Parmco HX-1-6NF-CER User manual

Installation
and Operating
Instructions
Model:
HX-1-6NF-CER
HX-1-6S-CER
For your convenience, we recommend to attach
the serial number label HERE.
727626032017

Dear Valued Customer,
Thank you and congratulations on purchasing your new Parmco appliance.
All Parmco products are made to the highest quality and design standards. We are
sure you will enjoy your new appliance.
As a note, please read through these instructions carefully. These will assist you
appliance. Please take special note of all detailed technical information and installation
instructions. It is essential that you follow these instructions to ensure the safety
and reliability of this appliance.
future warranty claims lodged, so please check with Parmco Appliances before any
installation is carried out.
this product or any other products in Parmco’s extensive range, visit us online at
www.parmco.co.nz.
Regards,
The Parmco Team

INDEX
Important Safety Warnings
2
Product overview
5
Top view
5
Control panel
5
Before using your Ceramic Hob
6
Using your Ceramic Hob
7
To start cooking
7
When you have finished cooking
7
Cooking guidelines
8
Heat sengs
9
Care and cleaning
10
Troubleshoong
11
Technical Specificaons
12
Installaon
13

3
17. Aer use switch offthe hob element at its control.
Other Safety Precauons
Your safety is important to us. Please read this informaon before using your cooktop.
•No combusble material or products should be placed on this appliance at any me.
•In order to avoid a hazard, this appliance must be installed by an authorised electrician
according to these instrucons.
•This appliance should be connected to a circuit which incorporates an isolang switch
providing full disconnecon from the power supply.
•Failure to install the appliance correctly could void the warranty or liability claims.
Installaon
Electrical Shock Hazard
•Disconnect the appliance from the mains electricity supply before carrying out any work
or maintenance on it.
•Connecon to a good earth wiring system is mandatory.
•Alteraons to the domesc wiring system must only be made by a qualified electrician.
•Failure to follow this advice may result in electrical shock or death.

4
Operaon and Maintenance Precauons
Hot Surface
•During use, accessible parts of this appliance may become hot enough to cause burns.
•Do not let your body, clothing or any item other than suitable cookware contact the glass
unl the surface is cool.
•Never leave metal objects (such as kitchen utensils) or empty pans on the cooktop as they
can become hot very quickly.
•Failure to follow this advice could result in burns and scalds.
General precauons
•Never leave the appliance unaended when in use. Spillovers can cause smoking and
greasy spillovers may ignite.
•Never use your appliance as a work or storage surface.
•Never leave any objects or utensils on the appliance.
•Never use your appliance for warming or heang the room.
•Aer use, always turn offthe cooking zones and the cooktop as described in this manual
(i.e. by using the touch controls).
•Do not repair or replace any part of the appliance unless specifically recommended in the
manual. All other servicing should be done by a qualified technician.
•Do not use a steam cleaner to clean your cooktop.
•Do not place or drop heavy objects on your cooktop.
•Do not stand on your cooktop.
•Do not use pans with jagged edges or drag pans across the glass surface as this can
scratch the glass.
•Do not use scourers or any other harsh abrasive cleaning agents to clean your cooktop, as
these can scratch the glass.

5
Product Overview
Top View Knob Controls
Control Panel

6
Before using your Ceramic Hob
•Read this guide, taking special note of the ‘Safety Warnings’ secon.
•Remove any protecve film that may sll be on your ceramic hob.
Note: you may noce a lile smoke when you turn the hob on for the first me. The smoke is due
to the manufacturing residues le on the hob.
Choosing the right Cookware
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the
cooking zone. Always centre your pan on the cooking zone.
Always li pans offthe ceramic hob – do not slide, as they may scratch the glass.

7
Using your Ceramic Hob
To start cooking
1. Turn on power supply to the hob.
2. Place a suitable pan on the cooking zone you wish to use.
•Make sure the boom of the pan and the surface
of the cooking zone are clean and dry.
3. Turn the associated knob clockwise to turn on the cooking zone.
When you have finished cooking
1. Turn the associated knob to the “0” (OFF) posion.
Note: the cooking zone will remain hot for a lile while aer it has been turned off.
A residual heat indicator will light up unl the cooking zone temperature has dropped to
a safe level.
Note: the cooking zone will remain warm aer the residual heat indicator is no longer
illuminated. Please take care.

8
Cooking Guidelines
Cooking Tips
•When food comes to the boil, reduce the temperature seng.
•Using a lid will reduce cooking mes and save energy by retaining the heat.
•Minimize the amount of liquid or fat to reduce cooking mes.
•Start cooking on a high heat seng then reduce the heat once the food has heated through.
Simmering, cooking rice
•Simmering occurs below boiling point, at around 85˚C, when bubbles are just rising occasionally
to the surface of the cooking liquid. It is the key to delicious soups and tender stews as the
flavours develop without overcooking the food.
•Some items, including cooking rice by the absorpon method, may require a seng higher than
the lowest seng to ensure the food is cooked properly in the me recommended.
Searing steak
To cook juicy steaks:
1. Stand the meat at room temperature for about 20 minutes before cooking.
2. Heat up a heavy-based boom frying pan.
3. Brush both sides of the steak with oil. Drizzle a small amount of oil into the hot pan and then
lower the meat onto the pan.
4. Turn the steak only once during cooking. The exact cooking me will depend on the thickness of
the steak and the desired degree of cooking. Times may vary between 2 – 8 minutes per each
side. Press the steak to gauge how cooked it is – the firmer it feels the more ‘well done’ it will
be.
5. Leave the steak to rest on a warm plate for a few minutes before serving.
Sr-frying
1. Choose a ceramic compable flat-based wok or a large frying pan.
2. Have all the ingredients and equipment ready. Sr-frying should be quick. If cooking large
quanes, cook the food in several smaller batches.
3. Preheat the pan briefly and add two tablespoons of oil.
4. Cook any meat first, then put it aside and keep warm.

9
5. Sr-fry the vegetables. When they are hot but sll crisp, turn the cooking zone to a lower seng,
return the meat to the pan and add your sauce.
6. Sr the ingredients gently unl they are heated through. Serve immediately.
Heat Sengs
The sengs below are guidelines only. The exact seng will depend on several factors, including
your cookware and the amount you are cooking. Experiment with the cooktop to find the sengs
that best suit you.
Heat seng Suitability
1 - 2 •delicate warming for small amounts of food
•melng chocolate, buer, and foods that burn quickly
•gentle simmering
•slow warming
3 - 4 •reheang
•rapid simmering
•cooking rice
5 - 6 •pancakes
7 - 8 •sautéing
•cooking pasta
9•sr-frying
•searing
•bringing soup to the boil
•boiling water

10
Care and Cleaning
What?
How?
Important!
Everyday soiling
on glass
(fingerprints,
marks, stains le
by food or
non-sugary
spillovers on the
glass)
1. Switch offthe power to
the cooktop at the wall.
2. Apply a non-abrasive
ceramic cleaner while
the glass is sll warm
(but not hot!), or simply
wipe clean with a so
cloth and lukewarm
water.
3. Rinse and wipe dry with
a so clean cloth or
paper towel.
4. 4. Switch the power to
the cooktop back on.
•When the power to the cooktop
is switched off, there will be no
‘hot surface’ indicaon but the
cooking zone may sll be hot!
Take extreme care.
•Heavy-duty scourers, some nylon
scourers and harsh/abrasive
cleaning agents may scratch the
glass. Always read the label to
check if the cleaner or scourer is
suitable.
•Never leave cleaning residue on
the cooktop: the glass may
become stained.
Boil-overs, melts,
and hot sugary
spills on
the glass
Remove these immediately
with a scraper suitable for
ceramic glass cooktop, being
careful of hot cooking zone
surfaces.
1. Switch offthe power to
the cooktop at the wall.
2. Hold the blade or utensil
at a 30° angle and scrape
the soiling or spill to a
cool area of the cooktop.
3. Clean the soiling or spill
up with a dish cloth or
paper towel.
4. Follow steps 2 to 4 for
‘everyday soiling on
glass’ above.
•Remove stains leby melts and
sugary food or spillovers as soon
as possible. If leto cool on the
glass, they may be difficult to
remove or even damage the glass
surface.
•Cut hazard: The scraper blade is
razor-sharp.
Use with extreme care and always
store safely and out of reach of
children.
Spillovers on the
knob controls
1. Switch offthe power to
the cooktop at the wall.
2. Soak up the spill
3. Wipe around the knob
control area with a clean
damp sponge or cloth.
(Remove the knob if
required).
4. Wipe the area
completely dry with a
socloth or paper
towel.
5. 5. Switch the power to
the cooktop back on.
•If you remove the knob, ensure
no fluid has moved past the rubber
seal around the knob sha.
•Also check that the rubber seal i
intact.

11
Trouble Shoong
Problem Possible causes What to do
The cooktop
cannot
be turned on.
No power.
Make sure the cooktop is
connected to the power supply
and that it is switched on.
Check whether there is a power
outage in your home or area.
If you’ve checked everything and
the problem persists, call a
qualified technician.
The glass is being
scratched.
Rough-edged cookware.
Cookware dragged across the
cooktop surface.
Unsuitable, abrasive scourer
or cleaning products being
used.
Use cookware with flat and
smooth bases. See ‘Choosing the
right cookware’ secon.
See ‘Care and cleaning’ secon.
Some pans make
crackling or
clicking noises.
This may be caused by the
construcon of your
cookware
(layers of different metals
vibrang differently once
heated).
This is normal for cookware and
does not indicate a fault.
There is smoke
when the hob is
turned on.
This is normal when the hob
is turned on for the first
me.
Turn the hob off, let it cool and
wipe it down with lukewarm
water and socloth to remove all
manufacturing residues.

12
Technical Specificaon
Model HX-1-6NF-CER & HX-1-6S-CER
Cooking Zones 4 Zones
Supply Voltage 220-240V~ 50Hz
Power 1200W (145mm)
1800W (180mm)
Product Size L×W×H(mm) 590x520x76mm
Cut-out Dimensions (A x B) 494(W) x 564(L) mm
Dimensions are approximate. Because we connually strive to improve our products we may
change specificaons and designs without prior noce.
HX-1-6S-CER
580x510x76mm HX-1-6NF-CER

13
Installaon
Selecon of installaon equipment
Cut out the work surface according to the sizes shown in the drawing.
For the purpose of installaon and use, a minimum of 50mm space shall be preserved
around the hole.
Be sure the thickness of the work surface is at least 40-50mm. Please select
heat-resistant work surface material to avoid larger deformaon caused by the heat
radiaon from the hotplate.
When installing the hob over drawers, a board must be installed 10mm underneath the
hob. The board must be made of suitable heat resistant materials.
A B C D E F
564mm 494mm 50mm min 50mm min 50mm min 50mm min
Make sure the hob is well venlated and the air inlet and outlet are not blocked.
Dear Installer:
Please affix data label provided on the adjacent cupboard near
the appliance for future reference. Thank you.
564mm (A)
494mm (B)
50mm mini
(D)
50mm mini
(C)
50mm mini
(F)
50mm mini
(E)

14
Note: The safety distance between the ceramic hob and the cupboard above it or
rangehood should be at least 650mm.
A(mm) B(mm) C(mm) D E
650 min 50 min 50 min Air intake Air exit 10 mm
When installing a rangehood above an appliance, all
relevant/current New Zealand building, installaon and
regulaon standards must be adhered to.

15
Inserng and fixing the hob
Before inserng the hob into the work surface, place the adhesive seal around the underside edge
of the hob. It is important to fix the seal evenly without gaps, to prevent liquids from seeping
underneath the hob.
1. Turn the hob upside down (ensure the surface will not scratch the ceramic glass).
2. Place the gasket around the boom edge of the hob.
3. Screw one end of the fixing brackets into the holes on the underside of the hob.
4. Place the hob into the work surface cutout, so it is sing firmly on the surface.
5. Adjust the posion of the brackets to suit the thickness of the work surface.
6. Screw the hob to the underside of the work surface using the other end of the fixing
brackets already aached to the hob.
Cauons
•The hob must be installed by qualified personnel. Never conduct the operaon by
yourself.
•The hob shall not be mounted to cooling equipment, dishwashers and rotary dryers.
•The wall and induced heang zone above the work surface shall withstand heat.
•To avoid any damage, the benchtop and adhesive must be resistant to heat.
•A steam cleaner is not to be used for cleaning the product.
1-worktop
2
13
4
5
2-screw
3-bracket
4-hob
5-hob seal
a
Worktop
Fixing bracket
Screw Ventilation slot ≥ mm30
15
MIN

16
Connecng the hob to the mains power supply
The power supply should be connected in compliance with the relevant local standards.
1. If the cable is damaged or needs replacing, the operaon must be carried out by a
qualified technician with dedicated tools to avoid any accidents.
2. The installer must ensure that the correct electrical connecon has been made and that it
is compliant with safety regulaons.
3. The cable must not be bent or compressed.
4. The installer must use the supplied power cord.
Recommended
type of
connection lead
CONNECTION DIAGRAM
Caution! Voltage of heating elements 220-240V
Caution! In the event of any connection the safety
Wire must be connected to the E terminal.
For 220-240V earthed one-phase connection, bridges
connect L terminals and terminals, safety wire to
E
N
L①
②
④
⑤
①
②
④
⑤
TERMINAL BOARD
WARNING
Close the cable clamp after making the
electrical connection. Close the
terminal board cover by twisting it down.

17
Disposal
DISPOSAL: Do not dispose this
product as unsorted municipal
waste. Collecon of such waste
separately for special treatment is
necessary.
This appliance is labeled in compliance with European direcve 2012/19/EU for
Waste Electrical and Electronic Equipment (WEEE). By ensuring that this
appliance is disposed of correctly, you will help prevent any possible damage to
the environment and to human health, which might otherwise be caused if it
were disposed of in the
wrong way.
The symbol on the product indicates that it may not be treated as normal
household waste. It should be taken to a collecon point for the recycling of
electrical and electronic goods.
This appliance requires specialist waste disposal. For further informaon
regarding the treatment, recovery and recycling of this product please contact
your local council, your household waste disposal service, or the shop where you
purchased it.
