Panasonic KX-HNB600FX User manual

System Setup Guide
Home Network System
Hub
Model No. KX-HNB600FX
Thank you for purchasing a Panasonic product.
This document explains how to configure the hub and access it using a mobile
device. These steps must be followed before you can use the system.
For details about how to use the system, refer to the User’s Guide (page 16).
Please read this document before using the unit and save it for future reference.

Introduction
Accessory information ..................................3
Expanding the Panasonic Home Network
System .........................................................4
Important Information
About this system .........................................6
For your safety .............................................6
Important safety instructions ........................7
Security cautions ..........................................7
For best performance ...................................8
Other information .........................................8
Setup
Part names and functions ..........................10
LED indicator ..............................................10
Connections ...............................................11
Wi-Fi® settings ...........................................12
Registering another mobile device .............14
Registering other devices to the hub ..........15
Appendix
Wireless communication range (DECT) .....16
Accessing the User’s Guide .......................16
Wall mounting ............................................17
Specifications .............................................19
Open source software notice .....................19
Software information ..................................19
2
Table of Contents

Accessory information
Supplied accessories
No. Accessory item/Part number Quantity
AAC adaptor/PNLV236CE 1
BTelephone line cord 1
CWall mounting adaptor 1
A B C
Additional accessories
microSD card (not supplied)
A commercially-available microSD card must be inserted into the hub in order to record images
from cameras. The following types of microSD cards are supported.
RmicroSD / SDHC card: Up to 32 GB
Other information
RDesign and specifications are subject to change without notice.
RThe illustrations in these instructions may vary slightly from the actual product.
Trademarks
RmicroSDHC Logo is a trademark of SD-3C, LLC.
RiPhone and iPad are trademarks of Apple Inc., registered in the U.S. and other countries.
RiPad mini is a trademark of Apple Inc., registered in the U.S. and other countries.
RAndroid and Google Play are registered trademarks or trademarks of Google Inc.
RMicrosoft, Windows, and Internet Explorer are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries.
RWi-Fi, WPA, and WPA2 are registered trademarks or trademarks of Wi-Fi Alliance.
RAll other trademarks identified herein are the property of their respective owners.
Notice
RThe hub supports microSD and microSDHC memory cards. In this document, the term
“microSD card” is used as a generic term for any of the supported cards.
3
Introduction

Expanding the Panasonic Home Network System
The Panasonic Home Network System is a wireless system that lets you create a powerful
network of devices, such as cameras, sensors, and smart plugs, and control them all with an
easy-to-use app.
Compatible devices are explained below. For information about the Home Network app, refer to
the User’s Guide (page 16).
The maximum number of devices for each device type is listed below.
Digital Cordless Handset (KX-HNH100: 6 max.*1)
RMakes and receives calls using your home landline
RCan be used to change the system’s arm mode
RDisplays system status
RReceives notification when the sensors are triggered
Indoor Camera (KX-HNC200: 4 max.*2)
RFull-colour camera and built-in microphone for live monitoring
and recording
RBuilt-in visual sensor, audio sensor, and temperature sensor
can be used to trigger other actions (camera recording, turning
on a light, etc.)
RBuilt-in microphone and speaker for two-way communication
Outdoor Camera (KX-HNC600: 4 max.*2)
RFull-colour camera with built-in microphone for live monitoring
and recording
RBuilt-in visual sensor and infrared sensor can be used to trigger
other actions (camera recording, turning on a light, etc.)
RBuilt-in microphone and speaker for two-way communication
RSplash proof design for permanent, outdoor installation
Window/Door Sensor (KX-HNS101: 50 max.*2)
RDetects when the corresponding window or door is opened
RCan be used to trigger other events (camera recording, turning
on a light, etc.)
Motion Sensor (KX-HNS102: 50 max.*2)
RDetects motion in the surrounding area
RCan be used to trigger other events (camera recording, turning
on a light, etc.)
4
Introduction

Smart Plug (KX-HNA101: 50 max.*2)
RCan be turned on and off using the handset or Home Network
app, when triggered by a sensor, or according to a schedule
RBuilt-in overcurrent and overwattage detection for added peace
of mind
RPower consumption is logged for your reference
RSmart plug availability varies by region. Contact your Panasonic
dealer for more information.
RSmart plug appearance varies by region.
RModel shown is KX-HNA101FX.
*1 Optional handsets may be a different colour from that of the handset supplied as part of a
pre-configured bundle.
*2 A total of 6 cordless handsets, 4 cameras, and 50 other devices (motion sensors, window/
door sensors, smart plugs, etc.) can be registered to the hub.
The Home Network System product lineup is growing!
You can look forward to new devices that will make your Home Network System even more
useful and convenient.
For information about the latest devices and bundles, visit the website below.
Poland: www.panasonic.pl
Hungary: www.panasonic.com/hu
Czech: www.panasonic.com/cz
Slovakia: www.panasonic.com/sk
Croatia: www.panasonic.com/hr
Romania: www.panasonic.com/ro
Bulgaria: www.panasonic.com/bg
Macedonia: http://www.videodata.com.mk/
Other countries: www.panasonic.eu
Mobile devices
Your mobile devices: 8 max.*1
You can expand the system by installing the Home Network
app on your mobile devices (smartphones, tablets, etc.) and
registering your mobile devices to the hub.
See page 12 for more information about the Home Network
app.
Note:
RYou must configure the hub’s Wi-Fi settings before you can
use the app.
*1 8 mobile devices can be registered to the hub, however, only the first 4 can use phone
features.
5
Introduction

About this system
RThis system is an auxiliary system; it is not
designed to provide complete protection
from property loss. Panasonic will not be
held responsible in the event that property
loss occurs while this system is in operation.
RThe system’s wireless features are subject
to interference, therefore functionality in all
situations cannot be guaranteed.
Panasonic will not be held responsible for
injury or damage to property that occurs in
the event of wireless communication error
or failure.
For your safety
To prevent severe injury and loss of life/
property, read this section carefully before
using the product to ensure proper and safe
operation of your product.
WARNING
Power connection
RUse only the power source marked on the
product.
RDo not overload power outlets and
extension cords. This can result in the risk
of fire or electric shock.
RCompletely insert the AC adaptor/power
plug into the power outlet. Failure to do so
may cause electric shock and/or excessive
heat resulting in a fire.
RRegularly remove any dust, etc. from the
AC adaptor/power plug by pulling it from
the power outlet, then wiping with a dry
cloth. Accumulated dust may cause an
insulation defect from moisture, etc.
resulting in a fire.
RUnplug the product from power outlets if it
emits smoke, an abnormal smell, or makes
an unusual noise. These conditions can
cause fire or electric shock. Confirm that
smoke has stopped emitting and contact an
authorised service centre.
RUnplug from power outlets and never touch
the inside of the product if its casing has
been broken open. Danger of electric shock
exists.
RNever touch the plug with wet hands.
Danger of electric shock exists.
RDo not connect non-specified devices.
Installation
RTo prevent the risk of fire or electrical
shock, do not expose the product to rain or
any type of moisture.
RDo not place or use this product near
automatically controlled devices such as
automatic doors and fire alarms. Radio
waves emitted from this product may cause
such devices to malfunction resulting in an
accident.
RDo not allow the AC adaptor or telephone
line cord to be excessively pulled, bent or
placed under heavy objects.
RKeep small parts, such as microSD cards,
out of the reach of children. There is a risk
of swallowing. In the event they are
swallowed, seek medical advice
immediately.
Operating safeguards
RUnplug the product from power outlets
before cleaning. Do not use liquid or
aerosol cleaners.
RDo not disassemble the product.
RDo not spill liquids (detergents, cleansers,
etc.) onto the telephone line cord plug, or
allow it to become wet at all. This may
cause a fire. If the telephone line cord plug
becomes wet, immediately pull it from the
telephone wall jack, and do not use.
RNever put metal objects inside the product.
If metal objects enter the product, turn off
the circuit breaker and contact an
authorised service centre.
Medical
RConsult the manufacturer of any personal
medical devices, such as pacemakers or
hearing aids, to determine if they are
adequately shielded from external RF
(radio frequency) energy. DECT features
operate between 1.88 GHz and 1.90 GHz
with a peak transmission power of 250 mW.
Wi-Fi features operate between 2.412 GHz
6
Important Information

and 2.472 GHz with a peak transmission
power of 100 mW.
RDo not use the product in health care
facilities if any regulations posted in the
area instruct you not to do so. Hospitals or
health care facilities may be using
equipment that could be sensitive to
external RF energy.
CAUTION
Installation and location
RNever install wiring during a lightning storm.
RNever install telephone line jacks in wet
locations unless the jack is specifically
designed for wet locations.
RNever touch uninsulated telephone wires or
terminals unless the telephone line has
been disconnected at the network interface.
RUse caution when installing or modifying
telephone lines.
RThe AC adaptor is used as the main
disconnect device. Ensure that the AC
outlet is installed near the product and is
easily accessible.
RThis product is unable to make calls when:
– there is a power failure.
– when the cordless handset or mobile
device’s batteries need recharging or
have failed.
Important safety
instructions
When using your product, basic safety
precautions should always be followed to
reduce the risk of fire, electric shock, and
injury to persons, including the following:
1. Do not use this product near water for
example, near a bathtub, washbowl,
kitchen sink, or laundry tub, in a wet
basement or near a swimming pool.
2. Avoid using a telephone (other than a
cordless type) during an electrical storm.
There may be a remote risk of electric
shock from lightning.
3. Do not use the telephone to report a gas
leak in the vicinity of the leak.
4. Use only the power cord indicated in this
document.
SAVE THESE INSTRUCTIONS
Security cautions
Take appropriate measures to avoid the
following security breaches when using this
product.
– Leaks of private information
– Unauthorised use of this product
– Unauthorised interference or suspension of
the use of this product
Take the following measures to avoid security
breaches:
RConfigure the wireless router that connects
your mobile device to this product to use
encryption for all wireless communication.
RYou may be vulnerable to security
breaches if the unit is used with the login
password, disarm code, or PIN code, or
other settings at their defaults values.
Configure your own values for these
settings.
RDo not use passwords that could be easily
guessed by a third party. If you keep a
record of your passwords, protect that
record. Change passwords regularly.
RIf you lose your mobile device, change the
password used to access this product.
RIf you enable the product’s auto login
feature, enable the screen lock or similar
security feature on your mobile device.
RTake care when performing important
security related operations such as deleting
MAC address, unit IDs, etc.
RTo prevent disclosure of personal
information, enable the screen lock or
similar security feature on your mobile
device.
RWhen submitting the product for repair,
make a note of any important information
stored in the product, as this information
may be erased or changed as part of the
repair process.
RBefore handing the product over to a third
party for repair or other purposes, perform
a factory data reset to erase any data
7
Important Information

stored in the product and remove the
microSD card. Use only trusted repair
services authorised by Panasonic.
RBefore disposing of the product, perform a
factory data reset to erase any data stored
in the product. Remove and erase the
microSD card.
RIf your mobile device will no longer be used
with the product, delete your mobile
device’s registration from the product and
delete the corresponding app from your
mobile device.
RIf this product experiences a power outage,
its date and time setting may become
incorrect. In this case, the date and time
setting will be automatically corrected when
your mobile device and this product are
connected to the same wireless network.
Additionally, note the following.
RMultiple hubs cannot be used on the same
network.
ROnly one mobile device can access this
product while away from home. If a second
mobile device connects to this product
while away from home, the first mobile
device is disconnected.
RCommunications may be interrupted
depending on network conditions and
wireless signal quality.
RThis product may be used in ways that
violate the privacy or publicity rights of
others. You are responsible for the ways in
which this product is used.
For best performance
Hub location/avoiding noise
The hub and other compatible Panasonic
devices use radio waves to communicate with
each other.
RFor maximum coverage and noise-free
communications, place your hub:
– at a convenient, high, and central
location with no obstructions between
the devices and hub in an indoor
environment.
– away from electronic appliances such as
TVs, radios, personal computers,
wireless devices, or other phones.
– facing away from radio frequency
transmitters, such as external antennas
of mobile phone cell stations. (Avoid
putting the hub on a bay window or near
a window.)
RCoverage and voice quality depends on the
local environmental conditions.
RIf the reception for a hub location is not
satisfactory, move the hub to another
location for better reception.
Environment
RKeep the product away from electrical noise
generating devices, such as fluorescent
lamps and motors.
RThe product should be kept free from
excessive smoke, dust, high temperature,
and vibration.
RThe product should not be exposed to
direct sunlight.
RDo not place heavy objects on top of the
product.
RWhen you leave the product unused for a
long period of time, unplug the product from
the power outlet.
RThe product should be kept away from heat
sources such as radiators, cookers, etc. It
should not be placed in rooms where the
temperature is less than 0 °C or greater
than 40 °C. Damp basements should also
be avoided.
RThe maximum communication range may
be shortened when the product is used in
the following places: Near obstacles such
as hills, tunnels, underground, near metal
objects such as wire fences, etc.
ROperating the product near electrical
appliances may cause interference. Move
away from the electrical appliances.
Other information
Routine care
RWipe the outer surface of the product with a
soft moist cloth.
8
Important Information

RDo not use benzine, thinner, or any
abrasive powder.
Protecting your recordings
RDo not remove the microSD card or
disconnect the hub’s AC adaptor while
reading or writing data to the microSD card.
Data on the card could become corrupted.
RIf a microSD card malfunctions or is
exposed to electromagnetic waves or static
electricity, data on the card could become
corrupted or erased. Therefore we
recommend backing up important data to a
computer or other device.
Notice for product disposal, transfer,
or return
RThis product can store your private/
confidential information. To protect your
privacy/confidentiality, we recommend that
you erase information such as phonebook
or caller list entries from the memory before
you dispose of, transfer, or return the
product.
Disposal of Old Equipment (Only for
European Union and countries with
recycling systems)
This symbol on the products, packaging, and/
or accompanying documents means that used
electrical and electronic products must not be
mixed with general household waste.
For proper treatment, recovery and recycling
of old products, please take them to applicable
collection points in accordance with your
national legislation.
By disposing of them correctly, you will help to
save valuable resources and prevent any
potential negative effects on human health
and the environment. For more information
about collection and recycling, please contact
your local municipality.
Penalties may be applicable for incorrect
disposal of this waste, in accordance with
national legislation.
For business users in the European
Union
If you wish to discard electrical and electronic
equipment, please contact your dealer or
supplier for further information.
Information on Disposal in other
Countries outside the European Union
This symbol is only valid in the European
Union. If you wish to discard these items,
please contact your local authorities or dealer
and ask for the correct method of disposal.
9
Important Information

Part names and functions
C
B
A
D E
G H I
F
Speaker
LED indicator
DC jack
LINE jack
MWi-Fi SETUPN
Used when performing initial setup.
microSD card slot
Used when inserting a microSD card.
Remove the label when inserting.
M HANDSET/LOCATORN
Used when registering a handset. You
can also press this button to locate a
misplaced handset.
M CAMERAN
Used when registering a camera.
M OTHER DEVICEN
Used when registering other devices,
such as sensors and smart plugs.
LED indicator
You can use the LED indicator to confirm the
hub’s status.
Indicator Status
Off No power, or LED
indicator is turned
off*1
Green, lit Normal operation,
connected to
wireless router*1
Green, blinking
slowly
Registration mode
Green, blinking
quickly
Hub is searching for
wireless router
Alternating:
Green, blinking
slowly
Yellow, blinking
slowly
Hub is starting up
(cannot be used
yet)*2
Red, lit Alarm system is
armed*1
Red, blinking quickly Alarm system was
triggered
Yellow, lit Initial setup required
Yellow, blinking
slowly
Initial setup in
progress, mobile
device connected
Yellow, blinking Initial setup is
starting
*1 You can configure the hub so that its LED
indicator does not light during normal
operation. For more information, refer to
the User’s Guide (page 16).
*2 It may take some time for the hub to finish
starting up.
10
Setup
