Parker H2PEMPD-510 User manual

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2PEMPD Series
www.parker.com/fns/balstonlabgenerators
1
1-800-343-4048
Parker Hydrogen Gas Generator
Installation, Operation, and Maintenance Manual
Models H2PEMPD-510, H2PEMPD-650,
H2PEMPD-850, H2PEMPD-1100, H2PEMPD-1300

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2PEMPD Series
www.parker.com/fns/balstonlabgenerators
2
1-800-343-4048
Parker Balston
Technical Information Bulletin
Please note that all Parker gas generators have a warranty period
of 1 year from the date of shipment
WARNING!
The H2PEMPD-1300 hydrogen generator, operating at full
ow, will consume the entire water reservoir volume in
approximately 60 hours.
If the user expects to run the generator, unattended, for greater than 60
hours then the auto water feed feature MUST BE used. See user’s guide for
details.
Failure to use auto water feed will result in loss of ow and pressure, and
could result in damage to generator.

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
1-800-343-4048 www.parker.com/balston
Warranty
This warranty applies to the generator and associated parts (the equipment) manufactured and supplied by Parker Hannifin
Corporation, Filtration Separation Division (the company).
Use of the generator without the recommended water quality or genuine parts will expressly invalidate the warranty. Any
modification of the generator will void the warranty.
It should be noted that the generator must be installed and running within three months of dispatch from the company to ensure the
optimum efficiency of the PEM cell. If this is not adhered to the warranty will be invalid. Should the equipment be defective as to
materials or workmanship, the company warrants that it will remedy such a defect. Where the equipment is the generator, the
warranty period will be 12 months from date of manufacture. Where the equipment is the PEM CELL, the warranty period will be 36
months from date of manufacture. In the case of equipment other than the generator, the warranty period shall commence from the
date of dispatch.
Should any defect occur during the warranty period and be notified in writing to the company or its authorized distributor within the
said period, the company will, as its sole option, remedy such defect by repair or provision of a replacement part, provided that the
equipment has been used strictly in accordance with the instructions provided with each item of equipment and has been stored,
installed, commissioned, operated and maintained in accordance with such instruction and with good practice. The company shall
not be under any liability whatsoever under the warranty, if, before giving notification in writing to the company as aforesaid, the
Customer or any third party meddles, interferes, tampers with or carries out work whatsoever (apart from normal maintenance as
specified in the said instructions) in relation to the equipment or any part thereof.
Any accessories, parts and equipment supplied by the company but not manufactured by the company shall carry whatever
warranty the manufacturer has given the company providing it is possible for the company to pass on such warranty to the
customer.
To claim under the warranty, the goods must have been installed and continually maintained in the manner specified in the User
Guide. Our product support engineers are qualified and equipped to assist you in this respect. They are also available to make
repairs that may become necessary in which event they will require an official order before carrying out the work. If such work is to
be the subject of a warranty claim, the order should be endorsed for consideration under warranty.
Where equipment is sold outside the USA direct to the end user the warranty will cover parts only. Any substitution of parts not
manufactured or approved by the company will expressly invalidate the warranty.

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
1-800-343-4048 www.parker.com/balston
1 Safety Information ..................................................................................................................................................................................................1
1.1 Markings and Symbols .......................................................................................................................................................................2
2 Description ..............................................................................................................................................................................................................3
2.1 Technical Specification........................................................................................................................................................................3
2.2 Weight and Dimensions......................................................................................................................................................................4
2.3 Receiving and Inspecting the Equipment ...........................................................................................................................................4
2.3.1 Storage..........................................................................................................................................................................4
2.3.2 Unpacking .....................................................................................................................................................................5
2.3.3 Overview of the equipment ..........................................................................................................................................5
2.4 Locating the Equipment......................................................................................................................................................................5
2.4.1 Environment .................................................................................................................................................................6
2.4.2 Space Requirements.....................................................................................................................................................6
2.4.3 Ventilation Requirements ............................................................................................................................................6
2.4.4 Water Supply Requirements ........................................................................................................................................6
2.4.5 Electrical Supply Requirements ....................................................................................................................................6
3 Installation & Setup…………. ................................................................................................................................................................................7
3.1 Recommended system layout ...........................................................................................................................................................7
3.1.1 Installation Kit ..............................................................................................................................................................7
3.2 Connecting the generator.................................................................................................................................................................8
3.2.1 Environmental filters....................................................................................................................................................8
3.2.2 Hydrogen outlet port....................................................................................................................................................8
3.2.3 Drain ports...................................................................................................................................................................8
3.2.4 Electrical supply ..........................................................................................................................................................8
3.2.5 Filling the water bottle ................................................................................................................................................9
3.2.6 Water supply (generators fitted with Auto Water Fill)................................................................................................9
3.3 Options Board Accessory .................................................................................................................................................................9
3.3.1 Fitting the Options Board............................................................................................................................................9
3.3.2 Wiring the Options Board ..........................................................................................................................................10
3.4 Starting up the Generator ..............................................................................................................................................................11
4 Operating the equipment ...................................................................................................................................................................................12
4.1 Overview of controls .....................................................................................................................................................................12
4.2 Starting the equipment .................................................................................................................................................................12
4.3 Operating Menus ..........................................................................................................................................................................13
4.3.1 Default Menu...........................................................................................................................................................13
4.3.2 Conductivity.............................................................................................................................................................14
4.3.3 Pressure Measurement...........................................................................................................................................14
4.3.4 Run Time Data ........................................................................................................................................................14
4.3.5 Flow.........................................................................................................................................................................15
4.3.6 Error Log .................................................................................................................................................................15
4.3.7 Generator Self Test ................................................................................................................................................15
4.4 Hard Reset...................................................................................................................................................................................16
4.5 Stopping the equipment and depressurizing ..............................................................................................................................16
5 Servicing...........................................................................................................................................................................................................16
5.1 Cleaning ......................................................................................................................................................................................16
5.1.1 Service Intervals.....................................................................................................................................................17
5.2 Service Kits..................................................................................................................................................................................18
5.2.1 Recommended Service A - Required every 4000Hrs (6 months) ..........................................................................18
5.2.2 Recommended Service B - Required every 16000Hrs (24 months) ......................................................................18
5.3 Consumable Replacement Procedures......................................................................................................................................19
5.3.1 Draining the water bottle …...................................................................................................................................19
5.3.2 Replacing the deionizer cartridge and 100 micron water filter ….. .......................................................................19
5.3.3 Replacing the Environmental Filters …..................................................................................................................19
5.3.4 Replacing the water pump…………………………………………………… ….. .......................................................................19
5.3.5 Replacing the fan guards………………. …..................................................................................................................21
5.3.6 Filling the water bottle…… .................................................................................................................................21
6 Error Messages................................................................................................................................................................................................20

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
1
1-800-343-4048 www.parker.com/balston
1 Safety Information
Do not install and operate this equipment until the safety information and instructions in this user guide have been read and understood by
all personnel concerned.
USER RESPONSIBILITY
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE PRODUCTS DESCRIBED HEREIN OR RELATED ITEMS CAN CAUSE DEATH,
PERSONAL INJURY AND PROPERTY DAMAGE.
This document and other information from Parker Hannifin Corporation, its subsidiaries and authorized distributors provide product or system
options for further investigation by users having technical expertise.
The user, through its own analysis and testing, is solely responsible for making the final selection of the system and components and assuring
that all performance, endurance, maintenance, safety and warning requirements of the application are met. The user must analyze all aspects
of the application, follow applicable industry standards, and follow the information concerning the product in the current product catalogue
and in any other materials provided from Parker or its subsidiaries or authorized distributors.
To the extent that Parker or its subsidiaries or authorized distributors provide component or system options based upon data or specifications
provided by the user, the user is responsible for determining that such data and specifications are suitable and sufficient for all applications and
reasonably foreseeable uses of the components or systems.
Only competent personnel trained, qualified, and approved by Parker Hannifin should perform installation, start-up, service and repair
procedures.
This equipment is for indoor use only. Do not operate outdoors.
This equipment is not suitable for use in any Hazardous, Flammable, or Explosive environments. Hydrogen is a highly flammable gas. Keep the
generator away from excessive heat and naked flames.
With the exception of oxygen, any gas can cause asphyxiation in high enough concentrations. In most scenarios, however, because hydrogen
rises and disperses so rapidly, it is unlikely to be confined where asphyxiation might otherwise occur. Always ensure that the generator is
operated in a well-ventilated area and all of the vent ports on the rear of the generator are kept clear and free from blockages.
Use of the equipment in a manner not specified within this user guide may result in an unplanned release of pressure, which may cause serious
personal injury or damage.
When handling, installing or operating this equipment, personnel must employ safe engineering practices and observe all related regulations,
health & safety procedures, and legal requirements for safety.
Ensure that the equipment is depressurized and electrically isolated, prior to carrying out any of the scheduled maintenance instructions
specified within this user guide.
Parker Hannifin cannot anticipate every possible circumstance which may represent a potential hazard. The warnings in this manual cover the
most known potential hazards, but by definition cannot be all-inclusive. If the user employs an operating procedure, item of equipment or a
method of working which is not specifically recommended by Parker Hannifin the user must ensure that the equipment will not be damaged or
become hazardous to persons or property.
Most accidents that occur during the operation and maintenance of machinery are the result of failure to observe basic safety rules and
procedures. Accidents can be avoided by recognizing that any machinery is potentially hazardous.
Note: Any interference with the calibration warning labels will invalidate the gas generator's warranty and may incur costs for the recalibration
of the gas generator.
Should you require an extended warranty, tailored service contracts or training on this equipment, or any other equipment within the Parker
Hannifin range, please contact your local Parker Hannifin office.
Details of your nearest Parker Hannifin sales office can be found at www.Labgasgenerators.com Retain this user guide for future reference.

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
2
1-800-343-4048 www.parker.com/balston
1.1 Markings and Symbols
The following markings and international symbols are used on the equipment or within this manual:
Table 1

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
3
1-800-343-4048 www.parker.com/balston
2 Description
This generator will produce a constant stream of high purity hydrogen at a predetermined flow rate and pressure when connected to
a suitable power supply and fed with a suitable quality of deionized water. It is suitable for use in laboratories and light industrial
environments and is nonhazardous for transportation purposes.
In order to guarantee the optimum efficiency of the PEM cell, this generator must be installed and running within three months of
dispatch from Parker Hannifin. Failure to do this may invalidate the warranty. The generator will perform a 60 minute (1 hour)
initialization sequence when powered for the first time. This sequence, which cannot be aborted, is necessary to guarantee the
correct hydration of the cell.
2.1 Technical Specification
This specification is valid when the equipment is located, installed, operated, and maintained as specified within this user guide.

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
4
1-800-343-4048 www.parker.com/balston
Table 2
Units
H2PEMPD-510
H2PEMPD-650
H2PEMPD-850
H2PEMPD-1100
H2PEMPD-1300
cc/week
4000
5000
7000
8000
9000
psi g
(bar g)
cc/min
°F
(°C)
ml/min.
510
650
850
1100
1300
H2PEMPd-XXX-100
H2PEMPd-XXX-175
%
Power
270
300
340
420
450
A
°F
(°C)
-
-
-
-
ft.
(m)
dB(A)
1. Based on full flow with 24 hour 7 day operation at 22
°C (72°F) ambient temperature.
2. Applies to generators with auto water fill only.
3. The balance is less than 1 ppm O2 and moisture.
4. Anti surge (T), 250V, 5 x 20mm HBC, Breaking capacity 1500A @ 250V, IEC 60127, UL R/C Fuse.
Pollution Degree
Installation Over Voltage Category
Maximum Altitude
Noise
Supply Voltage Range/Frequency
Fuse
4
Environmental Data
Ambient Temperature
Relative Humidity
IP Rating
Deionized, ASTM II, > 1M
?, <1µS, Filtered to <100µm
1.45
(0.1)
1000
68
(20)
Connection Type
High Purity Hydrogen (H
2
)
Outlet Flow Rate
Purity
3
Mechanical Connections
Hydrogen Outlet
Water Drain
Automatic Water Fill Inlet (factory or
field fit option)
Overflow Drain
Spillage Drain
Electrical Data
Supply Temperature (Max)
2
Outlet Pressure
Water
Water Quality
Consumption (Approximate)
1
Supply Pressure (Max)
2
Supply Flow Rate (Max)
2
1/2" Barbed push on fitting
psi g
(bar g)
5-100
± 0.5
(0.3-6.89 ± 0.034)
99.99999+%
1/4" Compression fitting
5-175
± 0.5
(0.3-12.06 ± 0.034)
<60
VA
50% @ 104
°F (40°C) (80% Max < 87.8°F (31°C)
IP20, NEMA 1, Indoor use only
2
II
<6562
(2000)
IEC320
100-240Vac 50/60Hz
5
50-90
(10-32)
Quick release push in fitting
Quick release push in fitting
Quick release push in fitting

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
5
1-800-343-4048 www.parker.com/balston
2.2 Weight and Dimensions
The dimensions and weight of the equipment are specified below.
Figure 1
Table 3
2.2 Receiving and Inspecting the Equipment
On receipt of the equipment carefully inspect the packaging for damage. If the packaging is damaged inform the delivery company
immediately and contact your local Parker Hannifin office.
2.3.1 Storage
If the equipment is to be stored prior to installation, do not remove it from the packaging. Ensure that it is stored in an upright
position as indicated by the arrows on the packaging
Do not attempt to lift the generator by yourself. It is recommended that the generator be carried by a minimum of
two persons or transported on a pallet truck.
Note. The storage area should be secure and the environmental conditions should fall within those specified in the technical
specification. If the generator is stored in an area where the environmental conditions fall outside of those specified, it is essential
that it be moved to its final location (installation site) and left to stabilize prior to unpacking. Failure to do this could cause
condensing humidity and potential failure of the generator.
Units H2PEMPD-510 H2PEMPD-650 H2PEMPD-850 H2PEMPD-1100 H2PEMPD-1300
in (mm) 17.1 (435) 17.1 (435) 17.1 (435) 17.1 (435) 17.1 (435)
in (mm) 13.5 (342) 13.5 (342) 13.5 (342) 13.5 (342) 13.5 (342)
in (mm) 21 (533) 21 (533) 21 (533) 21 (533) 21 (533)
in (mm) 25.4 (645) 25.4 (645) 25.4 (645) 25.4 (645) 25.4 (645)
in (mm) 4.3 (108) 4.3 (108) 4.3 (108) 4.3 (108) 4.3 (108)
in (mm) 4.4 (11.5) 4.4 (11.5) 4.4 (11.5) 4.4 (11.5) 4.4 (11.5)
in (mm) 2.3 (59.5) 2.3 (59.5) 2.3 (59.5) 2.3 (59.5) 2.3 (59.5)
lb (kg) 51.4 (23.4) 51.4 (23.4) 51.4 (23.4) 51.4 (23.4) 51.4 (23.4)
lb (kg) 60.2 (27.4) 60.2 (27.4) 60.2 (27.4) 60.2 (27.4) 60.2 (27.4)
( b )
( c )
Dimension
H
W
D
( a )
( d )
Weight
Water bottle empty
Water bottle full

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
6
1-800-343-4048 www.parker.com/balston
2.3.2 Unpacking
Once ready to install, remove the equipment from the packaging and check for signs of damage. Verify that the following items have
been included with the shipment:
Table 4
If any items are missing or damaged please contact your local Parker Hannifin office. Do not attempt to power up the generator.
2.3.3 Overview of the equipment
Figure 2
1Control panel 8Overflow drain
2Options boa rd connection port 9Fused IEC 320 inlet s ocket and ON/OFF s witch
3
O2 vent (<250ml/min) 10 Wa ter bottle s pi l lage drai n
4
Exces s H2 vent (<1 ml/min) 11 Environmental fi l ter
5Wa ter bottle vent 12
Hydroge n outl e t port val ve
6Wa ter drain 13 Puri fier
7Auto water fill conne ction (fa ctory or fi eld fit opti on) 14 Wa ter level
15 H2 blee d outlet
Table 5
2.4 Locating the Equipment
This equipment is not suitable for use in any Hazardous, Flammable, or Explosive environments. Keep the
generator away from excessive heat and open flames.
Description Qty
Wa ter drai n tube 1
Wa ter fill tube11
Dei onizer ca rtridge 1
Environmenta l fil ters 2
Electrical supply ca ble 5
1. Supplied only with generators fitted with the water fill option

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
7
1-800-343-4048 www.parker.com/balston
2.4.1 Environment
The equipment should be located indoors in an environment that protects it from direct sunlight, moisture, and dust. Changes in
temperature, humidity, and airborne pollution will affect the environment in which the equipment is operating and consequently may
impair the safety and operation.
It is the customers' responsibility to ensure that the environmental conditions specified in table 2 are maintained.
2.4.2 Space Requirements
The equipment should be mounted on a flat surface, capable of withstanding the weight of the equipment and all ancillary parts. A
minimum clearance of 150mm (5.9in) should be provided on all sides of the generator for air flow. Additional space should be
provided so that the generator can be moved to allow unrestricted access to the generator during servicing and maintenance.
Do Not block the side vents or the fans located on the rear panel of the generator.
When considering the vertical clearance you must take into account the height required when the front upper access panel is in the
open position. Refer to table 3 for overall dimensions of the equipment.
Do Not position the equipment so that it is difficult to operate or disconnect from the electrical supply.
2.4.3 Ventilation Requirements
The accumulation of hydrogen can displace oxygen thereby creating an asphyxiation hazard. Always ensure that
the equipment is operated in a well-ventilated area.
2.4.4 Water Supply Requirements
Generators fitted with an automatic water fill system maintain the water level from a gravity fed fresh deionized water supply. Refer
to “Technical Specification” on page 3 for the supply requirements.
The use of any water, other than deionized water (Deionized, ASTM II, >1 MΩ, <1µS, filtered to <100µm), within this
generator will damage and reduce the lifetime of the hydrogen cell.
The generator should be connected to the supply using 1/4” PTFE tubing (1/4” PTFE supplied). Note. The automatic water fill
system is available as a factory or field fit optional extra. Contact Parker Hannifin for further details.
2.4.5 Electrical Supply Requirements
The equipment should be connected directly from the fused IEC 320 inlet socket to the electrical supply using the appropriate power
cord supplied. The equipment should be positioned so that it can be connected to the electrical supply without the use of an
extension cord.
It is the customer’s responsibility to provide a fused electrical supply to the equipment (Refer to table 2 for the electrical
specification). It is recommended that this supply have surge protection.
The equipment is connected to protective earth (ground) through the power cord. It is essential that electrical
supply is equipped with a protective earth (ground) terminal. If an alternative power cord is used to connect the
equipment to the electrical supply, ensure that it is suitably rated for the application and contains a protective
earth (Ground) conductor.

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
8
1-800-343-4048 www.parker.com/balston
3 Installation & Setup
Only competent personnel trained, qualified, and approved by Parker Hannifin should perform commissioning
and service procedures.
3.1 Recommended system layout
Figure 3
Table 6
Note. For applications that require multiple generators, please contact your local Parker Hannifin office.
3.1.1 Installation Kit
Kit Number
Description
IK-0005
Hydrogen / Outlet Hard Copper Plumb
11417-1
Premium Copper Tubing 1/8"
11412-1
Premium Copper Tubing 1/4"
Table 7
The installation kits shown in table 7 will allow for installations as shown in figure 3. Please contact your local Parker Hannifin office
for more details.

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
9
1-800-343-4048 www.parker.com/balston
3.2 Connecting the generator
3.2.1 Environmental filters
Remove the transit plugs from the vent ports, on the rear of the generator, and fit the environmental filters as shown in figs. 4 and 5.
Figure 4 Figure 5
3.2.2 Hydrogen outlet port
Refer to “Recommended system layout” on page 7 for the desired system configuration.
The generator should be connected to the application instrument using either high quality stainless steel tube or grade (B-280)
copper tube. Remove the compression plug from the hydrogen outlet port compression fitting. Insert the tube into the outlet port
fitting and rotate the tube nut until finger tight. Using a spanner (wrench) tighten the nut one and one-quarter (1 1/4) turns. Take note
that the hydrogen outlet port valve remains closed until unit has initialized. When cutting the tubes always use the correct tools to
allow a clean perpendicular cut. Cutting tubes will cause debris that, if not removed, may damage the downstream instrumentation.
It is recommended that all pipes are purged to remove any debris that may exist. When routing the tubes ensure that they are
adequately supported to prevent damage and leaks in the system. All components used within the system must be rated to at least
the maximum operating pressure of the equipment. Always protect the system by installing suitably rated pressure relief valves.
To prevent injury, and damage to the application instrument, the system piping will require purging for at least 15 minutes to
remove any trapped oxygen. If using a 3-way ball valve with vent line, as recommended on page 7, ensure that the valve is open to
the vent line and not to the application instrument. If a ball valve is not being used, ensure that the application instrument is not
connected to the system piping. Refer to “Commissioning the Generator” on page 11 for details on purging.
3.2.3 Drain ports
The overflow drain and the water bottle spillage drain must be permanently piped away using 1/2” and 1/4” PTFE tubing
respectively. The tube connected to the overflow drain should have a u-bend to prevent contamination of the internal water bottle.
Always check with local guidelines for disposing of deionized water.
3.2.4 Electrical supply
Check the rating plate for the correct supply voltage and frequency. Select the required power cord and connect it to the switched
IEC 320 socket on the generator. Connect the plug directly to the electrical supply. Do not use an extension cord.

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
10
1-800-343-4048 www.parker.com/balston
3.2.5 Filling the water bottle
The use of any water, other than deionized water (Deionized, ASTM II, >1 MΩ, <1µS, filtered to <100µm), within this
generator will damage and reduce the life time of the hydrogen cell.
Fill the water bottle, as shown in figure 6, using fresh deionized water to a level approximately 15mm below the upper lip of the neck
of the bottle. If the generator is powered up an audible and visual indication will be given when the correct level is reached.
Wearing suitable gloves to prevent contamination, insert the deionizer cartridge into the water bottle and fit the cap securely.
3.2.6 Water supply (generators fitted with Auto Water Fill)
The optional water fill allows the generator's water bottle to be gravity fed from a suitable deionized water supply. When the water
level falls below the mid-point, the water bottle will be replenished from the deionized water supply.
Connect the deionized water supply to the automatic water fill inlet using the adaptor provided and clean 1/4” PTFE tubing. It is
recommended that a balance line is fitted at the inlet to prevent air locks. Flush the line through to remove any trapped air. Refer to
“Technical Specification” on page 3 for water supply requirements.
Figure 6
3.3 Options Board Accessory
The options board is designed for connection to Safe Extra Low Voltage (SELV) systems only. Maximum 12vdc 50mA.
The options board accessory allows direct communication with a PC via the USB port, and connection of water monitoring, remote
alarm, and remote stop circuits. For applications requiring load balancing, please contact your local Parker Hannifin office.

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
11
1-800-343-4048 www.parker.com/balston
3.3.1 Fitting the options Board
Plug the options board harness into the 15-way D-type connector on the rear of the generator. The harness should be secured in
place using the retaining screws provided. The options board enclosure can be placed on the bench or behind the generator
mounted to the wall.
Figure 7
3.3.2 Wiring the Options Board
Table 8
JP3 Remote Stop –The remote stop function allows the generator to be connected to an external stop circuit. Press to reset
the generator.
JP4 Alarm Output –The alarm output is designed for remote alarm indication. When an error occurs on the generator, the output
switching circuit is activated causing the remote circuit to be complete.
The remote alarm circuit will be reset when the generator error has been reset.
JP5 Water Fill Output –The water fill output allows for remote monitoring of the water bottle level. When the water level drops
below the mid-point in the water bottle, this output activates an external water fill system.
RS485 JP1_1
Not us ed
(Do not connect)
RS485 JP2_1
Not us ed
(Do not connect)
JP3_1 Swi tched i nput
JP3_2 GND
JP4_1
JP4_2
JP5_1
JP5_2
USB JP6
Wa ter fi ll output
Alarm output
Remote stop
Open col l ector output
Open col l ector output

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
12
1-800-343-4048 www.parker.com/balston
3.4 Starting up the Generator
Ensure that a suitable vent line is provided during the commissioning stage as hydrogen will flow from the unterminated
system piping.
In order to guarantee the optimum efficiency of the PEM cell, this generator must be installed and running within three
months of dispatch from Parker Hannifin. Failure to do this may invalidate the warranty. The generator will perform a 60
minute (1 hour) initialization sequence when powered for the first time. This sequence, which cannot be aborted, is
necessary to guarantee the correct hydration of the cell.
1 Referring to the recommended set up (figure 3), use the 3-way ball valve to isolate the application instrument from the
system and divert the flow to the vent line.
If a 3-way ball valve has not been installed, disconnect the application instrument from the system and connect the open
ended piping to a suitable vent line
2 Connect the generator to the electrical supply and switch it on at the wall socket. Turn the generator on at the power
switch (located on the rear of the generator) and wait.
The generator will perform a system check during which time the water bottle indicators will illuminate white then yellow,
the system check LED will flash, and the software version number, generator serial number and the company banner will
be displayed on the LCD.
On completion the generator will warm up and the display will show “Initializing”. Once warm up is complete the unit will
revert to the default menu as shown in figure 10.
Note: Upon first use, the generator may appear to stop building pressure while the separation chamber fills with water.
Should this happen, restart the generator.
3 The internal pressure (“ACT” pressure) of the generator will build up to the required operating pressure (“SET” pressure).
To achieve the required pressure at the process instrument, it is recommended that the set pressure of the generator be
10 psig above the required pressure (i.e. to achieve 50 psig at the instrument, set pressure of the generator should be 60
psig). Doing so will negate fluctuations in pressure due to the process and pressure drop within the process piping.
4 Once the required pressure is reached, the outlet valve of the generator will be opened, as indicated by “ LOAD ” on the
display. At this time, the hydrogen outlet port valve must be opened and hydrogen will flow through the system piping and
out through the atmospheric vent line.
5 Close the 3-way ball valve to pressurize the system piping. Check for leaks and repair as required.
6 Open the 3-way ball valve to divert the flow to the application instrument.
During start-up, the generator may revert to the last error mode it experienced. If this occurs press .
When the error is cleared, the generator will continue with the start up procedure. If the error cannot be cleared by this
method follow the fault finding procedure in section 6 of this user guide.
If the pressure envelope of the system has been breached it will be necessary to run through this procedure when starting
the generator.

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
13
1-800-343-4048 www.parker.com/balston
4 Operating the equipment
4.1 Overview of controls
Figure 8 Table 9
4.2 Starting the equipment
Connect the generator to electrical supply and switch it on at the wall socket. Turn the generator on ( I ) at the power switch (located
on the rear of the generator) and wait.
The generator will perform a system check during which time the water bottle indicators will illuminate white then yellow, the system
check LED will flash, and the software version number, generator serial number and the company banner will be displayed on the
LCD.
Upon completion, the generator will enter INITIALIZING mode while the purifier is heating. Once complete it will revert to the default
menu as shown in figure 10.
Note: Upon first use the generator may appear to stop building pressure while the separation chamber fills with water. Should this
happen, restart the generator. The internal pressure (“ACT” pressure) of the generator will build up to the required operating
pressure (“SET” pressure). Once the required pressure is reached, the outlet valve of the generator will be opened, as indicated by
“LOAD ” on the display shown in figure 9, and hydrogen will be supplied to the application instrument.
Figure 9
If the generator is being powered for the first time, it will take approximately 48 hours for the generator to reach
the purity specified.
During start-up the generator may revert to the last error mode it experienced. If this occurs press . When the error is cleared
the generator will continue with the startup procedure. If the error cannot be cleared by this method follow the fault finding procedure
in section 6 of this user guide.
1
2
3
Indicator Generator status
Flas hing green
Startup
Initi a l ization
Sol i d green On-li ne
Flas hing red Non criti ca l errors
Red
Criti ca l errors
(s ys tem l ocked)
Amber
On-l i ne,
servi ce required
Tri-col ored s ystem check i ndica tor
Control key pa d us ed for menu na vigation a nd
generator operation
16 x 2 line menus di s pl a y
SET 100 PSI LOAD X
ACT 90 PSI
SET 100 PSI LOAD√
ACT 100 PSI

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
14
1-800-343-4048 www.parker.com/balston
4.3 Operating Menus
There are 8 menus used by the generator to display and access operational parameters and data. These can be accessed from the
default menu by sequentially pressing on the control panel. These menus are shown in table 10.
Table 10
4.3.1 Default Menu
The default menu displays the following data:
Figure 10
SET - The outlet pressure required by the application.
The required outlet pressure can be adjusted up and down using the and keys respectively.
ACT - Current actual internal / outlet pressure of the generator.
LOAD X/ -Indicates the status of the generator outlet valve. “X” - Outlet is closed, “ “- Outlet is open.
100% - The shaded blocks indicate the rate of hydrogen production. Each block represents 20% of the
rated capacity of the generator.
During initial startup, all five blocks will be shaded indicating that the generator is building up pressure and not currently
on line. When the generator is on-line and delivering gas to the application, the number of blocks shaded will depend
upon the flow required by the application.
1Defa ul t
2Conducti vity (water qua l i ty)
3Pres sure - units of meas urement
4Run time / Service interval
5Flow
6Error log
7Generator s elf tes t
SET 100 PSI LOAD√
ACT 100 PSI
CONDUCTIVITY
X √
PRESSURE UOM
PSI
HOURS RUN XXXXX
SERVICE IN XXXXX
FLOW ml/MIN 000
LITERS 000
ERROR LOG
HOLD &
** SELF TEST **
HOLD &
SET 100 PSI LOAD√
ACT 100 PSI

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
15
1-800-343-4048 www.parker.com/balston
Stand by Mode–The flow of hydrogen to the application can be interrupted by switching the generator into standby mode.
Press and hold to select stand by. The default menu will change to the standby menu as shown to indicate that the outlet
valve is closed and hydrogen is no longer being supplied to the application.
Figure 11
To return to normal operation, press
Reset–Pressing the enter key (middle key) during an error condition will reset the system.
Figure 12
4.3.2 Conductivity
The conductivity menu gives a graphical indication of the water quality. When all 10 blocks are shaded the water quality is to
specification.
When the number of shaded blocks drops to four, the “Change Water” error message will be displayed, the water bottle indicator will
flash yellow, and an intermittent alarm will sound. Hydrogen will continue to be delivered to the application.
If the water quality degrades to the point at which none of the blocks are shaded, the outlet valve of the generator will close and a
conductivity error will be generated. The water bottle indicator will illuminate yellow and a continuous alarm will sound. Hydrogen will
not be delivered to the application.
Press to advance to the next menu.
Figure 13
The water bottle should be drained and refilled with deionized water, ASTM II, >1 MΩ, <1µS, filtered to <100µm at
the earliest convenient time.
4.3.3 Pressure Measurement
The units of pressure measurement may be changed between bar, psi and Mpa. Press or to change the units of
measurement. When the desired units have been selected, press to advance to the next menu
** STANDBY **
ACT 100 PSI
** RESET **
CHANGE WATER
ACT 100 PSI
CONDUCTIVITY
X √
CONDUCTIVITY
ACT 100 PSI

Bulletin TI-H2PEMPD-D Installation, Operation and Maintenance Manual
Hydrogen Gas Generator H2 PEMPD series
16
1-800-343-4048 www.parker.com/balston
HOURS RUN XXXXX
SERVICE IN XXXXX
4.3.4 Run Time Data
The Run Time Data Menu displays the following data:
HOURS RUN - Time in hours that the generator has been producing hydrogen.
SERVICE IN -The time in hours that the generator can produce hydrogen before a service is required.
Figure 14
4.3.5 Flow
The Flow menu displays the current flow and the total amount of hydrogen produced by the generator when on-line.
Flow ml/min. - Current flow in ml/min being produced by the generator. This is for qualitative indication only and we recommend the
use of a flow meter to gain an accurate measurement.
Liters - Total amount of hydrogen produced by the generator measured in liters.
Figure 15
4.3.6 Error Log
The Error Log menu allows the user to access the 10 most recent error messages. To access the errors press and hold .
The menu will display the most recent error, message number “0”, along with the date and time of when the error occurred. Use the
and keys to scroll through the remaining error messages. Press to return to the error log menu.
Figure 16
4.3.7 Generator Self Test
The generator must be disconnected from the system when running the self test routine.
From the Self Test Menu press and hold and . As the generator runs through the test routine, the menus will change as
follows:
Pressure release–All pressure within the generator is released. The test will not proceed until the generator is fully depressurized.
Pressure build–The generator is pressurized to a maximum operating pressure of 100 or 175 psi g (6.89 or 12.06 bar g). The time
taken to reach this pressure is monitored by the generator.
FLOW ml / MIN 000
LITERS 000
DD/MM/YY HH:MM 0
* DESCRIPTION *
ERROR LOG
HOLD &
