Paradyne Hotwire Routers User manual

HOTWIREDSL ROUTERS
USER’S GUIDE
Document No. 6371-A2-GB20-10
August 2000

A 6371-A2-GB20-10
August 2000
Copyright E2000 Paradyne Corporation.
All rights reserved.
Printed in U.S.A.
Notice
This publication is protected by federal copyright law. No part of this publication may be copied or distributed,
transmitted, transcribed, stored in a retrieval system, or translated into any human or computer language in any form
or by any means, electronic, mechanical, magnetic, manual or otherwise, or disclosed to third parties without the
express written permission of Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773.
Paradyne Corporation makes no representation or warranties with respect to the contents hereof and specifically
disclaims any implied warranties of merchantability or fitness for a particular purpose. Further, Paradyne Corporation
reserves the right to revise this publication and to make changes from time to time in the contents hereof without
obligation of Paradyne Corporation to notify any person of such revision or changes.
Changes and enhancements to the product and to the information herein will be documented and issued as a new
release to this manual.
Warranty, Sales, Service, and Training Information
Contact your local sales representative, service representative, or distributor directly for any help needed. For
additional information concerning warranty, sales, service, repair, installation, documentation, training, distributor
locations, or Paradyne worldwide office locations, use one of the following methods:
HInternet: Visit the Paradyne World Wide Web site at www.paradyne.com. (Be sure to register your warranty
at www.paradyne.com/warranty.)
HTelephone: Call our automated system to receive current information by fax or to speak with a company
representative.
— Within the U.S.A., call 1-800-870-2221
— Outside the U.S.A., call 1-727-530-2340
Document Feedback
We welcome your comments and suggestions about this document. Please mail them to Technical Publications,
Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773, or send e-mail to [email protected]. Include
the number and title of this document in your correspondence. Please include your name and phone number if you
are willing to provide additional clarification.
Trademarks
ACCULINK, COMSPHERE, FrameSaver, Hotwire, and NextEDGE are registered trademarks of Paradyne
Corporation. MVL, OpenLane, Performance Wizard, and TruePut are trademarks of Paradyne Corporation. All other
products and services mentioned herein are the trademarks, service marks, registered trademarks, or registered
service marks of their respective owners.

i
6371-A2-GB20-10 August 2000
Contents
About This Guide
HDocument Purpose and Intended Audience v. . . . . . . . . . . . . . . . . . . . . . . . .
HDocument Summary vi. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HProduct-Related Documents vii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HDocument Conventions viii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1 Introduction to Hotwire DSL Routers
HWhat is a Hotwire DSL Router? 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DSL Technologies Supported 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HTypical DSL Router System 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HHotwire DSL Router Features 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HService Subscriber 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Accessing the DSL Router
HAccess Control to the DSL Router 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Levels of Access 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing Access Session Levels 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Local Console Access 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting Up the New User’s Login 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Telnet Access 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Determining the Current Access Level 2-4. . . . . . . . . . . . . . . . . . . . . . . . .
Determining the Available Commands 2-4. . . . . . . . . . . . . . . . . . . . . . . . . .
Using the List Command 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the System Identity 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HExiting from the System 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manually Logging Out 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatically Logging Out 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents
ii 6371-A2-GB20-10
August 2000
3 Configuring the DSL Router
HOverview of DSL Router Configuration 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HInterfaces for the DSL Router 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ethernet and DSL Interface Identifiers 3-2. . . . . . . . . . . . . . . . . . . . . . . . . .
Service Domain IP Address Assignments 3-2. . . . . . . . . . . . . . . . . . . . . . .
Numbered DSL Interface 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Unnumbered DSL Interface 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HIP Routing 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HNetwork Considerations 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HAddress Resolution Protocol (ARP) 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HProxy ARP 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HNetwork Address Translation (NAT) 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Basic NAT 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Network Address Port Translation (NAPT) 3-6. . . . . . . . . . . . . . . . . . . . . .
IP Options Processing 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Applications Supported by NAT 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HDynamic Host Configuration Protocol (DHCP) Server 3-7. . . . . . . . . . . . . . . .
HDHCP Relay Agent 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HSecurity 3-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IP Filtering 3-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Land Bug/Smurf Attack Prevention 3-9. . . . . . . . . . . . . . . . . . . . . . . . . . . .
HRouted vs. Bridged PDUs 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 DSL Router Configuration Examples
HConfiguration Examples 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Basic Configuration Example 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Basic NAT Configuration Example 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
NAPT Configuration Example 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Unnumbered DSL Interface with Proxy ARP Configuration Example 4-5
DHCP Relay with Proxy ARP Configuration Example 4-6. . . . . . . . . . . . .
DHCP Server with Basic NAT Configuration Example 4-7. . . . . . . . . . . .
Downstream Router Configuration Example 4-8. . . . . . . . . . . . . . . . . . . . .

Contents
iii
6371-A2-GB20-10 August 2000
5 Monitoring the DSL Router
HWhat to Monitor 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HDetecting Problems 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HStatus of Interfaces 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HInterface Statistics 5-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HClearing Statistics 5-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HList of Discard Reasons 5-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 Diagnostics and Troubleshooting
HDiagnostics and Troubleshooting Overview 6-1. . . . . . . . . . . . . . . . . . . . . . . . .
HDevice Restart 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HAlarms Inquiry 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HSystem Log 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SYSLOG Events 6-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SYSLOG Message Display 6-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HPing 6-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ping Test Results 6-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HTraceRoute 6-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TraceRoute Test Results 6-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A Command Line Interface
HCommand Line Interface Feature A-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Navigation A-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Command Recall A-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Document Conventions A-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HCommand Line Interface Commands A-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuration Control Commands A-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RFC 1483 Encapsulation A-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ethernet Frame Format A-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interface and Service Domain IP Address A-4. . . . . . . . . . . . . . . . . . . . . .
IP Routing Table A-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ARP Table A-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Proxy ARP A-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
NAT A-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DHCP Server A-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DHCP Relay Agent A-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IP Packet Processing A-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Traps A-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Show Command Outputs A-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents
iv 6371-A2-GB20-10
August 2000
B Configuration Defaults & Command Line Shortcuts
HConfiguration Default Settings B-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HCommand Line Input Shortcuts B-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
C Traps & MIBs
HSNMP Overview C-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HTraps Overview C-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DSL Router Traps C-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HMIBs Overview C-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HStandard MIBs C-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MIB II (RFC 1213) C-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Group C-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interfaces Group (RFC 1573) C-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Extension to Interfaces Table (RFC 1573) C-7. . . . . . . . . . . . . . . . . . . . . .
IP Group (RFC 1213) C-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IP CIDR Route Group (RFC 2096) C-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmission Group C-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SNMP Group C-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ethernet-Like MIB (RFC 2665) C-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HParadyne Enterprise MIBs C-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Device Control MIB C-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Device Diagnostics MIB C-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Health and Status MIB C-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuration MIB C-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interface Configuration MIB C-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ARP MIB C-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
NAT MIB C-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DHCP MIB C-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DSL Endpoint MIB C-19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SYSLOG MIB C-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interface Configuration MIB C-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D DSL Router Terminal Emulation
HDSL Router Terminal Emulation D-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessing the List Command Output D-1. . . . . . . . . . . . . . . . . . . . . . . . . . .
Terminal Emulation Programs D-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Index

v
6371-A2-GB20-10 August 2000
About This Guide
Document Purpose and Intended Audience
This guide describes how to configure and operate Hotwire DSL routers. This
document addresses the use of the following Hotwire DSL Router models:
HHotwire 6301/6302 IDSL Router
HHotwire 6341/6342 Symmetric DSL Router
HHotwire 6371 RADSL Router
This document is intended for administrators and operators who maintain the
endpoints at customer premises. A basic understanding of internetworking
protocols and their features is assumed. Specifically, you should have familiarity
with the following internetworking concepts:
HTCP/IP applications
HIP and subnet addressing
HIP routing
HBridging
It is also assumed that you have already installed a Hotwire DSL Router. If not,
refer to
Product-Related Documents on page vii for installation documents.

About This Guide
vi 6371-A2-GB20-10
August 2000
Document Summary
Section Description
Chapter 1 Introduction to Hotwire DSL Routers. Provides an overview
of the Hotwire DSL Routers.
Chapter 2
Accessing the DSL Router. Describes the Hotwire DSL
Routers access control and provides instructions on how to
log in and log out of the system.
Chapter 3
Configuring the DSL Router. Describes the DSL router
interfaces, Domain Types, IP Routing, and network
considerations.
Chapter 4
DSL Router Configuration Examples. Presents several
common DSL router configuration examples.
Chapter 5
Monitoring the DSL Router. Describes operator programs
that monitor the Hotwire system.
Chapter 6
Diagnostics and Troubleshooting. Describes common
Hotwire operational problems and solutions. Contains
SysLog information.
Appendix A
Command Line Interface. Provides explanation of the DSL
router’s Command Line Interface and command syntax with
examples.
Appendix B
Configuration Defaults & Command Line Shortcuts.
Provides a list of all configuration options with factory
default settings and a list of all command line shortcuts with
the abbreviated command line input.
Appendix C
Traps & MIBs. Summarizes the MIBs and SNMP traps
supported by the DSL routers.
Appendix D
DSL Router Terminal Emulation. Provides configuration
setup procedures for two common text file programs.
Index Lists key terms, acronyms, concepts, and sections in
alphabetical order.
A master glossary of terms and acronyms used in Paradyne documents is
available on the Web at www.paradyne.com. Select
Library → Technical
Manuals
→ Technical Glossary.

About This Guide
vii
6371-A2-GB20-10 August 2000
Product-Related Documents
Contact your sales or service representative to order additional product
documentation.
Document Number Document Title
6301-A2-GN10 Hotwire 6301/6302 IDSL Routers Installation
Instructions
6341-A2-GN10 Hotwire 6341/6342 Symmetric DSL Routers
Installation Instructions
6371-A2-GN10 Hotwire 6371 RADSL Router Installation Instructions
8000-A2-GB22 Hotwire Management Communications Controller
(MCC) Card, IP Conservative, User’s Guide
8000-A2-GB26 Hotwire IP MVL, RADSL, IDSL, and SDSL Cards,
Models 8310/8312/8314, 8510/8373/8374, 8303/8304,
and 8343/8344, User’s Guide
Contact your sales or service representative to order additional product
documentation.
Paradyne documents are also available on the World Wide Web at
www.paradyne.com. Select Library → Technical Manuals →
Hotwire DSL & MVL
.

About This Guide
viii 6371-A2-GB20-10
August 2000
Document Conventions
The following syntax is used throughout this document.
Syntax Translation
[ ] Square brackets represent an optional element.
{ } Braces represent a required entry.
|Vertical bar separates mutually exclusive elements.
Italics
Entry is a variable to be supplied by the operator.
Bold Enter (type) as shown.
x.x.x.x 32-bit IP address and mask information where x is an
8-bit weighted decimal notation.
xx:xx:xx:xx:xx:xx MAC address information where x is a hexadecimal
notation.

1-1
6371-A2-GB20-10 August 2000
Introduction to Hotwire DSL
Routers 1
What is a Hotwire DSL Router?
The HotwirerDSL (Digital Subscriber Line) Router operates as an IP router
connecting a DSL link to an Ethernet network. This system provides high-speed
access to the Internet or a corporate network over a traditional twisted-pair
copper telephone line to the end user.
DSL Technologies Supported
Paradyne’s Hotwire DSL network supports the following types of technologies:
HHotwire IDSL (ISDN DSL) products provide IDSL multirate symmetric packet
transport and can operate over a connection with an ISDN repeater or digital
facilities. Data rates of 64 kbps, 128 kbps, or 144 kbps can be configured.
HHotwire RADSL (Rate Adaptive DSL) products are applicable for both
asymmetric and symmetric applications. The 1 Mbps symmetric operation is
ideal for traditional business applications while the 7 Mbps downstream with
1.1 Mbps upstream asymmetric operation provides added bandwidth for
corporate Internet access. RADSL products can also save line costs by
optionally supporting simultaneous data and voice over the same line.
HHotwire SDSL (Symmetric DSL) packet-based products provide high-speed
symmetric DSL services with bandwidth for business applications. These
products are configurable from 144 kbps up to 2.3 Mbps. This gives service
providers the opportunity to sell multiple services with a single product.

Introduction to Hotwire DSL Routers
1-2 6371-A2-GB20-10
August 2000
Typical DSL Router System
DSL is a local loop technology that uses standard twisted-pair copper wire to
support high-speed access over a single pair of twisted copper wires. DSL
applications are point-to-point, requiring DSL devices at the central site and at the
end-user site.
The Hotwire DSL routers interoperate with the following types of Hotwire IP DSL
cards (at the DSLAM/GranDSLAM chassis) to deliver applications at high speeds
in support of packet services over a DSL link:
HThe Hotwire 8303 or 8304 IP IDSL Cards interoperate with two Hotwire IDSL
Routers:
— Hotwire 6301 IDSL Router with one Ethernet port
— Hotwire 6302 IDSL Router with a 4-port Ethernet hub
HThe Hotwire 8343 or 8344 SDSL Cards interoperate with two Hotwire
Symmetric DSL Routers:
— Hotwire 6341 SDSL Router with one Ethernet port
— Hotwire 6342 SDSL Router with a 4-port Ethernet hub
HThe Hotwire 8510, 8373, and 8374 IP RADSL Cards interoperate with the
Hotwire 6371 RADSL Router with one Ethernet port
The following illustration shows a typical Hotwire system with a Hotwire DSL
Router. All Hotwire DSL routers transport data. The Hotwire 6371 RADSL Router
can transport data and POTS simultaneously.
Legend: DSL – Digital Subscriber Line POTS – Plain Old Telephone Service
MDF – Main Distribution Frame
* 6371 RADSL Router Only
IP DSL
Line
Card
DSLAM
Central Office (CO)
00-16576-02
Customer Premises (CP)
DSL
Router
CP
POTS
Splitter
CO
POTS
Splitter
MDF POTS/DSL
Core
Router
Data
Interface
POTS
*
Network
Service
Provider
Optional
Optional
Corporate
Intranet
Network Access Provider (NAP) Service Subscriber

Introduction to Hotwire DSL Routers
1-3
6371-A2-GB20-10 August 2000
Hotwire DSL Router Features
The Hotwire DSL routers contain the following features.
HIP routing with:
— NAT (Network Address Translation)
— NAPT (Network Address Port Translation)
— DHCP Server (Dynamic Host Configuration Protocol) and DHCP Relay
Agent
— A full set of IP filters
— SNMP Set/Get capability
HHigh-speed Internet or intranet access.
HDiagnostics. Provides the capability to diagnose device and network
problems and perform tests.
HDevice and Test Monitoring. Provides the capability of tracking and
evaluating the unit’s operation.
HRemote Firmware Download. Provides easy setup and activation of
firmware upgrades from a remote location.
HSecurity. Provides multiple levels of security, which prevents unauthorized
access to the DSL router.
HConsole Terminal Interface. Provides an interface for:
— Configuring and managing the DSL router.
— Remote terminal access via Telnet.
— Management from an NMS using SNMP.

Introduction to Hotwire DSL Routers
1-4 6371-A2-GB20-10
August 2000
Service Subscriber
The Service Subscriber is the user (or set of users) that has contracted to receive
networking services (e.g., Internet access, remote LAN access) for the end-user
system from an NSP (Network Service Provider). Service subscribers may be:
HResidential users connected to public network services (e.g., the Internet)
HWork-at-home users connected to their corporate intranet LAN
HCommercial users at corporate locations (e.g., branch offices) connected to
other corporate locations or connected to public network services
The Hotwire DSL Router must be installed at the customer premises to provide
the end user with access to any of the above services.
NOTE:
If you would like more information on DSL-based services, applications, and
network deployment, refer to Paradyne’s
The DSL Sourcebook. The book
may be downloaded or ordered through Paradyne’s World Wide Web site at
www.paradyne.com/library.

2-1
6371-A2-GB20-10 August 2000
Accessing the DSL Router 2
Access Control to the DSL Router
The Hotwire DSL Router can be managed from an NMS using SNMP or from the
command line interface. There are two methods to access the command line
interface:
HLocal access at the DSL router through the Console port, or
HAccess by a Telnet session (controlled through the management interface at
the Hotwire chassis).
When a local console connection is first established, a login prompt appears. The
Hotwire DSL Router accepts only one login session at a time. The DSL Router is
configured at the factory with a default login ID and password. However, to
provide login security to the DSL system, configure a new login ID and password.
Levels of Access
There is one login ID and two levels of privileges on the Hotwire DSL system.
Your user account can be configured with one user name and different
passwords for:
HAdministrator. The Administrator has two levels of access to the DSL router.
— Administrator, non-configuration mode: Provides read-only capabilities.
This is the same level of access as Operator.
— Administrator, configuration mode: Provides complete write access to the
DSL router. However, MIB sets are done from the NMS vs. the command
line.
HOperator. The Operator has read-only access to display device information
with no modification permission and no access to management functions.
Refer to Appendix A,
Command Line Interface , for access level details for each
command line entry.

Accessing the DSL Router
2-2 6371-A2-GB20-10
August 2000
Changing Access Session Levels
HYou can change the Administrator access level by entering:
admin enable
This command provides Administrator access level privileges. The DSL
router will respond with a prompt to enter the password for Administrator
access.
HYou can end the Administrator access level by entering:
admin disable
This command results in ending the Administrator access level session. No
password is needed.
Entering exit has the same results. Refer to
Exiting from the System on
page 2-5 for further details on ending a session.
The Operator and Administrator have the same Login ID with different passwords
for their access level. To determine the level of access for a session, refer to
Determining the Current Access Level on page 2-4.
Local Console Access
The DSL router ships with the local console enabled. After login, the local console
can be disabled with the command console disable. After saving this change
and ending the session, there is no local access through the console port. Any
access must be through a Telnet session or the NMS.
NOTE:
Entering console disable results in NO local access to the DSL router.
If you attempt to log in, you will receive an error message.
To determine via a Telnet session if a console is enabled, enter:
show console
The display returned for the show console command will be:
Hconsole enabled – Command line management at the console is
available, or
Hconsole disabled – No command line management is available at the
console.
For steps to set up the new user’s login, refer to
Setting Up the New User’s Login
on page 2-3.

Accessing the DSL Router
2-3
6371-A2-GB20-10 August 2000
Setting Up the New User’s Login
The DSL router will provide the login prompt when the local console connection is
first established. When the login prompt appears, a locally connected console
defaults to Console Enabled with Operator access only.
"Procedure
For first-time access to the Hotwire DSL Router’s command line interface:
1. At the initial login> prompt, type the default login ID paradyne and press
Enter.
2. At the password> prompt (for Operator), type the default password abc123
and press Enter.
The login ID and password fields are validated together.
3. At the system identity of CUSTOMER> prompt, type admin enable and press
Enter.
4. At the password> prompt (for Administrator), type the default password
abc123 and press Enter.
5. The system identity will change to the Administrator display mode of
CUSTOMER#>. Type configure terminal and press Enter.
6. The system identity will change to the Administrator configuration mode of
CUSTOMER - CONFIG#>.
7. To change the login ID, enter text to replace the default of paradyne:
name
your new login ID
NOTE:
The Login ID and Password fields are NOT case-sensitive.
8. Enter a new password and specify the level:
password
level password
Example: type password operator 238clrd3 and press Enter.
Both the Login ID and the Password fields are 1–31 printable alphanumeric
ASCII characters in the ASCII hex range of 0x21–0x7E. No spaces are
allowed. The following table lists the invalid characters.
Invalid Characters Value ASCII Hex Translation
#Number sign 0x23
$Dollar sign 0x24
%Percentage 0x25
&Ampersand 0x26

Accessing the DSL Router
2-4 6371-A2-GB20-10
August 2000
9. At the prompt, enter the new Administrator-level password to replace abc123:
password admin
new password and press Enter
save
and press Enter
NOTE:
Any input during an Administrator configuration session must be saved
while still in configuration mode.
For more information regarding the system identity, refer to
Determining the
Current Access Level,
below.
If you are denied access during a Telnet session, the session stops and an error
is logged. If you accessing the DSL router locally and a Telnet session is active,
you will receive a message:
Local console disabled by conflict
Telnet Access
The Telnet access defaults to Administrator level. If the login is at the Operator
level, then Operator level access is available. Telnet access is always enabled.
Determining the Current Access Level
The command line prompt displays the access level. The factory default for
System identity is CUSTOMER>. You can set your own system identity name to
replace CUSTOMER. See the example below.
If the prompt format
appears as . . . Then the DSL router
access level is . . .
And if you entered a System
identity of PARADYNE, the
prompt displays . . .
CUSTOMER> Operator, display mode PARADYNE>
CUSTOMER #> Administrator, display
mode PARADYNE #>
CUSTOMER – CONFIG#> Administrator,
configuration mode PARADYNE – CONFIG#>
Determining the Available Commands
To determine the commands available at the current login access level, enter:
Hhelp or
H? (question mark)
Hthe command without any parameters

Accessing the DSL Router
2-5
6371-A2-GB20-10 August 2000
Using the List Command
The list command displays a sequence of commands, in the form of ASCII
strings, that would have the effect of setting all configuration settings to the
current values. (The two passwords are not output.)
To determine the commands available, enter the Administrator configuration
mode and enter either:
Hlist
Displays the output in on-screen page mode. In on-screen page mode, the
user interface displays 23 lines of information. When the 24th line is reached,
More... is displayed. Pressing any key will display the next page.
Hlist config
Displays the output in scroll mode as a text file. Scroll mode captures and
displays all command strings in a text file for use with a terminal emulation
program. Refer to Appendix D,
DSL Router Terminal Emulation.
Changing the System Identity
"Procedure
To change the System Identity from the factory default of CUSTOMER>:
1. Login and enter the ADMIN-configuration mode.
2. At the CUSTOMER-CONFIG#> prompt, type the new System identity
(no spaces allowed), press Enter, type save, and press Enter.
system identity
new system identity
For example:
system identity PARADYNE and press Enter
save
and press Enter
3. In this example, after saving the entry and ending the configuration mode, the
System identity will display:
PARADYNE #>
The System identity is the same as the MIB entry of sysName. The
sysContact and SysLocation MIB entries are not displayed.
Exiting from the System
You can manually log out of the system, or let the system automatically log you
out. The DSL router will log you out immediately if you disconnect the Console
cable. Any unsaved configuration input will be lost.

Accessing the DSL Router
2-6 6371-A2-GB20-10
August 2000
Manually Logging Out
To log out, there are two commands: logout and exit.
"Procedure
To log out of the Hotwire DSL Router command line session or Telnet session:
1. At the >prompt, type logout and press Enter.
2. The system ends the session immediately. Any configuration updates must
be saved before exiting or the updates will be lost.
"Procedure
To exit the Hotwire DSL Router’s current access level:
1. At the >prompt, type exit and press Enter. If there are any unsaved
configuration changes, you will be prompted to save changes before exiting.
2. The exit command has the following effect:
If you are accessing the DSL router . . . Then . . .
At the Local console and logged in at the
Administrator level, configuration mode You are placed at the Operator level and any configuration updates must be
saved or the updates will be lost.
At the Local console and logged in at the
Administrator level, non-configuration
mode
You are placed at the Operator level.
At the Local console and logged in at the
Operator level The Exit command responds exactly like the Logout command.
Via a Telnet session and logged in at any
access level Entering either of the following ends the Telnet session immediately:
HExit
HCtrl + ] (right bracket)
Automatically Logging Out
The DSL router has an automatic timeout feature that logs you out of the system
after five minutes of inactivity. Any input that is not saved is lost. You will need to
log back in.
At the console, press Enter to display the login> prompt to log back in. The
autologout {enable | disable} command default is enabled. Unsaved
configuration input is lost.
When autologout is:
HEnabled, the current configuration is retained through a power recycle.
HDisabled, the system inactivity timer is disabled.
