX:EBII4 EBII4=+00000
EBII4=+00001
✔
✔
✔
✔
EDGE BLENDING-OVERLAPPED
BLACK LEVEL-LEFT INTERLOCKED
OFF
ON
VXX:EBII5=+00000
VXX:EBII5=+00001 QVX:EBII5 EBII5=+00000
EBII5=+00001
✔
✔
✔
✔
EDGE BLENDING-OVERLAPPED
BLACK LEVEL-RIGHT
OFF
ON
VXX:EBII6=+00000
VXX:EBII6=+00001 QVX:EBII6 EBII6=+00000
EBII6=+00001
✔
✔
✔
✔
EDGE BLENDING-AUTO
TESTPATTERN
OFF
ON
VXX:EATI1=+00000
VXX:EATI1=+00001 QVX:EATI1 EATI1=+00000
EATI1=+00001
✔
✔
✔
✔
FRAME RESPONSE NORMAL
FAST
FIXED
VXX:FDYI0=+00000
VXX:FDYI0=+00001
VXX:FDYI0=+00005
QVX:FDYI0 FDYI0=+00000
FDYI0=+00001
FDYI0=+00005
✔
✔
✔
✔
✔
✔
FRAME DELAY 0.00
100.00
VXX:FDYS1=+0.00
VXX:FDYS1=+100.00 QVX:FDYS1 FDYS1=+0.00
FDYS1=+100.00
✔
✔
✔
✔
FRAME CREATION OFF
1
2
3
VXX:FRCI1=+00000
VXX:FRCI1=+00001
VXX:FRCI1=+00002
VXX:FRCI1=+00003
QVX:FRCI1 FRCI1=+00000
FRCI1=+00001
FRCI1=+00002
FRCI1=+00003
✔
✔
✔
✔
✔
✔
✔
✔
FILM DETECTION OFF
ON
VXX:FDTI1=+00000
VXX:FDTI1=+00001 QVX:FDTI1 FDTI1=+00000
FDTI1=+00001
✔
✔
✔
✔
RASTER POSITION-HORIZONTAL -2048
+2047
VRH:2952
VRH:7047 QRH 2952
7047
✔
✔
✔
✔
RASTER POSITION-VERTICAL -2048
+2047
VRV:2952
VRV:7047 QRV 2952
7047
✔
✔
✔
✔
DISPLAY
LANGUAGE
LANGUAGE English
German
French
Spanish
Italian
Japanese
Chinese
Russian
Korea
OLG:ENG
OLG:DEU
OLG:FRA
OLG:ESP
OLG:ITL
OLG:JPN
OLG:CHI
OLG:RUS
OLG:KOR
QLG ENG
DEU
FRA
ESP
ITL
JPN
CHI
RUS
KOR
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
9/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
Portuguse OLG:POR POR ✔✔
3D
SETTINGS
3D SYSTEM SETTING SINGLE
DUAL(LEFT)
DUAL(RIGHT)
VXX:DSYI1=+00000
VXX:DSYI1=+00001
VXX:DSYI1=+00002
QVX:DSYI1 DSYI1=+00000
DSYI1=+00001
DSYI1=+00002
✔
✔
✔
✔
✔
✔
3D FILTER AUTO
OFF
ON
VXX:DFTI1=+00000
VXX:DFTI1=+00001
VXX:DFTI1=+00002
QVX:DFTI1 DFTI1=+00000
DFTI1=+00001
DFTI1=+00002
✔
✔
✔
✔
✔
✔
3D SYNC SETTING OFF
1
2
3
4
5
6
7
8
9
10
11
VXX:DSNI1=+00000
VXX:DSNI1=+00001
VXX:DSNI1=+00002
VXX:DSNI1=+00003
VXX:DSNI1=+00004
VXX:DSNI1=+00005
VXX:DSNI1=+00006
VXX:DSNI1=+00007
VXX:DSNI1=+00008
VXX:DSNI1=+00009
VXX:DSNI1=+00010
VXX:DSNI1=+00011
QVX:DSNI1 DSNI1=+00000
DSNI1=+00001
DSNI1=+00002
DSNI1=+00003
DSNI1=+00004
DSNI1=+00005
DSNI1=+00006
DSNI1=+00007
DSNI1=+00008
DSNI1=+00009
DSNI1=+00010
DSNI1=+00011
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
3D SYNC SETTING-STEREO SYNC
OUTPUT DELAY
0
25000
10 step VXX:DSNI2=+00000
VXX:DSNI2=+25000 QVX:DSNI2 DSNI2=+00000
DSNI2=+25000
✔
✔
✔
✔
3D SIMUL INPUT SETTING-
L:RGB1/R:RGB2
OFF
AUTO
VXX:DSMI1=+00000
VXX:DSMI1=+00002 QVX:DSMI1 DSMI1=+00000
DSMI1=+00002
✔
✔
✔
✔
3D SIMUL INPUT SETTING-
L:HDMI/R:DVI-D
OFF
AUTO
VXX:DSMI2=+00000
VXX:DSMI2=+00002 QVX:DSMI2 DSMI2=+00000
DSMI2=+00002
✔
✔
✔
✔
3D SIMUL INPUT SETTING-
L:SDI1/R:SDI2
OFF
AUTO
VXX:DSMI3=+00000
VXX:DSMI3=+00002 QVX:DSMI3 DSMI3=+00000
DSMI3=+00002
✔
✔
✔
✔
3D INPUT FORMAT AUTO
NATIVE(2D)
SIMULTANEOUS
SIDE BY SIDE
TOP AND BOTTOM
LINE BY LINE
FRAME SEQUENTIAL
VXX:DIFI1=+00000
VXX:DIFI1=+00001
VXX:DIFI1=+00002
VXX:DIFI1=+00003
VXX:DIFI1=+00004
VXX:DIFI1=+00005
VXX:DIFI1=+00006
QVX:DIFI1 DIFI1=+00000
DIFI1=+00001
DIFI1=+00002
DIFI1=+00003
DIFI1=+00004
DIFI1=+00005
DIFI1=+00006
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
3D LEFT/RIGHT SWAP NORMAL
SWAPPED
VXX:DSWI1=+00000
VXX:DSWI1=+00001 QVX:DSWI1 DSWI1=+00000
DSWI1=+00001
✔
✔
✔
✔
3D COLOR MATCHING SHARED 2D/3D
SEPARATE 2D/3D
VXX:DCMI1=+00000
VXX:DCMI1=+00001 QVX:DCMI1 DCMI1=+00000
DCMI1=+00001
✔
✔
✔
✔
3D PICTURE BALANCE 80
120
VXX:DBAI1=+00080
VXX:DBAI1=+00120 QVX:DBAI1 DBDI1=+00080
DBAI1=+00120
✔
✔
✔
✔
3D PICTURE BALANCE-WHITE
BALANCE HIGH RED
80
120
VXX:DBAI2=+00080
VXX:DBAI2=+00120 QVX:DBAI2 DBDI2=+00080
DBAI2=+00120
✔
✔
✔
✔
3D PICTURE BALANCE-WHITE
BALANCE HIGH GREEN
80
120
VXX:DBAI3=+00080
VXX:DBAI3=+00120 QVX:DBAI3 DBDI3=+00080
DBAI3=+00120
✔
✔
✔
✔
3D PICTURE BALANCE-WHITE
BALANCE HIGH BLUE
80
120
VXX:DBAI4=+00080
VXX:DBAI4=+00120 QVX:DBAI4 DBDI4=+00080
DBAI4=+00120
✔
✔
✔
✔
3D PICTURE BALANCE-
BRIGHTNESS
-8
+8
VXX:DBAI5=-00008
VXX:DBAI5=+00008 QVX:DBAI5 DBDI5=-00008
DBAI5=+00008
✔
✔
✔
✔
3D PICTURE BALANCE-WHITE
BALANCE LOW RED
-8
+8
VXX:DBAI6=-00008
VXX:DBAI6=+00008 QVX:DBAI6 DBDI6=-00008
DBAI6=+00008
✔
✔
✔
✔
3D PICTURE BALANCE-WHITE
BALANCE LOW GREEN
-8
+8
VXX:DBAI7=-00008
VXX:DBAI7=+00008 QVX:DBAI7 DBDI7=-00008
DBAI7=+00008
✔
✔
✔
✔
10/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
3D PICTURE BALANCE-WHITE
BALANCE LOW BLUE
-8
+8
VXX:DBAI8=-00008
VXX:DBAI8=+00008 QVX:DBAI8 DBDI8=-00008
DBAI8=+00008
✔
✔
✔
✔
3D PICTURE BALANCE-COLOR 80
120
VXX:DBAI9=+00080
VXX:DBAI9=+00120 QVX:DBAI9 DBDI9=+00080
DBAI9=+00120
✔
✔
✔
✔
3D PICTURE BALANCE-TINT -8
+8
VXX:DBAIA=-00008
VXX:DBAIA=+00008 QVX:DBAIA DBDIA=-00008
DBAIA=+00008
✔
✔
✔
✔
3D DARK TIME SETTING 0.5
1.0
1.5
2.0
2.5
2.7
VXX:DDTS1=+0.5
VXX:DDTS1=+1.0
VXX:DDTS1=+1.5
VXX:DDTS1=+2.0
VXX:DDTS1=+2.5
VXX:DDTS1=+2.7
QVX:DDTS1 DDTS1=+0.5
DDTS1=+1.0
DDTS1=+1.5
DDTS1=+2.0
DDTS1=+2.5
DDTS1=+2.7
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
3D FRAME DELAY 0
25000
VXX:DFDI1=+00000
VXX:DFDI1=+25000 QVX:DFDI1 DFDI1=+00000
DFDI1=+25000
✔
✔
✔
✔
3D TEST MODE NORMAL
SIDE BY SIDE
LEFT/LEFT
RIGHT/RIGHT
LEFT/BLACK
BLACK/RIGHT
VXX:DTSI1=+00000
VXX:DTSI1=+00001
VXX:DTSI1=+00002
VXX:DTSI1=+00003
VXX:DTSI1=+00004
VXX:DTSI1=+00005
QVX:DTSI1 DTSI1=+00000
DTSI1=+00001
DTSI1=+00002
DTSI1=+00003
DTSI1=+00004
DTSI1=+00005
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
3D SAFETY PRECAUTIONS
MESSAGE
OFF
ON
VXX:DMGI1=+00000
VXX:DMGI1=+00001 QVX:DMGI1 DMGI1=+00000
DMGI1=+00001
✔
✔
✔
✔
COLOR MATCHING OFF
3COLORS
7COLORS
MEASURED
VXX:CMAI0=+00000
VXX:CMAI0=+00001
VXX:CMAI0=+00002
VXX:CMAI0=+00004
QVX:CMAI0 CMAI0=+00000
CMAI0=+00001
CMAI0=+00002
CMAI0=+00004
✔
✔
✔
✔
✔
✔
✔
✔
COLOR MATCHING-3COLOR-RED 0 (R,G,B)
2048,2048,2048(R,G,B)
VMR:0000,0000,0000
VMR:2048,2048,2048 QMR 0000,0000,0000
2048,2048,2048
✔
✔
✔
✔
COLOR MATCHING-3COLOR-GREEN
0 (R,G,B)
2048,2048,2048(R,G,B)
VMG:0000,0000,0000
VMG:2048,2048,2048 QMG 0000,0000,0000
2048,2048,2048
✔
✔
✔
✔
COLOR MATCHING-3COLOR-BLUE 0 (R,G,B)
2048,2048,2048(R,G,B)
VMB:0000,0000,0000
VMB:2048,2048,2048 QMB 0000,0000,0000
2048,2048,2048
✔
✔
✔
✔
COLOR MATCHING-3COLOR-AUTO
TESTPATTERN
OFF
ON
VXX:CATI0=+00000
VXX:CATI0=+00001 QVX:CATI0 CATI0=+00000
CATI0=+00001
✔
✔
✔
✔
COLOR MATCHING-7COLOR-RED 0 (R,G,B)
2048(R,G,B)
VXX:C7CS0=0000,0000,0000
VXX:C7CS0=2048,2048,2048 QVX:C7CS0 C7CS0=0000,0000,0000
C7CS0=2048,2048,2048
✔
✔
✔
✔
COLOR MATCHING-7COLOR-GREEN
0 (R,G,B)
2048(R,G,B)
VXX:C7CS1=0000,0000,0000
VXX:C7CS1=2048,2048,2048 QVX:C7CS1 C7CS1=0000,0000,0000
C7CS1=2048,2048,2048
✔
✔
✔
✔
COLOR MATCHING-7COLOR-BLUE 0 (R,G,B)
2048(R,G,B)
VXX:C7CS2=0000,0000,0000
VXX:C7CS2=2048,2048,2048 QVX:C7CS2 C7CS2=0000,0000,0000
C7CS2=2048,2048,2048
✔
✔
✔
✔
COLOR MATCHING-7COLOR-CYAN 0 (R,G,B)
2048(R,G,B)
VXX:C7CS3=0000,0000,0000
VXX:C7CS3=2048,2048,2048 QVX:C7CS3 C7CS3=0000,0000,0000
C7CS3=2048,2048,2048
✔
✔
✔
✔
COLOR MATCHING-7COLOR-MAGEN
0 (R,G,B)
2048(R,G,B)
VXX:C7CS4=0000,0000,0000
VXX:C7CS4=2048,2048,2048 QVX:C7CS4 C7CS4=0000,0000,0000
C7CS4=2048,2048,2048
✔
✔
✔
✔
COLOR MATCHING-7COLOR-YELLO 0 (R,G,B)
2048(R,G,B)
VXX:C7CS5=0000,0000,0000
VXX:C7CS5=2048,2048,2048 QVX:C7CS5 C7CS5=0000,0000,0000
C7CS5=2048,2048,2048
✔
✔
✔
✔
COLOR MATCHING-7COLOR-WHITE
0 (R,G,B)
2048(R,G,B)
VXX:C7CS6=0000,0000,0000
VXX:C7CS6=2048,2048,2048 QVX:C7CS6 C7CS6=0000,0000,0000
C7CS6=2048,2048,2048
✔
✔
✔
✔
COLOR MATCHING-7COLOR-AUTO
TESTPATTERN
OFF
ON
VXX:CATI1=+00000
VXX:CATI1=+00001 QVX:CATI1 CATI1=+00000
CATI1=+00001
✔
✔
✔
✔
COLOR MATCHING-MEASURED
MODE-MEASURED DATA BLACK
0,1,1 (Y,x,y)
65535,999,999(Y,x,y)
VXX:CMMS0=00000,0001,0001
VXX:CMMS0=65535,0999,0999 QVX:CMMS0 CMMS0=00000,0001,0001
CMMS0=65535,0999,0999
✔
✔
✔
✔
11/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
COLOR MATCHING-MEASURED
MODE-MEASURED DATA RED
0,1,1 (Y,x,y)
65535,999,999(Y,x,y)
VXX:CMMS1=00000,0001,0001
VXX:CMMS1=65535,0999,0999 QVX:CMMS1 CMMS1=00000,0001,0001
CMMS1=65535,0999,0999
✔
✔
✔
✔
COLOR MATCHING-MEASURED
MODE-MEASURED DATA GREEN
0,1,1 (Y,x,y)
65535,999,999(Y,x,y)
VXX:CMMS2=00000,0001,0001
VXX:CMMS2=65535,0999,0999 QVX:CMMS2 CMMS2=00000,0001,0001
CMMS2=65535,0999,0999
✔
✔
✔
✔
COLOR MATCHING-MEASURED
MODE-MEASURED DATA BLUE
0,1,1 (Y,x,y)
65535,999,999(Y,x,y)
VXX:CMMS3=00000,0001,0001
VXX:CMMS3=65535,0999,0999 QVX:CMMS3 CMMS3=00000,0001,0001
CMMS3=65535,0999,0999
✔
✔
✔
✔
COLOR MATCHING-MEASURED
MODE-MEASURED DATA WHITE
0,1,1 (Y,x,y)
65535,999,999(Y,x,y)
VXX:CMMS4=00000,0001,0001
VXX:CMMS4=65535,0999,0999 QVX:CMMS4 CMMS4=00000,0001,0001
CMMS4=65535,0999,0999
✔
✔
✔
✔
COLOR MATCHING-MEASURED
MODE-TARGET DATA RED
0,1,1 (Y,x,y)
65535,999,999(Y,x,y)
VXX:CMTS0=00000,0001,0001
VXX:CMTS0=65535,0999,0999 QVX:CMTS0 CMTS0=00000,0001,0001
CMTS0=65535,0999,0999
✔
✔
✔
✔
COLOR MATCHING-MEASURED
MODE-TARGET DATA GREEN
0,1,1 (Y,x,y)
65535,999,999(Y,x,y)
VXX:CMTS1=00000,0001,0001
VXX:CMTS1=65535,0999,0999 QVX:CMTS1 CMTS1=00000,0001,0001
CMTS1=65535,0999,0999
✔
✔
✔
✔
COLOR MATCHING-MEASURED
MODE-TARGET DATA BLUE
0,1,1 (Y,x,y)
65535,999,999(Y,x,y)
VXX:CMTS2=00000,0001,0001
VXX:CMTS2=65535,0999,0999 QVX:CMTS2 CMTS2=00000,0001,0001
CMTS2=65535,0999,0999
✔
✔
✔
✔
COLOR MATCHING-MEASURED
MODE-TARGET DATA CYAN
0,1,1 (Y,x,y)
65535,999,999(Y,x,y)
VXX:CMTS3=00000,0001,0001
VXX:CMTS3=65535,0999,0999 QVX:CMTS3 CMTS3=00000,0001,0001
CMTS3=65535,0999,0999
✔
✔
✔
✔
COLOR MATCHING-MEASURED
MODE-TARGET DATA MAGENTA
0,1,1 (Y,x,y)
65535,999,999(Y,x,y)
VXX:CMTS4=00000,0001,0001
VXX:CMTS4=65535,0999,0999 QVX:CMTS4 CMTS4=00000,0001,0001
CMTS4=65535,0999,0999
✔
✔
✔
✔
COLOR MATCHING-MEASURED
MODE-TARGET DATA YELLOW
0,1,1 (Y,x,y)
65535,999,999(Y,x,y)
VXX:CMTS5=00000,0001,0001
VXX:CMTS5=65535,0999,0999 QVX:CMTS5 CMTS5=00000,0001,0001
CMTS5=65535,0999,0999
✔
✔
✔
✔
COLOR MATCHING-MEASURED
MODE-TARGET DATA WHITE
0,1,1 (Y,x,y)
65535,999,999(Y,x,y)
VXX:CMTS6=00000,0001,0001
VXX:CMTS6=65535,0999,0999 QVX:CMTS6 CMTS6=00000,0001,0001
CMTS6=65535,0999,0999
✔
✔
✔
✔
COLOR MATCHING-MEASURED
MODE-AUTO TESTPATTERN
OFF
ON
VXX:CATI3=+00000
VXX:CATI3=+00001 QVX:CATI3 CATI3=+00000
CATI3=+00001
✔
✔
✔
✔
AUTO SIGNAL OFF
ON
VXX:AASI0=+00000
VXX:AASI0=+00001 QVX:AASI0 AASI0=+00000
AASI0=+00001
✔
✔
✔
✔
AUTO SETUP -MODE USER
DEFAULT
WIDE
OAM:0
OAM:1
OAM:2
QAM 0
1
2
✔
✔
✔
✔
✔
✔
AUTO SETUP -POSITION ADJ. OFF
ON
VXX:APAI0=+00000
VXX:APAI0=+00001 QVX:APAI0 APAI0=+00000
APAI0=+00001
✔
✔
✔
✔
AUTO SETUP -SIGNAL LEVEL ADJ. OFF
ON
VXX:ASLI0=+00000
VXX:ASLI0=+00001 QVX:ASLI0 ASLI0=+00000
ASLI0=+00001
✔
✔
✔
✔
BACKUP INPUT SETTING-BACKUP
INPUT
PRIMARY
SECONDARY
TOGGLE
VXX:BACI1=+00001
VXX:BACI1=+00002
VXX:BACI1=+00010
QVX:BACI1 BACI1=+00001
BACI1=+00002
BACI1=+00010
✔
✔
✔
✔
✔
✔
BACKUP INPUT SETTING-BACKUP
INPUT MODE
OFF
ON/1
2
3
4
OFF
AUTO (3D)
VXX:BACI2=+00000
VXX:BACI2=+00001
VXX:BACI2=+00002
VXX:BACI2=+00003
VXX:BACI2=+00004
VXX:SIMI1=+00000
VXX:SIMI1=+00002
QVX:BACI2
QVX:SIMI1
BACI2=+00000
BACI2=+00001
BACI2=+00002
BACI2=+00003
BACI2=+00004
SIMI1=+00000
SIMI1=+00002
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
SIMUL INPUT SETTING - RGB IN
SIMUL INPUT SETTING -
HDMI/DVI IN
OFF
AUTO (2D)
AUTO (3D)
VXX:SIMI2=+00000
VXX:SIMI2=+00001
VXX:SIMI2=+00002
QVX:SIMI2 SIMI2=+00000
SIMI2=+00001
SIMI2=+00002
✔
✔
✔
✔
✔
✔
SIMUL INPUT SETTING - SDI IN OFF
AUTO (2D)
AUTO (3D)
VXX:SIMI3=+00000
VXX:SIMI3=+00001
VXX:SIMI3=+00002
QVX:SIMI3 SIMI3=+00000
SIMI3=+00001
SIMI3=+00002
✔
✔
✔
✔
✔
✔
RGB IN-RGB1 SYNC SLICE LEVEL LOW
HIGH
VXX:STRI0=+00000
VXX:STRI0=+00001 QVX:STRI0 STRI0=+00000
STRI0=+00001
✔
✔
✔
✔
RGB IN-RGB1 EDID MODE DEFAULT VXX:EDMI7=+00000 QVX:EDMI7 EDMI7=+00000 ✔✔
12/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
SCREEB FIT
USER
VXX:EDMI7=+00001
VXX:EDMI7=+00010 EDMI7=+00001
EDMI7=+00010
✔
✔
✔
✔
RGB IN-RGB2 SYNC SLICE LEVEL LOW
HIGH
VXX:STRI1=+00000
VXX:STRI1=+00001 QVX:STRI1 STRI1=+00000
STRI1=+00001
✔
✔
✔
✔
RGB IN-RGB2 EDID MODE DEFAULT
SCREEB FIT
USER
VXX:EDMI1=+00000
VXX:EDMI1=+00001
VXX:EDMI1=+00010
QVX:EDMI1 EDMI1=+00000
EDMI1=+00001
EDMI1=+00010
✔
✔
✔
✔
✔
✔
RGB IN-RGB2 EDID RESOLUTION 1024x768p
1280x720p
1280x768p
1280x800p
1280x1024p
1366x768p
1400x1050p
1440x900p
1600x900p
1600x1200p
1680x1050p
1920x1080p
1920x1080i
1920x1200p
VXX:EDRS1=1024:0768:p
VXX:EDRS1=1280:0720:p
VXX:EDRS1=1280:0768:p
VXX:EDRS1=1280:0800:p
VXX:EDRS1=1280:1024:p
VXX:EDRS1=1366:0768:p
VXX:EDRS1=1400:1050:p
VXX:EDRS1=1440:0900:p
VXX:EDRS1=1600:0900:p
VXX:EDRS1=1600:1200:p
VXX:EDRS1=1680:1050:p
VXX:EDRS1=1920:1080:p
VXX:EDRS1=1920:1080:i
VXX:EDRS1=1920:1200:p
QVX:EDRS1 EDRS1=1024:0768:p
EDRS1=1280:0720:p
EDRS1=1280:0768:p
EDRS1=1280:0800:p
EDRS1=1280:1024:p
EDRS1=1366:0768:p
EDRS1=1400:1050:p
EDRS1=1440:0900:p
EDRS1=1600:0900:p
EDRS1=1600:1200:p
EDRS1=1680:1050:p
EDRS1=1920:1080:p
EDRS1=1920:1080:i
EDRS1=1920:1200:p
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
RGB IN-RGB2 EDID VERTICAL
SCAN FREQUENCY
60Hz
50Hz
48Hz
30Hz
25Hz
24Hz
VXX:EDVI1=+06000
VXX:EDVI1=+05000
VXX:EDVI1=+04800
VXX:EDVI1=+03000
VXX:EDVI1=+02500
VXX:EDVI1=+02400
QVX:EDVI1 EDVI1=+06000
EDVI1=+05000
EDVI1=+04800
EDVI1=+03000
EDVI1=+02500
EDVI1=+02400
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
DVI-D IN-EDID EDID1
EDID2(PC)
EDID3
OED:1
OED:2
OED:3
QED 1
2
3
✔
✔
✔
✔
✔
✔
DVI-D IN-SIGNAL LEVEL 0-255 PC
15-235
AUTO
VXX:DVII0=+00000
VXX:DVII0=+00001
VXX:DVII0=+00002
QVX:DVII0 DVII0=+00000
DVII0=+00001
DVII0=+00002
✔
✔
✔
✔
✔
✔
DVI-D IN-EDID MODE DEFAULT
SCREEN FIT
USER
VXX:EDMI2=+00000
VXX:EDMI2=+00001
VXX:EDMI2=+00010
QVX:EDMI0 EDMI2=+00000
EDMI2=+00001
EDMI2=+00010
✔
✔
✔
✔
✔
✔
DVI-D IN-EDID RESOLUTION 1024x768p
1280x720p
1280x768p
1280x800p
1280x1024p
1366x768p
1400x1050p
1440x900p
1600x900p
1600x1200p
1680x1050p
1920x1080p
1920x1080i
1920x1200p
VXX:EDRS2=1024:0768:p
VXX:EDRS2=1280:0720:p
VXX:EDRS2=1280:0768:p
VXX:EDRS2=1280:0800:p
VXX:EDRS2=1280:1024:p
VXX:EDRS2=1366:0768:p
VXX:EDRS2=1400:1050:p
VXX:EDRS2=1440:0900:p
VXX:EDRS2=1600:0900:p
VXX:EDRS2=1600:1200:p
VXX:EDRS2=1680:1050:p
VXX:EDRS2=1920:1080:p
VXX:EDRS2=1920:1080:i
VXX:EDRS2=1920:1200:p
QVX:EDRS2 EDRS2=1024:0768:p
EDRS2=1280:0720:p
EDRS2=1280:0768:p
EDRS2=1280:0800:p
EDRS2=1280:1024:p
EDRS2=1366:0768:p
EDRS2=1400:1050:p
EDRS2=1440:0900:p
EDRS2=1600:0900:p
EDRS2=1600:1200:p
EDRS2=1680:1050:p
EDRS2=1920:1080:p
EDRS2=1920:1080:i
EDRS2=1920:1200:p
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
DVI-D IN-EDID VERTICAL SCAN
FREQUENCY
60Hz
50Hz
VXX:EDVI2=+06000
VXX:EDVI2=+05000 QVX:EDVI2 EDVI2=+06000
EDVI2=+05000
✔
✔
✔
✔
13/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
48Hz
30Hz
25Hz
24Hz
VXX:EDVI2=+04800
VXX:EDVI2=+03000
VXX:EDVI2=+02500
VXX:EDVI2=+02400
EDVI2=+04800
EDVI2=+03000
EDVI2=+02500
EDVI2=+02400
✔
✔
✔
✔
✔
✔
✔
✔
HDMI IN-SIGNAL LEVEL 0-1023
64-940
AUTO
VXX:HSLI0=+00000
VXX:HSLI0=+00001
VXX:HSLI0=+00002
QVX:HSLI0 HSLI0=+00000
HSLI0=+00001
HSLI0=+00002
✔
✔
✔
✔
✔
✔
HDMI IN-EDID MODE DEFAULT
SCREEN FIT
USER
VXX:EDMI3=+00000
VXX:EDMI3=+00001
VXX:EDMI3=+00010
QVX:EDMI3 EDMI3=+00000
EDMI3=+00001
EDMI3=+00010
✔
✔
✔
✔
✔
✔
HDMI IN-EDID RESOLUTION 1024x768p
1280x720p
1280x768p
1280x800p
1280x1024p
1366x768p
1400x1050p
1440x900p
1600x900p
1600x1200p
1680x1050p
1920x1080p
1920x1080i
1920x1200p
VXX:EDRS3=1024:0768:p
VXX:EDRS3=1280:0720:p
VXX:EDRS3=1280:0768:p
VXX:EDRS3=1280:0800:p
VXX:EDRS3=1280:1024:p
VXX:EDRS3=1366:0768:p
VXX:EDRS3=1400:1050:p
VXX:EDRS3=1440:0900:p
VXX:EDRS3=1600:0900:p
VXX:EDRS3=1600:1200:p
VXX:EDRS3=1680:1050:p
VXX:EDRS3=1920:1080:p
VXX:EDRS3=1920:1080:i
VXX:EDRS3=1920:1200:p
QVX:EDRS3 EDRS3=1024:0768:p
EDRS3=1280:0720:p
EDRS3=1280:0768:p
EDRS3=1280:0800:p
EDRS3=1280:1024:p
EDRS3=1366:0768:p
EDRS3=1400:1050:p
EDRS3=1440:0900:p
EDRS3=1600:0900:p
EDRS3=1600:1200:p
EDRS3=1680:1050:p
EDRS3=1920:1080:p
EDRS3=1920:1080:i
EDRS3=1920:1200:p
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
HDMI IN-EDID VERTICAL SCAN
FREQUENCY
60Hz
50Hz
48Hz
30Hz
25Hz
24Hz
VXX:EDVI3=+06000
VXX:EDVI3=+05000
VXX:EDVI3=+04800
VXX:EDVI3=+03000
VXX:EDVI3=+02500
VXX:EDVI3=+02400
QVX:EDVI3 EDVI3=+06000
EDVI3=+05000
EDVI3=+04800
EDVI3=+03000
EDVI3=+02500
EDVI3=+02400
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
DIGITAL LINK-SIGNAL LEVEL 0-1023
64-940
AUTO
VXX:DKLI0=+00000
VXX:DKLI0=+00001
VXX:DKLI0=+00002
QVX:DKLI0 DKLI0=+00000
DKLI0=+00001
DKLI0=+00002
✔
✔
✔
✔
✔
✔
DIGITAL LINK-SIGNAL LEVEL AUTO
0-1023
64-940
VXX:DKLI1=+00000
VXX:DKLI1=+00001
VXX:DKLI1=+00002
QVX:DKLI1 DKLI1=+00000
DKLI1=+00001
DKLI1=+00002
✔
✔
✔
✔
✔
✔
DIGITAL LINK-EDID MODE DEFAULT
SCREEN FIT
USER
VXX:EDMI4=+00000
VXX:EDMI4=+00001
VXX:EDMI4=+00010
QVX:EDMI4 EDMI4=+00000
EDMI4=+00001
EDMI4=+00010
✔
✔
✔
✔
✔
✔
DIGITAL LINK-EDID RESOLUTION 1024x768p
1280x720p
1280x768p
1280x800p
1280x1024p
1366x768p
1400x1050p
1440x900p
1600x900p
1600x1200p
1680x1050p
1920x1080p
1920x1080i
VXX:EDRS4=1024:0768:p
VXX:EDRS4=1280:0720:p
VXX:EDRS4=1280:0768:p
VXX:EDRS4=1280:0800:p
VXX:EDRS4=1280:1024:p
VXX:EDRS4=1366:0768:p
VXX:EDRS4=1400:1050:p
VXX:EDRS4=1440:0900:p
VXX:EDRS4=1600:0900:p
VXX:EDRS4=1600:1200:p
VXX:EDRS4=1680:1050:p
VXX:EDRS4=1920:1080:p
VXX:EDRS4=1920:1080:i
QVX:EDRS4 EDRS4=1024:0768:p
EDRS4=1280:0720:p
EDRS4=1280:0768:p
EDRS4=1280:0800:p
EDRS4=1280:1024:p
EDRS4=1366:0768:p
EDRS4=1400:1050:p
EDRS4=1440:0900:p
EDRS4=1600:0900:p
EDRS4=1600:1200:p
EDRS4=1680:1050:p
EDRS4=1920:1080:p
EDRS4=1920:1080:i
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
14/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
DISPLAY
OPTION
1920x1200p VXX:EDRS4=1920:1200:p EDRS4=1920:1200:p ✔✔
DIGITAL LINK-EDID VERTICAL
SCAN FREQUENCY
60Hz
50Hz
48Hz
30Hz
25Hz
24Hz
VXX:EDVI4=+06000
VXX:EDVI4=+05000
VXX:EDVI4=+04800
VXX:EDVI4=+03000
VXX:EDVI4=+02500
VXX:EDVI4=+02400
QVX:EDVI4 EDVI4=+06000
EDVI4=+05000
EDVI4=+04800
EDVI4=+03000
EDVI4=+02500
EDVI4=+02400
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
DIGITAL LINK-EDID RESOLUTION
/ VERTICAL SCAN FREQUENCY
* PARAMETER VXX:EDLS1=*********:*:**** QVX:EDLS1 EDLS1=*********:*:**** ✔✔
* PARAMETER1
1024x768
1280x720
1280x768
1280x800
1280x1024
1366x768
1400x1050
1440x900
1600x900
1600x1200
1680x1050
1920x1080
VXX:EDLS1=1024:0768:*:****
VXX:EDLS1=1280:0720:*:****
VXX:EDLS1=1280:0768:*:****
VXX:EDLS1=1280:0800:*:****
VXX:EDLS1=1280:1024:*:****
VXX:EDLS1=1366:0768:*:****
VXX:EDLS1=1400:1050:*:****
VXX:EDLS1=1440:0900:*:****
VXX:EDLS1=1600:0900:*:****
VXX:EDLS1=1600:1200:*:****
VXX:EDLS1=1680:1050:*:****
VXX:EDLS1=1920:1080:*:****
EDLS1=1024:0768:*:****
EDLS1=1280:0720:*:****
EDLS1=1280:0768:*:****
EDLS1=1280:0800:*:****
EDLS1=1280:1024:*:****
EDLS1=1366:0768:*:****
EDLS1=1400:1050:*:****
EDLS1=1440:0900:*:****
EDLS1=1600:0900:*:****
EDLS1=1600:1200:*:****
EDLS1=1680:1050:*:****
EDLS1=1920:1080:*:****
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
* PARAMETER2 Progressive
Interlace
VXX:EDLS1=*********:p:****
VXX:EDLS1=*********:i:**** EDLS1=*********:p:****
EDLS1=*********:i:****
✔
✔
✔
✔
* PARAMETER3
60Hz
50Hz
48Hz
30Hz
25Hz
24Hz
VXX:EDLS1=*********:*:6000
VXX:EDLS1=*********:*:5000
VXX:EDLS1=*********:*:4800
VXX:EDLS1=*********:*:3000
VXX:EDLS1=*********:*:2500
VXX:EDLS1=*********:*:2400
EDLS1=*********:*:6000
EDLS1=*********:*:5000
EDLS1=*********:*:4800
EDLS1=*********:*:3000
EDLS1=*********:*:2500
EDLS1=*********:*:2400
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
DIGITAL LINK-EDID STATUS
RESOLUTION / VERTICAL SCAN
FREQUENCY
* PARAMETER QVX:ESLS1 ESLS1=*********:*:**** ✔✔
* PARAMETER1
1024x768
1280x720
1280x768
1280x800
1280x1024
1366x768
1400x1050
1440x900
1600x900
1600x1200
1680x1050
1920x1080
1920x1200
ESLS1=1024:0768:*:****
ESLS1=1280:0720:*:****
ESLS1=1280:0768:*:****
ESLS1=1280:0800:*:****
ESLS1=1280:1024:*:****
ESLS1=1366:0768:*:****
ESLS1=1400:1050:*:****
ESLS1=1440:0900:*:****
ESLS1=1600:0900:*:****
ESLS1=1600:1200:*:****
ESLS1=1680:1050:*:****
ESLS1=1920:1080:*:****
ESLS1=1920:1200:*:****
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
* PARAMETER2 Progressive
Interlace
ESLS1=*********:p:****
ESLS1=*********:i:****
✔
✔
✔
✔
* PARAMETER3
60Hz
50Hz
48Hz
30Hz
25Hz
24Hz
ESLS1=*********:*:6000
ESLS1=*********:*:5000
ESLS1=*********:*:4800
ESLS1=*********:*:3000
ESLS1=*********:*:2500
ESLS1=*********:*:2400
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
SDI IN-SIGNAL LEVEL (SDI1) 64-940
4-1019
VXX:SSLI1=+00000
VXX:SSLI1=+00001 QVX:SSLI1 SSLI1=+00000
SSLI1=+00001
✔
✔
✔
✔
15/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
SDI IN-SIGNAL LEVEL (SDI2) 64-940
4-1019
VXX:SSLI2=+00000
VXX:SSLI2=+00001 QVX:SSLI2 SSLI2=+00000
SSLI2=+00001
✔
✔
✔
✔
SDI IN-SIGNAL LEVEL (DUAL LINK
1 : SDI1+2)
64-940
4-1019
VXX:SSLI3=+00000
VXX:SSLI3=+00001 QVX:SSLI3 SSLI3=+00000
SSLI3=+00001
✔
✔
✔
✔
SDI IN-BIT DEPTH (SDI1) AUTO
12-bit
10-bit
VXX:SBTI1=+00000
VXX:SBTI1=+00001
VXX:SBTI1=+00002
QVX:SBTI1 SBTI1=+00000
SBTI1=+00001
SBTI1=+00002
✔
✔
✔
✔
✔
✔
SDI IN-BIT DEPTH (SDI2) AUTO
12-bit
10-bit
VXX:SBTI2=+00000
VXX:SBTI2=+00001
VXX:SBTI2=+00002
QVX:SBTI2 SBTI2=+00000
SBTI2=+00001
SBTI2=+00002
✔
✔
✔
✔
✔
✔
SDI IN-BIT DEPTH (DUAL LINK 1 :
SDI1+2)
AUTO
12-bit
10-bit
VXX:SBTI3=+00000
VXX:SBTI3=+00001
VXX:SBTI3=+00002
QVX:SBTI3 SBTI3=+00000
SBTI3=+00001
SBTI3=+00002
✔
✔
✔
✔
✔
✔
SDI IN-3G SDI MAPPING (SDI1) AUTO
LEVEL A
LEVEL B
VXX:SGMI1=+00000
VXX:SGMI1=+00001
VXX:SGMI1=+00002
QVX:SGMI1 SGMI1=+00000
SGMI1=+00001
SGMI1=+00002
✔
✔
✔
✔
✔
✔
SDI IN-3G SDI MAPPING (SDI2) AUTO
LEVEL A
LEVEL B
VXX:SGMI2=+00000
VXX:SGMI2=+00001
VXX:SGMI2=+00002
QVX:SGMI2 SGMI2=+00000
SGMI2=+00001
SGMI2=+00002
✔
✔
✔
✔
✔
✔
SDI RESOLUTION * PARAMETER VXX:*****=+***** QVX:***** *****=+***** ✔✔
* PARAMETER1
SDI1
SDI2
DUAL LINK 1(SDI1+2)
VXX:SRSI1=+*****
VXX:SRSI2=+*****
VXX:SRDI1=+*****
SRSI1=+*****
SRSI2=+*****
SRDI1=+*****
✔
✔
✔
✔
✔
✔
* PARAMETER2
AUTO
720x480i
720x576i
1280x720p
1920x1080i
1920x1080p
1920x1080sF
2048x1080p
VXX:*****=+00000
VXX:*****=+00001
VXX:*****=+00002
VXX:*****=+00003
VXX:*****=+00005
VXX:*****=+00006
VXX:*****=+00007
VXX:*****=+00009
*****=+00000
*****=+00001
*****=+00002
*****=+00003
*****=+00005
*****=+00006
*****=+00007
*****=+00009
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
SDI SYSTEM SELECTOR * PARAMETER VXX:SYSS1=*:****:***** QVX:SYSS1=*:**** SYSS1=*:****:***** ✔✔
* PARAMETER1, 2
SDI1
SDI2
DUAL LINK 1(SDI1+2)
VXX:SYSS1=1:1
VXX:SYSS1=1:2
VXX:SYSS1=2:12
SYSS1=1:1:*****
SYSS1=1:2:*****
SYSS1=2:12:*****
✔
✔
✔
✔
✔
✔
* PARAMETER3
AUTO
RGB
YPbPr4:4:4
YPbPr4:2:2
XYZ
VXX:SYSS1=*:****:00000
VXX:SYSS1=*:****:00001
VXX:SYSS1=*:****:00002
VXX:SYSS1=*:****:00003
VXX:SYSS1=*:****:00004
SYSS1=*:****:00000
SYSS1=*:****:00001
SYSS1=*:****:00002
SYSS1=*:****:00003
SYSS1=*:****:00004
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
SDI IN - SDI LINK SINGLE LINK
DUAL LINK
AUTO
OFF
MASTER
SLAVE
VXX:SLKI1=+00000
VXX:SLKI1=+00001
VXX:SLKI1=+00010
VXX:MPSI1=+00000
VXX:MPSI1=+00001
VXX:MPSI1=+00002
QVX:SLKI1
QYX:MPSI1
SLKI1=+00000
SLKI1=+00001
SLKI1=+00010
MPSI1=+00000
MPSI1=+00001
MPSI1=+00002
✔
✔
✔
✔
✔
✔
MULTI PROJECTOR SYNC - MODE ✔
✔
✔
✔
✔
✔
FRAME SYNC SETTING(MULTI
PROJECTOR SYNC) - CONTRAST
OFF
ON
VXX:CSYI1=+00000
VXX:CSYI1=+00001 QVX:CSYI1 CSYI1=+00000
CSYI1=+00001
✔
✔
✔
✔
MULTI PROJECTOR SYNC -
SHUTTER SYNC.
OFF
ON
VXX:SSYI1=+00000
VXX:SSYI1=+00001 QVX:SSYI1 SSYI1=+00000
SSYI1=+00001
✔
✔
✔
✔
INPUT GUIDE OFF
ON (SIMPLE)
OID:0
OID:1 QDI 0
1
✔
✔
✔
✔
16/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
OSD POSITION UPPER LEFT
CETRE LEFT
LOWER LEFT
TOP CENTER
CENTER
LOEER CENTER
UPPER RIGHT
CENTER RIGHT
LOWER RIGHT
ODP:1
ODP:2
ODP:3
ODP:4
ODP:5
ODP:6
ODP:7
ODP:8
ODP:9
QDP 1
2
3
4
5
6
7
8
9
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
OSD MEMORY OFF
ON
VXX:OMYI0=+00000
VXX:OMYI0=+00001 QVX:OMYI0 OMYI0=+00000
OMYI0=+00001
✔
✔
✔
✔
ON SCREEN OFF
ON
OOS:0
OOS:1 QOS 0
1
✔
✔
✔
✔
WARNING MESSAGE OFF
ON
VXX:WMDI0=+00000
VXX:WMDI0=+00001 QVX:WMDI0 WMDI0=+00000
WMDI0=+00001
✔
✔
✔
✔
OSD DESIGN 1(YELLOW)
2(BLUE)
3(WHITE)
4(GREEN)
5(PEACH)
6(BROWN)
MOD:0
MOD:1
MOD:2
MOD:3
MOD:4
MOD:5
QOD 0
1
2
3
4
5
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
MENU MODE NORMAL
SIMPLE
VXX:MMDI1=+00000
VXX:MMDI1=+00001 QVX:MMDI1 MMDI1=+00000
MMDI1=+00001
✔
✔
✔
✔
SCREEN SETTING 16:10
16:9
4:3
VSF:0
VSF:1
VSF:2
QSF 0
1
2
✔
✔
✔
✔
✔
SCREEN POSITION-VERTICAL min.
max.
VXX:VSPI0=-00120
VXX:VSPI0=+00120 QVX:VSPI0 VSPI0=-00120
VSPI0=+00120 -60
60
-132
131
SCREEN POSITION-HOROZONTAL min.
max.
VXX:HSPI0=-00320
VXX:HSPI0=+00320 QVX:HSPI0 HSPI0=-00320
HSPI0=+00320 -160
160
STARTUP LOGO OFF
USER LOGO
DEFAULT LOGO
MLO:0
MLO:1
MLO:2
QLO 0
1
2
✔
✔
✔
✔
✔
✔
UNIFORMITY-PC CORRECTION * OFF
ON(PRE)
ON(POST)
VXX:UFMI1=+00000
VXX:UFMI1=+00011
VXX:UFMI1=+00021
QVX:UFMI1 UFMI1=+00000
UFMI1=+00011
UFMI1=+00021
✔
✔
✔
✔
✔
✔
UNIFORMITY-INITILIZE EXECUTE VXX:UFMI2=+00001 ✔✔
UNIFORMITY-
WHITE/RED/GREEN/RED
* PARAMETER E$W:*,****,****,** E$R:*,** **,****,**** ✔✔
* PARAMETER 1
WHITE
RED
GREEN
BLUE
E$W:W,****,****,**
E$W:R,****,****,**
E$W:G,****,****,**
E$W:B,****,****,**
E$R:W,**
E$R:R,**
E$R:G,**
E$R:B,**
**,****,****
**,****,****
**,****,****
**,****,****
✔
✔
✔
✔
✔
✔
✔
✔
* PARAMETER 2 VERTICAL(-127)
VERTICAL(+127)
E$W:*,-127,****,**
E$W:*,+127,****,** E$R:*,**
E$R:*,** **,-127,****
**,+127,****
✔
✔
✔
✔
* PARAMETER 3 HORIZONTAL(-127)
HOROZONTAL(+127)
E$W:*,****,-127,**
E$W:*,****,+127,** E$R:*,**
E$R:*,** **,****,-127
**,****,+127
✔
✔
✔
✔
* PARAMETER 4
L1(OFF)
L1(ON)
L2(OFF)
L2(ON)
E$W:*,****,****,0*
E$W:*,****,****,1*
E$W:*,****,****,*0
E$W:*,****,****,*1
E$R:*,0*
E$R:*,1*
E$R:*,*0
E$R:*,*1
0*,****,****
1*,****,****
*0,****,****
*1,****,****
✔
✔
✔
✔
✔
✔
✔
✔
SHUTTER SETTING-FADE IN 0.0s(OFF)
0.5s
VXX:SEFS1=0.0
VXX:SEFS1=0.5 QVX:SEFS1 SEFS1=0.0
SEFS1=0.5
✔
✔
✔
✔
17/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
1.0s
1.5s
2.0s
2.5s
3.0s
3.5s
4.0s
5.0s
7.0s
10.0s
VXX:SEFS1=1.0
VXX:SEFS1=1.5
VXX:SEFS1=2.0
VXX:SEFS1=2.5
VXX:SEFS1=3.0
VXX:SEFS1=3.5
VXX:SEFS1=4.0
VXX:SEFS1=5.0
VXX:SEFS1=7.0
VXX:SEFS1=10.0
SEFS1=1.0
SEFS1=1.5
SEFS1=2.0
SEFS1=2.5
SEFS1=3.0
SEFS1=3.5
SEFS1=4.0
SEFS1=5.0
SEFS1=7.0
SEFS1=10.0
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
SHUTTER SETTING-FADE OUT 0.0s(OFF)
0.5s
1.0s
1.5s
2.0s
2.5s
3.0s
3.5s
4.0s
5.0s
7.0s
10.0s
VXX:SEFS2=0.0
VXX:SEFS2=0.5
VXX:SEFS2=1.0
VXX:SEFS2=1.5
VXX:SEFS2=2.0
VXX:SEFS2=2.5
VXX:SEFS2=3.0
VXX:SEFS2=3.5
VXX:SEFS2=4.0
VXX:SEFS2=5.0
VXX:SEFS2=7.0
VXX:SEFS2=10.0
QVX:SEFS2 SEFS2=0.0
SEFS2=0.5
SEFS2=1.0
SEFS2=1.5
SEFS2=2.0
SEFS2=2.5
SEFS2=3.0
SEFS2=3.5
SEFS2=4.0
SEFS2=5.0
SEFS2=7.0
SEFS2=10.0
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
SHUTTER SETTING
-MECHANICAL SHUTTER
DISABLE
ENABLE
VXX:SEFI5=+00000
VXX:SEFI5=+00001 QVX:SEFI5 SEFS5=+00000
SEFS5=+00001
✔
✔
✔
✔
SHUTTER SETTING-STARTUP OPEN
CLOSE
VXX:SEFI3=+00000
VXX:SEFI3=+00001 QVX:SEFI3 SEFI3=+00000
SEFI3=+00001
✔
✔
✔
✔
SHUTTER SETTING-SHUT OFF OPEN
CLOSE
KEEP CURRENT STATE
VXX:SEFI4=+00000
VXX:SEFI4=+00001
VXX:SEFI4=+00002
QVX:SEFI4 SEFI4=+00000
SEFI4=+00001
SEFI4=+00002
✔
✔
✔
✔
✔
✔
BACK COLOR BLUE
BLACK
USER LOGO
DEFAULT LOGO
OBC:0
OBC:1
OBC:2
OBC:3
QBC 0
1
2
3
✔
✔
✔
✔
✔
✔
✔
✔
WAVEFORM MONITOR OFF
LUMINANCE
RED
GREEN
BLUE
OWM:0
OWM:5
OWM:6
OWM:7
OWM:8
QWM 0
5
6
7
8
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
WAVEFORM MONITOR-LINE ADJ. 0
+2159
VXX:WMLI0=+00000
VXX:WMLI0=+02159 QVX:WMLI0 WMLI0=+00000
WMLI0=+02159
✔
✔
✔
✔
AC VOLTAGE MONITOR OFF
ON
VXX:VMOI1=+00000
VXX:VMOI1=+00001 QVX:VMOI1 VMOI1=+00000
VMOI1=+00001
✔
✔
✔
✔
AC VOLTAGE QVX:VMOI2 VMOI2=+00000
VMOI2=+99999
✔
✔
✔
✔
CUT OFF-RED OFF
ON
VXX:CUTI1=+00000
VXX:CUTI1=+00001 QVX:CUTI1 CUTI1=+00000
CUTI1=+00001
✔
✔
✔
✔
CUT OFF-GREEN OFF
ON
VXX:CUTI2=+00000
VXX:CUTI2=+00001 QVX:CUTI2 CUTI2=+00000
CUTI2=+00001
✔
✔
✔
✔
CUT OFF-BLUE OFF
ON
VXX:CUTI3=+00000
VXX:CUTI3=+00001 QVX:CUTI3 CUTI3=+00000
CUTI3=+00001
✔
✔
✔
✔
PROJECTOR ID 0(ALL)
64
RIS:00
RIS:64
✔
✔
✔
✔
18/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
ID ALL OFF
ON
RVS:0
RVS:1 QVY 0
1
✔
✔
✔
✔
PROJECTION METHOD
INSTALLATION
FRONT/DESK
REAR/DESK
FRONT/CEILING
REAR/CEILING
FRONT/AUTO
REAR/AUTO
OIL:0
OIL:1
OIL:2
OIL:3
OIL:4
OIL:5
QSP 0
1
2
3
4
5
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
AUTO COOLING CONDITION-
STATUS
FLOOR
CEILING
VERTICAL UP
VERTICAL DOWN
PORTRAIT
QVX:ADRI1 ADRI1=+00000
ADRI1=+00001
ADRI1=+00002
ADRI1=+00003
ADRI1=+00004
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
OPERATING MODE NORMAL
HIGH
LONG LIFE1
LONG LIFE2
LONG LIFE3
USER1(USER)
USER2
USER3
VXX:OPEI1=+00000
VXX:OPEI1=+00004
VXX:OPEI1=+00011
VXX:OPEI1=+00012
VXX:OPEI1=+00013
VXX:OPEI1=+00101
VXX:OPEI1=+00102
VXX:OPEI1=+00103
QVX:OPEI1 OPEI1=+00000
OPEI1=+00004
OPEI1=+00011
OPEI1=+00012
OPEI1=+00013
OPEI1=+00101
OPEI1=+00102
OPEI1=+00103
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
LIGHT OUTPUT min.
max.
VXX:LOPI2=+00100
VXX:LOPI2=+01000 QVX:LOPI2 LOPI2=+00100
LOPI2=+01000 8%
100%
8%
100%
MAX LIGHT OUTPUT min.
max.
VXX:LOPI3=+00100
VXX:LOPI3=+01000 QVX:LOPI3 LOPI3=+00100
LOPI3=+01000 8%
100%
8%
100%
BRIGHTNESS CONTROL-SETUP-
CALIBRATION TIME
OFF
00:01
23:59
00:00
VXX:BTMI1=+00000
VXX:BTMI1=+00001
VXX:BTMI1=+02359
VXX:BTMI1=+02400
QVX:BTMI1 BTMI1=+00000
BTMI1=+00001
BTMI1=+02359
BTMI1=+02400
✔
✔
✔
✔
✔
✔
✔
✔
BRIGHTNESS CONTROL-SETUP-
CALIBRATION MESSAGE
OFF
ON
VXX:BMGI1=+00000
VXX:BMGI1=+00001 QVX:BMGI1 BMGI1=+00000
BMGI1=+00001
✔
✔
✔
✔
BRIGHTNESS CONTROL-SETUP-
CONSTANT MDOE
OFF
AUTO
PC
VXX:BCMI0=+00000
VXX:BCMI0=+00001
VXX:BCMI0=+00002
QVX:BCMI0 BCMI0=+00000
BCMI0=+00001
BCMI0=+00002
✔
✔
✔
✔
✔
✔
BRIGHTNESS CONTROL-SETUP-
LINK
OFF
GROUP A
GROUP B
GROUP C
GROUP D
VXX:BCLI0=+00000
VXX:BCLI0=+00001
VXX:BCLI0=+00002
VXX:BCLI0=+00003
VXX:BCLI0=+00004
QVX:BCLI0 BCLI0=+00000
BCLI0=+00001
BCLI0=+00002
BCLI0=+00003
BCLI0=+00004
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
BRIGHTNESS CONTROL-CHROMA
CORRECTION
OFF
ON
VXX:CHCI1=+00000
VXX:CHCI1=+00001 QVX:CHCI1 CHCI1=+00000
CHCI1=+00001
✔
✔
✔
✔
BRIGHTNESS CONTROL-SETUP APPLY APPLY VXX:BCSI0=+00001 ✔✔
STANDBY MODE NORMAL
ECO
VXX:STMI0=+00000
VXX:STMI0=+00003 QVX:STMI0 STMI0=+00000
STMI0=+00003
✔
✔
✔
✔
SCHEDULE OFF
ON
VXX:SCHI0=+00000
VXX:SCHI0=+00001 QVX:SCHI0 SCHI0=+00000
SCHI0=+00001
✔
✔
✔
✔
SCHEDLE-PROGRAM ASSIGN OFF
PROGRAM1
PROGRAM2
PROGRAM3
PROGRAM4
PROGRAM5
VXX:SPGI*=+00000
VXX:SPGI*=+00001
VXX:SPGI*=+00002
VXX:SPGI*=+00003
VXX:SPGI*=+00004
VXX:SPGI*=+00005
QVX:SPGI* SPGI*=+00000
SPGI*=+00001
SPGI*=+00002
SPGI*=+00003
SPGI*=+00004
SPGI*=+00005
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
19/25
CONTROL COMMANDS 2017/12/21
CONTROL QUERY RZ21K SERIES
CATEGORY
FUNCTION
Parameter/Name
Sub-Parameter
COMMANDS
COMMANDS
CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
PROGRAM6
PROGRAM7
VXX:SPGI*=+00006
VXX:SPGI*=+00007 SPGI*=+00006
SPGI*=+00007
✔
✔
✔
✔
* PARAMETER
SUN
MON
TUE
WED
THU
FRI
SAT
VXX:SPGI0=+0000*
VXX:SPGI1=+0000*
VXX:SPGI2=+0000*
VXX:SPGI3=+0000*
VXX:SPGI4=+0000*
VXX:SPGI5=+0000*
VXX:SPGI6=+0000*
QVX:SPGI0
QVX:SPGI1
QVX:SPGI2
QVX:SPGI3
QVX:SPGI4
QVX:SPGI5
QVX:SPGI6
SPGI0=+0000*
SPGI1=+0000*
SPGI2=+0000*
SPGI3=+0000*
SPGI4=+0000*
SPGI5=+0000*
SPGI6=+0000*
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
SCHEDLE-COMMAND SETTING COMMAND Del
STANDBY
POWER ON
SHUTTER OPEN
SHUTTER CLOSE
RGB1 INPUT
RGB2 INPUT
VIDEO INPUT
DVI-D INPUT
SDI1 INPUT
HDMI1 INPUT
SDI2 INPUT
NORMAL
ECO
LONG LIFE1
LONG LIFE2
LONG LIFE3
USER1(USER)
USER2
USER3
HIGH
Multi Display OFF
Multi Display USER1
Multi Display USER2
Multi Display USER3
VXX:SCCS*=**00****
VXX:SCCS*=**10****
VXX:SCCS*=**11****
VXX:SCCS*=**20****
VXX:SCCS*=**21****
VXX:SCCS*=**31****
VXX:SCCS*=**32****
VXX:SCCS*=**41****
VXX:SCCS*=**51****
VXX:SCCS*=**52****
VXX:SCCS*=**53****
VXX:SCCS*=**56****
VXX:SCCS*=**70****
VXX:SCCS*=**71****
VXX:SCCS*=**72****
VXX:SCCS*=**73****
VXX:SCCS*=**74****
VXX:SCCS*=**75****
VXX:SCCS*=**76****
VXX:SCCS*=**77****
VXX:SCCS*=**79****
VXX:SCCS*=**90****
VXX:SCCS*=**91****
VXX:SCCS*=**92****
VXX:SCCS*=**93****
QVX:SCCS*=** SCCS*=**00****
SCCS*=**10****
SCCS*=**11****
SCCS*=**20****
SCCS*=**21****
SCCS*=**31****
SCCS*=**32****
SCCS*=**41****
SCCS*=**51****
SCCS*=**52****
SCCS*=**53****
SCCS*=**56****
SCCS*=**70****
SCCS*=**71****
SCCS*=**72****
SCCS*=**73****
SCCS*=**74****
SCCS*=**75****
SCCS*=**76****
SCCS*=**77****
SCCS*=**79****
SCCS*=**90****
SCCS*=**91****
SCCS*=**92****
SCCS*=**93****
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
* PARAMETER1
PROGRAM1
PROGRAM2
PROGRAM3
PROGRAM4
PROGRAM5
PROGRAM6
PROGRAM7
VXX:SCCS1=********
VXX:SCCS2=********
VXX:SCCS3=********
VXX:SCCS4=********
VXX:SCCS5=********
VXX:SCCS6=********
VXX:SCCS7=********
QVX:SCCS1=**
QVX:SCCS2=**
QVX:SCCS3=**
QVX:SCCS4=**
QVX:SCCS5=**
QVX:SCCS6=**
QVX:SCCS7=**
SCCS1=********
SCCS2=********
SCCS3=********
SCCS4=********
SCCS5=********
SCCS6=********
SCCS7=********
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
* PARAMETER2 COMMAND 1
COMMAND 16
VXX:SCCS*=01******
VXX:SCCS*=16****** QVX:SCCS*=01
QVX:SCCS*=16 SCCS*=01******
SCCS*=16******
✔
✔
✔
✔
* PARAMETER3 00:00
23:59
VXX:SCCS*=****0000
VXX:SCCS*=****2359 SCCS*=****0000
SCCS*=****2359
✔
✔
✔
✔
STARTUP INPUT SELECT RGB1
RGB2
DVI-D
HDMI1
DIGITAL LINK
SDI1
SDI2
VXX:SISS1=RG1
VXX:SISS1=RG2
VXX:SISS1=DVI
VXX:SISS1=HD1
VXX:SISS1=DL1
VXX:SISS1=SD1
VXX:SISS1=SD2
QVX:SISS1 SISS1=RG1
SISS1=RG2
SISS1=DVI
SISS1=HD1
SISS1=DL1
SISS1=SD1
SISS1=SD2
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
Other manuals for PT-RZ21K
2
This manual suits for next models
1
Table of contents
Other Panasonic Projector manuals
Panasonic
Panasonic PT-EX12KE User manual
Panasonic
Panasonic PTLM1U - LCD PROJECTOR User manual
Panasonic
Panasonic PT-D4000E User manual
Panasonic
Panasonic PT-L720E User manual
Panasonic
Panasonic PT-EX12KU User manual
Panasonic
Panasonic PT-FZ570U Operating instructions
Panasonic
Panasonic PTLB20NTU - PROJECTOR- NETWORK IB User manual
Panasonic
Panasonic DLP PT-D6000 User manual
Panasonic
Panasonic PT-DW5000 System manual
Panasonic
Panasonic PT-VW431D User manual
Panasonic
Panasonic Whisper-Lite FV-08VQL4 User manual
Panasonic
Panasonic PT-VX61K Operating instructions
Panasonic
Panasonic PT-DW740E User manual
Panasonic
Panasonic PTL6600U - LCD PROJECTOR User manual
Panasonic
Panasonic PT-L735E User manual
Panasonic
Panasonic PT-VW530 User manual
Panasonic
Panasonic PT-REQ12 Series User manual
Panasonic
Panasonic PT-RZ570 User manual
Panasonic
Panasonic PT-RQ13K User manual
Panasonic
Panasonic PT-VX505NU User manual
