Panasonic MC-CG717 User manual

© 2011 Panasonic Manufacturing Malaysia Berhad
(6100-K). Unauthorized copying and distribution is a
violation of law.
PMMA110825CE
Vacuum Cleaner
Model No. MC-CG717
TABLE OF CONTENTS PAGE PAGE
1 Specifications ----------------------------------------------------- 2
2 Schematic Diagram---------------------------------------------- 2
3 Wiring Connection ----------------------------------------------- 3
3.1. CDS----------------------------------------------------------- 3
3.2. ECM (Alternative)------------------------------------------ 4
4 Trouble Shooting Chart ---------------------------------------- 5
5 Disassembly and Assembly Instruction------------------ 7
5.1. Disassembly of Upper and Lower Body ------------- 7
5.2. Disassembly of Motor Case Set ----------------------- 9
5.3. Disassembly of Cord Reel Unit ------------------------ 9
5.4. Disassembly of Rail Base Unit------------------------10
5.5. Disassembly of Fan Motor Unit -----------------------10
5.6. Disassembly of P.C.B. Ass’y---------------------------12
6 Exploded View and Replacement Parts List -----------13
6.1. Exploded View --------------------------------------------13
6.2. Attachment Exploded View ----------------------------14
6.3. Packing Instruction---------------------------------------15
6.4. Replacement Parts List ---------------------------------16

2
1 Specifications
2 Schematic Diagram
Model MC-CG717
Power Source 220V~240V~50/60Hz
Input Power (Max) 2300W
Input Power (IEC) 1600-2000W
Power Control SLIDE
Dust Capacity 6.0L
Automatic Cord Rewind 0
Vac Gauge 0
Exhaust Filter HEPA
Extension Wands MAGIC TELESCOPIC WAND
Blower Operation 0
Floor Nozzle 2-STEP
Dust Bag CLOTH
Dimension (H x W x L) mm 265mm X 320mm X 500mm
Net Weight 6.5 KG
Cord Length 5.0 M
Cleaning Tools CREVICE TOOL / DUSTING BRUSH

3
3 Wiring Connection
3.1. CDS

4
3.2. ECM (Alternative)

5
4 Trouble Shooting Chart

6

7
5 Disassembly and Assembly Instruction
5.1. Disassembly of Upper and
Lower Body
Step 1 Open Dust Cover & remove Dust Bag.
Step 2 Release Dust Cover from Hanger.
Step 3 Remove 5 screws from the Front Side and 2 screws
from Bottom Side of the body..
Step 4 Pull out Exhaust Cover.
Step 5 Remove 3 screws from back side of body.
Step 6 Remove 1 Screw.

8
Step 7 Remove Body Lining Upper using philip screwdriver.
Step 8 Push one by one follow the arrow to take out the pedal.
Step 9 Pull the On/Off switch to change position.
Step 10 Lift up Upper Body.
Step 11 Remove Upper Body from Lower Body.

9
5.2. Disassembly of Motor Case Set
Step 1 Release Rear Cover from Screw Holders.
Step 2 Remove Rear Cover.
Step 3 Pull up Motor Case Set from Lower Body.
5.3. Disassembly of Cord Reel Unit
Step 1 Release the pretension of the Cord Reel Unit slowly by
holding on the Power Plug and pressing on the Brake Lever.
Step 2 Remove the Cord Reel Unit from the Motor Case Set by
inserting a slotted screwdriver into the shaft of the Cord Reel
Unit and turning it 90°counter-clockwise.
To assemble:
Step 1 Assemble in reverse order of the disassembly.
Step 2 Pretension the Cord Reel Unit.
-Turn the Cord Reel Unit holding on the plug
-Number of turns for pretension of the Cord is engraved on the
steel at the side of Cord Reel Unit.

10
5.4. Disassembly of Rail Base Unit
Step 1 Remove 1 screw.
Step 2 Release Catch and pull upward.
Step 3 Remove Faston Terminals on Rail Base Unit.
5.5. Disassembly of Fan
Motor Unit
Step 1 Remove Swivel Cap.
Step 2 Remove 1 screw from top and 2 screws bottom Motor
Case Set.
Step 3 Remove Tabs.

11
Step 4 Lift up Motor Case Unit
Step 5 Disconnect Wire Terminal and remove Motor Set.
Step 6 Remove Noise Supprassor Unit and Motor Support
Rubbers.

12
5.6. Disassembly of P.C.B.
Ass’y
Step 1 Disassemble Volume by widening the Tab using Screw-
driver.
Step 2 Remove Volume Upward.
Step 3 Release Tabs and remove P.C.B. Cover.
To reassemble the unit, reverse the disassembly proce-
dure above.

13
6 Exploded View and Replacement Parts List
6.1. Exploded View
B6
B35
B1
B36
B38
B37
44
44
B32
B34
B2
B4
B3
B29
B30 B5
B10
B12
B13
B14
B15
B16
B17
B20
B21
B22
B28
B28
B24
B25
B27
B23
B18
B31
B11 B7
B8
B9
1
3
33
3
11
22
1
1
1
1
1
11
B33
B9
B39
Plug E2
Plug C3
B41
B42
B43
B43
5

14
6.2. Attachment Exploded View
A2
A3
A5
A4
A1
A7
A6

15
6.3. Packing Instruction
P1
HOSE UNIT
INSTRUCTION BOOK
CURVED WAND
CREVICE NOZZLE
CONNECTION PIPE
BODY
DUSTING BRUSH A
FLOOR NOOZLE ASS'Y
P3
P3
PARTITION BOARD A
EXTENSION WAND UNIT
P2 P2

16
6.4. Replacement Parts List
MMH1108
Safety Ref. No. Part No. Part Name & Description Qty Remarks
1 XTN4+20BFJ PAN TAP SCREW 10
2 XTN4+10FFJ SCREW 2
3 XTN4+14BFJ TAPPING SCREW 4
4 XTN4+12BFJ PAN TAP SCREW 4
5 XTN4+12BFJ PAN TAP SCREW 1
B1 YMV02ABW000 UPPER BODY 1
B2 YMV32KBW000 FILTER SUPPORTER 1
B3 YMV42KBW000 FILTER CASE 1
B4 YMV95KBW000 FILTER ASS'Y 1
B5 YMV96LBW000 BLOWER OUTLET UNIT 1
B6 YMV93KBW0R0 DUST COVER UNIT 1 RED
B7 YMV33LBW000 BLOWER COVER SPRING 1
B8 YMV59VBW000 PCB HOLDER 1
B9 YMV23EBW000 INSULATION PLATE 2
B10 YMV63FBW000 MOTOR SUPPORT COVER 1
B11 YMV09FBW000 MOTOR CASE 1
B12 YMV99GBX000 NOISE SUPPRESSOR UNIT 1
B13 YMV03FBW000 MOTOR SUPPORT RUBBER REAR 1
B14 YMV07FCH000 MOTOR SUPPORT FRONT 1
B15 YMV92FB700C MOTOR FAN UNIT 1
B16 YMV02FBX000 MOTOR SUPPORT RUBBER REAR 1
B17 YMV89VB6000 PCB A UNIT 1
B18 YMV69VBX000 LEAD WIRE C UNIT 1
B20 YMC99KXQ000 CLOTH BAG UNIT 1
B21 YMV37KBW000 SECONDARY FILTER 1
B22 YMV03ABW000 LOWER BODY 1
B23 YMC95C7K100 CASTER UNIT 1
B24 YMV01LBW000 REAR COVER 1
B25 YMV23KBW000 SUPPORTER 1
B26 YMV46HBW000 BAG CLAMPER SPRING 1
B27 YMV73KBW000 DUST BOX PACKING 1
B28 YMV01CBW000 WHEEL 2
B29 YMV99NBW000 CORD REEL UNIT 1 C3 PLUG
B29 YMV99NBW00Q CORD REEL UNIT 1 E2 PLUG
B30 YMV98NBW000 RAIL BASE UNIT 1
B31 YMV25QBW000 SWIVEL CAP 1
B32 YMV05EBW000 SWITCH PEDAL 1
B33 YMV46NBW000 CORD REWIND BUTTON 1
B34 YMV02GBW000 BODY LINING UPPER 1
B35 YMV99MBW000 INDICATOR PIPE UNIT 1
B37 YMV64HBW000 SUCTION INLET PACKING 1
B38 YMV25KBW000 DUST BOX PLATE 1
B39 YMV43KBW000 PRE FILTER 1
B41 YMV43NBW000 BRAKE LEVER 1
B42 YMV01E7B000 ON / OFF SWITCH 1
B43 YMV871NBW000 SPRING BRAKE BUTTON 2
A1 YMV99PBW000 METAL WAND TELESCOPIC 1
A2 YMV98PBW000 CURVE WAND UNIT 1
A3 YMV27HBW000 CONNECTION WAND 1
A4 YMV60R9L080 CREVICE NOZZLE 1
A5 YMC84PXP000 HOSE UNIT 1
A6 YMC99RXQ000 FLOOR NOZZLE ASS'Y 1
A7 YMC88RYX080 DUSTING BRUSH UNIT 1
P1 YMV61ZBW000 INDIVIDUAL CARTON 1
P2 YMV98ZBW000 CUSHION UNIT 1
P3 YMV46ZBW000 PARTITION BOARD 2
YMV01ZBW000 INSTRUCTION BOOK 1
