Panasonic SC-HC402 User manual

Model number suffix “EB” denotes UK model.
TQBJ0987-1
EG
EB
GN
2017/02/06
Operating Instructions
Compact Stereo System
Model No. SC-HC402
SC-HC400
Thank you for purchasing this product.
Please read these instructions carefully before using this product,
and save this manual for future use.
Included Installation Instructions (l2, 3 and 20, 21)
The installation work should be done by a qualified installation specialist.
Before commencing work, carefully read these installation instructions and the operating
instructions to ensure that installation is performed correctly.
(Please keep these instructions. You may need them when maintaining or moving this unit.)
SC-HC400_402-EGEBGN~TQBJ0987.book 1 ページ ２０１７年３月１６日 木曜日 午後７時５２分

2
TQBJ0987
Caution for AC Mains Lead
(For the AC mains plug of three pins)
For your safety, please read the following text carefully.
This appliance is supplied with a moulded three pin
mains plug for your safety and convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please ensure
that the replacement fuse has a rating of 5-ampere and
that it is approved by ASTA or BSI to BS1362.
Check for the ASTA mark Ï or the BSI mark Ì on the
body of the fuse.
If the plug contains a removable fuse cover you must
ensure that it is refitted when the fuse is replaced.
If you lose the fuse cover the plug must not be used
until a replacement cover is obtained.
A replacement fuse cover can be purchased from your
local dealer.
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differ according to the type of
AC mains plug (figures A and B). Confirm the AC
mains plug fitted and follow the instructions below.
Illustrations may differ from actual AC mains plug.
1. Open the fuse cover with a screwdriver.
2. Replace the fuse and close or attach the fuse
cover.
Safety precautions
Unit
≥To reduce the risk of fire, electric shock or product damage,
– Do not expose this unit to rain, moisture, dripping or
splashing.
– Do not place objects filled with liquids, such as vases, on
this unit.
– Use only the recommended accessories.
– Do not remove covers.
– Do not repair this unit by yourself. Refer servicing to
qualified service personnel.
– Do not let metal objects fall inside this unit.
– Do not place heavy items on this unit.
AC mains lead
≥To reduce the risk of fire, electric shock or product damage,
– Ensure that the power supply voltage corresponds to the
voltage printed on this unit.
– Insert the mains plug fully into the socket outlet.
– Do not pull, bend, or place heavy items on the lead.
– Do not handle the plug with wet hands.
– Hold onto the mains plug body when disconnecting the
plug.
– Do not use a damaged mains plug or socket outlet.
≥The mains plug is the disconnecting device.
Install this unit so that the mains plug can be unplugged from
the socket outlet immediately.
Unit
≥This unit utilizes a laser. Use of controls or adjustments or
performance of procedures other than those specified herein
may result in hazardous radiation exposure.
≥Do not place sources of naked flames, such as lighted
candles, on this unit.
≥This unit may receive radio interference caused by mobile
telephones during use. If such interference occurs, please
increase separation between this unit and the mobile
telephone.
≥This unit is intended for use in moderate climates.
Placement
≥Place this unit on an even surface.
≥To reduce the risk of fire, electric shock or product damage,
– Do not install or place this unit in a bookcase, built-in
cabinet or in another confined space. Ensure this unit is
well ventilated.
– Do not obstruct this unit’s ventilation openings with
newspapers, tablecloths, curtains, and similar items.
– Do not expose this unit to direct sunlight, high
temperatures, high humidity, and excessive vibration.
Figure A Figure B
Fuse cover
Figure A
Fuse
(5 ampere)
Figure B
Fuse
(5 ampere)
WARNING
CAUTION
SC-HC400_402-EGEBGN~TQBJ0987.book 2 ページ ２０１７年３月１６日 木曜日 午後７時５２分

3
TQBJ0987
Battery
≥Danger of explosion if battery is incorrectly replaced.
Replace only with the type recommended by the
manufacturer.
≥Mishandling of batteries can cause electrolyte leakage and
may cause a fire.
– Remove the battery if you do not intend to use the remote
control for a long period of time. Store in a cool, dark
place.
– Do not heat or expose to flame.
– Do not leave the battery(ies) in a car exposed to direct
sunlight for a long period of time with doors and windows
closed.
– Do not take apart or short circuit.
– Do not recharge alkaline or manganese batteries.
– Do not use batteries if the covering has been peeled off.
≥When disposing of the batteries, please contact your local
authorities or dealer and ask for the correct method of
disposal.
Table of contents
Caution for AC Mains Lead.............................. 2
Safety precautions............................................ 2
Accessories....................................................... 3
Control reference guide ................................... 4
Using the remote control ................................. 5
Connections ...................................................... 6
Inserting media .................................................7
Bluetooth® operations ...................................... 8
About Bluetooth®.............................................. 9
Media playback controls .................................. 9
[HC402] Listening to DAB/DAB+ ....................... 11
Listening to FM/AM radio............................... 13
Sound adjustment .......................................... 14
Clock and Timer.............................................. 14
Others .............................................................. 15
Troubleshooting.............................................. 16
Unit and media care........................................ 18
Playable media................................................ 18
Specifications..................................................19
Attaching the unit to a wall (optional)........... 20
Licenses .......................................................... 22
Limited Warranty (ONLY FOR AUSTRALIA)...... 25
Accessories
Check the supplied accessories before using this unit.
The symbols on this product (including the
accessories) represent the following:
AC
DC
Class II equipment (The construction of the
product is double-insulated.)
IOn
ÍStandby
About descriptions in these operating instructions
≥Pages to be referred to are indicated as “l±±”.
≥Unless otherwise indicated, operations are described using
the remote control. You can also use the controls on this
unit if they are the same.
≥These operating instructions are applicable to models
SC-HC402 and SC-HC400 for a variety of regions. Unless
otherwise indicated, illustrations in these operating
instructions are of SC-HC402 for the Continental Europe.
≥[HC402] :indicates features applicable to SC-HC402 only.
≥[HC400] :indicates features applicable to SC-HC400 only.
∏1 Remote control
(N2QAYB001139)
∏1 Battery for remote control
∏
(For the United Kingdom and Ireland )
1 AC mains lead
(For the black model: K2CT2YY00127)
(For the silver model: K2CT2YY00126)
∏(For Continental Europe)
1 AC mains lead
(For the black model: K2CQ2YY00153)
(For the silver model: K2CQ2YY00154)
(For the white model: K2CQ2YY00154)
(For the blue model: K2CQ2YY00153)
∏(For Australia and New Zealand)
1 AC mains lead
(K2CJ2YY00117)
∏([HC402])
1 DAB indoor antenna
(N1CYYYY00022)
∏([HC400])
1 FM indoor antenna
(RSAX0002)
∏([HC400])
(Australia and New Zealand only)
1 AM loop antenna
(N1DYYYY00011)
Wall mounting accessories
∏1 Safety holder
(TPBDA004)
∏2 Wall mount brackets
(RSC1262-1)
∏1 Wall mounting sheet
≥ Use this sheet for wall mounting. ( l 20)

≥Do not use AC mains lead with other equipment.
≥ Product numbers provided in these operating instructions are
correct as of December 2016. These may be subject to change.
SC-HC400_402-EGEBGN~TQBJ0987.book 3 ページ ２０１７年３月１６日 木曜日 午後７時５２分

4
TQBJ0987
Control reference guide
1USB port (l7)
2AUX IN jack (l6)
3Standby/on switch (Í/I)
Press to switch the unit from on to standby mode or vice
versa. In standby mode, the unit is still consuming a small
amount of power.
4Select the audio source
On this unit:
≥Press and hold to enter pairing mode (l8) or
disconnect a Bluetooth® device (l8).
On the remote control:
[ ]: “BLUETOOTH”
[CD/USB]: “CD” ,. “USB”
5Basic playback control buttons
6Adjust the volume (0 (min) to 50 (max))
7FAVOURITE buttons for storing or selecting radio
station ([1] to [5]) (l11, 13)
8Set wall mount mode
9Select D.BASS
10 Adjust surround
11 Open or close the sliding door
12 Display
13 Sliding door
14 Remote control signal sensor
Distance: Within approx. 7 m directly in front
Angle: Approx. 30o left and right
15 Speakers
These speakers do not have magnetic shielding. Do not
place them near a TV, personal computer or other
magnetic devices.
*Only available for Australia and New Zealand
13
12 14
15
53 64
12
78910 11
Top view
“CD” -. “DAB+” ([HC402]) -. “FM” -. “AM” ([HC400]) *
:;
“BLUETOOTH” (----------- “USB” (----------- “AUX”
[RADIO, EXT-IN]: “DAB+” ([HC402]) -"-. “FM”
:;
“AUX” ( -------- “AM” ([HC400])*
SC-HC400_402-EGEBGN~TQBJ0987.book 4 ページ ２０１７年３月１６日 木曜日 午後７時５２分

5
TQBJ0987
16 Turn the unit on or off
17 Select number
≥To select a 2-digit number
Example: 16: [S10] > [1] > [6]
≥To select a 3-digit number
Example: 124: [S10] > [S10] >[1] > [2]> [4]
18 Delete a programmed track
19 Enter sound menu
20 Set the play menu item
21 Change the displayed information
22 Clock and timer operation
23 Set the programme function
24 Mute the sound
Press again to cancel. “MUTE” is also cancelled when the
volume is adjusted or the unit is turned off.
25 Select preset EQ
26 Enter setup menu
27 Set the radio menu item
28 Selection/OK
29 Dim the display panel and indicator
Press again to cancel.
Using the remote control
Insert the battery so the terminals (i and j) match
those in the remote control.
Point it at the remote control signal sensor on this unit.
≥To avoid interference, please do not put any objects in front
of signal sensor.
EXT-IN
16
17
18
4
5
9
20
19
21
22
23
6
24
26
27
25
28
29
7
R6/LR6, AA
(Alkaline or manganese
battery)
SC-HC400_402-EGEBGN~TQBJ0987.book 5 ページ ２０１７年３月１６日 木曜日 午後７時５２分

6
TQBJ0987
Connections

≥Tape the antenna to a wall or column in a position with the least amount of interference.
≥If radio reception is poor, use an outdoor antenna (not supplied).
1Connect an external music device using an audio
cable (not supplied).
≥Plug type: ‰3.5 mm stereo
2Press [RADIO, EXT-IN] repeatedly to select “AUX”
and start playback on the connected device.
∫To select the sound input level of the
external device
1While in AUX mode, press [SOUND] repeatedly to
select “INPUT LEVEL”.
2Press [2,1] to select “NORMAL” or “HIGH” and
then press [OK].
≥The factory default is “NORMAL”.

≥To improve sound distortion when “HIGH” is selected, select “NORMAL”.
≥Switch the equalizer off or turn the volume of the external device down to reduce the input signal. High level of input signal will
distort the sound.
≥For details, refer to the operating instructions of the device.
Connect an external music device
1
2
Connect the antenna.
Be sure to tighten the nut fully.
To a mains socket
Connect the AC mains lead after all other
connections are completed.
This unit consumes a small amount of AC power
(l19) even when turned off.
≥In the interest of energy conservation, if you will not be using
this unit for an extended period of time, unplug it from the
mains socket.
≥Some settings will be lost after you disconnect the system.
You have to set them again.
DAB indoor antenna (supplied)
Adhesive tape (not supplied)
FM indoor antenna (supplied)
[HC402]
[HC400]
This unit can receive DAB/DAB+ and FM stations with the DAB antenna.
Adhesive tape (not supplied)
[HC400]
(Australia and New Zealand only)
Adhesive tape (not supplied)
FM indoor antenna (supplied) AM loop antenna
(supplied)
AC mains lead (supplied)
Audio cable
(not supplied)
SC-HC400_402-EGEBGN~TQBJ0987.book 6 ページ ２０１７年３月１６日 木曜日 午後７時５２分

7
TQBJ0987
Inserting media
∫Charging a device
Charging starts when a device (rated value: 5 V/1.5 A) is connected to the USB port of this unit.
1Turn the unit on.
2Connect a device.
{. Confirm from the screen of the connected device, etc. to
make sure charging has started.
≥A cable compatible with your device is required. Use the
cable that comes with your device.
≥Even if you connect a cable compatible with the USB port of
this unit, your device may not be charged. In that case, use
the charger that comes with the device.
≥Depending on your device, using other chargers may not
work. Check the operating instructions of your device before
use.
≥Do not connect a device with a rated value higher than 5 V/
1.5 A to this unit.
≥To check if charging is complete, look at the screen of the
connected device, etc.
≥Once fully charged, remove the USB cable from the USB
port.
≥After the device has started charging, you can turn the unit to
standby mode.
– When charging a depleted device, do not turn the unit to
standby mode until the device becomes operational.

≥Make sure that the unit does not fall when inserting or removing media.
≥When moving this unit, be sure to remove all media and turn this unit to standby mode.
≥Make sure to tilt the disc so as not to touch the sliding
door.
≥Do not open the sliding door manually.
The label side
∫Connecting a USB device
≥Insert the USB device directly. Do not use any USB extension cable.
≥Please disconnect the USB device if you finish using.
≥Before removing the USB device, select a source other than “USB”.
∫Inserting a CD
USB cable
(not supplied)
To the compatible device
SC-HC400_402-EGEBGN~TQBJ0987.book 7 ページ ２０１７年３月１６日 木曜日 午後７時５２分

8
TQBJ0987
Bluetooth®operations
You can listen to the sound from the Bluetooth® audio
device from this unit wirelessly.
≥Refer to the operating instructions of the Bluetooth®
device for details.
Preparation
≥Turn on the Bluetooth® feature of the device and
place the device near this unit.
∫Pairing with Bluetooth® devices
1Press [ ] to select “BLUETOOTH”.
≥If “PAIRING” is indicated on the display, go to step 3.
2Press [PLAY MENU] to select “PAIRING” and then
press [OK].
≥ Alternatively, press and hold [SELECTOR, s PAIRING]
on the unit.
3Select “SC-HC402” or “SC-HC400” from the
Bluetooth® device’s Bluetooth® menu.
≥The MAC address (e.g., 6C:5A:B5:B3:1D:0F) may be
displayed before “SC-HC402” or “SC-HC400” is
displayed.
≥The name of the connected device is indicated on the
display for a few seconds.
4Start playback on the Bluetooth® device.
∫Connecting a paired Bluetooth® device
1Press [ ] to select “BLUETOOTH”.
≥“READY” is indicated on the display.
2Select “SC-HC402” or “SC-HC400” from the
Bluetooth® device’s Bluetooth® menu.
≥The name of the connected device is indicated on the
display for a few seconds.
3Start playback on the Bluetooth® device.

≥If prompted for the passkey, input “0000”.
≥You can register up to 8 devices with this unit. If a 9th device
is paired, the device that has not been used the longest will
be replaced.
≥This unit can only be connected to one device at a time.
≥When “BLUETOOTH” is selected as the source, this unit will
automatically try and connect to the last connected
Bluetooth® device. (“LINKING” is indicated on the display
during this process.) If the connection attempt fails, try to
establish a connection again.
You can change the transmission mode to prioritise
transmission quality or sound quality.
Preparation
≥Press [ ] to select “BLUETOOTH”.
≥If a Bluetooth® device is already connected,
disconnect it.
1Press [PLAY MENU] repeatedly to select
“LINK MODE”.
2Press [2,1] to select the mode and then press
[OK].
MODE 1: Emphasis on connectivity
MODE 2: Emphasis on sound quality

≥Select “MODE 1” if the sound is interrupted.
≥When enjoying video contents with this function, the video
and audio output may not be synchronised. In this case,
select “MODE 1”.
≥The factory default is “MODE 2”.
If the sound input level from the Bluetooth® device is
too low, change the input level setting.
Preparation
≥Connect a Bluetooth® device.
1Press [PLAY MENU] repeatedly to select “INPUT
LEVEL”.
2Press [2,1] to select the level and then press
[OK].
“LEVEL 0” ,. “LEVEL i1” ,. “LEVEL i2”
^--------------------------------------------------J

≥Select “LEVEL 0” if the sound is distorted.
≥The factory default is “LEVEL 0”.
1While a Bluetooth® device is connected:
Press [PLAY MENU] repeatedly to select
“DISCONNECT?”.
2Press [2,1] to select “OK? YES” and then press
[OK].

≥You can also disconnect the Bluetooth® device by pressing
and holding [SELECTOR, sPAIRING] on the unit.
≥The Bluetooth® device will be disconnected if a different
audio source (e.g., “CD”) is selected.
Connecting via Bluetooth® menu
Bluetooth® transmission mode
Bluetooth® input level
Disconnecting a Bluetooth® device
SC-HC400_402-EGEBGN~TQBJ0987.book 8 ページ ２０１７年３月１６日 木曜日 午後７時５２分

9
TQBJ0987
About Bluetooth®
∫Frequency band used
≥This system uses the 2.4 GHz frequency band.
∫Certification of this device
≥This system conforms to frequency restrictions and
has received certification based on frequency laws.
Thus, a wireless permit is not necessary.
≥The actions below are punishable by law in some
countries:
– Taking apart or modifying the system.
– Removing specification indications.
∫Restrictions of use
≥Wireless transmission and/or usage with all
Bluetooth® equipped devices is not guaranteed.
≥All devices must conform to standards set by
Bluetooth SIG, Inc.
≥Depending on the specifications and settings of a
device, it can fail to connect or some operations can
be different.
≥This system supports Bluetooth® security features.
But depending on the operating environment and/or
settings, this security is possibly not sufficient.
Transmit data wirelessly to this system with caution.
≥This system cannot transmit data to a Bluetooth®
device.
∫Range of use
≥Use this device at a maximum range of 10 m. The
range can decrease depending on the environment,
obstacles or interference.
∫Interference from other devices
≥This system may not function properly and troubles
such as noise and sound jumps may arise due to
radio wave interference if this system is located too
close to other Bluetooth® devices or the devices that
use the 2.4 GHz band.
≥This system may not function properly if radio waves
from a nearby broadcasting station, etc. is too
strong.
∫Intended usage
≥This system is for normal, general use only.
≥Do not use this system near an equipment or in an
environment that is sensitive to radio frequency
interference (example: airports, hospitals,
laboratories, etc).
Media playback controls
The following marks indicate the availability of the
feature.
Preparation
≥Turn the unit on.
≥Insert the media or connect the Bluetooth®
compatible device. (l7, 8)
1Select the audio source.
For disc:
Press [CD/USB] repeatedly to select “CD”.
For USB device:
Press [CD/USB] repeatedly to select “USB”.
For Bluetooth® device:
Press [ ] to select “BLUETOOTH”.
(When selecting using this unit, press
[SELECTOR, sPAIRING].)
2Press [1/;] to start playback.
Basic controls
∫To display information
([CD], [USB], [BLUETOOTH])
You can display the track, artist, album name, file type,
bit rate, and other information. (The information varies
depending on the audio source.)
Press [DISPLAY] repeatedly.
e.g. [USB] (MP3)
Panasonic bears no responsibility for data and/or
information that is compromised during a
wireless transmission. [CD]: CD audio in CD-DA format or a CD that
contains MP3 files (l18)
[USB]: USB devices containing MP3 file (l18)
[BLUETOOTH]: Connected Bluetooth® device (l8)
Basic play
([CD], [USB], [BLUETOOTH])
Stop Press [∫].
≥[USB]: The position is memorised and
“RESUME” is displayed.
≥[USB]: Press [∫] twice to stop the
playback fully.
Pause Press [1/;].
Press again to continue playback.
Skip Press [:] or [9] to skip track.
(This unit: [:/6] or [5/9])
[CD] (MP3), [USB]
Press [3] or [4] to skip the album.
Search During play or pause, press and hold
[6] or [5].
(This unit: [:/6] or [5/9])
“A”: MP3 album number.
“T”: MP3 track number.
(“  ” stands for a number.)
SC-HC400_402-EGEBGN~TQBJ0987.book 9 ページ ２０１７年３月１６日 木曜日 午後７時５２分

10
TQBJ0987

≥To use this unit’s remote control with a Bluetooth® device, the
Bluetooth® device must support AVRCP (Audio Video
Remote Control Profile).
Depending on the status of the device, some controls may
not work.
≥[CD], [USB]:Tracks can be selected by pressing the numeric
buttons.
≥Maximum number of displayable characters:
Approx. 32
≥This system supports ver. 1 and 2 ID3 tags.
≥Text data that is not supported will not be displayed or will be
shown differently.
Select the playback mode.
1Press [PLAY MENU] repeatedly to select
“PLAYMODE” or “REPEAT”.
2Press [2,1] to select the setting and then press
[OK].

≥During random playback, you cannot skip to tracks which
have been played or press the numeric buttons.
≥Playmode function does not work with “Programme play”.
≥The mode is cancelled when you open the sliding door or
remove the USB device.
This function allows you to programme up to 24 tracks.
[CD] (CD-DA)
1Press [PROGRAM] in the stop mode.
≥“PROGRAM” is shown for a few seconds.
2Press the numeric buttons to select the desired
track.
≥Do this step again to programme other tracks.
3Press [1/;] to start playback.
[CD] (MP3), [USB]
1Press [PROGRAM] in the stop mode.
≥“PROGRAM” is shown for a few seconds.
2Press [3,4] to select the desired album.
3Press [9] and then press the numeric buttons to
select the desired track.
4Press [OK].
≥Do steps 2 through 4 again to programme other tracks.
5Press [1/;] to start playback.

≥The programme memory is cleared when you open the
sliding door or remove the USB device.
Playback modes ([CD], [USB])
PLAYMODE
OFF
PLAYMODE
Cancels the play mode setting.
1-TRACK Only plays the selected track.
≥“1”, “ ” is displayed.
(Skip to the desired track.)
1-ALBUM Only plays the selected album.
≥Press [3] or [4] to select the album.
≥“1”, “ ” is displayed.
RANDOM Plays the contents randomly.
≥“RND” is displayed.
1-ALBUM
RANDOM
Plays the tracks in the selected
album randomly.
≥Press [3] or [4] to select the album.
≥“1”, “ ”, “RND” is displayed.
REPEAT
ON REPEAT Turns on repeat mode.
≥“`” is displayed.
OFF
REPEAT
Turns off repeat mode.
Programme play
([CD], [USB])
Check
programme
contents
Press [:] or [9] in the stop
mode.
Clear the last
track
Press [DEL] in the stop mode.
Cancel
programme
mode
Press [PROGRAM] in the stop mode.
≥“PGM OFF” is shown for a few seconds.
Clear all
programmed
tracks
Press [ ∫ ] in the stop mode. “CLEAR
ALL” is shown. Within 5 seconds, press
[ ∫ ] again.
SC-HC400_402-EGEBGN~TQBJ0987.book 10 ページ ２０１７年３月１６日 木曜日 午後７時５２分
