Parallax PDT-PIN-7001-MP-I User manual

Operations Manual
PDT-PIN-7001-MP-I
Revision 1.0 –September 2022

Table of Contents
1. Revision History..............................................................................................................................................2
2. Abbreviations..................................................................................................................................................3
3. Safety Information..........................................................................................................................................4
3.1 General Safety Information ....................................................................................................................4
3.2 DC Power Supply ....................................................................................................................................4
4. Packing List .....................................................................................................................................................4
5. Product Overview...........................................................................................................................................5
6. Connectors and Indicators..............................................................................................................................6
6.1 LED Indicators.........................................................................................................................................6
6.2 RJ45 Ports ...............................................................................................................................................6
6.3 Power Supply Connector ........................................................................................................................6
7. Installation Procedures...................................................................................................................................7
7.1 DIN Rail Installation ................................................................................................................................7
7.2 Wall Mount Installation..........................................................................................................................7
8. Connection and Setup ....................................................................................................................................8
8.1 Inspection Checks...................................................................................................................................8
8.2 RJ45 Connections....................................................................................................................................8
8.3 Power Up ................................................................................................................................................8
9. Physical Dimensions .......................................................................................................................................8
10. Hardware Specification ..............................................................................................................................9

1.Revision History
Date
Rev
By
Comments
Checked
Date
13/09/2022
01
JF
Initial Release
SC
13/09/2022

2.Abbreviations
Abbreviation
Description
AP
Access Point
CCA
Copper-Clad Aluminium
DC
Direct Current
IEEE
Institute of Electrical and Electronic Engineers
IP
Internet Protocol
MTBF
Mean Time Between Failures
PD
Power Device
PSU
Power Supply Unit

3.Safety Information
3.1 General Safety Information
Only trained and authorised personnel should be permitted to work on this equipment. It is
assumed that those using this guide are competent to work on equipment of this nature and will
take appropriate precautions when working with the fault analysis guide.
All devices should be inspected upon receipt for signs of physical damage, which may in turn, affect
operational performance, or the overall safety of the unit. Any damaged items should be returned
to Parallax Digital Technologies Ltd for safety checks.
Parallax Digital Technologies accepts no responsibility for any injury or loss caused by unsafe or
inadequate working practices, or for work carried out by an unauthorised third party.
To prevent possible danger, damage, and bodily harm when handling the equipment, please
observe all warnings, cautions notices contained in this section. Failure to heed the following
danger, warnings, and cautionary statements could lead to serious injury or death.
3.2 DC Power Supply
The Unit should be mains-fed using a DC Power Supply using an appropriately rated cable
assembly, which is protected internally at the power supply device itself. If the device is to be fed
from an alternative power source, then the appropriate circuit protection device should be used
to ensure that the supply circuit is interrupted, in the event that a fault in the device causes too
much current to flow into it, causing an unsafe condition.
4.Packing List
The following items are included in the shipping carton:
•1 x PDT-PIN-7001-MP-I Industrial PoE Injector
•1 x DIN Rail Mounting Kit (Fitted)
•1 x Wall Mounting Kit
•Operation & Maintenance Manual (May be electronically supplied)
•Declaration of Conformity (May be electronically supplied)

5.Product Overview
The PDT-PIN-7001-MP-I is a hardened Gigabit Ethernet PoE Injector which facilitates connectivity
for IEEE 802.3 af/at devices, such as cameras, access points, and other PoE devices, up to a range
of 100m from the PoE Injector. The input and output ports both support 10/100/1000 BASE-T
and are compliant with IEEE 802.3ab.
This device incorporates a voltage booster circuit which allows for full support of IEEE 802.3 af
(PoE) and IEEE 802.3 at (PoE+) devices at +48VDC even with a +12VDC Power Supply, making it
suitable for battery and solar applications.
The device is designed for use in harsh industrial environments, and incorporating a rugged
aluminium housing, it can be operated across a wide temperature range (-40°C to +80°C) making
it suitable for most conditions.
A typical application setup can be seen in the following diagram:
Switch
IP Camera
+12~48VDC
Data
Data
Data
+12~48VDC
+12~48VDC
Data&Power
Data&Power
Data&Power
Access Point
Access Control

6.Connectors and Indicators
Front Panel
6.1 LED Indicators
The Front Panel LEDs display the status of the switch and the associated port connections as
indicated in the table below:
LED
Name
Colour
State
Status
PWR
Power
Green
OFF
Unit Power Off
ON
Unit Power On
PoE
PoE+ Output Power
Green
OFF
PoE Output On
ON
PoE Output Off
6.2 RJ45 Ports
The Front Panel has 2 RJ45 Ports; the Ethernet Port is used as the Data Input Port and is not PoE
compatible. The PoE+ Output Port should be used to connect directly to PoE devices.
6.3 Power Supply Connector
Model No
V-
V+
Power Input
PDT-PIN-7001-MP-I
GND
+12-48VDC
Note: All Power Supplies should provide over-current and short-circuit protection and should have
a capacity rating to meet the required output current for the device.

Press
Upper
part
Attach the Wall Mount Bracket (if not fitted)
to the switch case using the screws supplied
Mount the switch to the required surface
using appropriate fixings
7.Installation Procedures
7.1 DIN Rail Installation
7.2 Wall Mount Installation
Attach the DIN Rail Bracket (if not fitted) to
the switch case using the screws supplied
Clip the upper edge of the bracket onto the
DIN Rail and push to latch the bottom strip

8.Connection and Setup
8.1 Inspection Checks
Please inspect the unit to ensure that there is no damage to the external casing which could cause a
malfunction of the device or cause a safety critical fault. Any damaged units should be returned to Parallax
Digital Technologies for inspection and testing.
Please ensure that the DC Cables are securely fastened in the terminal block, and that the terminal block is
wired correctly, and correctly inserted into the switch power connector housing.
8.2 RJ45 Connections
Ensure all required RJ45 Ports are connected correctly using CAT5e cable or better to the client devices.
The source data feed should be connected to the Ethernet Port, and the target end device should be
connected to the PoE+ OUT Port.
8.3 Power Up
The Unit will automatically power up as soon as DC power is applied to the device. The Power Light will be
illuminated and as soon as valid power is available to the target device, the PoE LED will illuminate.
9. Physical Dimensions
All Dimensions are in mm

10. Hardware Specification
ETHERNET
Standards
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3x Full Duplex Flow Control
IEEE 802.3az Energy Efficient Ethernet
Forwarding and Filtering Rate
14,880pps (10Mbps)
148,800pps (100Mbps)
1,488,000pps (1000Mbps)
Packet Buffer
1Mbits
Packet Length
10KB
MAC Address Table
8K
Exchange Property
Backplane Bandwidth 20Gbps
Packet Forwarding Rate 14.88Mbps
INTERFACE
Data
1 x RJ45 Data Input
1 x RJ45 Power & Data Output (PoE+)
Power
DC In –2 Pin Terminal Block
POE
Standard
IEEE 802.3af/ IEEE 802.3at
Port
RJ45
Power Budget
Max 30W
ENVIRONMENTAL
Operating Temperature
-40°C to +80°C
Storage Temperature
-40°C to +85°C
Relative Humidity
5% - 95% non-condensing
MTBF
200,000 hours
ELECTRICAL
Operating Voltage
+12-48VDC (Terminal Block Connector)
Power Consumption
6w (Max 36W with full PoE+ Load)
Short-Circuit Protection
Auto-Reset
Reverse Polarity
Protected
MECHANICAL
Dimensions
95mm x 70mm x 29mm
Weight
250g
Casing
Aluminium
Mounting
DIN Rail & Wall Mount
INDICATORS
PWR
Power Status
PoE
PoE Power Output Status

CERTIFICATION
Electrical Safety
EN 62368-1:2020+A11:2020
Emissions
EN 55032:2015+A1:2020
Radiated Immunity
EN 55035:2017+A1:2020
Harmonic Emissions
EN 61000-3-2:2014
Fluctuations and Flicker
EN 61000-3-3:2013
Electro-Static Discharge
EN 61000-4-2:2009
Electromagnetic Field Immunity
EN 61000-4-3:2010
Electrical Fast-Transients
EN 61000-4-4:2012
Surge
EN 61000-4-5:2014+A1:2017
Conducted Immunity
EN 61000-4-6:2014
Power Frequency Magnetic Field
EN 61000-4-8:2010
RoHS
IEC 63000:2018
For all technical enquiries regarding this product, please contact our technical support team using the
following email address:
[e-mail]
