Parker isysNet E104P A Series Installation and maintenance instructions

Introduction
Follow these instructions when installing, operating, or servicing the
product.
isysNet EtherNet/IP Adapter, Series A
(PSSCENA)
The sealed IP67 housing of the adapter requires no enclosure.
(Note that environmental requirements other than IP67 may require
an additional appropriate housing.) The EtherNet/IP connector is
a sealed D-coded M12 (micro) style. The EtherNet/IP adapter is
shown below.
Installation & Service Instructions
E104P
isysNet EtherNet/IP Adapter,
Series A (PSSCENA)
ISSUED: December, 2006
Supersedes: December, 2005
Doc.# E104P, EN# 060961, Rev. 3
Pneumatic Division
Richland, Michigan 49083
EtherNet I/P
PSSCENA
Adapter
Status
Network
Activity
Network
Status
PointBus
Status
System
Power
Adapter
Power
X10
X100
PWR
X1
P
A
D
D
R
E
S
S
I
PSSCENA
M12
Connector
Mini 7/8"
Auxiliary
Power
Connector
Network
Address
Switches
isysNet EtherNet/IP Adapter User Manual
The isysNet EtherNet/IP Adapter User Manual PSS-UM004A-EN-P is
not available at this time. Please refer to Rockwell Automation 1734
POINT I/O EtherNet/IP Adapter User Manual 1734-UM011A-EN-P
for similar setup information, which is available online at
http://literature.rockwellautomation.com/.
WARNING
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE
PRODUCTS AND/OR SYSTEMS DESCRIBED HEREIN OR RELATED
ITEMS CAN CAUSE DEATH, PERSONAL INJURY AND PROPERTY
DAMAGE.
This document and other information from Parker Hannifin Corporation,
its subsidiaries and authorized distributors provide product and/or system
options for further investigation by users having technical expertise. It
is important that you analyze all aspects of your application, including
consequences of any failure and review the information concerning the
product or systems in the current product catalog. Due to the variety of
operating conditions and applications for these products or systems, the
user, through its own analysis and testing, is solely responsible for making
the final selection of the products and systems and assuring that all
performance, safety and warning requirements of the application are met.
The products described herein, including without limitation, product
features, specifications, designs, availability and pricing, are subject to
change by Parker Hannifin Corporation and its subsidiaries at any time
without notice.
EXTRA COPIES OFTHESE INSTRUCTIONS ARE AVAILABLE FOR INCLUSION
IN EQUIPMENT / MAINTENANCE MANUALSTHAT UTILIZETHESE PRODUCTS.
CONTACT YOUR LOCAL REPRESENTATIVE.
!
Safety Guide
For more complete information on recommended application guidelines, see
the Safety Guide section of Pneumatic Division catalogs or you can download
the Pneumatic Division Safety Guide at: www.parker.com/safety
WARNING
To avoid unpredictable system behavior that can cause personal injury
and property damage:
• Disconnect electrical supply (when necessary) before installation,
servicing, or conversion.
• Disconnect air supply and depressurize all air lines connected to
this product before installation, servicing, or conversion.
• Operate within the manufacturer’s specified pressure, temperature,
and other conditions listed in these instructions.
• Medium must be moisture-free if ambient temperature is below
freezing.
• Service according to procedures listed in these instructions.
• Installation, service, and conversion of these products must be
performed by knowledgeable personnel who understand how
pneumatic products are to be applied.
• After installation, servicing, or conversion, air and electrical
supplies (when necessary) should be connected and the product
tested for proper function and leakage. If audible leakage is present,
or the product does not operate properly, do not put into use.
• Warnings and specifications on the product should not be
covered by paint, etc. If masking is not possible, contact your local
representative for replacement labels.
!

isysNet EtherNet/IP Adapter, Series A (PSSCENA) E104P
2
Important User Information
Solid state equipment has operational characteristics differing from
those of electromechanical equipment. Safety Guidelines for the
Application, Installation and Maintenance of Solid State Controls
(available online at www.parker.com/pneu/isysNet) describes some
important differences between solid state equipment and hard-wired
electromechanical devices. Because of this difference, and also
because of the wide variety of uses for solid state equipment, all persons
responsible for applying this equipment must satisfy themselves that
each intended application of this equipment is acceptable.
In no event will Parker Hannifin Corporation be responsible or liable
for indirect or consequential damages resulting from the use or
application of this equipment.
The examples and diagrams in this manual are included solely
for illustrative purposes. Because of the many variables and
requirements associated with any particular installation, Parker
Hannifin Corporation cannot assume responsibility or liability for
actual use based on the examples and diagrams.
No patent liability is assumed by Parker Hannifin Corporation with
respect to use of information, circuits, equipment, or software
described in this manual.
Reproduction of the contents of this manual, in whole or in part, without
written permission of Parker Hannifin Corporation is prohibited.
Throughout this manual we use notes to make you aware of safety
considerations.
WARNING Identifies information about practices or
circumstances that can cause an explosion in
a hazardous environment, which may lead to
personal injury or death, property damage, or
economic loss.
IMPORTANT Identifies information that is critical for successful
application and understanding of the product.
ATTENTION Identifies information about practices or
circumstances that can lead to personal injury
or death, property damage, or economic loss.
Attentions help you:
• Identify a Hazard
• Avoid a Hazard
• Recognize the Consequence
SHOCK HAZARD Labels may be located on or inside the
equipment to alert people that dangerous
voltage may be present.
BURN HAZARD Labels may be located on or inside the
equipment to alert people that surfaces may
be dangerous temperatures.
!
!
Environment and Enclosure
This equipment is intended for use in overvoltage Category
II applications (as defined in IEC publication 60664-1), at
altitudes up to 2000 meters without derating. This equipment
is considered Group 1, Class A industrial equipment according
to IEC/CISPR Publication 11. Without appropriate precautions,
there may be potential difficulties ensuring electromagnetic
compatibility in other environments due to conducted as well as
radiated disturbance. This equipment is supplied as “enclosed”
equipment. It should not require additional system enclosure
when used in locations consistent with the enclosure type
ratings stated in the Specifications section of this publication.
Subsequent sections of this publication may contain additional
information regarding specific enclosure type ratings, beyond
what this product provides, that are required to comply with
certain product safety certifications.
NOTE: See NEMA Standards publication 250 and IEC
publication 60529, as applicable, for explanations of the degrees
of protection provided by different types of enclosure. Also,
see the appropriate sections in this publication, as well as the
publication E115P (“Industrial Automation Wiring and Grounding
Guidelines”), for additional installation requirements pertaining
to this equipment.
!
ATTENTION
Preventing Electrostatic Discharge
This equipment is sensitive to electrostatic discharge, which
can cause internal damage and affect normal operation. Follow
these guidelines when you handle this equipment:
• Touch a grounded object to discharge potential static.
• Wear an approved grounding wriststrap.
• Do not touch connectors or pins on component boards.
• Do not touch circuit components inside the equipment.
• If available, use a static-safe workstation.
• When not in use, store the equipment in appropriate static-
safe packaging.
!
ATTENTION

isysNet EtherNet/IP Adapter, Series A (PSSCENA) E104P
3
Mount the Adapter and I/O Base
To mount the adapter on a wall or panel, use the screw holes
provided in the adapter.
A mounting illustration for the adapter with I/O bases is shown
below.
Inches
(mm)
Adapter
2.0
(50)
2.0
(50)
1.9
(47.2)
4.02
(102)
1.81
(46)
4.32
(109.8)
5.39
(137.0)
Drill and Tap
for M4 Screw
I/O Module
Ground
2.39
(60.7)
3.02
(76.6)
3.13
(79.4)
5.98*
(151.9)
0.87
(22)
Drill and Tap
for M6 Screw
I/O Module
Ground
Install the Mounting Base as Follows:
1. Lay out the required points as shown above in the drilling
dimension drawing.
2. Drill the necessary holes for #8 (M4) machine or self-tapping
screws.
3. Mount the adapter using #8 (M4) screws.
4. Ground the system using the ground lug connection in the I/O
base. (The ground lug connection is also a mounting hole.)
Before You Begin
To effectively use your adapter, note the following considerations.
Determine Compatibility
If using the adapter with an Allen-Bradley 1756-ENBT module or
1788-ENBT module, use the following required firmware versions
for these bridge modules:
• 1756-ENBT firmware version 2.3 or greater
• 1788-ENBT firmware version 1.33 or greater
If you use the BootP Utility to assign IP addresses to the adapter,
use version 2.3.2 or greater.
Understanding Messaging
Class 3 (Explicit Message) requests through the adapter to a specific
I/O module may not always receive a response from the I/O module.
In the case where the I/O module does not reply to the request, the
adapter responds with an error code indicating a time-out.
Establish I/O Connections
When you power up an isysNet I/O system and establish I/O
connections, the outputs transition to the Idle state, applying Idle
state data before going to RUN mode. This occurs even when the
controller making the connection is already in RUN mode.
Configure Autobaud
The adapter cannot reconfigure an I/O module that you previously
configured to operate at a fixed baud rate. When you reuse an
isysNet I/O module from another isysNet I/O system, configure the
module to autobaud before using it with the adapter.
Open Configuration Method
For using isysNet EtherNet/IP Adapters without RSNetWorx™ or
RSLogix™ 5000, refer to document “User Guide: Configuration of
the isysNet™ Pneumatics Platform using Explicit Messaging", which
is available at www.parker.com/pneu/isysnet.
* Depending on the type and number of manifolds, this dimension
may vary. Refer to Catalog 0600P-# for additional information.
Grounding
Each isysNet base has two mounting holes, with the one on the
right being the means to ground each module. Each module must
be grounded.

Set the Network Address
To set the network address, you can:
• Adjust the switches on the front of the module
• Use a Dynamic Host Configuration Protocol (DHCP) server
• Retrieve the IP address from nonvolatile memory
The adapter reads the switches first to determine if the switches are
set to a valid number. You set the node address by adjusting the 3
switches on the front of the module (refer to the illustration on page
1). Use a small blade screwdriver to rotate the switches. Line up the
small notch on the switch with the number setting you wish to use.
Valid settings range from 001 through 254.
When the switches are set to a valid number, the adapter’s IP address
will be 192.168.1.xxx (where xxx represents the number set on the
switches). The adapter’s subnet mask will be 255.255.255.0 and the
gateway address will be set to 0.0.0.0. When the adapter is reading
the network address set on the switches, the adapter will not have a
host name assigned to it or use any Domain Name System.
If the switches are set to an invalid number (i.e., 000 or a value
greater than 254), the adapter checks to see if DHCP is enabled.
If DHCP is enabled, the adapter asks for an address from a DHCP
server. The DHCP server will also assign other Transport Control
Protocol (TCP) parameters.
If DHCP is not enabled, the adapter will use the IP address (along with
other TCP configurable parameters) stored in nonvolatile memory.
EDS File Requirements
The EDS file is available online at www.parker.com/pneu/isysNet.
isysNet EtherNet/IP Adapter, Series A (PSSCENA) E104P
4
This example shows
the network address
set at 163.
Add EtherNet/IP Adapter to RSLogix 5000
I/O Configuration
To add your PSSCENA to RSLogix 5000 I/O configuration, follow
these steps:
• In RSLogix 5000, highlight the EtherNet/IP Scanner, right click
and select New Module.
If your RSLogic 5000 is Version 15.X or greater:
• Choose the PSSCENA module from the list of Parker modules.
• Enter a name, an appropriate I/P address and chassis size.
• Choose Next to set RPI.
• Choose Finish. Notice that the PSSCENA is now under the I/O
configuration.
If your RSLogic 5000 is Version 13.X:
• Choose the 1738-AENT/A from the list of modules.
• Enter a name, an appropriate IP address, and chassis size. Make
sure to choose Compatible Module for Electronic Keying
setting.

• Choose Next to set RPI.
• Choose Finish. Notice that the 1738-AENT is now under the
I/O configuration
isysNet EtherNet/IP Adapter, Series A (PSSCENA) E104P
5
Wire the EtherNet/IP Adapter
Following are wiring instructions for the EtherNet/IP Adapter.
Make sure all connectors and caps are securely tightened to
properly seal the connections against leaks and maintain IP67
requirements.
!
ATTENTION
Female In Connector
PSSCENA Network Connector (D-Coded M12)
(view into connector)
Pin 1 - Tx +
Pin 2 - Rx +
Pin 3 - Tx -
Pin 4 - Rx -
Male In Connector
PSSCENA Auxiliary Power (Mini 7/8")
(view into connector)
Pin 1 - User Power +
Pin 2 - Adapter Power +
Pin 3 - Adapter Power -
Pin 4 - User Power -
NOTE: User power is the 24VDC power for field devices.
Adapter power is the 24VDC power for adapter. It is converted to
5VDC to power isysNet modules.

isysNet EtherNet/IP Adapter, Series A (PSSCENA) E104P
6
Troubleshoot with the Indicators
EtherNet I/P
PSSCENA
Adapter
Status
Network
Activity
Network
Status
PointBus
Status
System
Power
Adapter
Power
X10
X100
PWR
X1
P
A
D
D
R
E
S
S
I
PSSCENA
Adapter Status
Indicator
Network Activity
Indicator
Network Status
Indicator
PointBus Status
Indicator
System Power
Indicator
Adapter Power
Indicator
Indication Probable Cause
Adapter Status
Off No power applied to device
Flashing
Red/Green LED power up test (module self-test)
Green Device is operating normally
Flashing Red Recoverable fault has occurred:
- Firmware (NVS) update
- Network IP address changed
- CPU load exceeded
Solid Red Unrecoverable fault has occurred:
- Self-test failure (checksum failure
at power up, ramtest) failure at
power up
- Firmware fatal error
Indication Probable Cause
Network Activity
Off No link established
Flashing Green/Off Transmit or receive activity
Green Link established
Indication Probable Cause
Network Status
Off Device is not initialized. The module
does not have an IP address.
Flashing Green No CIP connections. Device has an IP
address, but no CIP connections are
established.
Green
CIP connections. Device on line, has an
IP address, and CIP connections are
established.
Flashing Red One or more Ethernet®connections
has timed out.
Red No link. The module is not physically
connected to a powered Ethernet
device.
Flashing Red/Green The module is performing a self test
(only occurs during power up test).
Indication Probable Cause
PointBus Status
Off Device not powered -
check module status indicator
Flashing Red/Green Recoverable fault has occurred:
- At power up the number of
expected modules does not equal
the number of modules present
- A module is missing
- Node fault (I/O connection timeout)
Red Unrecoverable fault has occurred:
- The adapter is bus off
- Controller in program/idle mode
- Ethernet cable open
Green Adapter is on line with connections
established (normal operation,
run mode)
Indication Probable Cause
System Power*
Off Not active - Field power is off,
overloaded backplane or dc-dc
converter problem
Green System power on - dc-dc converter
active (5V)
Indication Probable Cause
Adapter Power**
Off Not active - Field power is off
Green Power on - 24V present
* System Power Indicator shows the 5V power output from the dc-dc converter.
** Adapter Power Indicator shows the 24V power input to the dc-dc converter.

isysNet EtherNet/IP Adapter, Series A (PSSCENA) E104P
7
Specifications
Following are specifications for the PSSCENA EtherNet/IP adapter.
EtherNet/IP Adapter - PSSCENA
Expansion I/O Capacity • Maximum of 63 modules
• Maximum of 5 Rack Optimized connections (for digital modules only)
• Maximum of 25 Direct connections
•
PSSCENA backplane current output = 1.0A maximum. The actual number of modules
can vary. Add up the current requirements of the modules you want to use to make sure
they do not exceed the amperage limit of 1.0A for the PSSCENA.
• Backplane current can be extended beyond 1.0A with a PSSSE24A Backplane Extension
Power Supply. Add multiple PSSSE24A modules to reach the 63 module maximum.
Cat. No. PointBus Current Requirements
PSSN8xxx 75 mA
PSSP8xxx 75 mA
PSST8xxx 75 mA
PSSTR4M12A 90 mA
PSSNACM12A 75 mA
PSSNAVM12A 75 mA
PSSTACM12A 75 mA
PSSTAVM12A 75 mA
PSSS23A 75 mA
PSSV32A 75 mA
EtherNet/IP Communication Rate 10/100Mbits /s, half or full-duplex
Power Supply Specifications
Power Supply Note: In order to comply with CE Low Voltage Directives (LVD), you must use either a
NEC Class 2, a Safety Extra Low Voltage (SELV) or a Protected Extra Low Voltage (PELV)
power supply to power this adapter. A SELV supply cannot exceed 30V rms, 42.4V peak
or 60VDC under normal conditions and under single fault conditions. A PELV supply has
the same rating and is connected to protected earth.
Input Voltage Rating 24VDC nominal
10-28.8VDC range
Inrush Current 6A maximum for 10ms
Field Side Power Requirements, Maximum 24VDC (+20% = 28.8VDC) @ 400 mA
Interruption Output voltage will stay within specifications when input drops out for
10ms at 10V with maximum load
General Specifications
LED Indicators 1 green/red Adapter status
1 green Network activity
1 green/red Network status
1 green/red PointBus status
1 green System Power (PointBus 5V power)
1 green Adapter Power (24V from field supply)
Power Consumption, Maximum 8.1W @ 28.8VDC
Power Dissipation, Maximum 2.8W @ 28.8VDC
Thermal Dissipation, Maximum 9.5 BTU/hr. @ 28.8VDC
PointBus Output Current, Maximum 1A @ 5VDC ±5% (4.75 - 5.25)
Input Overvoltage Protection Reverse polarity protected
Isolation Voltage 50V rms
(continuous-voltage withstand rating) Tested to withstand 1250VAC rms for 60s
Field Power Bus
Nominal Voltage 24VDC
Supply Voltage 10-28.8VDC range
Supply Current 10A maximum
Dimensions Inches (Millimeters) 4.41H x 2.83W x 2.56D (112H x 72W x 65D)

isysNet EtherNet/IP Adapter, Series A (PSSCENA) E104P
8
General Specifications (continued)
Operating Temperature IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20 to 60°C (-4 to 140°F)
Storage Temperature IEC 60068-2-1 (Test Ab, Un-packaged Non-operating Cold),
IEC 60068-2-2 (Test Bb, Un-packaged Non-operating Dry Heat),
-40 to 85°C (-40 to 185°F)
Relative Humidity IEC 60068-2-30 (Test Db, Un-packaged Non-operating Damp Heat):
5-95% non-condensing
Shock IEC60068-2-27 (Test Ea, Unpackaged Shock):
Operating 30g
Non-operating 50g
Vibration IEC60068-2-6 (Test Fc, Operating):
5g @ 10-500Hz
ESD Immunity IEC 61000-4-2:
6kV contact discharges
8kV air discharges
Radiated RF Immunity IEC 61000-4-3:
10V/m with 1kHz sine-wave 80%AM from 30MHz to 2000MHz
10V/m with 200Hz 50% Pulse 100%AM at 900Mhz
10V/m with 200Hz 50% Pulse 100%AM at 1890Mhz
EFT/B Immunity IEC 61000-4-4:
±4kV at 5kHz on power ports
±2kV at 5kHz on communications ports
Surge Transient Immunity IEC 61000-4-5:
±1kV line-line(DM) and ±2kV line-earth(CM) on power ports
±2kV line-earth(CM) on unshielded communications port (tested as balanced circuits)
Conducted RF Immunity IEC 61000-4-6:
10Vrms with 1kHz sine-wave 80%AM from 150kHz to 80MHz
Emissions CSPR 11:
Group 1, Class A
Enclosure Type Rating Meets IP65/66/67 (when marked)
Mounting Base Screw Torque #8 screw, 7.5 in. lbs. in Aluminum, 16 in. lbs. in Steel
Wiring Category11 - on power ports
1 - on communications ports
Weight Imperial (Metric) 0.80 lb. (0.36 kg)
Certifications: (when product is marked) c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada
CE European Union 89/336/EEC EMC Directive, compliant with:
EN 61000-6-4; Industrial Emissions
EN 50082-2; Industrial Immunity
EN 61326; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
C-Tick Australian Radiocommunications Act, compliant with:
AS/NZS CISPR 11; Industrial Emissions
EtherNet/IP ODVA conformance tested to EtherNet/IP specifications
1. Use this Conductor Category information for planning conductor routing. Refer to Publication E115P, “Industrial Automation Wiring and
Grounding Guidelines”.
