Replacement Air Filter for the
HotWire 8800 DSLAM
Installation Instructions
Document Number 8800-A2-GN10-00
May 1997
What is an Air Filter?
The air filter prevents dust from entering the HotWire 8800 Digital Subscriber Line
Access Multiplexer (DSLAM) chassis. Install an air filter when the 8800 chassis is
in a dusty or unfiltered environment. Once the filter is installed, you should
inspect and/or replace the air filter periodically, or whenever the fan alarm is
active.
Installing the Replacement Air Filter
Procedure
To install the replacement air filter:
1. Unfasten the screws on the cover plate and remove it.
2. Remove the old air filter by sliding it out.
3. Slide the replacement air filter into the air filter channel guides.
4. Replace the cover plate and fasten screws.
97-15425
ALARMS
Major MinorFanBA
POWER
MGT
SERIAL
MGT
10BT ALARM
SLOTS 1- 6
SLOTS 7-12
SLOTS13-18
LINES
AB
-48V(A)
-48VINPUT
-48V(B) RET(A) RET(B)
246810 12 14 16 18
19
1357911 13 15 17
LAN/WAN SLOT 20
LAN/WAN SLOT
Cover Plate
Air Filter
