Panasonic ZEQUO 5410DL User manual

 Thank you for purchasing our product.
 This manual provides important information about safe and proper
operations of this Ethernet Switch.
 Please read the "Important Safety Instructions" on pages 3 to 5.
 Any problems or damages resulting from disassembly of this Ethernet Switch
by customers are not covered by the warranty.
C0917-20122
ZEQUO 5410DL
Model No.
Installation Guide
Printed in Japan
PN88162C-TH
PN88162C-MY
PN88162C-ID
PN88162C-SG
2-12-7, Higashi-Shimbashi, Minato-ku, Tokyo Japan, 105-0021
©
Panasonic Electric Works Networks Co.,Ltd.
Panasonic Electric Works Networks Co.,Ltd. 2022
 The instruction manuals (CLI Version), latest firmware and
SDN application (ZEQUO assist Plus) can be downloaded
from the following URL.
https://panasonic.co.jp/ew/pewnw/english/datadownload/index.html

Contents
2
Important Safety Instructions
Basic Instructions for the Use of This Product
1. Product Outline
1.1 Features
1.2 Specifications
1.3 Accessories
1.4 Basic operation
2. Part Names and Functions
3. Installation and Configuration
3.1 Using 10GBASE-T
3.2 Installing on level shelves
3
6
7
7
8
9
9
10
12
12
12
3.3 Mounting to rack
3.4 Configuration of IP address (Basic)
Troubleshooting
12
13
15

3
This chapter contains important safety instructions for preventing bodily injury
and/or property damage. Please read carefully, and follow them at all times.
Do not use power supply other than AC 100 - 240 V.
Deviation could lead to fire, electric shock, and/or equipment failure.

Do not handle this Ethernet Switch and connection cables during a thunderstorm.
Deviation could lead to electric shock.
Do not disassemble and/or modify this Ethernet Switch.
Deviation could lead to fire, electric shock, and/or equipment failure.
Do not damage the power cord. Do not bend too tightly, stretch, twist, bundle
Do not unplug nor plug in the power plug with wet hands.
Deviation could lead to electrical shock, and/or equipment failure.
Do not insert or drop any foreign objects such as metal or readily combustible
things into Ethernet Switch through the openings.
Deviation could lead to fire, electrical shock, and/or equipment failure.
Do not store or use the Ethernet Switch in places where it might get splashed
with liquids such as water, in places with a lot of humidity, in places with
conductive dust, or in places where there are corrosive and combustible gases.
Deviation could lead to fire, electrical shock, and/or equipment failure.
Do not use the Ethernet Switch in dusty environments such as on floors,
underneath floors, the backside of ceilings, or boards.
Do not use the Ethernet Switch in very dusty areas such as on floors, underneath
floors, the backside of ceilings, or boards. Deviation could lead to fire, electrical shock,
and/or equipment failure. It is recommended that the Ethernet Switch be operated in
environments such as the inside of racks where it is difficult for dust to be generated.
Do not store or use the Ethernet Switch in places where it will be exposed to
direct sunlight or high temperatures.
The temperature inside will rise, which may cause fire.
with other cord, pinch, put under a heavy object and/or heat it.
Damaged power cord could lead to fire, short, and/or electric shock.





This symbol indicates a potential hazard
that could result in serious injury or death.
 Severity of bodily injury and/or property damage, which could result from incorrect
use of the Ethernet Switch, are explained below.

The following symbols are used to classify and describe the type of instructions to be observed.
Important Safety Instructions
WARNING
CAUTION This symbol indicates safety instructions.
Deviation from these instructions could lead
to bodily injury and/or property damage.
This symbol is used to alert
users what they must do.
This symbol is used to alert
users what they must not do.
WARNING
Do not store or use the Ethernet Switch in places where there are lots of
vibrations and impacts, or in unstable areas.
It might fall, which may cause injuries and/or equipment failure.

Do not put the Ethernet Switch into fire.
Deviation could lead to explosion and/or fire.

4
Use the bundled power cord (AC 100 – 240 V specifications).
Deviation could lead to electric shock, malfunction, and/or equipment failure.
Unplug the power cord in case of equipment failure.
Deviation, such as keep connecting for a long time, could lead to fire.
Connect the power cord firmly to the power port.
Deviation could lead to electric fire, shock, and/or malfunction.
If the STATUS LED is blinking in orange (systemtfault), check for the cause
via the system log, since it might be a malfunction if it is not the temperature,
loop detection and shutoff, unplug the power plug.
Deviation, such as keep connecting for a long time, could lead to fire.






Handle the Ethernet Switch carefully to prevent fingers and hands from being
damaged by twisted pair port, SFP extension slot, stacking port, console port,
SD card slot, or power cord hook block.

Check whether the optical fiber cable connectors are contaminated with dust, etc.
This might cause the optical signal to not be transmitted normally, and cause
misoperations and malfunctions. If they are contaminated, make sure to clean
them off, then connect them to the optical fiber ports.
CAUTION
Do not connect any other devices except for 100BASE-TX/1000BASE-T/10GBASE-T
devices to the twisted pair ports.
Deviation could lead to equipment failure.
Do not insert any other modules except for our optional SFP module
(PN54021K/PN54023K) and the SFP+ module (PN59021/PN59023) to the SFP+
extension slots.
Do not insert any other modules except for our optional SFP module
(PN54021K/PN54023K), SFP+ module (PN59021/PN59023), or SFP+ direct-attach
cable (OPSFPP-T01/OPSFPP-T05) to the stacking ports (Port15-16).
Check out our website for the latest information on supported SFP modules.
Do not connect the console ports with any other console cables except for
our
optional
PN72001 RJ45-DSub 9-pin console cable.
Deviation could lead to fire, electrical shock, and/or equipment failure.
Be sure to connect the ground cable.
Otherwise this might cause electrical shocks, misoperations and malfunctions.
Connect the Ethernet Switch via the supplied power cord to the outlet which is
connected to the ground.
If the outlet is not connected to a ground, connect the ground cable to the ground
terminal screw.
When connecting 10GBASE-T (IEEE 802.3an) supported devices to this device,
use Cat6 or above cables.
If any other cables except for the aforementioned are used, malfunctions might be
caused.





CAUTION
When using this Ethernet Switch to design systems, use it after applying
appropriate measures such as setting up redundant configurations.
Communication failures might be generated due to causes such as malfunctions or
misoperations while the Ethernet Switch is being used.
When using this Ethernet Switch for applications which require extremely high
reliability, be careful to expend all possible means to ensure safety and
reliability.
This Ethernet Switch is not designed nor manufactured with the intention that it be
used for applications (in use with railways, aviation, and medical care, etc. where
the influence rate due to communication failures is extremely high in regard to
systems that directly affect systems and human lives) which require extremely high
reliability.
It is recommended that this Ethernet Switch be replaced about five years after
it has been installed.
This may vary depending upon conditions such as utilisation rates and usage
environments, but performance might decrease due to the age-related degradation,
etc. of components.
Be careful in regards to environmental restrictions whereby the Ethernet Switch
can be used.
Please isolate the business power lines and communication lines. Isolate distribution
lines and other distribution lines, and low current power lines, optical fiber cables,
metallic water conduits, and gas conduits, etc. Noise may be generated in the
communication lines which might cause communication glitches.
5
This Ethernet Switch is to be periodically serviced in order to maintain its
performance.
Please assign a product administrator, and be sure to implement
periodic maintenance. When doing maintenance, check the inspection chart that is
posted on our website which has the requisite items listed on it.

Basic Instructions for the Use of This Product
For inspection and/or repair, consult the shop.
Use commercial power supply from a wall socket, which is close and easily accessible to
this Ethernet Switch.
Unplug the power cord when installing or moving this Ethernet Switch.
Unplug the power cord when cleaning this Ethernet Switch.
Use this Ethernet Switch within the specifications. Deviation could lead to malfunction.
Do not touch the metal terminal of the RJ45 connector, the modular plug of connected
twisted pair cable, or the metal terminal of the SFP extension slot. Do not place charged
objects in the proximity of them. Static electricity could lead to equipment failure.
Do not put the modular plug of the connected twisted pair cable on objects that can
carry static charge, such as carpet. Do not place it in the proximity. Static electricity could
lead to equipment failure.
Do not put a strong shock, including dropping, to this Ethernet Switch. Deviation could
lead to equipment failure.

Before connecting a console cable to the console port, discharge static electricity, for
example by touching metal appliance (do not discharge by touching this Ethernet Switch).
Do not store and/or use this Ethernet Switch in the environment with the characteristics
listed below. (Store and/or use this Ethernet Switch in the environment in accordance
with the specification.)
- High humidity. Possible spilled liquid (water).
- Dusty. Possible static charge (such as carpet).
- Under direct sunlight.
- Possible condensation. High/low temperature exceeding the specifications
environment.
- Strong vibration and/or strong shock.
Please use this Ethernet Switch in place where ambient temperature is from 0 to 50°C.
Failure to meet the above conditions may result in fire, electric shock, breakdown,
When connecting the stacks, be sure to use firmware versions that are identical for all
of the devices.
Please note that operations are not guaranteed if the firmware versions are different.
Select the appropriate cables and lay them.
Communications might be affected by how the cables are laid, and environmental noise.
and/or malfunction. Please beware because such cases are out of guarantee.
Additionally, do not cover the bent hole of this Ethernet Switch.
Deviation could lead to high internal temperature, equipment failure and/or
malfunction.
When stacking Ethernet Switches, leave a minimum of 20 mm space between them.
1. Please note that Panasonic shall not bear any liability whatsoever for any damages
(this shall include, but isnotlimited to,lost earnings,lost opportunities, etc.)
which were generated in relation to damages caused by operations and usage,
or the inability to use this Ethernet Switch, whereby the customer does not follow
this Installation Guide.
2. The contents described in this document may be changed without prior notice.
3. For any question, please contact the retailer where you purchased the product.
6

Product Outline
ZEQUO 5410DL is a Layer 3 Ethernet Switch with management function having
100BASE-TX/1000BASE-T/10GBASE-T ports and SFP+ extension slots.
1.1 Features
1
 Has wire-speed Layer 3 switching function.
 Ports 1 to 4 are 100BASE-TX/1000BASE-T/10GBASE-T ports corresponding to
autonegotiation.
Also their speed and communication mode can be switched by configuration.
 Ports 5 to 16 are SFP+ extension slots. They are capable of 10-Gbps
communications. They can be used as SFP or SFP+ ports.

 Settings and firmware can be changed and saved by using an SD card.
 All twisted pair ports support straight/cross cable auto sensing function. Simply
connect devices with straight cables, whether it is a terminal or a network device.
(This function does not work if the port communication configuration is set at Fixed
or Link Aggregation.)
The Ring Redundant Protocol (RRP) is supported, allowing to make a redundant net-work-
via ring topology.
If the stacking functions have been activated, ports 15 and 16 will be stacking ports.
By using the SFP+ modules and the optical fiber cables, or the SFP+ direct attach
cables, stacking connections are feasible for up to a maximum of two units whereas
the ZEQUO 5410DL are used.

Equipped with two power ports, power redundancy is feasible.
Normally operates even with just the AC power supplied to either one of the power
ports.


Equipped with energy efficient Ethernet (EEE) conforming to IEEE802.3az (LPI).
When there is no data transmission at link up, the energy-saving state automatically
starts so that power consumption can be reduced on each port.
Due to the loop detection/shutoff function, a port where loop has occurred can be
automatically shut off to prevent loop failures.

The ports which the loop has generated are displayed via the LED, and the network
administrator can specify the ports which the loop has generated after the loop is
resolved via the loop history functions.
7

1.2 Specifications
Interface Twisted pair port 1–4: RJ45 connector
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3an 10GBASE-T
SFP+ extension slot 5-16
IEEE802.3z 1000BASE-SX/1000BASE-LX
IEEE802.3ae 10GBASE-SR/10GASE-LR
* Ports 15 and 16 can be used as stacking ports.
SD card slot: SD/SDHC, 128MB-32GB
Console port: RJ45 connector
Switching mode Store and Forward method: Forwarding rate
100BASE-TX: Max. 148,800 pps/port
1000BASE-T/SX/LX: Max. 1,488,000 pps/port
10GBASE-T/SR/LR: Max. 14,880,000 pps/port
MAC Address table: Max. 32K entry/unit
3M byte/unit:reffuB
Switching capability: 320Gbps
Layer 2 Features STP/RSTP/MSTP, Tag VLAN, MAC-based VLAN, Subnet-based VLAN,
Protocol-based VLAN, Dynamic VLAN, Guest VLAN,
Link Aggregation, SPAN, RSPAN,
Multicast (IGMP Snooping, MLD Snooping), QoS (PQ, WRR),
IEEE802.1X Port-based/MAC-based Authentication,
MAC Authentication, WEB Authentication,
Access control, Storm control, RRP
IPv4/v6 routing, IP forwarding,
Routing table size: Max. 7K (IPv4 + IPv6: 7K)
VRRP, RIP, IP filtering, DHCP relay
DHCP client, DHCP server,
DDM, Twisted pair cable diagnostics,
ZEQUO assist Plus, Console, TELNET,SSH,
SNMP (MIB II, RMON group 1,2,3,9), WEB
Layer 3 Features
Management
Power supply AC 100-240 V, 50/60 Hz, 1.7 A
When either power port 1, or power port 2 is connected
When both power port 1 and power port 2 are connected
*Power redundancy is feasible
Power consumption
Normally, Max. 44.6 W, Min. 21.4 W
Normally, Max. 47.2 W, Min. 24.5 W
Storage environment Temperature: -20–70°C, Humidity: 10–90% RH (no condensation)
Mass (Weight) 4,600 g
External dimensions 44 mm (Height) × 440 mm (Width) × 312 mm (Depth) (Excluding
protruding sections)
Operating environment Temperature: 0–50°C,Humidity: 20–80% RH (no condensation)
Fan Installed
8
Product Outline
1

1.3 Accessories
Installation Guide (this document) 1 (*)

Mounting bracket (for 19-inch rack) 2

Screw (for 19-inch rack) 4

Screw (for fixing the main unit and the mounting bracket) 8

Rubber foot 4
Dummy SD card 1
Power cord 2
* Just the PN88162C-TH has 1 Installation Guide in Thai (a total of 2 guides).
[Power Cord]
Please be sure to confirm the content.
The following power cords are supplied as per the intended nation of delivery.
The XXs are identical to the intended nation of delivery codes.
Please contact our distributor if any of the contents are insufficient. Quantity
SFP+ Direct attach cable (OPSFPPK-T01)

1
[Optional accessories]
PN54021K-XX 1000BASE-SX SFP Module
PN54023K-XX 1000BASE-LX SFP Module
PN59021-XX 10GBASE-SR SFP+ Module
PN59023-XX 10GBASE-LR SFP+ Module
9
Locale
Thailand 250 VAC 6 A TIS166-2549-
Indonesia 250 VAC 10 A
250 VAC 10 A
250 VAC 5 A
CEE7/7
BS1363
BS1363
-
13 A
5 A
Malaysia
Singapore
Product Number
PN88162C-TH
PN88162C-ID
PN88162C-MY
PN88162C-SG
250 VAC 10 A AS/NZS 3112-
Australia
New Zealand
PN88162C-NZ
Power Cord Rating FUSE Rated Current Plug Type
1.4 Basic operation
This Product does not have a power ON/OFF switch. Connect the supplied power
cord to this Ethernet Switch and connect the other end into an electric outlet.
This Ethernet Switch operates at AC 100 - 240 V (50/60 Hz).
The Ethernet Switch is equipped with1 or 2 power cords, so if the AC power supply is
normally supplied to the power ports, the corresponding POWER LEDs will light up
green, and the other LEDs will all light up.
Then, STATUS LED lights in orange, and self-diagnosis of hardware is executed.
On completion of self-diagnosis, STATUS LED light in green, and the Ethernet Switch
starts operation as a Ethernet Switch.
When this Ethernet Switch successfully communicates with a terminal connected to a
port, the Port LED lights up.
When the terminal is not operating normally, for example when power is not
supplied to the terminal, the Port LED does not light up.
* For configuration and management method, please see the PDF version
Operating Instructions on Panasonic’s website.

SD CARD SLOT
POWER1
STATUS
SD CARD
ZEQUO 5410DL
POWER2
STACK ID
1234
CONSOLE
9600.N.8.1(DTE) 1234 13 14 15 169 10 11 125 6 7 8
5 6 7 8 9 10 11 12 13 14 15 16
Part Names and Functions
2
100BASE-TX/1000BASE-T/10GBASE-T portSTACK ID LED
Console portSD card slot
Front panel
SFP+ extension slot
Stacking port
Power port 1 and Power port 2 (Power redundancy is feasible)
Connect the supplied power cord to this port and connect the other end into an
electric outlet.
Power cord hook block
If the supplied power cord is hanged to this block, the cord becomes hard to pull out
from the power port.
SD card slot
Insert an SD card into this slot to change/save settings and firmware.
100BASE-TX/1000BASE-T/10GBASE-T port (ports 1–4)
Devices such as 100BASE-TX/1000BASE-T/10GBASE-T terminal, hub, repeater, bridge,
and Ethernet Switch can be connected to this port.
Refer to page 12 about cable lengths when using 10GBASE-T.
When connecting via 100BASE-TX/1000BASE-T, install the Ethernet Switch so that the
twisted pair cable (CAT5e or above) lengths fall within 100 m or less.
SFP+ extension slot (ports 5-16)
An SFP or SFP+ module can be connected, and be supported only the full duplex
communication.
Stacking port (ports 15, 16)
Up to four units can be stacked by connecting optical fiber cables or SFP+ direct
attach cables.
Power port 1
(POWER1)
Power port 2
(POWER2)
MAC Address label Power cord hook block
Back panel
Serial number label Ground terminal
Ground terminal
Only qualified personnel should install minimum 18AWG green-and-yellow stranded
copper wire to Ground terminal screw.
10
(1) When connected to 1 power port
Even if just power port 1, or power port 2 (1 power cord) is connected, the device will
function normally, but there will not be power redundancy.
(2) When connected to 2 power ports
If both power port 1 and power port 2 (2 power cords) are connected, even if one of
them no longer supplies AC power, the device will not be restarted, and it will continue
to function on just the other AC power supply via the power redundancy functions.
