Panasonic RS-232C User manual

RS-232C Protocol Manual For
LCD Projectors
PT-L711, PT-L701, PT-L701SD,
PTL511, and PT-L501
Version 1.0

Revision List
Date Revision Number Description
07/02/2001 1.0 Manual first release
Panasonic Broadcast and Television Systems Company
3330 Cahuenga Blvd. West
Los Angeles, CA 90068
Phone [phone]
Web Site http\\www.panasonic.com

Panasonic RS-232 Protocol
for LCD Projector
Table of Content
1Introduction_________________________________________________ 5
2Connection __________________________________________________ 6
2.1 Communication Parameters _________________________________ 6
2.2 Address level______________________________________________ 6
2.3 RS-232C Connection_______________________________________ 6
2.4 Cable Specifications________________________________________ 7
3Communication ______________________________________________ 8
3.1 Command Format_________________________________________ 8
3.2 Replies___________________________________________________ 9
4The Command List___________________________________________ 10
5Command Explanation _______________________________________ 14
5.1 Details of Notation in Command Tables ______________________ 14
5.2 Audio Volume Down (AUD) _______________________________ 15
5.3 Audio Volume UP (AUU)__________________________________ 16
5.4 Audio Volume Set (AVL)__________________________________ 17
5.5 Control Panel (CPK) _____________________________________ 18
5.6 Digital Zoom Down (DZD)_________________________________ 19
5.7 Digital Zoom Up (DZU) ___________________________________ 20
5.8 Input Select (IIS)_________________________________________ 21
5.9 Keystone (KST) __________________________________________ 22
5.10 Auto Keystone (OAK)____________________________________ 23
5.11 Auto RGB Input (OAR)__________________________________ 24
5.12 Auto Set-up (OAS) ______________________________________ 25
5.13 Auto YPbPr (OAY)______________________________________ 26

Panasonic RS-232 Protocol
for LCD Projector
5.14 Background Color (OBC) ________________________________ 27
5.15 Cursor Down (OCD)_____________________________________ 28
5.16 Cursor Left (OCL) ______________________________________ 29
5.17 Cursor Right (OCR)_____________________________________ 30
5.18 Cursor Up (OCU) _______________________________________ 31
5.19 Enter (OEN)____________________________________________ 32
5.20 Function 1 (OFC) _______________________________________ 33
5.21 Freeze (OFZ) ___________________________________________ 34
5.22 Gamma Set (OGS) ______________________________________ 35
5.23 Input Display (OID) _____________________________________ 36
5.24 Installation (OIL) _______________________________________ 37
5.25 Index Window (OIX) ____________________________________ 38
5.26 Keystone (OKS)_________________________________________ 39
5.27 Language (OLG)________________________________________ 40
5.28 Lamp Power (OLP)______________________________________ 41
5.29 Menu (OMN)___________________________________________ 42
5.30 RGB Format (ORF) _____________________________________ 43
5.31 Resizing (ORZ) _________________________________________ 44
5.32 Shutter (OSH) __________________________________________ 45
5.33 Standard (OST)_________________________________________ 46
5.34 Power Off (POF) ________________________________________ 47
5.35 Power On (PON)________________________________________ 48
5.36 Query Auto Keystone (QAK)______________________________ 49
5.37 Query Auto RGB Input (QAR)____________________________ 50
5.38 Query Auto Set-up (QAS) ________________________________ 51
5.39 Query Volume Level (QAV) ______________________________ 52
5.40 Query Auto YPbPr (QAY)________________________________ 53
5.41 Query Background Color (QBC) __________________________ 54
5.42 Query Clock Phase Level (QCP) ___________________________ 55
5.43 Query Dot Clock Level (QDC)_____________________________ 56
5.44 Query Input Display (QDI) _______________________________ 57

Panasonic RS-232 Protocol
for LCD Projector
5.45 Query Function (QFC) ___________________________________ 58
5.46 Query Horizontal Frequency (QFH)________________________ 59
5.47 Query Vertical Frequency (QFV) __________________________ 60
5.48 Query Freeze (QFZ) _____________________________________ 61
5.49 Query H-Position Level (QHP) ____________________________ 62
5.50 Query Input Signal (QIN) ________________________________ 63
5.51 Query Index Window (QIX) ______________________________ 64
5.52 Query Keystone (QKS)___________________________________ 65
5.53 Query Language (QLG) __________________________________ 66
5.54 Query Lamp Power (QLP)________________________________ 67
5.55 Query Picture Mode (QPM)_______________________________ 68
5.56 Query Power Condition (QPW) ___________________________ 69
5.57 Query RGB Format (QRF) _______________________________ 70
5.58 Query Resizing (QRZ) ___________________________________ 71
5.59 Query Signal Mode (QSG)________________________________ 72
5.60 Query Shutter (QSH) ____________________________________ 73
5.61 Query Installation (QSP) _________________________________ 74
5.62 Query Brightness (QVB) _________________________________ 75
5.63 Query Color Level (QVC) ________________________________ 76
5.64 Query V-Position Level (QVP) ____________________________ 77
5.65 Query Contrast Level (QVR)______________________________ 78
5.66 Query Sharpness Level (QVS)_____________________________ 79
5.67 Query Tint Level (QVT)__________________________________ 80
5.68 Query Video Size Level (QVZ) ____________________________ 81
5.69 Query White Balance Blue (QWB)_________________________ 82
5.70 Query White Balance Green (QWG) _______________________ 83
5.71 Query White Balance Red (QWR) _________________________ 84
5.72 Query Lamp On Time (Q$L)______________________________ 85
5.73 Query Lamp On Condition (Q$S)__________________________ 86
5.74 Brightness (VBR) _______________________________________ 87
5.75 Contrast (VCN)_________________________________________ 88

Panasonic RS-232 Protocol
for LCD Projector
5.76 Color (VCO) ___________________________________________ 89
5.77 Clock Phase (VCP) ______________________________________ 90
5.78 Dot Clock (VDC)________________________________________ 91
5.79 H-Position (VHP) _______________________________________ 92
5.80 Picture Mode (VPM)_____________________________________ 93
5.81 Signal Mode Set (VSG)___________________________________ 94
5.82 Sharpness (VSR)________________________________________ 95
5.83 Video Size (VSZ) ________________________________________ 96
5.84 S1 Signal (VS1) _________________________________________ 97
5.85 Tint (VTN)_____________________________________________ 98
5.86 V-Position (VVP)________________________________________ 99
5.87 White Balance Blue (VWB) ______________________________ 100
5.88 White Balance Green (VWG) ____________________________ 101
5.89 White Balance Red (VWR) ______________________________ 102
6. ASCII CODE TABLE _______________________________________ 103
7List of Signals______________________________________________ 107

Panasonic RS-232 Protocol
for LCD Projector
5
5
1Introduction
This document describes the commands and data formats to control by RS-232C,
from a controller to the Panasonic projector.
This document should be used in conjunction with the Operation Instructions.
Information furnished in this document, is believed to be accurate and reliable.
However, no responsibility is assumed for its use.

Panasonic RS-232 Protocol
for LCD Projector
6
6
2Connection
2.1 Communication Parameters
Signal Level RS-232C
Sync Method Asynchronous
Data Speed 9600 bps
Data length 8bit
Parity None
Stop bit 1
X Parameter None
S Parameter None
Code (command) JIS X 0201 (Capital Letters Only)
The device controlling the projector must match the above parameters. There is no capability to
change the settings of the projector.
2.2 Address level
The address level of this Projector corresponds to address level 0 within the MIS standard. This unit
does not support multiple machine control from a single communication port.
Address level 0 only one projector and the address information is eliminated
2.3 RS-232C Connection
Connector is Dsub 9pin (Female) as seen from the outside
Pin # Signal Comment
1No connection
2TXD
3RXD
4Connected Internally
5GRD
6No connection
7CTS
8RTS Connected Internally
9No connection

Panasonic RS-232 Protocol
for LCD Projector
7
7
2.4 Cable Specifications
Use a RS-232C 9 pin to 9 pin straight cable. Pins 4,7 and 8 are internally shorted together in the
projector.

Panasonic RS-232 Protocol
for LCD Projector
8
8
3Communication
3.1 Command Format
Implement commands that are to be sent to the projector in the following manner.
[STX] COM1:P1P2P3P4 [ETX]
Head identifier -Send [STX] (Hex’02’or Ctrl B for ASCII), at the beginning of the command string.
This will allow the projector to receive the following command.
Command (COM1) –The Command is written by 3 characters. The Letters are capitalized. . See
the command tables in Section 5 for details.
Parameter (P1P2P3P4) -The Parameter data is required by certain commands. The parameter
data information can be 1 to 4 bytes in length, which is dependant on the individual commands. If no
parameter is required by the specific command, then this information does not need to be
transmitted. See the command tables in Section 5 for details.
End identifier -Send [ETX] (Hex’03’or CTRL C for ASCII) at the end of command string.
Command and its parameter should be separated by a ”:” colon (Hex’3A’). When a command that
does not require parameters is sent, then the separating colon can be eliminated.
Example of a command string
:
[STX] IIS:VID[ETX]
02 49 49 53 3A 56 49 44 03
CommandwithParameter
[STX] PON[ETX]
02 50 4F 4E 03
Command without Parameter

Panasonic RS-232 Protocol
for LCD Projector
9
9
3.2 Replies
When commands are sent to projector, the projector will respond in the following manner.
1) Normal command receiving
When the command is in the proper format and correct communications has been established
between the controlling device and the projector, the projector will reply with the response
information.
2) Command receiving error (NO Response)
If no response is transmitted from the projector, then check the communication settings and the
cable configuration. The command string must start with a [STX] Start of Text message. This
will alert the projector to start receiving commands. An [ETX] End of Text message must end
the command string or the projector will not execute the command.
3) Command Receiving Error [STX]ER401[ETX]
If this error is transmitted from the projector, the projector did not recognize the command that
was sent from the control device. Check the command list to ensure that the command is valid,
and the characters are capitalized.
4) Command Receiving Error [STX]ER402[ETX
If this command is transmitted from the projector, the projector did not recognize the parameter
that was sent from the control device. Check the command list for the appropriate parameter
data that is to be sent with the appropriate command to the projector.
5) Query Reponses
If a command such as [STX]Q$L[ETX] Query Lamp Operation Time is sent. The projector will
send the reply of [STX]Q$L:0000[ETX]. Parameter information will be replied only in the case of
a Question type command. Check the command list for the specific information.
Example of Commands sent to the Projector.
[STX]IIS:RGB1[ETX]
[STX]IIS[ETX]
Controller Projector
After IIS Command
has Executed

Panasonic RS-232 Protocol
for LCD Projector
1010
4The Command List
No The Command CommandDescription
1AUD Volume Down
2AUU Audio Volume Up
3AVL: Audio Volume Set
4CPK Control Panel
5DZD Digital Zoom Down
6DZU Digital Zoom Up
7IIS Input Select
8KST Keystone
9OAK Auto Keystone
10 OAR Auto RGB Input
11 OAS Auto Set-up
12 OAY Auto YPbPr
13 OBC Background Color
14 OCD Cursor Down
15 OCL Cursor Left
16 OCR Cursor Right
17 OCU Cursor Up
18 OEN Enter
19 OFC Function 1
20 OFZ Freeze
21 OGS Gamma Set
22 OID Input Display

Panasonic RS-232 Protocol
for LCD Projector
1111
No The Command CommandDescription
23 OIL Installation
24 OIX Index Window
25 OKS Keystone
26 OLG Language
27 OLP Lamp Power
28 ORF RGB Format
29 OMN Menu
30 ORZ Resizing
31 OSH Shutter
32 OST Standard
33 POF Power Off
34 PON Power On
35 QAK Query Auto Keystone
36 QAR Query Auto RGB Input
37 QAS Query Auto Set-up
38 QAV Query Volume Level
39 QAY Query Auto YPbPr
40 QBC Query Background Color
41 QCP Query Clock Phase Level
42 QDC Query Dot Clock Level
43 QDI Query Input Display
44 QFC Query Function
45 QFH Query Horizontal Frequency
46 QFV Query Vertical Frequency
47 QFZ Query Freeze

Panasonic RS-232 Protocol
for LCD Projector
1212
No The Command CommandDescription
48 QHP Query H-Position Level
49 QIN Query Input Signal
50 QIX Query Index Window
51 QKS Query Keystone
52 QLG Query Language
53 QLP Query Lamp Power
54 QPM Query Picture Mode
55 QPW Query Power Condition
56 QRF Query RGB Format
57 QRZ Query Resizing
58 QSG Query Signal Mode
59 QSH Query Shutter
60 QSP Query Installation
61 QVB Query Brightness
62 QVCQuery Color Level
63 QVP Query V-Position Level
64 QVR Query Contrast Level
65 QVS Query Sharpness Level
66 QVT Query Tint Level
67 QVZ Query Video Size Level
68 QWB Query White Balance Blue
69 QWG Query White Balance Green
70 QWR Query White Balance Red
71 Q$L Query Lamp on Time
72 Q$S Query Lamp On Condition

Panasonic RS-232 Protocol
for LCD Projector
1313
No The Command CommandDescription
72 VBR Brightness
73 VCN Contrast
74 VCO Color
75 VCP Clock Phase
76 VDC Dot Clock
77 VHP H-Position
78 VPM Picture Mode
79 VSG Signal Mode Set
80 VSR Sharpness
81 VSZ Video Size
82 VS1 S1 Signal
83 VTN Tint
84 VVP V-Position
85 VWB White Balance Blue
86 VWG White Balance Green
87 VWR White Balance Red

Panasonic RS-232 Protocol
for LCD Projector
1414
5Command Explanation
The following tables are the layout for the individual command explanations.
5.1 Details of Notation in Command Tables
Name This indicates the name of the command.
Syntax This indicates the syntax of the command.
Parameters are also notated when they are necessary. The
starting symbols in the command are [STX], and the
concluding symbols in the command are [ETX], the symbols
[ and ] are used for ease of explanation and are not to be
sent to the player.
Function This explains the function of the command.
Parameters This explains the parameters if parameters are required by
the syntax of the command.
Response This is the response character string from the AV device or
from the interface. In query commands, etc., this explains
the meaning of the response.
Interrupt Processing This indicates other commands that can be issued while the
AV equipment is processing the command.
Examples of Use This presents an example of actual notation
Notes Other information that is helpful concerning this command.
Projector Model to Command Compatibility
Model
Number PT-L711U PT-L701U PT-L701SDU PT-L501U PT-L511U
Command
Acceptance Yes Yes Yes Yes Yes
(Yes if Command can be used, No if command cannot be used)

Panasonic RS-232 Protocol
for LCD Projector
1515
5.2 Audio Volume Down (AUD)
Name Audio Volume Down
Syntax [STX]AUD[ETX]
Function This command will step the Audio Volume down one
notch
Parameters None
Response [STX]AUD[ETX]
Interrupt Processing The Projector must be powered on for this command to
be effective.
Examples of Use [STX]AUD[ETX]
Notes
If you want to step 5 steps the command must be sent 5 times. The range is from 0 to 63
Projector Model to Command Compatibility
Model
Number PT-L711U PT-L711XU PT-L701U PT-L701XU PT-L701SDU
PT-L701XSDU PT-L511U
PT-L511XU PT-L501U PT-L501XU
Command
Acceptance Yes Yes Yes Yes Yes
(Yes if Command can be used, No if command cannot be used)

Panasonic RS-232 Protocol
for LCD Projector
1616
5.3 Audio VolumeUP (AUU)
Name Audio Volume Up
Syntax [STX]AUU[ETX]
Function This command will step the Audio Volume up one notch
Parameters None
Response [STX]AUU[ETX]
Interrupt Processing The Projector must be powered on for this command to
be effective.
Examples of Use [STX]AUU[ETX]
Notes
If you want to step 5 steps the command must be sent 5 times. The range is from 0 to 63
Projector Model to Command Compatibility
Model
Number PT-L711U PT-L711XU PT-L701U PT-L701XU PT-L701SDU
PT-L701XSDU PT-L511U
PT-L511XUPT-L501U PT-L501XU
Command
Acceptance Yes Yes Yes Yes Yes
(Yes if Command can be used, No if command cannot be used)

Panasonic RS-232 Protocol
for LCD Projector
1717
5.4 Audio Volume Set (AVL)
Name Audio Volume Set
Syntax [STX]AVL:p1p2p3[ETX]
Function This command set the Audio Volume to a set level.
Parameters 000 –063 Volume Adjustment Range
Response [STX]AVL[ETX]
Interrupt Processing The Projector must be powered on for this command to
be effective.
Examples of Use [STX]AVL:047[ETX]
Notes
The adjustment range value 000 would be no volume and 063 would be maximum volume.
Projector Model to Command Compatibility
Model
Number PT-L711U PT-L711XU PT-L701U PT-L701XU PT-L701SDU
PT-L701XSDU PT-L511U
PT-L511XU PT-L501U PT-L501XU
Command
Acceptance Yes Yes Yes Yes Yes
(Yes if Command can be used, No if command cannot be used)

Panasonic RS-232 Protocol
for LCD Projector
1818
5.5 Control Panel (CPK)
Name Control Panel
Syntax [STX]CPK:p1[ETX]
Function This command will enable or disable the controls on the
top of the projector.
Parameters Code Description
0Disabled
1Enabled
Response [STX]CPK[ETX]
Interrupt Processing The Projector must be powered on for this command to
be effective.
Examples of Use [STX]CPK:0[ETX] will disable the Control Panel
Notes
Commands can still be used to control the projector. Sending CPK:0 can disable the buttons
Projector Model to Command Compatibility
Model
Number PT-L711U PT-L711XU PT-L701U PT-L701XU PT-L701SDU
PT-L701XSDU PT-L511U
PT-L511XU PT-L501U PT-L501XU
Command
Acceptance Yes Yes Yes Yes Yes
(Yes if Command can be used, No if commandcannot be used)
