Paradyne Hotwire 8774 User manual

1
8774-A2-GZ40-30 February 2001
Hotwirer8774 TDM SDSL Termination Unit
with DSX-1 Interface
Installation Instructions
Document Number 8774-A2-GZ40-30
February 2001
Product Documentation Online
Complete documentation for this product is available at www.paradyne.com.
Select Library →Technical Manuals →Hotwire DSL & MVL Systems.
Select the following document:
8774-A2-GB20
Hotwire 8774 TDM SDSL Termination Unit, with DSX-1 Interface, User’s
Guide
To order a paper copy of a Paradyne document:
HWithin the U.S.A., call 1-800-PARADYNE (1-800-727-2396)
HOutside the U.S.A., call 1-727-530-8623
Hotwire 8774 TDM SDSL Termination Unit
The Hotwirer8774 Termination Unit is a circuit card assembly that contains four
Time Division Multiplexer Symmetric Digital Subscriber Line (TDM SDSL) ports
and a DSX-1 interface. When the termination unit is used in a Hotwire 8600 or
8800 Series Digital Subscriber Line Access Multiplexer (DSLAM) chassis, it
transports up to 1544 kbps signals over traditional twisted-pair telephone wiring.
!HANDLING PRECAUTIONS FOR
STATIC-SENSITIVE DEVICES
This product is designed to protect sensitive components from damage
due to electrostatic discharge (ESD) during normal operation. When
performing installation procedures, however, take proper static control
precautions to prevent damage to equipment. If you are not sure of the
proper static control precautions, contact your nearest sales or service
representative.
496-15104

2 8774-A2-GZ40-30
February 2001
Installation Overview
Installation and configuration of the Hotwire 8774 TDM SDSL Termination Unit
consists of:
HInstalling the unit in the DSLAM.
HConnecting to the DTE.
HConnecting to an MDF.
HProviding initial unit identity information or changing existing identity
information.
HConfiguring your unit using the Configuration Edit menus.
Before you install the Hotwire 8774 TDM SDSL Termination Unit, read the
Important Safety Instructions on page 17.
Be sure to register your warranty at www.paradyne.com/warranty.
Planning the Installation
Review the following list to help plan for the installation.
-Obtain the applicable cables; refer to Cables You Need, below.
-Make sure the Hotwire DSLAM chassis is installed and power is supplied to
the chassis.
-After the Hotwire 8774 TDM SDSL Termination Unit is installed, there are
configuration procedures that must be performed before you can begin to use
the unit. Refer to the Hotwire 8774 TDM SDSL Unit, with DSX-1 Interface,
User’s Guide if you need detailed configuration procedures.
Cables You Need
The following standard cables are used with this product.
For the network connection:
HPlug-ended Telco 50-position cable for connection from the Hotwire 8600
Series DSLAM LINE port or one of the Hotwire 8800 Series DSLAM LINES
ports to the Main Distribution Frame (MDF) or other demarcation point.
For the DTE connection:
HThe 50-position plug to four 8-position non-keyed jacks (like Paradyne
Feature No. 8700-F1-505).
For further information refer to Connector Pin Assignments in the User’s Guide,
and the appropriate DSLAM installation document.

3
8774-A2-GZ40-30 February 2001
Installing TDM SDSL Cards
A Hotwire 8774 TDM SDSL Termination Unit can be installed, removed, and
replaced from a the DSLAM chassis without disrupting service to the other cards
in the chassis.
"Procedure
To install the unit:
1. Determine in which slot the unit will be installed. Verify that cards in adjacent
slots have been fastened.
2. Remove the filler plate from the installation slot and store for possible later
use.
3. Insert the unit into the DSLAM:
—For a Hotwire 8600 Series DSLAM chassis – Hold the unit horizontally,
with the component side facing up, and insert it into the left and right card
guides.
—For a Hotwire 8800 Series DSLAM chassis –Hold the unit vertically,
with the component side facing right, and insert it into the top and bottom
card guides.
4. Slide the unit into the slot until the power and network connectors seat firmly
in the mating connectors on the backplane.
CAUTION:
Do not force the unit into the slot. This can damage the backplane
connectors. If the card does not seat properly, remove the card and
reinstall it. If it still does not seat properly, call your service
representative.
The termination unit performs a power-on self-test. All of the LEDs turn ON
and OFF briefly. When the self-test is completed successfully, the SYSTEM
OK LED begins to pulse once per second.
5. If the LED is not pulsing, refer to Messages and Troubleshooting in the User’s
Guide.
6. Secure the unit by fastening the screws at each end of the faceplate.

4 8774-A2-GZ40-30
February 2001
Connecting to the DTE
Connection to the four ports of the Hotwire 8774 TDM SDSL Termination Unit is
through the 50-pin interface connector on its faceplate. Refer to Connector Pin
Assignments in the User’s Guide.
"Procedure
To connect the Hotwire 8774 TDM SDSL Termination Unit to your DTE:
1. Connect the 50-position connector of the cable to the connector on the
faceplate of the unit. Align one end of the cable connector with the card
connector, then push on the cable connector until it seats.
2. Feed the cable through the Cable Guide if it is installed. When all cables are
installed, anchor them with cable ties to the rack, DSLAM, or Cable Guide.
3. Connect the four terminating connectors to your DTE or DTEs.
Connecting to an MDF
You can connect the Hotwire DSLAM chassis containing the Hotwire 8774 TDM
SDSL Termination Unit to an MDF or other demarcation point. Do not connect it
to a POTS splitter.
"Procedure
To connect the Hotwire DSLAM chassis containing the unit to an MDF:
1. Plug the Telco 50-pin cable into the appropriate LINE port on the chassis:
2. Replace the longer Telco cable captive screw with a shorter connector
captive screw, which is provided with the Hotwire DSLAM chassis.
3. Insert a cable tie (provided with Hotwire DSLAM chassis) through the tie
mount to hold the Telco 50-pin connector in place. If more than one Telco
cable is being connected, span the two or three connectors.
4. Make sure the other end is connected to the appropriate MDF or demarcation
point.
Refer to Connector Pin Assignments in the User’s Guide for pinouts.
NOTE:
If connecting the Telco 25-pair, 50-pin cable to an MDF, a converter may be
necessary for terminating the other end of the cable on a punchdown block
before cross-connecting to an MDF.

5
8774-A2-GZ40-30 February 2001
Front Panel LEDs
The following table describes the meaning and states of the LEDs on the
Hotwire 8774 TDM SDSL Termination Unit’s faceplate.
Type LED LED is . . .* Indicating . . .
SYSTEM OK
(Green) On
Off
Slow Cycling
Pulsing
Unit failure; system processing has stopped.
No power to card.
Unit is in minimum mode and a download is
required.
Normal operation.
Alrm
(Amber) On
Off
Unit failure, or Power-On Self-Test (POST)
has failed.
No alarms.
Test
(Amber) On
Slow cycling
Off
Loopback test or 511 test pattern in progress.
POST in progress.
No tests.
DSX-1 1, 2, 3, 4
(Green) On
Slow cycling
Fast cycling
Off
Recoverable signal present on the DSX-1
network.
Yellow Alarm Indication (RAI) present.
An OOF, LOF, EER, or AIS condition exists.
No signal on the port.
DSL PORT 1, 2, 3, 4
(Green) On
Slow cycling
Fast cycling
Off
DSL link is up.
DSL training in progress.
OOF condition.
DSL link is down.
* Slow Cycling: LED turns off and on in equal duration once per second.
Fast Cycling: LED turns off and on in equal duration 5 times per second.
Pulsing: LED turns off momentarily once per second.
4
TDM
SDSL
8774
SYSTEM
OKAlrm
Test
123
123
DSX-1
DSL PORT
4
00-16144-01

6 8774-A2-GZ40-30
February 2001
Logging In to the Hotwire DSLAM
You can log in to the Hotwire DSLAM system using either a local VT100-
compatible terminal or a remote Telnet connection.
After you enter your user ID and password, the system displays the Hotwire
Chassis Main Menu. See your Management Communications Controller (MCC)
documentation for information about selecting the unit from the MCC card
selection screen.
Asynchronous Terminal Interface Menu
The following illustration shows the paths to the Hotwire 8774 TDM SDSL
Termination Unit’s various ATI screens.
Main
Status Test
System and
Test Status Performance Statistics Display LEDs Identity
Network
Error
Statistics
Network
Performance
Statistics
Configuration Control
Default
Factory
Configuration
Configuration
Loader
Current
Configuration
Change
Identity
Administer
Logins
Download
Code Apply
Download
Reset
Autorate
Network &
DSX-1Tests Device Tests Abort All Tests
01-15708-03
DSX-1
Statistics
Reset
Device
Current
Network
Performance
Network DSX-1 Copy
Ports System Options Management and
Communication
Telnet
Session SNMP NMS Security
General SNMP
Management SNMP
Traps

7
8774-A2-GZ40-30 February 2001
Entering Identity Information
After accessing your unit for the first time, use the Change Identity screen to
determine SNMP administrative system information that will be displayed on the
Identity screen of the Status branch. To access the Card Identity screen, follow
this menu selection sequence:
Main Menu →Control →Change Identity
Configuring the TDM SDSL Termination Unit
Configuration option settings determine how the unit operates. Use the
Configuration branch of the Hotwire 8774 TDM SDSL Termination Unit’s menu to
display or change configuration option settings.
The unit is shipped with factory settings in the Default Factory Configuration area.
If the factory default settings do not support your network’s configuration,
customize the configuration options for your application.

8 8774-A2-GZ40-30
February 2001
Accessing and Displaying Configuration Options
To display the configuration options, you must first load a configuration option set
into the edit area.
To load a configuration option set into the configuration edit area, follow this
menu selection sequence:
Main Menu →Configuration (Load Configuration From)
main/configuration Hotwire
Slot: 4 Model: 8774
LOAD CONFIGURATION FROM:
Current Configuration
Configuration Loader
Default Factory Configuration
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Ctrl-a to access these functions, ESC for previous menu MainMenu Exit
Î
ÎÎ
Make a selection by placing the cursor at your choice and pressing Enter.
If you select . . . Then . . .
Current
Configuration The selected configuration option set is loaded and the Configuration Edit/Display menu screen appears.
Configuration
Loader The Configuration Loader screen is displayed allowing you to upload or download configurations from a TFTP server.
Default Factory
Configuration The default factory configuration is loaded and the Configuration Edit/Display menu screen appears.

9
8774-A2-GZ40-30 February 2001
Configuration Edit/Display
The Configuration Edit/Display screen is displayed when the current, customer, or
default configuration is loaded and allows groups of configuration options to be
displayed. To access the Configuration Edit/Display screen, follow this menu
selection sequence:
Main Menu →Configuration →Current Configuration
–or –
Main Menu →Configuration →Default Factory Configuration
Î
Î
ÎÎ
ÎÎ
main/config/edit Hotwire
Slot: 4 Model: 8774
CONFIGURATION EDIT/DISPLAY
Network
DSX-1
Copy Ports
System Options
Management and Communication
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Ctrl-a to access these functions, ESC for previous menu MainMenu Exit
Save
Select . . . To Access the . . . To Configure the . . .
Network Network Interface Options, Table 1 T1 TDM SDSL network
interface Ports 1–4.
DSX-1 DSX-1 Interface Options, Table 2 DSX-1 interface Ports 1–4.
Copy Ports Copy Ports Options, Table 3 T1 TDM SDSL network and
DSX-1 interface ports by
copying options from port to
port.
System
Options System Options, Table 4 General system options of the unit.
Management
and
Communication
HTelnet Session Options, Table 5
HGeneral SNMP Management Options,
Table 6
HSNMP NMS Security Options, Table 7
HSNMP Traps Options, Table 8
Management support of the
unit through SNMP and
Telnet.

10 8774-A2-GZ40-30
February 2001
NOTE:
The SNMP NMS Security Options screen is not available in IP Conservative mode.
Table 1. Network Interface Options
Margin Threshold
Possible Settings: –5db, –4db, –3db, –2db, –1db, 0db, 1db,2db,3db,4db,5db,6db,
7db,8db,9db,10db
Default Setting: 0db
Determines the level, expressed in decibels, at which a signal-to-noise margin condition
is recognized.
Excessive Error Rate Threshold
Possible Settings: 1E–4,1E–5,1E–6,1E–7,1E–8,1E–9
Default Setting: 1E–6
Determines the error rate at which an excessive error rate (EER) condition is
recognized. The rate is the ratio of the number of CRC errors to the number of bits
received in a certain period.
AutoRate
Possible Settings: Enable, Disable
Default Setting: Disable
Determines whether the unit automatically adjusts to the best line rate for conditions, or
is fixed at the rate in the DSL Line Rate field. The automatically set rate cannot exceed
DSL Line Rate.
HAutoRate is only available when the unit is configured as an LTU.
DSL Line Rate
Possible Settings: 400, 528, 784, 1040, 1552
Default Setting: 1552
Determines the fixed line rate of the LTU when AutoRate is disabled, and the maximum
rate to which the unit can be set when AutoRate is enabled.
HDSL Line Rate is only available when the unit is configured as an LTU.
Peer IP Address
Possible Settings: 001.000.000.000 –223.255.255.255, Clear
Default Setting: 000.000.000.000
Specifies the peer IP address providing the remote management link on the DSL loop.
The Peer IP Address is only available when the unit is configured as an LTU.
HPeer IP Address is only available when the unit is configured as an LTU and the
unit is not running in IP Conservative mode.
Circuit Identifier
Possible Settings: [ASCII text], Clear
Default Setting: [blank]
Uniquely identifies the circuit number of the transmission vendor’s DSL line for
troubleshooting purposes.

11
8774-A2-GZ40-30 February 2001
Table 2. DSX-1 Interface Options
Port Status
Possible Settings: Enable, Disable
Default Setting: Enable
Determines whether the port can be configured and used.
Line Framing (LTU Only)
Possible Settings: ESF, D4
Default Setting: ESF
Specifies the framing format to be used by the DSX interface.
HLine Framing is only available when the unit is configured as an LTU. The NTU is
automatically configured to match the framing format used by the LTU.
Line Coding Format
Possible Settings: AMI, B8ZS
Default Setting: B8ZS
Specifies the line coding format to be used by the DSX interface.
Line Equalization
Possible Settings: 0-133, 133-266, 266-399, 399-533, 533-655
Default Setting: 0-133
Compensates for signal distortion for a DSX-1 signal over a given cable length.
Excessive Error Rate Threshold
Possible Settings: 1E–4,1E–5,1E–6,1E–7,1E–8,1E–9
Default Setting: 1E–4
Determines the error rate at which an excessive error rate (EER) condition is
recognized. The rate is the ratio of the number of CRC5 errors to the number of bits
received in a certain period.
Send AIS on Network Failure
Possible Settings: Enable, Disable
Default Setting: Enable
Specifies the action taken on the signal transmitted to the DSX-1 when a valid signal
cannot be recovered from the network interface (LOS or OOF).
Send All Ones on DSX-1 Failure
Possible Settings: Enable, Disable
Default Setting: Enable
Specifies the action taken on the signal transmitted to the network when a valid signal
cannot be recovered from the network interface (LOS or OOF).
Primary Clock Source
Possible Settings: DSX-1, Internal
Default Setting: Internal
Specifies where the unit will derive its timing from.
HPrimary Clock Source is only available when the unit is configured as an LTU. If
DSL Line Rate is set lower than 1552 kbps, Primary Clock Source is forced to
DSX-1 and cannot be changed.

12 8774-A2-GZ40-30
February 2001
Table 3. Copy Ports Options
From: Port n
Possible Settings: 1,2,3,4
Default Setting: 1
Controls the source of the configuration options.
To: Port y
Possible Settings: 1,2,3,4, All
Default Setting: 2
Controls the target of the configuration options.
NOTE: Peer IP Address and Circuit Identifier are not copied.
Table 4. System Options
DSL Mode
Possible Settings: LTU, NTU
Default Setting: LTU
Controls whether the unit is configured as a control unit or tributary unit. A
DSLAM-to-DSLAM configuration requires that one unit be set to NTU mode.
NOTE: Changing this option will reset the card.
Test Timeout
Possible Settings: Enable,Disable
Default Setting: Enable
Allows tests to end automatically. The feature should be enabled when the unit is
remotely managed, so that control can be regained after a test is accidentally executed.
Test Duration (min)
Possible Settings: 1–120
Default Setting: 10
Number of minutes for a test to be active before automatically ending.
HTest Duration (min) option appears when Test Timeout is enabled.
Telco Initiated Loopback
Possible Settings: Enable,Disable
Default Setting: Enable
Determines if the unit will respond to inband or bit oriented protocol loopback
commands on the DSX-1 interface.
Remote Telco Loopback
Possible Settings: Enable,Disable
Default Setting: Disable
Determines if the unit will perform a Telco initiated loopback on just the local unit or if
the loopback will be performed on the remote DSL unit.

13
8774-A2-GZ40-30 February 2001
Table 5. Telnet Session Options
Telnet Session
Possible Settings: Enable, Disable
Default Setting: Enable
Specifies if the unit will respond to a Telnet session request from a Telnet client on an
interconnected IP network.
Telnet Login Required
Possible Settings: Enable, Disable
Default Setting: Disable
Specifies whether a user ID and password are required to access to the ATI through a
Telnet session. Login IDs are created with a password and access level.
Session Access Level
Possible Settings: Administrator,Operator
Default Setting: Administrator
The Telnet session access level is interrelated with the access level of the Login ID.
Inactivity Timeout
Possible Settings: Enable, Disable
Default Setting: Disable
Provides automatic logoff of a Telnet session.
Disconnect Time (Minutes)
Possible Settings: 1–60
Default Setting: 5
Number of minutes of inactivity before a Telnet session terminates automatically.
Timeout is based on no keyboard activity.
HDisconnect Time (minutes) option appears when Inactivity Timeout is enabled.

14 8774-A2-GZ40-30
February 2001
Table 6. General SNMP Management Options
SNMP Management
Possible Settings: Enable, Disable
Default Setting: Disable
Enable or disables the SNMP management features.
Community Name 1
Possible Settings: [ASCII text], Public
Default Text: Public
Identifies the name of the community allowed to access the unit’s MIB. The community
name must be supplied by an external SNMP manager when that manager attempts to
access an object in the MIB.
Name 1 Access
Possible Settings: Read, Read/Write
Default Setting: Read
Determines the access level for Community Name 1.
Community Name 2
Possible Settings: [ASCII text], Public
Default Text: Public
Identifies the name of the second community allowed to access the unit’s MIB. The
community name must be supplied by an external SNMP manager when that manager
attempts to access an object in the MIB.
Name 2 Access
Possible Settings: Read, Read/Write
Default Setting: Read
Determines the access level for Community Name 2.

15
8774-A2-GZ40-30 February 2001
Table 7. SNMP NMS Security Options
NMS IP Validation
Possible Settings: Enable, Disable
Default Setting: Disable
Specifies whether security checking is performed on the IP address of SNMP
management systems attempting to access the node.
Number of Managers
Possible Settings: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10
Default Setting: 1
Specifies the number of SNMP management systems that can send SNMP messages.
NMS nIP Address
Possible Settings: 001.000.000.000 –223.255.255.255, Clear
Default Setting: 000.000.000.000
Specifies the Internet Protocol address used to identify each SNMP manager.
Access Level
Possible Settings: Read, Read/Write
Default Setting: Read
Determines the access level allowed for an authorized NMS when IP address validation
is being performed.

16 8774-A2-GZ40-30
February 2001
Table 8. SNMP Traps Options
SNMP Traps
Possible Settings: Enable, Disable
Default Setting: Disable
Controls the generation of SNMP trap messages. The options for addresses and types
of traps are located in this table.
Number of Trap Managers
Possible Settings: 1, 2, 3, 4, 5
Default Setting: 1
Sets the number of SNMP management systems that will receive SNMP traps.
HThis field is available only when the unit is not running in IP Conservative mode.
NMS nIP Address
Possible Settings: 001.000.000.000 –223.255.255.255, Clear
Default Setting: 000.000.000.000
Specifies the Internet Protocol address used to identify each SNMP trap manager.
HThis field is available only when the unit is not running in IP Conservative mode.
NMS nDestination
Possible Settings: IMC,DSL1,DSL2,DSL3,DSL4
Default Setting: IMC
Provides the network destination path of each trap manager.
HNMS nDestination is available only when the unit is configured as an NTU and not
running in IP Conservative mode. Disabled ports cannot be specified.
General Traps
Possible Settings: Disable, Warm, AuthFail, Both
Default Setting: Both
Determines which SNMP traps are sent to each trap manager.
Enterprise Specific Traps
Possible Settings: Enable, Disable
Default Setting: Disable
Determines if SNMP traps are generated for enterprise-specific events.
Link Traps
Possible Settings: Disable, Up, Down, Both
Default Setting: Both
Determines if SNMP traps are generated for link up and link down for one of the
communication interfaces.
Link Trap Interfaces
Possible Settings: Network, DSX-1, All
Default Setting: All
Determines if the SNMP linkUp, SNMP linkDown, and interface-related
enterpriseSpecific traps are generated for the network DSL interface and/or DSX-1
interface (DTE).

17
8774-A2-GZ40-30 February 2001
!Important Safety Instructions
1. Read and follow all warning notices and instructions marked on the product
or included in the manual.
2. Slots and openings in the cabinet are provided for ventilation. To ensure
reliable operation of the product and to protect it from overheating, these
slots and openings must not be blocked or covered.
3. Do not allow anything to rest on the power cord and do not locate the product
where persons will walk on the power cord.
4. Do not attempt to install or service this product yourself, as opening or
removing covers may expose you to dangerous high voltage points or other
risks. Refer all installation and servicing to qualified service personnel.
5. General purpose cables are provided with this product. Special cables, which
may be required by the regulatory inspection authority for the installation site,
are the responsibility of the customer.
6. When installed in the final configuration, the product must comply with the
applicable Safety Standards and regulatory requirements of the country in
which it is installed. If necessary, consult with the appropriate regulatory
agencies and inspection authorities to ensure compliance.
7. A rare phenomenon can create a voltage potential between the earth
grounds of two or more buildings. If products installed in separate buildings
are interconnected, the voltage potential may cause a hazardous condition.
Consult a qualified electrical consultant to determine whether or not this
phenomenon exists and, if necessary, implement corrective action prior to
interconnecting the products.
8. In addition, if the equipment is to be used with telecommunications circuits,
take the following precautions:
—Never install telephone wiring during a lightning storm.
—Never install telephone jacks in wet locations unless the jack is
specifically designed for wet locations.
—Never touch uninsulated telephone wires or terminals unless the
telephone line has been disconnected at the network interface.
—Use caution when installing or modifying telephone lines.
—Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.
—Do not use the telephone to report a gas leak in the vicinity of the leak.

18 8774-A2-GZ40-30
February 2001
EMI Notices
!UNITED STATES – EMI NOTICE:
This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
The authority to operate this equipment is conditioned by the
requirements that no modifications will be made to the equipment
unless the changes or modifications are expressly approved by
Paradyne Corporation.
!CANADA – EMI NOTICE:
This Class A digital apparatus meets all requirements of the Canadian
interference-causing equipment regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du
règlement sur le matérial brouilleur du Canada.

19
8774-A2-GZ40-30 February 2001
Warranty, Sales, Service, and Training Information
Contact your local sales representative, service representative, or distributor
directly for any help needed. For additional information concerning warranty,
sales, service, repair, installation, documentation, training, distributor locations, or
Paradyne worldwide office locations, use one of the following methods:
HInternet: Visit the Paradyne World Wide Web site at www.paradyne.com.
(Be sure to register your warranty at www.paradyne.com/warranty.)
HTelephone: Call our automated system to receive current information by fax
or to speak with a company representative.
—Within the U.S.A., call 1-800-870-2221
—Outside the U.S.A., call 1-727-530-2340
Document Feedback
We welcome your comments and suggestions about this document. Please mail
them to Technical Publications, Paradyne Corporation, 8545 126th Ave. N.,
Largo, FL 33773, or send e-mail to [email protected]. Include the
number and title of this document in your correspondence. Please include your
name and phone number if you are willing to provide additional clarification.
Trademarks
Hotwire is a registered trademark of Paradyne Corporation. All other products
and services mentioned herein are the trademarks, service marks, registered
trademarks or registered service marks of their respective owners.
Copyright E2001 Paradyne Corporation. Printed in U.S.A.
