FrameSaver®DSL 9788 Router
Installation Instructions
Document Number 9788-A2-GN11-00
July 2002
Contents
FrameSaver DSL Router Overview ............................................................... 2
Upgrading a Unit to Advanced SLM Feature Set .......................................... 3
Product Documentation Online ..................................................................... 3
Package Checklist ......................................................................................... 4
Wiring and Cables You May Need ................................................................ 5
Provisioning Data Circuits Before Installation ............................................... 6
Installing the Router ...................................................................................... 7
Power-On ...................................................................................................... 11
Status LEDs .................................................................................................. 12
Troubleshooting ............................................................................................. 13
Configuration Setup ...................................................................................... 14
Verifying that Self-Test Passed ..................................................................... 17
Using the Easy Install Feature ...................................................................... 17
Completing Setup From the NOC ................................................................. 18
Setting Up for In-Band Management ............................................................ 19
Provisioning the Router Interface .................................................................. 22
Cables and Connectors ................................................................................ 22
Router Technical Specifications .................................................................... 25
Important Safety Instructions ........................................................................ 26
Government Requirements ........................................................................... 27
Warranty, Sales, Service, and Training Information ...................................... 28

2
FrameSaver DSL Router Overview
The FrameSaver®DSL (Digital Subscriber Line) Router is a component in the
FrameSaver system. This system allows you to perform end-to-end service level
management (SLM) across a hybrid DSL/ATM/Frame Relay network. Service providers
can isolate and correct problems remotely from their NOC (Network Operations Center).
The router has a DSL interface and is a manageable frame relay-aware endpoint. It
operates as a bridge or an IP router that connects a DSL link to an Ethernet network.
The FrameSaver DSL Router is used for data only and provides corporate LAN access
over traditional twisted-pair copper telephone wiring. Copper pairs run from the central
office (CO) to the customer premises (CP) to create the local loop. The local loop
terminates on the customer premises at the demarcation point in a punchdown block or
network interface device (NID). The following diagram shows a typical use of the
FrameSaver DSL Router in a network.
DSL
Access
Network
00-16915a
ALARMS
MajorMinor
Fan
B
A
POWER
SERIAL
SMCM
CLOCK
A
ALARM
24681012141618
1357911131517
LAN/WANSLOT
B
CLOCKB
A
SERIAL
MCCAC
ALARM
48VRTN
48VNEG
POWERENTRYMODULE
LEFTUNIT:LINEA
RIGHTUNIT:LINEB
WARNING!
POWERMUSTBEDISCONNECTEDATTHESOURCE
BEFOREREMOVINGORINSTALLINGTHISPWRENTRYMODULE
48VRTN
48VNEG
POWERENTRYMODULE
LEFTUNIT:LINEA
RIGHTUNIT:LINEB
WARNING!
POWERMUSTBEDISCONNECTEDATTHESOURCE
BEFOREREMOVINGORINSTALLINGTHISPWRENTRYMODULE
ATM
Switches
Hotwire
GranDSLAMs
ALARMS
MajorMinor
Fan
B
A
POWER
SERIAL
SMCM
CLOCK
A
ALARM
24681012141618
1357911131517
LAN/WANSLOT
B
CLOCKB
A
SERIAL
MCCAC
ALARM
48VRTN
48VNEG
POWERENTRYMODULE
LEFTUNIT:LINEA
RIGHTUNIT:LINEB
WARNING!
POWERMUSTBEDISCONNECTEDATTHESOURCE
BEFOREREMOVINGORINSTALLINGTHISPWRENTRYMODULE
48VRTN
48VNEG
POWERENTRYMODULE
LEFTUNIT:LINEA
RIGHTUNIT:LINEB
WARNING!
POWERMUSTBEDISCONNECTEDATTHESOURCE
BEFOREREMOVINGORINSTALLINGTHISPWRENTRYMODULE
TDM
Access
Network
LAN
FR Network
FR/ATM
IWF
ATM
Switches FR
Switches
Frame Relay NSP's Network
ATM
NNI(s)
Aggregation
Switch
(Optional)
Copper
Loop
DSL
FrameSaver
DSL 9783
Bridge/Router
Endpoint
Customer
Premises–
Remote Site
Router
FrameSaver
Endpoint
Customer Premises–
HQ Site
Central Office
ATM
Services LAN
ATM –Asynchronous Transfer Mode
DSL –Digital Subscriber Line
FR –Frame Relay
HQ –Headquarters
IWF –Interworking Function
LAN –Local Area Network
NSP –Network Service Provider
TDM –Time Division Multiplexer

3
The FrameSaver DSL Router is available in two feature sets:
 Diagnostic Feature Set provides basic frame relay and diagnostic capability.
 Advanced SLM (Service Level Management) Feature Set provides the same
features as the Diagnostic Feature Set, plus service level management and
reporting capability.
Refer to
About FrameSaver DSL Devices in the User’s Guide for a list of FrameSaver
DSL router’s features, and the capabilities provided by each feature set.
Upgrading a Unit to Advanced SLM Feature Set
A FrameSaver DSL Router with the Diagnostic Feature Set can be upgraded to the
Advanced SLM Feature Set at any time by ordering a FrameSaver Advanced SLM
Activation Certificate (Feature Number 9788-C1-220). A certificate can be ordered for a
single DSL router, or for many DSL routers. You must specify the model to be activated
(for example, 9788-Rtr), your OpenLane SLM system license key number, and the
number of router activations to be included on the certificate.
The OpenLane®SLM system, Release 5.3 or later, is required toschedulethe activation
of Advanced SLM features and to manage the certificate activations included in the
certificate.
To learn more about activating the Advanced SLM Feature Set, refer to the
FrameSaver
SLV Activation Instructions
(Document Number 9000-A2-GK43), or contact your sales
representative.
Product Documentation Online
Complete documentation for this product is available at www.paradyne.com.
Select
Library
→
Technical Manuals
→
FrameSaver Frame Relay Devices.
Select the following document:
9700-A2-GB20
FrameSaver DSL, Models 9783 and 9788, User’s Guide
To order a paper copy of a Paradyne document:
 Within the U.S.A., call 1-800-PARADYNE (1-800-727-2396)
 Outside the U.S.A., call 1-727-530-8623

4
Package Checklist
In addition to these instructions, verify that your package contains the following:
❑FrameSaver DSL Router
❑Power cord with power transformer
❑Tie wrap for power cord strain relief
❑DSL network access cable (with U.S. models only)
❑
FrameSaver DSL Router, Models 9783 and 9788, Quick Reference (Document
Number 9700-A2-GL11)
Be sure to register your warranty at www.paradyne.com/warranty.

5
Wiring and Cables You May Need
The following wiring and cables are used with this product, which uses standard
interface connectors:
 Standard connectors: An 8-pin modular (similar to RJ45) wall jack for the DSL
network connection.
 DSL wiring: Unshielded twisted-pair wiring (CAT3, or better). The CAT3 wiring must
meet EIA/TIA-568 specifications with 24 AWG (0.5 mm) or 26 AWG (0.4 mm).
 Ethernet wiring: Shielded twisted-pair wiring (CAT5, or better). The CAT5 wiring
must meet EIA/TIA-568 specifications with 24 AWG (0.5 mm) or 26 AWG (0.4 mm).
For standard cables, refer to
Cables and Connectors on page 22 for standard pin
numbers. For Paradyne cables, contact your sales representative to order them.
Interface
Connection Cables Feature Number
COM
Communication
port to a PC or
asynchronous
terminal
DB9-to-DB9, standard EIA-232
straight-through cable —
ETHERNET
Ethernet port to a
NIC on a PC or an
Ethernet hub
For connection to a PC NIC:
Standard Ethernet crossover cable 9008-F1-550
For connection to an Ethernet Hub:
Standard Ethernet straight-through cable —
NET
Networkporttothe
DSL wall jack
Standard straight-through DSL network cable
with 8-pin modular connectors, similar to an
RJ45-to-RJ45 cable. Supplied with U.S.
models.
3100-F1-500

6
Provisioning Data Circuits Before Installation
Before installing the router, use the OpenLane SLM system’s Provision Circuit screen to
add:
 New circuits that start at the FrameSaver DSL endpoint and traverse the SCM and
ATM line card in the Hotwire®GranDSLAM™
 The default VC sets (from 1 to 4)
A group of 250 VCs can be allocated to each line card, which can be assigned to any
port on the card. These custom connections carry the frame relay traffic.
Note that before the custom cross-connections are configured, the Maximum VCI
number for the uplink VP to be used by these custom connections must be specified on
the Max VCI per VPI screen, and the apply changes executed.
For ATM line cards, custom connections can be used to expand the number of VCs
connected to the card. Each of the 250 VCs can be cross-connected from anyVC on the
uplink to any port on the line card.
The following information is collected by the Provision Circuit process:
 Uplink VPI/VCI
 Slot number and Port number of the DSL connection
 Traffic Profile
 DSL link VPI/VCI
 Frame relay DLCI (provided by NSP)
 Frame relay CIR, Be, Bc(provided by NSP)
A Circuit ID is then applied to the newly defined circuit, and stored in both the router and
the OpenLane SLM system.

7
Installing the Router
Place the FrameSaver DSL Router on a flat surface, with clearance for the rear
connectors.
Procedure
1. Use an 8-pin modular cable (supplied with U.S. models).
Insert one end of the cable into the jack labeled NET. Insert the other end into the
wall jack for DSL data communications.
ETHERNET
POWER NET
COM
NET
01-16981
DSL
Network

8
2. Use an 8-pin Ethernet cablefor the Ethernet connection. Insert one endof the cable
into the jack labeled ETHERNET.
—Use a straight-through cable to connect the other end of the cable to an
Ethernet hub. Do not connect to the hub’s optional Uplink connection with a
straight-through cable; the Uplink connection requires an Ethernet crossover
cable.
–or –
—Use an Ethernet crossover cable to connect to a PC with an Ethernet Network
Interface Card (NIC) installed or a hub’s Uplink connection.
01-16982
Ethernet
Straight-Through
Cable
ETHERNET
ETHERNET
POWER NET
COM
Hub

9
3. Use a VT100-compatible asynchronous terminal or PC to set up management
access to the unit. Insert the DB9 end of an EIA-232 cable into the router’s COM
port. Tighten the screws on each side of the connector. Insert the other end into the
terminal or PC.
The terminal or PC’s configuration must becompatible with the router’s. Refer to the
procedure on page 15 of
Configuration Setup . If connecting an external modem to
the COM port, refer to
Connecting an External Modem on page 24.
ETHERNET
POWER NET
COM
COM
01-16983

10
4. Insert the supplied power cord’s round end into the jack labeled POWER. Plug the
transformer into an AC outlet.
Install the supplied tie wrap for strain relief, as shown.
Installation of the hardware is now complete. When the power cord is installed, the
router goes through a power-on self-test.
ETHERNET
POWER NET
COM
01-16984
Grounded
Power
Outlet
Cable
Tie
POWER

11
Power-On
When power is applied, the router performs self-diagnostics and the PWR LED is on.
The self-diagnostics include a power-on self-test where all of the LEDs are on.
Refer to
Status LEDs on page 12 for information about the LEDs. Refer to
Troubleshooting on page 13 for LED indications requiring action.
FrameSaver DSL 9788 Router
01-16985
OK OK
ALM
TEST
ATM
DSL
NetworkSystem Port
9788 ROUTER
SLV
FrameSaver ®
DSL
SHDSL
R
System OK –green
Alarm –red
Test –yellow
ATM –green
DSL –green
Ethernet Port –green

12
Status LEDs
After a successful self-test, the LEDs should appear as indicated in BOLD in the
Condition column below.
LED Condition Status
System LEDs
OK ON The router has power.
ALM ON
OFF
An alarm condition exists.
No alarms have been detected by the router.
TEST ON
OFF
The router is performing the power-on self-test, or a test
initiated by the service provider is currently active.
No tests are active.
Network LEDs
ATM ON –Green
OFF
ATM LED is active and cell delineation is in sync.
ATM mode is active and there is loss of cell delineation.
DSL Blinking
ON
OFF
The router is in start-up or is retraining. The LED blinks
on and off about five times per second.
The DSL link is ready to transmit and receive data.
No DSL link has been established, or the link is down.
Port LED
OK ON
OFF
The Ethernet port is transmitting and receiving data.
Self-diagnostics have not been completed successfully.

13
Troubleshooting
LED Symptom Action
All LEDs are on. If the LEDs remain on for more than ten minutes, the router is
not functional. Unplug the router and reapply power. If the
ALM LED is still on, contact the service provider.
ALM LED only
remains on. The power-on self-test may have failed. Unplug the router and reapply power. If the alarm LED is still on, contact the
service provider.
ALM and TEST LEDs
are blinking. Firmware download may be in progress. If firmware download is not in progress or the LEDs continue blinking for
more than ten minutes, contact the service provider.
Do not
unplug the unit, unless instructed to do so by the service
provider.
ATM LED is off while
DSL LED is on. There is loss of cell delineation (OCD) due to line impairments. Contact the service provider.
DSL LED is off. Verify that the DSL cable is securely installed on both ends.
Unplug the unit and reapply power. If the problem continues,
contact the service provider.
DSL LED continues
blinking after the
power-on self-test
has completed.
The router is attempting to establish the DSL link, or adjusting
the DSL line rate due to line conditions. If the blinking
continues for more than ten minutes, contact the service
provider.
DSL and ATM LEDs
are on, but no data is
being transmitted.
The DSL link has been established, but there is no data
transmission. Verify the Ethernet connection. If the problem
persists, contact the service provider.
DSL, ATM, and Port
LEDs are on, but no
data is being
transmitted.
DSL and Ethernet links have been established, but there is
no data transmission. If the problem continues, contact the
service provider.
Port LED is off. Verify that the Ethernet cable is securely installed at both
ends, and at least one PC is connected and powered on.
Verify that the correct Ethernet straight-through or crossover
cable is installed. Refer to Step 2 on page 8.
System OK LED is off. Check that the power cord is securely installed on both ends.
If no LEDs are on, the power supply may be defective. Test
the outlet to verify power. If the outlet has power and the
problem persists, contact your service representative.
If other LEDs are on, the OK LED may be burned out. Unplug
the unit and reapply power, and watch all LEDs as the router
performs its power-on self-test. If the OK LED is functioning,
call your service representative.
TEST LED is on. A test initiated by the service provider may be active. Wait ten
minutes. If the LED does not go off, contact the service
provider.

14
Configuration Setup
Once the router is installed, it can be accessed locally through the menu-driven user
interface via an asynchronous terminal or PC connection, or remotely via a Telnet
session, and the router’s interfaces can be provisioned. The following provisioning can
be set up:
 Frame relay, ATM, and physical layer provisioning –Typically set up by the LEC
(Local Exchange Carrier) or CLEC (Competitive LEC) using the menu-driven user
interface via an ASCII terminal or PC running a terminal emulation program, or a
Telnet session.
 Router provisioning, using the CLI –Typically accessed by the frame relay
service provider providing managed router service, or by the end user.
 SLM provisioning –Typically set up by the frame relay service provider, LEC, or
CLEC.
As soon as the router’s COM port is connected to a terminal or PC, the menu-driven
user interface can be accessed. The terminal or PC’s configuration must be compatible
with the router’s COM port settings.

15
Procedure
To access the menu-driven user interface:
1. Verify the terminal or PC’s configuration:
—Data Rate is set to 19.2 kbps.
—Character Length is set to 8 data bits.
—Parity is set to None.
—Stop Bits is set to 1.
—Flow Control is set to None.
2. Press Enter to display the Main Menu.
If the Main Menu does not appear:

Press Enter again

Check the terminal or PC settings

Refer to
Troubleshooting
in the User’s Guide
main 9788-RtrSLV
Device Name: Node A 6/05/2001 00:02
MAIN MENU
Status
Test
Configuration
Control
Easy Install
-----------------------------------------------------------------------------
Ctrl-a to access these functions, Shift-r to access the Router's CLI. Exit

16
Menu Navigation
The router should operate using the default (factory-set) configuration options. Refer to
the following table for help in navigating the menus.
As an example, follow these steps to go to the Configuration Edit/Display menu so you
can start setting up the unit.
Procedure
To load a configuration for editing:
1. From theMain Menu, press the Tab key twice, or press the down (↓) arrow twice, so
the cursor is on Configuration.
2. Press Enter to select Configuration. The Load Configuration From menu appears.
3. Press Enter to select Current Configuration (the cursor is already on this selection).
The Configuration Edit/Display menu appears.
This sequence of steps would be shown as the menu selection sequence:
Main Menu
→
Configuration
Procedure
To save configuration changes:
1. Press Ctrl-a to switch to the function keys area at the bottom of the screen.
2. Type s(Save) and press Enter. The Save Configuration To menu appears.
3. Press Enter again to save your changes to the Current Configuration (the cursor is
already on this selection).
To continue configuring the router, press Esc until the Configuration Edit/Display menu
reappears. To return to the Main Menu, press Ctrl-a, type m(MainMenu), and press
Enter.
Press the . . . To . . .
Esc key Go back one screen or menu level. For a visual display of
the menu hierarchy, see the Quick Reference.
Tab key, and
Up (↑), Down (↓),
Left (←), Right (→)
Arrow keys
Move the cursor from one menu item to the next.
Enter or Return key Complete the menu or option selection.
Spacebar Display the next available setting when changing a
configuration option. All the available settings for an option
appear at the bottom of the screen.

17
Verifying that Self-Test Passed
To verify that the unit passed its self-test, go to the System and Test Status screen.
Main Menu → Status → System and Test Status
The results of the self-test appear directly under the screen title.
If any failure messages appear, reset the unit by disconnecting, then reconnecting the
power cord. The unit will perform the self-test again. If the failure reappears, call your
service representative for assistance.
Using the Easy Install Feature
An Easy Install screen is provided for custom configurations, but you are not required to
use it for normal installation. You can configure the router by making selections from the
Configuration Edit/Display menu.
Procedure
1. Select the Easy Install feature.
Main Menu → Easy Install
Easy Install Screen Example
2. Enter the Node IP Address and Subnet Mask.
main/easy_install 9788-RtrSLV
Device Name: Node A 6/5/2001 00:01
EASY INSTALL
Node IP Address: 000.000.000.000 Clear
Node Subnet Mask: 000.000.000.000 Clear
TS Access: VPI,VCI 0,35
Create a Dedicated Network Management Link
Ethernet Management Options Screen
Network 1 DSL Line Rate Mode Fixed
Network 1 DSL Line Rate (Kbps) 784
Network 1 FRF.8 Encapsulation Mode Transparent
-----------------------------------------------------------------------------
Ctrl-a to access these functions, ESC for previous menu MainMenu Exit
Save

18
3. Specify TS Access if a Troubleshooting (TS) DLCI or Virtual Circuit (VC) is being
set up for remote access by the service provider. The default is 0,35.
4. Select Create a Dedicated Network Management Link to set up for permanent
remote access by the NOC. Enter a DLCI, VPI, and VCI at the resulting prompts.
5. Select the Ethernet Management Options Screen to go directly to the Ethernet
Management Options screen. The interface (Status) is already enabled.
—Enter the IP Address (for example, 10.101.51.253) and Subnet Mask (for
example, 255.255.255.0) for the Ethernet interface.
—Enter the Default Gateway Address (the IP Address that will be used for
packets without a specified route).
—Press the Esc key to return to the Easy Install screen.
6. Change Network 1 DSL Line Rate (Kbps), if desired. The default is AutoRate.
7. Save the configuration and return to the Configuration Edit/Display menu.
Completing Setup From the NOC
Procedure
1. Access the router on the TS Management Link that was set up at the remote site in
Step 4 of
Using the Easy Install Feature .
2. Ping the router five times within five seconds. The router automatically provisions
the TS Access VC and accepts the destination IP address of the Ping as its
temporary IP address, which is used on the management VC interface.
3. If necessary, open a Telnet session and configure any specific configuration options
that require input or changes from default settings. Create all customer VCs,
including internal DLCIs and VPI/VCIs on the DSL interface, and cross-connect the
DLCIs to the VCCs.

19
Configuring SNMP Trap Managers and Traps
Procedure
To enter SNMP managers and configure traps:
1. Select SNMP Traps.
Main Menu
→
Configuration
→
Management and Communication
→
SNMP Traps
2. Configure the following:
—Enable SNMP Traps.
—Identify the total Number of Trap Managers.
—Specify the IP address for each NMS Trap Manager to which traps will be sent.
—Specify the Initial Route Destination for each Trap Manager. The default is
AutoRoute.
—Select or disable trap categories, as needed.
3. Save the configuration.
Setting Up for In-Band Management
If FRF.8 Encapsulation Mode is set to Translational, remote management of the router
can still be accomplished in-band, as indicated in the following procedure.
Before you use the following procedure, verify that:

The router’s Ethernet interface has already been assigned an IP address that is in
the same subnet as the management IP address entered in Step 5 on page 18 of
Using the Easy Install Feature

The router is not configured for bridging only
Refer to
Configuring the FrameSaver DSL Router
;
CLI Commands, Codes, and
Designations
, and
Command Line Summaries and Shortcuts
in the User’s Guide for
additional information.

20
Procedure
1. Create a DLCI on the router virtual port.
Configuration
→
Vitual Router Ports
→
DLCI Records
Assign the DLCI number that will be used for management on Serial port 0
(Rtr-S0 –e.g., DLCI 900).
2. Create a management PVC using the DLCI just configured on Serial port 0
to connect the management link to the router.
Configuration
→
Management and Communication
→
Management PVCs
Using the DLCI 900 example, make the following connection:
—Select Name: Mgmt900
—Intf IP Address: Special, and add the IP address for the Ethernet interface in
Step 5 on page 18 of
Using the Easy Install Feature .
—Intf Subnet Mask: Special, and add the Subnet Mask for the Ethernet interface
in Step 5 on page 18 of
Using the Easy Install Feature .
—Set DE: Leave at the default, Disable.
—Primary Link: Select Rtr-S0.
—Primary DLCI: Select 900.
3. Return to the Main Menu and press Shift-r to access the router’s CLI.
4. From the CLI, enable password and show the router’s configuration.
en
show config
A list of the router’s configuration is shown, most of the configuration already
completed using the default values.
interface serial 0.900
ip unnumbered
frame-relay interface-dlci 900
no bridge-group 1
exit
5. Add the route to the routing table.
config t
ip route 10.101.51.253 255.255.255.255 Serial 0.900
save
exit
6. Ping the Ethernet management interface to verify that the router can be reached.
ping 10.101.51.253
exit
The router is now set up for in-band management.
