Paradyne Hotwire 7996 Original operating instructions

7996-A2-374 SHDSL-G.703 NTU
Quick Installation Instructions
Document Number 7996-A2-GZ10-00
September 2004
Installation
➊Connect the LINE port to your DSL line with an RJ45
connector cable.
➋Connect the E1 interface to the data network using
two cables with BNC connectors for a 75 ohm
unbalanced E1 connection, or an RJ45 connector
cable for a 120 ohm balanced E1 connection.
➌Connect the LAN port to the SNMP management
network with an RJ45 connector cable.
➍Connect the Console port to a VT100-compatible
terminal or PC COM port with an RS232 cable.
➎Connect the Power to the power input.
For the DC version:
• –48V: Connect to –48 VDC power supply source.
• PG: Connect to the ground of –48 VDC power
supply source.
• FG : Connect to the frame ground.
For the AC version, connect the Power jack to the
power cable of the 110 or 220 VAC power adapter.
It can take a couple of minutes for the NTU to link up with
its partner unit.The link is up when the DSL LOS
indicator LED is off. See the User’s Guide for
management and troubleshooting information.
Off
On
Power Console
LAN
E1
LINE
DSL Line
VT100
Compatible
Terminal
Power
Adapter
04-17572
R T
or
120
ohm
75
ohm
E1 Interface
SNMP
Management
1
4
52
3
Copyright ©2004 Paradyne Corporation. Printed in U.S.A.
