Parasound 7100 User manual

Power Zone Source
Exit Menu
Surround
Volume
Select
Mute Dim
Model 7100 Surround Controller
DVD DOLBY D 3/2.1
PLIIX MOVIE VOL: 50
Model 7100
7.1 Channel Surround Controller
OWNER’S GUIDE

IMPORTANT SAFETY INSTRUCTIONS
The lightning flash with the arrowhead symbol within an equilateral triangle is intended to alert
the user to the presence of “dangerous voltage” inside the product that may constitute a risk
of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence
of important operating and maintenance instructions in the literature accompanying the product.
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
1. Read Instructions — Read all the safety and operating instructions before operating this product.
2. Retain Instructions — Retain safety and operating instructions for future reference.
3. Heed Warnings — Adhere to all warnings on the product and in the operating instructions.
4. Follow Instructions — Follow all operating and use instructions.
5. Cleaning — Unplug this product from the wall outlet before cleaning. Use a damp cloth for cleaning.
Clean the outside of the product only.
6. Attachments — Do not use attachments that are not recommended by the product manufacturer;
they may be hazardous.
7. Water and Moisture — Do not use this product near water.
8. Accessories — Do not place this product on an unstable cart or stand. The product may fall, causing
bodily injury and damage to the product. A product and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the product and cart to overturn.
9. Ventilation — Slots and openings in the cabinet are provided for ventilation to ensure reliable opera-
tion of the product and to protect it from overheating. These openings must not be blocked or
covered. This product should not be placed in a built-in installation such as a bookcase or rack unless
proper ventilation is provided.
10. Power Sources — Operate this product only from the type of power source indicated on the label.
If you are not sure of the type of power supply to your home, consult your dealer or local power
company. This product is equipped with a three-prong grounding plug. This plug will only fit into a
grounding power outlet. If you are unable to insert the plug into the outlet, contact your electrician
to replace your obsolete outlet. Do not defeat the safety purpose of the grounding plug.
11. Power Cord Protection — Power supply cords should be routed so that they are not likely to be
walked on or pinched by items placed upon or against them.
12. Lightning — Unplug the unit from the wall outlet for added protection during a lightning storm
and when it is left unattended and unused for long periods of time. This will prevent damage to the
product due to lightning and power line surges.
13. Overloading — Do not overload wall outlets or extension cords. This can result in a fire or electric shock.
14. Inserting Objects into Unit — Never push objects of any kind into this product through any openings;
they may touch dangerous voltage points or short out parts that could result in fire or electric shock.
15. Servicing — Do not attempt to repair or service this product yourself. Opening or removing covers may
expose you to dangerous voltage and other hazards. Refer all servicing to qualified service personnel.
16. Damage Requiring Service — Unplug this product from the wall outlet and refer servicing to quali-
fied service personnel under the following conditions: a) If the power-supply cord or plug is damaged.
b) If liquid has been spilled into the product. c) If the product has been exposed to rain or water. d)
If the product does not operate normally by following the operating instructions. e) If the product has
been dropped or damaged in any way. f) If the product exhibits a distinct change in performance.
17. Replacement Parts — When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer. Unauthorized substitutions may result in fire, elec-
tric shock, and other hazards.
18. Safety Check — Upon completion of any service or repairs to this product, ask the service technician
to perform safety checks to determine that the product is in proper operating condition.
19. Wall or Ceiling Mounting — Mount the product to a wall or ceiling only as recommended.
20. Heat — The product should be situated away from heat sources such as radiators, heat registers,
stoves, and other products (including amplifiers) that produce heat.
www.parasound.com

Thank You for Choosing Parasound
Your Parasound® Model 7100 Surround Controller is an advanced home theater control center
with extraordinary performance capabilities.
We designed the Model 7100 to be very easy to set up and to operate. This manual is divided
into two sections, one to connect and operate the Model 7100 even if you’ve had little or no
previous experience with audio-video components, and another section with further hookups
and instructions that pertain to its advanced features to complete your home theater and
multi-room installation.
We appreciate you taking the time to read these instructions and thank you for selecting
Parasound. For updates and corrections to this manual, we invite you to check our web site,
www.parasound.com.
Enjoy.
The Parasound Staff
Keeping Records for Future Reference
Record the five digit serial number located on the bottom panel of your Model 7100 in the
space below. Also note your Parasound Dealer’s name and telephone number. We recommend
that you make a copy of your original purchase receipt/bill of sale and store the original and the
copy in a safe place. Your purchase receipt/bill of sale is required to determine if your Model
7100 is eligible for Parasound warranty service.
You Should Know
There is no Parasound warranty for this unit if it was not purchased from an Authorized
Parasound Dealer. Investigate warranty coverage statements made by an unauthorized dealer
very carefully, as you will need to depend entirely upon your dealer, and NOT upon Parasound.
Unauthorized dealers lack the capability to make repairs or arrange for repairs of Parasound
equipment.
Authorized Parasound Dealers are listed at www.parasound.com
or you can call 415-397-7100 between 8:30 am and 4:30 pm Pacific time.
A missing or altered serial number could indicate that this unit was sold by an unauthorized
dealer or is stolen merchandise. If this unit is missing its serial number, you should return it to
your dealer immediately for a full refund.
OWNERSHIP REFERENCE INFORMATION
Parasound Model 7100 Controller Serial #:
Parasound Dealer:
/ /
Dealer Phone Number: Date of Purchase:
( ) -
INTRODUCTION 3

TABLE OF CONTENTS
Unpacking and Placement Guidelines .................................... 6
Basic Connections ............................................. 8 – 13
Basic Operation .............................................. 14 – 15
Using the Menu for Setup......................................... 16 – 19
Basic Setup / Speaker Setup ....................................... 20 – 24
Additional Connections .............................................25
OPERATION
Basic Operation – Frequently Used Controls ............................. 26 – 29
Selecting Surround Patterns (Listening Modes) ........................... 30 – 32
Mode Table ................................................. 33 – 35
Remote Zone – Operation & Connection ...................................36
Using the Remote Control......................................... 37 – 39
Menu Review & Intermediate Setup .................................. 40 – 44
Speaker Setup: Size, Level, Distance
Source Setup: Source Title, Digital Input, Preset Profile Selection, Video Input
Audio Setup: Dolby/DTS, Bass Limiter, Presets and Lipsync, Treble and Bass, LFE Level, Reverb
4

TABLE OF CONTENTS 5
Advanced Setup .............................................. 45 – 51
Advanced Connections, Setup & Control................................ 52 – 53
Trigger Setup ................................................ 52 – 53
Connecting a Second Entertainment Zone ............................... 54 – 55
Control Connections (RS-232, IR Inputs, Trigger Outputs) ...................... 52 / 55
Troubleshooting Guide .......................................... 56 – 58
Service and Warranty Repairs .........................................68
TECHNICAL INFORMATION
Technically Speaking ........................................... 59 – 61
Dolby Pro Logic IIx Q&A ......................................... 62 – 64
THX Technology and Features ...................................... 65 – 67
Licensing Acknowledgements .........................................69
Model 7100 Specifications ........................................... 69
Connection and Setup Notes ....................................... 70 – 71

UNPACKING AND PLACEMENT GUIDELINES
Unpacking Your Model 7100
Carefully unpack your Model 7100 from its shipping carton and locate all the enclosed accessories:
• Remote control carton, contents: SRC1 remote control,
four AAA batteries, its own user’s manual and a DVD tutorial
• AC Power cord, two DC trigger connector wires, with small plugs at each. If both plugs are
2.5mm sub-mini type, 3.5-mm mini plug adapters are included. If wires have a 2.5mm plug
at one end and 3.5mm plug at the other no adapter is required.
While you are unpacking your Model 7100, inspect it thoroughly for possible shipping damage
and tell your Parasound dealer right away if you find any. If possible, save and store both the inner
and outer cartons and — most especially — the foam packing inserts, so you can use them to
protect the Model 7100 if you have to move it or ship it. You can flatten the cartons to save room
in storage by cutting the taped seams on the bottom flaps.
Placement Guidelines
The Model 7100 will be easy to use and will last longer if you follow these simple guidelines:
• Place the Model 7100 on a shelf that will adequately support its weight.
• Unless you’ll control the Model 7100 through a remote infrared sensor/repeater system,
pick a shelf placed where you can aim the remote controls at the Model 7100 easily. (If you
do use remote sensors, be sure the remote’s beams can’t reach both the IR repeater’s sen-
sor and unit’s front-panel sensors at the same time.)
If you’re installing the Model 7100 yourself, use cables that are long enough to leave at least
two feet of slack; that enables you to pull the Model 7100 out to change connections without
inadvertently disconnecting things. If you’re putting the Model 7100 in a cabinet, make sure
there’s grab space on each side; with a space that’s at least 22 inches wide, you’ll be able to
turn it around for access to its rear panel connections.
Rack Mounting Your Parasound Model 7100
With its four feet removed, the Model 7100’s front panel height occupies three rack spaces (51⁄4”
or 133 mm; a single standard rack space occupies 13⁄4” vertical space.) For mounting in a standard
19” equipment rack, you must use the Parasound RMK33 rack mount kit (purchased separately).
The RMK33 includes four bolts and eight plastic washers with raised “shoulders.”
Slide one washer onto each mounting bolt with its raised shoulder pointing toward the panel hole.
Carefully insert the bolt through the hole and slide the other washer on the bolt with its raised
shoulder facing the rear side of the panel. The washers will sandwich the Model 7100 panel
and the four mounting bolts to prevent metal-to-metal contact between the Model 7100
chassis, the equipment rack, and the other components mounted in the rack.
Note: Tighten each bolt just enough to keep the unit secure
in the rack to avoid deforming the shoulder washers.
Power Zone Source
Exit Menu
Surround
Volume
Select
Mute Dim
Model 7100 Surround Controller
RMK33 Rack Bracket
6

GETTING STARTED 7
To get the most out of your Model 7100, you’ll need to know how to connect it to your other
components, how to set it up for your room and to work with each component, and how to
operate it. There are several tiers, or degrees of complexity, for connections, the setup choices
you’ll need to make, and for operating the Model 7100.
Basic Connections
These are the video and audio interconnect cables that go between your Model 7100 and the
TV, most popular source components and the power amplifier in your main home theater room.
Additional Connections
These are the video and audio interconnect cables that go between your Model 7100 and the
balance of the sources in your main home theater room. This includes connecting video and
audio recorders. After these are connected you can connect the cables and other types of
wires that go between your Model 7100 and the equipment in a remote zone and for special
features such as operating the 7100 from a remote control repeater system or triggering other
equipment on and off.
The first section of this manual will focus on Basic Connections so you won’t be overwhelmed
by system hookup.
Basic Setup
Basic setup includes the selections you’ll make in your 7100’s Setup Menu to match your
7100 to the speakers you’re using, to your TV set and to your most frequently used source
components. It also sets up each channel to play at the correct volume level in your room,
and so the sound from each channel reaches your ears at the correct time.
Intermediate Setup
Intermediate setup includes the settings you will make in the Setup Menu to set up each
source with a title (name) you prefer and to associate each source with a specific digital audio
input and a specific video input.
More Advanced Setup
This includes the selections you’ll make in your 7100’s Setup Menu to match your 7100 to
your less frequently used source components. It also includes the selections you’ll make in
your 7100’s Setup Menu for Dolby, DTS and THX parameters. After these are finished you
can make the settings that will optimize compatibility with analog sources, set up one or more
preset profiles in which you can save and recall a group of settings for bass, treble, lipsync and
channel trim levels. At this point you may wish to consider setting up the remote control with
macros that perform multiple commands with the press of a single button.
Frequently Used Controls
Basic operation includes the most frequently used controls on the 7100 and on its remote
control. This will enable you to turn the system on and off, adjust volume, select sources.
Secondary Controls and Operation
This includes the less used controls on the 7100 and its remote control. This includes surround
mode selection, late night listening feature, bass and treble adjust, enhanced bass feature.
Finally, you will learn how to switch on other components automatically and how turn on/off,
volume and source select for the remote zone.

BASIC CONNECTIONS
8
Basic Connections and Basic Settings
This section of the manual focuses on helping you get your theater up and running in the
shortest possible time.
Let’s start with your DVD player, satellite receiver (or cable set-top box) and VCR, the first
three sources we think you’re likely to use most often. You can get to your other components
and remote zone after you master these.
Expansion Port
For Future Technologies
Made In Finland
Manufactured under license from
Dolby Laboratories. "Dolby",
"Pro Logic", and the double-D
symbol are trademarks of Dolby
Laboratories.
Manufactured under license from Digital Theater
Systems, Inc. US Pat. No. 5,451,942, 5,956,674,
5,974,380, 5,978,762 and other world-wide patents
issued and pending. "DTS", "DTS-ES Extended
Surround" and Neo:6" are trademarks of Digital
Theater Systems, Inc. Copyright 1996, 2000 Digital
Theater Systems, Inc. All rights Reserved.
To Prevent Fire Or Shock
Hazard, Do Not Expose This
Unit To Rain Or Moisture.
To Prevent Electric Shock,
Do Not Remove Top Cover.
No User-Serviceable Parts
Inside. Refer Servicing To
Qualified Service Personnel.
CAUTION:
WARNING:
Power Consumption: 65W
Source-Digital Audio
Use Menu to assign to Source-Audio Inputs
Output
DVD
DVD VCR
SAT
In 5 Zone
SAT
L
R
VCR In 4
Optical 1 Optical 2 Optical 3 Optical 4 Optical
In 5 In 6
Record Out Zone Out
Source-Audio Inputs
Source-S-Video Inputs
DVD
SAT
Fixed Variable
VCR
Use Menu to assign to Source-Audio Inputs
Source-Component Video Inputs
1 2 3
Serial PortMain On Master Off
12
Ctr Ctr
Composite Video Outputs
In 4 In 6 In 4
S-Video Outputs
Front 1 Program 2
12V Trigger Event
Pb
Y
Pr
Pb
Y
Pr
RS-232 Control
Surround Sub Back Front Surround Sub Back
7.1 Channel Analog Audio Inputs
AC Power
Coax 1
Coax 2
Coax 3
Coax 4 100V-240V
50Hz-60Hz
AC
Main
Main
Main
Main
Main
Main
Main
L
R
Main Audio Outputs
Output
IR inputs
Manufactured under license from THX Ltd.
THX and Ultra2 are trademarks of THX Ltd.
which may be registered in some jurisdictions.
All right reserved.
Source-Composite Video Inputs
1. Expansion Port for future technologies
2. Digital Audio Inputs & Outputs (Optical)
3. Composite Video Inputs & Outputs
4. S-Video Inputs & Outputs
5. Component Video Inputs & Outputs
11. RS-232 Control
12. IR Inputs
13. 12V Trigger Outputs
14. AC Power Switch
15. AC Cord Inlet
6. Digital Audio Inputs & Outputs (Coax)
7. Unbalanced Analog Audio Inputs
8. Zone & Record Audio Outputs
9. 7.1 Channel Analog Audio Inputs
10. Main Analog Audio Outputs
1
7
6
2
9
810 13
12
11 14 15
35
4
Don’t attach the 7100’s AC cord yet. You will do this after all the other connections are made.

TV Set or Video Monitor Connections
You’ll obtain the best quality picture if you connect the trio of Component Video input jacks on
your TV to the three Component Video Out jacks on your 7100. Component Video connections
require three cables, which are readily available. The jacks are identified with red, green, and blue
colors. The component video cable’s plugs will be color coded to help you connect the same color
jacks on the TV and on your 7100.
Note: We recommend connecting your TV first so you can view the 7100’s setup menu on your
TV right away. This will enable you to visualize the menu and make setup selections faster.
Expansion Port
For Future Technologies
Made In Finland
Manufactured under license from
Dolby Laboratories. “Dolby,”
“Pro Logic,” and the double-D
symbol are trademarks of Dolby
Laboratories.
Manufactured under license from Digital Theater
Systems, Inc. US Pat. No. 5,451,942, 5,956,674,
5,974,380, 5,978,762 and other world-wide patents
issued and pending. "DTS", "DTS-ES Extended
Surround" and Neo:6" are trademarks of Digital
Theater Systems, Inc. Copyright 1996, 2000 Digital
Theater Systems, Inc. All rights Reserved.
To Prevent Fire Or Shock
Hazard, Do Not Expose This
Unit To Rain Or Moisture.
To Prevent Electric Shock,
Do Not Remove Top Cover.
No User-Serviceable Parts
Inside. Refer Servicing To
Qualified Service Personnel.
CAUTION:
WARNING:
Power Consumption: 65W
Source-Digital Audio
Use Menu to assign to Source-Audio Inputs
Output
DVD
DVD VCR
SAT
In 5
SAT
L
R
VCR In 4
Optical 1 Optical 2 Optical 3 Optical 4 Optical
In 5 In 6
Record Out Zone Out
Source-Audio Inputs
Source-S-Video Inputs
DVD
SAT
Fixed Variable
VCR
Serial PortMain On Master Off
12
Ctr Ctr
In 4 In 6 In 4
Front 1 Program 2
12V Trigger Event
RS-232 Control
Surround Sub Back Front Surround Sub Back
7.1 Channel Analog Audio Inputs
AC Power
Coax 1
Coax 2
Coax 3
Coax 4 100V-240V
50Hz-60Hz
AC
L
R
Main Audio Outputs
IR inputs
Manufactured under license from THX Ltd.
THX and Ultra2 are trademarks of THX Ltd.
which may be registered in some jurisdictions.
All right reserved.
Source-Composite Video Inputs
Zone
Composite Video OutputsS-Video Outputs
Main
Main
Main
Main
Main
Main
Main
Use Menu to assign to Source-Audio Inputs
Source-Component Video Inputs
123
Pb
Y
Pr
Pb
Y
Pr
Output
Composite
Video Outputs
S-Video
Outputs
Component
Video Outputs
Small TV
for Viewing OSD
Main Viewing
Screen
AC Cord Inlet
123
4
Source Component Connections
Each source component has video output jacks plus a digital output jack and analog output
jacks for its audio. These jacks connect to corresponding input jacks on the 7100. In the 7100
Source setup menu you will “assign” the digital audio input jack and the video input jacks
which will be the actual inputs for viewing and listening when you select a source. We’ll get
into this in more detail further in the manual.
To get you started faster, we’ve already made some of these settings for you.
We’ve set up the 7100 for the analog audio, digital audio and video connections from your DVD
player, satellite receiver (or cable box) and VCR (or DVR), so you can start watching even before
you make any choices in the Setup menu.
Note: Of course, you’re welcome to connect other combinations of audio and video jacks, but
these will require changing a few of the factory settings in the Setup menu.
BASIC CONNECTIONS continued 9

BASIC CONNECTIONS continued
Video Connections
DVD Player
Connect the Component Video jacks on your player to the Component Video Input – 1 jacks
on your 7100. Use cables that are made for video because audio cables usually compromise
picture quality.
Expansion Port
For Future Technologies
Made In Finland
Manufactured under license from
Dolby Laboratories. “Dolby,”
“Pro Logic,” and the double-D
symbol are trademarks of Dolby
Laboratories.
Manufactured under license from Digital Theater
Systems, Inc. US Pat. No. 5,451,942, 5,956,674,
5,974,380, 5,978,762 and other world-wide patents
issued and pending. "DTS", "DTS-ES Extended
Surround" and Neo:6" are trademarks of Digital
Theater Systems, Inc. Copyright 1996, 2000 Digital
Theater Systems, Inc. All rights Reserved.
To Prevent Fire Or Shock
Hazard, Do Not Expose This
Unit To Rain Or Moisture.
To Prevent Electric Shock,
Do Not Remove Top Cover.
No User-Serviceable Parts
Inside. Refer Servicing To
Qualified Service Personnel.
CAUTION:
WARNING:
Power Consumption: 65W
Source-Digital Audio
Use Menu to assign to Source-Audio Inputs
Output
DVD
DVD VCR
SAT
In 5
SAT
L
R
VCR In 4
Optical 1 Optical 2 Optical 3 Optical 4 Optical
In 5 In 6
Record Out Zone Out
Source-Audio Inputs
Source-S-Video Inputs
DVD
SAT
Fixed Variable
VCR
Serial Port Main On Master Off
12
Ctr Ctr
In 4 In 6 In 4
Front 1 Program 2
12V Trigger Event
RS-232 Control
Surround Sub Back Front Surround Sub Back
7.1 Channel Analog Audio Inputs
AC Power
Coax 1
Coax 2
Coax 3
Coax 4 100V-240V
50Hz-60Hz
AC
L
R
Main Audio Outputs
IR inputs
Manufactured under license from THX Ltd.
THX and Ultra2 are trademarks of THX Ltd.
which may be registered in some jurisdictions.
All right reserved.
Source-Composite Video Inputs
Zone
Composite Video OutputsS-Video Outputs
Main
Main
Main
Main
Main
Main
Main
Use Menu to assign to Source-Audio Inputs
Source-Component Video Inputs
12 3
Pb
Y
Pr
Pb
Y
Pr
Output
DVD PLAYER
AUDIO OUTPUTS VIDEO OUTPUTS
L R
Composite
Green Blue
Component
Red
S-Video
Analog Audio Optical Coaxial
Satellite (or Cable) Receiver
Connect the Component Video jacks on your satellite receiver to the
Component Video Input – 2 jacks on your 7100.
Expansion Port
For Future Technologies
Made In Finland
Manufactured under license from
Dolby Laboratories. “Dolby,”
“Pro Logic,” and the double-D
symbol are trademarks of Dolby
Laboratories.
Manufactured under license from Digital Theater
Systems, Inc. US Pat. No. 5,451,942, 5,956,674,
5,974,380, 5,978,762 and other world-wide patents
issued and pending. "DTS", "DTS-ES Extended
Surround" and Neo:6" are trademarks of Digital
Theater Systems, Inc. Copyright 1996, 2000 Digital
Theater Systems, Inc. All rights Reserved.
To Prevent Fire Or Shock
Hazard, Do Not Expose This
Unit To Rain Or Moisture.
To Prevent Electric Shock,
Do Not Remove Top Cover.
No User-Serviceable Parts
Inside. Refer Servicing To
Qualified Service Personnel.
CAUTION:
WARNING:
Power Consumption: 65W
Source-Digital Audio
Use Menu to assign to Source-Audio Inputs
Output
DVD
DVD VCR
SAT
In 5
SAT
L
R
VCR In 4
Optical 1 Optical 2 Optical 3 Optical 4 Optical
In 5 In 6
Record Out Zone Out
Source-Audio Inputs
Source-S-Video Inputs
DVD
SAT
Fixed Variable
VCR
Serial Port Main On Master Off
12
Ctr Ctr
In 4 In 6 In 4
Front 1 Program 2
12V Trigger Event
RS-232 Control
Surround Sub Back Front Surround Sub Back
7.1 Channel Analog Audio Inputs
AC Power
Coax 1
Coax 2
Coax 3
Coax 4 100V-240V
50Hz-60Hz
AC
L
R
Main Audio Outputs
IR inputs
Manufactured under license from THX Ltd.
THX and Ultra2 are trademarks of THX Ltd.
which may be registered in some jurisdictions.
All right reserved.
Source-Composite Video Inputs
Zone
Composite Video OutputsS-Video Outputs
Main
Main
Main
Main
Main
Main
Main
Use Menu to assign to Source-Audio Inputs
Source-Component Video Inputs
1 2 3
Pb
Y
Pr
Pb
Y
Pr
Output
SATELLITE
RECEIVER
AUDIO OUTPUTS VIDEO OUTPUTS
L R
Composite S-Video
Analog Audio Optical Coaxial
Green Blue
Component
Red
Note: If your satellite (or cable box) receiver does not have component video output jacks, you can
use its S-Video jack. Go to the 7100 Setup menu, Source setup page, > Video in, and
select “S-Video SAT” or “Composite SAT” (see page 41).
10

BASIC CONNECTIONS continued
Audio Connections
Your DVD player and satellite receiver have two kinds of audio outputs, analog and digital.
DVD Player
Most DVD players have two digital outputs, an opti-
cal “Toslink” connector and an RCA jack that is often
labeled Coaxial or Coax.
Connect the DVD player’s Coaxial jack to the Digital
Audio Input – Coax 1 jack on the 7100. Use a cable
made for digital because a conventional audio cable
may not have the correct electrical characteristics for
digital. You can usually use a video cable if you don’t
have a digital cable on hand.
Satellite Receiver
Satellite receivers and cable boxes often have
an optical Toslink digital output connector, but no
coaxial output jack. Connect this output to the
Digital Audio Input – Optical 1 connector on
the 7100. This requires a fiber optic cable with
Toslink connectors on the ends.
VCR
Connect the S-Video output (play) jack on the VCR to the 7100 Source S-Video Inputs – VCR jack.
Connect the S-Video input (record) jack on the VCR to any of
the 7100 S-Video Outputs – Main jacks.
Connect the L and R audio output (play) jacks on the VCR to
the 7100 Source Audio Inputs – VCR jacks on the 7100.
Connect the L and R audio input (record) jacks on the VCR to the Record Out jacks on the 7100.
Expansion Port
For Future Technologies
Made In Finland
Manufactured under license from
Dolby Laboratories. “Dolby,”
“Pro Logic,” and the double-D
symbol are trademarks of Dolby
Laboratories.
Manufactured under license from Digital Theater
Systems, Inc. US Pat. No. 5,451,942, 5,956,674,
5,974,380, 5,978,762 and other world-wide patents
issued and pending. "DTS", "DTS-ES Extended
Surround" and Neo:6" are trademarks of Digital
Theater Systems, Inc. Copyright 1996, 2000 Digital
Theater Systems, Inc. All rights Reserved.
To Prevent Fire Or Shock
Hazard, Do Not Expose This
Unit To Rain Or Moisture.
To Prevent Electric Shock,
Do Not Remove Top Cover.
No User-Serviceable Parts
Inside. Refer Servicing To
Qualified Service Personnel.
CAUTION:
WARNING:
Power Consumption: 65W
Source-Digital Audio
Use Menu to assign to Source-Audio Inputs
Output
DVD
DVD VCR
SAT
In 5
SAT
L
R
VCR In 4
Optical 1 Optical 2 Optical 3 Optical 4 Optical
In 5 In 6
Record Out Zone Out
Source-Audio Inputs
Source-S-Video Inputs
DVD
SAT
Fixed Variable
VCR
Serial PortMain On Master Off
12
Ctr Ctr
In 4 In 6 In 4
Front 1 Program 2
12V Trigger Event
RS-232 Control
Surround Sub Back Front Surround Sub Back
7.1 Channel Analog Audio Inputs
AC Power
Coax 1
Coax 2
Coax 3
Coax 4 100V-240V
50Hz-60Hz
AC
L
R
Main Audio Outputs
IR inputs
Manufactured under license from THX Ltd.
THX and Ultra2 are trademarks of THX Ltd.
which may be registered in some jurisdictions.
All right reserved.
Source-Composite Video Inputs
Zone
Composite Video OutputsS-Video Outputs
Main
Main
Main
Main
Main
Main
Main
Use Menu to assign to Source-Audio Inputs
Source-Component Video Inputs
1 2 3
Pb
Y
Pr
Pb
Y
Pr
Output
Note: If your VCR does not have an S-Video jack, you will need to use its Composite
video jack. Go to the 7100 Setup menu, Source setup page, > Video in, and select
“Composite VCR” (see page 41).
11
Expansion Port
For Future Technologies
Made In Finland
Manufactured under license from
Dolby Laboratories. “Dolby,”
“Pro Logic,” and the double-D
symbol are trademarks of Dolby
Laboratories.
Manufactured under license from Digital Theater
Systems, Inc. US Pat. No. 5,451,942, 5,956,674,
5,974,380, 5,978,762 and other world-wide patents
issued and pending. "DTS", "DTS-ES Extended
Surround" and Neo:6" are trademarks of Digital
Theater Systems, Inc. Copyright 1996, 2000 Digital
Theater Systems, Inc. All rights Reserved.
To Prevent Fire Or Shock
Hazard, Do Not Expose This
Unit To Rain Or Moisture.
To Prevent Electric Shock,
Do Not Remove Top Cover.
No User-Serviceable Parts
Inside. Refer Servicing To
Qualified Service Personnel.
CAUTION:
WARNING:
Power Consumption: 65W
Source-Digital Audio
Use Menu to assign to Source-Audio Inputs
Output
DVD
DVD VCR
SAT
In 5
SAT
L
R
VCR In 4
Optical 1 Optical 2 Optical 3 Optical 4 Optical
In 5 In 6
Record Out Zone Out
Source-Audio Inputs
Source-S-Video Inputs
DVD
SAT
Fixed Variable
VCR
Serial PortMain On Master Off
12
Ctr Ctr
In 4 In 6 In 4
Front 1 Program 2
12V Trigger Event
RS-232 Control
Surround Sub Back Front Surround Sub Back
7.1 Channel Analog Audio Inputs
AC Power
Coax 1
Coax 2
Coax 3
Coax 4 100V-240V
50Hz-60Hz
AC
L
R
Main Audio Outputs
IR inputs
Manufactured under license from THX Ltd.
THX and Ultra2 are trademarks of THX Ltd.
which may be registered in some jurisdictions.
All right reserved.
Source-Composite Video Inputs
Zone
Composite Video OutputsS-Video Outputs
Main
Main
Main
Main
Main
Main
Main
Use Menu to assign to Source-Audio Inputs
Source-Component Video Inputs
12 3
Pb
Y
Pr
Pb
Y
Pr
Output
SATELLITE
RECEIVER
OUTPUTS
G BL R
Unbalanced Analog
Audio
Composite
Video
Component
Video Outputs
S-Video Coaxial
Digital Optical
Outputs
R
Expansion Port
For Future Technologies
Made In Finland
Manufactured under license from
Dolby Laboratories. “Dolby,”
“Pro Logic,” and the double-D
symbol are trademarks of Dolby
Laboratories.
Manufactured under license from Digital Theater
Systems, Inc. US Pat. No. 5,451,942, 5,956,674,
5,974,380, 5,978,762 and other world-wide patents
issued and pending. "DTS", "DTS-ES Extended
Surround" and Neo:6" are trademarks of Digital
Theater Systems, Inc. Copyright 1996, 2000 Digital
Theater Systems, Inc. All rights Reserved.
To Prevent Fire Or Shock
Hazard, Do Not Expose This
Unit To Rain Or Moisture.
To Prevent Electric Shock,
Do Not Remove Top Cover.
No User-Serviceable Parts
Inside. Refer Servicing To
Qualified Service Personnel.
CAUTION:
WARNING:
Power Consumption: 65W
Source-Digital Audio
Use Menu to assign to Source-Audio Inputs
Output
DVD
DVD VCR
SAT
In 5
SAT
L
R
VCR In 4
Optical 1 Optical 2 Optical 3 Optical 4 Optical
In 5 In 6
Record Out Zone Out
Source-Audio Inputs
Source-S-Video Inputs
DVD
SAT
Fixed Variable
VCR
Serial PortMain On Master Off
12
Ctr Ctr
In 4 In 6 In 4
Front 1 Program 2
12V Trigger Event
RS-232 Control
Surround Sub Back Front Surround Sub Back
7.1 Channel Analog Audio Inputs
AC Power
Coax 1
Coax 2
Coax 3
Coax 4 100V-240V
50Hz-60Hz
AC
L
R
Main Audio Outputs
IR inputs
Manufactured under license from THX Ltd.
THX and Ultra2 are trademarks of THX Ltd.
which may be registered in some jurisdictions.
All right reserved.
Source-Composite Video Inputs
Zone
Composite Video OutputsS-Video Outputs
Main
Main
Main
Main
Main
Main
Main
Use Menu to assign to Source-Audio Inputs
Source-Component Video Inputs
12 3
Pb
Y
Pr
Pb
Y
Pr
Output
DVD PLAYER
OUTPUTS
G BL R
Unbalanced Analog
Audio
Composite
Video
Component
Video Outputs
S-Video Coaxial
Digital Optical
Outputs
R

BASIC CONNECTIONS continued
Power Amplifier and Subwoofer
5.1 Channel Setup
If you have a 5.1 channel system, you probably have a five channel power amplifier and a
subwoofer with its own built-in amplifier. The power amplifier and subwoofer connect to your
7100 with six audio cables that have RCA plugs on the ends.
Left Front: Connect the 7100 Main Audio Outputs – L jack to the input jack on the
amplifier for the channel whose speaker terminals are connected to the
left front speaker.
Center: Connect the 7100 Main Audio Outputs – Ctr jack to the input jack on the
amplifier for the channel whose speaker terminals are connected to the
center speaker.
Right Front: Connect the 7100 Main Audio Outputs – R jack to the input jack on the
amplifier for the channel whose speaker terminals are connected to the
right front speaker.
Left Surround: Connect the 7100 Main Audio Outputs – Surround L jack to the input jack
on the amplifier for the channel whose speaker terminals are connected to
the left surround speaker.
Right Surround: Connect the 7100 Main Audio Outputs – Surround R jack to the input jack
on the amplifier for the channel whose speaker terminals are connected to
the right surround speaker.
Subwoofer: Connect the 7100 Main Audio Outputs – Sub jack to the input jack on your
subwoofer’s built-in amplifier.
Expansion Port
For Future Technologies
Made In Finland
Manufactured under license from
Dolby Laboratories. “Dolby,”
“Pro Logic,” and the double-D
symbol are trademarks of Dolby
Laboratories.
Manufactured under license from Digital Theater
Systems, Inc. US Pat. No. 5,451,942, 5,956,674,
5,974,380, 5,978,762 and other world-wide patents
issued and pending. "DTS", "DTS-ES Extended
Surround" and Neo:6" are trademarks of Digital
Theater Systems, Inc. Copyright 1996, 2000 Digital
Theater Systems, Inc. All rights Reserved.
To Prevent Fire Or Shock
Hazard, Do Not Expose This
Unit To Rain Or Moisture.
To Prevent Electric Shock,
Do Not Remove Top Cover.
No User-Serviceable Parts
Inside. Refer Servicing To
Qualified Service Personnel.
CAUTION:
WARNING:
Power Consumption: 65W
Source-Digital Audio
Use Menu to assign to Source-Audio Inputs
Output
DVD
DVD VCR
SAT
In 5
SAT
L
R
VCR In 4
Optical 1Optical 2 Optical 3 Optical 4 Optical
In 5 In 6
Record Out Zone Out
Source-Audio Inputs
Source-S-Video Inputs
DVD
SAT
Fixed Variable
VCR
Serial Port Main On Master Off
12
Ctr Ctr
In 4 In 6 In 4
Front 1 Program 2
12V Trigger Event
RS-232 Control
Surround Sub BackFront Surround Sub Back
7.1 Channel Analog Audio Inputs
AC Power
Coax 1
Coax 2
Coax 3
Coax 4 100V-240V
50Hz-60Hz
AC
L
R
Main Audio Outputs
IR inputs
Manufactured under license from THX Ltd.
THX and Ultra2 are trademarks of THX Ltd.
which may be registered in some jurisdictions.
All right reserved.
Source-Composite Video Inputs
Zone
Composite Video OutputsS-Video Outputs
Main
Main
Main
Main
Main
Main
Main
Use Menu to assign to Source-Audio Inputs
Source-Component Video Inputs
123
Pb
Y
Pr
Pb
Y
Pr
Output
12

BASIC CONNECTIONS continued
7.1 Channel Theater
If you have a 7.1 channel system, you probably have a five channel power amplifier, a two
channel amplifier and a subwoofer with its own built-in amplifier. If your five channel amplifier is
of higher quality and higher power than your two channel amplifier, connect it exactly as in the
5.1 channel instructions above. Use the two channel amplifier for the back channels.
Expansion Port
For Future Technologies
Made In Finland
Manufactured under license from
Dolby Laboratories. “Dolby,”
“Pro Logic,” and the double-D
symbol are trademarks of Dolby
Laboratories.
Manufactured under license from Digital Theater
Systems, Inc. US Pat. No. 5,451,942, 5,956,674,
5,974,380, 5,978,762 and other world-wide patents
issued and pending. "DTS", "DTS-ES Extended
Surround" and Neo:6" are trademarks of Digital
Theater Systems, Inc. Copyright 1996, 2000 Digital
Theater Systems, Inc. All rights Reserved.
To Prevent Fire Or Shock
Hazard, Do Not Expose This
Unit To Rain Or Moisture.
To Prevent Electric Shock,
Do Not Remove Top Cover.
No User-Serviceable Parts
Inside. Refer Servicing To
Qualified Service Personnel.
CAUTION:
WARNING:
Power Consumption: 65W
Source-Digital Audio
Use Menu to assign to Source-Audio Inputs
Output
DVD
DVD VCR
SAT
In 5
SAT
L
R
VCR In 4
Optical 1Optical 2 Optical 3 Optical 4 Optical
In 5 In 6
Record Out Zone Out
Source-Audio Inputs
Source-S-Video Inputs
DVD
SAT
Fixed Variable
VCR
Serial Port Main On Master Off
12
Ctr Ctr
In 4 In 6 In 4
Front 1 Program 2
12V Trigger Event
RS-232 Control
Surround Sub BackFront Surround Sub Back
7.1 Channel Analog Audio Inputs
AC Power
Coax 1
Coax 2
Coax 3
Coax 4 100V-240V
50Hz-60Hz
AC
L
R
Main Audio Outputs
IR inputs
Manufactured under license from THX Ltd.
THX and Ultra2 are trademarks of THX Ltd.
which may be registered in some jurisdictions.
All right reserved.
Source-Composite Video Inputs
Zone
Composite Video OutputsS-Video Outputs
Main
Main
Main
Main
Main
Main
Main
Use Menu to assign to Source-Audio Inputs
Source-Component Video Inputs
1 2 3
Pb
Y
Pr
Pb
Y
Pr
Output
Left Back: Connect the 7100 Main Audio Outputs Back L jack to the left channel input jack on
the amplifier and connect its left channel speaker terminals to the left back speaker.
Right Back: Connect the 7100 Main Audio Outputs Back R jack to the right channel input
jack on the amplifier and connect its left channel speaker terminals to the right
back speaker.
Note: We recommend using your two channel power amplifier for the Left and Right front
speakers if it is of higher quality and equal or higher power than your five channel
amplifier. Connect the five channel amplifier to your Center, Left Surround, Right
Surround, Left Back and Right Back speakers.
If you have a single seven channel amplifier, you can connect the first five channels like the five
channel amplifier example and connect the back channels to the amp’s channels six and seven.
Check all of your connections to make sure the plugs are inserted firmly in the jacks and there
isn’t any tension on the cables that might cause them to pull loose later on.
AC Cord
The AC cord plugs into the AC inlet on the 7100 and to your wall outlet or power strip.
Before plugging this in make sure the adjacent master AC Power switch on your 7100 is
switched to its Off position. Now plug in the AC cord.
13

BASIC OPERATION
Operating the 7100
After you’ve connected your TV, a few source components, power amplifiers, speakers and
subwoofer, your system is ready for its shake-down cruise. Select the TV’s input to be the
same as its Video Input jacks connected to the 7100 Video Out jack.
Press the rear panel master AC Power switch to its On position.
When you look at the front panel of the 7100 you should notice a
faint glow around its Power button. The red glow indicates that the
7100 is in a Standby mode, ready to turn on after you press its Power
button or press the remote handset’s ON button.
(Almost) Instant Gratification
The 7100 comes with certain setup choices already made for you so you can see and hear a DVD,
satellite broadcast or videotape right away. It is much quicker to use the remote control for most
operations, including navigating the menu to make other settings or to change the factory settings.
Remote Control Handset - preview
Open the battery compartment cover
and install the batteries, making sure
their directions match the
markings on the remote.
14
LIGHT
Button
SHIFT
Button
FUNCTION
Buttons
DISPLAY
DEVICE
Buttons
+
+
+
+
-
-
-
-
To Prevent Fire Or Shock
Hazard, Do Not Expose This
Unit To Rain Or Moisture.
To Prevent Electric Shock,
Do Not Remove Top Cover.
No User-Serviceable Parts
Inside. Refer Servicing To
Qualified Service Personnel.
WARNING:
Power Consumption: 65W
Main On Master Off
AC Power
100V-240V
50Hz-60Hz
AC
Pb
Y
Pr

BASIC OPERATION continued
PARASOUND 7100
SURROUND SOUND
If your DVD is already playing you should see a picture and hear sound. We suggest using a
disc you know has 5.1 channel sound.
When you see the DVD’s program on your TV and hear the sound from your speakers it will
confirm you’ve made the correct connections and you can proceed to the basic setup selections.
Note: If you have a 7.1 channel system, you might not hear anything from the back speakers
at this point.
Adjusting Volume Adjusting Volume
Press the VOL + and – buttons – or – Turn the Volume knob
to adjust volume levels. to adjust volume levels.
The speakers won’t be playing at the correct levels relative to each other yet, because you still
need to make some adjustments for your room. The 7100 has a very simple menu to help you
make setup choices. It is easiest to view the menu on your TV because it can display more of
the menu. You can also see the menu on the front panel display, but the view is limited to the
setup item you are adjusting or selecting. We will refer to the TV onscreen display as OSD.
DVD DOLBY D 3/2.1
PLIIX MOVIE VOL: 50
15
Using the Remote Control
You’ll generally find it more convenient to use
the remote to set up and operate your 7100.
Press the remote’s MAIN Device button
to control the 7100; the remote controls the
7100 whenever MAIN is displayed at the top.
When you press the remote’s ON button, the
7100’s standby red glow will switch off and
the front panel status display will illuminate.
Selecting the DVD Player
Press button 1, labeled DVD. The panel
display will show DVD.
Using the Front Panel Controls
You can control some basic 7100 functions
with the front panel buttons and Volume/
Select knob. A number of functions are avail-
able only with the remote control handset.
When you press the remote’s ON button, the
7100’s standby red glow will switch off and
the front panel status display will illuminate.
Selecting the DVD Player
Press the Source button and turn the
Volume/Select knob until DVD is displayed.
VOLUME
Button
Power Zone Source
Exit Menu
Surround
Volume
Select
Mute Dim
Model 7100 Surround Controller
DVD DOLBY D 3/2.1
PLIIX MOVIE VOL: 50
VOLUME
Control Knob

USING THE MENU FOR SETUP
Navigating The Setup Menus ...................................... 17 – 20
Speaker Setup ............................................... 20 – 24
Size setup................................................ 20 – 23
Level setup ............................................... 23 – 24
Distance setup ................................................ 24
Display (OSD) Setup ...............................................40
Source Setup ................................................ 41 – 45
Input Titling .............................................. 42 – 44
Preset Association ............................................. 44
Input Monitor.................................................45
Video In ....................................................45
Audio Setup .................................................... 46
Dolby/DTS parameters ........................................ 47– 48
Preset Setup .............................................. 48 – 49
Treble, Bass, Center, Surround, Sub levels ...............................49
Reverberation ................................................47
Lip sync delay ................................................49
THX Audio Setup .............................................. 49 – 51
THX Sub Select ...............................................50
Subwoofer Boundary Gain Compensation ............................... 50
ASA (Advanced Speaker Array)...................................... 50
Bass Limiter Setup ............................................. 51
Trigger Setup ................................................ 52 – 53
16

USING THE MENU FOR SETUP continued
Setup Menu Using the Remote
Press the MENU button
on the remote handset.
The main menu will appear.
Note: The OSD may not appear stable immediately after you press the Menu button. This is
because some TVs require a few seconds to synchronize with the 7100’s OSD signal.
Setup Menu Structure
Main Menu is displayed when you press the Menu button on the 7100 (or the MENU button
on the remote) one time.
Note: If you press either the unit’s Menu button (or the remote’s MENU button) while the
menu is displayed, it will cancel the menu and save your setup settings.
Under Main Menu are the six setup category sub-menu pages that are one level lower.
• Speaker setup
• Source setup
• Audio setup
• THX audio setup
• Display setup
• Trigger setup
Each of these pages branches out into even lower levels, with one or two of its own
sub-sub-menu pages. Many consider this arrangement to be sub-lime.
17
MAIN MENU
SPEAKER SETUP
Main Menu
Speaker setup
Source setup
Audio setup
THX Audio setup
Display setup
Trigger setup
Exit
Press the MENU button on the
remote handset (above).
On your TV it looks like this (left);
this is the onscreen display (OSD)
On the front panel of the 7100
it looks like this (below):
MENU
Button

USING THE MENU FOR SETUP continued
18
In other words, you navigate the menu pages before you make the actual selections which are
on the lowest level pages.
MAIN MENU
SPEAKER SETUP
Main Menu
> Speaker setup
Source setup
Audio setup
THX Audio setup
Display setup
Trigger setup
Exit
For example, when you select
Speaker setup,
SPEAKER SETUP
SIZE SETUP
Speaker setup
> Size setup
Level setup
Distance setup
7.1 channel in L&R Large
Exit
You’ll see another page with a list of
speaker setup topics, starting with
Size setup:
SIZE SETUP
MAIN SPEAKERS: SMALL
Size setup
> Main speakers Small
Center speaker Yes
Surround speakers Small
Back speakers 2 Small
Subwoofer Yes
Subwoofer lter On
Subwoofer freq. 80Hz-THX
Enhanced bass Off
Exit
If you select Size setup, you’ll see
a page with the list of speaker size
items you select or adjust.

USING THE MENU FOR SETUP continued
Navigating the Menu with the Remote Handset
You can find menu pages and make selections with the remote
handset’s central left/right and up/down cursor buttons and
its Enter button. We call this group of buttons a thumbpad,
since you only need to move your thumb a short distance in
each direction to press any of these buttons.
You’ll soon know which button you’re pressing without hav-
ing to look at the remote; when you can keep your attention
on the Setup menu, the process will go much faster.
Note: The ENTER button is not the same as the
ENT button at the lower right of the handset.
When a menu page is displayed there will be a series
of headings below the name of that page. Press the up
and down buttons to position the menu cursor ( > )
alongside the one you wish to select. You press the
Enter button to select it, then the sub-menu page will
appear for that heading.
You’ll press the up or down button again to move
the cursor ( > ) next to the item you wish to select.
Actual adjustments or selections are made with the
right/left/up/down thumbpad buttons. After you
have made a selection, the cursor ( > ) will advance
down to the next listing. If you wish to review a
previous selection, press the up button to move the
cursor ( > ) up.
After all the selections for that page are made, press
the down button once more so the cursor ( > ) is
next to Exit. When you press the Enter button to
select Exit, the next higher level menu will reappear.
Note: You don’t have to make all the settings on
the page in order to exit it.
Note: You can also get to Exit by pressing the up button; press the up button when the cursor
( > ) is already on the top line and it will move to Exit. This will save you time if you want
to exit when the cursor ( > ) is above the middle of a page.
19
ENTER
Button
LEFT
UP
DOWN
RIGHT
Speaker setup
> Size setup
Level setup
Distance setup
7.1 channel in L&R Large
Exit
Size setup
> Main speakers Small
Center speakers Small
Surround speakers Small
Back speakers 2 Small
Subwoofer Yes
Subwoofer lter On
Subwoofer freq. 80Hz-THX
Enhanced Off
Exit
Speaker setup
Size setup
> Level setup
Distance setup
7.1 channel in L&R Large
Exit

BASIC SETUP / SPEAKER SETUP
Navigating the Menu with the Front Panel Controls
The Menu button brings up the menu. It also functions like the down button on the remote
control and you can move the cursor only in the down direction. When you press Menu the
Volume/Select knob changes from its volume adjust to menu select. Turn the knob to make
selections; turning it to the right is equivalent to pressing the remote’s right thumbpad. Turning
it to the left is equivalent to pressing the left thumbpad. When the menu cursor reaches Exit,
turning the knob either way is equivalent to pressing the Enter button on the remote.
Saving Your Setup Selections
You may exit the menu and save your settings any of these four ways:
• By pressing the remote’s ENTER button when the cursor is by Exit.
• By turning the Volume/Select knob when the cursor is by Exit.
• By pressing the remote’s MENU button.
• By pressing the Exit button.
Note: If you press the ESC (Escape) button on the remote to escape from the menu, none of your
newest menu settings will be saved and you’ll have to re-enter all of your menu selections.
Now that you know the Setup menu structure and how to make selections,
it’s time to start Basic Setup.
Size Setup
“Small” speakers are those with limited bass capacity. To avoid distortion, the 7100 filters out
low bass frequencies from any channels with “Small” speakers and sends the bass to the
subwoofer channel output. This affects frequencies below the Subwoofer freq. you will select
further down on the “Size setup” menu page.
Note: The factory default setting = Small.
Main speakers, the left and right front speakers, may be set as “Large” or “Small.”
Center speaker may be set to “Large,” “Small,” or “No.” If your system has no center
speaker, set this to “No” so the 7100 will divert any center-channel signals into your front
left and right speakers. This is sometimes referred to as a “Phantom” center because, even
without an actual center channel speaker, you will still hear sound apparently coming from
between your front speakers.
Note: The factory default setting = Small.
20
SIZE SETUP
MAIN SPEAKERS: SMALL
Size setup
> Main speakers Small
Center speaker Yes
Surround speakers Small
Back speakers 2 Small
Subwoofer Yes
Subwoofer lter On
Subwoofer freq. 80Hz-THX
Enhanced bass Off
Exit
This is the first thing you should set
up; it’s used to adapt the 7100 to the
number, locations, and types of speak-
ers in your system. The 7100 comes
with all speakers set to small because
this applies to a majority of systems.
