Pandora DXL-0050L User manual

Pandora would like to thank you for choosing
our DXL-0050L service and security system
Pandora is a brand of Russian Experimental Engineering Factory, a full production cycle
electronics R&D facility. We design and produce car service-security systems for more than 10 years
and have reached a considerable success on domestic markets – biggest security system markets in
the world. Our systems are made to withstand severe weather conditions and criminal situation of
northern Eurasia.
Pandora DXL-0050L is a premium car service-security system, built for cars with on-board
voltage of 12V. It is a complex engineering solution which includes car security system, telemetry,
remote and automatic engine start and various service options, all accessible via RF control remote
that can replace your factory remote. This system is designed to be all-in-one car service and security
solution and requires no additional modules: it includes algorithmic keyless bypass that works with
many popular car models. For even more convenience, it allows remote control over Webasto or
Eberspaecher preheaters – and even sequential use for automatic engine start.
WARNING!
IT IS STRONGLY ADVISED TO HAVE PROFESSIONAL CAR MECHANIC INSTALLING
THE SYSTEM. CERTIFIED INSTALLERS ARE RARE OUTSIDE RUSSIA, BUT ANY CAR
ELECTRONICS INSTALLER SHOULD BE ABLE TO INSTALL PANDORA DXL0050L
USING INSTALLATION SCHEME IN THIS MANUAL AND ALARMSTUDIO SOFTWARE.
MOST FEATURES ARE HIGHLY DEPENDENT ON COMPETENT INSTALLATION.
OUR SYSTEMS ARE THOROUGHLY TESTED FOR QUALITY, SO IF A FEATURE FAILS
TO PRODUCE EXPECTED RESULTS, MOST LIKELY THE PROBLEM IS IN IMPROPER
INSTALLATION.
It is essential for systems functioning that you read and understand instructions in this manual.
Note that all radio devices are subject to interference, which could affect proper performance.
This device has limited external factors resistance. It should not be subjected to water beyond occasional splatter, or operated in
temperatures outside -40 to +80 oC range.
IMPORTANT! Note that this manual describes remote and manual functions for the
most part. Functionality of the system is vast and would require a book-sized manual to
fully describe. Instead we use a handy software named AlarmStudio that functions as both
programming tool and an extended installation & functionality manual. It requires Windows
and can be downloaded at pandorainfo.com
Product is in conformity with Electromagnetic Compatibility
Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC

2User manualPandora DXL-0050L service-security system
Table of contents
• System features 3
• System set 4
• Control remotes 5
• LED indicator signals 5
• Quick access functions of the main control remote 6
• Icons of remote 7
• Arming procedure 10
• Disarming procedure 10
• Emergency disarming 11
• Unlocking the trunk 12
• Locking/unlocking doors when the engine is running 12
• Car search function 13
• Delayed arming (Hands Free mode) 13
• PANIC mode 13
• CHECK mode, monitoring car parameters 14
• Event history 14
• Remote and automatic engine start 15
• Engine preheater 18
• Maintenance/valet mode 18
• System settings menu 19
• Remote sensor settings 20
• Leaving connection zone notification settings 21
• Wiring diagram 22
• Wiring description 24
• Silent mode of the remote 27
• Siren signal settings 27
• Time settings 28
• Changing the factory preset service PIN-code 28
• Checking the number of recorded remotes 29
• Replacing a battery in the remote 29
• Changing core settings 30
• Siren sounds and turn light signals 38
• Meaning of indicator LED colors 38
• Glossary of terms 39
• Warranty obligations 40
• Installation certificate 41
• Acceptance certificate 44
• Warranty card 44

3User manualPandora DXL-0050L service-security system
System features
2-way LCD remote
• Arming and disarming security system using separate buttons.
• Controls status of 10 independent security zones.
• Vibrating alert.
• 16 notification ringtones.
• Automatic LED lighting of the LCD.
• Vibration confirmation of the button press.
• AAA battery (1,5V) (not shipped with the system).
• Battery level indicator.
• Current time indication.
• Time synchronizes with the base unit for exact time stamp in the event history.
• Engine* and interior temperature, voltage indication.
• Prompt remote access to the settings of shock sensor.
• Prompt remote access to the settings of motion sensor.
• View event history with time and event stamps.
• Automatic control of RF coverage zone.
Base unit
• Dialog coding of control commands sent at a frequency of 868 MHz.
• Individual 128-bit encryption key.
• Event history with exact time stamps is stored in the base unit and is transferred to the remote
when it is in range.
• Can be complemented with BM-103/105 single-wire digital block relay.
• Built-in integral accelerometer for determining motion and shocks with adaptive processing
algorithm and sensitivity controls via the remote.
• Monitoring of on-board voltage.
• Separate inputs for hood and trunk sensors.
• Advanced processing of sensor data, eliminating false alarm possibilities.
• Precision measurement of interior and engine* temperature, displayed on the remote.
• Sequential unlocking of the doors.
• Arming when the engine is running.
• Automatic arming.
• Registers delay for interior lighting when arming.
• Software updates via built-in micro-USB socket.
* Engine temperature indication is available only if temperature sensor is connected. The sensor availability depends
on the system set.

4Pandora DXL-0050L service-security system
* Triggering of the warning level of shock sensor is not saved in the event history.
System set
1. Base unit.........................................................................................................................................................1
2. Main control remote with LCD...............................................................................................................1
3. Cover of main control remote.................................................................................................................1
4. Supplementary control remote without LCD...................................................................................1
5. Main cable.....................................................................................................................................................1
6. Cable with three-colored light indicator............................................................................................1
7. Cable with VALET button.........................................................................................................................1
8. LIN interface wire........................................................................................................................................1
9. Fastening kit.................................................................................................................................................1
10. User installation manual with wiring diagram.................................................................................1
11. Relay automatic start module................................................................................................................1
12. Temperature sensor...................................................................................................................................1
13. Packaging.............................................................................................................................................1
Manufacturer reserves the right to change set and construction of the product to improve its technological
and operational parameters without notification.
Car security zones
Pandora DXL-0050L service-security system guards following independent zones with
corresponding zone notifications on the remote and recording alarms into the event history:
• car doors perimeter (separate for every door)
• front hood triggers
• trunk triggers
• ignition trigger
• brake pedal button
• triggering of the shock sensor (warning level)*
• triggering of the shock sensor (alarm level)
• triggering of the motion sensor
• triggering of the tilt sensor
• critically low on-board voltage
All* alarm events are recorded into system’s non-volatile memory with coordinates, date and
exact time the event happened. Event history can be read using a remote.

5User manualPandora DXL-0050L service-security system
Control remotes
Button 1 Button 2 Button 3Button 1
Button 2
Button
3
Ae
rial
SEND indicator
ALARM indicator LCD
SEND
indicator
Two-way remote is the main mean of control over the system. For easily distinguishable notifications
the remote uses 16 ringtones. Each ringtone matches particular event.
Remote has flashing
‘SEND’ and ‘ ALARM’ LED indicators for additional information.
The remote is already paired with the base unit and fully operational when shipped. To switch on
the remote, press and hold button for 3 seconds. ‘REMOTE ON’ ringtone will play. Pressing and
holding this button again for 3 seconds will cause the remote to switch off.
WARNING!
ALL CONTROL COMMANDS ARE TRANSMITTED VIA RADIO CHANNEL, FOR
MAXIMUM EFFECTIVENESS AND RANGE IT IS RECOMMENDED NOT TO SHIELD
AERIAL AREA SEE PICTURE WITH FINGERS WHEN USING A REMOTE.
WARNING!
REMOTE IS A UNIFIED CONTROL DEVICE. REMOTE CONTROL FUNCTIONS DEPEND
ON SECURITY SYSTEM MODEL.
Main control remote with LCD Supplementary control remote
LED indicator signals
Green Send indicator
• Flashes occasionally if there is a connection.
• Goes dark when there is no connection.
Red Alarm indicator
• Flashes frequently if there is any notification.
• Flashes occasionally when there is no connection.

6Pandora DXL-0050L service-security system
System disarmed System armed
(no alarm events)
Engine is running Engine is stopped
(short press) Lock doors without
arming
Arming with sound
conrmation
Search mode – car will
ash turn signals and
sound horn for 5 seconds
(1 sec.) Arming without sound
conrmation
Search mode – car will
ash turn signals without
any sounds for 5 seconds
(2 sec.) Switch on ignition
support
(3 sec.) Switch on programmed
neutral Remote engine start
(short press) Unlock doors Unlock doors Disarming with sound
conrmation
(1 sec.) Unlock doors Disarming without sound
conrmation
(>2 sec.) Switch o ignition
support
Switch o ignition when
turbo timer, remote or
automatic engine start
is active
(short press) Switch on LCD lighting (available only on the remote with LCD)
(1 sec.) Unlock trunk (CH1)
(2 sec.) Switch on/o timer channel (CH2)
Switch on/o engine preheater
(3 sec.) Switch on/o remote (available only on the remote with LCD)
+ (short press) PANIC mode
+ (short press)
Arming when the engine
is running with sound
conrmation
Arming in 30 seconds
(Hands Free mode) with
sound notication
+ (1 sec.)
Arming when the engine
is running without sound
conrmation
Arming in 30 seconds
(Hands Free mode) without
sound notication
Quick access functions of the main control remote

7User manualPandora DXL-0050L service-security system
Icons of remote
1. Sending command indicator
2. Flashes if there is no connection to the base unit
3. GSM connection indicator (for systems that are equipped with GSM-modem)
4.
GPS receiver. The icon will be lit if the GPS receiver is switched on and receiving
coordinates of the car. The icon ashes if it is not possible to receive the
coordinates of the car
5. Security mode status (armed/disarmed)
6. Tilt sensor security zone
1
19 20 21 22 23 24 25 26 27 28 29
15
16
17
18
2 3 4 5 6 7 8 9 10 11 13 1412

8Pandora DXL-0050L service-security system
7. Door security zone. Separate for each door
8. Fuel left
9. Front hood security zone
10. Engine operation icon
11. Motion sensor security zone
12. Car battery voltage, voltage security zone
13. Interior, engine and exterior air temperature
14. Numeric indicator. Displays current time
15. Light signalization (using marker lights, turn signals)
16. Trunk security zone
17. Immobilizer
18. Remote battery level
19. Original security system status

9User manualPandora DXL-0050L service-security system
20. Handbrake/neutral indicator, brake pedal security zone
21. Ignition, ignition security zone
22.
Shock sensor security zone
Warning level of the sensor
Alarm level of the sensor
Warning level zone monitoring disabled
Shock sensor monitoring disabled
23.
Silent mode of the system
Warning signals of the system disabled
All sound signals disabled
24. Engine preheater
25. System settings
26. Timer channels
27. Silent mode of the remote (MUTE)
28. Check current state and enter event history
28. Car maintenance mode

10 Pandora DXL-0050L service-security system
Arming procedure
short
press
doors locking
system arming 1 ash
1 ash
press
and
hold 1 sec.
~~
1x
Arming the system allows monitoring of all security zones, locks the doors and blocks the engine.
To arm the system when the engine is stopped, shortly press button on the remote. The siren
will sound and turn signals will flash once.The remote will play ‘ARMING’ringtone and security mode
status icon (the lock) will change to:
For arming without sound confirmation press for more than 1 second. If hood or trunk was
open when arming doors, the siren will sound 4 short signals instead of 1, turn signals will flash 4
times, remote will play ‘WARNING!’ ringtone (after ‘ARMING’ ringtone) and will show troubled zone.
This zone sensor will be disabled at that moment. Sensor will be armed again in 15 seconds after the
zone was set right.
For emergency arming when the ignition is switched off, press and hold VALET button for 3 sec-
onds until the system confirms with red LED indicator flash. A car will be armed in 30 seconds.
Disarming procedure
short
press
press
and
hold 1 sec.
doors unlocking
system disarming 2 ashes
2 ashes
~~
2x
To disarm the system, shortly press button on the remote. You will hear 2 short siren sounds
and will see 2 flashes of turn signals. The remote will play ‘DISARMING’ringtone and security mode
status icon will change to:
For disarming without sound confirmation press button for more than 1 second.

11User manual
If there were new alarming events during the time system was armed, siren will sound 4 times,
and turn signals will flash 4 times, the remote will sound ‘WARNING!’ringtone (after ‘DISARMING’
ringtone) and will indicate zones triggered. All recent alarm events can be viewed in the event history.
Emergency disarming
In case you cannot disarm the system using a remote, use special service PIN-code:
Factory preset PIN-code is 1-1-1-1. Use VALET button to input PIN-code.
Entering PIN-code is available only if the ignition is switched
off.
1. Using VALET button, input the first digit of the code
(press the button a number of times, equal to the first digit;
pauses between presses should not exceed 1 second). The
system will confirm with red LED indicator flash.
2. Use the same procedure to input the second, third and fourth digit. Every input will be
confirmed with red LED flash.
3. The system will confirm correct PIN-code with red and green flashes of LED indicator. If the input
was incorrect, it will be indicated with long red flash. New input can be attempted after 5 seconds.
4. If the system was armed, it will be disarmed after entering the correct PIN-code.
If the system is disarmed and the engine is stopped, after entering PIN-code the system will enter
programming mode.
WARNING!
FACTORY PRESET PINCODE IS 1111. PLEASE REMEMBER TO CHANGE PINCODE,
SEE PAGE 28.
VALET
button
LED
indicator

12 Pandora DXL-0050L service-security system
Unlocking the trunk
press
and hold
1 sec.
~~
To independently unlock the trunk, no matter if the system is armed or not, press button and
hold it for 1 second.
If the system is armed when this action is performed, the trunk will be disarmed, shock and
supplementary sensors of the trunk will be disabled. All the other security zones will remain armed.
If the trunk was not opened in 15 seconds after using ‘unlock trunk’command, the system will lock
it again, enable sensors and arm trunk security zone.
Locking/unlocking doors when the engine is running
The system controls doors locking when the engine is running. To lock doors, shortly press
arming button, to unlock doors, press disarming button.
There is an automatic movement lock mode that will lock the doors at the car movement and will
unlock them when the ignition is being switched off. In no less than 5 seconds after the ignition was
switched on, the doors will be locked automatically when the car starts moving, and unlocked when
the ignition will be switched off (programmable). If any door was opened after the ignition had been
switched on, automatic locking will be disabled to prevent locking the keys inside the car.
doors locking
short
press
doors unlocking
OFF
ON
ACC

13User manualPandora DXL-0050L service-security system
Car search function
short
press
5 ashes
5 ashes
press
and hold
1 sec.
~~
1x
To easily find your car on a massive parking, shortly press when the car is armed. The system
will sound the siren and flash turn signals 5 times in a row.
To search for car without sound confirmation, press and hold button for more than 1 second.
Delayed arming (Hands Free mode)
short press
doors locking
system arming
1 ash
1 ash
press and hold
1 sec.
30 sec. ~~
1x
+
If when leaving the car you cannot arm it using a remote (you have your hands full), you can use
delayed arming.
To activate this mode, shortly press and simultaneously. LED indicator will turn red, the
system will lock doors and will arm in 30 seconds, the siren will sound and turn signals will flash
once, indicating that the mode is triggered.
To activate this mode without sound confirmation, press and hold both and for more
than 1 second until the sound and vibration signal.
To cancel delayed arming when it is triggered, simply press .
PANIC mode
If your car or you are in danger and you want to draw attention to your car, you can use PANIC
mode. In this mode the siren will sound and turn signals will flash repeatedly for 30 seconds. To
trigger PANIC mode, press and simultaneously. To switch it off, press either or .

14 Pandora DXL-0050L service-security system
+ lights 30 sec.
short press ~~
+
CHECK mode, monitoring car parameters
short press
Engine
temperatur
e
~~
select
with presses
Interior
temperatur
e
Outside
temperatur
e
To receive information about engine temperature, interior temperature and on-board voltage,
press button, select icon and shortly press button.
For 10 seconds, numeric indicator will be sequentially showing interior temperature ( ),
engine temperature ( ) and battery voltage ( ). To exit this mode, shortly press
button, otherwise it will end automatically in 10 seconds.
NOTE: Temperature will only be shown if temperature sensor is connected. The sensor availability depends
on the system set. Fuel level and outside temperature indication is available only if there is some information
in CAN-bus.
Event history
short press
~~
select
with presses
Event 1
Event 48
To access event history into the system’s memory, press button and select icon and shortly
press button.
Navigate several last events using (forward) and (back). Events are displayed by showing
time of the events and flashing corresponding indicators. To exit this mode, press and hold for 1
second.

15User manual
Remote and automatic engine start
The system allows for remote engine start using remote engine start command or automatic
engine start using preconfigured automatic engine start function. Remote start can be used to heat
engine and interior, charge battery or to cool the interior with air conditioning.
Remote and automatic start can only be used when the system is armed.
If the car has manual transmission, automatic start will only occur if programmed neutral
procedure was followed when the car was arming.
Remote and automatic engine start on automatic transmission cars will only occur if transmission
selector lever was left in a ‘P’ position.
When using remote and automatic engine start functions, make sure that the car is secured with
handbrake or some other means of fixating the car on a parking position.
While system is in remote and automatic start mode, it keeps performing all security functions
save for shock sensor, which will have lower sensitivity during engine start and for a short time after
while algorithm adjusts to the new normal. To compensate, motion sensor sensitivity, responsiveness
and range will be increased. If any security zone will be triggered, the engine will be immediately
stopped and alarm mode will be entered. Herewith all immobilizer functions will be activated.
Programmable neutral procedure (for cars with manual transmission)
xate the car
using a handbrakeleave the car, close the doors
short press
‘engine stop’
ringtone
in 3 sec. the engine will
be stopped, the system
is ready to perform
remote start
OFF
ON
ACC
~~
If you are planning to use remote and automatic engine start on a car with manual transmission,
you will need to perform following actions before arming:
1. While the engine is running, fixate the car with the handbrake and put manual transmission
lever (shift-stick) to the neutral position.

16 Pandora DXL-0050L service-security system
2. Turn the key in the ignition lock to the OFF position (the engine should still be running) and
take it out of the lock.
3. Leave the car, close the doors.
4. Press button to arm the car and lock the doors. On LCD remote the engine operation icon
will be spinning and security mode status icon will light.
5. The engine will be stopped. Now the system is ready to perform remote and automatic engine start.
This procedure ensures that whenever remote start occurs, your car will not move by itself.
Remote engine start
If the system is prepared for remote start, to execute it, press and hold for 3 seconds. Sound
signal will confirm the command, LCD will show crossed out shock sensor icon and flashing
engine operation icon signifying preparation to the engine start. In a few seconds, the engine
will be started, the remote will play ‘ENGINE START’ ringtone and show spinning engine operation
icon .
Engine operation duration depends on system settings – either heating time or threshold temperature
for engine stop.
3 ashes
‘engine
start’ ringtone
press and hold
3 sec. preparing
to start engine start ~~
To remotely stop the engine while it performs heating, press and hold for 2 or more seconds.
The engine will be immediately stopped and it will be confirmed by remote playing of ‘ENGINE STOP’
ringtone and engine operation icon fading.
The remote will give notification 1 minute before designated engine stop, icon will flash and
‘ENGINE STOP IN 1 MINUTE’ringtone will play every 10 seconds.
‘engine stop’
ringtone
press and hold
2 sec. engine stop
~~
‘engine start’
ringtone
~~

17User manualPandora DXL-0050L service-security system
If the engine was started using remote or automatic start, remote engine start command will extend
its operation period by 10 minutes. This procedure can be repeated multiple times.
Automatic engine start
The system allows setting up modes of automatic engine start and stop. Synchronized real-time
clock on the remote and base unit and other autonomous system settings allow many engine start
options without needing to have the remote in command radio range.
WARNING!
ONLY ENABLE REMOTE START IF YOUR LOCAL LEGISLATION ALLOWS DRIVERLESS
CARS TO HAVE WORKING ENGINE.
2
5
8
4
7
3
6
1
select
with presses
On
O
set autostart
hours minutes
set temperature
increase decrease
set heating time
On
O
On
O
daily timer
autostart by temperature
periodic heating
increase decrease
set stop temperature
On
O
engine stop by temperature
increase decrease
Save selected settings
Cancel selected settings
Return to the beginning of settings
NOTE: If you have not saved new settings, remote and automatic
engine start settings will remain the same as before.
Automatic start and engine work conditions programming is done using LCD remote. Select
icon by pressing button and press button to enter remote start functions menu. This menu has
8 sub-levels that can be rotated by pressing . Sub-level values are changed using and .
When changing settings are done, the values should be saved. To do this, move to the ‘send’ sub-
level using presses. Press button to save selected settings. The changes will be sent to the base

18 Pandora DXL-0050L service-security system
unit, double short sound signal will confirm it.
NOTE: If you have not saved new settings, remote and automatic engine start settings will remain the same
as before.
- To move to the settings of the next parameter, shortly press .
- To exit remote start settings, press and hold for 1 second (or the menu will be exited in 10 seconds).
All unsaved settings will thus be lost.
NOTE: Engine start via temperature is available only if temperature sensor is connected. The sensor
availability depends on the system set.
Engine preheater
To switch on engine preheater, select icon by pressing button and then shortly press
button. Sound notification will confirm reception of the command. If preheater monitoring is con-
nected and enabled, LCD will display icon during engine preheater operation.
select
with presses short press
~~
Engine preheater started
To switch off engine preheater using a remote, select icon by pressing button and confirm
by shortly pressing button. Sound notification will confirm reception of command. LCD will
display icon.
NOTE: To start/stop the engine preheater immediately, press and hold button for 2 seconds. Available
for the current base unit software.
Maintenance/valet mode
short press
select
with presses
Valet mode active
~~
1

19User manualPandora DXL-0050L service-security system
It is recommended to put system into maintenance mode before handing it to the car service or
valet parking. When this mode is switched on, security system stops interfering with built-in electron-
ics and disables all functions to ease maintenance or parking. Moreover, you will not have to leave the
remote to the valet or the mechanic. Disabling valet mode is not possible without using the remote.
This feature is implemented to prevent recording additional remotes during maintenance without
the owner knowing.
To activate maintenance mode while the engine is running, select icon by pressing button
and confirm by shortly pressing button. To exit maintenance mode, select icon by pressing
button and confirm by shortly pressing button.
System settings menu
select
with presses press and hold 1 sec.
short press
Shock sensor settings
short press
Additional sensor settings*
short press
Motion sensor sensitivity
settings
short press
Tilt sensor sensitivity settings
Switch On/O GSM-interface*
short press
Leaving connection zone
notication settings
short press
Siren operation settings
Main system parameters and settings can be changed using LCD remote. To enter the settings
menu, select icon by pressing button and confirm by pressing button for 1 second. To
* Additional sensors control and GSM interface are not supported by this model.

20 Pandora DXL-0050L service-security system
cycle between sub-levels of settings, use button, to enter sub-level of settings, press and hold
for 1 second.
If there is no connection to the base unit, LCD will display‘Err’.
Remote sensor settings
Shock sensor control and sensitivity settings
Control settings
press
and hold
1 sec.
press
and hold
1 sec.
or
Shock sensor
enable
Shock sensor
disable
Control over warning
area of the shock
sensor disabled
increase
decrease
Save
settings
short
press short press
Warning levelAlarm level
increase
decrease
Sensitivity settings
For prompt remote adjustment of alarm and warning levels of the shock sensor enter the settings
menu, select icon with button presses and press button for 1 second. Press button to
cycle between control and sensitivity settings of warning and alarm sensor levels.
icon and left part of the numeric indicator will flash indicating that alarm level of shock
sensor is being adjusted. Short presses of button will increase the sensitivity of the alarm level (i.e.
sensor will trigger from smaller impacts), short presses of button will decrease the sensitivity of
the alarm level of the shock sensor.
Short presses of button will switch between sensitivity settings of warning and alarm levels of
the shock sensor. To save the new sensitivity values of the shock sensor, shortly press . To exit this
mode without saving, press and hold button for 1 second, otherwise it will end automatically in 10
seconds.
Max sensitivity value of warning and alarm level of sensors is 50.
