Panasonic NR-BR307(Z) User manual

Order No. PAPTH140802CE
Revision : JULY 2016
Service Manual
Refrigerator
Product Colour
NR-BR307
(Z)
NR-BR307
(X/V)
NR-BR347
(Z)
NR-BR347
(X/V)
Destination
Stainless Colour (ZS/XS)
Shining Silver (VS)
Thailand, Singapore, Malaysia
Vietnam, Indonesia, Hong Kong
RBD, Philippines
India
NR-BR307 SERIES
NR-BR347 SERIES
The service information is designed for experienced repair technicians only and is not designed for use by the general
public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting
to service a product. Products powered by electricity should be serviced or repaired only by experienced professional
technicians. Any attempt to service or repair the product or products dealt within this service information by anyone
else could result in serious injury or death.
WARNING
IMPORTANT SAFETY NOTICE
There are special components used in this equipment which are important for safety. These parts are marked by
in the Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that
these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards. Do
not modify the original design without permission of manufacturer.
© Panasonic Appliances (Thailand) Co., Ltd. 2016.
All rights reserved. Unauthorized copying and
distribution is a violation of law.
Service BR307_347.indd 1Service BR307_347.indd 1 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

1. Safety Cautions for Repairing 3
1.1 Warning
1.2 Caution
2. Specification and Components
2.1 NR-BR307 SERIES 4
2.2 NR-BR347 SERIES 5
3. Wiring Diagram
3.1 NR-BR307, NR-BR347 : Z 6
3.2 NR-BR307, NR-BR347 : X, V 7
4. Performance Data
4.1 NR-BR307 8
4.2 NR-BR347 8
5. Troubleshooting Guide 9
6. Temperature Control
6.1 Z Series 10
6.2 X, V Series 11
7. Disassembly Instruction
7.1 LED Cover 12
7.2 Plate Duct PCT 13
7.3 PAS-Control Door 14
8. Parts Exploded View and Replacement Parts List
8.1 Part Exploded View : Body 15
8.2 Part Exploded View : Door 16
8.3 Part Exploded View : Packing 17
8.4 Replacement Parts List : NR-BR307 SERIES 18 - 20
Detail Change Notice 20
CONTENT
- 2 -
Service BR307_347.indd 2Service BR307_347.indd 2 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

1. SAFETY CAUTIONS FOR REPAIRING
When you repair the refrigerator, please kindly take care for the following cautions.
1.1 Warning
Before repairing unit, unplug supply cord
• Before you repair the refrigerator, please unplug the supply cord.
Use authentic parts when repairing
• When you replace the parts, please use authentic parts to replace defective parts.
Caution during brazing
• When you use touch for brazing, please ensure ventilation.
Otherwise, you will be poisoned by carbon monoxide.
Pay attention to using refrigerant
• If refrigerant touches fire, the gas becomes poisonous gas.
Pay attention to getting electricity shock
• When you check the voltage of terminal, please do not touch the electricity part terminal.
• When you replace the parts, please wait for 3 minutes at least for discharging capacitor.
Check safety after repairing
• Check the screws, parts, lead wires to take in place.
• Check the repairing portion whether circumferential parts are damaged or not.
• Check insulation resistance between supply plug and earth.
• When install refrigerator, check condition of supply cord and plug.
• Wipe off the dust on plug.
• Cutting and seal the electric device carefully.
1.2 Caution
Watch the hot parts
• During operation and after operation, compressor and pipes are hot.
• Also, under these condition, heater are hot.
• Do not burn your fingers when you touch it.
Pay attention to refrigerant
• Do not touch liquid refrigerant. Otherwise your hands may be burnt.
Pay attention to edge of parts
• Otherwise, your fingers may be cut.
Pay attention to fins of evaporator and condenser
• Otherwise, your fingers may be cut.
Before transportatin, adjust the bolt
• Otherwise, the floor may be damaged.
Do not touch the pipe after brazing
• Otherwise, your hands may be burnt.
- 3 -
Service BR307_347.indd 3Service BR307_347.indd 3 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

2.1 NR-BR307 SERIES
Model NR-BR307
Destination Thailand Vietnam Hong Kong Indonesia Singapore RBD Malaysia Philippines India
Code Attached Model TH VN HK 1D SG WA MY PH X1
Power Source
220V/50Hz 220-240V/50Hz 220V/50Hz 220~240V/50Hz 220~240V/50Hz 220~240V/50Hz 220-240V/50Hz 230V/60Hz 230V/50Hz
Plug C3P C2P S3P C2P S3P C2P S3P A2P B3P
Grade Code Z/X Z Z/V Z Z Z Z Z X/V
Colour Code S S S S S S S S S
System Spec. Inverter + ECONAVI
Specification
Capacity Total Volume 265 265 296 302 296 296 296 265 296
FC 72 72 92 94 92 92 92 72 92
PC 193 193 204 208 204 204 204 193 204
Internal Dimension
( W x D x H )
FC 472.6 x 343 x 497.8 (mm.)
PC 513.6 x 426.7 x 828 (mm.)
External Dimensions 600 x 629 x 1546 (mm.)
Installation Space Side : 50mm min./ Back : 100mm min./ Top : 300mm min.
Temperature FC Slide Shutter / Plate Duct PCT
Control PC Control Board / PC Door / For Z only
Heating Device
For Defrosting
Type Radiant Heater / MM6 - 4404
Rating 322.7Ω
Defrosting Control Type PAS - BR307 (CONTROL)
Defrost Cycle (1) Power on 4h (Rated time)
(2) ATC corrected temp. ≤22°C 13h
(3) 23°C ≤ATC corrected temp. ≤33°C 8.5h
(4) ATC corrected temp. ≥34°C 8.5h
Inner Liner Vacuum formed ABS resin / Shell and door
Insulation Cyclopentane (DSD421.21) / Shell and door
Net Weight 51 Kg
Sealed Unit
Compressor Type Hermetically sealed, EEI57C13DFH-C0EXS
Refrigerant Type R - 134a
Charging Amt. 130 ± 2g
Lubricating Oil Type freol α- 10
Charging Amt. 215 ± 5ml
Condenser
(Material)
Side Single wall steel tube (Zinc Coat)
Bottom C1220TS - 0L
Pressure Reducing
Device
Type Capillary Tube
Material C1220TS - 1/2H
I/D x Length Ø 0.72mm x 2740mm
2 nd Pressure 0.640 MPa
Evaporator Type Fin and Tube
Electric Part
Door Switch (PC) Type S.P. - S.T. / D3D-121 (omron)
Rating 250V / 0.5A
Fan Motor Type 4515JL03WB10GFI / Prop fan (Box Type)
Rating DC9V / 0.1A / under applied fan Ø90 mm.
Compressor Motor Type TH13VD, DC Brushless Motor / 6 poles
Rating (out put) 27/37 r/s, 40.2 / 55.1W
PC Sensor (PCC) Type NTC
Rating B = 3808K, R0 = 6.409KΩ± 1%
Defrost Sensor
(DFC)
Type NTC
Rating B = 3819K ± 2%
R10 = 3.899KΩ± 3%
Ambient Temp.
Sensor (ATC)
Type NTC
Rating B = 3435K ± 1%
R25 = 10.0KΩ± 3%
Defrost Thermal
Fuse
Type Micro Temp.
Rating 250V / 10A / 73°C
Light Irradiation
Device (PC)
Type LED Lamp PCB
Rating 12V / 60mA
Overload Protector Type MM3 - 20 DCW
Opening Temp. 105 ± 5°C
Closing Temp. 61 ± 8°C
Impression I. 2.0 A ± 7.5% (AT 70°C)
2. SPECIFICATION AND COMPONENTS
- 4 -
Service BR307_347.indd 4Service BR307_347.indd 4 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

2.2 NR-BR347 SERIES
Model NR-BR347
Destination Thailand Vietnam Hong Kong Indonesia Singapore RBD Malaysia Philippines India
Code Attached Model TH VN HK 1D SG WA MY PH X1
Power Source
220V/50Hz 220-240V/50Hz 220V/50Hz 220~240V/50Hz 220~240V/50Hz 220~240V/50Hz 220-240V/50Hz 230V/60Hz 230V/50Hz
Plug C3P C2P S3P C2P S3P C2P S3P A2P B3P
Grade Code Z Z/X/V Z/V Z Z Z Z Z X,V
Colour Code S S S S S S S S S
System Spec. Inverter + ECONAVI
Specification
Capacity Total Volume 308 308 342 349 342 342 342 308 342
FC 72 72 92 94 92 92 92 72 92
PC 236 236 250 255 250 250 250 236 250
Internal Dimension
( W x D x H )
FC 472.6 x 343 x 497.8 (mm.)
PC 513.6 x 426.7 x 1008 (mm.)
External Dimensions 600 x 629 x 1726 (mm.)
Installation Space Side : 50mm min./ Back : 100mm min./ Top : 300mm min.
Temperature
Control
FC Slide Shutter / Plate Duct PCT
PC Control Board / PC Door / For Z only
Heating Device
For Defrosting
Type Radiant Heater / MM6 - 4404
Rating 322.7Ω
Defrosting Control Type PAS - BR347 (CONTROL)
Defrost Cycle (1) Power on 4h (Rated time)
(2) ATC corrected temp. ≤22°C 13h
(3) 23°C ≤ATC corrected temp. ≤33°C 8.5h
(4) ATC corrected temp. ≥34°C 8.5h
Inner Liner Vacuum formed ABS resin / Shell and door
Insulation Cyclopentane (DSD421.21) / Shell and door
Net Weight 53 Kg
Sealed Unit
Compressor Type Hermetically sealed, EEI57C13DFH-C0EXS
Refrigerant Type R - 134a
Charging Amt. 130 ± 2g
Lubricating Oil Type freol α- 10
Charging Amt. 215 ± 5ml
Condenser
(Material)
Side Single wall steel tube (Zinc Coat)
Bottom C1220TS - 0L
Pressure Reducing
Device
Type Capillary Tube
Material C1220TS - 1/2H
I/D x Length Ø 0.72mm x 2740mm
2 nd Pressure 0.640 MPa
Evaporator Type Fin and Tube
Electric Part
Door Switch (PC) Type S.P. - S.T. / D3D-121 (omron)
Rating 250V / 0.5A
Fan Motor Type 4515JL03WB10GFI / Prop fan (Box Type)
Rating DC9V / 0.1A / under applied fan Ø90 mm.
Compressor Motor Type TH13VD, DC Brushless Motor / 6 poles
Rating (out put) 27/37 r/s, 40.2 / 55.1W
PC Sensor (PCC) Type NTC
Rating B = 3808K, R0 = 6.409KΩ± 1%
Defrost Sensor
(DFC)
Type NTC
Rating B = 3819K ± 2%
R10 = 3.899KΩ± 3%
Ambient Temp.
Sensor (ATC)
Type NTC
Rating B = 3435K ± 1%
R25 = 10.0KΩ± 3%
Defrost Thermal Type Micro Temp.
Fuse Rating 250V / 10A / 73°C
Light Irradiation Type LED Lamp PCB
Device (PC) Rating 12V / 60mA
Overload Protector Type MM3 - 20 DCW
Opening Temp. 105 ± 5°C
Closing Temp. 61 ± 8°C
Impression I. 2.0 A ± 7.5% (AT 70°C)
- 5 -
Service BR307_347.indd 5Service BR307_347.indd 5 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

3. WIRING DIAGRAM
3.1 NR-BR307, NR-BR347 : Z
Color :
ZS
DOOR CONTROL BOARD
GREEN/YELLOW
WINDING RESISTANCE VALUE
U-W : 8.1

U-V : 8.1 
W-V :
8.1 
BLUE
BLUE
BLUE
BROWN
OVERLOAD PROTECTOR
PC DOOR SW.
N.C C
DFC
LED LAMP
ROOM LAMP LED BOARD
PCC
DEFROST HEATER
TEMP. FUSE
YELLOW YELLOW
(322.7 
Ý&
FAN MOTOR
7
9
10
V
U
CN2
CN201
CN302
CN1
CN301
BASE BOARD
CN303
W
COMPRESSOR
220 V - 240 V
/ 50-60 Hz
BLUE
BROWN
- 6 -
Service BR307_347.indd 6Service BR307_347.indd 6 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

3.2 NR-BR307, NR-BR347 : X, V
XS/VS
BLUE
BROWN
220 V - 240 V
/ 50-60 Hz
WINDING RESISTANCE VALUE
U-W : 8.1

U-V : 8.1 
W-V :
8.1 
- 7 -
Service BR307_347.indd 7Service BR307_347.indd 7 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

4.1 NR-BR307
-Cooling performance by Temperature control
Control Setting PC Coldest Medium Warmest
FC Coldest Medium Warmest
Mean Fresh Food compartment Temp. T3 (°C) -1.0 ± 2.5 2.0 ± 2.5 4.5 ± 2.5
Mean Freezer Load Temp. (°C) -27.0 ± 2.5 -20.0 ± 2.5 -16.5 ± 2.5
Vegetable Case Temp. (°C) - 4.0 ± 2.5 -
PC Door Shelf Upper Temp. (°C) - 5.0 ± 2.5 -
PC Door Shelf Bottom Temp. (°C) - 3.0 ± 2.5 -
Running Ratio (%) 85 ± 15 65 ± 15 50 ± 15
Power Consumption (kWh/Day) 1.15 or under
* Under On - load and ambient temperature 32 ± 1°C
-Cooling performance by ECONAVI control
Control Setting AT16°C AT32°C AT43°C
Mean Fresh Food compartment Temp. T3 (°C) - 3.0 ± 2.5 -
Mean Freezer Load Temp. (°C) - -19.0 ± 2.5 -
Vegetable Case Temp. (°C) - 5.0 ± 2.5 -
PC Door Shelf Upper Temp. (°C) - 6.0 ± 2.5 -
PC Door Shelf Bottom Temp. (°C) - 4.0 ± 2.5 -
Running Ratio (%) - 60 ± 15 -
4.2 NR-BR347
-Cooling performance by Temperature control
Control Setting PC Coldest Medium Warmest
FC Coldest Medium Warmest
Mean Fresh Food compartment Temp. T3 (°C) -3.0 ± 2.5 2.0 ± 2.5 4.5 ± 2.5
Mean Freezer Load Temp. (°C) -29.0 ± 2.5 -20.5 ± 2.5 -17.0 ± 2.5
Vegetable Case Temp. (°C) - 4.0 ± 2.5 -
PC Door Shelf Upper Temp. (°C) - 6.0 ± 2.5 -
PC Door Shelf Bottom Temp. (°C) - 3.0 ± 2.5 -
Running Ratio (%) 85 ± 15 70 ± 15 50 ± 15
Power Consumption (kWh/Day) 1.15 or under
* Under On - load and ambient temperature 32 ± 1°C
-Cooling performance by ECONAVI control
Control Setting AT16°C AT32°C AT43°C
Mean Fresh Food compartment Temp. T3 (°C) - 3.0 ± 2.5 -
Mean Freezer Load Temp. (°C) - -19.0 ± 2.5 -
Vegetable Case Temp. (°C) - 5.0 ± 2.5 -
PC Door Shelf Upper Temp. (°C) - 7.0 ± 2.5 -
PC Door Shelf Bottom Temp. (°C) - 4.0 ± 2.5 -
Running Ratio (%) - 65 ± 15 -
4. PERFORMANCE DATA
- 8 -
Service BR307_347.indd 8Service BR307_347.indd 8 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

5. TROUBLESHOOTING GUIDE
Vapor generated
inside and outside
the cabinet / surface
of door.
●Condensation may appear on the surface of cabinet when humidity is
high, e.g. during rainy season or the air circulation is not good.
●If there is condensation inside, check if the door is completely closed.
Is the refrigerator frequently opened or left open for a long time?
Is there any hot foodstuff refrigerated inside?
The refrigerator
does not operate.
●Check that the plug and its socket are in good condition.
●Check if there is any problem on main fuse and electrical system of the
house.
●Check by unplug and wait for 5 minutes before plugging it back in.
The refrigerator
does not cool
enough.
●Check to be sure that the temperature control button / knob is at the
proper position.
●
Check to see if the refrigerator is overloaded with stuff or there is any hot
foodstuff refrigerated inside.
●Is the refrigerator exposed directly to sunlight or heat source?
●Is the refrigerator door completely closed?
●Is the refrigerator door opened frequently?
The refrigerator
generates noise.
●Check if the refrigerator is located on a stable floor or is installed
properly.
●Check if there is any object in contact with the refrigerator.
LED lamp does not
turn on. ●Please contact Panasonic service center.
- 9 -
NR-BR307 / BR347
Service BR307_347.indd 9Service BR307_347.indd 9 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

6. TEMPERATURE CONTROL
- 10 -
TEMP. CONTROL REFRIGERATOR COMPARTMENT
Max
Min
“Max” Lower than “Med” by approximately 2°C ~ 3°C
Max
Min
“Med” Approximately 3°C ~ 5°C
Max
Min
“Min” Higher than “Med” by approximately 2°C ~ 3°C
Operate the Fridge Control when changing the temperature of REFRIGERATOR COMPARTMENT.
Press to lower the temperature and to raise it.
Operate the Cold Air Control when changing the cold air condition.
Fine adjustment mode
Cooling Level Minimum Maximum
Step 123456789
FRIDGE CONTROL
LED DISPLAY
Lighting Flashing Not Lighting
This refrigerator is specially designed for appropriate use, which the temperature can be controlled finely by
turning on the Fine adjustment mode.
How to operate of Fine adjustment mode
1. Start operation of Fine adjustment mode
Set Fridge Control to “Min” with the “Fridge Control” button, press Fridge Control button for
10 seconds or longer, then the Fine adjustment mode will be start.
2. Operation of the Fine adjustment mode
Fine adjustment mode can set following below table;
the setting Fine adjustment mode can be changed by
Each time of pressing Fridge Control button, it will be step 1➞2➞yyy➞8➞9
Each time of pressing Fridge Control button, it will be step 9➞8➞yyy➞2➞1
3. Finish operation of Fine adjustment mode
To exit the Fine adjustment mode, set button of fine adjustment mode to step 1,
press Fridge Control button for 10 seconds or longer, then the refrigerator return to normal
operation mode.
Note: Temperature control varies depends on the changing of environment and food storage quantity.
6.1 Z Series
Cold Air Control
“Fridge Max” REFRIGERATOR COMPARTMENT takes priority.
“Normal” Cold air condition is normal.
“Freezer Max” FREEZER COMPARTMENT takes priority.
Service BR307_347.indd 10Service BR307_347.indd 10 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

- 11 -
Note:
1Effectiveness differs depending on the ambient temperature, ambient brightness, number of times when
doors are opened and closed, and state in which food is stored.
2Darkness is detected by the light intensity sensor at approximately 3 lx to 10 lx or less.
ECONAVI operation
Detect opening and closing of door and brightness around refrigerator, and automatically controls operation
to save energy1.
ECONAVI lamp is on during ECONAVI operation
●This refrigerator learn the lifestyle patterns of your family from opening and the time periods of
infrequent use to perform ECONAVI operation.
Note:
●The refrigerator learns your lifestyle pattern from the
previous 3 weeks, and uses what it has learned from
the 4th week onwards. Therefore, the ECONAVI lamp
“ON/OFF” pattern may change from the 4th week
onwards.
●The refrigerator performs ECONAVI operation when it
becomes dark2around the refrigerator, such as when you
are asleep.
●The brightness of ECONAVI lamp is lowered
approximately 5 minutes after the lamp turns on.
Setting for enabling ECONAVI operation
●ECONAVI operation is enabled automatically only when the temperature control of the refrigerator
compartment are set to “Med”.
●
It is not possible to forcefully start ECONAVI operation while fridge control setting at “Max” and “Min” position.
● X, V Series operation by PAS-BR347 (MAIN) - X
ECONAVI lamp
Light intensity sensor
(For Z Series)
TEMP. CONTROL REFRIGERATOR COMPARTMENT
“1” Higher than “2” by approximately 2°C ~ 3°C
“2” Approximately 3°C ~ 5°C
“3” Lower than “2” by approximately 2°C ~ 3°C
COLD AIR CONTROL
“REFRIGE.MAX” REFRIGERATOR COMPARTMENT takes priority.
“NORMAL” Cold air condition is normal.
“FREEZER MAX” FREEZER COMPARTMENT takes priority.
Operate the REFRIGERATOR TEMP. CONTROL when changing the temperature of REFRIGERATOR
COMPARTMENT.
Operate the COLD AIR CONTROL when changing the cold air condition.
Note: Temperature control varies depends on the changing of environment and food storage quantity.
6.2 X, V Series
Service BR307_347.indd 11Service BR307_347.indd 11 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

7. DISASSEMBLY INSTRUCTION
- Take off by use small screwdriver put between gaps of LED Cover with Plate Duct PCT at lock as
Fig. 1
- Use small screwdriver push up the LED Cover for lock loose.
- Change LED Lamp by wear anti-eletrostatic glove while touch LED Lamp as Fig. 2
- After change LED Cover or LED Lamp, put LED Cover at the top side and slide up in lock position
as Fig. 3
- Use hand hit carefully at the right side of LED Cover from the top pass to bottom as Fig. 4
7.1 LED Cover
NR-BR307 / BR347
- 12 -
Service BR307_347.indd 12Service BR307_347.indd 12 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

- Use small screwdriver open at the screw hole cover as Fig. 1
- Take off screws at the Plate Duct PCT as Fig. 2
- Take off screws at the Plate Duct PCB and Plate Duct PC as Fig. 3
- At first, take off at the Piece Duct PC as Fig. 4
- After that take off at the Plate Duct PCB and other parts as Fig. 5
7.2 Plate Duct PCT
NR-BR307 / BR347
- 13 -
Service BR307_347.indd 13Service BR307_347.indd 13 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

NR-BR307 / BR347
- 14 -
7.3 PAS-Control Door
- Push up Cover Control As., for lock loose as Fig. 1
- Pull off Cover Control As., as Fig. 2
- Take off Lead wire socket which connect at PAS-Control as Fig. 3
- Take off screw by screwdriver at PAS-Control as Fig. 4
- Use hands push at lock for left up PAS-Control loose from Cover Control as Fig. 5
- After change new PAS-Control to place Cover Control As., at slot as Fig. 6
Service BR307_347.indd 14Service BR307_347.indd 14 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

8. PARTS EXPLODED VIEW AND REPLACEMENT PARTS LIST
- 15 -
1
2
9
11
8
12
13
36
28
6
7
10
14
S3P
5
4
3
37
37
29
35
34
31
32
33
38
43
45
46
42
39
40
41
47
30
74
75
C2P
44
17
18
19
22
16
23
24
27
15
20
21
26
25
(3 TURN)
73
8.1 Parts Exploded View : Body
NR-BR307 / BR347
Service BR307_347.indd 15Service BR307_347.indd 15 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

- 16 -
59
60
62 63
61
64
65
65
66
67
64
48
49
72
69
70
71
68
54
50
57
56
55
52
53
58
51
69
70
71
68
( FOR NR-BR307 SERIES )
8.2 Parts Exploded View : Door
NR-BR307 / BR347
Service BR307_347.indd 16Service BR307_347.indd 16 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

- 17 -
PACKING BELT
PLASTIC COVER
BOTTOM TRAY AS.
STICKER BARCODE
STICKER MODEL NAME
FOAM TOP PAD L, R
(FOR INDIA, HONG KONG MODEL)
(FOR INDIA, HONG KONG MODEL)
TOP PAD F & B
PROTECTOR DOOR AS.
8.3 Parts Exploded View : Packing
NR-BR307 / BR347
Service BR307_347.indd 17Service BR307_347.indd 17 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

- 18 -
8.4 REPLACEMENT PART LIST
Important safety notice :
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacturer’s specified part.
Parts List : NR-BR307, NR-BR347 SERIES
Safety
Ref.
No.
Part name Part No.
Model/Colour/Qty
RemarkNR-BR307 NR-BR347
ZS XS VS ZS XS VS
1 COVER HINGE TOP CNRAE-142672 1 1 1 1 ZS,XS TYPE
COVER HINGE TOP CNRAE-142702 1 1 VS TYPE
2 HINGE TOP CNRAE-142652 1 1 ZS TYPE
CNRAE-142662 1 1 1 1 XS,VS TYPE
3 GLASS TRAY PC AS. CNRBH-147680 3 3 3 3 3 3
4 GLASS TRAY CRISPER AS. CNRBH-194071 1 1 1 1 1 1
5 CRISPER CNRAH-313620 1 1
COLOUR:HIGH CLEAR SMOKE GRAY
CNRAH-275424 1 1 1 1 COLOUR:TRANSPARENT
6 HINGE CENTER CNRAE-136502 1 1 1 1 1 1
7 PIN HINGE CENTER CNRAE-136583 1 1 1 1 1 1
8 HINGE BOTTOM CNRAE-136494 1 1 1 1 1 1
9 CAP PAN H.4TS-ST CNR39-162720 1 1 1 1
CAP PAN H.4TS-SL CNR39-162680 1 1
10 CAP PAN H.4TS-W CNR39-162431 2 2 2 2 2 2
11 ADJUSTER BOLT CNRAC-225771 1 1 1 1 1 1 RIGHT
LEG SHELL CNRAC-228731 1 1 1 1 1 1 LEFT
12 SUPPORT COIL D CNRAF-183091 1 1 1 1 1 1 RIGHT
SUPPORT COIL CNRAF-163503 1 1 1 1 1 1 LEFT
13 CASE SW. FC CNRAC-201540 1 1 1 1 1 1
14 DOOR SW. CNRAG-153280 1 1 1 1 1 1
15 SENSOR DEF. CNRAG-168580 1 1 1 1 1 1
16 COIL AS. CNRBF-155774 1 1 1 1 1 1 COIL: 3 TURN
17 TEMP FUSE AS. CNRBG-180841 1 1 1 1 1 1
18 COVER REDIANT CNRAG-167241 1 1 1 1 1 1
19 HEATER AS. DEFROST CNRAG-173931 1 1 1 1 1 1
20 COVER COIL CNRAF-183034 1 1 1 1 1 1
21 INSULATION COVER COIL F CNRAF-183101 1 1 1 1 1 1
22 HOLDER ICE TRAY AS. CNRBH-141910 1 1 1 1 1 1
23 ICE CUBE TRAY AS. CNRBH-135250 1 1 1 1 1 1
24 BOX ICE TRAY CNRAH-313590 1 1
COLOUR:HIGH CLEAR SMOKE GRAY
CNRAH-227460 1 1 1 1 COLOUR:TRANSPARENT
25 CASE FCT CNRAH-313600 1 1 COLOUR:HIGH CLEAR SMOKE GRAY
CNRAH-227460 1 1 1 1 COLOUR:TRANSPARENT
26 RAIL FCT R CNRAC-203451 1 1 1 1 1 1
27 CASE FCB CNRAH-313610 1 1 COLOUR:HIGH CLEAR SMOKE GRAY
CNRAH-275443 1 1 1 1 COLOUR:TRANSPARENT
28 HANGER SHELL R CNRAC-225721 1 1 1 1 1 1
29 HANGER SHELL L CNRAC-225731 1 1 1 1 1 1
30 PAN WATER EVA CNRAF-190652 1 1 1 1 1 1
31 BOX PCB AS.-Z (C3P) CNRBG-193904 1 1 FOR : TH
BOX PCB AS.-Z (C2P) CNRBG-193914 1 1 1 1 1 1 FOR : VN,1D,RBD
BOX PCB AS.-Z (S3P) CNRBG-193924 1 1 1 1 FOR : HK,SG,MY
BOX PCB AS.-Z (A2P) CNRBG-193934 1 FOR : PH
BOX PCB AS.-X (C3P) CNRBG-194214 1 FOR : TH
BOX PCB AS.-X (S3P) CNRBG-193954 1 1 FOR : HK
BOX PCB AS.-X (B3P) CNRBG-204920 1 1 FOR : X1
32 BOX PCB CNRAG-173831 1 1 1 1 1 1
33 PAS-CONTROL PCB (INV) ARBPC1A03030 1 1 FOR : ZS TYPE
ARBPC1A03040 1 1 1 1 FOR : XS,VS TYPE
34 COVER BOX PCB CNRAG-173851 1 1 1 1 1 1
35 WARNING LABEL-TH CNRAH-240352 1 1 1 1 THAI
WARNING LABEL-EXPORT CNRAH-239732 1 1 1 1 1 1 EXPORT
36 WIRING DIAGRAM (PRINT)-ZSTH CNRAH-321301 1
WIRING DIAGRAM (PRINT)-ZSTH CNRAH-321191 1
WIRING DIAGRAM (PRINT)-ZSVN CNRAH-321311 1
WIRING DIAGRAM (PRINT)-ZSVN CNRAH-321201 1
WIRING DIAGRAM (PRINT)-ZSHK CNRAH-321321 1
WIRING DIAGRAM (PRINT)-ZSHK CNRAH-321211 1
WIRING DIAGRAM (PRINT)-ZS1D CNRAH-321331 1
WIRING DIAGRAM (PRINT)-ZS1D CNRAH-321221 1
WIRING DIAGRAM (PRINT)-ZSSG CNRAH-321341 1
WIRING DIAGRAM (PRINT)-ZSSG CNRAH-321231 1
WIRING DIAGRAM (PRINT)-ZSWA CNRAH-321351 1
WIRING DIAGRAM (PRINT)-ZSWA CNRAH-321241 1
WIRING DIAGRAM (PRINT)-ZSMY CNRAH-321361 1
WIRING DIAGRAM (PRINT)-ZSMY CNRAH-321251 1
WIRING DIAGRAM (PRINT)-ZSPH CNRAH-321371 1
WIRING DIAGRAM (PRINT)-ZSPH CNRAH-321261 1
WIRING DIAGRAM (PRINT)-XSTH CNRAH-321381 1
WIRING DIAGRAM (PRINT)-XSVN CNRAH-321271 1
WIRING DIAGRAM (PRINT)-VSVN CNRAH-321281 1
WIRING DIAGRAM (PRINT)-VSHK CNRAH-321391 1
WIRING DIAGRAM (PRINT)-VSHK CNRAH-321291 1
WIRING DIAGRAM (PRINT)-XSX1 CNRAH-337440 1
WIRING DIAGRAM (PRINT)-XSX1 CNRAH-337420 1
WIRING DIAGRAM (PRINT)-VSX1 CNRAH-337450 1
WIRING DIAGRAM (PRINT)-VSX1 CNRAH-337430 1
Service BR307_347.indd 18Service BR307_347.indd 18 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

- 19 -
8.4 REPLACEMENT PART LIST
Important safety notice :
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacturer’s specified part.
Parts List : NR-BR307, NR-BR347 SERIES
Safety
Ref.
No.
Part name Part No.
Model/Colour/Qty
Remark
NR-BR307 NR-BR347
ZS XS VS ZS XS VS
37 SUPPLY CORD AS.-C3P CNRBG-193602 11 1 FOR : TH
SUPPLY CORD AS.-S3P CNRBG-194051 1111 FOR : HK,SG,MY
SUPPLY CORD AS.-C2P CNRBG-194040 111111 FOR : VN,1D,RBD
SUPPLY CORD AS.-A2P CNRBG-194060 11 FOR : PH
SUPPLY CORD AS.-B3P CNRBG-204900 11 11 FOR : X1
38 U-RING7 CNRAJ-170190 444444
39 COMP.EEI57C13DFH-C0EXS CNR91-116490 111111
40 MOTOR PROTECTOR CNR06-598071 111111
41 PROTECTOR COVER CNRAG-170461 111111
42 CROSSRAIL REAR AS. CNRBF-163570 111111
43 5 DRYER W CNR39-340920 111111
44 PIPE WATER EVA CNRAF-195211 111111
45 RUBBER GROMMET CNRAJ-163250 444444
46 CLAMPER DRYER CNR39-163082 111111
47 EARTH WIRE AS.COMP.150 CNRBG-168610 111111
48 FAN MOTOR FC CNRAG-171790 111111
49 INS.DUCT PC CNRAH-275535 111111
50 PLATE DUCT PCT CNRAH-313581 11 NEW INNOCENT WHITE
CNRAH-275486 11 11 ICE CLEAR BLUE
51 SHUTTER - W CNRAH-313631 11 NEW INNOCENT WHITE
SHUTTER - B CNRAH-275592 11 11 ICE CLEAR BLUE
52 PAS CONTROL (INSIDE) CNRBG-182562 11 11
53 DIAL CONTROL(B) CNRAH-307610 11 11 ICE CLEAR BLUE
54 PLATE DUCT PCB CNRAH-316000 111111 NEW INNOCENT WHITE
55 PIECE DUCT PC AS. CNRBH-147670 111111 NEW INNOCENT WHITE
56 AG BIO FILTER CNRAH-245521 111111
57 PAS-BU343 (LED PCB) CNRBG-180303 111111
58 COVER LED LAMP CNRAH-275581 111111
59 GASKET DOOR PC CNRAD-349371 111
CNRAD-349381 111
60 EMBLEM CNRAD-379982 111111
61 DOOR AS. PC(CMPT)-ZS CNRBD-379144 1
CNRBD-397114 1
DOOR AS. PC(CMPT)-XS CNRBD-397154 1
CNRBD-397124 1
DOOR AS. PC(CMPT)-VS CNRBD-397164 1
CNRBD-397134 1
62 PAS-CONTROL DOOR CNRBG-194240 11
63 COVER CONTROL AS. CNRBD-397230 11
64 LATCH DOOR CNRAE-136513 111111
65 STOPPER DOOR CNRAD-305832 111111
66 GASKET DOOR FC CNRAD-344501 111111
67 DOOR AS. FC(CMPT)-ZS CNRBD-397070 11 11
DOOR AS. FC(CMPT)-VS CNRBD-397080 11
68 SHELF EGG CNRAD-373480 11 22 COLOUR:HIGH CLEAR SMOKE GRAY
CNRAD-343385 12 COLOUR:TRANSPARENT
69 TRAY EGG 8 CNRAD-350530 111111
70 SHELF PC CNRAD-373470 11 11 COLOUR:HIGH CLEAR SMOKE GRAY
CNRAD-343373 11 COLOUR:TRANSPARENT
71 SHELF BOTTLE CNRAD-373460 11 11 COLOUR:HIGH CLEAR SMOKE GRAY
CNRAD-343361 11 COLOUR:TRANSPARENT
72 LABEL NAME & REF. (PRINT)-ZSTH CNRAH-321520 1
LABEL NAME & REF. (PRINT)-ZSTH CNRAH-321410 1
LABEL NAME & REF. (PRINT)-ZSVN CNRAH-321530 1
LABEL NAME & REF. (PRINT)-ZSVN CNRAH-321422 1
LABEL NAME & REF. (PRINT)-ZSHK CNRAH-321540 1
LABEL NAME & REF. (PRINT)-ZSHK CNRAH-321430 1
LABEL NAME & REF. (PRINT)-ZS1D CNRAH-321550 1
LABEL NAME & REF. (PRINT)-ZS1D CNRAH-321440 1
LABEL NAME & REF. (PRINT)-ZSSG CNRAH-321560 1
LABEL NAME & REF. (PRINT)-ZSSG CNRAH-321450 1
LABEL NAME & REF. (PRINT)-ZSWA CNRAH-321570 1
LABEL NAME & REF. (PRINT)-ZSWA CNRAH-321460 1
LABEL NAME & REF. (PRINT)-ZSMY CNRAH-321580 1
LABEL NAME & REF. (PRINT)-ZSMY CNRAH-321471 1
LABEL NAME & REF. (PRINT)-ZSPH CNRAH-321590 1
LABEL NAME & REF. (PRINT)-ZSPH CNRAH-321482 1
LABEL NAME & REF. (PRINT)-XSTH CNRAH-321600 1
LABEL NAME & REF. (PRINT)-XSVN CNRAH-321492 1
LABEL NAME & REF. (PRINT)-VSVN CNRAH-321502 1
LABEL NAME & REF. (PRINT)-VSHK CNRAH-321610 1
LABEL NAME & REF. (PRINT)-VSHK CNRAH-321510 1
LABEL NAME & REF. (PRINT)-XSX1 CNRAH-337500 1
LABEL NAME & REF. (PRINT)-XSX1 CNRAH-337480 1
LABEL NAME & REF. (PRINT)-VSX1 CNRAH-337510 1
LABEL NAME & REF. (PRINT)-VSX1 CNRAH-337490 1
73 PAD COMP CNRAK-172050 11
74 EARTH AS. COMP.2500 CNRBG-165990 11
75 HARNESS AS. WIRE -CM CNRBG-193642 111111
Service BR307_347.indd 19Service BR307_347.indd 19 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM

DETAIL CHANGE NOTICE
- 20 -
Safety
Ref.
No.
Parts name Parts No.
Model/Colour/Qty
RemarkNR-BR307 NR-BR347
ZS XS VS ZS XS VS
1CARTON BOX (PRINT) - ALL CNRAK-172220 1 1 1
CARTON BOX (PRINT) - ALL CNRAK-172200 1 1 1
CARTON BOX (PRINT) - HK CNRAK-172231 1 1 FOR : HK,X1
CARTON BOX (PRINT) - HK CNRAK-17211 1 1 FOR : HK,X1
2STICKER MODEL NAME-ZSTH CNRAH-321960 1
STICKER MODEL NAME-ZSTH CNRAH-321850 1
STICKER MODEL NAME-ZSVN CNRAH-321971 1
STICKER MODEL NAME-ZSVN CNRAH-321861 1
STICKER MODEL NAME-ZSHK CNRAH-321980 1
STICKER MODEL NAME-ZSHK CNRAH-321870 1
STICKER MODEL NAME-ZS1D CNRAH-321990 1
STICKER MODEL NAME-ZS1D CNRAH-321880 1
STICKER MODEL NAME-ZSSG CNRAH-322000 1
STICKER MODEL NAME-ZSSG CNRAH-321890 1
STICKER MODEL NAME-ZSWA CNRAH-322010 1
STICKER MODEL NAME-ZSWA CNRAH-321900 1
STICKER MODEL NAME-ZSMY CNRAH-322020 1
STICKER MODEL NAME-ZSMY CNRAH-321910 1
STICKER MODEL NAME-ZSPH CNRAH-322031 1
STICKER MODEL NAME-ZSPH CNRAH-321921 1
STICKER MODEL NAME-XSTH CNRAH-322040 1
STICKER MODEL NAME-XSVN CNRAH-321931 1
STICKER MODEL NAME-VSVN CNRAH-321941 1
STICKER MODEL NAME-VSHK CNRAH-322050 1
STICKER MODEL NAME-VSHK CNRAH-321950 1
STICKER MODEL NAME-XSX1 CNRAH-337580 1
STICKER MODEL NAME-XSX1 CNRAH-337560 1
STICKER MODEL NAME-VSX1 CNRAH-337590 1
STICKER MODEL NAME-VSX1 CNRAH-337570 1
3BOTTOM TRAY AS. - ALL CNRBK-123865 1 1 1 1 1 1
BOTTOM TRAY AS. - HK CNRBK-121248 1 1 1 1 FOR : HK,X1
4 PLASTIC COVER CNRAJ-162111 1 1 1
CNRAJ-162101 1 1 1
5TOP PAD L CNRAK-147970 1 1 1 1 1 1
TOP PAD R CNRAK-147962 1 1 1 1 1 1
TOP PAD F CNRAK-148000 1 1 1 1 FOR : HK,X1
TOP PAD B CNRAK-148010 1 1 1 1 FOR : HK,X1
6 PROTECTOR DOOR AS. CNRBK-117320 1 1 1 1 FOR : HK,X1
7INSTRUCTION BOOK - TH CNRAK-172130 1 1 1
INSTRUCTION BOOK - VN CNRAK-172141 1 1 1 1
INSTRUCTION BOOK - HK CNRAK-172151 1 1 1 1
INSTRUCTION BOOK - 1D CNRAK-172161 1 1
INSTRUCTION BOOK - SG CNRAK-172171 1 1
INSTRUCTION BOOK - RBD CNRAK-172181 1 1
INSTRUCTION BOOK - MY CNRAK-172191 1 1
INSTRUCTION BOOK - PH CNRAK-173141 1 1
INSTRUCTION BOOK - X1 CNRAK-176440 1 1 1 1
8.4 REPLACEMENT PART LIST
Important safety notice :
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacturer’s specified part.
Parts List : NR-BR307, NR-BR347 SERIES
Revision Item no. Page Detail Remark
Jul.2016 1 1 Addition destination India
2 2 Addition : Detail change notice. P.20
3 4~5 Addition : Specification of India
4 6~7 Addition : 3P,Winding Resistance Value Plug,Compressor R spec
5 17 Addition : For India,Hong Kong Model Packing
618
Addition : Part list of India
Revise : No.1,2,16,19,21,31,33,36 Update:Part name&No.
719
Addition : Part list of India
Revise : No.37,40,41,51,52,57,61,67,72 Update:Part name&No.
620
Addition : Packing Part list of India
Revise : No.1,2,3,4,7 Update:Part name&No.
Service BR307_347.indd 20Service BR307_347.indd 20 7/26/2559 BE 9:07 AM7/26/2559 BE 9:07 AM
