Paradyne 1752 SHDSL Original operating instructions

1752 SHDSL Router
Quick Installation Instructions
Document Number 1752-A2-GZ10-00
June 2005
Installation
➊Connect the supplied RJ11 cable to the port marked DSL at the
back of the SHDSL router. Connect the other end of the cable to
your SHDSL source.
➋Insert one end of the RJ45 Ethernet cable into one of the LAN
ports marked LAN on the back of the SHDSL router. Connect
the other end of the cable into the Ethernet Network Interface
Card (NIC) installed in your computer. Connect up to four
Ethernet devices to the router. Use a crossover cable for a hub.
➌Connect an earth ground to the grounding terminal (marked
FG).
➍Connect the supplied external AC adapter into the DC power
outlet on the back of the router. Connect the power supply into
your wall outlet or surge protector.
The router’s default IP address is 192.168.1.1. To configure the
router, set up your PC to be on the same network segment and open
192.168.1.1 with your web browser. The default user name is admin
and the default password is admin.
See the user’s guide on the CD for more information.
*1752-A2-GZ10-00*
*1752-A2-GZ10-00*
05-17665
FG
DSL
LAN
CID DC IN
Reset
Internet
RJ11
Switch
or
Hub
RJ45
Copyright 2005 Paradyne Corporation. Printed in U.S.A.
