Parkinson Cowan SIG 233 User manual

GAS COOKER
SIG 233
GB

2

3
CONTENTS
Instructions for the User Instructions for the Installer
Warnings
Use and care
Use of the appliance
Using the Oven
Using the Grill
Using the Hob
Hints and tips
Maintenance and cleaning
Oven bulb replacement
Something Not Working
Service and spare parts
Guarantee Conditions
4
5
6
6
8
9
12
13
14
15
16
17
Technical Features
Advice for safety
Gas connection
Electrical connections
Installation
Gas connection
Conversion of gas
18
19
19
20
21
22
24
How to read the instruction book ?
The symbols below will guide you when reading
the instruction book
Safety instructions
Description of operations step by step
Advice and recommendation
Information environment protection

4
IMPORTANT SAFETY INFORMATION
Installation
•This cooker must be installed by qualified
personnel, according to the manufacturer’s
instructions and to the relevant British
Standards.
•This cooker is heavy. Take care when moving it.
•Any gas installation must be carried out by a
registered CORGI installer.
•Any electrical installation must be carried out
by a qualified electrician/competent person.
•Remove all packaging before using the cooker.
•This cooker must not be connected to a
combustion products evacuation device. It
shall be installed and connected in
accordance with current installation
regulations. Particular attention shall be given
to the relevant requirements regarding
ventilation.
•This cooker is designed to be connected to a
230-240V, 50Hz electrical supply.
•Ensure that the gas and electrical supply
complies with the type stated on the rating
plate, located near the gas supply pipe.
•Do not attempt to modify the cooker in any
way.
Child Safety
•This cooker is designed to be operated by
adults. Do not allow children to play near or
with the cooker.
•The cooker gets hot when it is in use. Children
should be kept away until it has cooled.
•Children can also injure themselves by pulling
pans or pots off the cooker.
During Use
•This cooker is intended for domestic cooking
only. It is not designed for commercial or
industrial purposes.
•When in use a gas cooker will produce heat
and moisture in the room in which it has been
installed. Ensure there is a continuous air
supply, by keeping air vents in good condition
or installing a cooker hood with a venting hose.
•When using the cooker for a long period time,
the ventilation should be improved, by
opening a window or increasing the extractor
speed.
•Do not use this cooker if it is in contact with
water. Do not operate the cooker with wet
hands.
•The grill pan will become hot during use,
always use oven gloves when removing or
replacing a hot grill pan.
•Ensure the control knobs are in the ‘OFF’
position when not in use.
•When using other electrical appliances,
ensure the cable does not come into contact
with the hot surfaces of the cooker.
•Unstable or misshapen pans should not be
used on the hob burners as unstable pans
can cause an accident by tipping or spillage.
•Never leave the cooker unattended when
cooking with oil and fat.
•Never pull the appliance by the oven handle.
•This cooker should be kept clean at all times.
A build-up of fat or foodstuff could result in a
fire.
•Never use steam or high pressure appliances
for cleaning the oven.
•Never use plastic dishes in the oven or on the
hob burners. Never line any part of the oven
with aluminium foil.
•Always ensure that the oven vent, which is
located at the centre back of the hob, is left
unobstructed to ensure ventilation of the oven
cavity.
•Perishable food, plastic items and aerosols
may be affected by heat and should not be
stored above the cooker.
•The appliance is fitted with a lid: this is
designed as a dust cover when closed, and
as a splash back when open. Do not use for
any other purpose.
•Always remove any spillage from the surface
of the lid before opening, and the appliance
should be allowed to cool before closing the lid.
•After using the cooker, the lid MUST NOT be
closed until the hob and oven are completely
cold.
Service
•This cooker should only be repaired or
serviced by an authorised Service Engineer
and only genuine approved spare parts
should be used.
Environmental Information
•After installation, please dispose of the
packaging with due regard to safety and the
environment.
•When disposing of an old appliance, make it
unusable, by cutting off the cable.
You MUST read these warnings carefully before installing or using the appliance. If you
need assistance
,
contact our Customer Care De
p
artment on 08705 950950.
Keep this instruction book for future
reference and ensure it is passed on to
an
y
new owner.

5
INSTRUCTIONS FOR THE USER
USE AND CARE
Control panel
Model : SIG 233
3
246
15
7
BACK LEFT FRONT LEFT FRONT RIGHT BACK RIGHT SELECTOR
1. Back left burner control knob
2. Front left burner control knob
3. Front right burner control knob
4. Back right burner control knob
5. Oven light
6. Oven/Grill burner control knob (selector)
7. Ignition switch
Hob
1
2
4
3
1. Back left burner (auxiliary)
2. Front left burner (rapid)
3. Front right burner (semi-rapid)
4. Back right burner (semi-rapid)

6
USE OF APPLIANCE
Before the First Use of the Cooker
Remove all packaging both inside and
outside of the cooker, before using it.
Before first use, the oven should be heated
without food. During this time, an unpleasant
odour may be emitted. This is quite normal.
1. Remove the oven accessories and ensure all
packaging has been removed.
2. Ignite the oven burner (see instructions) and
turn the control knob to maximum.
3. Open a window for ventilation.
4. Allow the oven to run empty for
approximately 45 minutes.
This procedure should be repeated with the grill
function for approximately 5-10 minutes.
Using the Oven
The cooker gets hot when it is in use.
Children should be kept away until it has
cooled.
Stand clear when opening the drop down
oven door. Do not allow it to fall open -
support the door using the door handle,
until it is fully open.
When using the oven the lid must be
open to avoid over-heating.
Attention: when turning on the oven and
grill burner the oven door has to be
opened.
The oven has four shelf levels, and is supplied
with one shelf.
The shelf positions are counted from the bottom
of the oven as shown in the diagram.
Oven Safety device
The cooker features a thermocouple; if for
any reason the flame should extinguish, the
device will stop the gas flow.
Use
The oven can be used for traditional cooking, or
for grilling, but not both functions simultaneously.
The symbol on the knob corresponds to the
symbol on the control panel.
Off
“8” Maximum
“1” Minimum
Grill function
4
3
2
1

7
Ignition
Attention: when turning on the oven and
grill burner the oven door has to be
opened.
•Open the oven door, push and turn the control
knob to the left to position 8, keeping the
control knob pressed.
•At the same time, push the electronic
ignition knob (see fig). Keep it pushed until the
gas ignites (1 spark / second).
•Release the knob after 10 seconds and
check that the burner is ignited through the
holes in the burner cover.
OR
During a power cut
•Open the oven door, push and turn the control
knob to the left to position 8, and hold a flame
near the hole in the bottom;
•Release the knob after 10 seconds and
check that the burner is ignited through the
holes in the burner cover.
If for any reason the flame should extinguish turn
the control knob to the off position, after at least 1
minute, try to re-ignite the oven.
To adjust the flame, turn the oven knob to the
position corresponding to the temperature desired,
after a few minutes of operation.
Turning off the oven burner
Turn the knob clockwise to mark « ».
Gas Mark Temperature oC
1 160
2 175
3 190
4 205
5 225
6 245
7 255
Cooking in the Oven
Traditional cooking is made by natural
convection; the heated air circulates on the
principle of ascending and descending draughts.
It is necessary to pre-heat the oven.
All cookers vary and it is important to be
aware of the approximate cooking
temperatures before you use the cooker.
8 275
The chart shows the gas mark temperatures
together with the approximate equivalent
temperatures in oC.
It may be necessary to adjust the temperature to
suit your individual requirements. Only
experience will enable you to determine the
correct setting for your personal requirements.

8
Using the Grill
When grilling, the accessible parts of the
appliance are hot and the appliance should
not be left unattended. Take care that children
do not play near it. While the grill is operating
leave the oven door half open and put the grill
deflector “A” into place.
Grill burner ignition
Attention: when turning on the oven and
grill burner the oven door has to be opened.
•Open the oven door push and turn the
control knob to the right to the “grill symbol”
and keep the control knob pressed.
•At the same time, push the electronic
ignition knob (see fig). Keep it pushed until
the gas ignites (1 spark / second).
•Upon ignition, keep the knob pressed for
approximately 10 seconds (until the safety
valve automatically keeps the grill burner
lit).
OR
During a power cut
•Open the oven door.
•Hold a flame to the gas grill burner holes (see
fig.).
•Press the oven/grill function control knob, then
turn it to the “grill symbol”. Upon ignition,
keep the knob pressed for approximately
10 seconds (until the safety valve
automatically keeps the grill burner lit).
If for any reason the flame should extinguish turn
the control knob to the " " position, leave for at
least 1 minute and then re-ignite.
The grill pan will become hot during use,
always use oven gloves when removing or
replacing a hot grill pan.
Grilling
When using the grill it has to be
supervised, the oven door opened and
the grill deflector “A” in its place.
When grilling, only the top burner is heating. It is
not necessary to preheat the grill.
•Insert the grill pan on the fourth level.
•Turn the knob to position “grill”.
•Adjust the grid and pan position to allow for
different thicknesses of food. Position the food
close the grill for faster cooking and further
away for gentler cooking.
A

9
Heat comes from the top of the oven. It is
suitable for grilling meat (beef bacon, pork bacon
…) that remains tender, for toast or to brown
dishes already cooked dishes.
Grilling meat
When using the grill it has to be
supervised, the oven door opened and
the grill deflector “A” in its place.
•Prepare the meat to be grilled, lightly brush it
with oil on both sides.
•Place it on the roasting grid.
•Turn the oven/grill control knob to position “grill”.
•Slide the roasting grid in the guide 4 and the
roasting tray in the guide 3.
•When the first side is brown, turn the meat
without pricking it in order that the juices are
not lost.
•Grill the second side.
Cooking time is determined by the thickness of
the piece to be grilled not by its weight.
Browning
•Turn the oven/grill control knob to the “grill”
position.
•Place the dish on the grid and slide it on shelf
guide 4.
•Leave the dish under the grill for a few
minutes.
Oven light
The oven is equipped with a lamp. It starts
operating when the switch on the control
panel is pressed .
Using the Hob
The Hob Burners
The symbol on the control panel shows which
burner is operated by the knob. (See control
panel).
Off
Maximum level
Minimum level
Use the maximum level for boiling and the
minimum for simmering.
Always choose positions between the minimum
and maximum, never between maximum and off.
4
3
2
1

10
Ignition of the burners
•Push the knob and turn it left to the “large flame“
symbol.
•At the same time, push the electronic ignition
knob (see fig). Keep it pushed until the gas
ignites (1 spark / second).
•Release the knob and check that the burner
has ignited.
•Upon ignition, adjust the flame as required.
OR
Power Cut
•Push the corresponding knob in completely
and turn it left to the “large flame“ symbol and
ignite with a match.
•Release the knob and check that the burner
has ignited.
•Upon ignition, adjust the flame as required.
If for any reason the flame should extinguish turn
off the relevant control knob, leave for at least
one minute and then re-ignite.
If after a few attempts the burner does not ignite,
check that the burner ring and its cap are
correctly positioned.
Turning off the burners
Turn the control knob clockwise to mark « ».
Do not put anything on the hob that is
liable to melt.
Selecting the Correct burner
Above every knob there is a symbol for the
corresponding burner.
For good cooking results, always choose pans,
which correctly fit to the diameter of the burner
used (see figs). Choose thick, flat bottom pots.
We recommend the flame is lowered as soon as
the liquid starts boiling.
For a correct ignition always keep the burner ring
and the spark plugs clean.
The following diameter pans can be used:
Good use
B
a
d
use
(
Power waste
)
Burner Power Diameter (mm)
(kW) min. max.
Rapid 3,00 160 280
Semi-
Rapid 2,00 140 240
Auxiliary 1,00 120 180

11
Accessories delivered with the
appliance
The following accessories are supplied with your
appliance.
•Grill Deflector
To be used when the grill is operation.
•Shelf for placing dishes on (roast, pastry
mounds)
The dish should be put in the middle of the
shelf to balance the weight.
•A roasting tray with roasting grid on it.
It is used to collect juice when cooking in it,
place it on the shelf 2.
If you do not use the roasting tray, remove it
from the oven.
•Removable handles
In addition to the accessories supplied we
recommend you only use heatproof dishes/pans
(according to the manufacturer’s instructions).
Removable drawer
The removable drawer is located underneath the
oven cavity.
During cooking the drawer may
become hot if the oven is in use for a long
period of time. Flammable materials such as
oven gloves, tea towels, plastic aprons etc.
should not be stored in the drawer.
Oven accessories such as baking sheets, will
also become hot, therefore care should be taken
when removing these items from the drawer
whilst the oven is in use or still hot.
To open
•Grasp the drawer from underneath and pull it
out as shown.
•To remove the drawer, pull it out to the stop,
then lift it up slowly and pull it out completely.
To replace the drawer follow the same
procedure in reverse.

12
Hints and Tips
Condensation and steam
When food is heated it produces steam in the
same way as a boiling kettle. The oven vents
allow some of this steam to escape. However,
always stand back from the oven when
opening the oven door to allow any build up of
steam or heat to release.
If the steam comes into contact with a cool
surface on the outside of the oven, e.g. a trim, it
will condense and produce water droplets. This
is quite normal and is not a fault with the oven.
To prevent discolouration, regularly wipe away
condensation and also soilage from surfaces.
Cookware
Use any ovenproof cookware, which will
withstand temperatures of 275°C.
Oven dishes, etc. should not be placed
directly on the oven base.
Oven Cooking
•Turn off the oven 5 minutes before the end of
cooking time, and use residual heat to
complete the cooking.
•The thickness, the material and the colour of
the pan will influence the cooking results.
•When cooking, certain dishes increase in
volume, ensure the pan is large enough.
•To prevent fat dripping when roasting use tall
rim pans proportional to the item being
roasted.
•Prick the skin of poultry and sausages with a
fork before cooking to avoid spitting.
•Use heatproof glass dishes for soufflés.
The effects of dishes on cooking results
Dishes and tins vary in their thickness,
conductivity, colour, etc. which affects the way
they transmit heat to the food inside them.
AAluminium, earthenware, oven glassware
and bright shiny utensils reduce cooking and
base browning.
BEnamelled cast iron, anodised aluminium,
aluminium with non-stick interior and coloured
exterior and dark, heavy utensils increase
cooking and base browning.

13
MAINTENANCE AND CLEANING
The oven should be kept clean at all
times. A build-up of fats or other
foodstuffs could result in a fire.
Before cleaning, ensure all control
knobs are in the OFF position, and the
appliance has cooled completely.
Before any maintenance or cleaning
can be carried out, you must
DISCONNECT the cooker from the
electricity supply.
Cleaning materials
Before using any cleaning materials on your
oven, check that they are suitable and that their
use is recommended by the manufacturer.
Cleaners that contain bleach should NOT
be used as they may dull the surface
finishes. A steam cleaner is not to be
used. Harsh abrasives should also be
avoided.
External cleaning
We recommend for cleaning cleaners that do
not scratch the surface; Avoid use of metall
objects, steel wool or nylon pads, abrasive or
caustic products, or diluents. Regularly wipe over
the control panel, the cover, oven door and door
seal using a soft cloth well wrung out in warm
water to which a little washing up liquid has been
added.
To prevent damaging or weakening the
door glass panels avoid the use of the
following:
•Household detergent and bleaches
•Impregnated pads unsuitable for non
stick saucepans
•Brillo/Ajax pads or steel wool pads
•Chemical oven pads or aerosols
•Rust removers
•Bath/Sink stain removers
Oven Cavity
The enamelled oven cavity is best cleaned whilst
the oven is still warm.
Wipe the oven over with a soft cloth soaked in
warm soapy water after each use. From time to
time it will be necessary to do a more thorough
cleaning, using a proprietary oven cleaner.
Hob
After every use wipe with a soft cloth well wrung
out in warm water to which a little washing up
liquid has been added, avoiding any leakage
through the holes of the hob. Rinse and dry with a
soft cloth.
To remove more stubborn stains, wet and leave to
dissolve, do not scratch and avoid the use of
abrasive or caustic products that could damage
the enamel.
Burners
The burner caps and crowns can be removed for
cleaning. Wash the burners caps and crowns using
hot soapy water, and remove marks with a mild
paste cleaner. A well-moistened soap impregnated
steel wool pad can be used with caution, if the
marks are particularly difficult to remove.
After cleaning, be sure to wipe dry with a soft
cloth.
Cleaning the oven door
For a more complete cleaning of the oven door, it
is advisable to remove it in the following way;
-Open the door completely.
-Lift the two locking plates on the hinge arms
to 170°;
-Partially close the door, to a 30oangle
-Lift the door and pull out.
locking plates
Refit the door by reversing the operation
described above.

14
DO NOT clean the oven door while the
glass panels are warm. If this precaution is
not observed the glass panel may shatter. If
the door glass panel becomes chipped or has
deep scratches, the glass will be weakened
and must be replaced to prevent the
possibility of the panel shattering.
Contact your local Service Centre who will be
pleased to advise further.
OVEN BULB REPLACEMENT
Ensure that the appliance is switched off
and disconnected from the electricity supply
before replacing the bulb to avoid possibility
of an electric shock.
If the oven bulb needs replacing, it must comply
with the following specifications:
Wattage: 25W
Voltage: 230/240V(50Hz)
Temperatures: 300ºC
Thread Type: E14
To replace the faulty bulb.
1. Turn the glass cover anticlockwise and
remove.
2. Remove the faulty bulb by turning it anti-
clockwise and replace with a new one.
3. Refit the glass cover.
Reconnect the appliance to the electricity supply.

15
SOMETHING NOT WORKING
If the appliance is not working correctly, please carry out the following checks, before contacting your
local Service Force Centre.
IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by
incorrect use or installation, a charge will be made even if the appliance is under guarantee.
Symptoms Solutions
1. No burner ignition
2. The gas ring burns unevenly
3. One of the oven or grill burners does not
ignite
4. Cooking results are not satisfactory
5. Cooking time is too long
6.The oven smokes
Check that:
•Gas supply is completely open
•The position of gas pipe is correct
•The burner is not wet
•The burner cap and ring burner have been
replaced correctly after cleaning
Check that:
•The main jet is not blocked and the ring
burner is clean of food particles
•The burner cap and ring burner have been
replaced correctly after cleaning
Check that:
•The burner is in its correct place
•The burner is not wet
•The control knob has been pressed for 10
seconds upon ignition
Check that:
•The correct temperature has been selected
•The cooking time is adapted
•The grill is placed correctly in the oven
Check that:
•The temperature is correct for the type of
food to be cooked.
Check that:
•The oven does not need cleaning
•The food does not spill over
•There is no excessive fat / juice on the oven
sides
•Check the fuses.
If after these checks, the appliance still does not operate correctly, contact your local Service Force
Centre. When you contact the Service Force Centre you will need to give the following details:
1. Your name, address and post code.
2. Your telephone number
3. Clear and concise details of the fault
4. The model and serial number of the appliance (found on the rating plate*)
5. The purchase date
* The rating plate can be found on the lower left hand corner of the front frame of the cavity.
Please note that a valid purchase receipt or guarantee documentation is required for in-
guarantee service calls.

16
SERVICE AND SPARE PARTS
In the event of your appliance requiring service, or if you wish to purchase spare parts, please contact
your local Service Force Centre by telephoning:-
08705 929929
Your telephone call will be automatically routed to the Service Force Centre covering your post code
area.
For the address of your local Service Force Centre and further information about Service Force,
please visit the website at www.serviceforce.co.uk
In-guarantee customers should ensure that the checks under the heading “Something Not
Working” have been made as the engineer will make a charge if the fault is not a mechanical or
electrical breakdown. Please note that it will be necessary to provide proof of purchase for any
in-guarantee service calls.
CUSTOMER CARE
For general enquiries concerning your Parkinson Cowan appliance and or for further information on
our products, contact our Customer Care Department by letter or telephone as follows:
Customer Care Department
Parkinson Cowan
55-77 High Street
Slough
Berkshire SL1 1DZ
Tel: [phone] (*)
(*) calls to this number may be recorded for training purposes.

17
GUARANTEE CONDITIONS
Standard Guarantee Conditions
We Parkinson Cowan undertake that if, within 12 months of the date of the purchase, this Parkinson
Cowan appliance or any part thereof is proved to be defective by any reason only of faulty
workmanship or materials, we will, at our option, repair or replace the same FREE OF ANY CHARGE
for labour, materials or carriage on condition that:
•The appliance has been correctly installed and used only on the electricity supply stated on the
rating plate.
•The appliance has been used for normal domestic purposes only, and in accordance with the
manufacturer's instructions.
•The appliance has not been serviced maintained, repaired, taken apart or tampered with by any
person not authorised by us.
•All service work under this guarantee must be undertaken by a Parkinson Cowan Service Force
Centre.
•Any appliance or defective part replaced shall become the Company's property.
•This guarantee is in addition to your statutory and other legal rights.
Home visits are made between 8.30am and 5.30pm Monday to Friday. Visits may be available
outside these hours, in which case a premium will be charged.
Exclusions
This guarantee does not cover:
•Damage or calls resulting from transportation, improper use or neglect, the replacement of any light
bulbs or removable parts of glass or plastic.
•Costs incurred for calls to put right an appliance which is improperly installed or calls to appliance
outside the United Kingdom.
•Appliances found to be in use within a commercial or similar environment, plus those, which are
the subject to rental agreements.
Products of Parkinson Cowan manufacture which are not marketed by Parkinson Cowan.
European Guarantee
If you should move to another country within Europe then your guarantee moves with you to your new
home subject to the following qualifications:
•The guarantee starts from the date you first purchased your product.
•The guarantee is for the same period and to the same extent for labour and parts as exist in the
new country of use for this brand or range of products.
•This guarantee relates to you and cannot be transferred to another user.
•Your new home is within the European Community (EC) or European Free Trade Area.
•The product is installed and used in accordance with our instructions and is only used
domestically, i.e. a normal household
•The electrical supply complies with the specification given in the rating label.
•The product is installed taking into account regulations in your new country.
Before you move, please contact your nearest Customer Care Centre, listed below, to give them
details of your new home. They will then ensure that the local Service Organisation is aware of your
move and able to look after you and your appliances.
France Senlis [phone]
Germany Nürnberg [phone]
Italy Pordenone [phone]
Sweden Stockholm [phone]
UK Slough [phone]

18
INSTRUCTIONS FOR THE INSTALLER
TECHNICAL FEATURES
Free standing Class 1
Hob Lid
Pan support
Front right burner
Back right burner
Front left burner
Back left burner
Hob ignition
Painted
Enamelled
Semirapid
Semirapid
Rapid
Auxiliary
2000 W
2000 W
3000 W
1000 W
Spark
Oven Oven
Oven burner power
Grill
Grill burner power
Oven lamp
Oven ignition
Cleaning
Gas
3000 W
Gas
2000 W
Lamp 25W type E14
Spark
Manual
Cavity dimensions Height
Width
Depth
Oven volume
267 mm
405 mm
381 mm
41,2 l
Accessories Oven shelf
Roasting tray
Roasting grid +2 handles
Grill deflector
Dimensions Height
Width
Depth
900 mm
500 mm
600 mm
This appliance complies with the following EEC
Directives :
93/68 ; 73/23 (Low Voltage Directive) and
subsequent modifications,
89/336, 90/31, 93/68 (Electro- magnetical
Compatibility Directive) and subsequent
modifications,
90/396 (Gas Appliance Directive) 93/68
(General Directives) and subsequent
modifications.

19
ADVICE FOR SAFETY
Gas connections
•Before installation ensure that the local
distribution conditions (gas type and
pressure) and the pre-setting of the
appliance are consistent.
•This appliance must be installed only in a
room with good ventilation.
•This appliance must not connected to a
chimney. It has to be installed and connected
in accordance with the rules in force. Special
attention should be paid to the applicable
disposal concerning ventilation.
•The adjacent furniture panels have to be heat
proof or protected by such material.
•The adjusting conditions of this appliance are
mentioned on the rating plate.
Connection to gas supply.
Check that the gas flow and the diameter of the
supply pipe is sufficient to supply all the
appliances of the installation.
•Check that all connections are tight.
•Install an accessible and visible gas tap to
isolate the appliance.
The manufacturer declines any
responsibility for possible damages resulting
from an installation which doesn't comply
with current legislation.
-Installation of flues and ventilation for
gas appliances of rated input not
exceeding 60 kW (1st, 2n
d
and 3r
d
family
gases) – Part 2 Specification for
installation of ventilation for gas
appliances – BS 5440;
-Gas burning appliances – Part 3
Domestic cooking appliances burning
gas – BS 5386;
-Specification for installation of low
pressure gas pipe work of up to 20mm
(R1) in domestic premises (2n
d
family
gas) – BS 6891;
-Pipe threads for tubes and fittings where
pressure-tight joints are made on the
threads (metric dimensions) – BS 21:
1985;
-Flexible hoses, end fittings and sockets
for gas burning appliances – BS 669;
-Installation of domestic gas cooking
appliances (1st, 2nd and 3rd family gases) –
BS 6172: 1990;

20
Electrical connections
Any electrical work required to install
this cooker should be carried out by a
qualified electrician or competent person, in
accordance with the current regulations.
THIS COOKER MUST BE EARTHED.
The manufacturer declines any liability
should these safety measures not be
observed.
This cooker is designed to be connected to a
230-240V AC 50Hz electrical supply.
Before switching on, make sure the electricity
supply voltage is the same as that indicated on
the cooker rating plate.The rating plate is located
on the oven frame.
The cooker is supplied with a 3 core flexible
supply cord incorporating a 13amp plug fitted. In
the event of having to change the fuse, a 13amp
ASTA approved (BS 1362) fuse must be used.
Should the plug need to be replaced for any
reason, the wires in the mains lead are coloured
in accordance with the following code:
Green and Yellow - Earth
Blue - Neutral
Brown - Live
- Connect the green and yellow (earth) wire to
the terminal in the plug which is marked with
the letter 'E' or the earth symbol or
coloured green and yellow.
- Connect the blue (neutral) wire to the
terminal in the plug which is marked with the
letter 'N' or coloured black.
- Connect the brown (live) wire to the terminal
in the plug which is marked with the letter 'L'
or coloured red.
NOTE: The earth wire should be about 2 cm
longer than the live and neutral wires.
Upon completion there must be no cut, or stray
strands of wire present and the cord clamp must
be secure over the outer sheath.
A cut off plug inserted into a 13 amp
socket is a serious safety (shock) hazard.
Ensure that the cut off plug is disposed of
safety.
Before connecting check that:
•The plug used for connection is easily
accessible when the appliance is installed.
Permanent Connection
In the case of a permanent connection, it is
necessary that you install a double pole switch
between the cooker and the electricity supply
(mains), with a minimum gap of 3mm, between
the switch contacts and of a type suitable for the
required load in compliance with the current
electric regulations.
The switch must not break the yellow and green
earth cable at any point.
Ensure that the cooker supply cord does
not come into contact with surfaces with
temperatures higher than 50 deg. C .
