Parkside PMML 5 A1 User manual

IAN 319468
MULTI-PURPOSE DETECTOR/
LASER DISTANCE MEASURER PMML 5 A1
MULTIFUNKTIONSDETEKTOR /
LASERENTFERNUNGSMESSER
Bedienungs- und Sicherheitshinweise
MULTI-PURPOSE DETECTOR/
LASER DISTANCE MEASURER
Operation and safety notes
MULTIFUNKČNÝ DETEKTOR/
LASEROVÝ MERAČ VZDIALENOSTI
Pokyny pre obsluhu a bezpečnostné pokyny
MULTIFUNKČNÍ DETEKTOR/
LASEROVÝ MĚŘIČ VZDÁLENOSTI
Pokyny pro obsluhu a bezpečnostní pokyny
MULTIFUNKCIÓS DETEKTOR/
LÉZERES TÁVOLSÁGMÉRŐ
Kezelési és biztonsági utalások

GB Operation and safety notes Page 5
HU Kezelési és biztonsági
utalások Oldal 47
CZ Pokyny pro obsluhu a
bezpečnostní pokyny Strana 88
SK Pokyny pre obsluhu a
bezpečnostné pokyny Strana 127
DE/AT/CH Bedienungs- und
Sicherheitshinweise Seite 168

2
11a
12
11
10
3
4
6
5
8
9
7
A
13
14
B
13a
14

C
D
E
1615
17 18
20
21
19
22
23
24
25
26
27
28

5GB
List of pictograms
used..........................................Page 7
Introduction.......................Page 8
Intended use............................Page 8
Description of parts.................Page 9
Technical data.........................Page 10
Scope of delivery....................Page 12
Safety instructions.......Page 13
General safety information.....Page 13
Information regarding
inaccurate measurement
results.......................................Page 17
Safety instructions for
batteries/rechargeable
batteries...................................Page 18
Before using......................Page 20
Preparing for use .........Page 21
Inserting/replacing the
batteries (see fig. A)................Page 21
Use............................................Page 22
Tip for distance measurement ...Page 22
Single distance measurement
mode........................................Page 23
Continuous distance
measurement mode.................Page 25
Addition of distances ..............Page 27

6 GB
Measuring surface areas........Page 28
Addition of surface areas.......Page 29
Measuring volumes.................Page 30
Addition of volumes ................Page 31
Locating concealed objects....Page 32
Tips on measurement ..............Page 33
Locating wooden objects........Page 37
Laser marking..........................Page 37
Troubleshooting ............Page 39
Maintenance and
cleaning................................Page 40
Storage .................................Page 41
Disposal................................Page 41
Service...................................Page 43
Warranty claim procedure.....Page 43
Service .....................................Page 44
Warranty.............................Page 45

7GB
List of pictograms used
Please read the
instructions for use.
Danger of explosion!
Wear safety gloves!
Attention! - The manual
must be consulted in all
cases where this symbol
is marked.
Protect yourself from
laser radiation!
Volt (Direct current)
Volt (Alternating current)
Batteries included

8 GB
Multi-Purpose Detector /
Laser Distance Measurer
Introduction
We congratulate you on the purchase of
your new product. You have chosen a
high quality product. The instructions for
use are part of the product. They contain
important information concerning safety,
use and disposal. Before using the prod-
uct, please familiarise yourself with all of
the safety information and instructions for
use. Only use the product as described
and for the specified applications. If you
pass the product on to anyone else,
please ensure that you also pass on all
the documentation with it.
Intended use
This product is intended for the detection
of metal, wood and live wires. The prod-
uct is not intended for commercial use.
This product is for indoor use only.

9GB
Description of parts
1Hanging point
1a Measurement starting edge
2Display
3Material switch STUD/ AC WIRE/
METAL (wood/ AC wire /metal)
4MODE button
5Stud button
6READ button
7M button (save)
8Vial
9Function switch LASER/DETECTOR/
DISTANCE
10 RM button (read memory)
11 Stud button
12 +/=-button
13 Battery compartment
13a Battery compartment cover
14 PUSH button
15 Laser beam opening/Laser sender
16 Laser receiver
LC Display (see fig. D):
17 Mode arrow
18 Battery symbol
19 High voltage warning symbol

10 GB
20 Upper row
21 Lower row
22 Measurement units
23 Detecting intensity arrow
24 Saving symbol M+
25 Distance measuring reference point
26 Laser symbol
27 Measuring mode indication symbol
28 Addition symbol “+”
Technical data
Laser distance
measurement
Detects: Wood,
AC wires, metal
Laser class: 2
Max. power
output (Pmax): < 1mW
Wave length: 635–660nm
Power supply: 2 x AAA
(2 x 1.5V)
batteries
Maximum
measuring range: 0.175–20 meter*
(measure from
bottom side)
