Configuration Guide for Panasonic KX-NS1000
1 | P a g e XO Communications Confidential
Panasonic KX-NS1000 V.4.2
Configuration Guide

Configuration Guide for Panasonic KX-NS1000
2 | P a g e XO Communications Confidential
Table of Contents
1Introduction....................................................................................................3
2Executive Summary.......................................................................................4
3Software and Hardware Equipment Requirements for Testing......................5
4Test Configurations........................................................................................6
4.1 Lab Configuration 6
5Panasonic Configuration................................................................................7

Configuration Guide for Panasonic KX-NS1000
3 | P a g e XO Communications Confidential
1 Introduction
This document contains the test results of the SIP Trunking used to certify Panasonic IP
PBX. This test verified the basic interoperability, features of the appliance, and the
integration of the architecture framework. This certification test plan is to be executed
in XO’s Plano Certification Laboratory (Plano Lab) which is equipped with different test
equipments and is capable to simulate XO’s VoIP network environment.

Configuration Guide for Panasonic KX-NS1000
4 | P a g e XO Communications Confidential
2 Executive Summary
This report provides the test results found to date for the Panasonic IP PBX SIP Trunking
evaluation. The following is a summary addressed the issues and limitation found while
performing the test.
“Diversion” header is not working properly so that the Call Forward originated
from PSTN and forwarded back to another PSTN number, the 3rd party can only
see the 2nd party calling ID instead of the 1st party.
Call Transfer with or without REFER works fine. But the Blind Call Transfer with
REFER works but has to use a specific dialing :
When the 1st party is talking to the 2nd party, the 2nd party must do the following
to make Blind Transfer working - <press Transfer Key>, <press *61 when hearing
dial tone>, <press a PSTN number>, <press #>.
Due to no analog port in the machine under test, fax and analog calls are not
tested.
Registration Method
Static registration is utilized between the Panasonic IP phones and the XO call agent.
XO SIP Service Packages Supported
Pkg
Codec
DTMF
Fax
1
G.711
RFC 2833 / in-band DTMF
T.38 / G.711 pass-through
2
G.729a/G.711
RFC 2833 / in-band DTMF
T.38 / G.711 pass-through

Configuration Guide for Panasonic KX-NS1000
5 | P a g e XO Communications Confidential
3 Software and Hardware Equipment Requirements for Testing
1. Panasonic KX-NS1000
Software version : 4.2
2. 2 Panasonic IP Phones
Model no.: KX-NT 551, KX-NT 556

Configuration Guide for Panasonic KX-NS1000
6 | P a g e XO Communications Confidential
4 Test Configurations
4.1 Lab Configuration
The following diagram is the configuration used during lab testing.
4693873331
IP Phone –192.168.0.20
Panasonic
Signal
192.168.0.101
IAD FE 0/1
205.158.163.82
255.255.255.248
XO Network
4693873330
IP phone [phone]
XO Lab Setup for
Panasonic IPPBx Testing
Media
192.168.0.102
192.168.0.199
207.155.151.90
Note: Above lab setup only shows main lab network elements. Above setup shows NAT
configuration is required on XO router (IAD) when IPPBX and IP phones have private IPs.
For detail, please refer to the attachment of IAD configuration.

Configuration Guide for Panasonic KX-NS1000
7 | P a g e XO Communications Confidential
5 Panasonic Configuration
Main screen

Configuration Guide for Panasonic KX-NS1000
8 | P a g e XO Communications Confidential
Virtual slot

Configuration Guide for Panasonic KX-NS1000
9 | P a g e XO Communications Confidential
Virtual Port - (Virtual SIP Gateway –Shelf Property)
*Make sure SIP Client port number should be 5060.

Configuration Guide for Panasonic KX-NS1000
10 | P a g e XO Communications Confidential
IP Address for Signaling IP Address of IPPBX - (NAT) internal:
192.168.0.101, external: 207.155.151.90
IP Address for Media IP Address of IPPBX –192.168.0.102
Default Gateway -> IP Address of XO Router (IAD) –192.168.0.1

Configuration Guide for Panasonic KX-NS1000
11 | P a g e XO Communications Confidential
VOIP port setting –Main
IP Address -> XO NBS IP Address

Configuration Guide for Panasonic KX-NS1000
12 | P a g e XO Communications Confidential
VOIP port setting - Account

Configuration Guide for Panasonic KX-NS1000
13 | P a g e XO Communications Confidential
VOIP port setting –Registration (Disable –due to static SIP)

Configuration Guide for Panasonic KX-NS1000
14 | P a g e XO Communications Confidential
VOIP port setting - Option

Configuration Guide for Panasonic KX-NS1000
15 | P a g e XO Communications Confidential
VOIP port setting - Calling party

Configuration Guide for Panasonic KX-NS1000
16 | P a g e XO Communications Confidential
VOIP port setting - RTP/RTCP (DSCP bit configuration)

Configuration Guide for Panasonic KX-NS1000
17 | P a g e XO Communications Confidential
VOIP port setting - Codec settings:

Configuration Guide for Panasonic KX-NS1000
18 | P a g e XO Communications Confidential
VOIP port setting - Codec settings (continue): (shows Fax /
DTMF configuration)

Configuration Guide for Panasonic KX-NS1000
19 | P a g e XO Communications Confidential
VOIP port setting - “Supplementary Service” – CNIP (receive) –‘Yes’
to display inbound CNAM; Blind/Attended Transfer (REFER) is
enabled.

Configuration Guide for Panasonic KX-NS1000
20 | P a g e XO Communications Confidential
Trunk settings:
