Panasonic Web-server II User manual

Operating Instructions
MEW01228
Revision 1
Web512 V2.6.x for Web-server II, 1598
Author: Jan Pettersson
Date of issue: 2009-09-21
Date of rev: 2011-08-12

This page has deliberately been left blank.

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
1
Table of contents
1Introduction________________________________ 5
2Definitions / Explanations ____________________ 6
3General description _________________________ 7
3.1 Web-server II, 1598 ________________________________ 8
4Functions __________________________________ 9
4.1 Login ___________________________________________ 10
4.2 Sound Off, Help & Print ____________________________ 10
4.2.1 Sound Off ___________________________________ 10
4.2.2 Help________________________________________ 11
4.2.3 Print________________________________________ 11
4.3 Tester4__________________________________________ 11
4.4 Status___________________________________________ 12
4.4.1 Control unit __________________________________ 12
4.4.2 Alarm_______________________________________ 13
4.4.3 Pre-warning__________________________________ 14
4.4.4 Co-incidence _________________________________ 15
4.4.5 Faults_______________________________________ 15
4.4.6 Disablements _________________________________ 15
4.4.7 Interlockings _________________________________ 15
4.4.8 Service signals________________________________ 16
4.4.9 Doors Opened ________________________________ 16
4.4.10 Zones in Test _________________________________ 16
4.5 Fault List ________________________________________ 17
4.6 Disablement______________________________________ 17
4.6.1 Zone Address. ________________________________ 18
4.6.2 Zone________________________________________ 18
4.6.3 Device type __________________________________ 18
4.6.4 Inter. Output (Interlocking Output.) _______________ 18
4.6.5 Loop unit Output ______________________________ 19
4.6.6 Relay Output _________________________________ 19
4.6.7 Voltage Output _______________________________ 19
4.6.8 RE8 Output (Re0-Re7.) ________________________ 19
4.6.9 GFBP Output_________________________________ 20
4.6.10 Control Unit Loop (COM loop 0-3.) ______________ 20
4.6.11 Loop unit Loop (Loop unit, zone line input.)________ 20
4.6.12 DET8 Loop (DET8 zone line input 0-7). ___________ 20
4.6.13 BS4 Loop (BS4 loop 0-3.) ______________________ 21
4.6.14 General _____________________________________ 21
4.6.15 By Time Channel _____________________________ 21
4.6.16 Alert annunciation_____________________________ 21
4.7 Sensor list _______________________________________ 23
4.7.1 Search by Tech. No. ___________________________ 23

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
2
4.7.2 Search by Zone - Address _______________________ 23
4.7.3 Search by Limit _______________________________ 24
4.8 Event log ________________________________________ 25
4.8.1 General _____________________________________ 25
4.8.2 Alarm_______________________________________ 25
4.8.3 Interlocking __________________________________ 26
4.8.4 Web Event___________________________________ 26
4.9 Operation; Daily__________________________________ 27
4.9.1 Daily - Disablement ___________________________ 27
4.9.2 Password (Access code)________________________ 28
4.9.3 Interlocking __________________________________ 28
4.9.4 Misc________________________________________ 30
4.9.5 Zone Test____________________________________ 30
4.9.6 Gateway_____________________________________ 30
4.9.7 Web links ___________________________________ 31
4.10 Operation; Maintenance ____________________________ 32
4.10.1 Maintenance –Disablement _____________________ 32
4.10.2 Password (Access code)________________________ 33
4.10.3 Misc________________________________________ 33
4.11 Operation; Service ________________________________ 35
4.11.1 Service –Misc. _______________________________ 35
4.11.2 Service –Act. Outputs _________________________ 36
4.11.3 Service –Statistic _____________________________ 37
4.11.4 Password (Access code)________________________ 39
4.11.5 Fire Drill ____________________________________ 39
4.11.6 FTP / Telnet__________________________________ 40
4.12 Logout __________________________________________ 41
4.13 E-mails _________________________________________ 41
4.14 Gateway function _________________________________ 41
5Web512 II Config Tool V2.6.x ________________ 42
5.1 Sites____________________________________________ 42
5.2 Web ____________________________________________ 44
5.2.1 TCP/IP (Ethernet IP) ___________________________ 44
5.2.2 NTP Server __________________________________ 44
5.2.3 Custom logo & text ____________________________ 44
5.2.4 Text ________________________________________ 45
5.2.5 Alarm sound _________________________________ 45
5.3 General e-mail____________________________________ 46
5.3.1 General e-mail configuration ____________________ 46
5.3.2 E-mail properties______________________________ 46
5.4 Language________________________________________ 50
5.4.1 Select language for web pages ___________________ 50
5.4.2 Select web link for Help text_____________________ 50
5.5 Gateway ________________________________________ 51
5.5.1 Type of gateway ______________________________ 51
5.5.2 SIA ________________________________________ 51

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
3
5.5.3 Tateco configuration ___________________________ 51
5.5.4 COM port configuration ________________________ 51
5.6 Users ___________________________________________ 53
5.6.1 User settings _________________________________ 53
5.7 Web Link________________________________________ 54
5.8 CU Name________________________________________ 55
5.9 FTP/SSL ________________________________________ 56
5.9.1 Change user info for FTP login___________________ 56
5.9.2 Select SSL Certificates _________________________ 56
5.10 Misc____________________________________________ 57
5.10.1 Event Log ___________________________________ 57
5.10.2 Misc. settings_________________________________ 58
5.10.3 EBL Talk on Ethernet __________________________ 58
5.11 About___________________________________________ 59
6Site download to Web-server II_______________ 60
7S/W download to Web-server II ______________ 61
8Installation / Commissioning _________________ 62
8.1 LED indicators ___________________________________ 62
8.2 Starting up the web-server __________________________ 62
9Connections _______________________________ 64
10 Revision history____________________________ 65

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
4

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
5
1 Introduction
This document describes Web512 V2.6.x for Web-server II 1598.
Web-server II 1598 is the hardware.
The functions are depending on which software that is downloaded to
the Web-server II.
The functions are also depending on which configuration data that is
created and downloaded to the Web-server II.
The software (Web512) is downloaded at the same time as the
configuration data to the Web-server II via a Config Tool (a PC
program).
The Config Tool is depending on the EBL system and the EBL
software version.
This document describes the following software:
Web512 V2.6.x for Web-server II 1598.
To create the configuration data and to download it as well as the
software to the Web-server II, the following Config Tool shall be
used:
Web512 II Config Tool V2.6.x.
The Web-server II is used when one EBL512 control unit or an
EBL512 system with two or more control units shall be connected to
Internet / an intranet (LAN) and/or as a Gateway, as follows:
For presentation of the EBL512 status in a PC (web browser).
For remote control of the EBL512 (via encrypted and safe two-
way communication).
As an e-mail client.
As a Gateway.
NOTE!
The Web-server II 1598 has replaced the Web-server 1588, which is
no longer manufactured. The Config Tools for Web-server 1588
cannot be used for Web-server II 1598. Config tools for Web-server
II 1598 have to be used, e.g. Web512 II Config Tool V2.6.x.

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
6
2 Definitions / Explanations
Definitions / explanations / abbreviations / etc. frequently used or not
explained elsewhere in the document.
C.i.e. Control and indicating equipment (=control unit; C.U.)
C.U. Control unit (=Control and indicating equipment)
S/W Software
H/W Hardware
System Two or more control units connected to a TLON
Network.
Circular log / list
The log / list re-starts when it is "full". The first events
will be overwritten, i.e. a circular log / list shows the xx
latest events.
Straight log / list
The log / list stops when it is full and has to be erased
before the logging can start again, i.e. a straight log
shows the xx earliest events.
LAN Local Area Network.

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
7
3 General description
The Web-server II (1598) can be used with one, two, three or four of
the following functions:
1. As a web-server when one EBL512 control unit or an EBL512
system with two or more control units shall be connected to
Internet / an intranet (LAN), for presentation of EBL512
status in a PC using the web browser Microsoft Internet
Explorer. See page 9.
2. As a web-server for remote control of EBL512 via encrypted
and safe two-way communication (HTTPS). See page 9.
3. As an e-mail client to send e-mails in case of special events
(e.g. fire alarm, fault, etc.), see page 46.
4. As a Gateway to a separate system, i.e. to transmit and present
fire alarm information in another (PC) system. See chapter
"Gateway", page 51.
NOTE! Pos. 2 and pos. 3 (above) cannot be used separately, only
together with pos. 1.
The Web-server II has to be configured and the Web-server II
software has to be downloaded via the Config Tool Web512 II
Config Tool V2.6.x. See also chapter "Introduction", page 5.
NOTE! Remote control is only valid for system EBL512 software
version > 2.5.
Figure 1. A PC is connected to an EBL512 system via internet /
an intranet (LAN) and the Web-server II, 1598.

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
8
3.1 Web-server II, 1598
Figure 2. Web-server II, 1598.
The Web-server II consists of a light grey plastic cabinet, which shall
be vertically mounted on a DIN rail.1
The Web-server II has four interfaces.
For connections and technical data, see Technical Description for
Web-server II 1598 (MEW01035).
1Symmetric 35 mm DIN rail. Not supplied with the Web-server II.

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
9
4 Functions
The following chapters describes all Web-server II functions.
The site's start page (before login) might look as follows:
NOTE! The look might vary depending on screen resolution, settings etc.
Up to the right: A predefined text string (custom text) with data about
the actual system, see chapter "Text", page 45.
Down to the right: An image (custom logo), see chapter "Logo", page
44.
A number of buttons (hyperlinks to other pages).
Depending on if "Anonymous login" is allowed or not, User name
and Password are required or not required, to see the status
information.
Even if the Web-server II is to be used for status information only
(User level 1), it is recommended to use User name and Password
(i.e. "Anonymous login" is not recommended).
For remote control and access to corresponding information, a User
name and a Password are always required for User level 2 (Daily),
User level 3 (Maintenance) and User level 4 (Service).
The Web-server II has to be configured via the PC tool Web512 II
Config Tool V2.6.x, see page 42.
User level 1 (Status information only.)
User level 2 (Daily)
User level 3 (Maintenance)
User level 4 (Service)

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
10
4.1 Login
Username: Type the user name for the User level respectively.
Password: Type the user password for the User level respectively.
Click OK to open the Status –Summary view.
NOTE! It is possible to have a "User lockout" for one hour after three
unsuccessful login attempts.
After login the site might look as follows:
The login User name (in this example "Tester4") will be shown up to
the left.
Depending on the login User name and Password (i.e. depending on
User level), different buttons can be used, which give access to remote
control and/or information.
Regarding Logout, see chapter "Logout", page 41.
4.2 Sound Off, Help & Print
4.2.1 Sound Off
NOTE! This button is only visible if a sound file is downloaded and
also Enabled, see chapter "Alarm sound", page 45.
When a fire alarm is activated the buzzer/speaker in the PC is used for
a sound alert.
Click Sound Off to silence the buzzer/speaker in the PC (until a new
fire alarm is activated).

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
11
4.2.2 Help
Click Help to open a help text. Regarding the user definable URL
(web link) for the help text, see chapter "Language", page 50.
4.2.3 Print
Click Print to open a "Print" dialog box. Select a printer, do the
required settings and click Print to start the printing.
You will get a print-out, on the selected printer, of the information
shown in the open view / list. An example:
4.3 Tester4
NOTE! Tester4 is in this example only! The User Name that you
used for login will be shown here.
Click Tester4 to open the Web user –Change password view:
The Password for any valid User Name can be changed.
Old password: Type the old password.
New password: Type the new password.
Verify password: Type the new password.
Click Change to carry out the change.

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
12
4.4 Status
After log in
or
In any other view click Status or Summary to see the Status –
Summary view.
Depending on the log in User level (which is depending on User
name and Password), different buttons can be used, which give
access to remote control and information or information only.
The page is continuously updated (approx. each 10th sec.).
In case of inconsistency between the Web-server II and the EBL512
system a synchronization has to be done via EBL512 (menu H8/S10).2
See also chapter "Synchronize", page 34. After restart of the Web-
server II is always a synchronization done (automatically).
Regarding User name and Password, see chapter "Functions", page 9.
User level 1 is for presentation of the actual EBL512 status only.
The user can, after log in on User level 1, view the Status –Summary
information shown above.
The different Items and Values (number of alarms etc.) as well as
each button are described on the following pages.
4.4.1 Control unit
Click Control Unit to open the Status –Control Unit view:
Sync. Status, see chapter "Synchronize", page 34.
2If more than one EBL512 are available the synchronization can be done via
Win512 (the PC with Win512 can be connected to one EBL512 c.i.e. and the
Web-server II to another).

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
13
Sync. Status = Finished = The control unit info for the system
(system) have been picked up by the Web-server II.
4.4.1.1 System Info
Click System Info to open the Status –System Information view:
System Information, e.g. software version (2.6.4) and maximum
number of addresses that can be used (MAX LOOPS 512).
Click Control Unit to return the Status –Control Unit view.
Click Summary to return to the Status –Summary view.
4.4.1.2 Gateway Fault
Value = Normal = There is no Web-server II  external equipment
communication fault.
Value = Error = There is a Web-server II  external equipment
communication fault.
4.4.1.3 Last sent e-mail tag
Value = Date and time when the last e-mail was sent. (Also showing
if the communication Web-server II  SMTP server was OK at
that time.)
4.4.1.4 RS232 Fault
Value = Normal = There is no Web-server II  EBL512
communication (RS232) fault.
Value = Error = There is a Web-server II  EBL512
communication (RS232) fault.
4.4.1.5 Version
Web512 S/W version.
4.4.2 Alarm
In case of a fire alarm (Value > 0 and red indication), click Alarm or
List to view the Alarm view / list.

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
14
The Time (date & time), Zone –Address and Text (alarm text) are
displayed.
Source = Smoke, Heat, Multi, MCP, Exting. system or Other.
State = Heavy smoke / heat, Test, Isolated and Alert Annunciation
alarm acknowledged / not acknowledged. 3(Alert Annunciation alarm
–see below)
Info: A hyperlink to open a document, a drawing etc. for more
information regarding the alarm point.
Camera: A hyperlink to a web camera.
Click Reset to reset the fire alarm respectively. (Require log-in on
User level 3 or higher.)
Click Reset All to reset all fire alarms. (Require log-in on User
level 3 or higher.)
If the list is "full" click Next to see the next list and Prev to see
previous list.
NOTE!
Ack (to the left of Reset All) can only be used when an Alert
Annunciation alarm is activated. Click Ack to acknowledge the Alert
Annunciation alarm.
4.4.3 Pre-warning
In case of a pre-warning (Value > 0 and yellow indication), click Pre-
warning or List to view the Pre-warning Alarm view / list.
The Time (date & time), Zone –Address and Text (alarm text) are
displayed.
Source = Smoke, Heat, Multi or Other.
3In Australian convention also Acknowledged alarm.
001-01

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
15
State = -
Info: A hyperlink to open a document, a drawing etc. for more
information regarding the alarm point.
Camera: A hyperlink to a web camera.
If the list is "full" click Next to see the next list and Prev to see
previous list.
4.4.4 Co-incidence
In case of a co-incidence alarm (Value > 0 and yellow indication), e.g.
one "two-address dependent alarm", click Co-incidence or List to
view the Co-incidence Alarm view / list.
The Time (date & time), Zone –Address and Text (alarm text) are
displayed.
Source = Smoke, Heat, Multi, MCP or Other.
State = -
Info: A hyperlink to open a document, a drawing etc. for more
information regarding the alarm point.
Camera: A hyperlink to a web camera.
Click Reset All to reset all co-incidence alarms. (Require log-in on
User level 3 or higher.)
Click Reset to reset the co-incidence alarm respectively. (Require
log-in on User level 3 or higher.)
If the list is "full" click Next to see the next list and Prev to see
previous list.
4.4.5 Faults
In case of one or more faults (Value > 0), click Faults or Fault List
(yellow font colour) or List to view the Fault list view.
See chapter "Fault List", page 17.
4.4.6 Disablements
In case of one or more disablements (Value > 0), click Disablement
(yellow font colour) or List to view the Disablement –Summary
view.
See chapter "Disablement", page 17.
4.4.7 Interlockings
In case of one or more activated interlocking input / output (Value >
0), click List to view the Activated Interlocking Comb. view.

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
16
4.4.8 Service signals
Like menu H4/U6 and menu H8/S4 respectively.
In case of one or more detectors having activated service signal
(Value > 0), click List to see the Status –Service List view.
Click Acknowledge (require login on User level 4) to acknowledge
the service signal for the detector respectively.
4.4.9 Doors Opened
Like menu H4/U3.
In case of one or more open doors (Value > 0), click List to see the
Status –Doors Opened view / list.
4.4.10 Zones in Test
Test mode, see chapter "Zone Test", page 30.
In case of one or more test mode alarms (Value > 0), click List to see
the Test mode Alarm view / list.
The Time (date & time), Zone –Address and Text (alarm text) are
displayed.
Source = Smoke, Heat, Multi, MCP, Exting. system or Other.
Info: A hyperlink to open a document, a drawing etc. for more
information regarding the alarm point.
Camera: A hyperlink to a web camera.
Click Send Mail to send an e-mail. (E-mail addresses are
programmed via the Config tool.)
Click Clear to clear the list.
Acknowledge
001-01

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
17
4.5 Fault List
In case of one or more faults (Value > 0), click Fault List (yellow
font colour) or Faults (in the Status –Summary view) to view the
Fault List view.
The Time (date & time), Zone –Address (when applicable), Text
(fault message) and Status (Serviced / Acknowledged / Not Serviced
and not Acknowledged) are displayed.
Info: A hyperlink to open a document, a drawing etc. for more
information regarding the fault.
Camera: A hyperlink to a web camera.
Click Ack to acknowledge the selected fault(s). (Require log-in on
User level 2 or higher.)
If the list is "full" click Next to see the next list and Prev to see
previous list.
4.6 Disablement
In case of one or more disablements (Value > 0), click Disablement
(yellow font colour) or (in the Status –Summary view) to see the
Disablement –Summary view:
The different Items (types) and Values (number of disablements for
the type respectively) are shown.
Value > 0 indicates disablement(s). Click the List button respectively
to see the disablement, including additional information.

Panasonic Electric Works Nordic AB
MEW01228 Rev: 1 Operating Instructions Web512 V2.6.x for Web-server II 1598
18
4.6.1 Zone Address.
Click List to view the Disablement list –Zone Address view / list.
The Time (date & time), Zone –Address, Re-enable time and
Reason (e.g. via the menu) are displayed.
Info: A hyperlink to open a document, a drawing etc. for more
information regarding the fault.
Camera: A hyperlink to a web camera.
Click ReEnable to re-enable the disablement respectively. (Require
log-in on User level 2 or higher.)
If the list is "full" click Next to see the next list and Prev to see
previous list.
Click Summary to return to the Disablement –Summary view.
4.6.2 Zone
Click List to view the Disablement list –Zone view / list.
Click ReEnable to re-enable the disablement respectively. (Require
log-in on User level 2 or higher.)
If the list is "full" click Next to see the next list and Prev to see
previous list.
Click Summary to return to the Disablement –Summary view.
4.6.3 Device type
Click List to view the Disablement list –Device Type view / list.
Click ReEnable to re-enable the disablement respectively. (Require
log-in on User level 2 or higher.)
If the list is "full" click Next to see the next list and Prev to see
previous list.
Click Summary to return to the Disablement –Summary view.
4.6.4 Inter. Output (Interlocking Output.)
Click List to view the Disablement list –Interlocking view / list.
