Paradox PCS265LTE Installation guide

PARADOX.COM
PCS265L-EI06 03/2022
You must use a SIM card with a
data charge limit. Paradox will not
be responsible in any way for any
usage charges of data or voice
whatsoever.
Installation
SIM Card Connection
The PCS265LTE supports two nano LTE/4G/3G/2G or GSM provider
SIM cards. To install the SIM cards, open the SIM Card tray and insert
card into base, as shown. SIM 1 is used as “Primary” and SIM 2 for
“Backup”. If only one SIM card is used, insert into SIM 1.
Note: SIM Card 2 can only be configured via SMS.
Panel Connections
Connect the PCS265LTE’s serial out to the serial connector on the
panel.
• For LTE/4G/3G/2G reporting, connect to the Serial port of
the panel.
• For GSM reporting, connect to the EBUS port of the panel.
RS485 Connection
A CVT485 module can be connected onto the control panel’s EBUS in
order to lengthen the distance (up to 300 m. / 1000 ft.) between the
panel and the PCS265LTE. Refer to the drawing for connections.
External Antenna Connection
Use the ANTK4G LTE external antenna kit for PTCRB installations or to
improve RF reception if your module’s signal strength is weak. External
antenna kits and extension kits are purchased separately.
IP Module Connection
The PCS265LTE can be connected to an IP Internet Module’s PCS port.
For more information on how to configure this option, please refer to the
IP module’s Installation manual.
Powering-up the PCS265LTE
Once your hardware connections are completed, the PCS265LTE
module will begin its power up sequence.
•Power LED will turn solid green
•Status LED will turn solid green
•SIM card 1 LED will slowly flash red while searching for the GSM
network; once found the LED will be solid yellow
If configured for LTE/4G/3G/2G reporting, you will need to configure
network provider information. Refer to the Programming section.
Note: The battery is optional. If a battery is used/installed, do not allow
the battery to deplete and ensure that the battery is replaced when low.
The battery function is to support power shut down and not to be used
as backup as defined in EN50131-6.
LED Functionality
*When using an e-bus connection, the LED is always yellow.
Programming
In order to configure the PCS265LTE for reporting, you will need to first
configure your SIM cards. Please note that SIM Card 1 can be
configured via panel programming or SMS and SIM Card 2 via SMS
only.
IP Reporting over LTE/4G/3G/2G and SMS Personal Reporting
Network Provider Information
Network Provider Information
Refer to the List of SMS Commands Table on page 2.
LTE/4G/3G/2G Reporting Options
1Mounting hole
2Antenna connector
3Wall tamper hole
4Serial connector
5RS485 / power terminal
6Upgrade connector
7Battery terminal
8Cover tamper switch
3
4
5
6
7
2
1
8
1
GSM (EBUS Connector)
LTE/4G/3G/2G (Serial Connector)
CVT485
Up to 300m (1000 ft.)*
Up to 50m (160 ft.) AWG18
LED Functionality
SIM1 and
SIM2*
Solid yellow GSM
Red flashing No network
Solid blue LTE/4G
Internet present, polling to SWAN
and received a connection identifier
Flashing Blue Data exchange/updating firmware
Solid green 3G/2G
Internet present, polling to SWAN
and received a connection identifier
Flashing green Data exchange/updating firmware
Flashing every
0.2 seconds
Internet present, polling to SWAN but
did not receive a connection identifier
Flashing every
0.5 seconds
Internet present, received a
connection identifier but it is not
polling to SWAN
Flashing every
1 second
Internet present, not polling to SWAN
and did not receive a connection
identifier
Off No Internet connection
Power Solid green Power on
Off No power
Status
Red Error condition, no firmware
Green No error and/or battery fully charged
Orange Battery charging
Signal
Strength
Three LEDs indicate network signal strength
MG/SP EVO Feature
[921] [2960] APN part 1 (characters 1-16)
[922] [2961] APN part 2 (characters 17-32)
[923] [2962] APN user name part 1 (1-16)
[924] [2963] APN user name part 2 (17-32)
[925] [2964] APN password part 1 (1-16)
[926] [2965] APN password part 2 (17-32)
Important: This information can be obtained from your mobile
network provider.
MG/SP EVO Feature Details
[918]
[919]
[2976] to
[2983]
Account / Partition
Registration
MG/SP: Sections
represent account/
partition 1 and 2
EVO: Sections
represent account /
partition 1 to 8
PCS265LTE
LTE / 4G / 3G / 2G / GSM
Communicator Module
V5.0 or higher
Installation and Programming Guide
**Compatible with Insite GOLD
and SWAN Server**

PARADOX.COM
PCS265L-EI06 03/2022
GSM Reporting (EBUS Connection)
Reporting Options
SMS Messages for Backup
Additional Programming Options
SMS Language
SMS Programming
Refer to the panel’s respective user manual for more information on
SMS Personal Reporting.
List of SMS Commands
Please note that the default password is admin.
EN Certification
The following statements apply for EN 50131 and EN 50136
certification:
• Mode of operation is pass-through
• PCS265LTE must be installed and connected to an EN approved
Grade 3 control panel
• Monitoring of the transmission network interface (Internet
connection): In case of network/interface failure, the device sends
a trouble message to the control panel which then displays it via
connected keypad(s)
• Information Security is achieved by 256-bit encrypted, supervised
communication (AES validation number 986) which prevents
unauthorized reading or modification of messages
• Substitution Security is achieved by Information Security (as stated
above), physical security (Tamper protection) and by a unique
Serial Number from each device. Messages sent to the receiving
station include the S/N in order to identify the substitution and alert
accordingly
Technical Specifications
Safety Note: This device may operate continuously in temperature of
55°C (131°F) for a maximum period of 7 days.
[806] [2975] [7] Off + [8] Off = landline only
[7] Off + [8] On = LTE/4G/3G/2G primary / land-
line backup (default)
[7] On + [8] Off = landline only
[7] On + [8] On = landline and LTE/4G/3G/2G in
parallel
Receiver Settings MG/SP
Receiver #:
IP address*
IP port **
IP address
WAN 2
IP port WAN2
Receiver password
Security Profile
1
[929]
[930]
[931]
[932]
[933]
[934]
2
[936]
[937]
[938]
[939]
[940]
[941]
Backup
[943]
[944]
[945]
[946]
[947]
[948]
Module registration
Press [ARM] to register
[935] [942] [949]
Receiver Settings EVO
Receiver #:
IP address*
IP port **
IP address
WAN 2
IP port WAN2
Receiver password
Security Profile
1
[2984]
2
[2986]
3
[2988]
4
[2990]
Module registration
Press [ARM] to register
[2985] [2987] [2989] [2991]
* For 1 or 2 digit numbers, add “0’s” before the digit: e.g.,
138.002.043.006
** Default = 10000
Enter [MEM] for blank space
MG/SP EVO Details
[805] [2950] [1] Off + [2] Off = landline only (default)
[1] Off + [2] On = landline primary / GSM
backup (default)
[1] On + [2] Off = GSM primary / landline
backup
[1] On + [2] On = GSM only
[815] to
[817]
[3071] to
[3074]
Telephone numbers
[811] to
[812]
[3061] to
[3068]
Account numbers
Command Description
P[PASSWORD].SMS[GSM MODEM
TELEPHONE #].[IPRS-7 PASSWORD]
Used to program the
receiver’s SMS parameters
Language Value Language Value
English (default) 000 Bulgarian 016
French 001 Romanian 017
Spanish 002 Slovak 018
Italian 003 Chinese 019
Swedish 004 Serbian 020
Polish 005 Malay 021
Portuguese 006 Slovenian 022
German 007 Lithuanian 023
MG/SP EVO Feature Details
Turkish 008 Finnish 024
Hungarian 009 Estonian 025
Czech 010 French Canadian 026
Dutch 011 Belgian 027
Croatian 012 Latvian 028
Greek 013 Albanian 029
Hebrew 014 Macedonian 030
Russian 015
Section SMS Site Name Label
EVO
[2954] __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/
__
MG/SP
[780] __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/
__
Command Description
P[password].A[IP
address].P[port number]
Used for LTE/4G/3G/2G remote
access
P[password].IP.[call back phone
number]
Used to obtain the IP address and IP
port of the PCS265LTE and whether
or not the “bandwidth saver” option is
being used
P[password].RESET Used to power cycle the PCS265LTE
P[password].STATUS.[phone
number]
Used to obtain the signal strength, sig-
nal quality, LTE/4G/3G/2G
connection status, and APN
settings of the current SIM card
P[password].
APN1.NAME.
[Access Point Name]
Used to program the SIM Card 1 APN
P[password].
APN1.USER.
[Access Point Name]
Used to program the SIM card 1 APN
User Name
P[password].
APN1.PSW.
[Access Point Name]
Used to program the SIM card 1 APN
Password
P[password].
APN1.CLEAR]
Used to clear the SIM Card 1 APN
P[password].
VAPN1.[CALL BACK PHONE
NUMBER]
Used to view the SIM Card 2 Access
Point Name information
P[password]. APN2.NAME.
[Access Point Name]
Used to program the SIM Card 2
Access Point Name
P[password].
APN2.USER.
[Access Point Name]
Used to program the SIM Card 2
Access Point User
P[password].
APN2.PSW.
[Access Point Name]
Used to program the SIM Card 2
Access Point Password
P[password].
APN2.CLEAR
Used to clear the SIM Card 2 Access
Point Name
P[password].
VAPN2.[CALL BACK PHONE
NUMBER]
Used to view the SIM Card 2 Access
Point Name information
P[password].[IP1W1/ IP1W2/
IP2W1/ IP2W2/ IP3W1/ IP3W2/
IP4W1/ IP4W2].[domain name]
Set domain name for LTE/4G/3G/2G
receiver
Language Value Language Value
P[password].[IP1W1/ IP1W2/
IP2W1/ IP2W2/ IP3W1/ IP3W2/
IP4W1/ IP4W2]
.CLEAR
Clear domain name for LTE/4G/3G/2G
receiver
C[user code].[ARM/
OFF].A[area number], [area
number], [area
number]TO[area number]
Arm/Disarm
P[password].---S Disable SWAN polling
(V4.10.011 and higher)
P[password].+++S Enable SWAN polling
(V4.10.011 and higher)
Specifications Description
RF Power Class 4 (2W) @ 850/1900 MHz
Class 2 (1W) @ 1800/1900 MHz
UMTS 850/1900 @ 0.25W (America)
UMTS 900/2100 @ 0.25W (Europe)
Antenna Bandwidth 5 bands, wideband
Voltage Input 12 VDC nominal
Consumption during
GPRS/GSM transmission
60 mA standby
300 mA maximum
Encryption 128-bit (AES)
SMS Protocol 7-bit (GSM: 3GPP TS 23.038/
GSM03.38)
or 16-bit (UCS2 ISO/IEC10646)
SIM Cards LTE/4G/3G
GSM (2G - n/a for North and South
America)
Humidity 0 - 90% non-condensing
Operating Temperature -20 - 50 °C (-4 to 122 °F)
Dimensions 20.8 x 7.5 x 2 cm / 8.2 x 2.9 x 0.8 in.
Certifications EN 50136-1 EN 50136-2 Grade 3
Class II
EN 50131-10 ATS Category SP5
Certification Body: Applica Test and
Certification
Command Description
Warranty
The Limited Warranty Statement can be found on the website www.paradox.com/terms.
Patents
Your use of the Paradox product signifies your acceptance of these terms and
conditions. The following US patents may apply 5,886,632 and
6,215,399. Other Canadian and international patents may apply.
©2022 Paradox Security Systems (Bahamas) Ltd. All rights reserved.
Specifications may change without prior notice.
