OWNER’S MANUAL
PDG0031

Table of Contents
Features __________________________
Exploded View _______________________
Part List ________________ _____________
Safety Information_____________________
___________________noitamrofnIlacirtcelE
Included Hardware_______________________
Assembly Instruction___________________
Maintenance ___________________________
Fold & Transport _______ ____________
Operations__________________________
Monitor Your Heart Rate ___________________
Warm Up___________________________
Warranty / Service ___________________
Page
3
4 -5
6
7
8
9
10 - 11
12
13
14 - 17
18 - 19
20
Fitness Guide _______________________ 21
Trouble Shooting _____________________ 22
24 - 25
Service Centre 07 3272 7010
2

Features
2
C
Book rack
onsole
Pulse sensors
Quick buttons
Console Mast
Running Belt
The treadmill has been designed and constructed to provide trouble free usage and enjoyable
exercise. You can greatly improve your understanding and benefits of exercising by carefully
reading the instructions given in this manual .Please familiarize yourself with the maintenance
advice provided for you.
SPECIFICATION
Horsepower Continuous / Peak: 2 / 4 hp
Speed Range: 0.8 – 18 Km/h
Striding Surface: 142 X 51 cm
Incline Level: 1-12% / Power
MAX.USER WEIGHT 160 KGS
3

Exploded View
2
Service Centre 07 3272 7010
B01
B62 B03
A15
C34
C04
C04
C05
C03 B05
B07
A02 C38
C03
B06
C06
C07
C38
B08
B10
B06
A03
B42
C01
B43
C01
C38
B09
B13
B10
C05
C06
B61 C01
4

B35
Exploded View
2
C04
C05
C05
C05
C05
C05
C05 C05
5

Part List
2
Service Centre 07 3272 7010
6

Important Safety Information
IMPORTANT: THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY
Your treadmill was designed and built for optimum safety. However, certain precautions apply
whenever you use your treadmill. Be sure to read the manual before assembly and operation.
Also, please note the following safety precautions:
DANGER: To reduce the risk of electric shock, always unplug the treadmill from the electrical outlet
immediately after using and before cleaning.
1. Read OWNER’S MANUAL and all accompanying literature and follow it carefully
before using your treadmill.
2. If dizziness, nausea, chest pains, or any other abnormal symptoms are experienced while using this
equipment, STOP the workout and CONSULT APHYSICIAN IMMEDIATELY.
3. Never leave the treadmill unattended when plugged in. Unplug from the outlet when not in use and
before removing or replacing parts.
4. Never operate the treadmill if it has a damaged cord or plug, if it is not working properly, if it has
been dropped, damaged, or exposed to water.
5. Do not pull the treadmill by the power supply cord or use cord as a handle. Keep cord away from
heated surfaces and open flames.
6. Fitness equipment must always be installed and used on a flat surface. Do not use outdoors or near
water.
7. Do not insert any objects into any openings.
8. Keep children and pets away from this equipment at all times while exercising.
9. Handicapped individuals should have medical approval and close supervision when using this
treadmill.
10.Do not place hands or feet under the treadmill. Always keep hands and legs off the treadmill
when others are using it.
11.Never turn on treadmill while standing on treadbelt. Always return the treadmill to slow speed to
provide for safe dismount and low speed restart.
12.To disconnect, turn all controls to the off position, then remove plug from outlet.
13. Use the treadmill only for it is intended use as described in this manual.
14. Warm up 5 to 10 minutes before each workout and cool down 5 to 10 minutes afterward. This allows
your heart rate to gradually increase and decrease and will help prevent straining muscles.
15. Never hold your breath while exercising. Breathing should remain at a normal rate in conjunction
with the level of exercise being performed.
16. Start your program slowly and very gradually increase your speed and distance.
17. Always wear suitable clothing and footwear while exercising. Do not wear loose fitting clothing
that could become entangled with the moving parts of your treadmill.
18. Do not walk or jog barefoot, in stockings or loose fitting shoes or slippers.
19. Care must be taken when lifting or moving the equipment, so as not to injure your back. Always use
proper lifting techniques.
WARNING: Before beginning any exercise program consult your physician. This is especially
important for individuals over the age of 35 or persons with pre-existing health problems.
Read all instructions before using any fitness equipment. We assume no responsibility
from personal injury or property damage sustained by or through the use of this product.
CAUTION!! Please be careful when opening this unit.
7

4
Grounded Outlet
Grounding Pin Grounded Outlet Box
Metal Screw
Adapter
Tab of
Grounding
Screw
Electrical Information
WARNING!
NEVER use a ground fault circuit interrupt (GFCI) wall outlet with this treadmill. Large switching currents of
the drive motor will trip GFCI type outlets, as any appliance with a large motor. Route the power cord away
from any moving part of the treadmill including the elevation mechanism and transport wheels.
NEVER remove any cover without first disconnecting AC power.
If voltage varies by ten percent (10%) or more, the performance of your treadmill may
be affected. Such conditions are not covered under your warranty. If you suspect
the voltage is low, contact your local power company or a licensed electrician for proper
testing.
NEVER expose this treadmill to rain or moisture.This product is NOT designed for use outdoors, near a pool
or spa, or in any other high humidity environment.The temperature specification is 4 to 48 degrees Celsius,
and humidity limit is 95%, non-condensing (no water drops forming on surfaces).
Grounding Instructions
This product must be grounded. If the treadmill should malfunction or breakdown, grounding provides a
path of least resistance for electric current, reducing the risk of electric shock.This product is equipped
with a cord having an equipment-grounding plug.The plug must be plugged into an appropriate outlet
that is properly installed and grounded in accordance with all local codes and ordinances.
DANGER - Improper connection of the equipment-grounding conductor can result in a risk of elec-
tric shock. Check with a qualified electrician or serviceman if you are in doubt as to whether the
product is properly grounded. Do not modify the plug provided with the product if it will not fit the
outlet. Have a proper outlet installed by a qualified electrician.
This product is for use on a nominal 240-volt circuit, and has a grounding plug that looks like the plug
illustrated below. A temporary adapter that looks like the adapter illustrated below may be used to
connect this plug to a 2-pole receptacle as shown below if a properly grounded outlet is not available.The
temporary adapter should be used only until a properly grounded outlet, (below) can be installed by a
qualified electrician.The green colored rigid ear-lug, or the like, extending from the adapter, must be
connected to a permanent ground such as a properly grounded outlet box cover.Whenever the adapter is
used, it must be held in place by a metal screw.
Service Centre 07 3272 7010
8

Included Hardware
Service Centre 07 3272 7010
M8 x 20 (8 pcs)
Screw M4 x 8 (7 pcs)
Curl washer 10 x 25 (2 pcs) Washer 8 x 18 (6 pcs)
Allen key
Speaker wire
Drew driver
Safety key
9

M8 x 20 (6 pcs)
M8 x 20 (2 pcs)
Curl washer 10 x 25 (2 pcs)
Washer 8 x 18 (2 pcs)
Washer 8 x 18 (4 pcs)
Assembly Instruction
1
2
You can leave the treadmill in the carton bottom. Flatten carton sides down before assembly.
10

Screw M4 x 8 (3 pcs)
Screw M4 x 8 (4 pcs)
Assembly Instruction
3
4
FINAL CHECK
Your Pacer 2500 treadmill is now assembled. Please make
the following final checks:
• Make sure all screws / bolts are tightened.
• Make sure the equipment is on a level surface.
POWER UP
• Plug one end of power cable into the treadmill
• Plug the other end into a suitable AC outlet (220-240 volt,
50Hz).
• Switch the treadmill on using the on/o switch.
• Attach the safety key to the console.
use the Quick Start instruction and allow the treadmill
to run independently for 10 minutes. Check the running
mat is tightened correctly and runs smoothly. If you think
the mat needs adjusting please see Maintenance page.
11

Maintenance
CENTERING RUNNING BELT
TREADMILL LUBRICATION
Lubricating under the treadbelt will ensure superior performance and extend its life expectancy.
After the first 25 hours of use (2-3 months) apply one half bottle of lubricant.
Every 50 hours of use (5-8 months) apply one half bottle of lubricant.
HOW TO CHECK TREADBELT FOR PROPER LUBRICATION
Lift one side of the treadbelt and feel the top surface of the treadboard.
If the surface is slick to the touch, then no further lubrication is required.
If the surface is dry to the touch, apply one packet of lubricant or half of the bottle of lubricant.
HOW TO APPLY LUBRICANT
Lift one side of treadbelt.
Pour one half of the lubricant bottle
under the center of the treadbelt on the top
surface of the treadboard.
Walk on the treadmill at a slow speed for 3 to 5
minutes to evenly distribute lubricant.
NOTE: DO NOT over lubricate treadboard. Any
excess lubricant that comes out should be wiped
off.
IMPORTANT: ONLY USE HALF THE BOTTLE OF LUBRICANT PER APPLICATION
LUBRICATION SCHEDULE.
Start the treadmill without anyone on the running belt, press
speed up bottom until speed reached 16kph.
If toward the left side of the deck
Using an Allen wrench, turn the left adjustment bolt 1/8 turn in
a clockwise direction and the right adjustment bolt counter
clockwise 1/8.
If toward the right side of the deck
Using an Allen wrench, turn the right adjustment bolt 1/8 turn
in a clockwise direction and the left adjustment bolt counter
clockwise 1/8.
ADJUST THE BELT TENSION
If the running belt feels as though it is “slipping” or hesitating when you plant your foot during a run,
the tension on the running belt may have to be increased. To increase the tension of the running belt,
turn both left and right adjustment bolts clockwise evenly.
12

Folding & Transport
2
FOLDING
NOTE! Make sure the treadmill’s elevation is at its
lowest position before folding the deck to avoid damage
to your machine.
To fold the machine, raise the deck until it locks into
position.
Make sure you hear the click sound of the deck locking
into position. This is to ensure the deck is locked in
place and will not drop back down.
TO RELEASE THE RUNNING DECK
Hold the upper end of machine, pull the pin to put down
the frame to the ground.
NOTICE! This machine has a built-in safety unfolding
feature to help lower the deck slowly. Please make sure
there are no children or other things under the deck
when you lower it.
TO MOVE THE TREADMILL
Before moving the treadmill, be sure the power cord is
unplugged from the wall and the treadmill. Fold up the
running deck until it is locked and push the equipment
on its transportation wheels. Hold the handlebars to
move the treadmill.
To prevent malfunctioning of the treadmill, store it in a
dry place with as little temperature variation as possible,
protected against dust. Always unplug the treadmill
from the electrical outlet when not in use.
13

Operations
MP3 player input to use with built-in speakers
GETTING STARTED
CONSOLE
Power the treadmill on by plugging it into an appropriate wall outlet, then turn on the power switch located
at the front of the treadmill below the motor hood.
Stand on the side rails. Place the safety key to the console. Start with slow speed and hold onto the
handrails until you become comfortable.
FUNCTION BUTTON
SELECT To choose a program
ENTER Confirm selection
POWER Turns the treadmill on and off
INCLINE ▼▲ Adjust incline levels or scroll through the programs
START/STOP Starts or stops the workout
SPEED ▼▲
Adjusts speed ( 0.2 km increment) or scroll through the programs
SAFETY KEY Attach the safety key in its position to power on the computer. When safety key is
pulled away, the treadmill stops
14

DISPLAY
SPEED: Displays the current running speed from 0.8 Kmh- 18Kmh (1Mph-10Mph).
DISTANCE: Shows workout distance
CALORIES: Shows estimated calories burned during the workout.
PULSE/INCLINE: Display your current heart rate in beats per minute during workout or displays
your current workout elevation from 0 to 10%.
Dot matrix: Shows incline and the elevation programs (P1 - P4)O and speed on speed programs (P5 - p6).
In manual mode, it displays a 0.4 km running track.
TIME: Shows workout time. When the safety key is inserted, it showsthe accumulated distance
Operations
SPEED DIRECT Quickly select speed
KEYS
INCLINE DIRECT Quickly select incline
KEYS
PULSE GRIP FEATURE
The Pulse (Heart Rate) console window will display your current heart rate in beats per minute during the
workout.
The console is equiped with Chest Strap receiver. you can also use a Chest Strap (not incuded with the treadmill)
for accurate pulse display.
You must use both stainless steel sensors on the front cross bar to display your pulse.
15

Operations
Quick Start:
Make sure the safety key is on. Treadmill will not work without it.
Press POWER, then press START
The treadmill will start at 0.8 kph. You can adjust the speed and incline.
P
Programs
rogram: Press POWER, then press SELECT to enter program selection
Press to select a program
Press ENTER to set timer or press START
An elevation program that goes from 0 - 3% grade. The speed is
controlled by user. Elevation changes every 1 minute.
An elevation program that goes from 0 - 5% grade. The speed is
controlled by user.
An elevation program that goes from 0 - 7% grade. The speed is
controlled by user.
An interval elevation program where elevation alternates between
0 - 7% grade. The speed is controlled by user.
Speed controlled program that goes up to 5.5 kph. An excellent
program for intermediate walkers. User controls elevation.
16

Switch between metric/mile, and display treadmill information
Operations
.
The program works by automatically adjusting the incline to keep you working out at your target heart rate.
To do this the treadmill will need your pulse reading throughout the exercise (we recommend you use a
heart rate chest strap).
• If your heart rate is too high the incline is decreased, at a rate of 1% every 30 seconds.
• If your heart rate is too low the incline is increased, at a rate of 1% every 30 seconds.
• The user is free to change to speed settings at any point during the workout.
NOTE: The HRC program has a 3 1/2 minute warm-up phase. During this time the treadmill won’t automatically adjust
the incline.
You can choose to display metric or mile.
1. Hold ENTER then press SELECT
2. Window displays
Calories model number
Speed software version
Incline year
Time date
3. Press ENTER twice, then press ▼▲ to switch between KM and MILE
4. Press ENTER to show total distance
5. Press ENTER to show total hours the treadmill has been used.
Speed controlled program that goes up to 7.2 kph. An excellent
program for beginner joggers and fast walkers. User controls elevation.
You can set the speed and incline. If speed or incline is changed during
workout, the monitor will store the value.
User 1 and 2
Weight loss program. Target Heart Rate is at 65%.
HRC 1
Cardio program. Target Heart Rate is at 80%.
HRC 2
Fat burn program. Target Heart Rate is at 75%.
HRC 3
17

Monitoring Your Heart Rate
To obtain the greatest cardiovascular benefits from your exercise workout, it is important to work
within your target heart rate zone. TheAmerican Heart Association (AHA) defines this target as
60%-75% percent of your maximum heart rate.
Your maximum heart rate may be roughly calculated by subtracting your age from 220. Your maxi-
mum heart rate and aerobic capacity naturally decreases as you age. This may vary from one
person to another, but use this number to find your approximate effective target zone. For example,
the maximum heart rate for an average 40 year-old is 180 bpm. The target heart rate zone is 60%-
75% of 180 or 108-135 bpm.
See Fitness Safety on page 17
Before beginning your workout, check your normal resting heart rate. Place your fingers lightly
against your neck, or against your wrist over the main artery. After finding your pulse, count the
number of beats in 10 seconds. Multiply the number of beats by six to determine your pulse rate per
minute. We recommend taking your heart rate at these times; at rest, after warming up, during your
workout and two minutes into your cool down, to accurately track your progress as it relates to
better fitness.
During your first several months of exercising, the AHA recommends aiming for the lower part of the
target heart rate zone-60%, then gradually progressing up to 75%. According to the AHA, exercising
above 75% of your maximum heart rate may be too strenuous unless you are in top physical condi-
tion. Exercising below 60% of your maximum will result in minimal cardiovascular conditioning.
Check your pulse recovery rate – If your pulse is over 100 bpm five minutes after you stop exercis-
ing, or if it’s higher than normal the morning after exercising, your exertion may have been too
strenuous for your current fitness level. Rest and reduce the intensity next time.
Fitness Safety The target heart rate chart indicates average rate zones for different ages. Avariety
of different factors (including medication, emotional state, temperature and other conditions) can
affect the target heart rate zone that is best for you. Your physician or health care professional can
help you determine the exercise intensity that is appropriate for your age and condition
(MHR) = Maximum Heart Rate
(THR) = Target Heart Rate
220 - age = maximum heart rate (MHZ)
MHZ x .60 = 60% of your maximum heart rate.
MHZ x .75 = 75% of your maximum heart rate.
For example, if you are 30 years old, your calculations will be as follows:
220 - 30 = 190
190 x .60 = 114 (low end or 60% of MHZ)
190 x .75 = 142 (high end or 75% of MHZ)
30 year-old (THR) Target Heart Rate would be 114-142
See Heart Rate Table (on next page) for additional calculations.
Service Centre 07 3272 7010
18

Monitoring Your Heart Rate
Service Centre 07 3272 7010
19

Quadriceps Stretch
With one hand against a wall for balance, reach behind you and pull
your right foot up. Bring your heel as close to your buttocks as
possible. Hold for 15 counts and repeat with left foot up.
Inner Thigh Stretch
Sit with the soles of your feet together with your knees
pointing outward. Pull your feet as close into your groin as possible.
Gently push your knees towards the floor. Hold for 10 counts
Toe Touches
Slowly bend forward from your waist, letting you back and shoulders
relax as you stretch toward your toes. Reach down as far as you
can and hold for 15 counts.
Hamstring Stretches
Sit with your right leg extended. Rest the sole of your left foot
against your right inner thigh. Stretch toward your toe as far as
possible. Hold for 15 counts Relax and then repeat with left leg
extended.
Warm Up
Service Centre 07 3272 7010
20
