Pandora Light User manual

Pandora would like to thank you for
choosing our service-security system
Pandora Light – is a car service-security system built for cars with on-board voltage of 12V. It
is a complex engineering solution, which includes unique and modern technological software and
hardware solutions.
When building the Pandora Light we were using the most up-to-date electronics from world’s
best manufacturers. The device is built using high-precision mounting and control machinery, thus
we guarantee highest possible quality, reliability and stable technical characteristics for the whole
operation period.
Pandora Light has a cryptographically strong authorization code with unique dialog algorithm
and individual 128 bit encryption key on every device. We guarantee 100% protection form electronic
hacking for the whole operation period.
The system is built for your convenience: it’s ergonomic, reliable, has the highest security and
service characteristics, 3 years unconditional warranty and free service and support on the territory
of Russian Federation and nearest states. We are happy to provide any support we can – feel free to
use our online support.
WARNING! It is strongly advised to have professional car mechanic installing the system.
Any car electronics installer should be able to install Pandora Light using installation
scheme in this manual and Alarm Studio software. Most features are highly dependent
on competent installation. Our systems are thoroughly tested for quality, so if a feature fails to
produce expected result, most likely the problem is in improper installation.
This device has limited external factors resistance. It should not be subjected to water beyond occasional splatter, or operated in
temperatures outside -40 to +80° C range. All system components must be installed only in a car interior.
Our web site: www.pandorainfo.com
Customer support: [email protected]om
Product is in conformity with Electromagnetic Compatibility
Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC

2Security-service system Pandora Light
Table of contents
System features 4
Remote control 4
Base unit 4
Security zones 5
System set 5
Remote control 6
LED indicator signals 6
Quick access functions of the remote control 7
Icons of the remote control 9
Arming procedure 10
Disarming procedure 10
Unlocking a trunk 11
Locking/unlocking doors when ignition is on 11
Car search function 12
Delayed arming 12
Panic mode 13
Remote and automatic engine start 13
Program neutral procedure (reservation mode) 14
Remote engine start 15
Code immobilizer function (pin-to-drive) 16
System settings menu 16
Engine heater 18
Time channels 18
Check car status 20
Event history 20
Automatic engine start 22
Wires description 24
Wiring diagram and connectors pin-out 26

3
User manual
Sensor settings 30
Shock sensor settings 30
Motion sensor settings 32
Tilt sensor settings 32
Siren signal settings 33
Sound notification settings 33
Radio channel control settings 34
Service/Valet mode 35
Time settings 35
Alarm clock settings 36
Replacing a battery in the remote control 36
Control over the system in case of emergency 37
Programming the system 39
Entering the programming mode 39
Exiting the programming mode 39
Preparing to program the system using a computer 40
Updating firmware 40
Programming using the VALET button 40
Additional information 46
Siren sound and light signalization 46
Meaning of the LED indicator signals 46
Checking the number of recorded remote controls 47
System modules layout 48
Warranty obligations 49
Installation certificate 50
Acceptance certificate 51
Warranty card 51

4Security-service system Pandora Light
SYSTEM FEATURES
Remote control
• Separate buttons for arming and disarming.
• 14 independent security zones control.
• Vibrating alert.
• 16 notifications ringtones.
• LED lighting of the LCD.
• Vibration confirmation of the button presses.
•  battery (1,5 V).
• Battery level indicator.
• Current time indication.
• Time synchronization with the base unit for exact time stamp in the event history.
• Engine and interior temperature, car battery voltage, fuel level indication.
• Prompt remote adjustment of the shock, motion, tilt sensors sensitivity.
• Event history with time and event stamps.
• Automatic control of RF coverage zone.
Base unit
• Individual PIN-code for disarming
• Dialog coding of control commands sent at a frequency of 868 MHz.
• Individual 128-bit encryption key.
• Event history with exact time stamps is stored in the base unit and is transferred to the remote
when it is in the range.
• Monitoring of on-board voltage.
• Built-in integral accelerometer for determining motion and shocks with adaptive processing
algorithm and sensitivity controls via the remote.
• Separate inputs for hood and trunk sensors..
• Advanced processing of sensor data, eliminating false alarm possibilities.
• Built in temperature sensor, additional engine temperature sensor.
• Sequential unlocking of the doors.
• Arming when the engine is running.
• Automatic arming.
• Can be complemented with BM-103/105 single-wire digital block relay.
• Software updates via built-in micro-USB socket.

5
User manual
Car security zones
Pandora Light service-security system guards following independent zones with corresponding zone
notifications on the remote and recording alarms into the event history:
• doors
• front hood
• trunk
• ignition
• brake pedal
• triggering of the shock sensor (warning level)
• triggering of the shock sensor (alarm level)
• triggering of the motion sensor
• triggering of the tilt sensor
• critically low in-board voltage
• OE car alarm status (via CAN-bus)
• triggering of the additional sensor (warning level)
• triggering of the additional sensor (alarm level)
SYSTEM SET
1. Base unit 1
2. Remote control 1
3. External VALET button 1
4. User manual 1
5. Owner’s plastic card 1
6. Main cable of the base unit 1
7. LIN-interface cable 1
8. IMMO-KEY-interface cable 1
9. Fastening kit 1
10. Relay module 1
11. Packaging 1
ATTENTION! The manufacturer reserves the right to change the system set and
construction of the product to improve its technological and operational parameters
without notication.

6Security-service system Pandora Light
REMOTE CONTROL
Two-way remote is the main mean of control over the system.
For easily distinguishable notifications the remote uses 16 ringtones. Each ringtone matches
particular event. Remote has flashing LED indicators for additional information.
ATTENTION! All control commands are transmitted via radio channel, for maximum
eectiveness and range it is recommended not to shield aerial area (see picture) with
ngers when using a remote control.
LED indicator signals
Green indicator:
• Flashes if there is a connection with the base unit
• Goes dark when there is no connection with the base unit.
Red indicator:
• Flashes frequently if there is any notification
• Flashes occasionally when there is no connection
ATTENTION! A remote control is a unied control device. Its functions
depend on security system model.
Aerial
SEND/ALARM
indicator
OLED-
display
Button 1
Button 2
Button 3
12
12 0B 48

7
User manual
Quick access functions of the remote control
System is disarmed System is armed
(no alarm events)
Ignition is switched on Ignition is switched o
(short press)
Lock doors without
arming
Arming with sound
confrmation
Search mode – flashes of turn
signals with
sound signals for 5 seconds
(1 sec.)
Arming without sound
confrmation
Search mode – flashes of turn
signals without
sound signals for 5 seconds
(2 sec.)
Switch on «Ignition
maintenance» mode
(3 sec.)
Switch on «Programmed
neutral» Remote engine start
(short press) Unlock doors Unlock doors Disarming with sound
conrmation
(1 sec.) Unlock doors Disarming without sound
conrmation
(> 2 sec)
Switch o «Ignition
maintenance» mode
Switch o the ignition during
remote or automatic engine
start procedure.
(short press) Switch on LCD lighting (available only on the remote with LCD)

8Security-service system Pandora Light
(1 sec.) Unlock trunk (CH1)
(2 sec.) Switch on/o timer channel (CH2)
(3 sec.) Switch on/o remote (available only on the remote with LCD)
+
(short press) PANIC mode
+
(short press)
Arming when the
engine is running with
sound conrmation
Arming in 30 seconds
With sound notication
+
(1 sec.)
Arming when the
engine is running with
sound conrmation
Arming in 30 seconds
without sound
notifcation

9
User manual
Icons of the remote control
P
STOP
Flashing when command
sending
Security mode status
Remote control
battery level
Numeric indicator displays
current time
Battery voltage
Interior temperature
Engine
temperature*
Fuel level*
Alarm clock
Shock sensor security zone
Warning level of the sensor;
Alarm level of the sensor
12 48
12°
0°
0
Tilt sensor
Security zone
Motion sensor security zone
Doors security zone
Front hood
security zone
Trunk
Security zone
Ignition
Security zone
Handbrake/ neutral indicator,
Brake pedal security zone
Low voltage security zone
Engine operation icon
Engine is stopped
12.0V
* Separate display indication of doors, original alarm status,
fuel level depend on information in CAN-bus digital protocol
of specific car

10 Security-service system Pandora Light
Arming procedure
Arming the system allows monitoring of all security zones, locks the doors and blocks the engine.
To arm the system when the engine is stopped, shortly press button on the remote control.
The siren will emit one sound signal and turn signals will flash once. The remote control will play
“ARMING” ringtone and security mode status icon (the lock) will change to
~~
short press doors locking
system arming 1 ash
1 ash
1x
press
and hold
for 1 sec.
For arming without sound confirmation press for more than 1 second.
If when arming doors, hood or trunk were open, the siren will sound 4 short signals instead of 1,
turn signals will flash 4 times, remote will play“WARNING!”ringtone (after“ARMING”ringtone) and will
show troubled zone. This zone sensor will be disabled at that moment. Sensor will be armed again in
15 seconds after the zone was set right.
For emergency arming when ignition is switched off, press and hold the VALET button for 3
seconds until the system confirms with red LED indicator flash. A car will be armed in 30 seconds.
Disarming procedure
To disarm the system, shortly press button on the remote control. You will hear 2 short siren
sounds and will see 2 flashes of turn signals. The remote will play “DISARMING” ringtone and security
mode status icon will change to:
~~
short
press
press
and hold
for 1 sec.
doors unlocking
system disarming 2 ashes
2 ashes
2x
For disarming without sound confirmation press button for more than 1 second.

11
User manual
If there were new alarming events during the time system was armed, siren will sound 4 times and
turn signals will flash 4 times, the remote control will sound “WARNING!” ringtone (after “DISARMING”
ringtone) and will indicate zones triggered. All recent alarm events can be viewed in the event history.
Unlocking a trunk
To independently unlock the trunk, no matter if the system is armed or not, press button and hold
it for 1 second.
Press
and hold
for 1 sec.
If the system is armed when this action is performed, the trunk will be disarmed, shock and
supplementary sensors will be disabled. All the other security zones will remain armed.
If the trunk was not opened in 15 seconds after using «unlock trunk» command, the system will
lock it again, enable sensors and arm trunk security zone. This will be indicated with 1 flash of turn
signals.
Locking/unlocking doors when ignition is on
The system controls doors locking when the ignition is on. Shortly press lock button to lock
doors. Shortly press unlock button to unlock doors.
OFF
ON
ACC
doors locking
short
press
doors unlocking
There is an automatic movement lock mode that will lock the doors at the car movement or on
switching on the ignition. Doors will be unlocked after the ignition is switched off. There is an option

12 Security-service system Pandora Light
in the settings that allows to prohibit automatic unlocking on switching off the ignition.
When using doors locking mode on the car movement start, the system will detect car moving
and perform doors locking (it depends on motion sensor sensitivity settings).
When using doors locking mode when switching on the ignition, in no less than 5 seconds after
the ignition was switched on, the doors will be locked automatically. If any door was opened after
the ignition had been switched on, automatic locking will be disabled to prevent locking the keys
inside the car.
Car search function
To easily find your car on a massive parking, shortly press button when the car is armed. The
system will sound the siren and flash turn signals 5 times in a row.
short
press
5 ashes
5 ashes
1x
press
and hold
for 1 sec.
To search for car without sound confirmation, press and hold button for more than 1
second.
Delayed arming
If when leaving the car you cannot arm it using a remote control (you have your hands full), you can
use delayed arming.
To activate this mode, shortly press and buttons simultaneously. The LED indicator will
turn red, the system will lock doors and will arm in 30 seconds, the siren will sound and turn signals
will flash once, indicating that the mode is triggered.
To activate this mode without sound confirmation, press and hold both and buttons for
1 second until the sound and vibration signal.

13
User manual
~~
short press
Doors locking,
system arming
1 ash
1x
press and
hold for 1 sec. 1 ash
30 sec.
+
To cancel delayed arming when it is triggered, simply press button.
Panic mode
If your car or you are in danger and you want to draw attention to your car, you can use PANIC mode.
In this mode the siren will sound and turn signals will flash repeatedly for 30 seconds. To trigger PANIC
mode, press and buttons simultaneously. To switch it off, press either or
button.
short press + lights 30 sec
+
Remote and automatic engine start
The system allows for remote engine start using remote engine start command or automatic engine
start using preconfigured automatic engine start function. Remote start can be used to heat engine
and interior, charge battery or to cool the interior with air conditioning.
Remote and automatic start can only be used when the system is armed. If the car has manual
transmission, remote or automatic start will only occur if the program neutral procedure (reservation
mode) was followed when the car was arming. Remote and automatic engine start on automatic
transmission cars will only occur, if transmission selector lever was left in the“P” position.
When using remote and automatic engine start functions, make sure that the car is secured with
handbrake or some other means of fixaing the car on a parking position.
While system is in remote and automatic start mode, it keeps performing all security functions
of all of the security zones excluding shock sensor. To compensate, motion sensor sensitivity and

14 Security-service system Pandora Light
responsiveness will be increased. If any security zone will be triggered, the engine will be immediately
stopped and alarm mode will be entered. Herewith all engine blocking functions will be activated.
Program neutral procedure (reservation mode)
(for cars with manual transmission)
If you are planning to use remote and automatic engine start on cars with manual transmission,
before arming you will need to perform following actions:
1. While ignition is on and engine is running, fixate the car with the handbrake and put the gear
lever to the neutral position. Program neutral procedure will be switched on automatically (it depends
on the system settings) or press and hold button for 3 seconds to forced switch on this program.
2. Turn the key in the ignition lock to the OFF position (the engine should still be running) and
take it out of the lock.
3. Leave the car, close the doors.
4. Press button to arm the car and lock the doors. The engine operation icon will be
spinning on LCD remote and security mode status icon will be shown.
5. The engine will be stopped. Now the system is ready to perform remote and automatic engine
start.
xate the car using
a handbrake leave the car, close the doors
OFF
ON
ACC
short
press
«engine stop»
ringtone
~~
in 3 sec.,
the engine will be stopped,
the system is ready
to perform remote start

15
User manual
Remote engine start
If the system is prepared for remote start, to execute it, press and hold button for 3 seconds.
Sound signal will confirm the command, LCD will show flashing engine operation icon signifying
preparation to the engine start. In a few seconds the engine will be started, the remote will play
“ENGINE START” ringtone and show spinning engine operation icon .
3 ashes
«Engine start»
ringtone
press and hold
for 3 sec. preparing
to start
engine start ~~
Engine operation duration depends on system settings – either heating time or threshold
temperature for engine stop.
To remotely stop the engine while it performs heating, press and hold button for 2 or more
seconds. The engine will be immediately stopped and it will be confirmed by the remote playing
“ENGINE STOP” ringtone and engine operation icon fading
«Engine stop»
ringtone
press
and hold
for 2 sec. engine stop
~~
«Engine start»
ringtone ~~
The remote will give notification 1 minute before designated engine stop: icon will flash
and “engine stop in 1 minute” ringtone will play every 10 seconds. Sending “Remote engine start”
command will extend its operation period by 10 minutes. This procedure can be repeated multiple
times.

16 Security-service system Pandora Light
CODE IMMOBILIZER FUNCTION PINTODRIVE
Code immobilizer (pin-to-drive) is a function that allows disarming, disabling blocking and controlling
timer channels using original vehicle controls (button, lever or pedal).
To enter the immobilizer code, switch on the ignition and press a programmed button a number
of times equals to the first digit. Pauses between presses should not exceed 1 second. More than 1
second pause will be interpreted as the start of the next digit input. The immobilizer code can consist
max of 4 digits from 1 to 9.
After entering a correct immobilizer code, depending on the settings, either the engine blocking
will be disabled or a programmed time channel will be activated or the system will be disarmed. It is
required to make additional connections and settings to use this function
Additional settings or additional connections are required for the code immobilizer
function.
SYSTEM SETTINS MENU
Enter the main menu with button short press. To switch between menu sections shortly press
button .
entering settings menu
engine
preheater
12 48
0
engine
preheater:
enabled
Engine
preheater:
disabled
remote start
settings
system
controls
CHECK
channel
controls
1 2 3
4 5 6
78 9
remote start
settings
system
controls
CHECK
channel
controls
1 2 3
4 5 6
78 9
remote start
settings
system
controls
CHECK
channel
controls
1 2 3
4 5 6
78 9
• Control over engine preheater
• Control over timer channels
• Control over car status, view event history
• Remote and automatic engine start adjusting

17
User manual
sounds
disabled
sounds
enabled
sounds
siren
settings
siren
settings
siren
settings
siren
sounds
• Sensors adjusting
• siren signals adjusting
sensors
adjusting
* The function is not available in this model
• Sound notifications of the remote control
• Notifications on loss of radio signal
• Anti-hi-jack mode*
• Maintenance mode of the car
• Time setting
• Alarm clock setting
• Alarm clock time adjusting
Exit settings menu
To exit menu, press and hold button for
1 second.
valet mode
disabled
Valet mode
valet mode
enabled
14 45
06 30
будильник
включен
будильник
выключен
будильник
sounds
disabled
sounds
enabled
sounds
siren
settings
siren
settings
siren
settings
siren
sounds
14 45
06 30
alarm clock
enabled
alarm clock
disabled
alarm clock
connect. lost:
ringtone
connect. lost:
alarm
connect. lost:
no sound
anti-hi-jack
противоразбой
выключен
14 45
06 30
будильник
включен
будильник
выключен
будильник

18 Security-service system Pandora Light
Engine heater
To switch on engine preheater, select “ENGINE HEATER MENU” and shortly press button. To
switch off preheater, shortly press button. If preheater monitoring is enabled, LCD will display
con during engine preheater operation.
engine
preheater
12 48
0
engine
preheater:
enabled
Engine
preheater:
disabled
engine
preheater
12 48
0
engine
preheater:
enabled
Engine
preheater:
disabled
Preheater operation is disabled
Preheater operation is enabled
Timer channels
Time channels can be used to implement additional functions and to control external devices. Timer
channels can be adjusted via the Pandora Alarm Studio.
To enter “TIME CHANNELS MENU”, shortly press button. The following presses of
button will cause switching between channels.
To activate/deactivate the channel, shortly press .
To exit menu, press and hold button for 1 second.

19
User manual
channel
controls
1 2 3
4 5 6
78 9
1channel 1
disabled
2channel 2
disabled
3channel 3
disabled
4channel 4
disabled
1channel 1
enabled
2channel 2
enabled
3channel 3
enabled
4channel 4
enabled
channel
controls
1 2 3
4 5 6
78 9
1channel 1
disabled
2channel 2
disabled
3channel 3
disabled
4channel 4
disabled
1channel 1
enabled
2channel 2
enabled
3channel 3
enabled
4channel 4
enabled
channel
controls
1 2 3
4 5 6
78 9
1channel 1
disabled
2channel 2
disabled
3channel 3
disabled
4channel 4
disabled
1channel 1
enabled
2channel 2
enabled
3channel 3
enabled
4channel 4
enabled
channel
controls
1 2 3
4 5 6
78 9
1channel 1
disabled
2channel 2
disabled
3channel 3
disabled
4channel 4
disabled
1channel 1
enabled
2channel 2
enabled
3channel 3
enabled
4channel 4
enabled
channel
controls
1 2 3
4 5 6
78 9
1channel 1
disabled
2channel 2
disabled
3channel 3
disabled
4channel 4
disabled
1channel 1
enabled
2channel 2
enabled
3channel 3
enabled
4channel 4
enabled
channel
controls
1 2 3
4 5 6
78 9
1channel 1
disabled
2channel 2
disabled
3channel 3
disabled
4channel 4
disabled
1channel 1
enabled
2channel 2
enabled
3channel 3
enabled
4channel 4
enabled
channel
controls
1 2 3
4 5 6
78 9
1channel 1
disabled
2channel 2
disabled
3channel 3
disabled
4channel 4
disabled
1channel 1
enabled
2channel 2
enabled
3channel 3
enabled
4channel 4
enabled
channel
controls
1 2 3
4 5 6
78 9
1channel 1
disabled
2channel 2
disabled
3channel 3
disabled
4channel 4
disabled
1channel 1
enabled
2channel 2
enabled
3channel 3
enabled
4channel 4
enabled
channel
controls
1 2 3
4 5 6
78 9
1channel 1
disabled
2channel 2
disabled
3channel 3
disabled
4channel 4
disabled
1channel 1
enabled
2channel 2
enabled
3channel 3
enabled
4channel 4
enabled

20 Security-service system Pandora Light
Check car status
To receive information about engine, interior temperature, battery voltage and fuel level, select
«SYSTEM CONTROLS» menu and shortly press button.
27°24°12 0V
0
system
controls
CHECK
27°24°12 0V
0
system
controls
CHECK
To exit menu, press and hold button for 1 second.
NOTE: Engine start via temperature is available only if temperature sensor is connected.
The sensor availability depends on the system set. Fuel level will only be shown if it can be read
from CAN-bus or if there is additional connection.
Event history
To view event history in the system’s memory, select «SYSTEM CONTROLS» menu, then shortly press
.
Navigate several last events using (forward) and (back) buttons. Events are displayed
by showing time of the event and flashing corresponding trigger zone indicators.
arming
12:43
disarming
12:44
System
controls
CHECK
arming
12:43
disarming
12:44
System
controls
CHECK
arming
12:43
disarming
12:44
System
controls
CHECK
