Panasonic NA-F70G6 Product guide

Contents
Safety Precautions 2
Part Names / Accessories
6
Before Washing 7
Operation Panel 8
Variety of Programs 10
Detergent 12
Washing 14
Washing Options
• Bedding
• Delicate
• Wash / Rinse / Spin
• Stain Master
• Air Dry (90 min)
• Cotton Eco
16
Contents of Programs 19
Convenient Functions 20
Maintenance 21
Installation 24
Error Display 28
Troubleshooting 29
Specications 30
Thank you for purchasing this product.
- Read these instructions carefully for optimum
performance and safety before use.
- Keep this manual for future reference.
AWW9901C6XC0-0C5
A1119-0(NZ)
Printed in Vietnam
11-2019
Operating & Installation Instructions
Fully Automatic Washing Machine (Household use)
Model No. NA-F70G6
NA-F60G6
AWW9901C6XC0-0C5

2
Safety Precautions
Read and follow these safety precautions.
May cause serious injury or death.
Do not allow children to use on their own.
zThis appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
zChildren should be supervised to ensure that they do not play
with the appliance.
Observe the following about the power plug and cord.
(To prevent re or electric shock)
zDo not plug in or unplug the power cord with wet hands.
zDo not hold or pull on the cord when removing the plug from the
socket.
zDo not use a power cord or plug that is damaged. If the power
cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid a
hazard.
zUse a socket that satises the rating requirement solely for this
appliance. Do not use a plug adaptor or extension cord.
zAlways fully insert the power plug into the socket.
zWipe the power plug periodically with a dry cloth. (Accumulated
dust collects moisture, which may cause insulation failure,
resulting in re.)
zUnplug the power cord before cleaning.
WARNING

Safety Precautions
3
Never disassemble, repair or modify the appliance
yourself.
zIn case of malfunction or failure (burnt odour smell, fume, etc.),
immediately stop use, unplug the power cord, and ask your
nearest service centre for repair.
Keep away from re.
Do not put ammable materials or clothes with such
things attached in the tub.
Keep them away from the appliance.
(To prevent explosion or re)
zFor example: Kerosene, gasoline, benzine/thinner, alcohol, etc.
Do not touch the tub until it completely stops.
(To prevent injury)
zIf the tub does not stop within 15 seconds when the lid
is opened during spin process, switch off the appliance
immediately and call a service person.
Be sure to provide a ground.
(To prevent electric shock if electricity leakage occurs.)
zTo establish a ground, ask a service person to do the grounding
work.
Home hot water heater safety.
zUnder certain conditions, hydrogen gas may be produced
in your hot water heater that has not been used for two
weeks or more. Hydrogen gas can be explosive under these
circumstances. To prevent the possibility of damage or injury,
you should turn on all hot water faucets in your home, and let
the water ow out for several minutes before connecting to your
washing machine. This will allow any built up hydrogen gas to
escape. Since hydrogen gas is ammable, do not smoke or use
an open ame or start appliance during this process.
WARNING

4
Safety Precautions (continued)
May cause injury or property damage.
Do not wash, rinse, or spin waterproof sheets or
clothes.
(To prevent injury, damage to the main unit, walls, oor or laundry,
or water leakage if the appliance falls over or oscillates extremely
while spinning)
zRaincoats, wet suits, etc.
Locate away from direct sunlight or heat.
(To prevent malfunction,
discoloration or deformation.)
Turn off the water faucet after operation.
(To prevent water leakage)
CAUTION

Safety Precautions
5
Observe the following
zBe careful not to get your ngers caught when opening and
closing the lid.
zNew hose-sets supplied with the appliance are to be used and
old hose-sets should not be reused.
zDo not obstruct the openings of the bottom face with carpet, etc.
zDo not insert your hands or feet under the main unit.
(To prevent injury by rotating parts.)
zDo not climb or put heavy objects on the appliance.
(To prevent deformation and breakage resulting in injury)
zIf the lid is broken, immediately stop using the appliance.
(To prevent deformation and breakage resulting in injury)
zDo not use water hotter than 60 ºC.
zDo not make wrong connection for the HOT and COLD water
supply faucets.
zDepending on the connected water heater, very hot water may
come out. Be careful not to burn yourself.
zDo not add extra water directly into the tub.
zThis appliance is only suitable for textiles labelled washing
machine washable.
zDo not add too much detergent. (This will cause poor rinsing or
cause the foam to overow and wet the oor.)
zDo not load too many clothes and be aware of items that can
easily oat up (e.g. duvet covers). Therefore, limit the load size
to a level below the balance ring. (Not doing so will tear clothes
and damage the resin parts of the washing machine.)
zIf detergent or softener comes in contact with the washing
machine (particularly the lid or the control panel), wipe it off
immediately with a towel wrung out of water or similar cloth.
(Not doing so will cause the printed information to come off,
damage the resin parts, corrode the metal parts or result in
malfunction.)
CAUTION

6
Part Names / Accessories
Accessories
Water supply hose
for HOT (White) (1)
(P. 26)
• Length: 1.25 m
Water supply hose
for COLD (Gray) (1)
(P. 26)
• Length: 1.25 m
Bottom cover (1) (P. 24)
Screw (1) (P. 24)
Drain hose (1)
Hose band (1)
Drain hose (P. 25)
Pulsator
Lint lter
(P. 21)
Lid
Tub
Leveller (P. 27)
Power cord and
plug* (P. 27)
* The plug shape
varies with the
region.
Adjustable leg (P. 27)
Detergent and
softener drawer
(P. 13)
Operation panel (P. 8)
Detergent/
Bleach inlet
(P. 12)
• Hose holder (1)
• Screw (1)
Hot
Cold
Water supply valve (P. 26)

Part Names / Accessories Before Washing
7
Before Washing
Laundry preparation and check
Wash separately for clothes
losing colour easily
Pre-laundry check
(To prevent damage to clothes and/
or machine damage or drainage
failure.)
zRemove coins, pins, paper clips,
nails, etc.
zFasten buttons and close zippers.
zDo not wash items (such as paper
nappies) other than laundry.
zReverse clothes likely to pill.
zUse a brush to remove pet and
human hair, sand, etc.
zTie strings, etc.
Use laundry nets for delicates
zUnderwire brassieres, lacy clothes,
lingerie and stockings
zDo not overpack.
zPut the zipper's slider into the cover.
(To prevent damage to clothes and
the main unit)
zDo not use the “Air Dry” program.
(To prevent uneven drying and
wrinkles)
For “Stain Master” program (P. 10)
zRecommended for removing stains.
zObserve the instructions on the
care labels of clothes.

8
Air Dry (P. 18) Start/PauseChild Lock lamp
(P. 20)
NOTE
zIn case of a power failure
during operation, operation
will resume from the point
where it was stopped when
the power is recovered
(Auto Restart).
zThe power turns off
automatically if you do not
press “Start/Pause” within
10 minutes after power-on.
Operation Panel
Water amount/remaining time
After starting
operation, indicates
the water amount
according to the
amount of laundry.
After approx.
5 seconds, indicates
the approximate
remaining time (min).
Preset
Set the time to nish washing (in hours). ( lights.)
e.g.) 8 hours later
zSetting range:
2 - 24 hours later, in one-hour increments.
(1 - 24 hours later for the “Quick Wash” program,
3 - 24 hours later for the “Soak” and “Cotton Eco” program)
zNot available for the following programs:
“Delicate”, “Bedding”, “Tub Hygiene”, “Air Dry”
Change water amount
During the wash process, press
“Water Level” to change the
water amount.
zSome water amounts cannot
be selected depending on the
program.
zWhen the remaining time is
displayed, press “Water Level”
to check the water amount.
• Operation panel of NA-F70G6
Wash / Rinse /
Spin (P. 16)

Operation Panel
9
Program
selection (P. 10)
Power Off/On
Detergent volume guideline
Water level (L) Detergent 1)
69 2) 55
51 47
38 27
1) : 1 scoop of detergent
2) NA-F70G6: 69 L
NA-F60G6: 66 L
Water amount/remaining time
After starting
operation, indicates
the water amount
according to the
amount of laundry.
After approx.
5 seconds, indicates
the approximate
remaining time (min).
Stain Master (P. 17)
Temp Setting
For washing, cold water can be mixed with hot water. Press the button
to select Hot/Warm/Cold. (P. 14)
Do not use water hotter than 60 ºC.
zThe estimated water temperature in the tub during wash process
(when hot water supply is 60 ºC, and cold water supply is 20 ºC):
Hot: approx. 40 ºC Warm: approx. 30 ºC
zLamp indications Lighted: Hot/Warm/Cold is set.
Flashing: Hot water is being supplied.
zNot available for the following programs: “Air Dry” (No water),
“Cotton Eco” (Hot is xed), “Delicate”, “Tub Hygiene” (Cold is xed)

10
Variety of Programs
Program Purpose Maximum capacity
NA-F70G6 NA-F60G6
Cotton (P. 14) Everyday clothes
zDaily washing 7.0 kg6.0 kg
Quich Wash (P. 14) Speedy washing for light soil 7.0 kg6.0 kg
Delicate (P. 16) Delicates
zWashing delicates gently 4.2 kg4.2 kg
Baby Care (P. 14)
Clothes for babies & people with
sensitive skin
zRinsing thoroughly
7.0 kg6.0 kg
Cotton Eco (P. 14)
Saving washing water and energy
* Washing consumes less energy and water,
but takes longer.
7.0 kg6.0 kg
Bedding (P. 16) Blankets 4.2 kg4.2 kg
Soak (P. 14) Heavily soiled clothes
zPresoaking to wash 7.0 kg6.0 kg
(P. 17)
Light stain
Heavy stain
Sweat Sweat stains
4.0 kg4.0 kg
Mud Mud stains
Soya/Sauce Sauce stains (soya, tomato, etc.)
Air Dry (90 min) (P. 18)
Drying synthetic bre clothes 2.0 kg2.0 kg
Tub drying ― ―
Tub Hygiene (P. 22) Tub cleaning
zPreventing black mould and smell ― ―
NOTE
z“Cotton” program and “Cotton Eco” program are recommended for a normally
soiled load at the rated capacity of this washing machine.

Variety of Programs
11
Program Purpose Maximum capacity
NA-F70G6 NA-F60G6
Cotton (P. 14) Everyday clothes
zDaily washing 7.0 kg6.0 kg
Quich Wash (P. 14) Speedy washing for light soil 7.0 kg6.0 kg
Delicate (P. 16) Delicates
zWashing delicates gently 4.2 kg4.2 kg
Baby Care (P. 14)
Clothes for babies & people with
sensitive skin
zRinsing thoroughly
7.0 kg6.0 kg
Cotton Eco (P. 14)
Saving washing water and energy
* Washing consumes less energy and water,
but takes longer.
7.0 kg6.0 kg
Bedding (P. 16) Blankets 4.2 kg4.2 kg
Soak (P. 14) Heavily soiled clothes
zPresoaking to wash 7.0 kg6.0 kg
(P. 17)
Light stain
Heavy stain
Sweat Sweat stains
4.0 kg4.0 kg
Mud Mud stains
Soya/Sauce Sauce stains (soya, tomato, etc.)
Air Dry (90 min) (P. 18)
Drying synthetic bre clothes 2.0 kg2.0 kg
Tub drying ― ―
Tub Hygiene (P. 22) Tub cleaning
zPreventing black mould and smell ― ―

12
Put in detergent, bleach and softener according to the water amount
displayed.
zFollow the instructions on each package.
Detergent
Detergent/Bleach inlet
Bleach
zDo not use whiten bleach (chlorine bleach) for
coloured clothes to prevent loss of colour.
zDo not use bleach for the “Delicate” program.
NOTE
zTurn the tub by hand if it is difcult to put in the
detergent/bleach inlet. (P. 20)
zAttach the detergent/bleach inlet cover if it comes off.
zIf the detergent/bleach inlet cover is wet, wipe it
before use.
(Wet cover can cause detergent clumps.)

Detergent
13
Detergent
Do not put detergent directly into
the tub.
Detergent may remain undissolved.
NOTE
zIf powder detergent is poorly
soluble, put detergent in the
detergent/bleach inlet.
zThe level of foaming depends on
the condition such as load size,
degree of soiling, detergent type,
and water hardness.
NOTE
zDo not put in too much
detergent.
zFor cleaning (P. 22)
Detergent and softener drawer
Liquid detergent
Powder detergent
Softener
Softener
zSoftener is automatically released
during the nal rinse process.
zTo add softener during operation,
press “Pause” rst.
zWhen using concentrated softener,
dilute it with water before putting it in.
Concentrated
softener Water
NOTE
zSoftener cannot be used with the
“Cotton Eco” program.
zDo not use separated or solidied
softener.
Do not ll above
the MAX line.
(Approx. 100 ml)

14
1
After loading laundry
Turn the power on.
zThe “Cotton” program is
selected when the power is
turned on.
2Select a program. (P. 10)
Temp Setting
Timer preset
Washing
Preparation:
zCheck if the washing machine is properly installed. (P. 24)
zTurn on the water faucet.
zWhen using Temp Setting, turn on both hot and cold water faucets.
• Operation panel of NA-F70G6
31
Timer preset 2
Set how many hours later
to nish operation. (P. 8)
z2 minutes after start, all
indications except turn off.
zTo conrm after the timer has
been set, press .
zTo cancel or change, press
.
zThe hours that can be set differ
depending on the program.
Press to select Hot/Warm/
Cold for washing. (P. 9)
Hot ← Warm ← Cold
Temp Setting
| ↑

Washing
15
3Start.
The pulsator moves without
water and measures the
amount of laundry
(approx. 5 seconds).
Water amount indication
(approx. 5 seconds)
Remaining time indication
zTo check the water amount
→Press “Water Level”.
4According to the water amount
indication
Put in detergent.
zApprox. 20 seconds after the
water amount is displayed,
water supply begins.
5Close the lid.
Operation ends with beeps.
After pressing “Start”
zYou can change the water level until
the end of the wash process.
zYou can change each of the
“Wash”, “Rinse” and “Spin”
operation contents until the end of
the wash process. Press “Pause”
beforehand.
zYou cannot change the program.

16
Washing Options
Bedding
Washable blankets
• Material: 100 % synthetic bre or
100 % cotton
• Weight: 4.2 kgor less
(King size bed)
• Blankets with a machine-
washable tag attached
zPut a blanket in the net and load it
in the tub.
The zipper part should face up.
(To prevent damage to the net)
Roll
NOTE
zUse liquid detergent.
zThe water amount indication shows
the maximum and cannot be
changed.
Delicate
Use this program to gently wash
delicate clothes and stylish garments.
Load laundry evenly.
zLoad lighter items rst and press
them from above.
zUse laundry nets for delicate
underwear only.
zAmount that can be washed at one
time:
Water Level Capacity
55 L 4.2 kg
47 L 3.0 kg
NOTE
zDo not use bleach.
zUse liquid delicate detergent.
zAfter operation ends, take out
clothes immediately. (To prevent
wrinkles and colour staining)
Wash / Rinse / Spin
Preparation:
Turn on the water faucet.
1
After loading laundry
Turn the power on.
2According to your purpose
Change process settings.
3After closing the lid
Start.
Operation ends with beeps.

Washing Options
17
Stain Master
Preparation:
Turn on the water faucet.
• Operation panel of NA-F70G6
1
After loading laundry
Turn the power on.
2Select a
“Stain Master”
program. (P. 10)
3Start.
4According to the water amount
indication
Put in detergent.
5Close the lid.
Operation ends with beeps.
NOTE
zAmount that can be washed at one
time: Max. 4.0 kg
13
zMaximum water amount: 55 L
zThe following pretreatments are
effective for heavily stained clothes.
• Hand wash them rst.
• Apply stain remover to stained
areas.
zSee “Laundry preparation and
check” before washing. (P. 7)
31
2

18
Air Dry (90 min)
Water is removed from clothes by the
air blown from the tub rotation.
Clothes that can be dried
• Material: Synthetic bre
• Weight: 2.0 kgor less
1After loading
clothes and closing
the lid
Turn the power on.
2Press.
3Start.
After 90 minutes, drying ends
with beeps.
NOTE
zClothes may not be sufciently
dried depending on the amount and
type of clothes, the temperature,
and the installation condition of the
washing machine.
zSince no heater is used for this
function, you may feel that clothes
are cold and half dry.
Washing Options (continued)
Cotton Eco
With the “Cotton Eco” cycle, the
washing machine consumes less
energy and water.
Preparation: Turn on both hot and
cold the water faucets.
(Default setting: Hot)
About Detergent
zWe recommend using high
efciency or low-sudsing detergent.
zFor better performance, it is
recommended to dissolve detergent
in 1 L of water at 35 °C and then pour
it around the inner wall of the tub.
zAdd detergent after the hot water ll
is completed. Opening the lid to add
detergent before hot water lling is
completed will alter the total amount
of hot water added, and hence
washing performance will change.
NOTE
zDo not use softener.
zThe water temperature setting is
xed to “Hot”.
zThe operation starts with the end of
hot water lled.
zIf “U13” appears, clothes in the
tub are out of balance. Follow
installation (P.28) to distribute the
clothes evenly, and close the lid.
zWe recommend leaving the
washing machine for at least 1 hour
between each use.

Washing Options Contents of Programs
19
Program Total time
(approx.) Wash Rinse Spin Temp Setting
Cotton 60 min 12 min 2 times 5 min
Hot /
Warm /
Cold
Quick Wash 35 min 3 min 2 times 3 min
Baby Care 65 min 12 min 2 times 7 min
Bedding 60 min 12 min 2 times 3 min
Soak 120 min *(Soak 60 min) +
12 min 2 times 5 min
Sweat 60 min 10 min 2 times 5 min
Mud 75 min 25 min 2 times 5 min
Soya/Sauce 105 min *(Soak 20 min) +
25 min 2 times 5 min
Delicate 45 min 9 min 2 times 1 min
Cold
Tub Hygiene 140 min *(Soak 60 min) +
12 min 2 times 30 min
Cotton Eco 110 min *(Soak 47 min) +
7 min 3 times 15 min Hot
* Remaining time of 99 minutes or less will be displayed.
NOTE
zTotal time is approximate.
(When the standard water supply rate is 15 L / min and the water
temperature is 28 ºC.)
zTotal time may increase depending on low water pressure, water temperature,
voltage, bad draining conditions, and the amount and type of clothes.
Contents of Programs

20
Convenient Functions
Cancelling buzzer
1
Pressing down,
press.
Then hold on for 3 seconds.
zTo reset, do the same
procedure.
Turning the tub by hand
If it is difcult to reach the detergent/
bleach inlet.
1
Turn the power on.
2When a clicking sound is heard
Turn the tub within
20 seconds.
Clockwise only
NOTE
zIf there is water in the tub, the tub
cannot be turned.
2 short
beeps
4 short
beeps
Setting Child Lock
To prevent children from falling into
the tub and drowning, if the lid is
opened while the washing machine
is operating, this function sounds a
buzzer until it is closed. Not closing it
within 10 seconds ushes the water
out.
zThis function does not lock the lid
and button operations.
zWhen water is drained forcibly,
“U 99” is displayed. (P. 28)
1After closing the lid
Turn the power on.
2Press and hold
for 5 seconds.
zTo cancel, do the same
procedure.
2 short
beeps
4 short
beeps
