Pantech TX-1000C User manual

REV.00 00000000000

User Guide
TX-1000C

2
3
WELCOME
Thank you for choosing the up-to-date TX-1000C, our new model, developed
by top researchers to support the CDMA2000 1X system through Qualcomm-
manufactured MSM6050 chips and CDMA technologies. This product allows
for high speed communication services, such as web browsing, data & fax
services, and a GUI animation menu.
T9 input mode makes it much easier to enter text, while VR (Voice
Recognition) makes the TX-1000C more user friendly.
Other proven technologies include:
• Full graphic display of 7 text input line and 1 icon line with variable font
size.
• Easy to dial through the VR feature.
• Easy to enter letters through the T9 text input mode.
• Enhanced for web browsing & data services (i.e.; wireless internet access,
wireless fax send/receive, UP browser)
• GUI & Animation display compliant with CDMA2000 1X.
• CSTN 65K Color LCD.
• Mobile camera (310K pixels)
• CMX 3.1 32 Poly Sound.
• Navigation Key and 22 keys aligned for more convenience.
• Sophisticated features of speaker phone, and voice recognition.
• Additional services of text messaging and Web browsing on top of
authentication, call forwarding, call transfer, call waiting.
IMPORTANT INFORMATION
This TX-1000C user guide contains very important information about how
to handle and use the product. Please read this manual thoroughly, pay
attention to the warranty on the back page and be alert to the exclusions
and limitations of your warranty, which are related with the unauthorised
use of components.
CHAPTER 1. BEFORE USING YOUR PHONE ...........................................................7
INSIDE THE PACKAGE ........................................................................................8
HANDSET DESCRIPTION ....................................................................................9
DISPLAY INDICATORS ...............................................................................................11
BATTERY USAGE .............................................................................................. 13
BATTERY INSTALLATION ..........................................................................................13
BATTERY REMOVAL .................................................................................................13
BATTERY CHARGING ................................................................................................14
BATTERY HANDLING INFORMATION ...............................................................16
DOs ...........................................................................................................................16
DON’Ts ......................................................................................................................16
CHAPTER 2. BASIC OPERATION ..........................................................................17
TURNING THE PHONE ON / OFF .......................................................................18
TURNING THE PHONE ON ........................................................................................18
TURNING THE PHONE OFF .......................................................................................18
ACCESSING THE MENU ....................................................................................19
MENU SUMMARY ............................................................................................20
BASIC FUNCTIONS ...........................................................................................23
MAKING A CALL .......................................................................................................23
SPEAKER PHONE ......................................................................................................24
PAUSE FEATURE .......................................................................................................24
ANSWERING A CALL ................................................................................................25
3 WAY CALL FUNCTION ...........................................................................................25
CALLER ID FUNCTION ..............................................................................................26
CALL WAITING FUNCTION .......................................................................................26
ADJUSTING VOLUME ...............................................................................................26
ETIQUETTE ................................................................................................................27
KEY GUARD ..............................................................................................................27
DURING A CALL ...............................................................................................28
MUTE (UNMUTE) ......................................................................................................28
SPEAKER MODE .......................................................................................................28
SILENT (SILENT QUIT) ...............................................................................................28
SEND MY PHONE # ..................................................................................................28
PHONE INFO. ............................................................................................................29
PHONEBOOK ............................................................................................................29
CALL HISTORY ..........................................................................................................29
MESSAGING ..............................................................................................................29
MAKING AN EMERGENCY CALL .....................................................................30
EMERGENCY NUMBER IN LOCK MODE ..................................................................30
CHAPTER 3. MEMORY FUNCTION .......................................................................31
STORING A PHONE NUMBER ...........................................................................32
ENTERING LETTERS, NUMBERS & SYMBOLS ...................................................33
STANDARD INPUT MODE ........................................................................................34
T9 INPUT MODE .......................................................................................................35
NUMERIC MODE ......................................................................................................36
TABLE OF CONTENTS

4
5
SYMBOL MODE ........................................................................................................36
MAKING A CALL THROUGH THE PHONE BOOK ...............................................37
SPEED DIAL#’S ..........................................................................................................37
CHAPTER 4. MENU FUNCTION ............................................................................39
CALL HISTORY ..................................................................................................40
ALL CALLS .................................................................................................................40
OUTGOING CALLS ....................................................................................................41
INCOMING CALLS .....................................................................................................42
MISSED CALLS ..........................................................................................................43
ERASE HISTORY ........................................................................................................44
AIR TIME ...................................................................................................................45
PHONE BOOK ...................................................................................................46
FIND ..........................................................................................................................46
NEW ENTRY ..............................................................................................................47
SPEED DIAL#’S ..........................................................................................................48
MY PHONE # ............................................................................................................48
GROUP ......................................................................................................................49
PICTURES ..........................................................................................................51
TAKE A PHOTO .........................................................................................................51
MY PICTURES ............................................................................................................54
ONLINE ALBUMS ......................................................................................................55
DOWNLOADS ...................................................................................................56
START DOWNLOADS ................................................................................................56
GAMES ......................................................................................................................57
RINGERS ....................................................................................................................58
WALLPAPERS ............................................................................................................59
DOWNLOADING APPLICATIONS ..............................................................................59
OTHERS .....................................................................................................................60
TOOLS ..............................................................................................................61
SCHEDULE .................................................................................................................61
MEMO PAD ...............................................................................................................62
ALARM ......................................................................................................................63
CALCULATOR ............................................................................................................65
STOPWATCH .............................................................................................................66
WORLD CLOCK .........................................................................................................67
SETTINGS .........................................................................................................68
SOUNDS ....................................................................................................................68
DISPLAY ....................................................................................................................73
ROAMING .................................................................................................................76
DATA SVC .................................................................................................................76
APPLICATIONS ..........................................................................................................77
SECURITY ..................................................................................................................78
AIRPLANE MODE ......................................................................................................83
OTHERS .....................................................................................................................84
PHONE INFO .............................................................................................................87
CHAPTER 5. VOICE SERVICE ...............................................................................89
VOICE RECOGNITION MODE ............................................................................90
VOICE TOOLS MENU ........................................................................................91
VOICE MEMO ...........................................................................................................91
VOICE DIAL ...............................................................................................................92
TRAIN WORDS ..........................................................................................................93
CHAPTER 6. VOICE MAIL, TEXT MESSAGE AND PICTURE MESSAGE .................95
WHEN A NEW MESSAGE ARRIVES ..................................................................96
VOICE MAIL .....................................................................................................96
SEND TEXT MSG ..............................................................................................97
SEND PICTURE MSG .........................................................................................98
INBOX ..............................................................................................................99
OUTBOX .........................................................................................................101
SAVED ............................................................................................................103
QUICK TEXT ....................................................................................................104
ERASE ALL .....................................................................................................105
SETTINGS .......................................................................................................106
SAVE SENT MSG .....................................................................................................106
DEFAULT CALLBACK ..............................................................................................106
REMINDER ..............................................................................................................106
AUTO ERASE ...........................................................................................................107
ENTRY MODE .........................................................................................................107
MESSAGE LOG ........................................................................................................108
RETRY TIME ............................................................................................................109
EDIT VOICE CB# ......................................................................................................109
CHAPTER 7. MOBILE BROWSER ........................................................................111
START MOBILE BROWSING ............................................................................112
ACCESS THE INTERNET ...........................................................................................112
MOBILE BROWSER MENU ..............................................................................113
BACK .......................................................................................................................113
HOME .....................................................................................................................113
FORWARD ..............................................................................................................113
BOOKMARKS ..........................................................................................................113
SEARCH ...................................................................................................................113
GO TO URL .............................................................................................................113
SHOW URL ..............................................................................................................114
RELOAD ..................................................................................................................114
SETTINGS ................................................................................................................114
HISTORY .................................................................................................................115
ABOUT..... ...............................................................................................................115
CHAPTER 8. SAFETY AND WARRANTY .............................................................117
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES .......................118
DRIVING SAFETY ....................................................................................................119
ELECTRONIC DEVICES ............................................................................................120
OTHER SAFETY GUIDELINES ..................................................................................121
PRECAUTIONS ........................................................................................................122
TABLE OF CONTENTS TABLE OF CONTENTS

6
SAFETY INFORMATION FOR FCC RF EXPOSURE ............................................123
CAUTIONS ...............................................................................................................123
SAR INFORMATION ........................................................................................124
FDA CONSUMER UPDATE ..............................................................................126
PROTECT YOUR WARRANTY ..........................................................................131
12 MONTH LIMITED WARRANTY ...................................................................132
TABLE OF CONTENTS
CHAPTER 1 BEFORE USING YOUR PHONE
This chapter provides important information about using the
TX-1000C including:
INSIDE THE PACKAGE
HANDSET DESCRIPTION
BATTERY USAGE
BATTERY HANDLING INFORMATION
CHAPTER 1
BEFORE
USING
YOUR PHONE
“LICENSED BY QUALCOMM INCORPORATED UNDER ONE OR MORE OF THE FOLLOWING PATENTS
: U.S.PATENT NO. 4,901,307 U.S.PATENT NO. 5,056,109 U.S.PATENT NO. 5,099,204 U.S. PATENT NO.
5,101,501 U.S. PATENT NO. 5,103,459 U.S. PATENT NO. 5,107,225 U.S.PATENT NO. 5,109,390.”

8
9
BEFORE USING
BEFORE USING INSIDE THE PACKAGE HANDSET DESCRIPTION
AC Charger
Handstrap
User Guide
Handset
Standard Battery
This package should include all items pictured below.
If any are missing or different, immediately contact the retailer where you
purchased the mobile phone.
This mobile phone is a dual mode (800 MHz CDMA, 1900 MHz PCS) CDMA2000
1X digital mobile phone with camera and web browsing capabilities.
The TX-1000C weighs 80.5g. And the dimensions are 105mm X 45mm X 18.1mm.
Function Keys
Earpiece
LCD Screen
Navigation key
Back/Clear Key
Send Key
Download Key
END/Power Key
Microphone
Camera Preview key
Volume Key
If the pressed END
Key while controlling
volume with side keys,
the changed value
won’t be saved.
Earjack
Camera Lens
Sound speaker
Pictures Menu key

10
BEFORE USING
11
BEFORE USING
HANDSET DESCRIPTION
Display Indicators
See page 11 for a list of icons.
Text & Graphic Area
Soft Key Indications
Shows the functions current-
ly assigned to each soft key
and displays some icons.
Find
(Right Soft Key)
Press to access the menu
or function displayed on
the right hand side of the
bottom line.
THE FUNCTION KEYS
In Idle Mode
Press UP to access the
Messaging, DOWN to
access the Phone Book,
RIGHT for Schedule and
LEFT for Mobile Web.
Inside The Menu
Within a menu, use to
scroll through menu
options, or to select a
function displayed on the
screen.
Press to make or
receive a call.
Press and hold to
turn on VR mode.
Press to turn the phone
on/off, to end a call or to
return to idle mode.
Press and hold to enter
etiquette mode.
Press and hold to enter
key guard mode.
Main Menu
(Left Soft Key)
Press to access the
menu or function
displayed on the
left hand side of
the bottom line.
Message
New text and/or voice message.
H
DISPLAY INDICATORS
Signal Strength
Current signal strength: the more lines, the stronger the signal.
Roaming
Phone is out of home area.
Service Indicator
Indicates call is in progress, indicates the phone cannot
receive a signal from the system.
Battery
Battery charging level – the more blocks, the stronger the charge.
Digital Mode
Phone is operating in digital mode.
Mute
Phone is mute during a call.
Silence
Appears when Silent All is selected as the ring mode.
Emergency Call
Blinks when an emergency call is in progress.
Auto Answer
Phone is in answering machine mode.
Speaker phone
Phone is in speaker phone mode.
Etiquette
Phone will vibrate when call is received.
Schedule
Appears when either an event or an alarm is set.
HANDSET DESCRIPTION
Press to clear a
digit from the
display or to return
to the previous
page.

12
BEFORE USING
13
BEFORE USING
Ring Mode
Appears when a ringer is set as a particular ringer
mode.
Dormant
Indicates the phone is in disconnection condition while on “Server
Connection”.
Fax Only
Receives a fax call as a voice call.
Data Only
Receives an async. call as a voice call.
1X
Phone is in the 1x service area.
Silent
Displays when Silent is in use during a call.
Web Browser
Phone is a web browser session.
HANDSET DESCRIPTION BATTERY USAGE
H BATTERY INSTALLATION
 
Put the metal locators of the battery into the hole located at the
bottom of the unit, as shown in the figure below.

Press the upper
side of the battery until you hear the “click” sound.
H BATTERY REMOVAL
 
While holding the button, push the battery up and remove it.
If the battery is not correctly placed in the compartment, the handset will not
turn on and/or the battery may detach during use.

14
BEFORE USING
15
BEFORE USING
BATTERY USAGE
H BATTERY CHARGING
POWER CONNECTION

Plug the AC charger into a standard outlet.

Plug the other end of the AC Charger into the bottom of your mobile
phone. The battery must be installed on to the mobile phone.
• When you charge the battery with the phone power off, you will see a
charging status screen. You cannot operate the phone until it is powered
on.
• The battery is not charged at the time of purchase.
• Fully charge the battery before use.
• It is more efficient to charge the battery with the handset powered off.
• The battery must be connected to the phone in order to charge it.
• Battery operating time gradually decreases over time.
• If the battery fails to perform normally, you may need to replace the bat-
tery.
BATTERY USAGE
BATTERY TALK TIME
The operating time is subject to your handset usage and configuration.
BATTERY STAND-BY TIME (FOR A NEW BATTERY)
The operating time is subject to your handset usage and configuration.
These times are for a new battery. Talk and Standby time may decrease over
time.
Battery Capacity
STD 1000 mAh
DCS
Up to 200 minutes
PCS
Up to 200 minutes
Battery Capacity
STD 1000 mAh
DCS
150 Hours
PCS
150 Hours

16
BEFORE USING
BATTERY HANDLING INFORMATION
H DOs
H DON’Ts
• Only use the battery and charger approved by the manufacturer.
• Only use the battery for its original purpose.
• Try to keep batteries in a temperature between 41ºF (5ºC ) and 95ºF (35ºC).
• If the battery is stored in temperatures above or below the recommended
range, give it time to warm up or cool down before using.
• Completely drain the battery before recharging.
It may take one to four days to completely drain.
• Store the discharged battery in a cool, dark, and dry place.
• Purchase a new battery when its operating time gradually decreases after
fully charging.
• Properly dispose of the battery according to local laws.
• Don’t attempt to disassemble the battery – it is a sealed unit with no service-
able parts.
• Don’t accidentally short circuit the battery by carrying it in your pocket or
purse with other metallic objects such as coins, clips and pens. This may criti-
cally damage the battery.
• Don’t leave the battery in hot or cold temps. Otherwise, it could significantly
reduce the capacity and lifetime of the battery.
• Don’t dispose of the battery into a fire.
CHAPTER 2 BASIC OPERATION
This chapter explains the basic features of your mobile phone
including:
TURNING THE PHONE ON / OFF
ACCESSING THE MENU
MENU SUMMARY
BASIC FUNCTIONS
DURING A CALL
MAKING AN EMERGENCY CALL
CHAPTER 2
BASIC OPERATION
