Panasonic EASA-PHONE KX-T2315 User manual

PANASONIC
PANASONICPANASONIC
PANASONIC
Speaker Phone
Easa-Phone
Model No. KX-T2315
For product service
•Panasonic Service centers are listed in the service center directory.
•Call 1-800-545-2672 for the location of an authorized service center.
When you ship the product
•Carefully pack your unit, preferable in the original carton.
•Attach a letter, detailing the symptom, to the outside of the carton.
Symptom
____________________________________________________
•Send the unit to an authorized service center, prepaid and adequately insured.
•Do not send your unit to the Panasonic Consumer Electronics Company listed
below or to executive or regional sales offices. These locations do not repair
consumer products.
For your future reference
Serial No. Date of purchase
(found on the bottom of the unit)
Name and address of dealer
Panasonic Consumer Electronics Company,
Division of Matsushita Electric Corporation of America
One Panasonic Way, Secaucus, New Jersey 07094
Panasonic Sales Company,
Division of Matsushita Electric of Puerto Rico, Inc.
Ave, 65 de Infanteria, Km. 9.5, San Gabriel Industrial Park
Carolina, Puerto Rico 00985

2
Please read IMPORTANT SAFETY INSTRUCTIONS On page 33 before
use. Read and understand all instructions.
FEATURES
Thank you for purchasing the Panasonic Telephone.
The KX-T2315 features include:
nLocal Mode
The unit can be set to prohibit the user from making long-distance and
overseas calls.
nBuilt-in Speakerphone
To converse “hands-free” or have conference calls.
nOne-Touch/Speed Dialing
For up to 20 16-digit telephone numbers plus 8 one-touch automatic dialing
buttons.
nSwitchable Tone/Pulse Setting
For compatibility with tone-actuated systems and any phone line.
nOne-Touch Tone Switching
Lets you temporarily switch to tone from pulse mode by pressing a button.
nElectronic Hold
To hold your calling party --- can be released just by lifting the handset of the
unit or any extension.
nTimed Flash (700 ms) Memory
For automatic dialing and special telephone company services, such as call
waiting.
nOn-Hook Dialing
Monitor speaker lets you dial without lifting the handset.

3
CONTENTS
Features 2
Contents 3
Preparation
Location of Controls and Jack 4
Battery Installation 5
Connection 5
Initial Settings 6
Operation
Making and Receiving Calls 7
Storing Numbers 8
Automatic Dialing 10
nDialing
nCorrecting an Error while Storing 10
nErasing Stored Numbers 10
nConfirming a Stored Number 11
Other Features
Mute Operations 11
Tone Button Usage 11
Pause Button Usage 11
Hold 12

4
LOCATION OF CONTROLS AND JACK
1) Direct Call Button: They are used to dial telephone numbers already stored in them.
(One-Touch Dialing)
2) Memory Card: This card is used to write the names of the persons
Whose phone numbers have been stored in the speed
Dialing buttons. On the reverse of this card, find
Directions for automatic dialing and storage.
3) Flash Button: It is used to access some of the features of your host
PBX, and your telephone company.
4) Mute Button: It is used when you do not want your voice to be heard
By the other party. The voice of the calling party will still
Be heard.
5) Hold Button: It is used to put the calling party on hold during a
conversation.
6) Auto/Store Button: It is used to store and dial telephone numbers in
Speed dialing mode.
7) Ringer Volume Selector: It is used to adjust the ringer volume
level.
8) Program Button: It is used to program telephone numbers in memory.
9) Dialing Mode Selector: It is used to select either Pulse or Tone dialing.
10) Pause Button: It is used to pause during dialing.
11) Redial Button: It is used to redial the last dialed telephone numbers.
12) SP-Phone Button and Indicator: It is used for on-hook dialing and
Hands-free operation. When this feature is being used,
The indicator lights.
13) Mute/Store Indicator: Lights up when the MUTE or PROGRAM button
Is pressed.
14) Telephone Line Jack
15) local Call Only Switch: It is used to select the local only.

5
BATTERY INSTALLATION
Three R6 (AA, UM-3) size batteries serve as the power source to activate
the SP-PHONE fully, and to retain the stored phone numbers in memory.
1) Remove the wall mounting adapter from the bottom of the unit.
2) Open the battery compartment cover.
3) Insert the three R6(AA,UM-3) size batteries observing the correct
polarity, then close the compartment cover.
4) Insert the tabs of the wall mounting adapter into the openings of the unit,
then push it in the direction of the arrow. (The word “DESK UP”
on the adapter should be upward.)
NOTE:
nPlease check your batteries before calling telephone repair.
nTo prevent loss of the stored telephone numbers, replace new batteries within
10 minutes after removing the old ones.
nDisconnect the telephone cord before opening the battery compartment cover.
nReplace all the batteries once a year, or mis-operation may occur.
nDo not use Nickel-Cadmium batteries.
BATTERY PRECAUTIONS:
nThe batteries should be used correctly, otherwise, the unit may be damaged
due to battery leakage.
nDo not mix different types of batteries.
nDo not charge, short-circuit, disassemble, heat or dispose in fire.
nRemove all the batteries when replacing.
CONNECTION
1) Connect the handset: Fasten the handset cord to the holder at the bottom of
the unit.
2) Connect the telephone line cord: Connect cord to single-line telephone jack
(RJ11C)
NOTE:
nUse only Panasonic handset for the KX-T2315.

6
INITIAL SETTINGS
1) Dialing Mode Selector:
Set to “Tone”. If dialing can not be done, set to “Pulse”.
(Dialing Mode Selector Button is located on the mid-right side of your Panasonic
phone.)
2) Volume Selector:
Used to adjust the sound level from the built-in speaker.
(Volume Selector Button is located on the top right side of your Panasonic
phone.)
1) Select the Ring Volume:
HIGH: The ringing sound will be high.
LOW: The ringing sound will be low.
OFF: The telephone will not ring.
(Ring Volume Button is located on the right side just below the Volume Selector
Button of your Panasonic phone.)
2) Local Call Only Switch:
OFF: Local and long distance calls can be made.
ON: The manual or automatic dialing operation of a number with more than 8
digits are not possible.
(Local Call Switch Button is located on the bottom of phone.)
Memory Card
Use a pencil or a ball-point pen to fill in the station directory with station name.
(You can use the reverse side for writing, too.)
nRemove the cover using an instrument with a pointed end like a pen.

7
MAKING AND RECEIVING CALLS
Making calls with a handset
1) Lift the handset.
2) Dial the telephone number.
3) Speak to the other party.
§You can switch to the speakerphone at anytime by pressing the SP-PHONE
button. You can replace the handset on the cradle.
4) Hang up when finished.
Making calls with the speakerphone
1) Press the SP-PHONE button.
§The SP-PHONE indicator will light.
2) Dial the telephone number.
3) Speak to the other party.
§You can also switch to the handset at anytime by lifting the handset.
4) When finished, Press the SP-PHONE button again.
§The SP-PHONE indictor light goes out.
Helpful Hints when using the speakerphone
nWhen the other party finds it difficult to hear your voice:
Lower the sound level using the Speaker Volume Control or speak louder.
nAbsorbing echoes:
Use in a room that has curtains or carpeting.
nTo avoid lost or broken conversation:
If you and the caller speak at the same time, parts of your conversation will be
lost. To avoid this, speak alternately.

8
MAKING AND RECEIVING CALLS (continued)
Receiving Calls
1) Lift the handset.
Press the SP-PHONE button.
2) Speak to the calling party.
Speak into the microphone.
Redialing
Press the Redial button when the line is busy.
§Pressing the Redial button enables you to redial once.
STORING PHONE NUMBERS
nThere are 20 memory stations, each station is capable of storing 16 digits.
nThere are 8 Direct Call buttons, each is capable of storing 16 digits. Each
Dialing button serves as a memory station.
Be sure that the handset is on the cradle and the SP-PHONE indicator is off and
the batteries are installed.
CAUTION: Please, do not press any button of “automatic dialer” before
programming. This is to prevent mis-operation of auto dialer function.
(Home Use
Speed Dialing
1) Press the Program button until the Store indicator light is on.
2) Press the Station number.
nPhone numbers can be stored into memory station “0 1” to “2 0” following
the same procedure.
3) Dial the telephone number.

9
STORING PHONE NUMBERS (continued)
4) Press the Auto/Store button to store the number into memory.
5) After storing all the numbers, press the Program button.
nThe STORE indicator light goes out.
NOTE: When pressing the station number for speed dialing, use the digits 01, 02,
03, …09, etc., as 1, 2, 3, …9, will not be recognized by the phone.
(Home Use
One-Touch Dialing
1) Press the Program button until the Store indicator light is on.
2) Press the Direct Call button.
3) Dial the telephone number.
4) Press the Auto/Store button to store the number into memory.
nTo store other telephone numbers, repeat steps 2 through 4.
5) After storing all the numbers, press the Program button.
nThe STORE indicator light goes out.
(Office Use (PBX)
1) Press the Program button until the Store indicator light is on.
2) Press the Station number.
nYou may use the Direct Call button instead of pressing the station number.
3) Enter Line access number for an example 9.
4) Press the Pause button.
5) Dial the telephone number.
6) Press the Auto/Store button.
nTo store other telephone numbers, repeat steps 2 through 6.
7) After storing all the numbers, press the Program button.
nThe Store indicator light goes out.

10
AUTOMATIC DIALING
Speed Dialing
1) Lift the handset, or press the SP-PHONE button.
2) Press the Auto/Store button, then press the station number. (01 to 20)
3) Speak to the other party.
One-Touch Dialing
1) Lift the handset, or press the SP-PHONE button.
2) Press the Direct Call button.
3) Speak to the other party.
nTo change a stored number, repeat the steps of “Storing Phone Numbers”.
nIf the batteries are not installed, programming and speakerphone operation can
not be done.
Correcting an Error while Storing
Press the PROGRAM button if you notice an error.
nRepeat all the steps of “Storing Phone Numbers” to reprogram.
Erasing Stored Numbers
Example: To erase the number in memory station 02: Be sure that the handset is
on the cradle and the SP-PHONE indicator is off and the batteries are installed.
1) Press the PROGRAM button until the STORE indicator light is on.
2) Press the Station number 02.
3) Press the AUTO/STORE button.
4) Press the PROGRAM button.
nThe STORE indicator light goes out.
NOTE: If the number that you want to erase is stored in a direct call button, press
That button on step 2 of the above procedure.

11
AUTOMATIC DIALING (continued)
Confirming a Stored Number
Be sure that the handset is on the cradle and the SP-PHONE indicator light is off
and the batteries are installed.
1) Press the PROGRAM button until the STORE indicator light is on.
2) Repeat storing the same number into the same station.
3) Press the AUTO/STORE button.
nThe STORE indicator.
Flashes once: The entry is the same as what was previously stored.
Lights: The entry is different from the one that was previously stored.
OTHER FEATURES
Mute Operation
The MUTE button is useful when you do not want your voice or conversation to be
heard by the other party.
1) Press the MUTE button.
nThe MUTE indicator light in on.
2) To resume the conversation, press the MUTE button again.
nThe MUTE indicator light is off.
Tone Button Usage
If you want to change from pulse mode into tone mode during dialing, the TONE
button can be used instead of changing the Dialing Mode selector.
Pause Button Usage
The PAUSE button function is needed behind the PBX for outside line access or a
computer access dial tone.
When you press the PAUSE button, you can dial the phone number without waiting
for an outside dial tone.
One pause is required when waiting for an outside dial tone.
Example (PBX):
9-----PAUSE-----Phone No.
“9” is the Line Access Number.
Some PBXs require this “PAUSE” for the redial function

12
HOLD
Placing a Call on Hold
The HOLD Button is used to keep a call on hold while having a conversation.
Press the HOLD button while having a conversation.
nThe HOLD indicator flashes slowly.
nYou can place the handset on to the cradle, if needed.
Releasing a Call on Hold
nIf the handset is the off-hook: Press the HOLD button and start speaking.
nIf the handset is on the cradle: Lift the handset or press the SP-PHONE button
and start speaking.
nWhen using another telephone connected on the same line: Lift the handset of
the other telephone.
If the hold is not released, press the hook switch of the other telephone for about
one second.
